Repetition of chemistry from a recently retracted paper. A cautionary note

Article abstract of DOI:10.1016/j.tetlet.2018.05.042

The base-catalyzed condensation reaction between (E)-4-phenylbut-2-enal and phenylpropargyl aldehyde recently reported in the literature to provide formylcyclobutadiene was repeated under the published conditions. The product obtained was identified as (E)-5-phenyl-2-((E)-styryl)pent-2-en-4-ynal rather than the reported 2-phenyl-3-styrylcyclobutadiene-1-carboxaldehyde. The structure assignment is supported by NMR and IR data and a x-ray structure of the crystalline alcohol obtained by Luche reduction.

Full text of DOI:10.1016/j.tetlet.2018.05.042

Accepted Manuscript
Repetition of chemistry from a recently retracted paper. A cautionary note
Wilson Ryan, Korey Bedard, Daler Baidilov, Marcus Tius, Tomas Hudlicky
PII:
S0040-4039(18)30656-7
https://doi.org/10.1016/j.tetlet.2018.05.042
TETL 49989
DOI:
Reference:
Tetrahedron Letters
To appear in:
Received Date:
Revised Date:
Accepted Date:
18 April 2018
15 May 2018
17 May 2018
Please cite this article as: Ryan, W., Bedard, K., Baidilov, D., Tius, M., Hudlicky, T., Repetition of chemistry from
a recently retracted paper. A cautionary note, Tetrahedron Letters (2018), doi: https://doi.org/10.1016/j.tetlet.
2018.05.042
This is a PDF file of an unedited manuscript that has been accepted for publication. As a service to our customers
we are providing this early version of the manuscript. The manuscript will undergo copyediting, typesetting, and
review of the resulting proof before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that apply to the journal pertain.

Repetition of chemistry from a recently retracted paper. A cautionary note.
Wilson Ryan,a Korey Bedard, a Daler Baidilov, a Marcus Tius b and Tomas Hudlicky a*
a. Department of Chemistry and Centre for Biotechnology, Brock University,
1812 Sir Isaac Brock Way, St. Catharines, ON L2S 3A1, Canada
thudlicky@brocku.ca
b. Department of Chemistry, University of Hawaii at Manoa, 2545 McCarthy Mall
Honolulu, HI 96822-2275
Abstract. The base-catalyzed condensation reaction between (E)-4-phenylbut-2-enal and
phenylpropargyl aldehyde recently reported in the literature to provide
formylcyclobutadiene was repeated under the published conditions. The product obtained
was identified as (E)-5-phenyl-2-((E)-styryl)pent-2-en-4-ynal rather than the reported 2-
phenyl-3-styrylcyclobutadiene-1-carboxaldehyde. The structure assignment is supported
by NMR and IR data and a x-ray structure of the crystalline alcohol obtained by Luche
reduction.
The strict requirements for physical reproduction of research results ensure
reproducibility and provide lasting experimental value to the community. In today’s
world of rapid and exponentially increasing rates of publication both the reproducibility
of results and the overall value to the permanent record are jeopardized. In addition,
characterization of compounds, often incomplete, at small scales can (and does) lead to
problems in structure assignments.
In August 2017 a paper published in Org. Lett.1 reported the synthesis of a series of
cyclobutadienes, as shown in Figure 1. One of us (MT) was struck by the implausibility
of the cyclobutadiene enal structures. Even if the anti-aromatic compounds had been
prepared, the highly reactive formylcyclobutadiene would surely not have survived for
long. Also, the 13C NMR spectra reported for the cyclobutadiene products contained
signals a 109.62 and 86.91 ppm (compound 3aa) that would be more appropriately
assigned to disubstituted alkynes rather than to cyclobutadienes.
In addition, the anti-aromatic cyclobutadienes are not stable unless coordinated to metals
(this fact was also mentioned and referenced by the authors)2 and these observations led

to our questioning of the reported results. We decided to repeat the chemistry and provide
experimental validation of the products.
Figure 1. Reported synthesis of cyclobutadienes.1
While we were repeating the experimental protocol the above paper was retracted3 in
13
December 2017, citing as the reason inadequate characterization of the products by C
NMR. We continued our work and have completed the project for reasons of academic
interest and also to provide the results in this short note that should serve as a cautionary
reminder to authors and referees of the importance of validating chemical structures with
complete experimental and spectral data sets.
In our repetition we chose the substrates shown in Figure 1 and obtained aldehyde 4 in
58% yield [the reported yield in the literature for compound 3aa was 58% under the
conditions shown in Figure 1]. Under different conditions and with a different
organocatalyst (one derived from proline) the authors reported a yield of 87% for 3aa.
Figure 2. Repetition of the condensation reaction of 1 and 2.
Reduction of this somewhat unstable aldehyde provided alcohol 5 [white needles, mp
119-120 °C, EtOH:H2O, 75:25] whose structure, along with that of aldehyde 4, was
validated by detailed NMR analysis (See the Supplemental Information Section for data).
Both compounds showed acetylene absorptions in the IR spectrum (4 at 2183 cm-1 and 5
at 2030 cm-1). IR analysis was not reported in the Experimental Section of the original
paper and this fact alone would have cast doubt on the assignment of products as
cyclobutadienes as the IR absorptions clearly indicate the presence of an acetylene.

13
Figure 3 shows the C NMR data for compound 4 as obtained by us compared with the
13C NMR published data of 3aa. Although the signal for one carbon atom is missing in
the published spectrum it is clear that the two compounds are identical.
Figure 3. Comparison of 13C NMR spectrum of 4 with that of compound 3aa as reported
in the literature.1 (Scale of our spectrum (see SI section) was adjusted for comparison.)
Alcohol 5 was converted to its p-bromobenzoate in an effort to produce crystalline
material for x-ray analysis, however, the ester was a low melting solid. Finally, suitable
crystals for x-ray analysis were obtained from alcohol 5, as shown in Figure 4.4
The take home lesson form this exercise is clear: more attention should be paid to the
reported experimental data and their integrity. It should have been noticed by the referees
that the authors did not obtain/report IR spectra for any of the compounds. Relying solely
on NMR and MS data is obviously insufficient. While we repeated only the synthesis of
the presumed 3aa it is likely that none of the other compounds reported are
13
cyclobutadienes, as evidenced by the signals (corresponding to acetylenes) in their C
NMR spectra. Perhaps a more rigorous attention to review may eliminate similar

occurrences in the future. We enjoyed this particular exercise but one has to wonder how
many other erroneous results are contained in today’s literature.
Figure 4. X-ray structure of 5.
Acknowledgements. We are grateful to the following agencies for financial support of
this work: Natural Sciences and Engineering Research Council of Canada (NSERC) (Idea
to Innovation and Discovery Grants), Canada Research Chair Program, Canada
Foundation for Innovation (CFI), TDC Research, Inc., TDC Research Foundation.
Supplemental Information Section: Experimental and spectral data for the synthesis
and characterization of compounds 4, and 5.
References
1.Li, W.; Lang, M.; Wang, J. Org. Lett. 2017, 19, 4564.
2.(a) Emerson, G. F.; Watts, L.; Pettit, R. J. Am. Chem. Soc. 1965, 87, 131; (b) Watts, L.;
Fitzpatrick, J. D.; Pettit, R. J. Am. Chem. Soc. 1965, 87, 3253; (c) Rosenblum, M.;
Gatsonis, C. J. Am. Chem. Soc. 1967, 89, 5074; (d) Sekiguchi, A.; Tanaka, M.; Matsuo,
T.; Watanabe,
H. Angew. Chem., Int. Ed. 2001, 40, 1675.
3. Li, W.; Lang, M.; Wang, J. Org. Lett. 2018, 20, 316.
4. While this work was being completed a recent publication also reported the synthesis
of enal 4 obtained by repetition of the work in reference 1: Riveira, M. J.; Sarotti, A.M.
Org. Biomol. Chem. 2018, 16, 1442. The structure was elucidated by NMR methods only.
The unambiguous assignment of the alcohol 5 by x-ray is provided in this work, which
was submitted originally to Org. Lett. but was rejected by the Editor without external
review.

Highlights



Repetition of published work
Correction of reported results
Organocatalyzed dehydrative aldol reaction
