Hydrothermal syntheses, crystal structures, and photophysical
properties of two 2D coordination polymers with mixed Ligands
Li Yan*1,2, Chun-Ling Liu1,2
1. Key Laboratory of Preparation and Applications of Environmental Friendly Materials, Ministry
of Education, Jilin Normal University, Siping, 136000, People’s Republic of China
2. College of Chemistry, Jilin Normal University, Siping, 136000, People’s Republic of China
Abstract
Two novel metal-organic coordination polymers [Cd(ipdt)(m-BDC)·3H2O]n (1) and
[Pb(mip)2(NTC)
·2H2O]n
(2)
[ipdt
mip
=
=
2,6-Dimethoxy-4-(1H-1,3,7,8-tetraaza-
2-(3-methoxyphenyl)-1H-imidazo[4,5-
cyclopenta[l]phenanthren-2-yl)-phenol,
f][1,10]phenanthroline, m-BDC = isophthalic acid, NTC = nicotinic acid] have been synthesized
by hydrothermal reactions and characterized by elemental analysis, thermogravimetric (TG)
analysis, infrared spectrum (IR) and single-crystal X-ray diffraction. Single-crystal X-ray
diffraction reveals that 1 exhibits two-dimensional (2D) layer architecture, and 2 shows 1D chain
architecture. TG analysis shows clear courses of weight loss, which corresponds to the
decomposition of different ligands. The luminescent properties for the ligand ipdt, mip and
complexes 1-2 are also discussed in detail, which should be acted as potential luminescent
material.
Keywords Cadmium, Lead, Crystal structures, Thermal stability analysis, Fluorescence
__________________________
The project was supported by National Natural Science Foundation of China (No. 21406085), and the Science
Development Project of Jilin Province of China (20130522071JH).
Corresponding author. Li Yan, E-mail: yanli820618@163.com

ACCEPTED MANUSCRIPT
1. Introduction
During the past decades, the rational design and synthesis of novel metal-organic complexes
have attracted intense interest owing to the realization of their potential use as materials in
catalysis, porosity, sensors, magnetism, luminescence, molecular recognition and so on[1-7]. In this
aspect, considerable progress has been made on the theoretical prediction and network-based
approaches for controlling the topology and geometries of the networks to produce useful functional
materials. However, it is still a great challenge to predict the exact structures through controlling the
factors that affect the framework formation, because the formation of metal-organic complexes are
determined by several factors, such as the coordination nature of metal ions, coordination environment
of metal nodes, ligand structures, pH value, structural characteristics of the polydentate ligands,
solvents, templates, counterions, temperature and so on, may all play a role in determining the network
structure of a compound[8, 9]. Nowadays, the method of hydrothermal synthesis is widely used to
synthesis novel crystal structures, because it can solve the problems of ligands solubility and
enhance the reactivity of reactants in the crystallization process to obtain perfect crystal.
Multidentate ligands such as poly-carboxylate and N-heterocyclic ligands are widely used in the
rational design to obtain anticipant structures and desired properties[10-13]. Our strategy of rational
design and synthesis of coordination polymers is to employ a new designed long-conjugated
unsymmetrical ligand ipdt (2,6-Dimethoxy-4-(1H-1,3,7,8-tetraaza-cyclopenta[l]phenanthren-2-yl)-
phenol) and mip (2-(3-methoxyphenyl)-1H-imidazo[4,5-f][1,10]phenanthroline) (as shown in
Scheme 1): in view of the following characteristics: (1) possess extended long-conjugated
unsymmetrical aromatic system to provide supramolecular interactions; (2) possess two nitrogen
atoms, which is similar with 2,2'-bipyridyl-like bidentate chelating molecules; (3) possess strong
and rigidity of coordination ability to metal atoms. At this stage, combine N-heterocyclic ligands
and anionic O-donor as mixed ligands with metal to design various architectures should be
considered as an attractive design strategy. As far as we know, the investigation for the similar N-
heterocyclic ligands is not enough, in especially it has not been reported for using ipdt, mip,
isophthalic acid (m-BDC) and nicotinic acid (NTC) as mixed ligands to construct coordination
polymers.

ACCEPTED MANUSCRIPT
Scheme 1. The synthesis of ipdt and mip ligands
As for cadmium (II) ion, the chemistry of d10 metal clusters is of current interest not only
because of their interesting structures but also their photoluminescent[14, 15]. Up to now, the design
and control over coordination compounds is mainly focused on the incorporation of s-, d-, and
even f-block metals as coordination centers, whereas less attention has been paid to the p-block
metals despite their important applications in electroluminescent devices and fluorescent sensors.
Lead(II), as a heavy p-block metal ion, has a large radius and exhibits flexible coordination
modes, which provides unique opportunities for the construction of novel coordination networks
as well as photochemical and photo physical properties[16]
.
In this paper, we use m-BDC and NTC for the second ligands to obtain two coordination
polymers: [Cd(ipdt)(m-BDC)·3H2O]n (1) and [Pb(mip)2(NTC)·2H2O]n (2). Both of the two
complexes contain hydrogen bond interactions.
2. Experimental sections
2.1 Materials and physical measurements
The ligand ipdt and mip was prepared by the method according to the description in the
literature procedures[17]. All the other chemicals from commercial sources were of AR grade and
used without further purification. The FT-IR spectrum was recorded on an Alpha Centauri FT-IR
spectrophotometer using KBr discs in the 400-4000 cm–1 region. TG analysis was performed with
a Diamond DSC thermal analyzer at the rate of 10 °C /min rise of temperature in nitrogen

ACCEPTED MANUSCRIPT
atmosphere. Crystal structures were determined on a Bruker SMART APEX II CCD X-ray
diffractometer. Elemental analyses of C, H and N were performed on a PE-2400 elemental
analyzer. Fluorescence spectra were recorded on a FLSP 920 Edinburgh fluorescence
spectrometer.
2.2. Syntheses of 1–2
2.2.1. Synthesis of [Cd(ipdt)(m-BDC)·3H2O]n (1): A mixture of Cd(NO3)2·4H2O (0.098 g, 0.3
mmol), ipdt (0.120 g, 0.3 mmol), m-BDC (0.100 g, 0.3 mmol) and H2O (18 mL) was stirred at
room temperature and adjusted the pH value to 6.0 with NaOH. We put the cloudy solution into a
30-mL Teflon-lined stainless vessel under autogenous pressure at 433 K for 72 h, and afterwards
cooled to room temperature at a rate of 5 °C/ h. The yellow crystals of 1 were collected in 70%
yield based on Cd. C29H26CdN4O10: calcd. C 49.55, H 3.73, N 7.97%; found: C 49.84, H 3.82, N
7.91%. IR (KBr, cm–1): 3255(s), 3416(s), 1612(vs), 1521(vs), 1382(vs), 638(s), 561(m).
2.2.2. Synthesis of [Pb(mip)2(NTC)·2H2O]n(2): Complex 2 was synthesized by a procedure
similar to that used for 1 except that the mixture was adjusted the pH value to 8.5, and heated the
temperature under 453 K. Yellow crystals of 2 were collected in 85% yield based on Pb.
C46H36N9O6Pb: calcd. C 54.27, H 3.56, N 12.38%; found: C 54.35, H 3.62, N 12.52%. IR (KBr,
cm–1): 3104(s), 3006(s), 1528(vs), 1393(vs), 1188(s), 1080(s), 732(s), 621(m).
2.3 X-ray crystallography y
Single-crystal X-ray diffraction data were collected at room temperature with a Bruker
SMART APEX II CCD diffractometer equipped with a graphite-monochromatized MoKα
radiation (λ = 0.71073 Å) at 293(2) K in the range of 1.44 ≤ θ ≤ 26.08° for 1 and 1.50≤ θ ≤26.03°
for 2. Absorption corrections were applied using multi-scan technique and all the structures were
solved by direct methods with SHELXS-97[18] and refined with SHELXL-97[19] by full-matrix
least-squares techniques on F2. Non-hydrogen atoms were refined with anisotropic temperature
parameters. Experimental details for crystallographic data and structure refinement parameters for
1 and 2 are listed in Table 1.
3. Results and discussion
3.1 Description of crystal structures
3.1.1[Cd(ipdt)(m-BDC)·3H2O]n (1)
The molecular structure of complex 1 is shown in Fig. 1. The 1D double-chain structure is

ACCEPTED MANUSCRIPT
suggested in Fig. 2. The simplified 1D chain structure is suggested in Fig. 3,and the 2D layer
structure linked by C–H···O hydrogen bonds is shown in Fig. 4. Selected important bond lengths
and bond angles are given in Table 2.
As shown in Fig. 1, the asymmetric unit contains one Cd (II) atoms, one ipdt ligand, one m-
BDC ligand, and three lattice water molecules. In 1, the Cd (II) atom is hexa-coordinated with four
carboxylate oxygen atoms from three distinct m-BDC ligands, and two nitrogen atoms donors
from one chelating ipdt ligand, forming distorted octahedral geometry. The angle of O(2)–Cd(1)–
N(1), N(1)–Cd(1)–N(2), N(2)–Cd(1)–O(7), and O(7)–Cd(1)–O(2) is 87.17, 70.78, 100.60 and
102.34°, and the sum is 360.89°. For the coordination environment of Cd(1), the Cd(1), O(2),
N(1), N(2) and O(7) atoms define the basal plane, and O(1) and O(3) atoms occupy the apical
axial
positions.
The
equation
of
a
plane
is：-
4.2682(0.0456)x+7.4613(0.0390)y+13.6408(0.0151)z=8.0454(0.0107). The deviation of atoms
Cd(1), O(2), N(1), N(2) and O(7) to the plane is -0.4548, 0.2603, -0.0796, 0.2741, -0.8738, -
2.5242 and 1.8265 Å, respectively. The bond distances of Cd–O in 1 are from 2.226 to 2.425 Å,
and those of Cd–N bond distances fall in the 2.341 to 2.361 Å range, which are similar with the
values reported[20-23]. The N(O)–Cd–O(N) angles range are from 82.73 to 170.41º.
As showed in the Fig. 2, One m-BDC ligand coordinate to three Cd (II) ions through four
carboxylic oxygen atoms in a mono-bridging and bidentate chelating fashion, which give rise to a
1D double-chain structure. It is interesting that in the unit of 1, two type of rings formed: 8-
membered ring, in which the angle of O(1)–Cd(1)–O(7) is 98.220°, and the distance of Cd···Cd is
3.952 Å; The 16-membered ring with the angle of O(1)–Cd(1)–O(2) is 90.150°, and The distance
of Cd···Cd is 7.812 Å (Fig. 3); N-heterocyclic ligands ipdt are attached to both sides of this chain
regularly, and the ligands on the same side are parallel nearly.
Hydrogen bonding interactions are usually important in the synthesis of supra-molecular
architectures, and the most interesting aspect of the structure in 1 concerns the intermolecular N–
H···O and C–H···O interactions. The existence of N4–H4A···O3 and C8–H8A···O3 hydrogen
bonds interactions [H(4A)···O(4) = 1.99 Å, N(4)···O(3) = 2.806 Å and N4–H4A···O3 = 151°;
H(8A)···O(3) = 2.52 Å, C(8)···O(3) = 3.353 Å and C8–H8A···O3 = 146°] lead the 1D chain to
2D structure, see Fig. 4. The two parallel ipdt ligands in the same side recognize each other
through aromatic π-π stacking interaction with the face to face distance is 3.693 Å.

ACCEPTED MANUSCRIPT
3.1.2[Pb(mip)2(NTC)·2H2O]n (2)
The molecular structure is shown in Fig. 5, and the 1D chain structure is suggested in Fig. 6.
Selected important bond lengths and bond angles are listed in Table 2.
As shown in Fig. 5, the asymmetric unit of complex 2 consists of one Pb (II) atom, two mip
ligands, one NTC ligand, and two lattice water molecules. The Pb (II) atom is hexa-coordinated
with four nitrogen atoms (N(2), N(3), N(6), N(7)) from two chelating mip ligands and two oxygen
atoms from one chelating bidentate NTC, furnishing a distorted [:PbN4O2] pentagonal
bipyramidal geometry. For the coordination environment of Pb(1), the Pb(1), N6, N7, O1, O2, N3
atoms define the basal plane, and the N2 atom and the lone pair of electrons occupy the apical
axial positions. The N(O)–Pb–O(N) angles range are from 73.02 to 156.80º. The bond distances of
Pb–O in complex 2 are from 2.599 to 2.698 Å, and those of Pb–N bond distances fall in the 2.499
to 2.626 Å range, which are similar with the values reported[24-27]. The most interesting factors are
that contribute to the disposition of ligands around the lead with geometries are (1) holo-directed,
in which the bonds to ligand atoms are distributed throughout the surface of an encompassing
globe, and (2) hemi-directed, in which the bonds to ligand atoms are directed throughout only part
of an encompassing globe[28]. The coordination environment of Pb (II) in complex 2 is a good
example of the hemi-directed coordination, in which the bonds to ligand atoms are directed
throughout only part of the globe, that is, there is an identifiable gap (or void) in the distribution of
bonds to the ligands.
Hydrogen bonding interactions are usually important in the synthesis of supramolecular
architectures, and the most interesting aspect of the structure in 2 concerns the intermolecular C–
H···O [H(43A)···O(4) = 2.36 Å, C(43)···O(4) = 3.236 Å and C(43)-H(43A)···O(4) = 158°]
interactions, which helps in the construction of the 1D chain structure (Fig. 6).
In complex 1, the coordination sphere of the Cd(II) ions are holo-directed, but the coordination
sphere of the Pb(II) ions are hemi-directed in complex 2. Coordination modes and the coordination
sphere of the central metal ions are suggested in Fig. 7.
We can conclude that the diversity of coordination modes of dicarboxylates ligand result in the
difference of structures in complexes 1 and 2. Coordination modes (chelating bis-bidentate or bis-
monodentate) usually raise the 1D chain or 1D double-chain structure, and diverse coordination
modes (monodentate-bidentate or chelating/bridging bis-bidentate) usually raise the higher

ACCEPTED MANUSCRIPT
dimensional crystal structures.
3.2 IR spectra
In 1, the two peaks at 1612 and 1521 cm–1 correspond to the antisymmetric stretching of
carboxyl, and the peak at 1383 cm–1 corresponds to the symmetric stretching of carboxyl. The Δv
(vas(COO–)-vs(COO–)) are 230 and 139 cm–1, indicating that the carboxyls are bidentately and
monodentately coordinated with Cd(II) atoms. In 2, the strong absorption peaks at 1528 cm–1 is
the antisymmetric stretching of carboxyl, and the absorption at 1393 cm–1 is the symmetric
stretching of carboxyl. The separation is 135 cm–1, which indicates the carboxyls adopt bidentate
coordination mode. The IR results are good agreement with their solid structural features from the
results of their crystal structures.
3.3 Thermal analysis
TG analysis was used to investigate the thermal stability of 1 and 2 (Fig. 8). As expected, TG
analysis shows clear courses of weight loss, which corresponds to the decomposition of different
ligands. Complex 1 exhibits three weight loss processes. First weight loss of 7.30% from 118 to
204 °C reveals the loss of the lattice water molecules (calcd. 7.68%). The second weight loss of
22.50% from 204 to 435 °C reveals the loss of the m-BDC ligands (calcd. 23.61%), and the last
weight loss of 53.50 % from 435 to 631 °C corresponds to the loss of ipdt ligands (calcd. 52.92%);
In 2, the first weight loss of 3.05% from 252 to 263 °C corresponds to the loss of two lattice water
molecules (calcd. 3.53%). The second weight loss in the temperature range of 352-453 °C can be
ascribed to the release of NTC ligands (obsd 11.25%, calcd 12.08%), and the last weight loss of
65.10% from 453 to 676 °C corresponds to the loss of mip ligands (calcd. 64.04%). The final
formation may be the metal oxide PbO.
3.4 Photoluminescent properties
Luminescent complexes are currently of great interest because of their various applications in
photochemistry and photophysics. So in this study, we research the luminescence of complexes 1
and 2 (see Fig. 9 and 10). Complex 1 shows one strong emission band at 436 nm, and complex 2
shows one strong emission band at 578 nm (excitation at 320 nm). To further analyze the nature of
these emission bands, the emission properties of ipdt as well as mip were also investigated under
the same experimental conditions. The free ligand ipdt exhibits one emission band at 391 nm, and
the ligand mip exhibits one emission band at 539 nm (excitation at 320 nm). The results suggest

ACCEPTED MANUSCRIPT
that compared with free ligand, complex 1 is red-shifted by 45 nm relative to that of free ligand
ipdt, and complex 2 is red-shifted by 39 nm relative to that of free ligand mip. Because the Cd(II)
ion with d10 configuration is difficult to oxidize or to reduce, so the emission of 1 can be mainly be
ascribed to the intra-ligand π→π* transitions, namely ligand-to-ligand charge transfer (LLCT)[29]
.
The emission of 2 can be attributed to a metal-centered transition involving the s and p metal
orbitals, as proposed by Vogler et al[30]. Additionally, the enhancement and the red shifts of
luminescence emission maxima for 1 and 2 may be due to the chelating and bridging effects of the
relevant ligands to the metal atoms, which effectively increase the rigidity and conjugation upon
metal coordination and then affect the loss of energy by a radiationless pathway. However, the
effect of the microenvironment between ligands and complexes on the luminescence properties
still needs further investigations. Complexes 1 and 2 may be good candidate for potential
photoluminescence materials, because it is highly thermally stable and insoluble in water and
common organic solvents.
4. Conclusions
In conclusion, two unique complexes 1 and 2 have been synthesized by using plane
multifunctional ligands ipdt, mip, m-BDC and NTC. It is noteworthy that non-covalent
interactions (π···π interactions, H-bond and coordination bonds) can be one of the most powerful
force for directing the supra-molecular structures. The results also present a feasible strategy for
the construction of framework architectures by synthesis condition design, such as pH value,
temperature, and so on. This material will give new impetus to the construction of novel functional
material with potentially useful physical properties. Complexes 1-2 are very thermal stable and
worthy of further study as candidate of potential photoluminescence material.
5. Supplementary materials
CCDC 943444 and 929590 contain the supplementary crystallographic data for 1 and 2,
respectively. These data can be obtained free of charge from the Cambridge Crystallographic Data
Centre via www.ccdc.cam.ac.uk/ data request. cif.
Acknowledgement
We thank the National Natural Science Foundation of China (No. 21406085) and the Science
Development Project of Jilin Province of China (20130522071JH) for financial support.

ACCEPTED MANUSCRIPT
References
[1] W.T. Chen, M.S. Wang, X. Lin, G.C. Guo, J.S. Huang, Cryst. Growth Des. 6, 2289 (2006)
[2] J. L. C. Rowsell, O. M. Yaghi, J. Am. Chem. Soc. 128, 1304 (2006)
[3] J. Xu, Z. Su, M.S. Chen, S.S. Chen, W.Y. Sun. Inorg. Chim. Acta 362, 4002 (2009)
[4] H. Kwong, H. Yeung, W. Lee, W.T. Wong. Chem. Commun., 46, 4841 (2006)
[5] Z.Q. Zhang, R.D. Huang, Y.Q. Xu, C.W. Hu, Chem. J. Chin. Univ. 29, 1528 (2008)
[6] J.W. Ye, J. Wang, J.Y. Zhang, P. Zhang, Y. Wang. Cryst. Eng. Comm. 9, 515 (2007)
[7] A.J. Blake, N.R. Champness, T.L. Easun, D.R. Allan, H. Nowell, M.W. George, J.H. Jia, X.Z. Sun, Nature
Chem 2, 688 (2010)
[8] J.P. Zhang, X.M. Chen, Chem. Comm. 16, 1689 (2006)
[9] J. Yang, J.F. Ma, Y.Y. Liu, J.C. Ma, S.R. Batten, Inorg. Chem. 46, 6542 (2007)
[10] X.L. Xu, Y. He, J.H. Pang, Z.G. Kong, Chin. J. Inorg. Chem. 27, 2279 (2011)
[11] X.L. Xu, Y. He, S. Ma, N.S. Weng, Chin. J. Inorg. Chem. 28, 851 (2012)
[12] Y.J. Huang, L. Ni. J. Inorg. Organomet. Polym. 21, 97 (2011)
[13] L. Yan, C.B. Li, D.S. Zhu, L. Xu, J Inorg. Organomet. Polym. 22, 395 (2012)
[14] H. Chen, H. Xu, G.X. Liu, X.M. Ren, Chem. J. Chin. Univ. 25, 1508 (2009)
[15] C. Guo, X.J. Kong, X.M. Ren, G.X. Liu, Chem. J. Chin. Univ. 25, 1452 (2009)
[16] Q.Y. Liu, L. Xu, Eur. J Inorg. Chem. 2006, 1621 (2006)
[17] Q.L. Zhang, J.H. Liu, X.Z. Ren, H. Xu, Y. Huang, J.Z. Liu, L.N. Ji, J Inorg. Biochem. 95, 195 (2003)
[18] G.M. Sheldrick, SHELXS 97, Program for the Solution of Crystal Structure (University of Göttingen,
Germany, 1997)
[19] G.M. Sheldrick, SHELXS 97, Program for the Refinement of Crystal Structure (University of Göttingen,
Germany, 1997)
[20] W. Q. Geng, X. L. Li, J. H. Yin, H. P. Zhou, J. Y. Wu , Y. P. Tian, Inorg. Chem. Comm. 13, 1285 (2010)
[21] J. Zhang, B. Li, X. Wu, H. Yang, W. Zhou, X. Meng, H. Hou, J. Mol. Struct. 984, 276 (2010)
[22] M. Hu, X.G. Yang, Q. Zhang, L.M. Zhou, S.M. Fang, C.S. Liu, Z. Anorg. Allg. Chem. 637, 480 (2011)
[23] S.L. Li, Y.Q. Lan, J.F. Ma, J. Yang, G.H. Wei, L.P. Zhang, Z.M. Su, Cryst. Growth Des. 8, 680 (2008)
[24] Q.Y. Liu. L. Xu, Eur. J. Inorg. Chem. 2006, 1621 (2006)
[25] C.X. Li, J. Wang, C.B. Liu, G.B. Che, X.Y. Li, X.C. Wang, Chin. J. Inorg. Chem. 25, 2213 (2009)
[26] F. Marandi, R. Rutvand , M. Rafiee , J.H. Goh , H.K. Fun, Inorg. Chim. Acta 363, 4003 (2010)

ACCEPTED MANUSCRIPT
[27] Y.J. Shi, G.Q. Jiang, Y.H. Zhang, X.Z. You, Appl. Organometal. Chem. 18, 89 (2004)
[28] X.L. Wang, Q. Gao, Y.Q. Chen, G.C. Liu, A.X. Tian, Z.H. Kang, Z Anorg Allg Chem 637, 144 (2011)
[29] M. Hu, X.G. Yang, Q. Zhang, L.M. Zhou, S.M. Fang, C.S. Liu, Z Anorg Allg Chem 637, 478 (2011)
[30] P.C. Ford, A. Vogler, Acc Chem Res 26, 220 (1993)
Table 1
Crystal data and details for 1 and 2
Compound
1
2
Empirical formula
Formula weight
Crystal system
space group
C29H26CdN4O10
702.94
C46H36N9O6Pb
1018.03
monoclinic
C2/c
monoclinic
P2(1)/n
a (Å)
20.296(5)
22.010(6)
14.836(4)
115.144(4)
6000(3)
10.623(4)
16.771(7)
22.946(1)
92.771(1)
4083(5)
b (Å)
c (Å)
β (o)
Volume (Å3)
Z
8
4
Density (Mg/m3) (calculated)
Absorption coefficient (mm-1)
F(000)
1.556
1.656
0.791
4.195
2848
2020
Crystal size (mm3)
Theta range (o)
Reflections collected
Unique reflections [Rint]
Goodness-of-fit on F2
Final R indices [I > 2σ (I)]
0.41 x 0.32 x 0.30
1.4426.08
16187
0.34 x 0.30 x 0.25
1.5026.03
29899
5895 [0.040]
1.035
8000 [0.034]
1.018
R1 = 0.046
wR2 = 0.136
R1 = 0.069
wR2 = 0.153
1.470, -0.586
R1 = 0.031
wR2 = 0.074
R1 = 0.043
wR2 = 0.079
1.491, -0.514
R indices (all data)
Largest difference peak and hole (e. Å-3)

ACCEPTED MANUSCRIPT
Table 2
Selected bond lengths [Å] and bond angles [°] for 1
bond
Dist.
bond
Dist.
Cd(1)–O(1)
2.257(4)
2.425(4)
2.341(4)
(°)
Cd(1)–O(2)
2.367(3)
2.226(4)
2.361(4)
(°)
Cd(1)–O(3)
Cd(1)–O(7)
Cd(1)–N(1)
Cd(1)–N(2)
Angle
Angle
O(1)–Cd(1)–O(3)
O(7)–Cd(1)–O(1)
O(1)–Cd(1)–O(2)
N(1)–Cd(1)–O(3)
O(1)–Cd(1)–N(1)
O(7)–Cd(1)–N(2)
N(2)–Cd(1)–O(2)
N(1)–Cd(1)–N(2)
144.50(12)
98.21(15)
90.15(13)
89.49(14)
82.73(14)
100.60(15)
140.54(13)
70.78(14)
O(2)–Cd(1)–O(3)
O(7)–Cd(1) –O(3)
O(7)–Cd(1) –O(2)
O(7)–Cd(1)–N(1)
N(1)–Cd(1)–O(2)
O(1)–Cd(1)–N(2)
N(2)–Cd(1)–O(3)
54.78(12)
95.05(13)
102.34(14)
170.41(14)
87.17(15)
117.74(14)
91.66(13)
Table 3
Selected bond lengths [Å] and bond angles [°] for 2
bond
Dist.
bond
Dist.
Pb(1)–O(1)
2.698(3)
2.499(3)
2.626(3)
(°)
Pb(1)–O(2)
2.599(3)
2.568(3)
2.596(3)
(°)
Pb(1)–N(2)
Pb(1)–N(3)
Pb(1)–N(6)
Pb(1)–N(7)
Angle
Angle
O(2)–Pb(1)–O(1)
N(7)–Pb(1)–O(2)
N(2)–Pb(1)–O(2)
N(3)–Pb(1)–O(1)
N(6)–Pb(1)–O(1)
N(2)–Pb(1)–N(7)
N(2)–Pb(1)–N(6)
N(7)–Pb(1)–N(6)
49.20(8)
75.27(9)
73.02(10)
80.23(9)
156.80(10)
81.01(10)
77.72(11)
63.19(10)
O(2)–Pb(1)–N(6)
N(3)–Pb(1)–O(2)
N(2)–Pb(1)–O(1)
N(7)–Pb(1)–O(1)
N(2)–Pb(1)–N(3)
N(3)–Pb(1)–N(7)
N(3)–Pb(1)–N(6)
132.08(9)
117.69(9)
81.98(10)
124.47(9)
65.15(10)
135.39(10)
81.13(10)

ACCEPTED MANUSCRIPT
Fig. 1 The molecular structure of complex 1 (hydrogen atoms were omitted)
Fig. 2 1D double chain structure of complex 1 (hydrogen atoms were omitted)
Fig. 3 The simplified chain structure of complex 1 (hydrogen atoms were omitted)

ACCEPTED MANUSCRIPT
Fig. 4 2D layer structure of complex 1 linked by C–H···O hydrogen bonds (dotted lines represent
hydrogen bonds)
Fig. 5 The molecular structure of complex 2 (hydrogen atoms were omitted)

ACCEPTED MANUSCRIPT
Fig. 6 1D arm-shaped chain structure of complex 2 (hydrogen atoms were omitted)
Fig. 7 TG curves of complexes 1 and 2

ACCEPTED MANUSCRIPT
Fig. 8 Coordination modes and sphere of the central metal ions in complex 1 (a) and complex 2 (b)

ACCEPTED MANUSCRIPT
Fig. 9 Luminescent spectrum of complex 1 and ipdt ligand in solid state at room temperature
Fig. 10 Luminescent spectrum of complex 2 and mip ligand in solid state at room temperature
