PAPER
Acridine-based thiosemicarbazones as novel
inhibitors of mild steel corrosion in 1 M HCl:
synthesis, electrochemical, DFT and Monte Carlo
simulation studies
Cite this: RSC Adv., 2019, 9, 29590
ab
abd
Ekemini D. Akpan,
Ibanga O. Isaac,c Lukman O. Olasunkanmi,
ab
ef
*
Eno E. Ebenso
and El-Sayed M. Sherif
Electrochemical, surface morphology, density functional theory and Monte Carlo simulation methods were
employed in investigating the effects of (2E,20E)-2,20-(3,3,6,6-tetramethyl-9-phenyl-3,4,6,7-tetrahydroacridine-
1,8(2H,5H,9H,10H)-diylidene)bis(N-phenylhydrazinecarbothioamide) (IAB-NP), (2E,20E)-2,20-(3,3,6,6-tetramethyl-
9-phenyl-3,4,6,7-tetrahydroacridine-1,8(2H,5H,9H,10H)-diylidene)bis(N-(2,4-difluorophenyl)hydrazinecarbothioa
mide)IAB-ND) and (2E,20E)-2,20-(3,3,6,6-tetramethyl-9-phenyl-3,4,6,7-tetrahydroacridine-1,8(2H,5H,9H,10H)-
diylidene)bis(N-(2-fluorophenyl) hydrazinecarbothioamide) (IAB-NF) on mild steel corrosion in 1 M HCl solution.
From the studies, compounds IAB-NP, IAB-ND and IAB-NF inhibit mild steel corrosion in the acid and the
protection efficiencies were found to increase with the increase in concentration of each compound. At the
optimum inhibitor concentration of 1.5 ꢀ 10ꢁ4 M, the inhibition efficiencies (%) of the compounds are in the
order IAB-NF (90.48) > IAB-ND (87.48) > IAB-NP (85.28). Potentiodynamic polarization measurements revealed
that all the compounds acted as mixed-type corrosion inhibitors. Experimental data for the adsorption of the
studied molecules on a mild steel surface in 1 M HCl fitted into the Langmuir adsorption isotherm and the
standard free energies of adsorption (DGoads) suggested both physisorption and chemisorption mechanisms.
Scanning electron microscopy analyses confirmed the formation of a protective film on the mild steel surface
by the inhibitor molecules, resulting in protection of the metal from corrosive electrolyte ions. The
experimental findings were corroborated by both theoretical density functional theory and Monte Carlo
simulation studies.
Received 25th June 2019
Accepted 13th September 2019
DOI: 10.1039/c9ra04778f
rsc.li/rsc-advances
metal.2,3 Susceptibility of metals to corrosion in nearly all
industrial environments has limited the advancement of new
technologies.4 Increasing the durability of construction mate-
rials and essential infrastructures such as rail tracks, bridges
and metallic structures including cars, storage tanks, corru-
gated iron, etc. by decreasing the rate of corrosion becomes
necessary. Because of wide applicability, high efficiency and
other numerous advantages, the use of inhibitors stands out as
the most efficient method in mitigating corrosion.5,6
Introduction
There is a continuous increase in the use of mild steel in the
construction and chemical industries and also for domestic
appliances because mild steel is relatively cheap and possesses
advantageous mechanical properties.1 Exposure of mild steel to
aqueous environments, especially concentrated acidic envi-
ronments results in the electro-dissolution and corrosion of the
Currently, there is a growing and continuous need to develop
active, appropriate and environmentally friendly inhibitors to
mitigate the electro-dissolution and corrosion of metals.7
Mostly studied and widely utilized corrosion inhibitors are
compounds containing heteroatoms, such as nitrogen, sulphur,
oxygen and p-electron systems. Moreover, previous studies have
revealed that these organic compounds inhibit corrosion by
adsorption on the surface of the metal.4,7–9 Organic molecules
used as corrosion inhibitors protect the metals from the
corrosive species in the immediate environment by forming
resistive layer on the metal surface, which ensures high resis-
tance to electron transfer reactions.10,11 Molecular orbitals and
aDepartment of Chemistry, Faculty of Natural and Agricultural Sciences, North-West
University, Private Bag X2046, Mmabatho 2735, South Africa. E-mail: Eno.Ebenso@
nwu.ac.za
bMaterial Science Innovation & Modelling (MaSIM) Research Focus Area, Faculty of
Natural and Agricultural Sciences, North-West University, Private Bag X2046,
Mmabatho 2735, South Africa
cDepartment of Chemistry, Faculty of Natural and Applied Sciences, Akwa Ibom State
University, Ikot Akpaden, Akwa Ibom State, Nigeria
dDepartment of Chemistry, Faculty of Science, Obafemi Awolowo University, Ile-Ife
220005, Nigeria
eCenter of Excellence for Research in Engineering Materials (CEREM), King Saud
University, P. O. Box 800, Al-Riyadh 11421, Saudi Arabia
fElectrochemistry and Corrosion Laboratory, Department of Physical Chemistry,
National Research Centre, El-Behoth St. 33, Dokki, Cairo 12622, Egypt
29590 | RSC Adv., 2019, 9, 29590–29599
This journal is © The Royal Society of Chemistry 2019

Evaluation Only. Created with Aspose.PDF. Copyright 2002-2021 Aspose Pty Ltd.
View Article Online
Paper
RSC Advances
electron densities around the donor atoms of an inhibitor functional groups such as –C]C–, –C]N–, –N]N–, –NH, –C]S
molecule strongly inuence the adsorption and corrosion and p-bonds will enhance the adsorption of the molecules on mild
inhibiting abilities of the inhibitor. Furthermore, steric factors steel surface. The compounds differ in the number of uorine (Fꢁ)
and the type of functional groups present in a compound used substituents on the phenyl rings, such that IAB-NP is unsubstituted,
as inhibitors are also very important.12–15
IAB-NF has one F-substituent at position 2 on the phenyl ring (2-F
Acridine derivatives, which are widely used as antibacterial substituted) and IAB-ND has two F-substituents at positions 2 and 4,
and antiprotozoal agents are the derivatives of tricyclic nitrogen i.e. it is 2,4-F substituted. The effect of F-substitution on the phenyl
heterocyclic compounds.16 Acridine derivatives are reported to ring on corrosion inhibition potentials of the compounds is there-
have unique physical and chemical properties, biological fore examined.
activities, and industrial applications.17 The use of acridine
derivatives as corrosion inhibitors have been reported in liter-
ature. The inuence of toluidine and acridine derivatives on the
Experimental and computational
corrosion of 63/37 brass in nitric acid solution was reported to
be excellent, with efficiency attributed to the elimination of
nitrous acid as well as the adsorption of onium type ions at the
metal surface.18 Diffusion and ionization steps associated with
the dissolution of a-brass in 1 M NaCl + 0.01 M HCl solution
had been found to be inhibited by alkyl acridinium halides. The
studies
Synthesis and characterization of acridine-based
thiosemicarbazones IAB-NP, IAB-ND and IAB-NF
The synthesis protocol for inhibitors IAB-NP, IAB-ND and IAB-
NF is as outlined in Scheme 1. Detailed procedures, purica-
tion methods, experimental yields and spectroscopy data,
compounds were also found to be effective in inhibiting copper
including proton nuclear magnetic resonance (1H NMR),
dissolution than brass.19
carbon-13 nuclear magnetic resonance (13C NMR), Fourier
Following the existing history of corrosion inhibition by acridine
transform infrared spectroscopy (FTIR), electron-spray ioniza-
derivatives, the present work reports the corrosion inhibition prop-
erties of some novel acridine-based thiosemicarbazones namely
(2E,20E)-2,20-(3,3,6,6-tetramethyl-9-phenyl-3,4,6,7-tetrahydroacridine-
tion mass spectroscopy (ESI-MS) and heteronuclear multiple
bond correlation HMBC have been reported elsewhere.20
1,8(2H,5H,9H,10H)-diylidene)bis(N-phenylhydrazinecarbothioamide)
(IAB-NP), (2E,20E)-2,20-(3,3,6,6-tetramethyl-9-phenyl-3,4,6,7-tetrahy-
Materials
droacridine-1,8(2H,5H,9H,10H)-diylidene)bis(N-(2,4-diuorophenyl)
Chemical composition of mild steel samples employed for
hydrazinecarbothioamide) (IAB-ND) and (2E,20E)-2,20-(3,3,6,6-tetra-
electrochemical and surface morphology studies was deter-
methyl-9-phenyl-3,4,6,7-tetrahydroacridine-1,8(2H,5H,9H,10H)-diyli-
mined prior to use; 0.076% C, 0.039% Ni, 0.015% P, 0.050% Cr,
dene)bis(N-(2-uorophenyl) hydrazinecarbothioamide) (IAB-NF) for
0.030% S and 99.456% Fe. The samples of steel used for elec-
mild steel in 1 M HCl. The effects of IAB-NP, IAB-ND and IAB-NF on
trochemical measurements were press-cut into 1 cm2 surface
mild steel corrosion in the acid were investigated using electro-
area. Before all measurements and analyses were done, mild
chemical and scanning electron microscopy techniques. Theoretical
steel surface was ground with different grade of emery papers
computational studies were carried out on the novel compounds
(600, 800 and 1200), washed with double distilled water,
using density functional theory (DFT) and Monte Carlo simulation
degreased with ethanol and acetone and dried at room
calculations. The compounds in this study were synthesized as
temperature and used immediately. The corrosive solution, 1 M
outlined in Scheme 1.20 It is anticipated that the presence of
HCl was prepared by carefully diluting appropriate amount of
32% analytical grade HCl (purchased from Merck South Africa)
with double distilled water.
Inhibitor solution
A stock solution of the respective inhibitors (concentration of
0.15 mM) were prepared by rst dissolution in 5 mL of acetone
(5% equivalent), and subsequently diluted to various concen-
trations; 0.13, 0.09, 0.07 and 0.05 mM.
Electrochemical measurements
The working electrode employed in these measurements was a mild
steel coupon with exposed area of 1 cm2. The other components of
the electrochemical cell include Ag/AgCl (3 M KCl) as the reference
electrode and a platinum rod as the counter electrode. All
measurements were carried out at 25 ꢂ 1 ꢃC on Metrohm AutoLab
Potentiostat/Galvanostat (PGSTAT302N) driven by AutoLab Nova 2.1
soware. To ensure a stable open circuit potential (OCP), the
working electrode was immersed in the test solution for 30 min
Scheme 1 Synthetic protocol for inhibitors IAB-NP, IAB-ND and IAB-
NF.20
