Macromolecules
Article
chromatography (PE/Et2O 20:1, silica gel) to yield 1.48 g (74% of
theory) of pure BPT as a bright yellow powder. m.p.: 70−72 °C. GC−
MS (THF, EI, m/z): 311.96 (M); 282.00; 206.99; 154.10; 105.03;
results, we have chosen to study a benzoyl telluride compound,
which cleaves to give a highly reactive benzoyl radical and also
allows photoinduced TERP.
1
77.06. H NMR (CD2Cl2, δ): 7.75−7.49 (m, 5H, CO−C6H5); 7.48−
We describe the newly discovered polymerization control
properties of the telluroorganic compound benzoyl phenyl-
telluride (BPT), which combines the positive characteristics of
the already mentioned organotellurium compound ethyl 2-
phenyltellanyl-2-methylpropionate with the reactivity of a
benzoyl chromophore and compare it to the most relevant
photoiniferter from literature benzyl dithiocarbamate
(BDC).7,14−16 The comparison to a photoiniferter makes
more sense than the comparison with other TERP reagents
because TERP reagents behave very similar to photoiniferters
when they are used as photoinitiator instead of thermal
initiator.24 This applies especially to the mechanism. While in
thermally initiated TERP a degenerative transfer mechanism is
exclusively responsible for the control abilities, in photoinduced
TERP, a dissociation−combination is assumed to also play an
important role, although degenerative transfer still occurs as a
competing reaction.25 This is also the case for photoiniferters,
even though the degenerative transfer is less important. It is
worth mentioning that a similar compound (benzoyl
methyltelluride) to our BPT has already been described in
literature as a thermal TERP-reagent, but this compound
showed poor control abilities because of the high C−Te-bond
dissociation energy, which should be lower in our case due to
an aryl substituent on the Te atom.26 We will show that BPT
can be used as control agent for acrylates (ACs) and
acrylamides (AMs) in the visible light (400−500 nm) region.
The ability of BPT to control the polymerization has been
confirmed by steady-state polymerization experiments, which
include measurements of the polydispersity and the combina-
tion of molecular weight and DBC, respectively. While rate
constants for reactions of dithiocarbamyl radicals were reported
in literature,27 no constants for photoinduced reactions of
TERP reagents have been reported yet. Therefore, the
comparison of control abilities will be done on the basis of
achievable PDIs. A polymerization mechanism based on
literature is proposed; photo-DSC and UV−vis measurements
are provided for comparison with other photoinitiating systems.
7.20 (m, 5H, Te−C6H5). 13C NMR (CD2Cl2, δ): 143.3; 141.1; 134.5;
129.9; 129.6; 129.3; 127.3; 125.7. IR (ATR, cm−1): 1663.47 ν(CO).
UV−vis Measurements. UV−vis measurements were carried out
on a Shimadzu UV-1800 spectrophotometer using quartz cuvettes
with 10 mm thickness. The photoiniferter samples were dissolved in
CH2Cl2 with a concentration of 1 × 10−3 mol L−1 for BDC, BPT, and
MAPO and with 1 × 10−2 mol L−1 for CQ and measured in the dark.
Kinetic Studies. The photopolymerization of the four different
monomers (BA, BMA, St, NAM) was carried out in a photoreactor
(Figure S1 in the Supporting Information). The reactor was filled to a
height of ∼25 mm with monomer formulation (monomer + BPT/
BDC), which was degassed with argon. For irradiation an OmniCure
2000 (Lumen Dynamic), mercury lamp with a filter excluding all but
400−500 nm was used. The effective irradiation intensity was adjusted
to the reactivity of the monomer (0.07 W cm−2 on the surface of the
formulation for BA, BMA, and St and 0.03 W cm−2 on the surface for
NAM). For the more reactive monomers, a lower effective irradiation
intensity and photoiniferter/TERP-reagent to monomer molar ratio
was chosen (BA: 1:200, BMA: 1:100, St: 1:100, NAM: 1:500) to make
sure the polymerization would be slow enough to take samples. These
samples were taken with a syringe over the side joint of the reactor.
Typical sample size was 0.05 mL, of which 10 mg was used for GPC
analysis and the rest of ∼40−50 mg was used for 1H NMR-
spectroscopy.
For determination of the number-average molecular weight (Mn)
and the polydispersity index (PDI), a Waters 717plus GPC with three
columns (Styragel HR 0.5 THF, Styragel HR 3 THF, and Styragel HR
4 THF) and a Waters 2410 refractive index detector were used. The
eluent was THF with a flow rate of 1.0 mL min−1, and the temperature
was set to 40 °C. For calibration, polystyrene standards were used,
which offer a molecular weight resolving range of 102 to 106 g/mol.
A Bruker AC-E-200 FT-NMR-spectrometer was used for the
samples taken from the photoreactor to determine the monomer
DBC. The solvent was deuterated chloroform (CDCl3) with a degree
of deuteration ≥99.8% D. Out of these spectra, the double-bond
conversion was calculated by comparing the integrals of the monomer
specific double bonds to the combined integrals of the side chains of
monomer and polymer.
Photo-DSC Measurements. Photo-DSC analysis was done on a
Netzsch DSC 204 F1 using an OmniCure 2000 (Lumen Dynamic)
mercury lamp light source equipped with a built-in 400−500 nm filter.
The lamp was calibrated with an OmniCure R2000 radiometer to an
effective irradiation intensity of 3.00 W cm−2. The measurements were
done with 10 1 mg of monomer formulation, which consisted of
photoinitiator/CRP-reagent and NAM in a molar ratio of 1:500 (0.3
to 0.5 wt %). As a result from the measurements, the time until the
maximum heat of polymerization (tmax) is reached can be obtained
directly. Also, the time until 95% of the maximum DBC (t95%) can be
directly acquired through integration of the resulting curves. However,
the rate of polymerization (Rp) and the DBC of the monomer need to
be calculated according to eqs 1 and 2
EXPERIMENTAL SECTION
■
Materials. The monomers styrene (St), n-butyl acrylate (BA), n-
butyl methacrylate (BMA), and 4-acryloylmorpholine (NAM) and the
photoiniferters/photoinitiators benzyl dithiocarbamate (BDC), mono-
acylphosphinoxide (MAPO) (diphenyl(2,4,6-trimethylbenzoyl)-
phosphine oxide), camphorquinone (CQ), and ethyl 4-(dimethylami-
no)-benzoate (DMAB) are commercially available (Aldrich) and were
used in the highest purities available. Benzoyl phenyltelluride (BPT)
was synthesized according to a slightly modified synthetic procedure
described in literature.28
Synthesis of Benzoyl Phenyltelluride (BPT). All synthesis was
performed under light protection in an orange light lab, which excludes
wavelengths below 520 nm. The following procedure is slightly
modified from that of Gardner et al.28 Diphenyl ditelluride (3.23
mmol, 1.32 g) was dissolved in a mixture of toluene and ethanol (5
mL, 25/75 v/v) and heated to reflux. To this solution NaBH4 (5.17
mmol, 0.20 g) dissolved in 1N NaOH (4.4 mL) was added dropwise.
During the addition, there appeared a strong formation of H2, and the
solution became colorless. Then, benzoyl chloride (7.75 mmol, 1.09 g,
0.89 mL) was added in one portion, and the warm reaction mixture
was stirred for another 5 min. Afterward, 25 mL of water was added,
and the resulting mixture was extracted with diethyl ether. The
combined organic phase was dried over anhydrous NaSO4, and after
removal of the solvent the crude product was purified via liquid
ΔHmax*ρ
Rp =
ΔH0*Mw
(1)
A
ΔH0
DBC =
*100
(2)
Herein ΔHmax is the maximum heat of polymerization, ΔH0 (NAM:
513.57 J g−1)29 is the theoretical heat of polymerization, ρ (NAM:
1114 g L−1)29 is the density of the formulation, Mw is the molecular
weight, and A is the integrated area of the DSC plot. All of these
numbers are referring to the monomer.
