Design of a Real-Time GPS Satellite Signal
Simulator on the MULTISHARC Parallel
Processing System
S. V. M. K. PRASAD, V. VAIDEHI, P. V. RAMAKRISHNA, C. N. KRISHNAN, T. ANANDA SARANGARAM,
G. BOOPALAN, N. NAGALAKSHMI, and S. NAPPINNAI
Department of Electronics Engineering, Madras Institute of Technology, Anna University, Chennai, India
Received October 2002; Revised April 2003
ABSTRACT: A GPS signal simulator is a versatile instrument used for testing and performance evaluation of
a GPS receiver during its design and manufacture. A real-time GPS signal simulator (RTGPSSS) outputs the L1
signal of GPS satellites as received by the GPS receiver at its antenna. The generation of the GPS L1 signal for our
design specification requires the transmission of a coarse acquisition (CA)-code, which is a pseudorandom noise
(
PRN) code at a rate of 1.023 Mchip/s, and the calculation of Doppler frequency at a rate of 19.55 ꢇs under high
receiver dynamics. These critical timing requirements necessitate parallel processing techniques. In this paper, the
design of a 12-channel RTGPSSS using a digital signal processor (DSP)–based parallel processing system is
presented. The effects of receiver dynamics, receiver clock drift, multipath, and atmosphere anomalies (ionospheric
and tropospheric delay) are also incorporated in the simulated GPS signal.
INTRODUCTION
rated with all the atmospheric effects, such as iono-
spheric and tropospheric delays.
The signal generated by the GPS signal simulator
is an L1 C/A-code signal given by
The GPS [1–3] all-weather, all-time facility avail-
able worldwide enables one to know one’s position fix
and time very accurately whenever and wherever
desired. GPS provides spread-spectrum signals that
can be processed in a GPS receiver, enabling the
receiver to compute position, velocity, and time. At
least four satellites are used to compute position in
three dimensions and the time offset in the receiver
clock [4–6].
A real-time GPS signal simulator (RTGPSSS) is
an instrument capable of simulating a high-
fidelity L1 coarse acquistion (C/A)-code signal,
which is fed at the radio frequency (RF) front end of
the GPS receiver. These signals are similar to the
one that exists at the antenna of the GPS receiver in
real time. RTGPSSS test facilities are used to test
the software and hardware of GPS receivers and
their augmentation systems. Almost any type of
GPS receiver test procedure requires the use of an
RTGPSSS. These simulators replicate transmitted
RF signals from satellites visible at a receiver’s loca-
tion. The simulators usually have a trajectory pro-
file generator for dynamic receiver applications.
GPS signals are modeled for static and dynamic
user environments. The generated signal is incorpo-
N
S(t) ꢆ
s (t)
j
(1)
͚
jꢆ1
where N visible satellites are present, and the simu-
lator is to output S(t) in real time.
The simulated signal from satellite j would have
the structure [7–9]
M
S (t) ꢆ
j
√(2P )D (t ꢄ ꢀ (t))G (t ꢄ ꢀ (t))
͚
ci
j
i
j
i
iꢆ1
ꢂcos (2ꢃf (t ꢄ ꢀ (t)) ꢅ ꢁ (t))
L1
i
i
(2)
where M multipath components exist; P is the
ci
th
th
received signal power from the j satellite in the i
multipath: D (t) is the 50 Hz navigation data of the
satellite; G (t) is the length-1023 pseudorandom
noise (PRN) code of the j satellite with a chipping
rate of 1.023 Mchip/s; ꢀ (t) is the delay in the i mul-
tipath component from the j GPS satellite to the
j
th
j
j
th
th
i
th
receiver (inclusive of the unknown propagation
delays, ionospheric and tropospheric delays, etc.); fL1
th
is the carrier frequency of the signal from the j
satellite (1575.42 MHz); and ꢁ (t) is the phase shift
i
encountered by the signal.
In reality, RTGPSSSs are RF channel simulators.
The commercially available RTGPSSSs are presented
NAVIGATION: Journal of The Institute of Navigation
Vol. 50, No. 1, Spring 2003
Printed in the U.S.A.
57

in [11–13]; however, their internal details are not
available in the literature. The schemes presented in
Hence maximum frequency error is 8.125 Hz/ms,
and the corresponding velocity error is given by
ꢉ * 8.125, which is equal to 1.625 m/s. If the frequency
error is 0.2 Hz/ms, the corresponding velocity error is
0.04 m/s. Frequency update is the rate at which the
frequency of the L1 signal should be calculated.
To obtain a frequency error of 0.2 Hz/ms, the frequen-
cy update for every calculation should be done every
24 ꢇs. Using these specifications, it is found that fre-
quency update every 19.55 ꢇs will result in a pseudo-
range rate error of less than 0.04 m/s.
The design of the RTGPSSS [20] consists of both
software [21] and hardware [22] design. The software
design deals with the computation of frequency,
phase, and amplitude for all 12 channels. These
parameters are given to the hardware to generate
S(t). This paper presents the design and implemen-
tation of a 12-channel RTGPSSS on Spectrum’s par-
allel processing system (Darlington SHARC3000
PCI motherboard), consisting of 10 SHARC (ADSP-
21060) processors connected in a three-level tree
topology. This design produces the parameters
required for IF signal generation. This paper
addresses the issues involved in the software design
only. For a detailed description of the hardware
design, see [22].
[
14] and [15] use MATLAB toolboxes for simulating
the signal in digital form (digital samples) and store it
in memory. These samples are then modulated onto
an RF carrier to provide digital construction of the
simulated signal. However, these schemes require
huge amounts of memory. Moreover, signal simulation
depends upon the volume of data generated by the
MATLAB toolboxes.
The recent increase in the performance of digital
signal processors (DSPs) and field programmable
gate arrays (FPGAs) greatly reduces the complexity
of implementing a channel simulator. Hence the
implementation of channel simulators using DSP
processors and FPGAs has been the topic of recent
research [16, 17]. However, the RF channel simula-
tors on the market today are complex and costly
[
18]. In this paper, a low-cost solution for the design
of RTGPSSSs using DSPs and FPGAs is considered.
The generation of a GPS signal requires the com-
putation of signal parameters, such as amplitude,
frequency, and phase, at different update rates. The
calculation of these signal parameters requires a
range of computations within a short time period. It is
not possible to run all the above tasks with the
required update rates on a single processor. Therefore,
a multiprocessing system having suitable link ports
for hardware interfacing is needed for the design of an
RTGPSSS. Moreover, the GPS signal simulator should
output the data on 12 channels simultaneously, and
these outputs must be integrated with hardware to
receive the intermediate frequency (IF) signal.
This paper first describes the implementation of
the RTGPSSS in the DSP-based parallel processing
system. Subsequently, a parallel algorithm for the
computational block and results are presented.
IMPLEMENTATION DETAILS
Examples of popular DSP-based parallel process-
ing systems are the TI 320C40 processor and
the ADSP SHARC-21060 processor [19]. However,
the ADSP SHARC processor has a node speed of
A complete block diagram of the RTGPSSS is
shown in Figure 1. In this figure, the HOST system
and MPS (Multiprocessing System) relate to the
software design, while the IF and RF blocks relate to
the hardware design. Since the MPS does all the
computation for signal generation, it is often
referred to as the computational block.
1
20 MFLOPS and a link speed of 40 Mbytes. These
parameters are better than those of the TMS320C40,
and hence the SHARC-based multiprocessing (MUL-
TISHARC) system was selected for this design.
Simultaneous generation of signals in 12 ports is fea-
sible using the MULTISHARC system as it supports
parallel updating of data in the links using a built-in
direct memory access (DMA) controller.
Host Interface
In this design, a Pentium-based system acts as
a host system. Receiver parameters, such as receiver
initial position, receiver dynamics, and date and time
of simulation, are input by the user. These parame-
ters are provided to the MPS for signal generation.
The host also displays the data coming from the MPS
in a graphical user interface (GUI) environment.
RTGPSSS specifications for this design are as
follows [9]: velocity (v) ꢆ 10,000 m/s, acceleration
2
3
(
a ) ꢆ 500 m/s , jerk (a ) ꢆ 500 m/s , and pseudorate
0
1
error ꢆ 0.04 m/s. Considering these specifications
as maximum values, the corresponding Doppler
frequency (f ) is calculated as follows:
d
2
v ꢆ a t ꢅ a · t /2 ꢈ 10,000 m/s
(3)
0
1
Multiprocessing System (MPS)
By substituting a ꢆ 500 m/s2 and a ꢆ 500 m/s
3
0
1
in equation (3), we get t ꢆ 5.5 s. Doppler frequency
To achieve high computational power, a DSP-based
parallel processing system with 10 ADSP SHARC-
21060 processors on board (Spectrum Darlington
SHARC 3000 PCI) is used [23]. Each ADSP SHARC-
2
f ꢆ f * v/c ꢆ f * (a t ꢅ a * t /2)/c, df /dt ꢆ f (a /c
d
0
0
0
1
d
0
0
ꢅ a * t/c) ꢆ a /ꢉ ꢅ a * t/ꢉ ꢆ 16.25 Hz/ms, where
1
0
1
ꢉ ꢆ f /c ꢆ 1575.42 MHz/300000000 ꢆ 0.2 m.
0
5
8
Navigation
Spring 2003

Fig. 1–Overall Block Diagram of 12-Channel Real-Time GPS Signal Simulator
2
1060 processor is capable of a computational
Figure 1. The data flow structure is based on the
required update rate, which is the rate at which the
parameter is calculated in that particular node. It
has been found by extensive analysis that this tree
interconnection topology of the processors is the
best method for our design as it decreases the com-
munication overhead, reduces the number of links
required to interconnect all the processors, and pro-
vides an easy way to interact with the hardware.
speed of 120 MFLOPS, and easy interprocessor com-
munication via six link ports with input/output (I/O)
bandwidth of 40 Mbyte/s/link port [19].
The processors in the MULTISHARC system are
configured in the following way: the root processor is
named the level-0 processor (P0), while the other
processors, which are connected to the root proces-
sor directly, are named level-1 processors (P1, P2,
P3). The processors that are not connected directly
to the root processor are named level-2 processors
Tasks in Level-0 Processor (Root)
(
P4, P5, P6, P7, P8, P9). The data from the root
processor can reach a level-2 processor in two hops
and vice versa.
To have a hierarchical data flow structure, a tree-
connected architecture is derived, as shown in
The tasks assigned to the root processor, along
with the computational load, are given in Table 1.
The tasks to be executed in the root processor are
detailed below.
Vol. 50, No. 1
Prasad et al.: Design of a Real-Time GPS Satellite Signal Simulator
59

Table 1—Tasks and Computational Load of Level-0 Processor
Computational Load in
Machine Cycles (M/c)
Task
Constellation generation, visibility check
Iono, tropospheric delay calculation
Receiver earth-centered, earth-fixed (ECEF) coordinates and
north-east-up (NEU) vector calculation
Host and level-1 processor communication
Channel allocation
6,500,000
864
15,625
1,500
1,000
48
Satellite vehicle (SV) clock error calculation
Total
6,519,037
The total time needed for the root processor under worst-case conditions is
,519,037/40 MHz ꢆ 0.163 s with a processor speed of 40 MHz.
6
Satellite Vehicle (SV) Constellation Generation
and Visibility Check
If the receiver position is static, the ECEF and
NEU unit vectors of the receiver remain constant
throughout the simulation. Thus for the static case,
it is enough to update the constellation every 10 s.
If the receiver position is dynamic, i.e., if the
receiver is moving with certain velocity or with
acceleration and jerk, receiver position must be
updated more frequently than in the static case.
It has been found by analysis that an update period
of 1 s is needed for the dynamics specified in this
design.
Satellite vehicle (SV) constellation generation
7, 8] is the task in which the earth-centered,
[
earth-fixed (ECEF) position of all 32 satellites is
determined for the given receiver position, time,
and ephemeris data. The visible satellite list is
obtained by calculating user ECEF position, user
north–east–up (NEU) unit vectors, the up vector
between the user and the satellite, and the satel-
lite elevation angle. The NEU local frame is
defined by taking receiver position as the origin.
The simulator has a capability to enter the user-
required mask angle, which could be either a positive
or negative value. The up vector is calculated
between the receiver and the satellite in the NEU
coordinate system. The satellite is said to be visible
if and only if the elevation angle is greater than the
mask angle (typically ꢅ5 deg).
Each level-1 processor handles 4 channels. The
root processor sends the details of 4 channels to each
level-1 processor, along with receiver parameters
and delays, every 1 s.
Tasks in Level-1 Processors
The tasks and the computational load of level-1
processors are given in Table 2. There are three
level-1 processors, each controlling 4 channels. The
complex computations required for signal generation
are performed in these processors. The tasks to be exe-
cuted in a level-1 processor are described below.
Ionospheric and Tropospheric Delay Calculations
As a result of the propagation of the GPS signal
through the ionosphere and troposphere [7, 8], delays
are introduced in the received signal, because the
electromagnetic (EM) wave sees a different path
length when it propagates through the ionosphere.
The model used in this work is that of Klobuchar [7],
which is the cosine approximation of the ionospheric
delay.
Troposphere is a nondispersive medium for radio
waves up to 15 MHz, and the delay introduced by
this medium is denoted as the tropospheric delay.
The model used here is the Saastamoinen model [7].
Satellite Relative Velocity and Carrier Doppler
Frequency Calculation
The range-rate computation requires calculation of
the range between the satellite and the receiver,
which is calculated from the satellite position and
receiver position. Knowing the satellite position and
receiver position at two different times, the relative
velocity between receiver and satellite is computed as
Relative velocity (V ) ꢆ (R2 ꢄ R1)/(T2 ꢄ T1) (4)
rel
SV Clock Error Calculation
where R2 is the range between receiver and satellite
at time T2, and R1 is the range between receiver
Although the SV clock placed is an atomic clock,
this clock is affected by a small error. The SV clock
error is calculated using the SV clock correction
parameters present in the ephemeris data.
The update rate at each level depends on processor
speed, processor computational load, and the accu-
racy of the position fix in the receiver.
and satellite at time T1. Using V , the carrier
rel
Doppler frequency (Fd) is calculated as follows:
Fd ꢆ (V /C) · F
(5)
rel
L1
where FL1 is the L1 frequency (1575.42 MHz), and C
is the velocity of light in m/s.
6
0
Navigation
Spring 2003

Table 2—Maximum Computational Load of Level-1 Processor
Module
M/c Needed
Receiver position updating
12,102
111,992
80
Satellite relative velocity calculation
Frequency and change in frequency calculation
Signal power calculation
122
Code Doppler and chip period calculation
Approximate total for a single satellite
50
124,346
Each level-1 processor has to handle 4 channels. Total computational requirement ꢆ 124,346 · 4
6
Ϸ 498,000 M/c. For a 40 MHz processor, computational time ꢆ 498,000 ꢊ 10 Ϸ 12.45 ms.
Frequency and Change in Frequency Calculation
Signal Transmission Time Calculation
The total IF (F ) is calculated by eliminating
Doppler frequency:
From the given receiver time and the calculated
delays, the signal transmission time is calculated as
t
Total frequency F ꢆ F ꢄ Fd
(6)
Ttrans ꢆ t ꢄ tIONO ꢄ tTROPO ꢄ tPD ꢅ tsvclock (11)
t
IF
where FIF is the IF (4.3046 MHz). F is up converted
to RF in the hardware.
The change in frequency for 19.55 ꢇs is calcu-
lated as
where t is the receiver local time (in GPS seconds),
tIONO is ionospheric delay, tTROPO is tropospheric
delay, d(t) is the range between receiver and satel-
lite at time t, tPD is the propagation delay between
receiver and satellite at time t (d(t)/C), and tsvclock is
the SV clock error correction.
t
Fchange ꢆ ((Acc * F )/C) · 19.55 ꢇs
(7)
L1
where Acc is the change in relative velocity (accelera-
tion) between receiver and satellite. Acc is computed
by knowing the relative velocity betwen receiver and
satellite at two different times:
In the above equation, however, relativistic errors
[7] are considered negligible. The level-1 processor
sends the calculated data (Ttrans, F , and Fchange) of
t
2 channels to each level-2 processor every 20 ms.
As per the computational load given in Table 2,
the frequency word calculation requires a total com-
putational time of 12.5 ms. Hence the update period
of level-1 processors was fixed at 20 ms.
Acc ꢆ (Vrel(T1) ꢄ Vrel(T2))/T2 ꢄ T1
(8)
Code Doppler Calculation
The code Doppler shift is calculated as is done for
carrier Doppler frequency:
Tasks in Level-2 Processors
Fcd ꢆ Vrel · Fc/C
where Fc is the PRN code chipping rate
1.023 Mchip/s).
(9)
All level-2 processors store 32 satellite PRN codes
in memory in a look-up table format (a single satel-
lite requires 1023 locations) and navigation data
with a length of 1 superframe [9]. Navigation data is
generated by the host processor and provided to all
the level-2 processors before the start of the simula-
tion. After the existing navigation data (12.5 min)
has been placed in memory, the level-2 processor
updates it in a background process. Each level-2
processor handles 2 channels.
The update rate is chosen as 19.55 ꢇs because the
scheme is implemented in such a way that a level-2
processor downloads 20 PRN chips to the hard-
ware at a time (20 * single PRN code chip
duration Ϸ 19.55 ꢇs, where the single PRN code
chip duration is 1/1.023 MHz); also, as per the above
calculations, the frequency must be updated every
(
Signal Power Calculation
The signal power of all 32 satellites is set by the
user at the start of the simulation (S0 [in dBm]) and
will be varied as the simulation progresses.
2
2
S1 (in dBm) ꢆ S0 ꢅ 10 log (R0 /R1 )
(10)
S0 and S1 are the powers of the GPS signal at times
t and t1, and R0 and R1 are the range between
receiver and satellite at the times t and t1, respec-
tively. S0 is assigned a value input by the user at the
start of the simulation.
2
4 ꢇs. Since frequency and phase are downloaded to
Receiver Position Updating
the hardware at the same time, 19.55 ꢇs (minimum
of the above two) is chosen as the update rate. The
tasks assigned to level-2 processor are described
below.
If the receiver is dynamic, receiver position has to
be updated periodically. Here the receiver position is
updated in ECEF [7] coordinates every 20 ms.
Vol. 50, No. 1
Prasad et al.: Design of a Real-Time GPS Satellite Signal Simulator
61

Frequency Updating
Fchange is used here to update the frequency of the
signal to be transmitted every 19.55 ꢇs:
Ftransmit ꢆ F ꢅ F
(12)
come from a level-1 processor
change
t
change
The new F and F
t
every 20 ms.
Calculating the Starting Phase of the Signal
From the signal reception time, the level-2 proces-
sor calculates the starting phase of the signal for the
assigned satellites by calculating the number of
superframes, subframes, bits, epochs, and chips
elapsed in the transmission time. It also finds the
starting chip and the navigation bit to be transmitted.
Fig. 2–Hardware Implementation of RTGPSSS for Single Channel
Chip Period Calculation
The chip period gives the duration of the chip in
samples:
multipath signal is fed into one of the simulator free
channels. The free channels (not allocated to any
satellite) can be switched on for multipath effect for
any visible satellite. However, the effect of multi-
path is not investigated here.
All the modules at level-0 are running with 64-bit
precision to achieve high-precision results. Most of
the tasks at level-0 and level-1 are coded in C, and
most of the modules at level-2 are coded in assembly
language.
Chip period ꢆ (master clock frequency
of the hardware board)/(Fc ꢅ Fcd)
(13)
The master clock frequency is selected as
9.667 MHz, which results in an integer chip period
2
of 29 samples (with no Fcd). But in real scenarios,
Fcd exists, and this results in fractional chip peri-
ods. Since hardware can accept only an integer num-
ber of samples, fractional chip period is accumulat-
ed to obtain an integer number of samples and
added or subtracted from the original 29 samples,
depending on positive or negative Fcd.
PARALLEL ALGORITHM
The tasks carried out by each processor in the par-
allel processing system are presented in the following
algorithm.
The F , signal power, 20 PRN chips, and chip period,
t
which are used for calculating the frequency, phase,
and amplitude of the signal, respectively, are trans-
mitted by the level-2 processor to the hardware peri-
odically with a period of 19.55 ꢇs. At the start of the
simulation, the level-2 processor downloads the start-
ing chip and the number of samples present in the
starting chip. The 20 chips are exlusive-or’ed with the
navigation data bit before downloading to the hard-
ware. After 20 chips have been exhausted, the hard-
ware requests from the level-2 processor the next 20
chips. The level-2 processor downloads the next 20
chips, which are transmitted to the hardware, and the
sequence continues.
Level-0 processor
REPEAT for every 1s
BEGIN
Generate Constellation
Find Visible Satellites
Assign a channel for all Visible Satellites
Compute Ionospheric, Tropospheric,
Propagation delays and SV clock error
Send channel details to all 3 Level-1
processors, and Send data to HOST for
display
Figure 2 shows the hardware implementation for a
single channel. The FPGA collects all the data
coming from the level-2 processor and in turn passes
the data to the direct digital synthesizer (DDS) for IF
signal generation; the IF signal is then up converted
to the L1 frequency, as shown in Figure 2. More
detail on the implementation of the FPGA and the
hardware of the RTGPSSS is presented in [22].
The multipath signal for any of the visible satel-
lites is simulated by delaying the original signal by
a fraction of a chip and attenuating the signal. The
END
END
Level-1 processors
Do FOR ALL Processors (P1, P2, and P3)
BEGIN
REPEAT for every 1 s
BEGIN
Get 4-channel details from root processor
END
6
2
Navigation
Spring 2003

END
REPEAT for every 20 ms
BEGIN
FOR ALL enabled channels
Compute Vrel and Acc
Compute F and F
t
change
Send details of 2 channels to each level-2
processor
END FOR
END
END DO
Fig. 3–Receiver Output
Level-2 processors
Do FOR ALL Processors (P4, P5, P6, P7, P8 and P9)
BEGIN
REPEAT for every 20 ms
(
satellite IDs) are the best four satellites selected by
the GPS receiver to give the position fix, being
tracked in channels 04, 05, 06, and 08, respectively.
The corresponding status, constellation, ephemeris,
almanac, slew, Doppler, and average track value are
also shown in this figure.
Figure 4 shows a Gantt chart that presents the
processor utilization with respect to time for all
processors at each level. It is found that the processor
utilization of each level-2 processor is 80 percent, that
of each level-1 processor is 62 percent, and that of the
level-0 processor is 16 percent.
BEGIN
Get details of 2 channels from level-1
processor
END
REPEAT for every 19.55 ꢇs
FOR ALL channels
BEGIN
Compute Ftransmit
Send Ft, signal power, 20 PRN chips, and chip
period to hardware
CONCLUSION
END
END
The design of an RTGPSSS using a DSP-based
multiprocessing system has been presented in this
paper. The multiprocessing system generates phase
word, amplitude word, and frequency word. These
words are given to the FPGA-based hardware unit
for generating the real-time GPS signal. The
computational complexity of the GPS modules, the
load on each processor, processor connectivity for
efficient parallel implementation, and the rates at
which the frequency, phase, and amplitude of the
signal are to be downloaded to the FPGA have been
studied and verified.
RESULTS AND DISCUSSION
All the modules mentioned above are implemented
in the MULTISHARC system, and the results are
verified using a GPS receiver development board. The
host displays the data calculated by the level-0
processor—visible satellite list, channel allocated to
each satellite, and position of each satellite in ECEF
X,Y,Z) coordinates. The host also displays the four
best satellites selected using geometric dilution of
precision (GDOP).
The L1 signal (1575.42 MHz) generated by the
simulator is interfaced with the GPS receiver devel-
opment board, incorporating low dynamics in the
receiver position. The receiver is able to acquire,
track, and demodulate the navigation data bits
present in the signal. The receiver identifies and
extracts the almanac and ephemeris data present in
the navigation data. A sample of the test results for
the receiver for a signal simulated for a stationary
case is given in Figure 3.
(
The RTGPSSS generates different platform motion
profiles, stores them for repeated use, and calculates
The signal is simulated for the position 10 deg lat-
titude, 80 deg longitude, and 1000 m altitude. From
Figure 3, it can be observed that the receiver was
able to give the three-dimensional position fix using
four satellites. The corresponding speed, heading,
horizontal dilution of precision (HDOP), and posi-
tional dilution of precision (PDOP) values are dis-
played. It can also be seen that 17, 05, 10, and 09
Fig. 4–Gantt Chart
Vol. 50, No. 1
Prasad et al.: Design of a Real-Time GPS Satellite Signal Simulator
63

the frequency of the signal every 19.55 ꢇs. The overall
10. NAVSTAR, GPS Constellation Simulator SCS2400
Online).
11. NovATel’s GPS Timing Simulator—Document from
web.
(
efficiency of the parallel scheme is 66 percent, and the
2
pseudorate error is 0.04 m/s . In this design, the user
can select any position and time and generate the
corresponding visible satellite signals. The designed
simulator has been tested for the static and simple
dynamic receiver configuration.
1
1
1
2. BFGoodRich Aerospace, GNS 743A GPS/GLONASS
Satellite Simulator, JcAIR Systems, Charlotte, NC,
1998.
3. Sprint Communications, Low Cost Multi-channel
GPS/SBAS Simulation System STR4500, GSS,
(
Online).
4. Brown, A., N. Gerein, and K. Taylor, Modeling and
Simulation of GPS Using Software Signal Generation
and Digital Signal Reconstruction, Proceedings of the
ION National Technical Meeting, Anaheim, CA,
January 2000.
ACKNOWLEDGMENT
The authors acknowledge the Aeronautical
Research and Development Board (AR&DB),
Ministry of Information and Communication
Technology (Department of Electronics), New Delhi,
and Signals & Systems (SANDS), Chennai, for spon-
soring this project. The authors also acknowledge
the help given by Mr. Senthil Kumar of the
Electronics Department.
1
1
1
5. Brown, A., and N. Gerein, Advanced GPS Hybrid
Simulator Architecture, Proceedings of the ION
National Technical Meeting, Anaheim, CA, January
2000.
6. Papenfuss, J. R., and M. A. Wickert, A TMS320C6701/
FPGA Based Frequency Selective RF Channel
Simulator Using IF Sampling, TI DSPS Fest,
Houston, TX, August 2000.
7. Wickert, M. A., and J. Papenfuss, Implementation of
Real-Time Frequency Selective RF Channel Simulator
Using a Hybrid DSP-FPGA Architecture, IEEE Trans.
on Microwave Theory and Techniques, Vol. 49, No. 8,
August 2001, pp. 1390–1396.
REFERENCES
1. Getting, I. A. The Global Positioning System, IEEE
Spectrum, December 1993.
2
. Chandha, K., The Global Positioning System:
Challenges in Bringing GPS to Mainstream Consumers,
SiRF Technology, Inc., Santa Clara, CA, 1998.
18. Schweber, B., RF Channel Simulators, Bring Reality’s
Challenges to Your Prototype, EDN, September 11,
1998, pp. 52–64.
19. Analog Devices, ADSP-2106x SHARC User Manual,
2nd edition, 1997.
3
4
5
6
7
. Enge., P., and P. Misra, Scanning the Special Issue/
Technology on Global Positioning System, Proceedings
of IEEE, Vol. 87, January 1999, pp. 3–15.
. Lewandowski, W., J. Azoubib, and W. J. Klepczynski,
GPS: Primary Tool for Time Transfer, Proceedings of
IEEE, Vol. 87, No.1, January 1999, pp. 163–171.
. Herring, T. A., Geodetic Applications of GPS,
Proceedings of IEEE, Vol. 87, No. 1, January 1999,
pp. 92–109.
. Abbott, E., and D. Powell, Land-Vehicle Navigation
Using GPS, Proceedings of IEEE, Vol. 87, No. 1,
January 1999, pp. 144–161.
. Hofmann-Wellnhof, B., H. Lichtenegger and J. Collins,
Global Positioning System: Theory and Practice,
Fourth edition, Springer-Verlag Wien, New York,
20. Krishnan, C. N., P. V. Ramakrishna, V. Vaidehi,
G. Boopalan, S. V. M. K. Prasad, G. Ramya,
U. Chandra, J. Gnana Prakash, T. A. Sarangaram,
N. Kumar, and R. Ashok raj, Development of Real-
Time GPS Signal Simulator, Proceedings of the
Workshop on GPS Modernization and Augmentation
Systems, Osmania University, Hyderabad, February
2001, pp. 129–136.
21. Prasad, S. V. M. K., T. A. Sarangaram, G. Boopalan,
V. Vaidehi, C. N. Krishnan, and P. V. Ramakrishna,
Real-Time GPS Satellite Signal Simulator: Software
Design on a Multi SHARC Parallel Processing
System, Proc. of NCC, IITB, Mumbai, 2002, pp.
553–557.
22. Boopalan, G., S. V. M. K. Prasad, V. Vaidehi, C. N.
Krishnan, P. V. Ramakrishna, and L. R. Rajagopal,
Hardware Design for GPS Signal Simulators, Proc. of
NCC, IIT Bombay, Mumbai, 2002, pp. 84–69.
23. Spectrum Signal Processing, Apex-Lite, Apex-Debug,
Apex-Trace, Darlington SHARC3000 PCI Mother-
board Manuals, Revision 2.0, Burnaby, B. C., Canada
July 1998.
1997.
8. Parkinson, B. W., and J. J. Spilker Jr., Global
Positioning System: Theory and Applications, Volumes
1
& 2, American Institute of Aeronautics and
Astronautics, 1996.
9
. Krishnan, C. N., P. V. Ramakrishana, and V. Vaidehi,
Real Time GPS Signal Simulator Development,
Interim Technical Report and Documentation,
Electronics Engineering Department, Madras
Institute of Technology, April 1999.
6
4
Navigation
Spring 2003
