H.-J. Seo et al. / Organic Electronics 11 (2010) 564–572
571
7.8 Hz), 7.76 (d, 1H, J = 4.5 Hz), 7.49 (t, 1H, 5.7 Hz), 7.12 (d,
1H, J = 6.0 Hz), 6.90 (d, 1H, J = 6.3 Hz), 5.64 (d, 1H,
J = 10.2 Hz), 5.69 (d, 1H, J = 10.8), 2.59 (s, 6H). Anal. Calc.
for C32H18F10IrN3O3: C, 43.94; H, 2.07; N, 4.80. Found: C,
44.18; H, 2.35; N, 4.57%.
the Korea government (MEST) (No. M10600000157-
06J0000-15710) and Strategic Technology under Ministry
of Knowledge Economy of Korea.
Appendix A. Supplementary data
4.6. Measurements of physical and electrochemical properties
Supplementary data associated with this article can be
UV–visible absorption spectra of 6 and 7 were recorded
by using a Varian 5000 spectrophotometer. Photolumines-
cence (PL) spectra were measured with a He:Cd laser (k:
325 nm, and continuous wave) as the excitation light
source and a photomultiplier tube (PMT, Hamamatsu) with
a monochromator (Acton Research Co., SpectraPro 2300i)
as the detector. Cyclic voltammograms (CV) of the Ir(III)
complexes were recorded by using a Princeton Applied Re-
search (AMETEK VSP) potentiostat at room temperature on
0.1 M solutions of the Ir(III) complexes in acetonitrile or
dichloromethane containing tetrabutylammonium per-
chlorate (Bu4NClO4) at a scan rate of 100 mV/s under nitro-
gen gas. Pt was used as the working and counter electrode
and Ag/AgCl electrode as the reference electrode.
References
[1] C.W. Tang, S.A. Van Slyke, Appl. Phys. Lett. 51 (1987) 913.
[2] R.H. Friend, R.W. Gymer, A.B. Holmes, J.H. Burroughes, R.N. Marks, C.
Taliani, D.D.C. Bradley, D.A. Dos Santos, J.L. Bredas, M. Logdlund, W.R.
Salaneck, W.R. Nature (London) 397 (1999) 121.
[3] R.J. Tseng, R.C. Chiechi, F. Wudl, Y. Yang, Appl. Phys. Lett. 88 (2006)
093512.
[4] B.W. D’Andrade, S.R. Forrest, Adv. Mater. 16 (2004) 1585.
[5] S. Lamansky, P. Djurovich, D. Murphy, F. Abdel-Razzaq, H.E. Lee, C.
Adachi, P.E. Burrows, S.R. Forrest, M.E. Thompson, J. Am. Chem. Soc.
123 (2001) 4304.
[6] W. Zhu, Y. Mo, M. Yuan, W. Yang, Y. Cao, Appl. Phys. Lett. 80 (2002)
2045.
[7] X. Gong, J.C. Ostrowski, G.C. Bazan, D. Moses, A.J. Heeger, Appl. Phys.
Lett. 81 (2002) 3711.
[8] K.R.J. Thomas, M. Velusamy, J.T. Lin, C.H. Chien, Y.T. Tao, Y.S. Wen,
Y.H. Hu, P.T. Chou, Inorg. Chem. 44 (2005) 5677.
[9] W. Lu, B.X. Mi, M.C.W. Chan, Z. Hui, C.M. Che, N. Zhu, S.T. Lee, J. Am.
Chem. Soc. 126 (2004) 4958.
[10] C.H. Huang, F.Y. Li, W. Huang, Introduction to Organic Light-Emitting
Materials and Devices, Fudan University, Shanghai, China, 2005.
[11] M.A. Baldo, S. Lamansky, P.E. Burrows, M.E. Thompson, S.R. Forrest,
Appl. Phys. Lett. 75 (1999) 4.
[12] Y.S. Park, J.W. Kang, D.M. Kang, J.W. Park, Y.H. Kim, S.K. Kwon, J.J.
Kim, Adv. Mater. 20 (2008) 1957.
[13] D.M. Kang, J.W. Kang, J.W. Park, S.O. Jung, S.H. Lee, D. Park, Y.H. Kim,
S.C. Shin, J.J. Kim, S.K. Kwon, Adv. Mater. 20 (2008) 2003.
[14] K.S. Yook, S.O. Jeon, C.W. Joo, J.Y. Lee, Appl. Phys. Lett. 93 (2008)
113301.
[15] J.J. Park, T.J. Park, W.S. Jeon, R. Pode, J. Jang, J.H. Kwon, E.S. Yu, M.Y.
Chae, Org. Electron. 10 (2009) 189.
[16] J. Lee, J.I. Lee, K.I. Song, S.J. Lee, H.Y. Chu, Appl. Phys. Lett. 92 (2008)
133304.
[17] J. Brooks, Y. Babayan, S. Lamansky, P.I. Djurovich, I. Tsyba, R. Bau,
M.E. Thompson, Inorg. Chem. 41 (2002) 3055.
The PL efficiencies of doped films containing 6 and 7
were measured using the integrating sphere (Newport)
with a He:Cd laser (k: 325 nm, and continuous wave) as
the excitation light source. The absolute PL efficiency mea-
surement system was calibrated by using two standard
lamps of LS-1-CAL calibrated light source and DH-2000
deuterium–tungsten halogen light source (Ocean Optics,
Inc.). Transient photoluminescence of the phosphorescent
dye doped films were measured using a Nd:YAG laser (k:
355 nm, 10 Hz, and 9 ns pulse width) as the excitation light
source and PMT (Hamamatsu) with a monochromator
(Acton Research Co., SpectraPro 2300i) as the detector.
The samples were kept in a vacuum chamber maintained
at pressures under 10ꢁ3 Torr during the measurement.
4.7. Fabrication of the PhOLEDs using Ir(III) complexes 6
and 7
[18] P.C. Wu, J.K. Yu, Y.H. Song, Y. Chi, P.T. Chou, S.M. Peng, G.H. Lee,
Organometallics 22 (2003) 4938.
The PhOLEDs were fabricated by using thermal evapora-
tion onto a cleaned glass substrate precoated with indium
tin oxide (ITO) under a vacuum. Prior to organic layer depo-
sition, the ITO substrates were exposed to UV-ozone flux for
10 min following degreasing in acetone and isopropyl
alcohol. All of the organic layers were deposited by using
thermal evaporation at a base pressure of <5 ꢂ 10ꢁ8 Torr.
Current density–voltage–luminescence (J–V–L) character-
istics of the PhOLEDs were measured simultaneously using
a Keithley 2400 programmable source meter and Spectra-
Scan PR650 (Photo Research). All the materials were
purified using train sublimation before use.
[19] D. Tanaka, Y. Agata, T. Takeda, S. Watanabe, J. Kido, Jpn. J. Appl. Phys.
46 (2007) L117.
[20] S.J. Su, E. Gonmori, H. Sasabe, J. Kido, Adv. Mater. 20 (2008) 4189.
[21] C. Yang, X. Zhang, H. You, L. Zhu, L. Chen, L. Zhu, Y. Tao, D. Ma, Z.
Shuai, J. Qin, Adv. Funct. Mater. 17 (2007) 651.
[22] K. Dedeian, J. Shi, N. Shepherd, E. Forsythe, D.C. Morton, Inorg. Chem.
44 (2005) 4445.
[23] C.H. Yang, S.W. Li, Y. Chi, Inorg. Chem. 44 (2005) 7770.
[24] T. Sajoto, P.I. Djurovich, A. Tamayo, M. Yousufuddin, R. Bau, M.E.
Thompson, Inorg. Chem. 44 (2005) 7992.
[25] H. Fukagawa, K. Watanabe, T. Tsuzuki, S. Tokito, Appl. Phys. Lett. 93
(2008) 133312.
[26] Y. Zheng, S.H. Eom, N. Chopra, J. Lee, F. So, J. Xue, Appl. Phys. Lett. 89
(2008) 2343.
[27] H. Jang, C.H. Shin, N.G. Kim, K.Y. Hwang, Y. Do, Synth. Met. 154
(2005) 157.
[28] S.Y. Kim, J.H. Kim, Y. Ha, S.H. Lee, J.H. Seo, Y.K. Kim, Curr. Appl. Phys.
7 (2007) 380.
Acknowledgement
[29] S.C. Lee, Y.S. Kim, Mol. Cryst. Liq. Cryst. 2491 (2008) 209.
[30] V. Adamovich, J. Brooks, A. Tamayo, A.M. Alexander, P.I. Djurovich,
B.W. D’Andrade, C. Adachi, S.R. Forrest, M.E. Thompson, New J. Chem.
26 (2002) 1171.
[31] A.B. Tamayo, B.D. Alleyne, P.I. Djurovich, S. Lamansky, I. Tsyba, N.N.
Ho, R. Bau, J. Am. Chem. Soc. 125 (2003) 7377.
[32] P. Coppo, E.A. Plummer, L.D. Cola, Chem. Commun. 2004 (1774).
[33] S.J. Yeh, M.F. Wu, C.T. Chen, Y.H. Song, Y. Chi, M.H. Ho, S.F. Hsu, C.H.
Chen, Adv. Mater. 17 (2005) 285.
This research was supported by a grant (2009K000069)
from Center for Nanoscale Mechatronics and Manufactur-
ing, one of the 21st Century Frontier Research Programs,
which are supported by Ministry of Education, Science
andTechnology. This work was supported by the Korea Sci-
ence and Engineering Foundation (KOSEF) grant funded by
