Self-Assembled Fluorescent Pt(II) Metallacycles as Artificial Light-Harvesting Systems

Article abstract of DOI:10.1021/jacs.9b08403

Light-harvesting is one of the key steps in photosynthesis, but developing artificial light-harvesting systems (LHSs) with high energy transfer efficiencies has been a challenging task. Here we report fluorescent hexagonal Pt(II) metallacycles as a new platform to fabricate artificial LHSs. The metallacycles (4 and 5) are easily accessible by coordination-driven self-assembly of a triphenylamine-based ditopic ligand 1 with di-platinum acceptors 2 and 3, respectively. They possess good fluorescence properties both in solution and in the solid state. Notably, the metallacycles show aggregation-induced emission enhancement (AIEE) characteristics in a DMSO-H₂O solvent system. In the presence of the fluorescent dye Eosin Y (ESY), the emission intensities of the metallacycles decrease but the emission intensity of ESY increases. The absorption spectrum of ESY and the emission spectra of the metallacycles show a considerable overlap, suggesting the possibility of energy transfer from the metallacycles to ESY, with an energy transfer efficiency as high as 65% in the 4^a+ESY system.

Full text of DOI:10.1021/jacs.9b08403

Subscriber access provided by University of Otago Library
Communication
Self-Assembled Fluorescent Pt(II) Metallacycles
as Artificial Light-Harvesting Systems
Koushik Acharyya, Soumalya Bhattacharyya, Hajar Sepehrpour, Shubhadip Chakraborty,
Shuai Lu, Bingbing Shi, Xiaopeng Li, Partha Sarathi Mukherjee, and Peter J. Stang
J. Am. Chem. Soc., Just Accepted Manuscript • Publication Date (Web): 03 Sep 2019
Downloaded from pubs.acs.org on September 3, 2019
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a service to the research community to expedite the dissemination
of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts appear in
full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been fully
peer reviewed, but should not be considered the official version of record. They are citable by the
Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered to authors. Therefore,
the “Just Accepted” Web site may not include all articles that will be published in the journal. After
a manuscript is technically edited and formatted, it will be removed from the “Just Accepted” Web
site and published as an ASAP article. Note that technical editing may introduce minor changes
to the manuscript text and/or graphics which could affect content, and all legal disclaimers and
ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors or
consequences arising from the use of information contained in these “Just Accepted” manuscripts.
is published by the American Chemical Society. 1155 Sixteenth Street N.W.,
Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 6
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
Self-Assembled Fluorescent Pt(II) Metallacycles as Artificial
Light-Harvesting Systems
Koushik Acharyya,*† Soumalya Bhattacharyya,‡ Hajar Sepehrpour,† Shubhadip Chakraborty,¶
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Shuai Lu,§ Bingbing Shi,† Xiaopeng Li,§ Partha Sarathi Mukherjee,* ‡ and Peter J. Stang*†
†Department of Chemistry, University of Utah, 315 South 1400 East, Room 2020, Salt Lake City, Utah 84112, United States
‡Department of Inorganic and Physical Chemistry, Indian Institute of Science, Bangalore 560012, India
¶Institut de Physique de Rennes, UMR CNRS 6251, Université de Rennes 1, Campus de Beaulieu, 35042 Rennes Cedex,
France
§Department of Chemistry, University of South Florida, 4202 East Fowler Avenue, Tampa, Florida 33620, United States
Supporting Information Placeholder
should not suffer fluorescence quenching in their closely packed
arrangements.
ABSTRACT: Light-harvesting is one of the key steps in
photosynthesis, while, developing artificial light-harvesting
systems (LHSs) with high energy transfer efficiencies has
been a challenging task. Here we report fluorescent hexagonal
Pt(II) metallacycles as a new platform to fabricate artificial LHSs.
The metallacycles (4 and 5) are easily accessible by coordination
driven self-assembly of a triphenylamine-based ditopic ligand 1
with di-platinum acceptors 2 and 3, respectively. They possess
good fluorescence properties both in solution and in the solid
state. Notably, the metallacycles show aggregation induced
emission enhancement characteristics (AIEE) in a DMSO-H2O
solvent system. In the presence of a fluorescent dye Eosin Y
(ESY), the emission intensities of the metallacycles decrease but
the emission intensity of ESY increases. The absorption spectrum
of ESY and the emission spectra of the metallacycles show a
considerable overlap, suggesting the possibility of energy transfer
from the metallacycles to ESY, with an energy transfer efficiency
as high as 65% in the 4a+ESY system.
The LHSs reported to date could be broadly classified into two
categories: a) covalently bonded networks and b) self-assembled
architectures. The former one has the advantage of providing a
stable platform but it needs laborious synthetic steps. In contrast,
self-assembled architectures could be easily obtained by mixing
appropriate building blocks under suitable conditions. Therefore,
supramolecular coordination complexes (SCCs) with easy
synthetic accessibility, well-defined shapes, sizes, easy solution
processability and tunable photophysical properties could be
interesting materials for light harvesting.
Over the past few decades several SCCs like one dimensional
(1D) helices, two dimensional (2D) polygons and three-
dimensional (3D) polyhedrons have been developed utilizing the
directional coordination bonding approach.9 Such SSCs are found
to be attractive materials owing to their widespread applications in
catalysis,10 sensing,11 biomedical science,12 proton conduction,13
and so on. Although several luminescent platinum based
metallacycles and cages have been reported,14 their application
towards light harvesting is in its infancy.15 We report here two
new fluorescent hexagonal platinum (II) metallacycles 4 and 5
(Figure 1), along with their light-harvesting properties.
Photosynthesis is the main energy source for the survival of the
living world. The natural photosynthesis process that takes place
in the green plants and other organisms starts with the absorption
of light energy (sunlight) by a large number of closely packed
green pigments chlorophyll, embedded in a complex known as
antenna protein or light-harvesting complex.1 Subsequently, the
absorbed energy funnels through chlorophylls to the reaction
center where light energy transforms into chemical energy
(carbohydrates, like sugar). Inspired by nature chemists have
developed several artificial light-harvesting systems (LHSs) to
understand the key aspects of the process, intricacies of the
mechanism along with their potential applications in
The desired metallacycles were designed and synthesized from
ditopic organic donor 1 and di-platinum (II) acceptors 2 and 3
(Figure 1). Ligand 1 has a triphenylamine core with a
cyanostilbene moiety decorated with an alkyl chain bearing a
phenyl group, which could facilitate supramolecular assembly
formation through non-covalent interactions.16 The cyanostilbene
moiety has interesting optical properties of aggregation induced
emission enhancement (AIEE), as a result of their restricted
rotation in the aggregate state.17 Moreover, the cyanostilbene
moieties promote self-assembly to form various nano-
architectures. Accordingly, the metallacycles may easily form
supramolecular assemblies, and in their closely packed state will
not suffer fluorescence quenching and thus, could serve as an
excellent platform for light harvesting.
photosynthesis, photocatalysis, and photovoltaics. In this context,
2
wide varieties of scaffolds such as dendrimers,
organo or
hydrogels, vesicles,4 micelles, host-guest assemblies,6 metal-
3
5
organic frameworks, organic polymers8 and so on have been
7
utilized in the last few years.
The hexagonal [3+3] metallacycle 4 was readily accessible by
stirring an equal molar mixture of 1 and Pt-acceptor 2 in a mixed
solvent system of dichloromethane-methanol (1:1; v/v) at
There are two prime factors that one should take into account to
achieve high energy collection efficiency in LHSs: I) the system
should possess multiple donors per acceptor and II) the donors
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 2 of 6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 1. Metallacycles 4, 5 and the building blocks 1, 2, and 3.
room temperature for 6 h; a [6+6] metallacycle 5 was obtained
from 1 and Pt-acceptor 3, under similar reaction conditions
(Schemes S2 and S3). The metallacycles were obtained as yellow
solids upon addition of diethyl ether onto the reaction mixtures,
and were characterized by various spectroscopic techniques like
1
1
1H NMR, 31P{1H} NMR, H-1H COSY, 2D diffusion-ordered H
NMR spectroscopy (DOSY), and electrospray ionization time-of-
flight mass spectrometry (ESI-TOF-MS) analysis (Figures S1-
S14).
In the 1H NMR spectrum of 4 characteristic NMR signals
corresponding to 1 and the Pt acceptor 2 observed at around 8.57
ppm and 7.12-7.19 ppm respectively with a 1:1 intensity ratio
indicated the formation of [3+3] assembly (Figures 2a and S4).
1
Similarly, metallacycle 5 formation was indicated by H NMR
signals with a 1:1 intensity ratio corresponding to the ligand 1 and
Pt-acceptor 3 at around 8.56 ppm and 7.19 ppm respectively
(Figure S8). The 31P{1H} NMR of both metallacycles displayed
sharp singlet peaks (Figures 2b and S9) with concomitant 195Pt
satellites (δ= 16.06 ppm and 16.30 ppm for 4 and 5 respectively),
which indicated the presence of only one type of phosphorus in
the assemblies, confirming the formation of highly symmetric
structures. An upfield shift of ~ 6 ppm was observed in the
31P{1H} NMR of the metallacycles with respect to their
corresponding Pt-building blocks, attributed to the metal-ligand
coordination. The stoichiometry of the formation of metallacycles
4
and 5 was confirmed by ESI-TOF-MS analysis. For
metallacycle 4, isotopic patterns of the peaks at m/z 1053.24 Da
and 852.84 Da for the [M-5OTf]5+ and [M-6OTf]6+ respectively
matches well with their calculated isotopic distribution patterns
(Figure 2c). In contrast, the larger metallacycle 5 shows a peak at
m/z 1186.82 Da for [M-9OTf]9+, however, the isotopic
distribution pattern suggests that the peak is actually due to two
fragments X3+ and Y6+(Figures S11 and S12) resulting from [M-
9OTf]9+.
1
Figure 2. (a) H NMR (400 MHz, CD2Cl2, 298 K) and (b)
31P{1H} NMR (121.4 MHz, CD2Cl2, 298 K) spectra of the
metallacycle 4 and its building blocks, (c) experimental (red) and
calculated (blue) ESI-TOF-MS spectra of 4.
ACS Paragon Plus Environment

Page 3 of 6
Journal of the American Chemical Society
Moreover, single diffusion bands at 7.6× 10-9 m2/sec and 3.6×
Figure 3. TEM images of (a) 4, (b) 5, SEM images of (c) 4, (d) 5,
and DLS profiles of (e) 4, (f) 5 in H2O-DMSO (4:1; v/v). Insets:
TEM image of a single spherical particle.
1
1
2
3
4
5
6
7
8
10-9 m2/sec in the H DOSY NMR spectra (Figures S13 and S14)
of 4 and 5 respectively are in agreement with the formation of a
single product in the reaction. To gain further insight into the
structural characteristics of the metallacycles PM6 semi-empirical
calculations were carried out, where the ethyl groups of the
phosphine ligands were modeled as hydrogen atoms. The
computational results indicate that the metallacycles have an
almost planar hexagonal backbone, with internal cavity sizes of
around 3.2 nm and 6.6 nm for 4 and 5 respectively (Figures S15
and S16).
The morphologies of the metallacycles in the aggregated state
were investigated by scanning electronic microscopy (SEM) and
transmission electron microscopy (TEM). The TEM analysis
(Figures 3a and 3b) shows the formation of spherical particles,
while the SEM analysis suggests an agglomeration of these
spherical particles (Figure 3c and 3d). Dynamic light scattering
(DLS) experiments (Figures 3e and 3f) provided average
hydrodynamic diameters of the aggregates of around 250 nm and
174 nm for 4 and 5 respectively in H2O-DMSO (4:1; v/v).
9
The photophysical properties of the metallacycles were
investigated in DMSO. The UV-Vis spectrum of 4 exhibits two
absorption bands at around 300 nm and 400 nm, whereas, 5 has
absorption bands at around 340 nm and 400 nm (Figure S17 and
S18). Upon excitation at 410 nm both metallacycles display
similar emission pattern with an emission maximum at 521 nm
(Figure S19). The absorption and emission of the metallacycles
were also investigated in various solvents, which did not indicate
any significant solvatochromic characteristics (Figure S20). With
increasing water content in the DMSO solution of the
metallacycle (4 or 5), a substantial increase in fluorescence
intensity is observed (Figures S21 and S22), as expected due to
the presence of the cyanostilbene moieties that facilitate AIEE.
The highest emission intensity was observed in 80% H2O/DMSO,
while further increase in water fraction leads to a decrease in
emission intensity, presumably due to the precipitation of the
metallacycles. This AIEE behavior is also supported by a sharp
increase in fluorescence quantum yields (φ) of the metallacycles
in the solid-state and in the aggregates (4a and 5a). For instance,
fluorescence quantum yield of 4 was found to be 28 % in the
solid-state and 17 % in a H2O-DMSO (4:1; v/v) solvent system,
which are substantially higher than the quantum yield of the
metallacycle in the DMSO solution (φ= 9 %). A similar trend was
observed in metallacycle 5, which has fluorescence quantum
yields of 33 %, 28 % and 10 % in the solid-state, H2O-DMSO
solvent system (4:1; v/v) and in a DMSO solution respectively
(Table S1).18
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 4. Fluorescence spectra of the metallacycles (a) 4 and (b)
5 with gradual addition of ESY (λex= 410 nm) in H2O-DMSO
(4:1; v/v). Change in the fluorescence decay profiles of the
metallacycles (c) 4 and (d) 5 in presence of ESY (metallacycle:
ESY
= 20:1) in H2O-DMSO (4:1; v/v). (e) A cartoon
representation of light harvesting system generated from 4 and
ESY, with visible color change of the solution under 365 nm UV
light in H2O-DMSO (4:1; v/v).
These results indicated that a H2O-DMSO (4:1; v/v) solvent
system would be the best medium to investigate the light-
harvesting property of the metallacycles, as under such
aggregated state the metallacycles showed the highest
fluorescence emission without any self-quenching and
precipitation from the solution. To prepare the LHSs we used the
fluorescent dye Eosin Y (ESY) as a fluorescence energy acceptor.
It is worth noting that for efficient energy transfer the absorption
band of the acceptor should overlap with the emission band of the
donor. The UV-Vis spectrum of ESY in H2O-DMSO has an
absorption band from 430 nm to 550 nm with an absorption
maximum at 520 nm. As shown in Figure S23 the absorption
spectrum of ESY and the emission spectra of the metallacycles
overlap well, suggesting the possibility of energy transfer from
the metallacycles to ESY. When a 1 μM solution (H2O-DMSO,
4:1, v/v) of ESY was gradually added to a 3 mL 1 μM solution
(H2O-DMSO, 4:1, v/v) of a metallacycle (4 or 5), a sharp decrease
in emission intensity of the metallacycle was observed (Figures 4a
and 4b), and the fluorescence intensity corresponding to ESY was
found to increase upon excitation at 410 nm. In contrast, under
3
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 4 of 6
(2) (a) Ziessel, R.; Ulrich, G.; Haefele, A.; Harriman, A. An Artificial
similar condition, ESY alone was found to be non-emissive upon
excitation at 410 nm (Figure S24), ruling out the possibility of
direct excitation of ESY. Moreover, a substantial increase in the
quantum yields of the metallacycles was observed in the presence
of ESY, which suggests that ESY accepts and emits most of the
excitation energy. The energy transfer efficiencies are calculated
as 65 % and 52 % in the 4a+ESYand 5a+ESY systems
respectively at a 10:1 donor/acceptor ratio, which are comparable
with some of the recently reported single molecule based
supramolecular light-harvesting systems.15,19
Light-Harvesting Array Constructed from Multiple Bodipy Dyes. J. Am.
Chem. Soc. 2013, 135, 11330-11344. (b) Shi, Y.; Cao, X.; Hu, D.; Gao,
H. Highly Branched Polymers with Layered Structures that Mimic Light-
Harvesting Processes. Angew. Chem. Int. Ed. Engl. 2018, 57, 516-520.
1
2
3
4
5
6
7
8
(3) (a) Ajayaghosh, A.; Praveen, V. K.; Vijayakumar, C.; George, S. J.
Molecular
Wire
Encapsulated
into
πꢀOrganogels:
Efficient
Supramolecular Light-Harvesting Antennae with Color-Tunable
Emission. Angew. Chem. Int. Ed. Engl. 2007, 46, 6260-6265. (b) Ardoña,
H. A. M.; Draper, E. R.; Citossi, F.; Wallace, M.; Serpell, L. C.; Adams,
D. J.; Tovar, J. D. Kinetically Controlled Coassembly of
Multichromophoric Peptide Hydrogelators and the Impacts on Energy
Transport. J. Am. Chem. Soc. 2017, 139, 8685-8692.
9
The best way to understand the energy transfer process is to
measure the fluorescence lifetime of the donor in the presence of
the acceptor. Therefore, fluorescence decay experiments were
carried out to support the occurrence of the light-harvesting
process. The fluorescence lifetime of the metallacycle 4 (τ1= 0.75
ns and τ2 = 2.94 ns) was found to be higher than the fluorescence
lifetime of 4 in the presence of ESY (τ1= 0.51 ns and τ2 = 2.65 ns)
(Figure 4c). Similarly, the fluorescence lifetime of the assembly
of 5 and ESY (τ1= 0.57 ns and τ2 = 2.86 ns) was found to be
shorter (Figure 4d) than the fluorescence lifetime of 5 (τ1= 0.75 ns
and τ2 = 2.97 ns). These results indicate that the energy transfer
takes place from the metallacycle to the ESY (Figure 4e).
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
(4) (a) Calver, C. F.; Schanze, K. S.; Cosa, G. Biomimetic Light-
Harvesting Antenna Based on the Self-Assembly of Conjugated
Polyelectrolytes Embedded within Lipid Membranes. ACS Nano 2016, 10,
10598-10605. (b) Okazawa, Y.; Kondo, K.; Akita, M.; Yoshizawa, M.
Polyaromatic Nanocapsules Displaying Aggregation-Induced Enhanced
Emissions in Water. J. Am. Chem. Soc. 2015, 137, 98−101.
(5) (a) Liu, Y.; Jin, J.; Deng, H.; Li, K.; Zheng, Y.; Yu, C.; Zhou, Y.
Protein-Framed Multi-Porphyrin Micelles for a Hybrid Natural–Artificial
Light-Harvesting Nanosystem. Angew. Chem. Int. Ed. Engl. 2016, 55,
7952-7957. (b) Li, C.; Zhang, J.; Zhang, S.; Zhao, Y. Efficient Light-
Harvesting Systems with Tunable Emission through Controlled
Precipitation in Confined Nanospace. Angew. Chem. Int. Ed. Engl. 2019,
58, 1643-1647.
In conclusion, two fluorescent hexagonal metallacycles (4 and
5) were devised to construct artificial light-harvesting systems.
The metallacycles were found to have good fluorescence
properties and AIEE characteristics. Most importantly, simple
mixing of the acceptor (Eosin Y) and a metallacycle, results in an
efficient Förster resonance energy transfer (FRET) process
between the metallacycle and ESY, leading to the in-situ
formation of an efficient artificial LHS. These artificial LHSs
exhibit good energy transfer efficiencies, as high as 65% in the
4a+ESY system at a 10:1 donor/acceptor ratio. We anticipate that
understanding the light-harvesting properties in such
supramolecular coordination complexes will open up new
possibilities for the design and fabrication of LHSs in the future.
(6) (a) Li, J.-J.; Chen, Y.; Yu, J.; Cheng, N.; Liu, Y. A Supramolecular
Artificial Light-Harvesting System with an Ultrahigh Antenna Effect.
Adv. Mater. 2017, 29, 1701905. (b) Guo, S.; Song, Y.; He, Y.; Hu, X.-Y.;
Wang, L. Highly Efficient Artificial Light-Harvesting Systems
Constructed in Aqueous Solution Based on Supramolecular Self-
Assembly. Angew. Chem. Int. Ed. Engl. 2018, 57, 3163-3167.
(7) (a) Williams, D. E.; Rietman, J. A.; Maier, J. M.; Tan, R.; Greytak, A.
B.; Smith, M. D.; Krause, J. A.; Shustova, N. B. Energy Transfer on
Demand:
Photoswitch-Directed
Behavior
of
Metal–Porphyrin
Frameworks. J. Am. Chem. Soc. 2014, 136, 11886-11889. (b) Lee, H.;
Jeong, Y.-H.; Kim, J.-H.; Kim, I.; Lee, E.; Jang, W.-D. Supramolecular
Coordination Polymer Formed from Artificial Light-Harvesting
Dendrimer. J. Am. Chem. Soc. 2015, 137, 12394-12399.
(8) (a) Winiger, C. B.; Li, S.; Kumar, G. R.; Langenegger, S. M.; Häner,
R. Long-Distance Electronic Energy Transfer in Light-Harvesting
Supramolecular Polymers. Angew. Chem. Int. Ed. Engl. 2014, 53, 13609-
13613. (b) Jiang, Y.; McNeill, J. Light-Harvesting and Amplified Energy
Transfer in Conjugated Polymer Nanoparticles. Chem. Rev.2017, 117,
838-859.
ASSOCIATED CONTENT
Supporting Information
Experimental details and characterization data of all new
compounds.
The Supporting Information is available free of charge on the
http://pubs.acs.org.
(9) (a) Sato, S.; Iida, J.; Suzuki, K.; Kawano, M.; Ozeki, T.; Fujita, M.
Fluorous Nanodroplets Structurally Confined in an Organopalladium
Sphere. Science 2006, 313, 1273-1276. (b) Pluth, M. D.; Bergman, R. G.;
Raymond, K. N. Acid Catalysis in Basic Solution: A Supramolecular Host
Promotes Orthoformate Hydrolysis. Science 2007, 316, 85-88. (c) Park,
K.-M.; Kim, S.-Y.; Heo, J.; Whang, D.; Sakamoto, S.; Yamaguchi, K.;
Kim, K. Designed Self-Assembly of Molecular Necklaces. J. Am. Chem.
Soc. 2002, 124, 2140-2147. (d) Freye, S.; Michel, R.; Stalke, D.;
Pawliczek, M.; Frauendorf, H.; Clever, G. H. Template Control over
Dimerization and Guest Selectivity of Interpenetrated Coordination
Cages. J. Am. Chem. Soc. 2013, 135, 8476-8479. (e) Li, S.; Huang, J.;
Cook, T. R.; Pollock, J. B.; Kim, H.; Chi, K.-W.; Stang, P. J. Formation of
[3]Catenanes from 10 Precursors via Multicomponent Coordination-
Driven Self-Assembly of Metallarectangles. J. Am. Chem. Soc. 2013, 135,
2084-2087. (f) Chakrabarty, R.; Mukherjee, P. S.; Stang, P. J.
Supramolecular Coordination: Self-Assembly of Finite Two- and Three-
Dimensional Ensembles. Chem. Rev.2011, 111, 6810-6918. (g) Forgan, R.
S.; Sauvage, J.-P.; Stoddart, J. F. Chemical Topology: Complex Molecular
Knots, Links, and Entanglements. Chem. Rev.2011, 111, 5434-5464. (h)
Ayme, J.-F.; Beves, J. E.; Leigh, D. A.; McBurney, R. T.; Rissanen, K.;
Schultz, D. Pentameric Circular Iron(II) Double Helicates and a Molecular
Pentafoil Knot. J. Am. Chem. Soc. 2012, 134, 9488-9497. (i) Saha, M. L.;
Schmittel, M. From 3-Fold Completive Self-Sorting of a Nine-Component
Library to a Seven-Component Scalene Quadrilateral. J. Am. Chem. Soc.
2013, 135, 17743-17746. (j) Yan, X.; Jiang, B.; Cook, T. R.; Zhang, Y.;
Li, J.; Yu, Y.; Huang, F.; Yang, H.-B.; Stang, P. J. Dendronized
Organoplatinum(II) Metallacyclic Polymers Constructed by Hierarchical
Coordination-Driven Self-Assembly and Hydrogen-Bonding Interfaces. J.
Am. Chem. Soc. 2013, 135, 16813-16816. (k) Sun, Y.; Li, S.; Zhou, Z.;
AUTHOR INFORMATION
Corresponding Authors
koushikchemistry@gmail.com
psm@iisc.ac.in
stang@chem.utah.edu
Notes
The authors declare no competing financial interests.
ACKNOWLEDGMENT
P.J.S. thanks the U.S. National Institutes of Health (Grant R01
CA215157) for financial support. P.S.M. thanks the SERB (India)
for financial support (Grant No. CRG/2018/000315). S.B. thanks
CSIR India for research fellowship. K. A. is thankful to Heng
Wang and Ruidong Ni for their help in ESI-TOF-MS analysis.
REFERNCES
(1) McDermott, G.; Prince, S. M.; Freer, A. A.; Hawthornthwaite-
Lawless, A. M.; Papiz, M. Z.; Cogdell, R. J.; Isaacs, N. W. Crystal
structure of an integral membrane light-harvesting complex from
photosynthetic bacteria. Nature 1995, 374, 517-521.
4
ACS Paragon Plus Environment

Page 5 of 6
Journal of the American Chemical Society
Saha, M. L.; Datta, S.; Zhang, M.; Yan, X.; Tian, D.; Wang, H.; Wang, L.;
metallacages. Nat. Chem. 2015, 7, 342. (c) Zhou, Z.; Chen, D.-G.; Saha,
M. L.; Wang, H.; Li, X.; Chou, P.-T.; Stang, P. J. Designed Conformation
and Fluorescence Properties of Self-Assembled Phenazine-Cored
Platinum(II) Metallacycles. J. Am. Chem. Soc. 2019, 141, 5535-5543. (d)
Bhattacharyya, S.; Chowdhury, A.; Saha, R.; Mukherjee, P. S.
Multifunctional Self-Assembled Macrocycles with Enhanced Emission
and Reversible Photochromic Behavior. Inorg. Chem. 2019, 58, 3968-
3981.
Li, X.; Liu, M.; Li, H.; Stang, P. J. Alanine-Based Chiral Metallogels via
Supramolecular Coordination Complex Platforms: Metallogelation
Induced Chirality Transfer. J. Am. Chem. Soc. 2018, 140, 3257-3263.
1
2
3
4
5
6
7
8
(10) (a) Brown, C. J.; Toste, F. D.; Bergman, R. G.; Raymond, K. N.
Supramolecular Catalysis in Metal–Ligand Cluster Hosts. Chem. Rev.
2015, 115, 3012-3035. (b) Yoshizawa, M.; Tamura, M.; Fujita, M. Diels-
Alder in Aqueous Molecular Hosts: Unusual Regioselectivity and
Efficient Catalysis. Science 2006, 312, 251-254.
(15) Zhang, Z.; Zhao, Z.; Hou, Y.; Wang, H.; Li, X.; He, G.; Zhang, M.
Aqueous Platinum(II)-Cage-Based Light-Harvesting System for
Photocatalytic Cross-Coupling Hydrogen Evolution Reaction. Angew.
Chem. Int. Ed. Engl. 2019, 58, 8862-8866.
(11) (a) Tang, J.-H.; Sun, Y.; Gong, Z.-L.; Li, Z.-Y.; Zhou, Z.; Wang, H.;
Li, X.; Saha, M. L.; Zhong, Y.-W.; Stang, P. J. Temperature-Responsive
Fluorescent Organoplatinum(II) Metallacycles. J. Am. Chem. Soc. 2018,
140, 7723-7729. (b) Chen, L.-J.; Ren, Y.-Y.; Wu, N.-W.; Sun, B.; Ma,
J.-Q.; Zhang, L.; Tan, H.; Liu, M.; Li, X.; Yang, H.-B. Hierarchical Self-
Assembly of Discrete Organoplatinum(II) Metallacycles with
Polysaccharide via Electrostatic Interactions and Their Application for
Heparin Detection. J. Am. Chem. Soc. 2015, 137, 11725-11735.
9
(16) (a) Shi, B.; Liu, Y.; Zhu, H.; Vanderlinden, R. T.; Shangguan, L.; Ni,
R.; Acharyya, K.; Tang, J.-H.; Zhou, Z.; Li, X.; Huang, F.; Stang, P. J.
Spontaneous Formation of a Cross-Linked Supramolecular Polymer Both
in the Solid State and in Solution, Driven by Platinum(II) Metallacycle-
Based Host–Guest Interactions. J. Am. Chem. Soc. 2019, 141, 6494-6498.
(b) Shi, B.; Zhou, Z.; Vanderlinden, R. T.; Tang, J.-H.; Yu, G.; Acharyya,
K.; Sepehrpour, H.; Stang, P. J. Spontaneous Supramolecular
Polymerization Driven by Discrete Platinum Metallacycle-Based Host–
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
(12) (a) Vajpayee, V.; Yang, Y. J.; Kang, S. C.; Kim, H.; Kim, I. S.;
Wang, M.; Stang, P. J.; Chi, K.-W. Hexanuclear self-assembled arene-
ruthenium nano-prismatic cages: potential anticancer agents. Chem.
Commun. 2011, 47, 5184-5186. (b) Mattsson, J.; Zava, O.; Renfrew, A.
K.; Sei, Y.; Yamaguchi, K.; Dyson, P. J.; Therrien, B. Drug delivery of
lipophilic pyrenyl derivatives by encapsulation in a water soluble metalla-
cage. Dalton Trans. 2010, 39, 8248-8255. (c) Fujita, D.; Suzuki, K.; Sato,
S.; Yagi-Utsumi, M.; Yamaguchi, Y.; Mizuno, N.; Kumasaka, T.; Takata,
M.; Noda, M.; Uchiyama, S.; Kato, K.; Fujita, M. Protein encapsulation
within synthetic molecular hosts. Nat. Commun. 2012, 3, 1093.
Guest
Complexation.
J.
Am.
Chem.
Soc.
2019,
doi.org/10.1021/jacs.9b06181.
(17) An, B.-K.; Gierschner, J.; Park, S. Y. π-Conjugated Cyanostilbene
Derivatives: A Unique Self-Assembly Motif for Molecular Nanostructures
with Enhanced Emission and Transport. Acc. Chem. Res. 2012, 45, 544-
554.
(18) The ligand 1 has absolute fluorescent quantum yields of 7 %, 11 %
and 17 % in DMSO, H2O-DMSO (4:1; v/v), and in the solid state
respectively.
(13) Samanta, D.; Mukherjee, P. S. Structural Diversity in Multinuclear
PdII Assemblies that Show Low-Humidity Proton Conduction. Chem.
Eur. J. 2014, 20, 5649-5656.
(19) Li, Y.; Dong, Y.; Cheng, L.; Qin, C.; Nian, H.; Zhang, H.; Yu, Y.;
Cao, L. Aggregation-Induced Emission and Light-Harvesting Function of
Tetraphenylethene-Based Tetracationic Dicyclophane. J. Am. Chem. Soc.
2019, 141, 8412-8415.
(14) (a) Zhang, C.-W.; Ou, B.; Jiang, S.-T.; Yin, G.-Q.; Chen, L.-J.; Xu,
L.; Li, X.; Yang, H.-B. Cross-linked AIE supramolecular polymer gels
with multiple stimuli-responsive behaviours constructed by hierarchical
self-assembly. Polym. Chem. 2018, 9, 2021-2030. (b) Yan, X.; Cook, T.
R.; Wang, P.; Huang, F.; Stang, P. J. Highly emissive platinum(II)
5
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 6 of 6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
ACS Paragon Plus Environment
