Design and Synthesis of a Novel Banana-Shaped
Functional Molecule via Double Cross-Coupling
Bingchuan Yang 1,2,3,*, Guodong Shen 1, Xianqiang Huang 1 and Rutao Liu 2,
*
1
School of Chemistry and Chemical Engineering, Liaocheng University, Liaocheng 252000, China;
shenguodong@lcu.edu.cn (G.S.); hxq@lcu.edu.cn (X.H.)
School of Environmental Science and Engineering, Shandong University, Jinan 250100, China
The Department of Chemistry, University of South Florida, 4202 East Fowler Avenue, Tampa, FL 33620, USA
Correspondence: bingchuan@mail.usf.edu (B.Y.); rutaoliu@sdu.edu.cn (R.L.);
Tel.: +1-813-613-5202 (B.Y.); +86-1380-531-5917 (R.L.)
2
3
*
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
Academic Editors: Artur M. S. Silva and Maria Manuel Marques
Received: 4 January 2019; Accepted: 12 February 2019; Published: 15 February 2019
ꢀꢁꢂꢃꢄꢅꢆ
Abstract: A novel banana-shaped molecule using 2,8-Dimethyl-6H,12H-5,11-methanodibenzo [b,f]
[1,5]diazocine (Tröger’s base) as bent-core was synthesized via double Carbon-Carbon cross-coupling
reaction. The double Sonogashira cross-coupling reaction was optimized by using Pd(PPh3)2Cl2 as
catalyst, CuI as cocatalyst and diisopropylamine as base in place of triethylamine. The structure of this
compound was confirmed by 1H-NMR, 13C-NMR, Fourier transform infrared (FT-IR) spectroscopy
and mass spectrometry.
Keywords: bent-core; Tröger’s base; double Sonogashira coupling
1. Introduction
Molecules bearing bent-cores have attracted extensive worldwide attention due to their
outstanding properties. Some of these molecules have potential applications in asymmetric
catalysis [
molecules have rigid
special structure, the molecules can pack closely and align in the direction of bending [
banana-shaped molecules with bent-cores and flexible tails can exhibit a variety of novel characteristics
involving chirality, polarity, and liquid crystalline (LC) features [ 12]. Especially when bent-core
1,
2
], and others have been wildly used in molecular recognition [
shape, which will induce intermolecular polarity. Also because of their
]. As a result,
3–6]. Banana-shaped
Λ
7
8–
is constructed in the liquid crystal molecules, this special bent shape promotes molecules packed in
polar [3] and tilted [13] ways to form chiral lamellar phases such as the B2 and B7 [14–16].
Bent-core liquid crystal molecules also have nonlinear optical properties due to their unique shape
and polar character, which have attracted considerable interest. What is more, polar characters
of bent-shaped molecules were also used to develop ferroelectric switches or anti-ferroelectric
materials [17].
This special usages have drawn great interest from not only scientific researchers but also
industrial designers. Based on these fused properties, liquid crystals have been widely used in
one-dimensional conductors, photoconductors, light emitting diodes, photovoltaic solar cells, and gas
sensors [18–21].
We have been focusing on the development of facile syntheses of heterocyclic systems [22–26]
Herein, we choose bent-shaped 5,6,11,12-tetrahydrodibenzo[b,f] [1,5]diazocines (Tröger’s base like)
as the bent-core to design and synthesize a novel banana-shaped molecule (Scheme 1). Tröger’s
base was first synthesized by Tröger in 1887 [27], and its space structure is just similar to the letter
of the Greek alphabet
and rigid C2 symmetry property [28
Λ
. It has recently received renewed interest due to its inherent chirality
39]. Tröger’s base is a rigid and curved molecule due to
–
Molecules 2019, 24, 698; doi:10.3390/molecules24040698
www.mdpi.com/journal/molecules

Molecules 2019, 24, 698
2 of 8
its bridgehead stereogenic nitrogen atoms. A methylene strap connects the two chiral nitrogen
atoms together, which is very suitable for the construction of liquid crystalline materials. To the
different substituted groups, the dihedral angle between two benzene rings in Tröger’s base changes
from 90◦ to 100◦. For example, the dihedral angle between two aromatic rings in (5S,11S)-2,8-
dibromo-6H,12H-5,11-ethanodibenzo[b,f] [1,5]diazocine is 94.5◦ [40], and the dihedral angle between
two aromatic rings 1,2,3,4,7,8,9,10-octafluoro-6H,12H-5,11-methanodibenzo[b,f][1,5]-diazocine is
98.4◦ [41].
Scheme 1. Retrosynthetic Analysis of target molecule A.
Tröger’s base has been constructed as a bent-core to bind different functional groups without
ruining their original properties. And Tröger’s base can be used as molecular clefts because the
bicyclic skeleton forces the molecule in a rigid locked conformation with the benzene rings in
proximity. In supramolecular chemistry, Tröger’s base has been explored for the recognition of aliphatic
dicarboxylic acids and enzyme inhibitors [42
Tröger’s base was also used in DNA intercalation and acted as ligands in asymmetric synthesis [48].
What is more, this -shaped twisted configuration is theoretically disadvantageous for the formation
of close stacking, which may lead to fluorescence quenching in the solid state. But recent study
revealed that the -shaped Tröger’s base scaffolds can express aggregation-induced emission (AIE)
properties [49,50].
–45]. Enantiomerically enriched [46,47] analogues of
Λ
π–π
Λ
2. Experimental Section
2.1. General
All chemicals purchased were used without purification. THF of analytical grade and de-ionized
1
water were used throughout the experiment as solvents. H-NMR spectra were recorded on a Bruker
Advance 400 (400 MHz) or 300 (300 MHz) spectrometer, using CDCl3 as solvent and tetramethylsilane
(TMS) as internal standard. 13C-NMR spectra were recorded on a Bruker Advance 100 (100 MHz) or
75 (75 MHz) spectrometer, using CDCl3 as solvent and tetramethylsilane (TMS) as internal standard.
HRMS spectra were determined on a Q-TOF6510 spectrograph (Agilent). Supplementary Materials:
Representative experimental procedures, spectral data of compounds 3–8. This material is available
free of charge via the internet.
2.2. Experimental Procedure for the Preparation of
2,8-Dibromo-6H,12H-5,11-methanodibenzo[b,f][1,5]diazocine (2)
To a stirred mixture of the 4-bromoaniline (1) (3.44 g, 30 mmol), paraformaldehyde (5.40 g,
60 mmol) was added with TFA (100 mL; 1.3 mol), the mixture was stirred for 168 h at room temperature
Then, TFA was removed in vacuo, water (100 mL) was added followed by the addition of saturated
aqueous NH3 solution (100 mL). The aqueous layer was extracted with dichloromethane (3
The combined organic layers were dried (MgSO4), filtered, concentrated in vacuo and purified by
×
50 mL).

Molecules 2019, 24, 698
3 of 8
flash chromatography on silica gel to gain the product
2
(PE:EtOAc = 20:1, 3.363 g, 88%). As shown in
1
Figure 1. H-NMR (DMSO, TMS, 400 MHz): 4.08 (d, J = 16.8 Hz, 1H), 4.2 (s, 1H), 4.62 (d, J = 16.8 Hz,
1H), 6.87 (d, J = 8.48 Hz, 1H), 7.23 (d, J = 8.08 Hz, 1H), 7.46 (d, J = 8.56 Hz, 1H). 13C-NMR (CDCl3, TMS,
100 MHz): 58.3, 66.7, 116.8, 126.7, 129.7, 129.7, 130.6, 146.8.
Figure 1. Ball-and-Stick model of compound 8.
2.3. Experimental Procedure for the Preparation of
2,8-Bis((trimethylsilyl)ethynyl)-6,12-dihydro-5,11-methanodiben-zo[b,f][1,5]diazocine (3)
A Schlenk tube containing 2,8-dibromo-6,12-dihydro-5,11-methanodibenzo [b,f][1,5] diazocine (2)
(0.38 g, 1 mmol), dichlorobis(triphenylphosphine)palladium(II) (0.07 g, 0.1 mmol), copper(I) iodide
(0.012 g, 0.06 mmol), triphenylphosphine (0.052 g, 0.2 mmol) was degassed on a vacuum line by
repeatedly alternating between an argon atmosphere and vacuum. Then diisopropylamine (30 mL)
was added dropwisely. Finally, a solution of trimethylsilylacetylene (0.53 mL, 3 mmol) was added
dropwise and the mixture was stirred at 50 ◦C for 11 h. After that the mixture was filtered through a
pad of celite and dichloromethane (30 mL) was used to wash the additional product through the celite
pad. The filtrate was evaporated to dryness and purified by flash chromatography on silica gel to gain
1
the product
3
(PE:EtOAc = 6:1, 0.250 g, 60%).As shown in Figure 2. H-NMR (CDCl3, 300 MHz)
δ
0.20
(s, 18H), 4.10 (d, J =16.8 Hz, 2H), 4.27 (s, 2H), 4.62 (d, J =16.8 Hz, 2H), 7.01 (d, J = 8.4 Hz, 4H), 7.24 (dd,
J = 8.7, 2.4 Hz, 2H). 13C-NMR (CDCl3, TMS, 100 MHz): 0.00, 58.5, 66.8, 93.4, 104.8, 118.6, 124.8, 127.7,
130.7, 131.0, 148.3.
Figure 2. The optimized structure of 8 calculated by Gaussian 09 program using the B3LYP method
with the 6-31G + (d,p) basis set [51].
2.4. Experimental Procedure for the Preparation of
2,8-Diethynyl-6,12-dihydro-5,11-methanodibenzo[b,f][1,5]diazoci-ne (4)
2,8-bis((trimethylsilyl)ethynyl)-6,12-dihydro-5,11-methanodi- benzo[b,f][1,5] diazocine (0.150 g,
0.362 mmol) was dissolved in THF/MeOH (VTHF:VMeOH = 1:1) 50 mL and potassium carbonate was
added (0.333 g, 2.461 mmol). The mixture was stirred for 5 h, filtered, concentrated in vacuo and
purified by flash chromatography on silica gel to gain the product 4 (PE:EtOAc = 6:1, 0.092 g, 95%). As
1
shown in Figure 3. H-NMR (CDCl3, 300 MHz)
δ 2.97 (s, 2H), 4.13 (d, J = 16.8 Hz, 2H), 4.29 (s, 2H),

Molecules 2019, 24, 698
4 of 8
4.65 (d, J = 16.8 Hz, 2H), 7.07 (d, J = 8.1 Hz, 4H), 7.24 (dd, J = 8.1 Hz, 1.5 Hz, 2H); 13C-NMR (CDCl3,
300 MHz) δ 58.4, 66.7, 76.5, 76.6, 77.0, 77.5, 83.3, 117.6, 125.0, 127.8, 130.9, 131.2, 148.5.
-1.491905 eV
LUMO
ΔE = 5.718146 eV
HOMO
-7.210052 eV
Figure 3. HOMO/LUMO imagines of 8 calculated by Gaussian 09 program using the B3LYP method
with the 6-31G + (d,p) basis set [51].
2.5. Experimental Procedure for the Preparation of 4-(Methoxycarbonyl)phenyl-4-iodobenzoate (7)
One equivalent of p-Iodobenzoic acid ( ) (0.250 g, 1 mmol), methyl 4-hydroxybenzoate (6) (0.152 g,
5
1 mmol), DCC (0.206 g, 1 mmol) and DMAP (0.025 g, 0.2 mmol) were dissolved in dimethyl carbonate
(DMC) 30 mL and stirred at room temperature for 10 h. The whole mixture was filtered and the filtrate
was distilled by vacuum. The crude product was purified by flash chromatography on silica gel to
1
gain the product 7 (PE:EtOAc = 6:1, 0.308 g, 80%). H-NMR (CDCl3, 400 MHz)
δ 3.93 (s, 6H), 4.73
(d, J = 16.8 Hz, 2H), 7.29 (d, J = 8.7 Hz, 2H), 7.89 (s, 4H), 8.12 (d, J = 8.7 Hz, 2H); 13C-NMR (CDCl3,
400 MHz) δ 52.2, 102.0, 121.7, 128.0, 128.6, 131.3, 131.6, 138.1, 154.4, 164.2, 166.3.
2.6. Experimental Procedure for the Preparation of
Bis(4-(methoxycarbonyl)phenyl)4,40-((6,12-dihydro-5,11-methano-dibenzo[b,f][1,5]diazocine-2,8-diyl)bis
(ethyne-2,1-diyl))diben-zoate (8)
A Schlenk tube containing 2,8-diethynyl-6,12-dihydro-5,11-methanodibenzo[b,f][1,5]diazocine
(97 mg, 0.36 mmol), 4-(methoxycarbonyl)phenyl 4-iodobenzoate (276 mg, 0.72 mmol),
dichlorobis(triphenylphosphine)palladium(II) (25 mg, 0.036 mmol), copper(I) iodide (3 mg,
0.018 mmol), triphenylphosphine (19 mg, 0.072 mmol) and dry triethylamine (20 mL) was degassed
on a vacuum line by repeatedly alternating between an argon atmosphere and vacuum. The reaction
◦
mixture was stirred at 50 C for 18 h. The reaction mixture was then filtered and evaporated to dryness.
The product was purified by column chromatography on silica gel using CHCl3:EtOAc = 15:1 as the
◦
eluent to gain the product 8 (141 mg, 50%). white solid; m.p. 210 C. IR (KBr),
2202, 1733, 1713, 1600, 1506. H-NMR (CDCl3, 400 MHz)
ν
(cm−1): 2946, 2900,
max
1
δ 3.93 (s, 6H), 4.22 (d, J = 16.8 Hz, 2H), 4.35 (s,
2H), 4.73 (d, J = 16.8 Hz, 2H), 7.15 (d, J = 9.8 Hz, 4H), 7.30 (d, J = 8.1 Hz, 2H), 7.39 (dd, J = 8.3, 1.7 Hz,
2H), 7.60 (d, J = 8.5 Hz, 4H), 8.14 (t, J = 9.8 Hz, 14.1 Hz, 8H); 13C-NMR (CDCl3, 400 MHz)
δ
52.2, 58.5,
66.8, 88.0, 92.9, 118.0, 121.7, 125.2, 127.9, 128.0, 128.2, 129.1, 130.2, 130.6, 131.0, 131.3, 131.6, 148.8, 154.5,
164.1, 166.3; HRMS (EI): Calcd for C49H34N2O8, 779.2388; found, 779.2383.
2.7. Theoretical Study
Computational methods. All calculations were conducted using the B3LYP functional (Gaussian
09, Revision B. 01.; Gaussian, Inc.: Wallingford, 2009) combined with the 6-31+(d,p) basis set,
as implemented in Gaussian 09 software package (Gaussian 09, Revision B. 01.; Gaussian, Inc.:
Wallingford, 2009). Vibrational analyses at the same level of theory were also carried out to confirm all

Molecules 2019, 24, 698
5 of 8
stationary points as minima (zero imaginary frequencies) or first-order saddle points (one imaginary
frequency) and to provide free energies at 298.15 K.
3. Results and Discussion
As shown in Scheme 2, starting from 4-bromoaniline
by condensation of with paraformaldehyde in trifluoroacetic acid (TFA) according to the procedure
described in Scheme 1. Tröger’s base derivative could react with trimethylsilylacetylene (TMSA)
smoothly to get high yield product under the common conditions of Sonogashira cross-coupling
reaction by using Pd(PPh3)2Cl2 as catalyst, CuI as cocatalyst and diisopropylamine as base in place of
triethylamine. Then the trimethylsilyl groups of was removed to obtain the product in excellent
yield under the conditions of K2CO3 as the base and VTHF:VMeOH = 1:1 as solvent. Intermediate
1, rac-(
±
)-Tröger’s base 2 was synthesized
1
2
3
3
4
7
was obtained from p-iodobenzoic acid and Methyl 4-hydroxybenzoate under the conditions of
0
N,N -dicyclohexylcarbodiimide (DCC) as dehydrant and 4-dimethylaminopyridine (DMAP) as catalyst
in the solvent of dimethyl carbonate (DMC). At the end, the intermediate
target molecule 14] in high yield under the conditions of PdCl2(PPh3)2 and CuI as cocatalyst and
triethylamine as base.
7 could react with 3, to obtain
8
[
Scheme 2. Synthesis of Tröger’s base like derivative.
We slightly modified the Sonogashira cross-coupling reaction conditions by using
diisopropylamine as base instead of triethylamine, and the reaction temperature changed from
room temperature to 50 ◦C improving the yield of 2,8-dibromo-6,12-dihydro-5,11-methano-
dibenzo[b,f][1,5]diazocine
6
to 60% successfully. Finally, the target molecule was obtained in 26%
overall yield in five steps.
To understand the structure changes of
8. We carried out density functional theory (DFT)
calculation by Gaussian 09 program using the B3LYP method with the 6-31G + (d,p) basis set.
The optimized structure shown in Figures 1 and 2 has a clear bent-core configuration, however
the tails of the molecule are not flexible enough. The HOMO-LUMO energy gap of compound
8 is
5.718146 eV (Figure 3). Electron cloud transferred from the Tröger’s base like core to the benzene rings
when the molecule excitated from HOMO to LUMO. According to the research results, this molecule
has potential application in liquid crystal field and further study will be conducted.

Molecules 2019, 24, 698
6 of 8
4. Conclusions
In summary, we have designed and synthesized a novel banana-shaped molecule based on
Tröger’s base via double Sonogashira cross-coupling reaction. The chemical structures have been
1
characterized by H-NMR, 13C-NMR, Fourier transform infrared (FT-IR) spectroscopy and mass
spectrometry. Theoretical study was also conducted by Gaussian 09 program, and we confirmed that
the molecule has a bent-core structure. In the future, we will use this method to obtain a series of these
bent-core compounds. Further studies on its applications in the photology are currently in progress.
Supplementary Materials: Representative experimental procedures, spectral data of compounds 3–8. This
material is available free of charge via the internet.
Author Contributions: Investigation, B.Y.; Methodology, B.Y.; Project administration, X.H.; Supervision, R.L.;
Writing-original draft, G.S.
Funding: We are grateful to National Science Foundation of China (No. 51378306, 21402079) and Liaocheng
University fund (318051515, 201610447013) for financial support of this research.
Conflicts of Interest: The authors declare no conflicts of interest.
Date Availability: The data used to support the findings of this study are available from the corresponding author
upon request.
References
1.
2.
3.
4.
Harmata, M.; Kahraman, M. Congeners of Troeger’s base as chiral ligands. Tetrahedron Asymmetry 2000, 11,
2875. [CrossRef]
Goldberg, Y.; Alper, H. Transition metal complexes of Tröger’s base and their catalytic activity for the
hydrosilylation of alkynes. Tetrahedron Lett. 1995, 36, 369. [CrossRef]
Wilcox, C.S.; Cowart, M.D. New approaches to synthetic receptors. Synthesis and host properties of a water
soluble macrocyclic analog of Tröger’s base. Tetrahedron Lett. 1986, 27, 5563. [CrossRef]
Adrian, J.C.; Wilcox, C.S. General effects of binding site water exclusion on hydrogen bond based molecular
recognition systems: A closed binding sites is less affected by environmental changes than an open site.
J. Am. Chem. Soc. 1992, 114, 1398. [CrossRef]
5.
6.
7.
Crossley, M.J.; Hambley, T.W.; Mackay, L.G. Porphyrin analogues of Tröger’s base: Large chiral cavities with
a bimetallic binding site. J. Chem. Soc. Chem. Commun. 1995, 1077. [CrossRef]
Hansson, A.P.; Norrby, P.O.; Wärnmark, K. A bis (crown-ether) analogue of Tröger’s base: Recognition of
achiral and chiral primary bisammonium salts. Tetrahedron Lett. 1998, 39, 4565. [CrossRef]
Paliwal, S.; Geib, S.; Wilcox, C.S. Molecular torsion balance for weak molecular recognition forces. effects of
“Tilted-T” Edge-to-Face aromatic interactions on conformational selection and solid-state structure. J. Am.
Chem. Soc. 1994, 116, 4497–4498. [CrossRef]
8.
9.
Takezoe, H.; Takanishi, Y. Bent-core liquid crystals: Their mysterious and attractive world. Jpn. J. Appl. Phys.
2006, 45. [CrossRef]
Reddy, R.A.; Tschierske, C. Bent-core liquid crystals: Polar order, superstructural chirality and spontaneous
desymmetrisation in soft matter systems. J. Mater. Chem. 2006, 16, 907. [CrossRef]
10. Niori, T.; Sekine, T.; Watanabe, J.; Furukawa, T.; Takezoe, H. Distinct ferroelectric smectic liquid crystals
consisting of banana shaped achiral molecules. J. Mater. Chem. 1996, 6, 1231–1233. [CrossRef]
11. Slattery, J.M.; Bruce, D.W.; Gao, Y.; Shimizu, K.; Slattery, J.M. Liquid-Crystalline Ionic Liquids as Ordered
Reaction Media for the Diels–Alder Reaction. Chem. Eur. J. 2016, 1–12.
12. Ube, T.; Kawasaki, K.; Ikeda, T. Photomobile Liquid-Crystalline Elastomers with Rearrangeable Networks.
Adv. Mater. 2016, 28, 8212–8217. [CrossRef] [PubMed]
13. Link, D.R.; Natale, G.; Shao, R.; Maclennan, J.E.; Clark, N.A.; Körblova, E.; Walba, D.M. Spontaneous
formation of macroscopic chiral domains in a fluid smectic phase of achiral molecules. Science 1997, 278,
1924–1927. [CrossRef] [PubMed]
14. Walba, D.M.; Körblova, E.; Shao, R.; Maclennan, J.E.; Link, D.R.; Glaser, M.A.; Clark, N.A. A ferroelectric
liquid crystal conglomerate composed of racemic molecules. Science 2000, 288, 2181. [CrossRef] [PubMed]

Molecules 2019, 24, 698
7 of 8
15. Coleman, D.A.; Fernsler, J.; Chattham, N. Polarization-modulated smectic liquid crystal phases. Science 2003
301, 1204. [CrossRef] [PubMed]
,
16. Bayón, R.; Coco, S.; Barcenilla, M.; Espinet, P.; Imbuluzqueta, G.; Hidalgo, J.; Rojas, E. Feasibility of Storing
Latent Heat with Liquid Crystals. Proof of Concept at Lab Scale. Appl. Sci. 2016, 6, 121. [CrossRef]
17. Bisoyi, H.K.; Srinivasa, H.T.; Kumar, S. Novel banana-discotic hybrid architectures. Beilstein J. Org. Chem.
2009, 5, 52. [CrossRef]
18. Kumar, S. Self-organization of disc-like molecules: Chemical aspects. Chem. Soc. Rev. 2006, 35, 83. [CrossRef]
19. Laschat, S.; Baro, A.; Steinke, N.; Giesselmann, F.; Hägele, C.; Scalia, G.; Judele, R.; Kapatsina, E.; Sauer, S.;
Schreivogel, A.; Tosoni, M. Discotic liquid crystals: From tailor-made synthesis to plastic electronics.
Angew. Chem. Int. Ed. 2007, 46, 4832. [CrossRef]
20. Sergeyev, S.; Pisula, W.; Geerts, Y.H. Discotic liquid crystals: A new generation of organic semiconductors.
Chem. Soc. Rev. 2007, 36, 1902. [CrossRef]
21. Wu, J.; Pisula, W.; Müllen, K. Graphenes as potential material for electronics. Chem. Rev. 2007, 107, 718.
[CrossRef] [PubMed]
22. Huang, A.P.; Chen, Y.M.; Zhou, Y.G.; Guo, W.; Wu, X.D.; Ma, C. An efficient one-pot synthesis of benzo [4,
5] imidazo [1, 2-a] quinoxalines via copper-catalyzed process. Org. Lett. 2013, 15, 5480–5483. [CrossRef]
[PubMed]
23. Zhao, Y.M.; Wu, Y.M.; Jia, J.; Zhang, D.J.; Ma, C. One-Pot Synthesis of Benzo [1, 4] thiazin-3 (4 H)-ones and a
Theoretical Study of the S–N Type Smiles Rearrangement Mechanism. J. Org. Chem. 2012, 77, 8501–8506.
[CrossRef] [PubMed]
24. Yang, B.C.; Niu, X.Y.; Huang, Z.X.; Zhao, C.H.; Liu, Y.; Ma, C. A novel kind of dimmer (excimer)-induced-AIE
compound 2-phenylisothiazolo [5, 4-b] pyridin-3 (2H)-one as high selective bisulfite anion probe. Tetrahedron
2013, 69, 8250–8254. [CrossRef]
25. Yang, B.C.; Tan, X.C.; Guo, R.Y.; Chen, S.W.; Zhang, Z.Y.; Chu, X.L.; Xie, C.X.; Zhang, D.J.; Ma, C. Transition
Metal-Free One-Pot Synthesis of Fused 1, 4-Thiazepin-5 (4 H)-ones and Theoretical Study of the S–N Type
Smiles Rearrangement Process. J. Org. Chem. 2014, 79, 8040–8048. [CrossRef] [PubMed]
26. Tan, X.C.; Du, Y.N.; Yang, B.C.; Ma, C. A novel type of AIE material as a highly selective fluorescent sensor
for the detection of cysteine and glutathione. RSC Adv. 2015, 5, 55165. [CrossRef]
27. Tröger, J. Uber einige mittels nascierenden Formaldehyds entstehende Basen (About some bases formed via
nascent formaldehyde). J. Prakt Chem. 1887, 36, 225. [CrossRef]
28. Adrianm, J.C.; Wilcox, C.S. Orderly functional group dyads. Recognition of biotin and adenine derivatives
by a new synthetic host. J. Am. Chem. Soc. 1989, 111, 8055. [CrossRef]
29. Crossley, M.J.; Try, A.C.; Walton, R. Synthesis of accurate distance models of the primary donor-primary
acceptor pair of bacterial photosynthetic reaction centres. Tetrahedron Lett. 1996, 37, 6807. [CrossRef]
30. Try, A.C.; Painter, L.; Harding, M.M. Rigid chiral carbocyclic clefts as building blocks for the construction of
new supramolecular hosts. Tetrahedron Lett. 1998, 39, 9809. [CrossRef]
31. Tatibouët, A.; Demeunynck, M.; Andraud, C.; Collet, A.; Lhomme, J. Synthesis and study of an acridine
substituted Tröger’s base: Preferential binding of the (–)-isomer to B-DNA. Chem. Commun. 1999, 23, 161.
[CrossRef]
32. Kubo, Y.; Ohno, T.; Yamanaka, J.; Tkita, S.; Iida, T.Y.; Ishimaru, J. Chirality-transfer control using a heterotopic
zinc (II) porphyrin dimer. J. Am. Chem. Soc. 2001, 123, 12700. [CrossRef] [PubMed]
33. Deprez, N.R.; McNitt, K.A.; Petersen, M.E.; Brown, R.G.; Lewis, D.E. Synthesis and fluorescence properties
of naphthalimide-containing Tröger’s bases. Tetrahedron Lett. 2005, 46, 2149–2153. [CrossRef]
34. Valík, M.; Malina, J.; Palivec, L.; Foltýnová, J.; Tkadlecová, M.; Urbanová, M.; Brabec, V.; Král, V. Tröger’s
base scaffold in racemic and chiral fashion as a spacer for bisdistamycin formation. Synthesis and DNA
binding study. Tetrahedron 2006, 62, 8591. [CrossRef]
35. Hof, F.; Schär, M.; Scofield, D.M.; Fischer, F.; Diederich, F.; Sergeyev, S. Preparation of Tröger Base Derivatives
by Cross-Coupling Methodologies. Helv. Chim. Acta 2005, 88, 2333–2344. [CrossRef]
36. Kiehne, U.; Weilandt, T.; Lützen, A. Diastereoselective Self-Assembly of Double-Stranded Helicates from
Tröger’s Base Derivatives. Org. Lett. 2007, 9, 1283–1286. [CrossRef] [PubMed]
37. Šturala, J.; Cibulka, R. Synthesis of Symmetrical Dinitro- and Diamino- Substituted Tröger’s Base Analogues.
Eur. J. Org. Chem. 2012, 36, 7066–7074. [CrossRef]

Molecules 2019, 24, 698
8 of 8
38. Sun, Q.; Dai, Z.; Meng, X.; Xiao, F.S. Porous polymer catalysts with hierarchical structures. Chem. Soc. Rev.
2015, 44, 6018–6034. [CrossRef]
39. Jensen, J.; Tejler, J.; Wärnmark, K. General Protocols for the Synthesis of C 2-Symmetric and Asymmetric 2,
8-Disubstituted Analogues of Tröger’s Base via Efficient Bromine Lithium Exchanges of 2, 8-Dibromo-6H,
−
12 H-5, 11-methanodibenzo [b, f][1, 5] diazocine. J. Org. Chem. 2002, 67, 6008–6014. [CrossRef]
40. Faroughi, M.; Try, A.C.; Klepetko, J.; Turner, P. Changing the shape of Tröger’s base. Tetrahedron Lett. 2007
48, 6548–6551. [CrossRef]
,
41. Vande Velde, C.M.; Didier, D.; Blockhuys, F.; Sergeyev, S. Racemic. 1, 2, 3, 4, 7, 8, 9, 10-octafluoro-6H, 12H-5,
11- methanodibenzo[b, f][1, 5] diazocine: An octafluorinated analogue of Tröger’s base. Acta Crystallogr. Sect.
E Struct. Rep. Online 2008, 64, 538. [CrossRef] [PubMed]
42. Demeunynck, M.; Tatibouët, A. Progress in Heterocyclic Chemistry; Gribble, G.W., Gilchrist, T.L., Eds.;
Pergamon: Oxford, UK, 1999; Volume 11, pp. 1–20.
43. Dolenský, B.; Elguero, J.; Kral, V.; Pardo, C.; Valik, M. Current Tröger’s base chemistry. Adv. Heterocycl. Chem.
2007, 93, 1–56.
44. Valik, M.; Strongin, R.M.; Král, V. Tröger’s Base Derivatives-New Life for Old Compounds. Supramol. Chem.
2005, 17, 347–367. [CrossRef]
45. Pardo, C.; Sesmilo, E.; Gutiérrez-Puebla, E.; Monge, A.; Elguero, J.; Fruchier, A. New chiral molecular
tweezers with a bis-Tröger’s base skeleton. J. Org. Chem. 2001, 66, 1607–1611. [CrossRef] [PubMed]
46. Wilen, S.H.; Qi, J.Z.; Williard, P.G. Resolution, asymmetric transformation, and configuration of Troeger’s
base. Application of Troeger’s base as a chiral solvating agent. J. Org. Chem. 1991, 56, 485. [CrossRef]
47. Boyle, E.M.; Comby, S.; Molloy, J.K.; Gunnlaugsson, T. Thiourea Derived Tröger’s Bases as Molecular Cleft
Receptors and Colorimetric Sensors for Anions. J. Org. Chem. 2013, 78, 8312–8319. [CrossRef] [PubMed]
48. Blaser, H.U.; Jalett, H.P.; Lottenbach, W.; Studer, M. Heterogeneous enantioselective hydrogenation of ethyl
pyruvate catalyzed by cinchona-modified Pt catalysts: Effect of modifier structure. J. Am. Chem. Soc. 2000
122, 12675. [CrossRef]
,
49. Yuan, C.X.; Tao, X.T.; Ren, Y.; Li, Y.; Yang, J.X.; Yu, W.T.; Wang, L.; Jiang, M.H. Synthesis, structure, and
aggregation-induced emission of a novel lambda (Λ)-shaped pyridinium salt based on tröger’s base. J. Phys.
Chem. C 2007, 111, 12811. [CrossRef]
50. Xin, Q.; Tao, X.T.; Wang, F.Z.; Sun, J.L.; Zou, D.C.; Wang, F.J.; Liu, H.J.; Liu, Z.; Ren, Y.; Jiang, M.H.
Fluorene-based Tröger’s base analogues: Potential electroluminescent materials. Org. Electron. 2008, 9,
1076–1086. [CrossRef]
51. Frisch, M.J.; Trucks, G.W.; Schlegel, H.B.; Scuseria, G.E.; Robb, M.A.; Cheeseman, J.R.; Montgomery, J.A.;
Vreven, T., Jr.; Kudin, K.N.; Burant, J.C.; et al. Gaussian 03 Citation. 2004. Available online: http://gaussian.
com/g03citation/ (accessed on 1 November 2016).
Sample Availability: Samples of the compounds 3–8 are available from the authors.
©
2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
