Coupling the Antimalarial Cell Penetrating Peptide
TP10 to Classical Antimalarial Drugs Primaquine and
Chloroquine Produces Strongly
Hemolytic Conjugates
Luísa Aguiar 1, Arnau Biosca 2,3 , Elena Lantero 2,3, Jiri Gut 4, Nuno Vale 5,6,7
,
Philip J. Rosenthal 4 , Fátima Nogueira 8 , David Andreu 9, Xavier Fernàndez-Busquets 2,3,10
and Paula Gomes 1,
*
1
LAQV-REQUIMTE, Departamento de Qu
4169-007 Porto, Portugal; luisa.aguiarts@gmail.com
Barcelona Institute for Global Health (ISGlobal, Hospital Cl
í
mica e Bioqu
í
mica, Faculdade de Ci
ê
ncias, Universidade do Porto,
2
ínic-Universitat de Barcelona), Rossell 149-153,
ó
08036 Barcelona, Spain; abiosca@ibecbarcelona.eu (A.B.); elantero@ibecbarcelona.eu (E.L.);
xfernandez_busquets@ub.edu (X.F.-B.)
Nanomalaria Group, Institute for Bioengineering of Catalonia (IBEC), The Barcelona Institute of Science and
Technology, Baldiri Reixac 10-12, 08028 Barcelona, Spain
School of Medicine, University of California at San Francisco, 1001 Potrero Avenue, San Francisco,
San Francisco, CA 94110, USA; jiri.gut@ucsf.edu (J.G.); Philip.Rosenthal@ucsf.edu (P.J.R.)
Departamento de Farmacologia, Departamento de Ciências do Medicamento, Faculdade de Farmácia da
Universidade do Porto, Rua de Jorge Viterbo Ferreira 228, 4050-313 Porto, Portugal; nuno.vale@ff.up.pt
3
4
5
6
IPATIMUP—Instituto de Patologia e Imunologia Molecular da Universidade do Porto, Rua J
úlio Amaral de
Carvalho 45, 4200-135 Porto, Portugal
7
8
i3S, Instituto de Investigação e Inovação em Saúde, Rua Alfredo Allen 208, 4200-135 Porto, Portugal
Global Health and Tropical Medicine, Instituto de Higiene e Medicina Tropical, Universidade Nova de
Lisboa, 1349-008 Lisbon, Portugal; FNogueira@ihmt.unl.pt
Department of Experimental and Health Sciences, Pompeu Fabra University, Barcelona Biomedical Research
Park, Dr. Aiguader 88, 08003 Barcelona, Spain; david.andreu@upf.edu
Nanoscience and Nanotechnology Institute (IN2UB), University of Barcelona, Martí i Franquès 1,
08028 Barcelona, Spain
9
10
*
Correspondence: pgomes@fc.up.pt
ꢀꢁꢂꢀꢃꢄꢅꢆꢇ
Academic Editor: Steven L. Cobb
Received: 25 October 2019; Accepted: 10 December 2019; Published: 12 December 2019
ꢀꢁꢂꢃꢄꢅꢆ
Abstract: Recently, we disclosed primaquine cell penetrating peptide conjugates that were more
potent than parent primaquine against liver stage Plasmodium parasites and non-toxic to hepatocytes.
The same strategy was now applied to the blood-stage antimalarial chloroquine, using a wide
set of peptides, including TP10, a cell penetrating peptide with intrinsic antiplasmodial activity.
Chloroquine-TP10 conjugates displaying higher antiplasmodial activity than the parent TP10 peptide
were identified, at the cost of an increased hemolytic activity, which was further confirmed for their
primaquine analogues. Fluorescence microscopy and flow cytometry suggest that these drug-peptide
conjugates strongly bind, and likely destroy, erythrocyte membranes. Taken together, the results
herein reported put forward that coupling antimalarial aminoquinolines to cell penetrating peptides
delivers hemolytic conjugates. Hence, despite their widely reported advantages as carriers for
many different types of cargo, from small drugs to biomacromolecules, cell penetrating peptides
seem unsuitable for safe intracellular delivery of antimalarial aminoquinolines due to hemolysis
issues. This highlights the relevance of paying attention to hemolytic effects of cell penetrating
peptide-drug conjugates.
Keywords: antimalarial; cell penetrating peptide; chloroquine; erythrocyte fluorescence;
flow cytometry; hemolysis; microscopy; Plasmodium; primaquine; red blood cell
Molecules 2019, 24, 4559; doi:10.3390/molecules24244559
www.mdpi.com/journal/molecules

Molecules 2019, 24, 4559
2 of 21
1. Introduction
Malaria is responsible for about half a million deaths every year and represents a great threat
for the billions of people living in or traveling to endemic areas. This parasitic disease is caused
by different species of the Plasmodium genus, in particular P. falciparum and P. vivax. The life cycle
of malaria parasite within the human body is complex, but can be divided in two stages: (i) the
asymptomatic liver stage, which progresses to (ii) the blood stage, when clinical illness appears [1].
Apart from the complexity of the Plasmodium life cycle, several other factors hinder the eradication of
this disease, such as (i) widespread resistance to cheaper and safer antimalarial drugs like chloroquine
(CQ,
1 in Figure 1), (ii) toxicity of many older antimalarials, e.g., primaquine (PQ, 2 in Figure 1),
quinacrine (CQR) or amodiaquine, (iii) low oral bioavailability, e.g., PQ, (iv) lack of effective vaccines,
and (v) scarcity of multi-stage antimalarials that are able to efficiently eliminate liver- and blood-stage
forms of Plasmodium parasites [2]. Resistance to newer antimalarials, including artemisinin-based
combination therapies that are standard to treat CQ-resistant falciparum malaria has also emerged.
Therefore, the search for new antimalarial therapeutic strategies remains an urgent task.
One of our main lines of research concerns the chemical modification of classical antimalarials
such as PQ, CQ, or CQR, aimed at “masking” the drugs in such a way that their activity is preserved or
even improved, while undesirable metabolic conversions and/or toxicity are decreased, and/or parasite
resistance pathways are eluded [3–10]. Recently, we hypothesized that coupling cell-penetrating
peptides (CPP) to classical antimalarials could both improve internalization into Plasmodium-infected
cells and avoid resistance and pharmacokinetic liabilities. CPP have been widely explored as targeting
agents for several small molecules, as they can efficiently permeate cellular membranes without
requiring specific receptors or compromising membrane integrity, while carrying a wide range of
cargoes, from proteins to nucleic acids, inside living cells [11].
While CPP have been widely investigated mostly for cancer or genetic disorders [12–15], their use
as targeting agents for parasitic diseases, including malaria, is yet underexplored, although the
combination (either ionic or covalent) of fosmidomycin to the octaarginine CPP has been proven a
successful strategy to improve the antiplasmodial activity of this antibiotic. [16]. The relevance of
filling this void is clear if we consider the potential value of previously reported antimalarial peptides,
such as (i) TP10, a CPP with activity against blood-stage malaria infection [17], (ii) DPT-sh1 and
DPT-sh2, reported to preferentially internalize Plasmodium-infected red blood cells (PiRBC) over healthy
erythrocytes (hRBC) [18], or (iii) IDR-1018, a broad-spectrum antimicrobial and immunomodulatory
peptide [19]. In view of this, we recently explored how conjugation of the antimalarial drug PQ with
selected CPP would influence its action against liver-stage Plasmodium parasites, and found that activity
was improved in PQ-CPP conjugates (3 in Figure 1) with TP10 or the related peptide Transportan as
the CPP moiety [20]. Building on these findings, and considering that reports on antimalarial activity
of TP10 and other peptides, like DPT-sh1 and -sh2, addressed blood-stage infections, we have now
investigated whether conjugation to CPP would be equally promising when applied to CQ, the classical
blood-stage antimalarial that is currently limited by widespread drug resistance [21].

Molecules 2019, 24, 4559
3 of 21
Table 1. Selected CPP, their molecular weights (MW), and MW of respective conjugates 5a-5i.
CPP
Amino Acid Sequence (Respective MW/Da)
Cq-C4-CPP Conjugate (Respective MW/Da)
TP10
Transportan
DPT-sh1
DPT-sh2
IDR-1018
TAT
PasTAT
R9
Penetratin
AGYLLGKINLKALAALAKKIL (2182)
GWTLNSAGYLLGKINLKALAALAKKIL (2840)
VKKKKIKREIKI (1510)
5a (2512)
5b (3170)
5c (1841)
5d (2732)
5e (1867)
5f (2049)
5g (2852)
5h (1753)
5i (2576)
RQKRLIRQKRLIRQKRLI (2402)
VRLIVAVRIWRR (1535)
GRKKRRQRRRPPQ (1718)
FFLIPKGGRKKRRQRRRPPQ (2521)
RRRRRRRRR (1423)
RQIKIWFQNRRMKWKK (2246)
Figure 1. Structures of CQ (
chloroquine analogue (Cq,
first generation of Cq-CPP conjugates (Cq-C4-CPP, 5a-i).
1), PQ (2), PQ- CPP conjugates previously disclosed by us (3) [20], and the
4) bearing a free primary amine to be linked to CPP (Table 1), and afford the
2. Results
2.1. Synthesis and Antiplasmodial Activity of First-Generation Drug-Peptide Conjugates 5a–5i
Drug-CPP conjugates 5a–5i (Figure 1), derived from chloroquine analogue (Cq, Figure 1) and
based on analogous PQ-CPP conjugates , were successfully prepared through a combination of
4
3
solution- and solid-phase synthesis procedures (Scheme 1).
All conjugates and their respective parent CPP (Table 1), were screened in vitro for their
antiplasmodial activity, using the CQ-resistant P. falciparum W2 strain. The primaquine analogue to 5a
i.e., conjugate where the CPP is TP10, PQ-C4-TP10 (3a), was also included in the study for comparison.
Results (Table 2) showed that, unlike previously found for PQ-CPP conjugates (Figure 1) [20],
none of their CQ counterparts 5a-i displayed an activity equal or superior to that of the commercial
reference drug, CQ ( , IC50 = 699 nM) [22]. Still, these data cannot be directly compared, as they refer
,
3
3
1
to different species (P. berghei vs. P. falciparum) and developmental stages (liver vs. blood) of malaria
parasites. Nonetheless, the activity of the PQ-C4-TP10 conjugate 3a against blood-stage P. falciparum
W2 was also evaluated, but no consistent data could be obtained, due to apparently strong hemolytic
effects that were later confirmed (cf. Section 2.2. and Table 3). Regarding unmodified CPP, all but TP10
(IC50 = 5.53
N-terminally truncated derivative of Transportan; see their shared sequence underlined in Table 1),
were inactive (IC50 > 10 M) against P. falciparum. This was not surprising, since TP10 has been shown
to possess intrinsic antiplasmodial activity [8], whereas the other unrelated CPP have not.
µM) and Transportan (IC50 = 3.05 µM), which are closely related to each other (TP10 is an
µ

Molecules 2019, 24, 4559
4 of 21
Scheme 1. Synthesis of conjugates 5a-5i: (i) 20% piperidine in dimethylformamide (DMF) containing
0.1 M of 1-hydroxybenzotriazole (HOBt), microwave irradiation (MWI) for 30 s at 24 W plus 3 min
at 28 W; (ii) 5 eq, respective to the resin reactive groups, of the Fmoc-AA-OH in DMF (0.2 M), 5 eq
of 0.5 M O-(Benzotriazol-1-yl)-N,N,N0,N0-tetramethyluronium hexafluorophosphate (HBTU)/HOBt
in DMF, and 10 eq of 2 M N-ethyl-N,N-diisopropylamine (DIPEA) in N-methylpyrrolidone (NMP),
MWI for 5 min at 35 W; (iii) trifluoroacetic acid (TFA)/water/triisopropylsilane (TIS) 95:2.5:2.5 v/v/v
or TFA/thioanisole/ethane-1,2-dithiol/anisole 90:5:3:2 v/v/v/v cocktail (1 mL/100 mg of resin), room
temperature (RT), 120 min; (iv) 5 eq of
6 and of (benzotriazol-1-yloxy)tripyrrolidinophosphonium
hexafluorophosphate (PyBOP), 10 eq DIPEA in DMF, RT, overnight; (v) 1.2 eq of succinic anhydride
and of DIPEA in DMF, RT, 120 min. Grey sphere stands for the Rink-amide resin used as polymer
support used for solid-phase peptide synthesis (SPPS). PG, protecting group.
Only three of the Cq-C4-CPP conjugates, namely, 5a
M, with TP10- and Transportan-derived conjugates 5a (IC50 = 1.52
being the most active. Interestingly, while conjugation of Cq to Transportan affording conjugate 5b
,
5b, and 5g, displayed IC50 values below
10
µ
µ
M) and 5b (IC50 = 5.20 M)
µ
caused a decrease in antiplasmodial activity, the opposite occurred in the TP10-derived conjugate, 5a
for which antiplasmodial activity was enhanced over that of the parent CPP. Still, the activity of this
conjugate was lower than that of the parent drug, CQ.
,
Table 2. Activity of unmodified CPP and respective conjugates 5a-5i against P. falciparum W2.
CPP
IC50/µM
SD (n = 3)
Cq-C4-CPP
IC50/µM
SD (n = 3)
TP10
Transportan
DPT-sh1
DPT-sh2
IDR-1018
TAT
PasTAT
R9
Penetratin
5.5
3.1
0.2
0.8
Cq-C4-TP10, 5a
Cq-C4-Transportan, 5b
Cq-C4-DPT-sh1, 5c
Cq-C4-DPT-sh2, 5d
Cq-C4-IDR-1018, 5e
Cq-C4-TAT, 5f
Cq-C4-PasTAT, 5g
Cq-C4-R9, 5h
Cq-C4-Penetratin, 5i
1.5
5.2
0.1
0.2
-
-
-
-
0.2
-
>10
>10
>10
>10
>10
>10
>10
-
-
-
-
-
-
-
>10
>10
>10
>10
8.5
>10
>10
-
CQ (1)
0.699 a
a
Value taken from [22].

Molecules 2019, 24, 4559
5 of 21
Table 3. Antiplasmodial (P. falciparum 3D7) and hemolytic activity of conjugates 3a, 5a, 10-14, 140.
% hemolysis at 10 µM ± SD
(n = 3)
Test Compound
MW/Da
IC50 ± SD (n = 3)/µM
hRBC
PiRBC
a
PQ-C4-TP10, 3a
2525
-
89 ± 8
49 ± 7
Cq-C4-TP10, 5a
Cq-C10-TP10, 10
Cq-TR-TP10, 11
Cq-S-S-TP10, 12
TP10-C4-Cq, 13
TP10-S-S-Cq, 14
2514
2626
2665
2636
2514
2636
0.8 ± 0.1
0.8 ± 0.3
1.2 ± 0.2
1.0 ± 0.3
23 ± 1
6.5 ± 0.4
38 ± 2
19 ± 1
23 ± 1
10.7 ± 0.1
2.0 ± 0.3
41 ± 2
8.5 ± 0.5
50 ± 2
a
-
2.3 ± 0.4
18.2 ± 0.8
7 ± 1
a
TP10-S-S-PQ, 140
2647
-
99.7 ± 0.4
3.7 ± 0.1
72 ± 9
TP10
CQ, 1
Cq, 4
2182
319.9
249.7
n.a.
1.9 ± 0.5
3.4 ± 0.2
c
c
0.021b
-
-
-
-
c
c
0.07 ± 0.02
0.024d
Cq + TP10 1:1
4.4 ± 0.6
1.8 ± 0.5
Consistent growth inhibition data could not be obtained; b taken from reference [ ]; c hemolysis not detected;
2
a
d
SD (n = 3) were too high, this should be considered an orientative, not an accurate value; n.a., not applicable.
These results clearly show that antiplasmodial activity of the conjugates is influenced by both
the aminoquinoline and the peptide building blocks. The lack of activity of DPT-sh1 and -sh2
derived conjugates, 5c and 5d, was somewhat surprising, as those peptides had been reported to
preferentially internalize PiRBC [18]. Considering these results, we hypothesized that the modest or
absent antiplasmodial activity of conjugates 5a-5i might be explained by inadequate linkage between
CPP and drug, as linker features such as length, stability, lipophilicity, or lability towards specific
environments are likely to affect the overall performance of the conjugate [14,23,24].
2.2. Synthesis, Antiplasmodial, and Hemolytic Activity of Second-Generation Conjugates 10–14
To test the above hypothesis, i.e., to explore how variation of the spacer and conjugation chemistry
might affect the antiplasmodial activity of Cq-CPP conjugates, and keeping in mind that conjugation
of Cq to TP10 produced the most active first-generation conjugate, 5a, a series of novel conjugates
(Table 3) was synthesized, with the aminoquinoline linked to TP10 through different spacers, namely,
a larger flexible alkyl spacer (Cq-C10-TP10, 10), to increase the lipophilicity and drug’s exposure;
a rigid 1,2,3-triazole ring (Cq-TR-TP10, 11), which has been widely explored for the modification of
antiplasmodial agents [25–28], and a disulfide linker (Cq-S-S-TP10, 12), providing a labile (chemo-
and bio-reducible) linkage between peptide and drug. Moreover, to evaluate the relevance of the
relative position of drug and peptide building blocks (drug coupled at the peptide N- or C-terminus),
two additional conjugates were synthesized, with Cq conjugated to the TP10 C-terminal region through
a succinyl (TP10-C4-Cq, 13) or disulfide (TP10-S-S-Cq, 14) linker.
These second-generation conjugates (synthesis routes depicted in Scheme 2; Scheme 3) were
evaluated in vitro, alongside the commercial reference drug, CQ (
1), their parent building blocks,
TP10 and Cq ( ), and first-generation conjugate 5a, regarding their ability to inhibit growth of
4
blood-stage parasites of the CQ-sensitive P. falciparum 3D7 strain (Table 3). The primaquine analogues
of Cq conjugates 5a and 14, respectively, PQ-C4-TP10 (3a) and TP10-S-S-PQ (Figure 2, 140), were also
included for comparison; the synthesis of these conjugates, 3a and 140, has been reported elsewhere [20].
Of note, substantial hemolysis was detected upon erythrocyte exposure to some of the test conjugates,
particularly at the higher concentrations tested. In view of this, emolysis assays were also conducted
on cultures of both hRBC and PiRBC (Table 3).

Molecules 2019, 24, 4559
6 of 21
Scheme 2. Synthesis of conjugates 10–12: (i) 5 eq, respective to the resin reactive groups, of the fluorenylmethyloxycarbonyl (Fmoc) or tert-butyloxycarbonyl
(Boc)-AA-OH in DMF (0.2 M), 5 eq of 0.5 M HBTU/HOBt in DMF, and 10 eq of 2 M DIPEA in N-NMP, MWI for 5 min at 35 W; (ii) 20% piperidine in DMF containing
0.1 M of HOBt, MWI for 30 s at 24 W plus 3 min at 28 W; (iii) 5 eq of and of PyBOP, 10 eq DIPEA in DMF, RT, overnight; (iv) TFA/water/TIS 95:2.5:2.5 v/v/v (1 mL/100
mg of resin), RT, 120 min; (v) 1.2 eq of succinic anhydride and of DIPEA in DMF, RT, 120 min; (vi) 6-azido hexanoic acid (1.2 eq), HBTU (1.2 eq), DIPEA (2.4 eq) in DMF,
0 ◦C
RT, 3 h; (vii) copper(I) bromide (1.2 eq), 2,6-lutidine (10 eq), sodium ascorbate (3 eq), and DIPEA (10 eq), solubilized in a mixture of acetonitrile (ACN) and
DMF (1:2 v/v), RT, overnight; (viii) Boc-Cys(Trt)-OH (1.2 eq), HBTU (1.2 eq), DIPEA (2.4 eq) in DMF, 0 ◦C RT, 3 h; (ix) TFA:TIS:H2O 95:2.5:2.5 (v/v/v), 1 h, 0 ◦C
RT;
(x) 1 M aqueous acetic acid, RT, 36 h. Grey sphere stands for the Rink-amide resin used as polymer support used for SPPS. Ph, phenyl group.
6
→
→
→

Molecules 2019, 24, 4559
7 of 21
Scheme 3. Synthesis of conjugates 13–17: (i) resin treated with 1% TFA in DCM, RT, until no yellow color detected in filtrate; (ii) 5 eq of
6 and of PyBOP, 10 eq DIPEA
in DMF, RT, overnight; (iii) 1.2 eq of succinic anhydride and of DIPEA in DMF, RT, 120 min; (iv) 20% piperidine in DMF containing 0.1 M of HOBt, MWI for 30 s at
24 W plus 3 min at 28 W; (v) TFA/water/TIS 95:2.5:2.5 v/v/v (1 mL/100 mg of resin), RT, 120 min; (vi) 1 M aqueous acetic acid, RT, 36 h; (vii) Boc-Cys(Trt)-OH (1.2 eq),
HBTU (1.2 eq), DIPEA (2.4 eq) in DMF, 0 ◦C
(0.3 eq), anhydrous MeOH, 18 h, RT; (x) 5(6)-carboxyfluorescein (CF; 5.0 eq), PyBOP (5.0 eq), DIPEA (10 eq), DMF, 2 h, RT.
→
RT, 3 h; (viii) TFA:TIS:H2O 95:2.5:2.5 (v/v/v), 1 h, 0 ◦C
→
RT; (ix) 2,20-dithiopyridine (2-PDS, 2.0 eq), glacial acetic acid

Molecules 2019, 24, 4559
8 of 21
Figure 2. Structure of conjugate 140, TP10-S-S-PQ.
Antiplasmodial activities of CQ ( ), TP10 and 5a were greater against the CQ-sensitive 3D7 strain
1
than against the CQ-resistant W2 strain (Tables 2 and 3). While increased activity against CQ-sensitive
3D7 versus CQ-resistant W2 was expected for CQ, these results highlight that resistance mechanisms
in P. falciparum W2 also alter its sensitivity to the unmodified peptide and its Cq conjugate. The W2
strain is resistant to many antimalarials, including CQ, and has been reported to exhibit multiple
resistance determinants [29], including mutations in the P. falciparum CQ resistance transporter (PfCRT)
and P. falciparum multi-drug resistance transporter 1 (PfMDR1) [25]. In fact, parasite resistance to
CQ has been primarily associated with mutations in PfCRT [30
resistance are not well understood, but which likely include changes in the pH of the parasite digestive
vacuole (DV), limiting accumulation of basic CQ [32 33]. Hence, it is reasonable to assume that, as
,31], for which mechanisms mediating
,
they are also basic, both the CPP and its conjugate 5a will have lower accumulation in the DV of W2,
compared to 3D7 parasites.
The in vitro activity of Cq (
4), which was the building block actually used in the synthesis of
conjugates and 10–14, was comparable to that of CQ (
5
1); this was an expected observation, based on the
well-known structure-activity relationships described for CQ and related compounds, which highlight
the vital role of the 7-chloro-4-aminoquinoline core and the possibility to carry out slight to moderate
changes in the aliphatic moiety without a major impact on activity [34]. Moreover, the equimolar
mixture of Cq (4) with TP10 was also tested, but the apparent IC50 value displayed, which was similar
to that of Cq alone, cannot be regarded as an accurate one, as high standard deviation values were
obtained. Still, this suggests that there are no synergistic effects arising from non-covalent combination
of those two building blocks.
Regarding the influence of the linker and relative position of the peptide and drug building
blocks on antiplasmodial activity, comparison of IC50 values obtained for conjugates 5a and 10–14
allow us to infer that: (i) increasing the size and, consequently, hydrophobicity, of an alkyl spacer
(
5a versus 10) does not significantly alter activity; (ii) increasing polarity and rigidity of the linker
(as in 11 versus 5a or 10) causes a decrease in antiplasmodial activity; (iii) replacing a stable linker
(as in 5a 10 or 11) by a chemo- and bio-reversible disulfide, as in 12, does not contribute to an increase
,
in antiplasmodial activity; (iv) altering the order in which peptide and drug are linked together, i.e.,
moving the antimalarial building block from an N-terminal (as in 12) to a C-terminal (as in 14) position
does not favor antiplasmodial activity.
Relevantly, for PQ-derived conjugates 3a and 140, i.e., where the 4-aminoquinoline building block
in 5a and in 14, respectively, was replaced by the antimalarial 8-aminoquinoline PQ, in vitro data on
blood-stage activity could not be reliably determined, due to the extensive hemolytic effects displayed
by those conjugates (Table 3). Hemolytic activity was equally considerable for Cq-derived conjugates
5a and 10–14, and data compiled on Table 3 show that: (i) while CQ (1) and its analogue Cq (4) are
not hemolytic, and peptide TP10 is only slightly hemolytic, all conjugates are significantly hemolytic,
especially for cultures exclusively containing hRBC; (ii) the least hemolytic conjugate is 12, where Cq is
linked to TP10 through a bioreducible disulfide bridge, indicating that (iii) using a stable linker as in
5a, 10, and 11 significantly increases hemolysis, which might be associated with a “detergent”-like

Molecules 2019, 24, 4559
9 of 21
action on erythrocyte membranes; (iv) coupling the drug to the peptide C- rather than N-terminus
augments hemolytic activity, as illustrated by data for 14 vs. 12 and for 13 vs. 5a.
In fact, the significant hemolytic activity of 13 impeded the determination of consistent
antiplasmodial activity data, as occurred with the PQ-derived conjugates 3a and 140; (v) % hemolysis
was greater for erythrocyte cultures exclusively containing hRBC than for those where 3% of the
erythrocytes were PiRBC, suggesting that the conjugates are more disruptive to membranes of hRBC
than to those of PiRBC.
Still in regard to hemolysis, the equimolar mixture of Cq and TP10 displayed very low hemolytic
activity, similar to that of TP10 alone; this highlights the fact that the substantial hemolytic effects
observed for drug-peptide conjugates only arise when both building blocks are covalently bound to
each other. Noteworthy, the hemolytic activity previously reported for Transportan [35] differs from
that found by us for TP10; this is not surprising, as, though related, Transportan and TP10 are not
the same peptide. Still, the hemolytic activity of TP10 has also been reported before [36], and differs
from that obtained by us. However, in the previously reported study, whole blood samples treated
with an anticoagulant were used for hemolysis assays, whereas we opted to use isolated erythrocytes,
i.e., separated from the other blood components. This choice was based in the fact that fluorescently
labeled analogues of our conjugates (see Section 2.3) were found to gather around, and internalize,
leucocytes (data not shown); this precludes accurate determination of hemolysis that, by definition,
is the destruction of red blood cells.
Considering the findings above described, further studies of interactions between Cq-CPP
conjugates and erythrocytes (both hRBC and PiRBC) were pursued, by means of fluorescence microscopy
and flow cytometry, as follows.
2.3. Insights into the Interactions between Chloroquine-Peptide Conjugates and Erythrocytes
Erythrocyte targeting and internalization studies were carried out using fluorescently labeled
derivatives of the most active conjugate 5a
(16), of the parent peptide TP10 (15), and of the inactive
conjugate Cq-C4-TAT 5f 17), for comparison. Fluorescent labeling was achieved by coupling
(
5(6)-carboxyfluorescein (CF) to a lysine residue added to the C-terminus of the peptide sequence,
as depicted in Scheme 3. After incubating the fluorescently labeled compounds 15–17 in asynchronous
cultures of P. falciparum 3D7 at 3% parasitemia (i.e., containing 3% PiRBC and 97% hRBC), the nuclei of
intraerythrocytic parasites were stained with DNA-binding Hoechst 33342 [37], and cell suspensions
analyzed through flow cytometry.
Quantitative data from this analysis (Figure 3), allowed us to conclude that: (i) binding of the
fluorescently labeled Cq-C4-TP10 (16) to red blood cells (hRBC + PiRBC) is significantly higher than that
of unconjugated TP10 (15), essentially due to much increased interaction of 16 with hRBC, as compared
to the peptide, since the degree of binding of either peptide (15) or conjugate (16) to PiRBC does
not substantially differ; and (ii) the interaction of fluorescently labeled Cq-C4-TAT (17) with either
uninfected or parasitized RBC, is negligible.
Quantitative analysis of cell suspensions was complemented by fluorescence microscopy studies.
As shown in Figure 4A,B, both the CF-labeled peptide TP10 (15) and its Cq-conjugate 16 apparently
interact only with RBC that show significant membrane damage, so-called “ghost” erythrocytes.
In turn, no green fluorescence was detected on hRBC with an apparently intact membrane or in the
presence of the inactive Cq-TAT conjugate 17 (not shown). Likewise, both labeled TP10 (15) and its Cq
conjugate (16) seemed to interact preferentially with PiRBC (parasitized cells can be identified by blue
staining parasites nuclei), which show clearly damaged membranes and host parasites that are at a
later stage of development (Figure 5A,B).

Molecules 2019, 24, 4559
10 of 21
3A
3B
3C
Figure 3. Flow cytometry analysis of the interaction between hRBC/PiRBC and CF-labelled (
A)
TP10, ( ) Cq-C4-TP10, and ( ) Cq-C4-TAT. Upper quadrants (Q1 and Q2) refer to compound-bound
B
C
cells (green CF fluorescence) and right-hand quadrants (Q2 and Q4) refer to PiRBC (blue Hoechst
fluorescence). Q3 includes hRBC, which were not internalized by the CF-labelled test compounds.
4A
4B
Figure 4. Microscopy fluorescence images showing the interaction between hRBC and (
A) CF-labeled
TP10 (15) and (B) CF-labeled Cq-C4-TP10 (16). Arrows depict “ghost” uninfected erythrocytes.

Molecules 2019, 24, 4559
11 of 21
5A
5B
Figure 5. Microscopy fluorescence images showing the interaction between PiRBC (distinguished by
the blue staining of parasites’ nuclei) and ( ) CF-labeled TP10 (15) and ( ) CF-labeled Cq-C4-TP10 (16).
Arrows depict “ghost” Plasmodium-infected erythrocytes.
A
B
While unconjugated peptide (15) apparently co-localizes with parasite DNA (Figure 6A), its Cq
conjugate 16 does not; instead, the latter seems to be bound to what appears to be PiRBC debris
produced by cellular disruption upon parasite release (Figure 6B), although, without additional studies,
one cannot rule out the hypothesis of being a lymphocyte phagocytizing the peptide. Taken together,
these observations suggest that peptide and conjugate have different modes of interaction, with an
apparently stronger perturbation of the host cell membrane by the conjugate, consistent with its greater
hemolytic activity compared to the unconjugated peptide (Table 3).
6A
6B
Figure 6. Microscopy fluorescence images showing an apparent co-localization of (
A) CF-labeled TP10
(
15) and DNA of parasites released after PiRBC disruption, or of ( ) CF-labeled Cq-C4-TP10 (16) and
B
what appears to be PiRBC debris surrounding nuclei of released parasites.
Although it can be argued that insertion of an external moiety, like a fluorescent tag, onto a bioactive
molecule, could dramatically change its physiological behavior, this concern is practically limited to
cases where a large fluorophore is coupled to a small drug. However, many studies on the ability
of distinct CPP and CPP conjugates to internalize different types of cells, including small constructs
designed to cross the blood-brain barrier, have relied on the use of differently sized fluorophores,
including very large ones, such as fluorescent proteins or quantum dots [38]. This implicitly means that
such diverse fluorescent cargos do not considerably change the cell-penetration/interaction properties
of the labelled peptide constructs. The same can be assumed in our case, since the distinct behavior of
the fluorescently-labelled TP10 and TAT conjugates reflected the in vitro anti-plasmodial and hemolytic
data on the respective untagged analogues. Indeed, the fact that both TP10 and its conjugate only

Molecules 2019, 24, 4559
12 of 21
interact with RBC whose membranes are visibly thinned agrees with in vitro data associating these
compounds with hemolytic effects. None of the compounds were observed inside ring stage PiRBC,
but only in hRBC (Figure 4) or PiRBC at later stages of parasite development (Figure 5). This suggests
that, as soon as it invades an RBC, the parasite induces modifications in the membrane that render
it more impermeable to both the CPP and its drug conjugate; later, as RBC egress is approached,
increased permeability of both the parasitophorous vacuole and the erythrocyte membrane may
facilitate internalization and subsequent antiplasmodial action [39]. Lastly, although it remains to be
confirmed if interactions between the TP10-derived conjugate 16 and RBC membranes are the major
cause for the display of antiplasmodial activity, it is undeniable that they must have a role in such
activity, as they were not observed for its inactive TAT-derived analogue 17.
3. Discussion
Taken together, our results demonstrate that significant changes in the mode of interaction
of TP10, an antiplasmodial CPP, with RBC are induced upon conjugation of the peptide with the
aminoquinoline Cq (4). However, Cq alone cannot account for the hemolytic and antiplasmodial
properties of the conjugate, as Cq-C4-TAT did not display a similar behavior; instead, the latter was
unable to invade erythrocytes or interact with their membranes, which is clearly correlated with its
lack of antiplasmodial activity.
The significant increase in the hemolytic activity of TP10 upon conjugation to the 4-aminoquinoline
suggests that drug cargo prevents an otherwise active CPP carrier from exerting the desired cell
penetrating/antiplasmodial action safely, as it produces conjugates that exert membranolytic activity.
Similarly, we recently found that PQ-CPP conjugates 3 (Figure 1) [20], including the PQ-TP10 conjugates
3a and 140, respectively analogue to 5a and 14, are also significantly hemolytic (Table 3). Thus, hemolytic
effects are seen with conjugation to a 4- or 8-aminoquinoline. Also, lytic effects might be specific to RBC,
as PQ-CPP conjugate
3 is not toxic to hepatocytes [20]. RBC have specific characteristics, including
being enucleated, having a highly plastic biconcave discoid structure, and stabilization by the so-called
RBC membrane skeleton [40]. As such, membrane interaction and internalization phenomena in RBC
are complex and different from those operating in other types of mammalian cells [41]. Moreover,
it has been recently suggested that changes in membrane and membrane-skeleton organization
continuously occur from the early stages of erythropoiesis up to the end of the life of an erythrocyte [42].
In addition, upon invasion by Plasmodia, erythrocyte membranes undergo several changes [43
–45].
In any event, both this and previous reports [ ] demonstrate that TP10 is a CPP able to (i) interact
8
with PiRBC membranes, and (ii) display antiplasmodial activity, without provoking significant
hemolysis. However, attaching aminoquinolines does not contribute to increase antiplasmodial activity,
and triggers important hemolytic effects. Possibly, the heterocyclic aminoquinoline core inserts into
the fatty acid chains of the RBC membrane lipid bilayer, causing an increase in the lipid-lipid distance
and in membrane fluidity, ultimately leading to RBC disruption. This is being further studied using
biophysical techniques.
4. Materials and Methods
4.1. Chemicals and Reagents
Except where otherwise stated, chemicals used for this work were purchased from Sigma-Aldrich.
Rink-amide 4-methylbenzhydrylamine (MBHA) resin (0.52 mmol/g), Nα-Fmoc or Boc-protected
amino acids, and HBTU, for SPPS, were purchased from NovaBiochem. High performance liquid
chromatography (HPLC) gradient or liquid chromatography-mass spectrometry (LC-MS) grade
solvents were purchased from Merck.
Aluminum foils coated with silica-gel 60 F254 from Merck (Darmstadt, Germany) were used for
thin-layer chromatography (TLC), and TLC chromatograms obtained were revealed under ultra-violet
light (254 nm), using a Viber Lourmat lamp, model CN-6 (Vilber, Eberhardzell, Germany).

Molecules 2019, 24, 4559
13 of 21
Purifications by liquid column chromatography were performed utilizing silica gel 60 as stationary
phase. The mobile phase varied for each compound and is specified below.
P. falciparum 3D7 strain (chloroquine and mefloquine susceptible) was continuously cultured as
previously described [46]. Parasitemia was monitored daily by microscopic examination of Giemsa
(MERCK, Sigma-Aldrich) stained thin blood smears.
4.2. Instrumentation and General Procedures
Solid phase synthesis was carried out on a Liberty 1 microwave-assisted solid phase peptide
synthesizer (CEM Corporation, Mathews, NC, USA). Peptide analysis by analytical high performance
liquid chromatography (HPLC) was done using a Hitachi-Merck Elite LaChrom system from Hitachi
High-Technologies America (Schaumburg, IL, USA) equipped with an L-2130 quaternary pump,
an L-2200 thermostatted (Peltier effect) automated sampler, and an L-2455 diode-array detector (DAD).
Samples were prepared by solubilization of crude products in aqueous acetic acid (10% v/v) and
injected in a reverse phase C18 column Purospher star RP-C18 of 125
×
4.0 mm with 5 µM pore size.
A gradient elution of varying proportions of 0.05% aqueous TFA (eluent A) and acetonitrile (ACN)
(eluent B) was carried out for 30 min, at a flow rate of 1 mL/min, and detection was set at 220 nm.
A Finnigan Surveyor LCQ DECA XP MAX spectrometer was used either alone, for direct electrospray
ionization-ion trap mass spectrometry (ESI-IT MS) analysis, or coupled to a Finnigan Surveyor HPLC,
equipped with a DAD Plus Detector, an Autosampler Plus and an LC Pump Plus, from ThermoElectron
Corporation (Waltham, MA, USA), for LC-MS analysis. In either case, samples were prepared by
sample solubilization in aqueous acetic acid (10% v/v). ESI-IT MS spectra and chromatograms obtained
for the synthesized compounds can be found in Supplementary Materials.
Purifications of CPP and CPP-drug conjugates were carried out by preparative HPLC, to a purity
of at least 90%. To this end, samples were injected in a LaPrep Sigma VWR preparative HPLC system
equipped with an UV detector LP 3104 and an LP 1200 pump; a reverse-phase C18 column (250
×
25 mm ID with 5 µM pore size) from Merck was used, and a gradient elution using a varying
relative proportion of eluent A and eluent B was carried out for 60 min at a flow rate of 15 mL/min.
Pure peptide fractions were pooled and freeze-dried, using a VirTis freeze drier, model BenchTop Pro
9L with Omnitronics, from SP Scientific. A FACSort flow cytometer using CellQuest software (Becton,
Dickinson, and Company, Franklin Lakes, NJ, USA) was used for antimalarial activity assays in vitro
.
For fluorescence microscopy studies, an Olympus IX51 inverted system microscope, equipped with
an IX2-SFR X-Y stage, a U-TVIX-2 camera and a fluorescence mirror unit cassette for UV/blue/green
excitation and detection of the corresponding blue/green/red emission ranges, was used. A BD
LSRFortessa cell analyzer (Becton Dickinson S.A., San Agustín del Guadalix, Spain) was used for FCM.
4.3. Solution-Phase Synthesis
4.3.1. Synthesis of N-(7-Methylquinolin-4-yl)butane-1,4-diamine, Cq (4)
We mixed 1.0 molar equivalents (eq) of 4,7-dichloroquinoline and 10.0 eq of butane-1,4-diamine
in a round bottom flask, and the resulting solution was heated to 100 ◦C and left under reflux for
3 h. Then, the mixture was allowed to cool down to room temperature (RT), diluted with 25 mL of
dichloromethane (DCM) and washed three times with an aqueous solution of Na2CO3. The organic
phase was then dried with anhydrous Na2SO4 and, after filtration, the DCM was evaporated under
reduced pressure. The resulting white solid (80% yield) was chromatographically homogeneous (TLC),
and presented correct mass spectral data (ESI-IT MS, positive mode): m/z calculated for C13H16ClN3:
249.10 atomic mass units (a.m.u.); found: 250.33 (quasi-molecular ion, [M + H+]+).
4.3.2. Synthesis of 3-({4-[(7-Methylquinolin-4-yl)amino]butyl}carbamoyl)propanoic acid, Cq-C4 (6)
Compound
4 (1.0 eq), succinic anhydride (1.2 eq), and DIPEA (1.2 eq) were dissolved in DMF,
and the mixture was stirred for 2 h (RT). Then, the mixture was diluted with a 1:1 (v/v) mixture of

Molecules 2019, 24, 4559
14 of 21
DCM and methanol (MeOH), and purified by liquid chromatography on a silica gel column, using
the same DCM/MeOH mixture as eluent. Compound was obtained as a chromatographically
6
homogeneous white solid (85% yield), whose structure was confirmed by ESI-IT MS (+). m/z calculated
for C17H20ClN3O3: 349.12 a.m.u.; found: 350.67 ([M + H+]+).
4.3.3. 6-Azido-N-{4-[(7-Methylquinolin-4-yl)amino]butyl}hexanamide, Cq-C6-N3 (7)
6-azido hexanoic acid (1.2 eq) was mixed with HBTU (1.2 eq), and DIPEA (2.4 eq), in DMF, and
the mixture placed under stirring in an ice-water bath, for 30 min. Then, compound
added, the reaction left under stirring in the ice-water bath, and its progress monitored by TLC. After
3 h, the mixture was diluted in ethyl acetate (20 mL) and washed with 5% aqueous Na2CO3 (3
4 (1.0 eq) was
×
15 mL). The organic layer was dried with anhydrous Na2SO4 and, after filtration, ethyl acetate was
removed by evaporation under reduced pressure. The crude residue was then purified by liquid
column chromatography on silica gel, using DCM/MeOH (5:1 v/v) as eluent, to afford 7 in 57% yield
and presenting correct ESI-IT MS (+) data. m/z calculated for C19H26ClN6O: 389.19 a.m.u.; found:
389.73 ([M + H+]+).
4.3.4. Synthesis of 2-Amino-N-{4-[(7-Methylquinolin-4-yl)amino]butyl}-3-sulfanylpropanamide,
Cq-Cys (8)
The protected AA Boc-Cys(Trt)-OH (1.2 eq) was mixed with HBTU (1.2 eq) and DIPEA (2.4 eq)
in DMF, and the solution was stirred in an ice-water bath, for 30 min. Then, compound
4 (1.0 eq)
was added to the reaction mixture, which was left under stirring in the ice-water bath for another 3 h.
The mixture was then diluted in ethyl acetate (20 mL) and extracted with an aqueous solution of 5%
Na2CO3 ( 3). The organic phase was dried with anhydrous Na2SO4 and, after filtration, ethyl acetate
×
was removed by evaporation under reduced pressure. The resulting residue was then purified by
column chromatography on silica gel, using DCM/MeOH (20:1 v/v) as eluent, to afford the protected
Cq-Cys(Trt)-Boc intermediate. The Boc and Trt protecting groups were removed from this intermediate
by acidolysis with TFA (95%), TIS (2.5%), and H2O (2.5%) for 1 h, in an ice-water bath. Crude product
8
was precipitated from the reaction mixture using cold tert-butyl methyl ether (TBME), the slurry
centrifuged, the supernatant discarded, and the pellet re-suspended in fresh cold TBME. The procedure
was repeated three more times, after which the solid pellet, corresponding to compound 8, was dried in
a desiccator (75% yield). Cq-Cys was finally analyzed by ESI-IT MS, and stored at -20 ◦C until further
use. m/z calculated for C16H21ClN4OS: 352.11 a.m.u.; found: 353.47 ([M + H+]+).
4.3.5. 2-Amino-N-{4-[(7-Methylquinolin-4-yl)amino]butyl}-3-(pyridin-2-yldisulfanyl)propaneimide,
Cq-Cys(2-PDS) (9)
The thiol group in Cq-Cys (8) was activated upon reaction with 2-PDS. To this end, compound
8
(1.0 eq) and 2-PDS (2.0 eq) were dissolved in anhydrous methanol (4 mL) containing glacial acetic
acid (0.3 eq). The mixture was stirred at RT for 18 h and the solvent was removed under reduced
pressure to obtain the crude product. This was purified by flash chromatography on a two-step elution
starting with DCM/MeOH (10:1 v/v) as eluent, followed by DCM/MeOH (1:1 v/v) as the second eluent.
This afforded the target compound CQ-Cys(2-PDS) (9), in high purity and moderate yield (60%), and
with correct mass spectral data. m/z calculated for C21H24ClN5OS2: 461.11 a.m.u.; found: 462.20
([M + H]+).
4.4. Solid-Phase Synthesis
4.4.1. General Procedures for Solid-Phase Peptide Synthesis
All target peptide sequences (Table 1) were produced as C-terminal amides by microwave-assisted
solid-phase peptide synthesis. Generally, each peptide (C-terminal amide) was assembled by Fmoc/tBu
SPPS methodologies, assisted with microwave energy, on a Rink amide MBHA resin that was

Molecules 2019, 24, 4559
15 of 21
preconditioned for 15 min in DMF and then transferred into the reaction vessel. The initial Fmoc
deprotection step was carried out using 20% piperidine in DMF containing 0.1 M HOBt in two
microwave irradiation pulses: 30 s at 24 W plus 3 min at 28 W, in both cases with temperature below
75 ◦C. The C-terminal AA was then coupled to the deprotected resin, using 5 eq of the Fmoc-protected
AA (Fmoc-AA-OH) in DMF (0.2 M), 5 eq of 0.5 M HBTU/HOBt in DMF, and 10 eq of 2 M DIPEA in
NMP; the coupling step was carried out for 5 min at 35 W microwave irradiation, with maximum
temperature reaching 75 ◦C. The remaining AA were sequentially coupled in the C
N direction by
→
means of similar deprotection and coupling cycles, except for the incorporation of Fmoc-Cys(Trt)-OH,
which requires special attention during synthesis under microwave conditions in order to minimize the
possibility of its racemization [47]. Hence, this amino acid was coupled in two steps, first with 2 min
coupling without microwave irradiation (RT), then followed by 4 min coupling at 25 W, with maximum
temperature reaching 50 ◦C. Following completion of the sequence, the N-terminal Fmoc-protecting
group was removed with piperidine, as above, and the peptidyl-resin split in several portions to be
either (i) cleaved to afford the unmodified (parent) CPP, or (ii) further modified (if needed) and coupled
to compounds 6–9 (see below), then cleaved to afford the relevant drug-CPP conjugate. In either case,
the target crude product was released from the resin with simultaneous removal of the AA side-chain
protecting groups, by a 2-h acidolysis (RT) using a TFA-based cocktail containing either (i) TIS and
deionized water as scavengers (TFA/TIS/H2O 95:2.5:2.5 v/v/v) for peptides with up to two arginine
residues, or (ii) thioanisole, ethane-1,2-dithiol and anisole (90:5:3:2 v/v/v/v) for peptides with more
than two arginines. Crude products were precipitated and washed with cold TBME, and purified by
preparative HPLC. ESI-IT MS and analytical HPLC were used to check for the product’s molecular
weights and purity. All peptides and respective conjugates were freeze-dried and stored at
until further use.
−
20 ◦C
4.4.2. Synthesis of Cq-C4-CPP Conjugates (5a–5i)
Each of the CPPs listed in Table 1 were coupled on-resin prior to cleavage to compound
6, to afford
peptide-drug conjugates 5a–5i. To this end, (5 eq) was pre-activated with PyBOP (5 eq) and DIPEA
6
(10 eq) for 10 min (RT), and then added to each peptidyl-resin. The reaction was left overnight under
stirring, then resin was washed three times with DMF and another three times with DCM. The final
Cq-C4-CPP conjugates 5a–5i were obtained after acidolytic cleavage, and purification by preparative
HPLC, as above described.
4.4.3. Synthesis of Cq-C10-TP10 Conjugate (10)
TP10 was assembled by microwave-assisted SPPS, as previously described, and its sequence
further elongated upon coupling of an additional 6-aminohexanoyl (Ahx) residue at the N-terminus.
To this end, Fmoc-Ahx-OH was coupled to the peptidyl-resin as described for standard AA. After
removal of Fmoc and convenient washing of the resin, compound 6 was coupled to the resin-bound
N-(6-aminohexanoyl)-TP10 peptide, as described for conjugates 5a–5i. The target Cq-C10-TP10
conjugate (10) was obtained after cleavage and purification, as before.
4.4.4. Synthesis of Cq-TR-TP10 Conjugate (11)
TP10 was assembled by microwave-assisted SPPS, as previously described, and its sequence further
elongated upon coupling of an additional Fmoc-protected propargylglycine residue (Fmoc-Pra-OH) to
the peptide’s N-terminus, and its Fmoc-protecting group next removed, by standard procedures in
SPPS. Then, the resin-bound N-(propargylglycyl)-TP10 peptide was reacted with compound
7 (1.2 eq)
in the presence of copper(I) bromide (1.2 eq), 2,6-lutidine (10 eq), sodium ascorbate (3 eq), and DIPEA
(10 eq), solubilized in a mixture of ACN and DMF (1:2 v/v) [48]. The slurry was stirred overnight (RT),
after which the resin was thoroughly washed with DCM (3
A 2-h acidolysis, using 95% TFA, 2.5% TIS, and 2.5% water, delivered crude product 11, which was
×
), MeOH (3
×
), ACN (3
×
), and DMF (3 ).
×
purified, analyzed, and stored as above.

Molecules 2019, 24, 4559
16 of 21
4.4.5. Synthesis of Cq-S-S-TP10 Conjugate (12)
TP10 was assembled by microwave-assisted SPPS as before, and its sequence further elongated
upon coupling of its N-terminal AA to an additional Boc-Cys(NPys)-OH (5.0 eq), pre-activated with
HBTU (5.0 eq) and DIPEA (10 eq), as usual. The peptidyl-resin was then cleaved as described above,
to render the peptide intermediate H-Cys(NPys)-TP10 (12). This intermediate (1.0 eq) was next mixed
with compound 8 (1.2 eq) in 1 M aqueous acetic acid, and the thiol-disulfide exchange reaction allowed
to proceed for 36 h under stirring (RT). Reaction progress was monitored by HPLC and LC-DAD/ESI-IT
MS. The target Cq-S-S-TP10 conjugate (12) was purified, analyzed and stored as described for the
other conjugates.
4.4.6. Synthesis of TP10-C4-Cq Conjugate (13)
Peptide TP10 was assembled by microwave-assisted SPPS as previously described,
but using a Fmoc-Lys(Mtt)-OH residue on position 19 of the peptide sequence (bold in
AGYLLGKINLKALAALAK
via mild acidolytic conditions without peptide cleavage from the resin [49
K
IL), enabling selective side-chain deprotection of this particular residue
50]. Once the peptide
,
sequence was fully assembled, and prior to removal of the N-terminal Fmoc protecting group,
the peptidyl-resin was treated with 1% TFA in DCM, for selective removal of the Mtt protecting group;
this procedure was repeated until the yellow color associated with Mtt release was no longer observed.
Then, after convenient washing of the peptidyl-resin, compound
-amine, by in situ activation with PyBOP (5.0 eq) and DIPEA (10 eq), in DMF. This reaction was left
overnight under stirring (RT), after which the resin was filtered and washed with DCM (3 ) and DMF
(3 ). The crude conjugate 13 was obtained by acidolytic cleavage, then purified, analyzed, and stored,
6 was coupled to the lysine side chain
ε
×
×
as previously described for the other conjugates.
4.4.7. Synthesis of TP10-S-S-Cq Conjugate (14)
A TP10 derivative bearing an additional C-terminal cysteine residue, or briefly, peptide TP10-Cys
(AGYLLGKINLKALAALAKKIL ), was assembled by standard microwave-assisted SPPS procedures,
and cleaved by acidolysis, as done for all other peptides. The peptide (1.0 eq) was then mixed with
compound (1.2 eq) in 1 M aqueous acetic acid, and the thiol-exchange reaction allowed to proceed for
C
9
48 h, at RT. This reaction was monitored by HPLC, with a gradient elution of 1–100% ACN in 0.05%
aqueous TFA, and by LC-DAD/ESI-IT MS. The target peptide conjugate, TP10-S-S-Cq (14) was purified,
analyzed, and stored as described for the other conjugates.
4.4.8. Synthesis of Fluorescently-Labeled TP10-K(CF) (15) and TAT-K(CF) Peptides
TP10 and TAT derivatives bearing an additional C-terminal lysine, i.e., TP10-Lys
(AGYLLGKINLKALAALAKKILK) and TAT-Lys (RKKRRQRRRPPQK) were synthesized via standard
microwave-assisted SPPS, using Fmoc-Lys(Mtt)-OH (5.0 eq) as the C-terminal residue. Once each
peptide sequence was fully assembled, and prior to removal of the N-terminal Fmoc protecting group,
the peptidyl-resin was treated with 1% TFA in DCM, for selective removal of the Mtt protecting group;
this procedure was repeated until the yellow color associated with Mtt release was no longer observed.
Then, after convenient washing of the peptidyl-resin, 5(6)-carboxyfluorescein (CF) was coupled to
the lysine side chain
This reaction proceeded for 2 h under stirring (RT), after which the resin was filtered and washed with
DCM (3 ) and DMF (3 ). The Fmoc-protected peptidyl-resin bearing the TP10-based sequence was
ε-amine, by in situ activation with PyBOP (5.0 eq) and DIPEA (10 eq), in DMF.
×
×
split into two equal portions, one of which was treated with piperidine for removal of the N-terminal
Fmoc-protecting group, and next cleaved by acidolysis to release the fluorescently-labeled peptide
15, which was purified, analyzed and stored as before. The other portion was stored for subsequent
on-resin coupling to compound
6 (see below). Likewise, the Fmoc-protected peptidyl-resin bearing the
TAT-based sequence was stored for subsequent coupling to compound 6 (see below).

Molecules 2019, 24, 4559
17 of 21
4.4.9. Synthesis of Fluorescently Labeled Cq-C4-TP10-K(CF) (16) and Cq-C4-TAT-K(CF)
(17) Conjugates
Fmoc-protected peptidyl resins bearing the fluorescently labeled peptides TP10 and TAT, prepared
as described above, were treated with 20% piperidine in DMF, to remove the N-terminal Fmoc
protecting group. Next, compound 6 was coupled to the peptidyl-resin, upon activation with PyBOP
(5.0 eq) and DIPEA (10.0 eq), in DMF. This reaction was kept under stirring overnight (RT), after which
the resin was filtered and washed with DCM (3
conjugates 16 and 17 were obtained after a 2 h cleavage (RT) of the peptidyl-resins with a solution of
×
) and DMF (3 ). The crude fluorescently-labeled
×
TFA (95%), TIS (2.5%), and water (2.5%). The conjugates were purified, analyzed, and stored as above.
4.5. In Vitro Assessment of Antimalarial Activity
4.5.1. Activity of Conjugates 3a and 5a-i against P. falciparum W2
Synchronized ring-stage P. falciparum parasites (W2 strain) were incubated with test compounds
for 48 h in Roswell Park Memorial Institute (RPMI) 1640 medium containing 10% human serum or 0.5%
Albumax serum substitute. Parasites were then fixed with 1% formaldehyde in phosphate-buffered
saline (PBS), pH 7.4, for 48 h at RT and labeled with YOYO-1 (1 nM; molecular probes) in 0.1% Triton
X-100 in PBS. Parasitemias were determined by flow cytometry, from dot plots (forward scatter versus
fluorescence). For 50% inhibitory concentration (IC50) determinations, dose-response studies were
performed, with the values normalized to percent control activity, and IC50s were calculated using
GraphPad Prism, with data fitted by nonlinear regression.
4.5.2. Activity of Conjugates 3a, 5a, 140 and 11–15 against P. falciparum 3D7
Synchronized ring-stage P. falciparum (3% hematocrit, 1% parasitemia) were incubated in a
microtiter plate for 48 h in the presence of two-fold serial dilutions of TP10 and derived conjugates
11–15, in the 10–10000 nM concentration range. Cultures incubated with three-fold serial dilutions of
chloroquine bisphosphate, and also of its analogue 4, in the 0.1–8000 nM concentration range, were
included for comparison. Culture without test compounds was also added to the microtiter plate,
as negative control. After incubation, 100 µL of a solution of SYBR Green (Thermo Fisher; SG; 0.001%
v/v in PBS) was added to each well and plates incubated for another 60 min under standard culture
conditions. Plates were then centrifuged at 2500 rpm for 2 min, the supernatant was discarded, and
cells were re-suspended in 100 µL of PBS. Fluorescence was collected in a multi-mode microplate
reader (Triad, Dynex Technologies) with excitation at 485 nm and emission at 535 nm [37]. Fluorescence
values were normalized (to take into account the normal growth of the parasite) and then plotted
against logC. IC50 were determined using GraphPad Prism 6.
4.6. In Vitro Assessment of Hemolytic Activity
PiRBC and hRBC were plated in micro-titer plates and cultured for 1 h in the presence of four-fold
serial dilutions of Cq, TP10 and their conjugates (40–10000 nM). For positive and negative controls,
1% Triton X-100 and PBS were added, respectively. After this period, the plates were centrifuged
and supernatants transferred to another plate. Supernatant absorbance at 450 nm was assessed in
a multi-mode microplate reader (Triad, Dynex Technologies, Chantilly, VA, USA) and values were
treated using the following equation (1):
Abs − Abs(negative control)
% Hemolysis =
(1)
Abs(positive control) − Abs(negative control)

Molecules 2019, 24, 4559
18 of 21
4.7. Fluorescence Microscopy and Flow Cytometry Studies
4.7.1. Fluorescence Microscopy Assays
PiRBC suspensions (3% hematocrit, 3% parasitemia) were incubated for 1 h with CF-labeled
conjugates 15 or 16 (to a final concentration of 8
M), at 37 ◦C. After incubation, cells were washed
twice with culture medium and finally re-suspended in a solution of 2 g/mL of Hoescht 33342 in
µ
µ
culture medium, in order to stain the PiRBC nuclei. Cells were then diluted to 0.1% hematocrit in
RPMI 1640, and finally deposited onto a Lab-TekTM chambered coverglass slide. Microscopic analysis
was performed with an Olympus IX51 inverted system microscope, equipped with an IX2-SFR X-Y
stage, a U-TVIX-2 camera, and a fluorescence mirror unit cassette for UV/blue/green excitation and
detection of the corresponding blue/green/red emission ranges.
4.7.2. Flow Cytometry
Flow cytometry was used to determine the targeting efficiency of fluorescently labeled TP10 (15)
and conjugates 16 and 17 towards an unsynchronized P. falciparum 3D7 culture. To this end, parasitemia
was adjusted to approximately 3% and the culture was incubated for 1 h at 37 ◦C in the presence of the
labeled compounds (8
µM). After incubation, the suspensions were washed twice with RPMI complete
medium and finally re-suspended in a solution of 2
µg/mL of Hoechst 33342 in RPMI 1640, in order to
stain PiRBC nuclei. Samples were then diluted in PBS to a final concentration of 107 cells/mL, prior
to flow cytometry analysis. Forward- and side-scatter areas (FSC-A, SSC-A) in a linear scale were
used to gate the RBC population, and PiRBC stained with Hoescht 33342 were detected by excitation
through a 350 nm laser and emission collection with a 450/50 nm bandpass filter in a logarithmic scale.
RBC targeted by CF-labeled test compounds were detected by excitation through a 488 nm laser and
emission collection with a 525/50 nm bandpass filter in a logarithmic scale.
5. Conclusions
The disclosure of CPP as carriers for a wide range of payloads has been an undeniable scientific
breakthrough, paving the way towards targeted intracellular delivery of many different types of cargo,
from small anticancer drugs to large proteins and nucleic acids [51–54]. To the best of our knowledge,
markedly increased hemolysis upon conjugation of CPP to drugs has never been reported before,
which highlights the relevance of assessing hemolytic activity of any newly developed CPP-cargo
conjugate. The heteroaromatic structure of the antimalarial drugs used is apparently relevant for the
observed hemolytic effects, as these were not described for previously reported fosmidomycin-CPP
conjugates displaying antimalarial activity [16]. Ongoing biophysical studies will hopefully clarify
the molecular mechanisms that are responsible for the observations herein reported, towards future
strategies that may overcome this hurdle.
Supplementary Materials: The following are available online at http://www.mdpi.com/1420-3049/24/24/4559/s1,
Figures S1 to S55: ESI-IT MS spectra and chromatograms obtained for the synthesized compounds.
Author Contributions: Conceptualization, X.F.-B. and P.G.; Data curation, L.A., A.B., E.L. and J.G.; Formal
analysis, L.A., A.B., E.L., P.J.R., F.N. and X.F.-B.; Funding acquisition, X.F.-B. and P.G.; Investigation, L.A., F.N.,
X.F.-B. and P.G.; Methodology, L.A., A.B., E.L., J.G., N.V., P.J.R., F.N., D.A. and X.F.-B.; Project administration, P.G.;
Resources, P.J.R., F.N., D.A., X.F.-B. and P.G.; Supervision, N.V., P.J.R., F.N., D.A., X.F.-B. and P.G.; Writing—original
draft, L.A.; Writing—review & editing, L.A., A.B., E.L., N.V., P.J.R., F.N., D.A., X.F.-B. and P.G.
Funding: This research was funded by Fundação para a Ciência e Tecnologia (FCT), Portugal, grants
UID/QUI/50006/2019, IF/00092/2014/CP1255/CT0004, and PD/BD/106035/2015 and Ministerio de Ciencia, Innovación
y Universidades, Spain, grant RTI2018-094579-B-I00 (which included FEDER funds).
Acknowledgments: The authors thank Fundação para a Ciência e Tecnologia (FCT, Portugal) for funding through
grants UID/QUI/50006/2019 (LAQV-REQUIMTE), NV thanks FCT and FEDER (European Union) for funding
project IF/00092/2014/CP1255/CT0004 and IF position. LA thanks FCT and the Medicinal Biochemistry and
Biochemistry International Doctoral Programme (M2B-PhD) for PhD grant PD/BD/106035/2015. ISGlobal and
IBEC are members of the CERCA Programme, Generalitat de Catalunya. This research is part of ISGlobal’s
Program on the Molecular Mechanisms of Malaria, which is partially supported by the Fundación Ramón Areces.

Molecules 2019, 24, 4559
19 of 21
Conflicts of Interest: The authors declare no conflict of interest.
References
1.
Prud
stage. Nat. Rev. Genet. 2006, 4, 849–856. [CrossRef] [PubMed]
Gomes, A.; Machado, M.; Lobo, L.; Nogueira, F.; Prud ncio, M.; Teixeira, C.; Gomes, P. N-Cinnamoylation of
êncio, M.; Rodríguez, A.; Mota, M.M. The silent path to thousands of merozoites: The Plasmodium liver
2.
ê
antimalarial classics: Effects of using acyl groups other than cinnamoyl toward dual-stage antimalarials.
ChemMedChem 2015, 10, 1344–1349. [CrossRef] [PubMed]
3.
4.
5.
6.
7.
8.
9.
Araújo, M.J.; Bom, J.; Capela, R.; Casimiro, C.; Chambel, P.; Gomes, P.; Iley, J.; Lopes, F.; Morais, J.;
Moreira, R.; et al. Imidazolidin-4-one derivatives of primaquine as novel transmission-blocking antimalarials.
J. Med. Chem. 2005, 48, 888–892. [CrossRef] [PubMed]
Vale, N.; Prud
Cushion, M.T.; do Ros
J. Med. Chem. 2009, 52, 7800–7807. [CrossRef] [PubMed]
Matos, J.; Da Cruz, F.P.; Cabrita, .; Gut, J.; Nogueira, F.; Do Ros
Prud ncio, M.; Gomes, P. Novel potent metallocenes against liver stage malaria. Antimicrob. Agents Chemother.
2012, 56, 1564–1570. [CrossRef]
Perez, B.; Teixeira, C.; Albuquerque, I.S.; Gut, J.; Rosenthal, P.J.; Prud
ê
ncio, M.; Marques, C.A.; Collins, M.S.; Gut, J.; Nogueira, F.; Matos, J.; Rosenthal, P.J.;
ário, E.V.; et al. Imidazoquines as antimalarial and anti-pneumocystis agents.
É
ário, V.E.; Moreira, R.; Rosenthal, P.J.;
ê
ê
ncio, M.; Gomes, P. PRIMACINS,
N-Cinnamoyl-Primaquine conjugates, with improved liver-stage antimalarial activity. MedChemComm 2012
3, 1170–1172. [CrossRef]
,
Pérez, B.C.; Teixeira, C.; Albuquerque, I.S.; Gut, J.; Rosenthal, P.J.; Gomes, J.R.B.; Prudêncio, M.; Gomes, P.
N-Cinnamoylated chloroquine analogues as dual-stage antimalarial leads. J. Med. Chem. 2013, 56, 556–567.
[CrossRef]
Gomes, A.; Perez, B.; Albuquerque, I.S.; Machado, M.; Prudêncio, M.; Nogueira, F.; Teixeira, C.; Gomes, P.
N-Cinnamoylation of antimalarial classics: Quinacrine analogues with decreased toxicity and dual-stage
activity. ChemMedChem 2013, 9, 305–310. [CrossRef]
Ferraz, R.; Noronha, J.; Ferreira, F.I.H.M.; Nogueira, F.; Machado, M.; Prudêncio, M.; Parapini, S.;
D’Alessandro, S.; Teixeira, C.; Gomes, A.; et al. Primaquine-based ionic liquids as a novel class of
antimalarial hits. RSC Adv. 2016, 6, 56134–56138. [CrossRef]
10. Moles, E.; Galiano, S.; Gomes, A.; Quiliano, M.; Teixeira, C.; Aldana, I.; Gomes, P.; Fernàndez-Busquets, X.
ImmunoPEGliposomes for the targeted delivery of novel lipophilic drugs to red blood cells in a falciparum
malaria murine model. Biomaterials 2017, 145, 178–191. [CrossRef]
11. Bechara, C.; Sagan, S. Cell-Penetrating peptides: 20 years later, where do we stand? FEBS Lett. 2013
587, 1693–1702. [CrossRef] [PubMed]
,
12. Svensen, N.; Walton, J.G.; Bradley, M. Peptides for cell-selective drug delivery. Trends Pharmacol. Sci. 2012
33, 186–192. [CrossRef] [PubMed]
,
13. Dissanayake, S.A.; Denny, W.; Gamage, S.; Sarojini, V. Recent developments in anticancer drug delivery
using cell penetrating and tumor targeting peptides. J. Control. Release 2017, 250, 62–76. [CrossRef] [PubMed]
14. Wang, Y.; Cheetham, A.G.; Angacian, G.; Su, H.; Xie, L.; Cui, H. Peptide–drug conjugates as effective prodrug
strategies for targeted delivery. Adv. Drug Deliv. Rev. 2017, 112–126. [CrossRef] [PubMed]
15. Bolhassani, A. Potential efficacy of cell-penetrating peptides for nucleic acid and drug delivery in cancer.
Biochim. Biophys. Acta (BBA)-Rev. Cancer 2011, 1816, 232–246. [CrossRef]
16. Sparr, C.; Purkayastha, N.; Kolesinska, B.; Gengenbacher, M.; Amulic, B.; Matuschewski, K.; Seebach, D.;
Kamena, F. Improved efficacy of fosmidomycin against Plasmodium and Mycobacterium species by combination
with the cell-penetrating peptide octaarginine. Antimicrob. Agents Chemother. 2013, 57, 4689–4698. [CrossRef]
17. Arrighi, R.B.G.; Ebikeme, C.; Jiang, Y.; Ranford-Cartwright, L.; Barrett, M.P.; Langel, Ü.; Faye, I.
Cell-penetrating peptide TP10 shows broad-spectrum activity against both Plasmodium falciparum and
Trypanosoma brucei brucei. Antimicrob. Agents Chemother. 2008, 52, 3414–3417. [CrossRef]
18. Guergnon, J.; Dessauge, F.; Dominguez, V.; Viallet, J.; Bonnefoy, S.; Yuste, V.J.; Mercereau-Puijalon, O.;
Cayla, X.; Rebollo, A.; Susin, S.A.; et al. Use of penetrating peptides interacting with PP1/PP2A proteins as a
general approach for a drug phosphatase technology. Mol. Pharmacol. 2006, 69, 1115–1124. [CrossRef]

Molecules 2019, 24, 4559
20 of 21
19. Mansour, S.C.; De La Fuente-N
úñez, C.; Hancock, R.E.W. Peptide IDR-1018: Modulating the immune system
and targeting bacterial biofilms to treat antibiotic-resistant bacterial infections. J. Pept. Sci. 2015, 21, 323–329.
[CrossRef]
20. Aguiar, L.; Machado, M.; Sanches-Vaz, M.; Prudêncio, M.; Vale, N.; Gomes, P. Coupling the cell-penetrating
peptides transportan and transportan 10 to primaquine enhances its activity against liver-stage malaria
parasites. MedChemComm 2019, 10, 221–226. [CrossRef]
21. Wellems, T.E.; Plowe, C.V. Chloroquine-Resistant malaria. J. Infect. Dis. 2001, 184, 770–776. [CrossRef]
[PubMed]
22. Pradines, B.; Barbe, J.; Fusai, T.; Papa, V.; Houdoin, C.; Mosnier, J.; Rogier, C.; Santelli-Rouvier, C.;
Alibert-Franco, S.; Parzy, D. In vitro reversal of chloroquine resistance in Plasmodium falciparum with
dihydroethanoanthracene derivatives. Am. J. Trop. Med. Hyg. 2002, 66, 661–666. [CrossRef] [PubMed]
23. Kumai, J.; Hozumi, K.; Yamada, Y.; Katagiri, F.; Kikkawa, Y.; Nomizu, M. Effect of spacer length and type on
the biological activity of peptide-polysaccharide matrices. Pept. Sci. 2016, 106, 512–520. [CrossRef] [PubMed]
24. Mbatha, L.; Chakravorty, S.; Koning, C.; Otterlo, W.; Arbuthnot, P.; Ariatti, M.; Singh, M. Spacer Length:
A Determining Factor in the Design of Galactosyl Ligands for Hepatoma Cell-Specific Liposomal Gene
Delivery. Curr. Drug Deliv. 2016, 13, 935–945. [CrossRef] [PubMed]
25. Yadav, N.; Agarwal, D.; Kumar, S.; Dixit, A.; Gupta, R.D.; Awasthi, S.K. In vitro antiplasmodial efficacy of
synthetic coumarin-triazole analogs. Eur. J. Med. Chem. 2018, 145, 735–745. [CrossRef]
26. Boechat, N.; Ferreira, M.D.L.G.; Pinheiro, L.C.S.; Jesus, A.M.L.; Leite, M.M.M.; Júnior, C.C.S.; Aguiar, A.C.C.;
Andrade, I.M.; Krettli, A.U.; De Andrade, I.M. New compounds hybrids 1H-1,2,3-triazole-quinoline against
Plasmodium falciparum. Chem. Boil. Drug Des. 2014, 84, 325–332. [CrossRef]
27. Singh, P.; Sachdeva, S.; Raj, R.; Kumar, V.; Mahajan, M.P.; Nasser, S.; Vivas, L.; Gut, J.; Rosenthal, P.J.;
Feng, T.-S.; et al. Antiplasmodial and cytotoxicity evaluation of 3-functionalized 2-azetidinone derivatives.
Bioorganic Med. Chem. Lett. 2011, 21, 4561–4563. [CrossRef]
28. Bakunov, S.A.; Bakunova, S.M.; Wenzler, T.; Ghebru, M.; Werbovetz, K.A.; Brun, R.; Tidwell, R.R. Synthesis
and Antiprotozoal activity of cationic 1,4-diphenyl-1H-1,2,3-triazoles. J. Med. Chem. 2010, 53, 254–272.
[CrossRef]
29. Rathod, P.K.; McErlean, T.; Lee, P.-C. Variations in frequencies of drug resistance in Plasmodium falciparum.
Proc. Natl. Acad. Sci. USA 1997, 94, 9389–9393. [CrossRef]
30. Ecker, A.; Lehane, A.M.; Clain, J.; Fidock, D.A. PfCRT and its role in antimalarial drug resistance.
Trends Parasitol. 2012, 28, 504–514. [CrossRef]
31. Chinappi, M.; Via, A.; Marcatili, P.; Tramontano, A. On the mechanism of chloroquine resistance in Plasmodium
falciparum. PLoS ONE 2010, 5, e14064. [CrossRef] [PubMed]
32. Ursos, L.M.; Roepe, P.D. Chloroquine resistance in the malarial parasite, Plasmodium falciparum. Med. Res.
Rev. 2002, 22, 465–491. [CrossRef] [PubMed]
33. Pulcini, S.; Staines, H.M.; Lee, A.H.; Shafik, S.H.; Bouyer, G.; Moore, C.M.; Daley, D.A.; Hoke, M.J.;
Altenhofen, L.M.; Painter, H.J.; et al. Mutations in the Plasmodium falciparum chloroquine resistance
transporter, PfCRT, enlarge the parasite’s food vacuole and alter drug sensitivities. Sci. Rep. 2015, 5, 14552.
[CrossRef] [PubMed]
34. Boudhar, A.; Ng, X.W.; Loh, C.Y.; Ni Chia, W.; Tan, Z.M.; Nosten, F.; Dymock, B.W.; Tan, K.S.W. Overcoming
chloroquine resistance in malaria: Design, synthesis, and structure-activity relationships of novel hybrid
compounds. Antimicrob. Agents Chemother. 2016, 60, 3076–3089. [CrossRef] [PubMed]
35. Medina, S.H.; Miller, S.E.; Keim, A.I.; Gorka, A.P.; Schnermann, M.J.; Schneider, J.P. An intrinsically disordered
peptide facilitates non-endosomal cell entry. Angew. Chem. Int. Ed. 2016, 55, 3369–3372. [CrossRef] [PubMed]
36. Eriksson, O.S.; Geörg, M.; Sjölinder, H.; Sillard, R.; Lindberg, S.; Langel, Ü.; Jonsson, A.-B. Identification of
cell-penetrating peptides that are bactericidal to Neisseria meningitidis and prevent inflammatory responses
upon infection. Antimicrob. Agents Chemother. 2013, 57, 3704–3712. [CrossRef] [PubMed]
37. Franklin, R.M.; Brun, R.; Grieder, A. Microscopic and flow cytophotometric analysis of parasitemia in cultures
of Plasmodium falciparum vitally stained with Hoechst 33342—application to studies of antimalarial agents.
Zeitschrift für Parasitenkunde 1986, 72, 201–212. [CrossRef]
38. Oller-Salvia, B.; S
Cecchelli, R.; Garc
Angew. Chemie Int. Ed. 2016, 55, 572–575. [CrossRef]
ánchez-Navarro, M.; Ciudad, S.; Guiu, M.; Arranz-Gibert, P.; Garcia, C.; Gomis, R.R.;
ía, J.; Giralt, E.; et al. MiniAp-4: A venom-inspired peptidomimetic for brain delivery.

Molecules 2019, 24, 4559
21 of 21
39. Hale, V.L.; Watermeyer, J.M.; Hackett, F.; Vizcay-Barrena, G.; Van Ooij, C.; Thomas, J.A.; Spink, M.C.;
Harkiolaki, M.; Duke, E.; Fleck, R.A.; et al. Parasitophorous vacuole poration precedes its rupture and rapid
host erythrocyte cytoskeleton collapse in Plasmodium falciparum egress. Proc. Natl. Acad. Sci. USA 2017
114, 3439–3444. [CrossRef]
,
40. Lux, S.E. Anatomy of the red cell membrane skeleton: Unanswered questions. Blood 2016, 127, 187–199.
[CrossRef]
41. Gao, X.; Yue, T.; Tian, F.; Liu, Z.; Zhang, X. Erythrocyte membrane skeleton inhibits nanoparticle endocytosis.
AIP Adv. 2017, 7, 065303. [CrossRef]
42. Minetti, G.; Achilli, C.; Perotti, C.; Ciana, A. continuous change in membrane and membrane-skeleton
organization during development from proerythroblast to senescent red blood cell. Front. Physiol. 2018, 9.
[CrossRef] [PubMed]
43.
Y
á
ñez-M
ó
, M.; Alfranca, A.; Cabanas, C.; Marazuela, M.; Tejedor, R.; Ursa, M.A.; Ashman, L.K.;
De Land
á
zuri, M.O.; S nchez-Madrid, F. Regulation of endothelial cell motility by complexes of tetraspan
á
molecules CD81/TAPA-1 and CD151/PETA-3 with alpha 3beta 1 integrin localized at endothelial lateral
junctions. J. Cell Boil. 1998, 141, 791–804. [CrossRef] [PubMed]
44. Zuccala, E.; Baum, J. Cytoskeletal and membrane remodelling during malaria parasite invasion of the human
erythrocyte. Br. J. Haematol. 2011, 154, 680–689. [CrossRef]
45. Callan-Jones, A.; Arriagada, O.E.A.; Massiera, G.; Lorman, V.; Abkarian, M. Red blood cell membrane
dynamics during malaria parasite egress. Biophys. J. 2012, 103, 2475–2483. [CrossRef]
46. Nogueira, F.; Diez, A.; Radfar, A.; Pérez-Benavente, S.; Rosario, V.E.D.; Puyet, A.; Bautista, J.M.
Early transcriptional response to chloroquine of the Plasmodium falciparum antioxidant defence in sensitive
and resistant clones. Acta Trop. 2010, 114, 109–115. [CrossRef]
47. Palasek, S.A.; Cox, Z.J.; Collins, J.M. Limiting racemization and aspartimide formation in microwave-enhanced
Fmoc solid phase peptide synthesis. J. Pept. Sci. 2007, 13, 143–148. [CrossRef]
48. Turner, R.A.; Oliver, A.G.; Lokey, R.S. Click chemistry as a macrocyclization tool in the solid-phase synthesis
of small cyclic peptides. Org. Lett. 2007, 9, 5011–5014. [CrossRef]
49. Jain, N.; Friedman, S.H. A tetra-orthogonal strategy for the efficient synthesis of scaffolds based on cyclic
peptides. Int. J. Pept. Res. Ther. 2018, 24, 535–542. [CrossRef]
50. Li, D.; Elbert, D.L. The kinetics of the removal of the N-methyltrityl (Mtt) group during the synthesis of
branched peptides. J. Pept. Res. 2002, 60, 300–303. [CrossRef]
51. Derakhshankhah, H.; Jafari, S. Cell penetrating peptides: A concise review with emphasis on biomedical
applications. Biomed. Pharmacother. 2018, 108, 1090–1096. [CrossRef]
52. Guidotti, G.; Brambilla, L.; Rossi, D. Cell-penetrating peptides: From basic research to clinics.
Trends Pharmacol. Sci. 2017, 38, 406–424. [CrossRef]
53. Böhmová, E.; Machová, D.; Pechar, M.; Pola, R.; Venclíková, K.; Janoušková, O.; Etrych, T. Cell-Penetrating
peptides: A useful tool for the delivery of various cargoes into cells. Physiol. Res. 2018, 67, S267–S279.
[CrossRef] [PubMed]
54. Zhu, P.; Lin, L. Cell penetrating peptides: A promising tool for the cellular uptake of macromolecular drugs.
Protein Pept. Sci. 2018, 19, 211–220. [CrossRef] [PubMed]
Sample Availability: Freshly synthesized samples of all compounds can be made available from the authors.
©
2019 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access
article distributed under the terms and conditions of the Creative Commons Attribution
(CC BY) license (http://creativecommons.org/licenses/by/4.0/).
