A purified MAA-based ELISA is a useful tool for determining anti-MAA antibody titer with high sensitivity

Article abstract of DOI:10.1371/journal.pone.0172172

Atherosclerosis is widely accepted to be a chronic inflammatory disease, and the immunological response to the accumulation of LDL is believed to play a critical role in the development of this disease. 1,4-Dihydropyridine-type MAA-adducted LDL has been implicated in atherosclerosis. Here, we have demonstrated that pure MAA-modified residues can be chemically conjugated to large proteins without by-product contamination. Using this pure antigen, we established a purified MAA-ELISA, with which a marked increase in anti-MAA antibody titer was determined at a very early stage of atherosclerosis in 3-month ApoE-/-mice fed with a normal diet. Our methods of N? -MAA-L-lysine purification and purified antigen-based ELISA will be easily applicable for biomarker-based detection of early stage atherosclerosis in patients, as well as for the development of an adduct-specific Liquid Chromatography/Mass Spectrometry-based quantification of physiological and pathological levels of MAA.

Full text of DOI:10.1371/journal.pone.0172172

RESEARCH ARTICLE
A purified MAA-based ELISA is a useful tool for
determining anti-MAA antibody titer with high
sensitivity
Takasumi Shimomoto1, Leonard B. Collins1, Xianwen Yi2, Darcy W. Holley3,
Zhenfa Zhang1, Xu Tian1, Koji Uchida4, Chunguang Wang5,6, Sohvi Horkko5,6, Monte
¨
¨
S. Willis7,8, Avram Gold1, Scott J. Bultman3, Jun Nakamura1*
1 Department of Environmental Sciences and Engineering, University of North Carolina, Chapel Hill, North
Carolina, United States of America, 2 Lineberger Comprehensive Cancer Center, University of North
Carolina, Chapel Hill, North Carolina, United States of America, 3 Department of Genetics, University of
North Carolina, Chapel Hill, North Carolina, United States of America, 4 School of Bioagricultural Sciences,
Nagoya University, Nagoya, Japan, 5 Medical Microbiology and Immunology, Research Unit of Biomedicine,
Faculty of Medicine, University of Oulu, Oulu, Finland, 6 Medical Research Center and Nordlab Oulu,
University Hospital and University of Oulu, Oulu, Finland, 7 Department of Pathology & Laboratory Medicine,
University of North Carolina, Chapel Hill, North Carolina, United States of America, 8 McAllister Heart
Institute, University of North Carolina, Chapel Hill, North Carolina, United States of America
a1111111111
a1111111111
a1111111111
a1111111111
a1111111111
* junnakamura77777@gmail.com
OPEN ACCESS
Abstract
Citation: Shimomoto T, Collins LB, Yi X, Holley
DW, Zhang Z, Tian X, et al. (2017) A purified MAA-
based ELISA is a useful tool for determining anti-
MAA antibody titer with high sensitivity. PLoS ONE
12(2): e0172172. doi:10.1371/journal.
pone.0172172
Atherosclerosis is widely accepted to be a chronic inflammatory disease, and the immuno-
logical response to the accumulation of LDL is believed to play a critical role in the develop-
ment of this disease. 1,4-Dihydropyridine-type MAA-adducted LDL has been implicated in
atherosclerosis. Here, we have demonstrated that pure MAA-modified residues can be
chemically conjugated to large proteins without by-product contamination. Using this pure
antigen, we established a purified MAA-ELISA, with which a marked increase in anti-MAA
antibody titer was determined at a very early stage of atherosclerosis in 3-month ApoE-/-
mice fed with a normal diet. Our methods of Nε-MAA-L-lysine purification and purified anti-
gen-based ELISA will be easily applicable for biomarker-based detection of early stage
atherosclerosis in patients, as well as for the development of an adduct-specific Liquid Chro-
matography/Mass Spectrometry-based quantification of physiological and pathological lev-
els of MAA.
Editor: Christoph E Hagemeyer, Monash
University, AUSTRALIA
Received: October 20, 2016
Accepted: January 31, 2017
Published: February 21, 2017
Copyright: © 2017 Shimomoto et al. This is an
open access article distributed under the terms of
the Creative Commons Attribution License, which
permits unrestricted use, distribution, and
reproduction in any medium, provided the original
author and source are credited.
Data Availability Statement: All relevant data are
within the paper and its Supporting Information
files.
Introduction
Funding: This work was supported by NIH grants
P42-ES05948 and P30-ES10126. The funders had
no role in study design, data collection and
analysis, decision to publish, or preparation of the
manuscript.
Lipid peroxidation produces a wide variety of reactive aldehydes, which can form covalent
adducts with proteins [1]. These protein adducts can initiate pro-inflammatory responses, and
the resulting inflammation caused by these aldehyde-derived protein adducts has been impli-
cated in chronic inflammatory diseases, such as atherosclerosis [2]. During the development of
atherosclerosis, protein adducts can be generated by MDA and its degradation product acetal-
dehyde, which are lipid peroxidation products reactive towards lysine residues on proteins
Competing interests: The authors have declared
that no competing interests exist.
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
1 / 14

Pure MAA antigen-based ELISA
Fig 1. Structure of the MAA-lysine adduct and pMAA and crMAA epitopes. (A) 1,4-dihydropyridine-type
MAA-lysine adducts are formed by a reaction between acetaldehyde and two equivalents of MDA with a
primary amine, usually at the ε-position amino moiety of a lysine residue on the target protein. (B) BSA
chemically conjugated to purified MAA-6ACA (MAA-lysine analog) was used in the present study and
compared to BSA attached to crMAA epitopes, which were utilized in many previous reports.
doi:10.1371/journal.pone.0172172.g001
(Fig 1A) [3]. Specifically, 1,4-dihydropyridine-type MAA-modified LDL, which is a form of
oxidized LDL (oxLDL), has been implicated in atherogenesis [3–5]. MAA-lysine adducts have
been reported to be highly stable [6, 7], toxic [8], pro-inflammatory [9], and profibrogenic [10,
11]. Repeated immunization with MAA-modified protein induces robust antibody production
even in the absence of adjuvant [12]. Thus, MAA-lysine adducts have been proposed to be one
of the most potent atherogenic protein adducts caused by lipid peroxidation [3, 4]. As such,
MAA adducts appear to play a critical role in atherogenesis [3].
Studies have found that serum antibodies against MAA-modified proteins are associated
with active and chronic stages of atherosclerosis in humans [13] and that there are detectable
levels of anti-MAA antibody even during the development and progression of atherosclerosis
[13–15]. These studies have detected the anti-MAA antibody using ELISA plates coated with
antigens that are reported to be predominantly a 4-methyl-1,4-dihydropyridine-3,5-dicarbal-
dehyde derivative of an amino group of protein carriers [16]. However, given the number of
lysines found throughout the carriers used in the studies, this cyclic fluorescent adduct was
likely not the only product present. For example, a 1:1:1 adduct without fluorescent properties
has been reported to be present within the antigen mixture [17]. The heterogeneity of the
MAA epitopes, in addition to the other adducts generated by the reaction of MDA and acetal-
dehyde, likely affect the specificity and sensitivity of these anti-MAA assays. Therefore a
method of generating homogeneous MAA-adducted proteins to assay for MAA adducts is
important for early diagnosis of atherosclerosis.
Published MAA adduct preparations involve reaction of acetaldehyde and two equivalents
of MDA with a primary amine, usually the ε-amino group of a lysine residue on the target pro-
tein [18]. During this reaction, many stable (e.g. 2:1:1 product) and unstable adducts (e.g.
MDA-lysine) are generated (Fig 1B) [7, 18, 19]. However for early and accurate detection and
diagnosis of atherosclerosis, improved sensitivity and specificity of diagnostic biomarker
assays is imperative. Thus, in the present study, we synthesized pMAA-lysine and pMAA-
6ACA, an MAA-lysine analog. The purified MAA adducts were conjugated through the car-
boxylic acid moiety to the amino groups of BSA or KLH by the EDC crosslinking reaction (Fig
1B and S1A Fig). Using the purified antigens, we tested the immunogenicity of pMAA mole-
cules and analyzed the serum titer of the anti-MAA-lysine antibody in the atherosclerotic
ApoE-/- mice, for the first time in the absence of confounding factors such as contaminating
epitope by-products of the reaction with MDA and acetaldehyde. The pMAA antigen-based
ELISA, using BSA chemically conjugated to purified MAA adducts, has not only proven to be
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
2 / 14

Pure MAA antigen-based ELISA
more sensitive and specific than the crude MAA antigen-based ELISA that is currently in use
but has also been able to detect markedly increased anti-MAA antibody titers in the serum of
ApoE-/- mice at a very early stage of atherosclerosis.
Materials and methods
Materials
Boc-lysine, 6-ACA, acetaldehyde, BSA, KLH, TFA, TMB, and H2O2 were purchased from
Sigma-Aldrich (St. Louis, MO). Malondialdehyde bis(dimethyl acetal), the Imject EDC
mcKLH Spin Kit, goat anti-rabbit IgG (H+L) antibody with HRP, and goat anti-mouse IgM
secondary antibody were obtained from Thermo Scientific (Rockford, IL). EnVision+Single
Reagents anti-mouse-HRP and rabbit anti-human IgG F(ab’)2 fragment antibody with HRP
were purchased from Dako North America, Inc. (Carpentaria, CA) and Jackson Immuno
Research Laboratories (West Grove, PA), respectively.
Synthesis of Nε-(MAA)-L-lysine (MAA-lysine) adducts. MDA was generated as previ-
ously reported [20]. Briefly, 704 μL of malondialdehyde bis(dimethyl acetal) was hydrolyzed
with 96 μL of 4M HCl in the presence of 3.2 mL of water at 37˚C for 10 min. The reaction was
stopped by adjusting the pH to 7.4 with NaOH. The total volume was brought to 8 mL with
water to prepare 500 mM MDA. MAA-lysine was synthesized as previously described for the
MAA-BSA preparation [21] with some modifications (S1B Fig). 4 mM of Boc-lysine, 4 mM of
acetaldehyde, and 8 mM of MDA were dissolved in water or PBS. The reaction mixture was
incubated at 37˚C for 3 days. During this time, a yellowish color developed. MAA-Boc-lysine
was purified by HPLC using an Agilent 1200 HPLC system (Agilent, Santa Clara, CA) with a
Poroshell 120 EC-C18 column (Agilent, 4.6 x 50 mm, 2.7 um) and isocratic elution by 0.1%
formic acid and 25% acetonitrile in water at a flow rate of 1 mL/min and UV detection at 264
nm. Fractions (3 mL) were collected by an autosampler, with both the tray and fraction collec-
tor chambers maintained at 4˚C. The retention time of the fraction containing MAA-Boc-
lysine was determined, and a 3.8 to 4.2 min fraction of the mobile phase eluate containing
MAA-Boc-lysine was collected automatically. The collected fractions were evaporated and fur-
ther incubated with 150 μL of 100% TFA overnight to remove the Boc protecting group. Fol-
lowing evaporation, the fractions were dissolved in HPLC-grade water for subsequent HPLC
purification. MAA-lysine was purified by the HPLC system described above using a gradient
elution program as follows: eluant A, 0.1% formic acid in water; eluant B, acetonitrile, starting
at 2% B increasing linearly to 30% B over 2 min and held at 30% B for an additional 3 min
before re-equilibration at 2% B for 4 min. The retention time of MAA-lysine was determined,
and a 3.8 to 4 min fraction containing MAA-lysine was collected by autosampler. The fractions
were evaporated and used for LC-MS and NMR characterization, and BSA/KLH-conjugation.
Synthesis of MAA-6ACA adducts
MAA-6ACA was synthesized as described for the MAA-lysine preparation with some modifi-
cations (S1C Fig). 4 mmoles of 6-ACA, 4 mmoles of acetaldehyde, and 8 mmoles of MDA
were dissolved in water or PBS. The reaction mixture was incubated at 37˚C for 3 days. MAA-
6ACA was purified by HPLC as described above using a gradient elution program as follows:
0.1% formic acid in water (A) and acetonitrile (B) at 2% B linearly increasing to 5% B over 2
min, then increased linearly to 25% B over 0.5 min, held at 25% for an additional 3.5 min, line-
arly decreased to 2% B over 0.5 min and maintained at 2% B for 3.5 min. The retention time of
MAA-6ACA was determined, and a 6.4 to 7.1 min fraction of the eluate containing MAA-
6ACA was collected by autosampler. The fractions were evaporated and used for LC-MS,
NMR characterization, and BSA/KLH-conjugation.
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
3 / 14

Pure MAA antigen-based ELISA
LC-MS analysis
MAA-Boc-lysine, MAA-lysine, and MAA-6ACA were characterized with an Agilent Technol-
ogies liquid chromatograph-mass spectrometer system consisting of a series 1200 HPLC and
6520 Accurate Mass Q-TOF mass spectrometer (Santa Clara, CA). Products were injected on a
Waters Acquity UPLC CSH Fluoro-phenyl column, 2.1 mm x 100 mm, 1.7 μm particle size.
Mobile phase was delivered isocratically at 0.2 mL/min using 70% water containing 0.1% for-
mic acid and 30% acetonitrile. Solvent flow was diverted to waste for the first 1.2 min of the
analysis. Mass spectrometer parameters were set to the following values: positive ionization
mode, capillary voltage of 3500 V, nebulizing gas pressure of 40 psi, drying gas temperature of
300˚C, drying gas flow of 12 L/min, and fragmentor voltage of 150 V. Scans from m/z 100 to
m/z 1700 were acquired at a rate of 1 scan/s in the high-resolution, low-mass instrument
mode. Reference masses used for real-time mass axis adjustment were purine, m/z 121.050873
and HP-0921, m/z 922.009798.
NMR spectrometry
1H NMR spectra were recorded on a Varian INOVA 400 spectrometer at 400 MHz in ACN-d3
or DMSO-d6, as specified. Chemical shifts are reported in ppm relative to TMS.
NMR spectrometry for MAA-Boc-lysine. UV (ddH2O): λmax = 260 nm. ESI-MS: m/z
calc for C19H29N2O6: 381.2025, obs, 381.2019 MH+, m/z 325.1397 [MH—Boc] +. 1H NMR
(400 MHz, DMSO-d6): 9.23 (singlet, 2H, CHO), 7.33 (singlet, 2H, dihydropyridine-H2,H6),
6.82 (doublet, 1H, J = 7.5 Hz, amide), 3.84–3.76 (multiplet, 1H, Hα), 3.61 (quartet, 2H, J = 6.5
Hz, dihydropyridine-H4), 3.52 (triplet, 2H, J = 6.9 Hz, CεH2), 1.76–1.52 (multiplet, 4H, Cβ,
δH2), 1.35–1.26 (m, 2H, CγH2), 1.35 (singlet, 9H, Boc-CH3), 0.92 (doublet, 3H, J = 6.5 Hz,
CH3) ppm.
NMR spectrometry for MAA-lysine. C14H20N2O4:UV (ddH2O): λmax = 260 nm. ESI-MS:
m/z calc for C14H21N2O4: 281.1501, obs 281.1498 MH+. 1H NMR (400 MHz, DMSO-d6): 9.26
(singlet, 2H, CHO), 7.32 (singlet, 2H, dihydropyridine-H2,H6), 3.62 (quartet, 1H, dihydropyri-
dine-H4), 3.50 (triplet, J = 6.9 Hz, 2H, CεH2), 3.17–3.11 (m, 1H, Hα), 1.51–1.83 (m, 4H, Cβ,
δH2), 1.13–1.37 (m, 2H, CγH2), 0.92 (doublet, J = 6.5 Hz, 3H, CH3) ppm.
NMR spectrometry for MAA-6ACA. C14H19NO4:UV (ddH2O): λmax = 260 nm. ESI-MS:
m/z 266.1391 MH+. 1H NMR (400 MHz, DMSO-d6): δ 9.22 (singlet, 2H, CHO), 7.34 (singlet,
2H, dihydropyridine-H2,H6), 3.61 (quartet, J = 6.5 Hz, 1H, dihydropyridine-H4), 3.53 (triplet,
2H, J = 7.2 Hz, C6H2), 2.22 (triplet, 2H, J = 7.2 Hz, C2H2COOH),1.64 (quintet, 2H), J = 7.3 Hz,
1.54 (quintet, 2H J = 7.5 Hz,), 1.25–1.33 (m, 2H) (C3H2, C4H2, C5H2), 0.92 (doublet, 3H,
J = 6.5 Hz, CH3) ppm.
Fluorescence measurements
Fluorescent properties of MAA-6ACA were characterized using a CLARIOstar microplate
reader (BMG LABTECH) equipped with a scanning mode of continuous adjustable wave-
lengths (320–850 nm). Fluorescence measurements were also performed for MAA-lysine and
MAA-6ACA and their BSA/KLH conjugate complexes using a FLX800 microplate fluores-
cence reader (Bio-Tek) equipped with excitation (360/40, 400/10, and 485/20) and emission
filters (460/40, and 528/20).
Preparation of antigens (S1A Fig)
50 nmol of MAA-lysine or MAA-6ACA were coupled to either 2 mg of BSA or KLH using the
Imject EDC mcKLH Spin Kit, according to the manufacturer’s directions. EDC-mediated
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
4 / 14

Pure MAA antigen-based ELISA
amide formation was used for conjugation between MAA epitopes containing a carboxyl moi-
ety and either BSA or KLH. The antigens were purified by spin column and sterile filtered
(0.2 μm, Fisher Scientific). Pure antigens were referred to as pMAA-lysine-BSA, pMAA-
6ACA-BSA, and pMAA-6ACA-KLH. In order to compare pMAA-lysine-proteins and the
crude antigens utilized previously, a reaction with BSA, MDA, and acetaldehyde was per-
formed. BSA (20 mg/7ml in PBS) was incubated with 4 mM acetaldehyde and 8 mM MDA at
37˚C for 24 hours. The reaction product was extensively dialyzed for 72 hours in PBS. This
crude immunogen was referred to as crMAA-BSA.
Animal treatment, blood collection, and serum preparation
All mouse experiments were performed using protocols approved by the Institutional Animal
Care and Use Committees of UNC and in accordance with federal guidelines. ApoE-/- mice on
a C57BL/6 background and their wild-type controls were obtained from The Jackson Labora-
tory. For addressing the immunogenicity of MAA-lysine, 8-month aged C57BL/6 female mice
(3 mice per group) were used. The mice were treated intraperitoneally with BSA or pMAA-
lysine-BSA (51 fluorescence units [measured by FLX800 with filter of Ex360/Em460] per
103 μg BSA in 200 μL PBS) once a week for 6 weeks without adjuvant. Seven days after the
final injection, mice were euthanized by CO2 euthanasia. Blood was collected from the abdom-
inal vein for serum sample collection. Serum samples were stored at -70˚C until use. A four-
fold serial dilution of each serum sample was prepared using a 5-fold diluted supernatant of
5% Casein PBS suspension. For studying the association between an increase in MAA anti-
body titer and atherosclerosis, 3-month old C57BL/6 and ApoE-/- male mice (4 mice per geno-
type) were utilized for quantitating levels of antibody against MAA. Blood samples were
collected from either the maxillary vein or abdominal vein, followed by serum separation.
Serum samples were stored at -70˚C until use. Each sample was then diluted 320 fold with 1%
BSA in PBS for analysis with ELISA.
ELISA
ELISA-based analysis characterizing pMAA-6ACA-BSA using previously-reported
anti-MAA antibodies. An indirect ELISA was performed to compare the reactivity of four
different previously-reported anti-MAA antibodies [15, 22, 23] against pMAA-6ACA-BSA.
96-well plates (Corning Incorporated, Kennebunk, ME) were coated with pMAA-6ACA-BSA
(50 μL/well) at 4˚C overnight. After washing, followed by blocking with 3% BSA in PBS, 50 μL
of the anti-MAA antibodies were incubated at different concentrations at 4˚C overnight. A
two-fold serial dilution of each anti-MAA antibody was prepared using 1% BSA in PBS. 1%
BSA in PBS was used as a negative control. After washing each well, quantitation of primary
antibody binding was performed through the reaction with peroxidase-labeled secondary anti-
bodies. The TMB/H2O2 substrate was added to all the wells and kept at room temperature for
30 min. The plates were then read with a plate reader (Vmax Kinetic Microplate Reader,
Molecular Devices, Sunnyvale, CA) at a wavelength of 650 nm. Each antibody value was cor-
rected by subtracting the OD of the negative control from the value of each sample. The pri-
mary and secondary antibodies used for the ELISA were as follows: 1] moMoAb-1F83 [23]
and EnVision+Single Reagents anti-mouse-HRP (Code K4001, Dako North America, Inc.,
Carpentaria, CA); 2] rabPoAb [22] and goat anti-rabbit IgG (H+L) antibody with HRP
(Thermo Fisher Scientific); 3] huFull-MoAb (IFUf-08_108) [15] and rabbit anti-human IgG F
(ab’)2 fragment antibody with HRP (Jackson Immuno Research Laboratories); and 4] huPre-
MoAb (IFUp-08_107) [15] and rabbit anti-human IgG F(ab’)2 fragment antibody with HRP
as described above.
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
5 / 14

Pure MAA antigen-based ELISA
ELISA for determining anti-MAA antibody titers of serum samples obtained from mice
immunized with pMAA-lysine-BSA or BSA. The serum samples of mice immunized with
pMAA-lysine-BSA or BSA were separated from the blood to determine the IgG and IgM anti-
body values against pMAA-6ACA-KLH. Blood samples were collected into 2 mL tubes and
centrifuged at 2,000 g for 10 min at 4˚C. After separation, aliquots of serum were frozen at
-80˚C until analysis. The samples were diluted and used for ELISA-based analysis. pMAA-
6ACA-KLH (50 μL/well with equivalent fluorescence to pMAA-6ACA-BSA) was coated in
each well of the 96-well plates at 4˚C overnight. After washing, followed by blocking with the
supernatant of 5% Casein PBS suspension (hereafter referred to as supernatant A), 50 μL of the
serum samples were incubated at different concentrations at 4˚C overnight. A four-fold serial
dilution of each serum sample was prepared using 5-fold diluted supernatant A. The 5-fold
diluted supernatant A was used as a negative control. After washing each well, quantitation of
the antibody binding was performed through a reaction with peroxidase-labeled secondary
antibodies (IgG: EnVision+Single Reagents anti-mouse-HRP; IgM: Goat anti-Mouse IgM sec-
ondary antibody with HRP). The TMB reaction and plate reading were performed as described
above.
ELISA for quantitating anti-MAA antibody titers of serum samples obtained from
wild-type and ApoE-/- mice. The serum anti-MAA IgG and IgM titers in wild-type and
ApoE-/- mice were determined using 96-well plates coated with pMAA-6ACA-BSA or
crMAA-BSA. The plates were coated with equivalent amount of fluorescence between two
types of antigens. After blocking with 3% BSA in PBS, 50 μL of the 320-fold diluted serum sam-
ples in 1% BSA PBS solution were incubated at 4˚C overnight. 1% BSA PBS solution was used
as a negative control. After washing each well, the quantitation of primary antibody binding
was performed as described above.
Statistical analysis
The antibody values were indicated as mean SD of the mean, and the statistical differences
between the two groups (ApoE-/- vs wild-type mice; pMAA-6ACA-BSA plate vs crMAA-BSA
plate) were evaluated by unpaired Student t-tests after log transformation. A p-value < 0.05
was considered significant.
Results
Synthesis and purification of Nε-MAA-lysine
The ε amine of lysine is usually the target site for modification by MAA [24]; therefore, Nε-
(3,5-diformyl-4-methylpyridin-1(4H)-yl)lysine was the synthetic target. The Boc-protected
lysine adduct was synthesized by incubating Boc-lysine with MDA and acetaldehyde in a 1:2:1
ratio. The procedure for purifying the MAA-lysine is described in detail in S1B Fig. The reac-
tion mixture was analyzed by LC-MS and fractions containing the target product (S2A Fig)
were collected with confirmation of the structure by 1H NMR (S2B Fig). As anticipated, based
on previous reports, multiple contaminating adducts were present. The reaction of the Boc-
protected lysine with MDA and acetaldehyde produced unstable adducts (e.g., acetaldehyde-
Boc-lysine, MDA-Boc-lysine, and MDA-acetaldehyde (1:1)-Boc-lysine) as well as the stable
target. Previous studies on MAA have performed dialysis with the assumption that contami-
nating protein adducts are unstable and eliminated; however, we confirmed that even exten-
sive dialysis of the mixtures from the direct reaction of BSA, acetaldehyde, and MDA at
various concentrations does not remove contaminating protein adducts, as determined by
their fluorescence characteristics. Following deprotection of the Boc group, MAA-lysine was
purified by HPLC and the peak for pMAA-lysine was identified. The purity and identity of the
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
6 / 14

Pure MAA antigen-based ELISA
Fig 2. The full scan mass spectrums of MAA-lysine and MAA-6ACA. (A) The full scan mass spectrum shows the
protonated molecular ion for MAA-lysine at m/z 281.1498. Other peaks are minor background ions and reference ions m/z
121.0509 and m/z 922.0098. (B) The full scan mass spectrum shows the protonated molecular ion of MAA-6ACA at m/z
266.1391. Other peaks are minor background ions and reference ions m/z 121.0509 and m/z 922.0098.
doi:10.1371/journal.pone.0172172.g002
MAA-lysine adduct was confirmed by 1H NMR (S2C Fig) and the molecular composition was
determined by exact mass measurement of the molecular ion (Fig 2A).
Synthesis and purification of Nε-MAA-6ACA
As an alternative to the two-step HPLC purification procedure for pMAA-lysine synthesis,
MAA-6ACA, an analog of MAA-lysine that does not contain the α-amino group, was synthe-
sized by the reaction of 6-ACA with MDA and acetaldehyde (S1C Fig). pMAA-6ACA was
purified by HPLC and its identity and purity were confirmed by LC-MS and 1H NMR (Fig 2B
and S2D Fig).
Fluorescence properties of pMAA adducts
The purified adducts exhibited fluorescence, as expected for the 1,4-dihydropyridine chromo-
phore in MAA-lysine [6, 16, 23, 25]. pMAA-6ACA has an excitation/emission maximum of
399/462 nm. These values are in line with previously characterized MAA-lysine analog fluores-
cent properties [23].
Anti-MAA antibody reactivity to pMAA-6ACA-BSA
By ELISA-based analyses, the four previously-used anti-MAA antibodies we tested recognized
the pMAA-6ACA-BSA seeded on the bottom of a 96-well plate, all at different reactivities (Fig
3). The anti-MAA monoclonal mouse antibody (1F83) reacted with the MAA antigen at ~4
orders of magnitude lower concentration compared to the other anti-MAA antibodies.
Immunogenicity of pMAA-lysine-BSA
The immunogenicity of the MAA unit was previously characterized using a crude MAA-modi-
fied BSA mixture (henceforth referred to as crude MAA-BSA, “crMAA-BSA”) in the absence
of adjuvant. To evaluate whether pMAA-lysine-BSA also shows immunogenicity in mice,
C57BL/6 mice were treated intraperitoneally with pMAA-lysine-BSA or BSA in the absence of
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
7 / 14

Pure MAA antigen-based ELISA
Fig 3. An ELISA method for characterizing the activity of anti-MAA antibodies to pMAA epitopes.
Using the ELISA-based assay, we analyzed the four anti-MAA antibodies that were previously used
(moMoAb-1F83, huPre-MoAb, huFull-MoAb and rabPoAb). The ELISA plates were first coated with the
pMAA-6ACA-BSA antigens. The moMoAb-1F83 reacted with pMAA-6ACA-BSA at ~4 orders of magnitude
lower concentration compared to the other anti-MAA antibodies.
doi:10.1371/journal.pone.0172172.g003
adjuvant. The antibody titers of IgG and IgM directed against pMAA-lysine, which were
detected using pMAA-6ACA-KLH-coated plates, showed trends in accordance with the dilu-
tion levels of the samples. The titers were clearly increased in pMAA-lysine-BSA-immunized
mice compared to controls (BSA-treated mice) (Fig 4A and 4B).
Anti-MAA antibody titer in the serum of atherosclerosis-prone ApoE-/-
mice
A previous study reported that oxLDL levels are comparable in the peripheral blood of wild-
type and ApoE-/- mice fed a normal diet at 10 weeks of age but increases and peaks at 20 weeks
of age in the ApoE-/- mice [26]. To determine whether a pMAA antigen-based ELISA can
detect early increases in anti-MAA antibody titers in atherosclerosis, we next addressed
Fig 4. The immunogenicity of pMAA-lysine-BSA in the absence of adjuvant. C57BL/6 mice were
injected i.p. with pMAA-lysine-BSA or BSA in the absence of adjuvant. The antibody titers of IgG (A) and IgM
(B) against pMAA-lysine were detected using pMAA-6ACA-KLH-coated plates. The anti-MAA antibody titers
were clearly increased in pMAA-lysine-BSA-immunized mice compared to the controls (BSA-treated mice).
Error bars represent SD.
doi:10.1371/journal.pone.0172172.g004
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
8 / 14

Pure MAA antigen-based ELISA
Fig 5. Serum anti-MAA IgG and IgM antibody levels in wild-type and ApoE-/- mice. (A) Serum anti-MAA
IgG and IgM antibody levels in wild-type and ApoE-/- mice. The anti-MAA IgG and IgM antibody levels showed
significant differences between wild-type and ApoE-/- mice with the pMAA-6ACA-BSA and crMAA-BSA
ELISAs for all except the IgM levels with crMAA-BSA ELISA (*: p<0.05; **: p<0.01). In addition, the
differences between pMAA-6ACA-BSA and crMAA-BSA ELISAs in the wild type and ApoE-/- mice for anti-
MAA IgG and IgM antibody levels were significant for all except the IgM levels in ApoE-/- mice. (B) The anti-
MAA IgG and IgM antibody titers in ApoE-/- mice were normalized to those of wild-type mice. The individual
titer values of ApoE-/- animals were divided by the average titer value of the wild-type animals. Of note, the
differences between the antibody titers in the wild-type and ApoE-/- mice were much greater with the pMAA-
6ACA-BSA ELISA than with the crMAA-BSA ELISA. Error bars represent SD. Due to the redundancy of the
statistical analyses, we did not include any asterisks for statistical significance in Fig 5B.
doi:10.1371/journal.pone.0172172.g005
whether serum levels of IgG and IgM antibodies against pMAA are increased at a very early
stage of atherosclerosis in ApoE-/- mice fed with a normal diet. Blood serum was collected
from 3-month-old ApoE-/- mice and used in an ELISA to detect antibody titers. In addition,
the sensitivities of ELISAs were compared between the pMAA-6ACA-BSA- and the
crMAA-BSA-coated ELISAs (the plates were coated with antigens containing equivalent
amounts of fluorescence). The IgG and IgM antibody values using the pMAA-6ACA-BSA-
coated plates in ApoE-/- mice were significantly higher than those in wild-type mice, with
6.5-fold and 5.1-fold increases, respectively (Fig 5A and 5B). On the other hand, the IgG and
IgM antibody values using the crMAA-BSA-coated plates in ApoE-/- mice showed only
1.9-fold and 1.4-fold higher values, respectively, compared to the values in wild-type mice. ELI-
SAs using serially diluted serum samples (1:80 to 1:1280 dilutions) showed similar results to
Fig 5B at different dilutions (S1 Table). These results observed with the pMAA-6ACA-BSA
ELISAs indicate that the levels of antibodies against pMAA are markedly increased at very
early stages of atherosclerosis. Notably, wild-type mice showed 6.9- and 4.8-fold higher IgG
and IgM levels, respectively, using the crMAA-BSA-coated plates compared to pMAA-
6ACA-BSA-coated plates (Fig 5A). In contrast, the antibody titers in ApoE-/- mice using
crMAA-BSA-coated plates were only slightly increased compared to pMAA-6ACA-BSA-
coated plates.
Discussion
In this study, we developed a method to purify Nε-MAA-L-lysine molecules. Protein adducts
were then generated by conjugation with either pMAA-lysine or pMAA-6ACA, free of con-
tamination with modified protein impurities present in the reaction mixtures of MDA and
acetaldehyde. This method, for the first time, allows for the investigation of the biological
response specific to pMAA-lysine and the antibody response against MAA-lysine in athero-
sclerosis animal models. The ELISA plates coated with pMAA-6ACA-BSA detected a marked
increase in anti-MAA antibody titer in ApoE-/- mice with higher specificity and sensitivity than
the crMAA-BSA-coated ELISA. In contrast to pMAA-6ACA-BSA plates, the wild-type mice
showed high background IgG and IgM levels using the crMAA-BSA-coated plates. These
results suggest that the previous method of extensive dialysis of mixtures from the direct
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
9 / 14

Pure MAA antigen-based ELISA
reaction of BSA, acetaldehyde, and MDA was unlikely to remove contaminating protein
adducts, which left the confounding factor of antibody responses to antigens other than MAA.
Indeed, when we incubated MDA, acetaldehyde and 6-ACA at 37˚C followed by HPLC-UV
separation, we found that the yield of many major peaks (including MAA-6ACA) were
increased, indicating the production of many different, stable adducts. These results suggest
that the crMAA-BSA mixture contains many different stable epitopes including MAA. Com-
pared to the current ELISA methods using crMAA-BSA epitope, the pure-MAA ELISA shows
improvements in terms specificity and sensitivity and has the potential for detecting early
stage atherosclerosis.
Previous studies have demonstrated high titers of IgG antibodies directed against MDA-
LDL in 5–6 month old atherosclerosis-prone ApoE-/- mice fed a diet of regular mouse chow.
However, these results were based on a crude MDA-protein-coated radioimmunoassay [27].
Our ELISA technique, using pMAA-6ACA-BSA-coated plates, shows a substantial increase in
anti-MAA IgG and IgM antibody levels in ApoE-/- mice fed a normal diet, even as early as at
three months of age. Further, the differences between the antibody titers in the wild-type and
ApoE-/- mice were much greater with the pMAA-6ACA-BSA ELISA than with the crMAA-
BSA assay (Fig 5A and 5B). These results indicate that the high purity of the antigen improves
the sensitivity of the assay. These results strongly suggest that the pMAA-BSA ELISA method
may be a useful tool to detect early stages of atherosclerosis in patients. In future studies, we
hope to apply the pMAA-based ELISA using samples from patients at different stages of
atherosclerosis.
In humans, anti-MAA antibodies exist as natural IgM antibodies in the umbilical cord
blood of new born babies [15], and anti-MAA IgA, IgM, and IgG antibodies have been
detected in the peripheral blood of normal individuals [3, 15, 28]. Such results strongly suggest
that MAA epitopes are present under normal physiological conditions and that the total bur-
den of MAA-adducted proteins increase with the progression of atherosclerosis, leading to an
increase in anti-MAA antibody generation in atherosclerosis patients. To understand the path-
ogenesis of the disease, it is crucial to know the kinetics and regions of accumulation of MAA-
modified proteins during the development of atherosclerosis. Since it generally takes ~2 weeks
to observe a significant increase in antibody titer after a boost vaccination in mice [29, 30], the
marked increase in anti-MAA antibody titer in 3-month-old ApoE-/- mice in our study sug-
gests that ApoE deficiency may cause an increase in MAA epitopes at as early as 11 weeks of
age. Because ApoE-/- mice fed with a regular chow diet exhibit only very subtle phenotypes at
10 weeks, with small lesions on 0.5% of the surface of the aorta [26], the 6.5-fold and 5.1-fold
increases in IgG and IgM antibodies, respectively, against the pMAA group in ApoE-/- mice at
3 months indicates that antibodies against the pMAA group have potential as a very sensitive
biomarker for early atherosclerosis. Further studies are necessary to understand the mecha-
nism by which MAA epitopes are increased in ApoE-/- mice, as well as the time course of
MAA-lysine accumulation. Development of an ultra-sensitive LC-MS-based quantitative anal-
ysis using pMAA-lysine standards will be vital to answering these critical questions.
Our method also has substantial potential to increase the specificity of an ELISA-based
method for detecting anti-MAA antibody titers. It is noteworthy that there were significant
differences in anti-MAA antibody titers with the pMAA-6ACA-BSA and crMAA-BSA ELISAs,
particularly in wild-type mice (Fig 5A). The IgG and IgM antibody titers in wild-type mice
using crMAA-BSA-coated plates were significantly higher compared to pMAA-6ACA-BSA-
coated plates. These results strongly suggest that using 96-well plates coated with pMAA-
6ACA-BSA significantly decreases background resulting from immunoreactive contaminants,
such as other adducts present in the MDA–acetaldehyde reaction. These results also suggest
that there may be significant levels of MDA- and acetaldehyde-derived antibodies, in addition
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
10 / 14

Pure MAA antigen-based ELISA
to anti-MAA antibodies, in mice under normal conditions. The antibodies detected in the
wild-type mice by the crMAA-BSA ELISA could be derived from both previously identified
and unidentified protein adducts, including MDA-acetaldehyde-lysine 1:1:1 adducts, MDA-
lysine adducts, and acetaldehyde-lysine adducts [31, 32]. HPLC analysis detected multiple
peaks after incubation of MDA, acetaldehyde, and Boc-lysine at physiological temperature and
pH. Some of these adducts may be abundant enough to persist even after the crMAA-BSA
antigen purification by extensive dialysis. Our results also suggest that, at early stages of athero-
sclerosis in this mouse model, atherosclerotic conditions may stimulate formation of antibod-
ies specific to MAA-lysine adducts.
In addition to improving ELISA-based analyses, our pMAA antigens may prove to be a
great tool to investigate the atheroprotective effects of the immunization of MAA-modified
proteins. In animal models, anti-oxLDL antibody (Fab or Fv fragment) infusion and immu-
nization of MDA- or MAA-modified LDL, which leads to high levels of serum antibodies
(IgM and possibly IgG1), have both been shown to confer protection against atherosclerosis
[4, 33, 34]. These increases in serum antibodies against MDA- and MAA-modified LDL
appear to interfere with the interaction between MDA- and MAA-lysine epitopes and mac-
rophages, resulting in inhibition of the inflammatory response. This inhibition is believed to
further inhibit both the engulfment of oxLDL by macrophages as well as MAA-mediated
inflammation. However, as mentioned previously, the MDA and MAA preparations used in
previous studies for immunization resulted in crude, heterogeneous mixtures of various
adducts. Since previous studies used impure immunogens for investigating their atheropro-
tective properties [4, 35], their results need to be interpreted with caution because of a
potential increase in non-targeted immune responses caused by the contaminating protein
adducts. Therefore, it is important to determine the exact protein adducts that confer ather-
oprotection by immunization. One of these reports attempted to identify the MDA-derived
protein adducts critical for rescue [4]. Interestingly, they found that the responsible adducts
could be, in fact, the 1,4-dihydropridine-type MAA-protein adducts based on their immu-
nogenicity potential. Although the authors of this study attempted a more rigorous purifica-
tion protocol, their efforts still yielded a heterogeneous pool of adducts. These studies
further highlight the need for investigations conducted with pMAA adducts as well as the
identification of the various contaminating protein adducts generated by reaction with
MAA. In our study, BSA was conjugated with pMAA free of contaminating epitopes and we
successfully increased anti-MAA antibodies in serum of mice immunized with pMAA-
lysine-BSA in the absence of adjuvant. Thus, it will be informative to utilize pMAA-lysine-
BSA and pMAA-6ACA-BSA immunogens for improved testing of atheroprotection by
MAA immunization.
Supporting information
S1 Table. Ratios of ApoE-/—to-wild-typeserum antibody titers against pMAA-6ACA-BSA
or crMAA-BSA.
(DOCX)
S1 Fig. Preparation of MAA-lysine, MAA-6ACA, and pMAA-lysine-BSA complex.
(DOCX)
S2 Fig. The full scan mass spectrum and NMR results of MAA-Boc-lysine and NMR results
of MAA-lysine and MAA-6ACA.
(DOCX)
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
11 / 14

Pure MAA antigen-based ELISA
Acknowledgments
This work was supported in part by NIH grants P42-ES05948 and P30-ES10126. We are also
thankful to Dr. Todd A Wyatt for providing a polyclonal rabbit antibody against MAA. We
are thankful to Dr. Louise Ball for valuable discussion and Dr. Naohiko Isobe for critical read-
ing of our manuscript. The excellent technical assistance of Mr. Scott Klayner in the analysis of
fluorescent properties of MAA adducts is acknowledged. The content is solely the responsibil-
ity of the authors and does not necessarily represent the official views of the National Institutes
of Health.
Author Contributions
Conceptualization: JN.
Formal analysis: TS LBC DWH ZZ XT JN.
Funding acquisition: AG JN.
Investigation: TS LBC XY DWH ZZ XT SJB JN.
Methodology: MSW AG SJB JN.
Resources: KU CW SH.
Supervision: MSW AG SJB JN.
Writing – original draft: TS LBC ZZ JN.
Writing – review & editing: SH MSW AG SJB JN.
References
1. Domingues RM, Domingues P, Melo T, Perez-Sala D, Reis A, Spickett CM. Lipoxidation adducts with
´
peptides and proteins: deleterious modifications or signaling mechanisms? J Proteomics. 2013;
92:110–31. doi: 10.1016/j.jprot.2013.06.004 PMID: 23770299
2. Holvoet P, Collen D. Oxidation of low density lipoproteins in the pathogenesis of atherosclerosis. Ath-
erosclerosis. 1998; 137 Suppl:S33–8.
3. Antoniak DT, Duryee MJ, Mikuls TR, Thiele GM, Anderson DR. Aldehyde-modified proteins as media-
tors of early inflammation in atherosclerotic disease. Free Radic Biol Med. 2015; 89:409–18. doi: 10.
1016/j.freeradbiomed.2015.09.003 PMID: 26432980
4. Gonen A, Hansen LF, Turner WW, Montano EN, Que X, Rafia A, et al. Atheroprotective immunization
with malondialdehyde-modified LDL is hapten specific and dependent on advanced MDA adducts:
implications for development of an atheroprotective vaccine. J Lipid Res. 2014; 55(10):2137–55. doi:
10.1194/jlr.M053256 PMID: 25143462
5. Veneskoski M, Turunen SP, Kummu O, Nissinen A, Rannikko S, Levonen AL, et al. Specific recognition
of malondialdehyde and malondialdehyde acetaldehyde adducts on oxidized LDL and apoptotic cells by
complement anaphylatoxin C3a. Free Radic Biol Med. 2011; 51(4):834–43. doi: 10.1016/j.
freeradbiomed.2011.05.029 PMID: 21683785
6. Kikugawa K, Kosugi H, Asakura T. Effect of malondialdehyde, a product of lipid peroxidation, on the
function and stability of hemoglobin. Arch Biochem Biophys. 1984; 229(1):7–14. PMID: 6703702
7. Slatter DA, Murray M, Bailey AJ. Formation of a dihydropyridine derivative as a potential cross-link
derived from malondialdehyde in physiological systems. FEBS Lett. 1998; 421(3):180–4. PMID:
9468302
8. Willis MS, Klassen LW, Tuma DJ, Thiele GM. Malondialdehyde-acetaldehyde-haptenated protein
induces cell death by induction of necrosis and apoptosis in immune cells. Int Immunopharmacol. 2002;
2(4):519–35. PMID: 11962731
9. Duryee MJ, Klassen LW, Freeman TL, Willis MS, Tuma DJ, Thiele GM. Lipopolysaccharide is a cofactor
for malondialdehyde-acetaldehyde adduct-mediated cytokine/chemokine release by rat sinusoidal liver
endothelial and Kupffer cells. Alcohol Clin Exp Res. 2004; 28(12):1931–8. PMID: 15608611
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
12 / 14

Pure MAA antigen-based ELISA
10. Kharbanda KK, Shubert KA, Wyatt TA, Sorrell MF, Tuma DJ. Effect of malondialdehyde-acetaldehyde-
protein adducts on the protein kinase C-dependent secretion of urokinase-type plasminogen activator
in hepatic stellate cells. Biochem Pharmacol. 2002; 63(3):553–62. PMID: 11853706
11. Thiele GM, Duryee MJ, Freeman TL, Sorrell MF, Willis MS, Tuma DJ, et al. Rat sinusoidal liver endothe-
lial cells (SECs) produce pro-fibrotic factors in response to adducts formed from the metabolites of etha-
nol. Biochem Pharmacol. 2005; 70(11):1593–600. doi: 10.1016/j.bcp.2005.08.014 PMID: 16202982
12. Thiele GM, Tuma DJ, Willis MS, Miller JA, McDonald TL, Sorrell MF, et al. Soluble proteins modified
with acetaldehyde and malondialdehyde are immunogenic in the absence of adjuvant. Alcohol Clin Exp
Res. 1998; 22(8):1731–9. PMID: 9835288
13. Anderson DR, Duryee MJ, Shurmur SW, Um JY, Bussey WD, Hunter CD, et al. Unique antibody
responses to malondialdehyde-acetaldehyde (MAA)-protein adducts predict coronary artery disease.
PLoS One. 2014; 9(9):e107440. doi: 10.1371/journal.pone.0107440 PMID: 25210746
14. Hill GE, Miller JA, Baxter BT, Klassen LW, Duryee MJ, Tuma DJ, et al. Association of malondialdehyde-
acetaldehyde (MAA) adducted proteins with atherosclerotic-induced vascular inflammatory injury. Ath-
erosclerosis. 1998; 141(1):107–16. PMID: 9863543
¨
15. Wang C, Turunen SP, Kummu O, Veneskoski M, Lehtimaki J, Nissinen AE, et al. Natural antibodies of
newborns recognize oxidative stress-related malondialdehyde acetaldehyde adducts on apoptotic cells
and atherosclerotic plaques. Int Immunol. 2013; 25(10):575–87. doi: 10.1093/intimm/dxt022 PMID:
23900424
16. Xu D, Thiele GM, Kearley ML, Haugen MD, Klassen LW, Sorrell MF, et al. Epitope characterization of
malondialdehyde-acetaldehyde adducts using an enzyme-linked immunosorbent assay. Chem Res
Toxicol. 1997; 10(9):978–86. doi: 10.1021/tx970069t PMID: 9305579
17. Ohya T. Formation of a new 1,1,1 adduct in the reaction of malondialdehyde, n-hexylamine and alkanal
under neutral conditions. Biol Pharm Bull. 1993; 16(2):137–41. PMID: 8364449
18. Ishii T, Kumazawa S, Sakurai T, Nakayama T, Uchida K. Mass spectroscopic characterization of protein
modification by malondialdehyde. Chem Res Toxicol. 2006; 19(1):122–9. doi: 10.1021/tx050231p
PMID: 16411665
19. Donohue TM, Tuma DJ, Sorrell MF. Acetaldehyde adducts with proteins: binding of [14C]acetaldehyde
to serum albumin. Arch Biochem Biophys. 1983; 220(1):239–46. PMID: 6830235
20. Robertson AK, Zhou X, Strandvik B, Hansson GK. Severe hypercholesterolaemia leads to strong Th2
responses to an exogenous antigen. Scand J Immunol. 2004; 59(3):285–93. doi: 10.1111/j.0300-9475.
2004.01403.x PMID: 15030580
21. Tuma DJ, Thiele GM, Xu D, Klassen LW, Sorrell MF. Acetaldehyde and malondialdehyde react together
to generate distinct protein adducts in the liver during long-term ethanol administration. Hepatology.
1996; 23(4):872–80. doi: 10.1002/hep.510230431 PMID: 8666344
22. McCaskill ML, Kharbanda KK, Tuma DJ, Reynolds JD, DeVasure JM, Sisson JH, et al. Hybrid malon-
dialdehyde and acetaldehyde protein adducts form in the lungs of mice exposed to alcohol and cigarette
smoke. Alcohol Clin Exp Res. 2011; 35(6):1106–13. doi: 10.1111/j.1530-0277.2011.01443.x PMID:
21428986
23. Yamada S, Kumazawa S, Ishii T, Nakayama T, Itakura K, Shibata N, et al. Immunochemical detection
of a lipofuscin-like fluorophore derived from malondialdehyde and lysine. J Lipid Res. 2001; 42
(8):1187–96. PMID: 11483619
24. Uchida K, Sakai K, Itakura K, Osawa T, Toyokuni S. Protein modification by lipid peroxidation products:
formation of malondialdehyde-derived N(epsilon)-(2-propenol)lysine in proteins. Arch Biochem Bio-
phys. 1997; 346(1):45–52. PMID: 9328283
25. Kikugawa K, Kato T, Iwata A. Determination of malonaldehyde in oxidized lipids by the Hantzsch fluoro-
metric method. Anal Biochem. 1988; 174(2):512–21. PMID: 3239753
26. Kato R, Mori C, Kitazato K, Arata S, Obama T, Mori M, et al. Transient increase in plasma oxidized LDL
during the progression of atherosclerosis in apolipoprotein E knockout mice. Arterioscler Thromb Vasc
Biol. 2009; 29(1):33–9. doi: 10.1161/ATVBAHA.108.164723 PMID: 18988894
27. Palinski W, Ord VA, Plump AS, Breslow JL, Steinberg D, Witztum JL. ApoE-deficient mice are a model
of lipoprotein oxidation in atherogenesis. Demonstration of oxidation-specific epitopes in lesions and
high titers of autoantibodies to malondialdehyde-lysine in serum. Arterioscler Thromb. 1994; 14(4):605–
16. PMID: 7511933
´
28. Rolla R, Vay D, Mottaran E, Parodi M, Traverso N, Arico S, et al. Detection of circulating antibodies
against malondialdehyde-acetaldehyde adducts in patients with alcohol-induced liver disease. Hepatol-
ogy. 2000; 31(4):878–84. doi: 10.1053/he.2000.5373 PMID: 10733543
29. Xiang ZQ, Spitalnik SL, Cheng J, Erikson J, Wojczyk B, Ertl HC. Immune responses to nucleic acid vac-
cines to rabies virus. Virology. 1995; 209(2):569–79. doi: 10.1006/viro.1995.1289 PMID: 7778289
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
13 / 14

Pure MAA antigen-based ELISA
30. Silva GP, Cruz SC, Cruz AC, Milagres LG. Short-term and long-term antibody response by mice after
immunization against Neisseria meningitidis B or diphtheria toxoid. Braz J Med Biol Res. 2013; 46
(2):148–53. doi: 10.1590/1414-431X20122556 PMID: 23369971
31. Kearley ML, Patel A, Chien J, Tuma DJ. Observation of a new nonfluorescent malondialdehyde-acetal-
dehyde-protein adduct by 13C NMR spectroscopy. Chem Res Toxicol. 1999; 12(1):100–5. doi: 10.
1021/tx980132u PMID: 9894024
32. Uchida K. Lipofuscin-like fluorophores originated from malondialdehyde. Free Radic Res. 2006; 40
(12):1335–8. doi: 10.1080/10715760600902302 PMID: 17090422
33. Haberland ME, Fogelman AM, Edwards PA. Specificity of receptor-mediated recognition of malondial-
dehyde-modified low density lipoproteins. Proc Natl Acad Sci U S A. 1982; 79(6):1712–6. PMID:
6281781
34. Tsimikas S, Miyanohara A, Hartvigsen K, Merki E, Shaw PX, Chou MY, et al. Human oxidation-specific
antibodies reduce foam cell formation and atherosclerosis progression. J Am Coll Cardiol. 2011; 58
(16):1715–27. doi: 10.1016/j.jacc.2011.07.017 PMID: 21982317
35. Palinski W, Miller E, Witztum JL. Immunization of low density lipoprotein (LDL) receptor-deficient rabbits
with homologous malondialdehyde-modified LDL reduces atherogenesis. Proc Natl Acad Sci U S A.
1995; 92(3):821–5. PMID: 7846059
PLOS ONE | DOI:10.1371/journal.pone.0172172 February 21, 2017
14 / 14
