New tetraphenylpyridinium-based luminogens with
aggregation-induced emission characteristics
WANG ZongTan1, FANG Yuan1, SUN JingZhi1, QIN AnJun1* & TANG Ben Zhong1, 2, 3*
1MOE Key Laboratory of Macromolecular Synthesis and Functionalization, Department of Polymer Science and Engineering, Zhejiang
University, Hangzhou 310027, China
2Department of Chemistry, Institute for Advanced Study, Institute of Molecular Functional Materials, The Hong Kong University of Science &
Technology (HKUST), Clear Water Bay, Kowloon, Hong Kong, China
3Guangdong Innovative Research Team, SCUT-HKUST Joint Research Laboratory, State Key Laboratory of Luminescent Materials and
Devices, South China University of Technology (SCUT), Guangzhou 510640, China
Received June 26, 2013; accepted July 7, 2013
The research on aggregation-induced emission (AIE) has drawn increasing interests in the past decade. With the efforts scien-
tists paid, a variety of AIE systems have been developed, among which the tetraphenylethelene and silole derivatives are the
most studied. Development of new AIE systems could further enrich the AIE molecules and promote the development of AIE
area. In this communication, we prepared a new AIE system based on 1,2,4,6-tetraphenylpyridinium ions according to the re-
striction of intramolecular rotation mechanism. These molecules could be facilely synthesized via one-step and one-pot reac-
tion. The ionic AIE-active molecules could find wide application in sensing and optoelectronic areas.
aggregation-induced emission, cation, restriction of intramolecular rotation, tetraphenylpyridinium
used as solid films in their real-world applications [7, 8].
Various chemical, physical, and engineering approaches
1 Introduction
(e.g. attachment of alicyclic pendants, encapsulation by
amphiphilic surfactants, and blending with transparent
polymers) have been taken to alleviate the ACQ effect.
These attempts, however, have met with limited success
[9–11]. Dye aggregation is a spontaneously occurred physi-
cal phenomenon in nature. It will be better if the dye aggre-
gation plays a positive instead of negative role for its emis-
sion in condensed phase. Thus, researchers never need to
painfully fight against this process but amusedly utilize it to
generate efficient emitters in the solid state [12–14].
We have observed an unusual phenomenon of “aggrega-
tion-induced emission” (AIE) in 2001 [15], which is exactly
opposite to the aforementioned ACQ effect. A series of
propeller-shaped molecules are nonluminescent when mo-
lecularly dissolved but become highly emissive in the ag-
gregate state. Restriction of intramolecular rotation (RIR) of
their multiple phenyl rings in the aggregate or solid states
Development of efficient luminescent materials in the solid-
state is a hot research topic because of their promising prac-
tical applications in organic light-emitting diodes (OLEDs),
organic solid-state lasers, chemical sensors, biological
probes, logic circuitry, etc [1–6]. With the enthusiastic ef-
forts scientists paid, tremendous fluorogenic dyes have been
generated. However, many of them are highly emissive
when dissolved in good solvents but faintly luminescent or
totally nonemissive when increased the concentration or
aggregated in poor solvents. This is the thorny problem of
aggregation-caused quenching (ACQ) effect, which should
be properly tackled because these materials are commonly
*Corresponding authors (email: qinaj@zju.edu.cn; tangbenz@ust.hk)
© Science China Press and Springer-Verlag Berlin Heidelberg 2013
chem.scichina.com www.springerlink.com

2
Wang ZT, et al. Sci China Chem January (2013) Vol.56 No.1
has been proven experimentally and theoretically as the
main cause for the AIE effect [16–25].
would consume the energy of excited state and make the
molecule nonemissive or weakly luminescent. While, in the
aggregate or solid states, the rotations are greatly restricted
physically, and the emission will turn on.
Attracted by the intriguing photophysical process of AIE
effect, the researchers throughout the world have been ac-
tively involved in this area. As a result, a variety of AIE
systems have been developed in the past decade, among
which the tetraphenylethelene (TPE) and silole derivatives
have been widely investigated and identified as the arche-
type AIE systems [12, 13, 26]. They have been widely ap-
plied in fluorescent chemosensors and bioprobes, stimuli-
responsive nanomaterials, and as active layers in efficient
OLEDs [27]. However, the emission efficiency of TPEs and
the tedious synthesis and purification procedures of siloles
have greatly limited the expansion of the researches on AIE.
To further promote the development of the AIE area, new
AIE system is highly demanded. Furthermore, for biological
applications, the AIE molecules have always been decorated
with hydrophilic groups on their periphery to make them
water soluble, which requires additional functionalization
procedures. [28, 29].
We are interesting in exploring new AIE systems, espe-
cially the ionic AIE-active molecules because of their
promising application in biological field. According to the
RIR mechanism of AIE, a propeller-shaped molecule with
multiple phenyl rotors could feature such characteristics,
and pyridine derivatives could generate ionic species by
substitution reaction with ease. Following these rules, a type
of cationic molecules named 1,2,4,6-tetraphenylpyridinium
drew our attention [3032]. In such molecule, four phenyl
rings are integrated on a pyridinium cation. We thus antici-
pated that the rotation of these phenyl rings in solution
2 Results and discussion
The 1,2,4,6-tetraphenylpyridinium-based ionic molecules
could be facilely synthesized. As shown in Scheme 1, the
reactions between 2,4,6-triphenylpyrylium tetrafluoroborate
and mono- or di-amines in the refluxed ethanol solutions
readily furnished corresponding compounds 1, 2 and 3 after
simply workup procedures [33]. Unlike other ionic
AIE-active luminogens, which were prepared via post-
functionalization reactions, the cationic pyridiniums are
formed in situ with the substitution reactions of oxygen by
nitrogen. The molecules are soluble in dichloromethane and
other polar solvents like DMSO and DMF, but partially
soluble in water. The molecules were fully characterized by
1H (Figure S1) and 13C (Figure S2) NMR and mass spectra
(Figure S3), and satisfactory data corresponding their struc-
tures were obtained [see Supporting Information for de-
tails].
Then, we studied their photophysical properties. As can
be seen from Figure S4, the dilute DMSO solutions of 1, 2
and 3 show absorption maximum (max) at 309, 313, and
317 nm, respectively. The red-shift of the max is probably
due to the conjugation extension from 1 to 3.
According to the RIR mechanism of AIE, the 1,2,4,6-
tetraphenylpyridinium derivatives should possess such
Scheme 1 Synthetic routes to 1,2,4,6-tetraphenylpyridiniums 1, 2 and 3.

Wang ZT, et al. Sci China Chem January (2013) Vol.56 No.1
3
was recorded. Furthermore, the emission peaks were gradu-
ally red shifted from 422 to 446 nm under the same meas-
urement conditions, which is probably due to the solvent
polarity effect with more water added. Since 2 is partially
soluble in water, addition of large amount water into its
DMSO solution will make the molecules aggregated. 2 was
thus induced to emit by aggregate formation, i.e. 2 is
AIE-active. While, for 1 and 3, their DMSO solutions could
emit weak light but the intensities were strengthened upon
addition of water (Figures S5 and S6). In other words, they
feature the characteristics of aggregate-enhanced emission
(AEE).
The plots of relative emission intensity of the molecules
in DMSO/water mixtures vs. fw further confirm their
AIE/AEE features. As shown in Figure 1(b), the emission
intensity of 1, 2 and 3 was gradually increased with addition
of water, and the highest values were all recorded in
DMSO/water mixtures with fw of 90%, which are 12.6, 85.0,
and 6.1-fold higher than that those in their DMSO solutions,
respectively. The relatively low intensity enhancement of 1
and 3 is because their solutions are weakly emissive.
These results indicate that the emission behaviors of
1,2,4,6-tetraphenylpyridinium-based molecules could be
easily fine-tuned through molecular engineering.
3 Conclusions
In summary, according to the RIR mechanism, we have
developed a new AIE system based on 1,2,4,6-tetraphen-
ylpyridinium ion. Compounds 1, 2 and 3 could be facilely
synthesized from commercially available starting materials
of 2,4,6-triphenylpyrylium tetrafluoroborate and mono- or
di-amines in the refluxed ethanol solutions. The photophys-
ical measurements showed that these molecules possess
AIE/AEE characteristics, which in turn proves the reasona-
bility of the RIR mechanism. Unlike the reported ionic
AIE-active molecules, in which the charges were on their
periphery, these molecules have charges on their cores,
which are promising to be applied as chemosensors and
bioprobes with high sensitivity. The generation of more
AIE-active 1,2,4,6-tetraphenylpyridinium ions and explora-
tion of their applications are on-going in our research
groups.
Figure 1 (a) PL spectra of 1,2,4,6-tetraphenylpyridinium derivative 2 in
the DMSO/H2O mixtures with different fractions of water (fw). Concentra-
tion: 10 µM; excitation wavelength: 313 nm. (b) Plot of the change in PL
intensity with fw of 1,2,4,6-tetraphenylpyridinium derivative 2, where I0
and I are the maxima PL intensity. Inset: Plots of the changes in PL inten-
sity with fw of 1,2,4,6-tetraphenylpyridinium derivatives 1 and 3.
characteristics. We thus investigated the photoluminescence
(PL) behaviors of 1, 2 and 3 in the solution and aggregate
states. The aggregates were prepared by adding water into
their DMSO solutions under vigorous stirring. The re-
sultant mixtures are visually transparent and macroscopi-
cally homogenous, suggesting that the molecular aggregates
are nanometer-sized [34].
Variations of the PL spectra of 2 with fw in the
DMSO/water mixtures are shown in panel (a) of Figure 1 as
an example. When excited at 313 nm, the PL spectrum of
the diluted DMSO solution of 2 gives almost a flat line par-
allel to the abscissa, manifesting that 2 is a weak emitter
when molecularly dissolved. In contrast, when a large
amount of water is added into the solution, intense emission
This work was partially supported by the National Science Foundation of
China (21222402, 21174120, 20974098), the National Basic Research
Program of China (2013CB834702, 2009CB623605), and the Research
Grants Council of Hong Kong (603509, HKUST2/CRF/10, 604711,
NHKUST620/11).
1
2
Shimizu M, Hiyama T. Organic fluorophores exhibiting highly effi-
cient photoluminescence in the solid state. Chem Asian J, 2010, 5:
1516–1531
Liu B, Dan T, Bazan GC. Collective response from a cationic tetra-

4
Wang ZT, et al. Sci China Chem January (2013) Vol.56 No.1
hedral fluorene for label-free DNA detection. Adv Funct Mater, 2007,
17: 2432–2438
cence enhancements of benzene-cored luminophores by restricted in-
tramolecular rotations: AIE and AIEE effects. Chem Commun, 2007,
70–72
3
Chen Q, Wang JX, Yang F, Zhou D, Bian N, Zhang XJ, Yan CG,
Han BH. Tetraphenylethylene-based fluorescent porous organic
polymers: Preparation, gas sorption properties and photolumines-
cence properties. J Mater Chem, 2011, 21: 13554–13560
Chi ZG, Zhang XQ, Xu BJ, Zhou X, Ma CP, Zhang Y, Liu SW, Xu
JR. Recent advances in organic mechanofluorochromic materials.
Chem Soc Rev, 2012, 41: 3878–3896
Ning ZJ, Chen Z, Zhang Q, Yan YL, Qian SX, Cao Y, Tian H. Ag-
gregation-induced emission (AIE)-active starburst triarylamine
fluorophores as potential non-doped red emitters for organic
light-emitting diodes and Cl2 gas chemodosimeter. Adv Funct Mater,
2007, 17: 3799–3807
Teng MJ, Jia XR, Yang S, Chen XF, Wei Y. Reversible tuning lumi-
nescent color and emission intensity: a dipeptide-based light-emitting
material. Adv Mater, 2012, 24: 1255–1261
Lee SH, Jang BB, Kafafi ZH. Highly fluorescent solid-state asym-
metric spirosilabifluorene derivatives. J Am Chem Soc, 2005, 127:
9071–9078
20 Shi JQ, Chang N, Li CH, Mei J, Deng CM, Luo XL, Liu ZP, Bo ZS,
Dong YQ, Tang BZ. Locking the phenyl rings of tetraphenylethene
step by step: understanding the mechanism of aggregation-induced
emission. Chem Commun, 2012, 48: 10675–10677
4
5
21 Li Y, Zhou NC, Zhang W, Zhang F, Zhu J, Zhang ZB, Cheng ZP, Tu
YF, Zhu XL. Light-driven and aggregation-induced emission from
side-chain azoindazole polymers. J Polym Sci Part A: Polym Chem,
2011, 49: 4911–4920
22 Yao H, Ashiba K. Highly fluorescent organic nanoparticles of thia-
cyanine dye: A synergetic effect of intermolecular H-aggregation and
restricted intramolecular rotation. RSC Adv, 2011, 1: 834–838
23 Chien WL, Yang CM, Chen TL, Li ST, Hong JL. Enhanced emission
of a pyridine-based luminogen by hydrogen-bonding to organic and
polymeric phenols. RSC Adv 2013, 3: 6930–6938
6
7
8
24 Wu QY, Deng CM, Peng Q, Niu YL, Shuai ZG. Quantum chemical
insights into the aggregation induced emission phenomena:
A
Aldred MP, Li C, Zhang GF, Gong WL, Li ADQ, Dai YF, Ma DG,
Zhu MQ. Fluorescence quenching and enhancement of vitrifiable ol-
igofluorenes end-capped with tetraphenylethene. J Mater Chem, 2012,
22: 7515–7528
Wang J, Zhao Y, Dou YC, Sun H, Xu P, Ye K, Zhang J, Jing S, Li F,
Wang Y. Alkyl and dendron substituted quinacridones:ꢀ Synthesis,
structures, and luminescent properties. J Phys Chem B, 2007, 111:
5082–5089
QM/MM study for pyrazine derivatives. J Comput Chem, 2012, 33:
1862–1869
25 He JT, Xu B, Chen FP, Xia HJ, Li KP, Ye L, Tian WJ. Aggrega-
tion-induced emission in the crystals of 9,10-distyrylanthracene de-
rivatives: The essential role of restricted intramolecular torsion. J
Phys Chem C, 2009, 113: 9892–9899
26 Qian LJ, Zhi JG, Tong B, Yang F, Zhao W, Dong YP. Organic com-
pounds with aggregation-induced emission. Prog Chem, 2008, 20:
673–678
27 Zhao GS, Shi CX, Guo ZQ, Zhu WH, Zhu SQ. Recent application
progress on aggregation-induced emission. Chin J Org Chem, 2012,
32: 1620–1632
9
10 Hecht S, Fréchet JMJ. Dendritic encapsulation of function: Applying
nature's site isolation principle from biomimetics to materials science.
Angew Chem Int Ed, 2001, 40: 74–91
11 Chen L, Xu S, McBranch D, Whitten D. Tuning the properties of
conjugated polyelectrolytes through surfactant complexation. J Am
Chem Soc, 2000, 122: 9302–9303
28 Wang M, Zhang GX, Zhang DQ, Zhu DB, Tang BZ. Fluorescent
bio/chemosensors based on silole and tetraphenylethene luminogens
with aggregation-induced emission feature. J Mater Chem, 2010, 20:
1858–1867
12 Hong YN, Lam JWY, Tang BZ. Aggregation-induced emission. Chem
Soc Rev, 2011, 40: 5361–5388
13 Hong YN, Lam JWY, Tang BZ. Aggregation-induced emission: Phe-
nomenon, mechanism and application. Chem Commun, 2009,
4332–4353
14 Qin AJ, Lam JWY, Tang BZ. Luminogenic polymers with aggregation-
induced emission characteristics. Prog Polym Sci, 2012, 37: 182–209
15 Luo JD, Xie ZL, Lam JWY, Cheng L, Chen HY, Qiu CF, Kwok HS,
Zhan XW, Liu YQ, Zhu DB, Tang BZ. Aggregation-induced emission
of 1-methyl-1,2,3,4,5-pentaphenylsilole. Chem Commun, 2001,
1740–1741
16 Chen JW, Law CCW, Lam JWY, Dong YP, Lo SMF, Williams ID,
Zhu DB, Tang BZ. Synthesis, light emission, nanoaggregation, and
restricted intramolecular rotation of 1,1-substituted 2,3,4,5-
tetraphenylsiloles. Chem Mater, 2003, 15:1535–1546
17 Zhang S, Qin AJ, Sun JZ, Tang BZ. Progress in mechanism study of
aggregation-induced emission. Prog Chem, 2011, 23:623–636
18 Li Z, Dong YQ, Mi BX, Tang YH, Haussler M, Tong H, Dong YP,
Lam JWY, Ren Y, Sung HHY, Wong KS, Gao P, Williams ID,
Kwok HS, Tang BZ. Structural control of the photoluminescence of
silole regioisomers and their utility as sensitive regiodiscriminating
chemosensors and efficient electroluminescent materials. J Phys
Chem B, 2005, 109:10061–10069
29 Ding D, Li K, Liu B, Tang BZ. Bioprobes based on AIE fluorogens.
Acc Chem Res, 2013, 46: DOI: 10.1021/ar3003464
30 Miranda MA, Garcia H. 2,4,6-Triphenylpyrylium tetrafluoroborate as
an electron-transfer photosensitizer. Chem Rev, 1994, 94, 1063-1089
31 Perez RT, Sanchez-Pedreno C, Ortuno JA. 1,2,4,6-Tetraphenylpyri-
dinium perchlorate as a reagent for ion-association complex for-
mation and its use for the spectrophotometric determination of thal-
lium. Analyst, 1982, 107: 185–189
32 Han FL, Lu Y, Zhang Q, Sun JF, Zeng XS, Li CX. Homogeneous and
sensitive DNA detection based on polyelectrolyte complexes of cati-
onic conjugated poly(pyridinium salt)s and DNA. J Mater Chem,
2012, 22: 4106–4112
33 Fortage J, Tuyèras F, Ochsenbein P, Puntoriero F, Nastas F, Campa-
gna S, Griveau S, Bedioui F, Ciofini I, Lainé PP. Expanded pyri-
diniums biscyclization of branched pyridiniums into their fused pol-
ycyclic and positively charged derivatives—assessing the impact of
pericondensation on structural, electrochemical, electronic, and pho-
tophysical feature, Chem Eur J, 2010, 16: 11047–1063
34 Wang J, Mei J, Hu RR, Sun JZ, Qin AJ, Tang BZ. Click synthesis,
aggregation-induced emission, E/Z isomerization, self-organization,
and multiple chromisms of pure stereoisomers of
a
tetra-
19 Zeng Q, Li Z, Dong YQ, Di CA, Qin AJ, Hong YN, Ji L, Zhu ZC,
Jim CKW, Yu G, Li QQ, Li ZA, Liu YQ, Qin JG, Tang BZ. Fluores
phenylethene-cored luminogen. J Am Chem Soc, 2012, 134:
9956–9966
