the Cu/ZnO catalyst was obviously different from the morphol- References
ogy of the Cu/SiO2 catalyst (Fig. 4a). The morphology of the
1 Y. F. Zhao, Y. Yang, C. Mims, C. H. F. Peden, J. Li and
D. H. Mei, Insight into methanol synthesis from CO2
hydrogenation on Cu(111): Complex reaction network and
the effects of H2O, J. Catal., 2011, 281(2), 199–211.
2 M. T. Schaal, A. Y. Metcalf, J. H. Montoya, J. P. Wilkinson,
C. C. Stork, C. T. Williams and J. R. Monnier, Hydrogenation
of 3,4-epoxy-1-butene over Cu–Pd/SiO2 catalysts prepared
by electroless deposition, Catal. Today, 2007, 123(1–4),
142–150.
3 A. Bienholz, F. Schwab and P. Claus, Hydrogenolysis of
glycerol over a highly active CuO/ZnO catalyst prepared by
an oxalate gel method: influence of solvent and reaction
temperature on catalyst deactivation, Green Chem., 2010,
12(2), 290–295.
Cu/ZnO catalyst was spindle-shaped, while the morphology of
Cu/SiO2 was flake-like. With increasing SiO2 content, agglom-
eration was clearly observed (e.g., Cu/ZnO-95S (Fig. 8c)), con-
firming that the addition of excess SiO2 was not conducive to
the dispersion of copper. At the same time, it was found that
the particle of the Cu/ZnO catalyst significantly grew after the
reaction (Fig. 8a1). However, an apparent reunion was not
observed for the Cu/ZnO-5S catalyst after reaction (Fig. 8b1),
suggesting that the addition of a small quantity of SiO2 played a
role in hindering catalyst agglomeration. In other words, a
small amount of silica can act as a partitioning material to
hinder the agglomeration of Cu/ZnO catalyst particles. Never-
theless, this effect was wakened with increasing SiO2 content,
for example, the Cu/ZnO-95S catalyst (Fig. 8c1). This may have
occurred because there are similar impacts on Cu/SiO2 due to
the addition of excess ZnO that was produced with the increase in
SiO2 content. That is, if the Cu/ZnO catalyst was added to excess
SiO2, it can also be seen as the Cu/SiO2 catalyst doping ZnO.
4 A. Y. Yin, C. Wen, X. Y. Guo, W. L. Dai and K. N. A. Fan,
Influence of Ni species on the structural evolution of
Cu/SiO2 catalyst for the chemoselective hydrogenation of
dimethyl oxalate, J. Catal., 2011, 280(1), 77–88.
5 W. W. Lin, H. Y. Cheng, J. Ming, Y. C. Yu and F. Y. Zhao,
Deactivation of Ni/TiO2 catalyst in the hydrogenation of
nitrobenzene in water and improvement in its stability by
coating a layer of hydrophobic carbon, J. Catal., 2012, 291,
149–154.
6 Y. N. Wang, X. P. Duan, J. W. Zheng, H. Q. Lin, Y. Z. Yuan,
H. Ariga, S. Takakusagi and K. Asakura, Remarkable
enhancement of Cu catalyst activity in hydrogenation of
dimethyl oxalate to ethylene glycol using gold, Catal. Sci.
Technol., 2012, 2(8), 1637–1639.
7 C. Wen, Y. Y. Cui, A. Y. Yin, K. N. Fan and W. L. Dai,
Remarkable improvement of catalytic performance for a
new cobalt-decorated Cu/HMS catalyst in the hydrogenation
of dimethyloxalate, ChemCatChem, 2013, 5(1), 138–141.
8 Y. F. Zhu, X. Kong, X. Q. Li, G. Q. Ding, Y. L. Zhu and
Y. W. Li, Cu nanoparticles inlaid mesoporous Al2O3 as a
high-performance bifunctional catalyst for ethanol synth-
esis via dimethyl oxalate hydrogenation, ACS Catal., 2014,
4(10), 3612–3620.
9 S. H. Zhu, X. Q. Gao, Y. L. Zhu, W. B. Fan, J. G. Wang and
Y. W. Li, A highly efficient and robust Cu/SiO2 catalyst
prepared by the ammonia evaporation hydrothermal
method for glycerol hydrogenolysis to 1,2-propanediol,
Catal. Sci. Technol., 2015, 5(2), 1169–1180.
4. Conclusion
In this study, the effect of the ZnO/SiO2 ratio on the water-tolerant
hydrogenation of Cu/SiO2 and Cu/ZnO catalysts was explored by
ethyl acetate hydrogenation under reaction conditions with
impure water. For the Cu/SiO2 catalyst, the proper addition of
ZnO can decrease the reaction temperature without sacrificing
conversion, but the stability rapidly decreases as the ZnO content
increases. This occurred because the catalyst particles were easy to
sinter in the reaction due to the addition of ZnO. For the Cu/ZnO
catalyst, which had 95% conversion of hydrogenation at relatively
low reaction temperature, obvious agglomeration was found after
the reaction. The addition of a small amount of silica (5 wt%)
onto the Cu/ZnO catalyst acted as a partition, and it effectively
hindered the agglomeration of Cu/ZnO catalyst particles. However,
the addition of excess SiO2 resulted in the Cu/ZnO catalyst
producing effects similar to those that were caused by the
addition of excess ZnO for the Cu/SiO2 catalyst. Therefore, the
appropriate addition of ZnO had a positive effect on the Cu/SiO2
catalyst. Similarly, the positive effect can also be observed for
the Cu/ZnO catalyst due to the appropriate addition of SiO2.
10 M. M. J. Li, J. W. Zheng, J. Qu, F. L. Liao, E. Raine,
W. C. H. Kuo, S. S. Su, P. Po, Y. Z. Yuan and S. C. E. Tsang,
The remarkable activity and stability of a highly dispersive
beta-brass Cu–Zn catalyst for the production of ethylene
glycol, Sci. Rep., 2016, 6, 8.
11 J. Ding, Y. Liu, J. Zhang, K. Liu, H. Xiao, F. Kong, Y. Sun and
J. Chen, Excellent performance in hydrogenation of esters
over Cu/ZrO2 catalyst prepared by bio-derived salicylic acid,
Catal. Sci. Technol., 2016, 6(19), 7220–7230.
Conflicts of interest
The authors declare no competing financial interests.
Acknowledgements
This work was supported by the National Natural Science
Foundation of China (Grant No. 21673272, No. 21603257, and
No. 21503256), the Chinese Academy of Sciences Strategic Pilot
Science and Technology Special (Class A) (XDA21020000), and
the autonomous research project of the State Key Laboratory of
Coal Conversion (SKLCC 2018BWZ001).
12 Y. Zhao, X. Wu, J. Zhou, Y. Wang, S. Wang and X. Ma, MOF-
derived Cu@C catalyst for the liquid-phase hydrogenation
of esters, Chem. Lett., 2018, 47(7), 883–886.
