[(FeIII(OH2)2)3(A-r-PW9O34)2]9- on Cationic Silica Nanoparticles, a New Type of
Material and Efficient Heterogeneous Catalyst for Aerobic Oxidations
Nelya M. Okun, Travis M. Anderson, and Craig L. Hill*
Department of Chemistry, Emory UniVersity, Atlanta, Georgia 30322
Received April 29, 2002 ; E-mail: chill@emory.edu
The development of materials that catalyze selective O2/air-based
oxidations under mild conditions are of both considerable intel-
lectual interest and potential utility. To date there are very few
molecules or materials that catalyze rapid air-based oxidations under
mild conditions.1 We report here the preparation and characteriza-
tion of a new type of material comprised of anionic metal oxygen
clusters (polyoxometalates or “POMs”)2 that are electrostatically
bound to cationic silica nanoparticles (henceforth “(Si/AlO2)n+.”).3
Figure 1. (A) Illustration of the electrostatic association of K81 monoanions
The binding of a new sandwich-type POM4 of formula, [(FeIII-
with the cationic surfaces of the (Si/AlO2)n+ nanoparticles. Compound 1 is
shown in combination polyhedral/ball-and-stick notation. The WO6 and PO4
(OH2)2)3(A-R-PW9O34)2]9- (1), to (Si/AlO2)n+ forms an active
heterogeneous catalyst, for selective O2 oxidations under mild
conditions that is actually more reactive than the same quantity of
the same POM catalyst in solution.
polyhedra are shaded gray and pink, respectively, and the Fe atoms and
the K+ cations are shaded orange and translucent purple, respectively. (B)
A TEM image of an average-sized (∼17 nm) particle of K81/(Si/AlO2) after
catalysis. The sizing bar is 10 nm in length. The dark spots of 1 are more
visible on the lighter background of the larger Si/AlO2 nanoparticle.
The POM, 1, is prepared by the reaction of (A-Na8HPW9O34)5
and Fe(NO3)3 in water, and the K+ salt readily produces both ana-
lytically pure bulk samples and diffraction quality crystals.6 The
X-ray structure of 1 shows it to be an A-type sandwich POM of
approximate D3h symmetry.7,8 The charge on 1 was inferred from
the number of K+ counterions determined by both elemental anal-
ysis and X-ray crystallography. Bond-valence-sum calculations indi-
cate the three central metals in 1 are ferric ions. It is a trivalent
is consistent with ∼58 K81 monoanions per nanoparticle (loss of
one K+ per POM unit).9 Third, the relative sizes of 1 from X-ray
crystallography and the average K81/(Si/AlO2) particle from DLS
are also consistent with an approximate single layer of 1 on the
surface of each nanoparticle. Fourth, high-resolution TEM confirms
the diameter of the average K81/(Si/AlO2) particle from DLS (∼17
nm). Fifth, the TEM of the K81/(Si/AlO2) particles shows the
electrostatically bound electron-dense W-based POMs as dark spots;
the reactant (Si/AlO2)Cl particles show no such spots. The photo-
micrographs all show some spots the size of individual POMs and
larger spots consistent with some POMs that are proximal or on
top of one another on a surface that is rough and also one that has
a nonuniform distribution of cationic surface sites as per the manu-
facturer’s specifications (Figure 1B).3 Catalysis does not change
the appearance of the TEM images.
structural analogue of the POMs of formula, [MII (A-R-PW9O34)2]12-
,
A
3
where M ) MnII, FeII, NiII, CuII, and ZnII, reported by Knoth.4b,c
thermal ellipsoid plot (Figure S1) and all the structural data on the
K+ salt of 1 (K91) (R1 ) 4.19%) are given in the Supporting
Information.
Whereas the anionic POMs do not bind strongly to conventional
negatively charged or neutral silicas (POMs are displaced from most
silicas upon simple washing with conventional solvents), they do
bind very strongly to cationic (Si/AlO2)n+ nanoparticles. Simply
stirring aqueous solutions of the POMs with aqueous suspensions
of (Si/AlO2)Cl produces POM-bound nanoparticles.9 In the case
of 1, five lines of evidence are consistent with the chemistry and
stoichiometry in eq 1 for this process. Namely, there is a loss, on
average, of one of the nine cations of the POM (K91) upon binding
to the (Si/AlO2)n+ nanoparticles, and the POMs form an approx-
imate single layer of K81 monoanions on the surface of each nano-
particle. This translates to an average formula of {K8[(FeIII(OH2)2)3-
(PW9O34)2]}58(Si/AlO2) (henceforth K81/(Si/AlO2)) with an average
diameter of 17 nm. Figure 1A depicts this association, with 1 shown
in combination polyhedral/ball-and-stick notation.
This new type of material, K81/(Si/AlO2), is an active catalyst
for the aerobic oxygenation of sulfides and the autoxidation of
aldehydes (see Supporting Information, part S6), eqs 2 and 3.
R2S + 0.5 O2 w R2SO
(2)
(3)
RCHO + 0.5 O2 w RCOOH
Both reactions proceed rapidly using ambient air as the oxidant at
25 or 75 °C for CH3CHO or THT, respectively. Significantly, an
equimolar quantity of 1 alone, either in the same solution (CH3-
CN) or as a powder, is totally or nearly inactive catalytically.
Aerobic sulfide oxidation in the presence of metal complexes rarely
if ever proceeds by autoxidation. The marked catalysis of eq 2
(studied most extensively where R2S ) tetrahydrothiophene,
“THT”) by K81/(Si/AlO2) (Table 1) coupled with the lack of activity
of 1 dissolved in the same medium (which, in principle, represents
the highest possible total POM “surface area”) argues for some
sort of POM activation upon binding to the particles. An induction
period in the THT-O2-K81/(Si/AlO2) system indicates the initial
K81/(Si/AlO2) is a precatalyst (see Supporting Information, part
S7).11 Typically, the two molecular catalysis parameters, turnover
number and tunover frequency, are not used for heterogeneous cata-
lytic processes because the effective concentration of active sites
58 K91 + (Si/AlO2)Cl w
{K8[(FeIII(OH2)2)3(PW9O34)2]}58(Si/AlO2) + 58 KCl (1)
The first line of evidence for this formulation is dynamic laser
light scattering (DLS) which shows the average diameter of the
initial (Si/AlO2)Cl particles is 12 nm (surface area 227 m2 g-1),
while that of the product K81/(Si/AlO2) particles is 17 nm (160 m2
g-1) (see Supporting Information) as would be roughly expected if
an approximate single layer of K81 monoanions surrounds each
polycationic (Si/AlO2)n+ particle.10 Second, the elemental analysis
9
3194
J. AM. CHEM. SOC. 2003, 125, 3194-3195
10.1021/ja0267223 CCC: $25.00 © 2003 American Chemical Society

C O M M U N I C A T I O N S
Table 1. Selective Catalytic Aerobic Oxidation of
Tetrahydrothiophene to Tetrahydrothiophene Oxide (THTO) under
Ambient Conditionsa
