Synthesis and antiangiogenic activity of exo-olefinated deoxoartemisinin derivatives

Article abstract of DOI:10.1016/j.bmcl.2004.05.013

10-exo-Bromoalkylidene and benzylidene deoxoartemisinin derivatives with antiangiogenic activity were synthesized from corresponding 10-alkanesulfonyl dihydroartemisinin and 10-phenylmethanesulfonyl dihydroartemisinin using a highly efficient, mild, and s

Full text of DOI:10.1016/j.bmcl.2004.05.013

Bioorganic & Medicinal Chemistry Letters 14 (2004) 3683–3686
Synthesis and antiangiogenic activity of exo-olefinated
deoxoartemisinin derivatives
Sangtae Oh,a In Howa Jeong,a Woon-Seob Shinb,* and Seokjoon Leec,*
aDepartment of Chemistry, Yonsei University, Wonju 220-710, South Korea
bDepartment of Microbiology, Kwandong University College of Medicine, Gangneung 210-701, South Korea
cDepartment of Basic Science, Kwandong University College of Medicine, Nategok-dong 522, Gangneung 210-701, South Korea
Received 9 April 2004; revised 29 April 2004; accepted 10 May 2004
Available online 2 June 2004
Abstract—10-exo-Bromoalkylidene and benzylidene deoxoartemisinin derivatives with antiangiogenic activity were synthesized
from corresponding 10-alkanesulfonyl dihydroartemisinin and 10-phenylmethanesulfonyl dihydroartemisinin using a highly effi-
€
cient, mild, and simple Ramberg–Backlund rearrangement.
ꢀ 2004 Elsevier Ltd. All rights reserved.
Angiogenesis, the formation of new blood vessels from
existing host capillaries stimulated by biochemical
stimulators, plays a key role in the growth of the solid
tumors, their invasion, and metastasis.1 Therefore, the
control of angiogenesis may be a promising therapeutic
strategy for the related diseases.2
come a potential lead compound in the development of
antimalarial8 and recently anticancer agents.9
However, to search for novel types of artemisinin ana-
logues with a high antiangiogenic activity and synthetic
effectiveness, we decide to synthesize the C-10 exo-olef-
inated deoxoartemisinin derivatives (4) by using the
€
Because of bioavailability, biostability, and effectiveness
of endogenous antiangiogenic proteins, it is very
important to discover the antiangiogenic small mole-
cules that might be suitable as clinical therapies.3
Ramberg–Backlund rearrangement of S-glycoside for 1-
exo-methylene glycal (Fig. 1).10
In the course to discover small molecular angiogenesis
inhibitors from natural lead compounds, we had re-
ported that coronarin A4 and artemisinin (1) deriva-
tives5 have an antiangiogenic activity. In particular,
thioacetal artemisinin derivatives (3) have a strong
effect.5 Recently, Chen and co-workers reported that
artemisinin (1), dihydroartemisinin (2), and artesunate
have the antiangiogenic activity as well as the antitumor
activity on in vitro models of angiogenesis.6
15
H
4
5
2
H
6
3
O
O
O
7
8
5a
8a
1
14
O
O
O
12
H
H
9
O
O
10
16
OH
H
O
1
2
H
The natural sesquiterpene endoperoxide artemisinin (1),
which was isolated from Artemisia annua L.,7 has be-
O
O
O
O
O
O
H
H
O
O
17
R
n= 0, 2
n(O)S
18
19
R
R
Keywords: Angiogenesis; Antiangiogenesis; Artemisinin; exo-Olefi-
nated deoxoartemisinin.
3
4
* Corresponding authors. Tel.: +82-33-649-7454; fax: +82-33-641-10-
74; e-mail: sjlee@kwandong.ac.kr
Figure 1.
0960-894X/$ - see front matter ꢀ 2004 Elsevier Ltd. All rights reserved.
doi:10.1016/j.bmcl.2004.05.013

3684
S. Oh et al. / Bioorg. Med. Chem. Lett. 14 (2004) 3683–3686
H
H
H
O
O
O
O
CF2Br2, KOH/Al2O3
O
UHP, TFAA
O
t-BuOH, MC, 5oC to rt
O
O
H
O
NaHCO3
O
-30oC
H
H
O
O
R2
R3
O2S
S
R1
R1
9a - 9e
Thiol, MC
BF3Et2O
5a - 5e
7a - 7e
2
+
E-9a R2: H, R3: Br
r. t.
Z-9a R2: Br, R3: H
H
H
E-9b R2: CH3, R3: Br
Z-9b R2: Br, R3: CH3
E-9c R2: Propyl, R3: Br
Z-9c R2: Br, R3: Propyl
9d R2: CH3, R3: CH3
E-9e R2: H, R3: Phenyl
Z-9e R2: Phenyl, R3: H
O
O
O
O
UHP, TFAA
O
O
a: methyl
b: ethyl
NaHCO3
-30oC
H
H
O
O
c: n-butyl
d: isopropyl
e: benzyl
S
O2S
R1
6a - 6e
R1
8a - 8e
€
Scheme 1. Synthesis of exo-olefinated deoxoartemisinin derivatives by Ramberg–Backlund rearrangement: 9a (E:Z ¼ 50:50, 74%), 9b (E:Z ¼ 84:16,
76%), 9c (E:Z ¼ 92:8, 44%), 9d (26%), 9e (E:Z ¼ 70:30, 78%).
Herein, based on the screening of formation assay of
HUVEC tube on Matrigel and Chorioallantomic
membrane (CAM) assay as well as growth inhibition
activity against HUVEC, we report that C-10 exo-olef-
inated deoxoartemisinin derivatives (4) effectively inhibit
the growth of HUVEC and these molecules are noble
promising antiangiogenic agents.
10-(1-bromoethylidene) deoxoartemisinin (9b) (76%
yield, E:Z ¼ 84:16) and 10-(1-bromobutylidene) deoxo-
artemisinin (9c) with a high stereoselectivity (84%
yield, E:Z ¼ 92:8), which is a very rare case that the
bromo-olefinated products could be synthesized from
€
alkanesulfonyl reactants by a Ramberg–Backlund rear-
rangement.
As shown in Scheme 1, the reaction of dihydroartemis-
inin (2) with the corresponding thiol reactants11 in the
presence of BF3Et2O gave a separable mixture of major
thioacetal dihydroartemisinin (5a–e) with a C-10a ste-
reochemistry, and minor C-10b diastereomers (6a–e),
respectively,12 which were transformed to produce the
corresponding 10a-substituted sulfonyl dihydroartemis-
inin (7a–e) and 10b derivatives (8a–e) by oxidation13
with H2O2/urea (UHP), trifluoroacetic anhydride
(TFAA), and NaHCO3 as high yield.14
In the case of the secondary alkane substituted sulfonyl
dihydroartemisinin (7d), 10-isopropylidene deoxo-
artemisinin (9d) was obtained in a very low yield (26%)
due to steric hindrance of the isopropyl group.
Unlike the alkane sulfonyl reactants (7a–d), the 10a-
phenylmethanesulfonyl dihydroartemisinin (7e) with an
aromatic sulfonyl group gave separable E- and Z-iso-
mers of the 10-benzylidene deoxoartemisinin (9e) with
no bromide in a 78% yield (E:Z ¼ 70:30). The stereo-
chemistry of E-9e and Z-9e was determined by com-
paring each chemical shift of H-17 (6.43 ppm for E and
5.45 ppm for Z) and H-9 (3.45 ppm for E and 3.33 ppm
for Z) of the two isomers.14;17
To obtain exo-olefinated deoxoartemisinin derivatives
€
(4), we used modified Ramberg–Backlund rearrange-
ment conditions.15 The reaction between 10a-metha-
nesulfonyl dihydroartemisinin (7a) and CF2Br2, and
KOH/Al2O3 in t-BuOH and methylene chloride (2:1) at
room temperature gave an inseparable E and Z mixture
of 10-bromomethylene deoxoartemisinin (9a) in the
same ratio.16 Under the same reaction conditions, two
10a-alkanesulfonyl dihydroartemisinin 7b and 7c stereo-
selectively produced a separable E and Z mixture of
To investigate the antiangiogenic activity of C-10 exo-
olefinated deoxoartemisinin derivatives (9a–e), they
were examined on a HUVEC proliferation assay using
the MTT colorimetric method,18 tube formation assay
on Matrigel19 and CAM assay.20 These results were lis-
ted in Table 1.
Table 1. Antiangiogenic activity of C-10 exo-olefinated deoxoartemisinin derivatives
Compounds
Growth inhibition IC50 (lg/mL)a
Tube formation inhibition at 10 lg/mL (%)
CAM assay at 10 lg/egg (%)
E/Z mixture of 9a
4.8
4.5
25.4
1.5
1.9
2.3
1.9
2.3
25
65
32
39
10
13
10
10
80
50
43
57
8
E-9b
Z-9b
E-9c
Z-9c
9d
29
10
5
E-9e
Z-9e
