Chiroptical properties and the racemization of pyrene and tetrathiafulvalene-Substituted allene: Substitution and solvent effects on racemization in tetrathiafulvalenylallene

Article abstract of DOI:10.3390/molecules19032829

Dissymmetric 1,3-diphenylallene derivative 3 connected with 4,5-bis(methylthio) tetrathiafulvalenyl and 1-pyrenyl substituents was prepared and characterized. The molecular structure was determined by X-ray crystallographic analysis. Optical resolution wa

Full text of DOI:10.3390/molecules19032829

Molecules 2014, 19, 2829-2841; doi:10.3390/molecules19032829
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Chiroptical Properties and the Racemization of Pyrene and
Tetrathiafulvalene-Substituted Allene: Substitution and Solvent
Effects on Racemization in Tetrathiafulvalenylallene
Masashi Hasegawa *, Seiya Iwata, Yasuto Sone, Junta Endo, Hideyo Matsuzawa and
Yasuhiro Mazaki *
Department of Chemistry, School of Science, Kitasato University, Sagamihara,
Kanagawa 252-0373, Japan
* Authors to whom correspondence should be addressed; E-Mails: masasi.h@ktiasto-u.ac.jp (M.H.);
mazaki@kitastao-u.ac.jp (Y.M.); Tel.: +81-427-78-8158 (M.H. & Y.M.);
Fax: +81-427-78-9961 (M.H. & Y.M.).
Received: 21 January 2014; in revised form: 21 February 2014 / Accepted: 23 February 2014 /
Published: 4 March 2014
Abstract: Dissymmetric 1,3-diphenylallene derivative 3 connected with 4,5-bis(methyl-
thio)tetrathiafulvalenyl and 1-pyrenyl substituents was prepared and characterized. The
molecular structure was determined by X-ray crystallographic analysis. Optical resolution
was accomplished using a recycling chiral HPLC, and its chiroptical properties were
examined with optical rotation and electronic circular dichroism (ECD) spectra. The title
compound underwent photoracemization under daylight. This behavior was investigated in
various solvents and compared with that of 1,3-bis(tetrathiafulvalenyl)allene (bis-TTF-
allene) derivative 2. The first-order rate plot of the intensity of the ECD spectra at a given
time interval gave the rate of racemization. Mild racemization was observed in polar
solvents, whereas a relatively fast rate was obtained in less polar solvents. In addition, the
TTF groups of the allene also accelerate the racemization rate. These results suggest that
the racemization mechanism occurs via a non-polar diradical structure.
Keywords: axis chirality; allene; tetrathiafulvalene; electronic circular dichroism; racemization

Molecules 2014, 19
2830
1. Introduction
Substituted allenes with axial chirality have been extensively studied as a class of chiral building
blocks that are useful precursors for chirality transfer reactions, pharmaceutical agents, and materials
possessing chiroptical properties [1–6]. Their definitive chirality imparts strong, reliable chiral effects
in enantiocontrolled organic reactions and in polarized light-related optical properties. The axial
chirality in the allene framework is defined by the substituents. When the combination of substituents
is R1 ≠ R2 and R3 ≠ R4, allene 1 must be chiral (Figure 1). Typically, the chiral allene with substituents
are stable toward racemization under ordinary circumstances because the rotation barrier of the allenic
C=C=C bond is typically very large (ΔG‡ = 180 kJ/mol for 1,3-dimethylallenes) [7,8]. Therefore, while
the racemization reaction occurs only under harsh conditions, such as irradiation by strong light,
prolonged heating at very high temperatures, or addition of metal catalyst, chiral allenes are ordinarily
obtained as chiral-persistent separable isomers after optical resolution or asymmetric synthesis [9–16].
Figure 1. Allenes 1–3.
Normally, π-conjugation decreases the racemization barrier; thus, some allenes with aryl or olefinic
substituents are occasionally susceptible to racemization under mild conditions. Previously, Diederich
and co-workers reported that certain chiral 1,3-diethynylallenes containing 4-N,N-dimethylanilyno
(DMA) groups exhibited racemization in the presence of daylight [17]. This reactivity presumably
stems from the electron donating ability of the terminal DMA groups. They also found that the
photoisomerization in the shape-persistent macrocycles occurred on a chiral allene-ethynylene
scaffold. In this case, the installed anthracene moieties may act as intramolecular sensitizers toward
photoracemization [18]. More recently, we have developed 1,3-diphenyl-1,3-bis(tetrathiafulvalenyl)allene
(2, Figure 1) and its derivatives as a new class of materials that have electrochromic chiroptical
properties during their redox reaction. In the aforementioned system, the terminal tetrathiafulvalenes
(TTFs) are effectively conjugated to the central allene, and this conjugation results in intensive
chiroptical properties that show Cotton effect in the electronic circular dichroism (ECD) spectra
depending on the redox state of each molecule [19]. However, allene 2 showed slow racemization in
solution under daylight, whereas optical resolution by HPLC on a chiral stationary phase gave good
separation of each enantiomer.
Many experiments and computational studies of the ground state and the excited state of a simple
allene have been carefully executed in connection with the mechanistic investigation of the
racemization reaction, the generation of a reactive carbene species, and the interactions within coherent
laser light, among others [20,21]. Until now, the racemization mechanism of simple allenes with

Molecules 2014, 19
2831
aliphatic substituents has been considered a process involving a planar triplet excited state of an ally
diradical character after photosensitization of the solvent molecules [22]. Although a chiral allene installed
into the rigid π-framework has great potential as a chiral source for versatile applications, a comprehensive
understanding of the nature of racemization in aryl-substituted allenes has not been achieved.
To obtain further insight regarding chiral stability and the photoracemization reaction in chiral
allenes installed into a large π-conjugation system, we have now designed a hetero-substituted allene,
(R)/(S)-3 (Figure 1) where the TTF and pyrene are connected at the 1 and 3 positions of the allene,
respectively. Unlike compound 2, replacing TTF into the pyrene unit may affect the stability of the
axial chirality. Herein, we report the synthesis, structure, and chiroptical properties of 3. Furthermore,
the photoracemization reaction of 2 and 3 under daylight in various solvents has also been examined,
and the rates of the racemization reaction were analyzed.
2. Results and Discussion
2.1. Synthesis of Pyrene and Tetrathiafulvalene-substituted Allene 3 and X-ray Determination
An efficient route to connect the TTF moiety into the allenic framework was established by a
palladium-catalyzed cross-coupling reaction as shown in Scheme 1 [23,24]. Starting with ketone 4,
prepared by Friedel-Crafts acylation of pyrene, the reaction with the lithiated acetylide of
phenylacetylene in THF at low temperature afforded propargyl alcohol 5 quantitatively. The treatment
of acetic anhydride with 5 in the presence of a catalytic amount of N,N-dimethyl-4-aminopyridine
(DMAP) yielded acetyl ester 6 in 98% yield. Finally, addition of the organozinc intermediate derived
from 4,5-bis(methylthio)tetrathiafulvalene (BMT-TTF) [25] into a mixture of 6 and palladium catalyst
with PPh3 provided the allene compound 3 in moderate yield (65%). Compound 3 was fully
characterized by 1H-, 13C-NMR, IR, MS, and elemental analysis. The chemical shift of 3 in 13C-NMR
spectrum was found to be 208.2 ppm, suggesting a typical linear allenic framework. The vibrational
stretching frequency of C=C=C was observed at 1919 cm−1 in the FT-IR spectrum, and it is also
inconsistent with the bent structure.
Scheme 1. Synthesis of 3.
Recrystallization of 3 from a CHCl3-hexane solution at 4 °C gave single crystals suitable for X-ray
analysis. The molecular structure is shown in Figure 2. Compound 3 crystalizes with CHCl3 molecules
in a triclinic system, space group P–1, and the unit cell contains two types of 3 (A and B in Figure 2a).
Both molecular structures exhibit a typical allenic structure. The central C=C=C moiety is essentially
linear (C(1a)–C(2a)–C(3a) = 173.5(5)° and C(1b)–C(2b)–C(3b) = 171.5(5)°). The dihedral angles of

Molecules 2014, 19
2832
BMT-TTF against the central allene were found to be 21.4(6)° (for S(1a)–C(4a)–C(1a)–C(2a) in
molecule A) and 21.6(6)° (for S(1b)–C(4b)–C(1b)–C(2b) in molecule B), whereas those of the
pyrenyl groups were almost perpendicular to the central allene, whose dihedral angles were 89.26(6)°
(for C(25a)–C(12a)–C(3a)–C(2a)) and 93.8(6)° (for C(25b)–C(12b)–C(3b)–C(2b)), respectively.
Conversely, the dihedral angles of the two phenyl rings that are directly connected with the allenic
skeleton were 46.0 (ring a) and 5.4° (ring b) for molecule A, and 49.8 (ring a) and 8.41° (ring b) for
molecule B. Thus, the BMT-TTF moiety can reasonably conjugate to the central allene, while the
pyrenyl group on the same side (ring a in Figure 2) is nearly perpendicular to the allene C=C bond. In
the packing motif, each of the BMT-TTF parts dimerized in a face-to-face fashion with the equivalent
part of the other enantiomer (Figure 2b). Several shorter distances within the sum of the van der Waals
radii were found through S•••S and π-π interactions. Although the pyrenyl moiety also formed a
dimeric motif in the crystal lattice, no intermolecular contacts were found between the parts.
Figure 2. (a) ORTEP drawing of 3. (b) Packing diagram of 3. For clarity, the phenyl
groups and the other atoms are displayed as the wireframe and the ball and stick model,
respectively. Lines indicate selected intermolecular interactions. (i) S(1a)•••S(2a)1 3.527 Å
(1 = −x, 2−y, 1−z); (ii) C(6a)•••C(6a)1 3.316 Å; (iii) S(1b)•••S(2b)2 3.482 Å (2 = 1−x, 2−y,
−z); iv) C(6b)•••C(6b)2 3.247 Å; v) S(2b)•••C(6b)2 3.466 Å.
2.2. Electrochemical Properties
The redox potentials obtained from the cyclic voltammetry (CV) analyses of 3 and its related
compounds are summarized in Table 1. In the cyclic voltammogram of 3, two reversible redox waves
of E11/2 = 0.00 and E21/2 = 0.33 V (vs. Fc/Fc+) were observed within a range of −0.3–0.7 V (Figure 3a).
Both redox waves are assigned to one-electron transfers for the successive formation of 3•+ to 32+.
Because these redox potentials are comparable to those of BMT-TTF 7, the first and second oxidations
correspond to the oxidation of the BMT-TTF fragment of 3. The cyclic voltammogram of 3 exhibited
two additional peaks when the scanning was performed with a wider potential range. Thus, the Epa3 of
0.92 V with anodic current and the Epc3 of 0.31 V with cathodic current were found as a pair of
semi-reversible peaks. Compared with the CV of pyrene, these characteristic redox peaks can be
assigned to the redox of the pyrene unit in 3.

Molecules 2014, 19
2833
Table 1. Redox potentials of 3 and its related compounds a.
1/2
1/2
Compound
E1
E2
Epa3
Epc3
3
7
0.00
0.33
0.34
0.92 b
0.31 b,c
−0.02
pyrene
0.92 b
0.33 b,c
a In CH2Cl2 containing 0.1 MnBu4NClO4 using a Pt working electrode and counter electrodes. The potentials
b
were measured against an Ag/Ag+ electrode and converted to the value vs. Fc/Fc+. Semi-reversible redox
wave. c Shoulder peak.
Figure 3. CV chart of (a) 3 (gray line: scan range −0.3 to 0.7 V; black line: scan range
−0.3 to 1.2 V) and (b) pyrene.
2.3. Optical Resolution and ECD Spectra
The elution of racemic 3 with a hexane-CHCl3-EtOH solution (v/v = 40:10:0.2) on the chiral
stationary phase (DAICEL Chiralpak IA-3) using a recycling chiral HPLC method efficiently provided
optically active 3. The resulting enantiomeric compounds (+)-3 and (−)-3 showed optical rotations of
[α]D24 = +267 (c =0.0018) and −267 (c = 0.0015), respectively. To avoid racemization under light, the
enantiomeric compounds were treated in the dark.
Figure 4 shows the electronic circular dichroism (ECD) spectra of the (+)-3 and (−)-3 isomers
recorded in a hexane-CHCl3-EtOH solution (v/v = 40:10:0.2) as well as the absorption spectra of 3 and
its related compounds in CHCl3. The UV-Vis absorption spectra of 3 in a CHCl3-hexane solution
exhibit four absorption maxima at 268, 278, 332, and 348 nm with a shoulder absorption at 405 nm.
From the spectra of 7 and pyrene, the four characteristic maxima observed in 3 can be assigned to the
electronic transitions of the pyrenyl group on the allene, whereas the shoulder absorption can be
attributed to the electronic transition of the BMT-TTF moiety. The ECD spectra of the (+)-3 and (−)-3
enantiomers exhibited mirror images with whose trend lines that appeared over the entire absorption
range. An intensive Cotton effect was found at approximately 350 nm with long shoulder band tails up
to approximately 450 nm, and the sign observed near 350 nm could be associated with the transition of
the pyrenyl moieties. A positive sign from the first Cotton effect was observed in (+)-3, while a
negative sign was observed from the first Cotton effect in (−)-3.

Molecules 2014, 19
Figure 4. (a) UV-Vis spectra of 3 and its related compounds (b) ECD spectra of (R)-(+)-3
2834
and (S)-(−)-3 together with the simulated ECD spectrum of (R)-3 using a CAM-TD-DFT
(CAM-B3LYP/6-311G(d,p)//B3LYP/6-31G(d,p)) calculation. The grey bars of S1–S4
indicate the selected rotational strength.
To the validation of the absolute configuration of (+)/(−)-3, a theoretical simulation of the electronic
transition energies and rotational strengths was carried out by the employing time-depended Coulomb-
attenuating density functional theory (TD-CAM-B3LYP/6-311G(d,p)) method following geometry
optimization at the B3LYP/6-31G(d,p) level [26,27]. The optimized molecular geometry resembled the
molecular structure observed in X-ray analysis: the pyrenyl group connects with the central allene
almost perpendicularly, while the BMT-TTF moiety conjugates with the central allene. As shown in
Figure 4b, the simulated curvature of the (R)-configuration of 3 is qualitatively satisfactory to represent
the trend line of (+)-3 for the sign of the first Cotton effect. The strong positive sign at 340 nm was
calculated as the S2 transition that was associated with the mixing of electron transitions from the
HOMO (#178) to the LUMO (#179) and from the HOMO-1 (#177) to the LUMO (#179), where the
HOMO-1 and the LUMO mainly located at pyrenyl moiety (Figure 5). In addition, the electron
transition found as S1 (at 379 nm), which was attributed to the transition of TTF moiety, also slightly
found as the negative sign [28].
Figure 5. Molecular orbitals of 3.

Molecules 2014, 19
2835
2.4. Racemization of 2 and 3 in Various Solvents
As mentioned previously, an allene framework with axial chirality is occasionally vulnerable to
photoracemization at ambient temperature. The racemization behavior of 2 and 3 in various solvents
was investigated in the daylight. A narrow range was scanned to obtain the ellipticity of the ECD
spectra and the values were recorded in a quartz cell. Both 2 and 3 underwent photoracemization
without decomposition, while the ECD spectra showed virtually no change in the dark. Figure 6 shows
plots of the relative magnitude of ellipticity for 2 and 3 in various solvents at given time intervals.
For 2, relatively fast racemization proceeded in benzene and methylcyclohexane (MCH), while the
more polar CH2Cl2 and a mixture of CH2Cl2-CH3CN exhibited slower racemization at the same
concentration (0.5 M). Compound 3 also exhibited a similar behavior. Because these experiments were
carried out in distillated, degassed solvents, a unimolecular reaction was anticipated. Therefore, the
decrease in ellipticity can be analyzed as a first-order rate plot (Figure 6). Table 2 summarizes the
kinetic data that were obtained for 2 and 3 from these analyses in various solvents. For both 2 and 3,
the polar solvents suppressed the racemization rates. On the contrary, the less polar solvents, benzene
and MCH, greatly induced racemization rates. The rate of racemization for compound 3 in various
solvents exhibited a similar tendency. However, it is noteworthy that the lower racemization rate was
occurring in 3 rather than in 2, which was found in an identical solvent.
Figure 6. First-order rate plots for the intensity (at 355 nm) of the ECD spectra of (a) (R)-2
and (b) (R)-3 in benzene (circle and red line), MCH (plus and black line), CH2Cl2 (square
and orange line), CH2Cl2–MeCN (4:1) (triangle and green line), and CH2Cl2–MeCN (1:1)
(cross and blue line).
Table 2. Racemization rate of 2 and 3 in various solvent.
Compound
Solvent
Benzene
Rate (×10−3·min−1) Half-life (min)
22.8 ± 0.37
17.8 ± 0.26
12.1 ± 0.24
8.87 ± 0.08
7.18 ± 0.08
7.78 ± 0.01
5.91 ± 0.06
5.22 ± 0.04
30
39
MCH
2
CH2Cl2
57
CH2Cl2–MeCN (v/v = 4:1)
CH2Cl2–MeCN (v/v = 1:1)
Benzene
78
96
89
3
CH2Cl2
117
133
CH2Cl2–MeCN (v/v = 1:1)

Molecules 2014, 19
2836
A simple view of the photoisomerization of ethylenic double bonds (i.e., stilbene, 1,4-diphenyl-1,3-
butadiene, etc.) is illustrated by the reduction of the bond order upon electronic excitation, followed by
a twisting during the excited-state lifetime [29]. However, the detailed descriptions, even including
multiplicity, are still complicated. Various influences, such as polarity, friction, viscosity, and heavy-
atom effects of the solvent molecules, have been demonstrated in photoisomerization; however, it
varies with substituents. Although the detailed mechanism of the racemization of 2 and 3 is still
unclear, predominantly the solvent polarity rather than viscosity essentially affects to the rotation of
the allene. Accelerating the racemization rates by decreasing polarity may imply a certain contribution
of not dipolar but less polar character as exemplified by diradical species rather than dipolar species
having charge-transfer character in excited state. The kinetic rate in MCH, that cannot be a
photosensitizer, is comparable to that in benzene. It is also consistent with that supposition.
Additionally, the enhancement of racemization in 2 compared with 3 suggests that the electron
donating TTF moiety can act as a sensitizer to electronic excitation or as a stabilizer of the excited
states, which both lead to the fastest racemization.
3. Experimental
3.1. General Information
13
1H and
C-NMR spectra were recorded on Bruker AVANCE-III-400 (Bruker Corporation,
1
13
Billerica, MA, USA) (400 MHz for H, 100 MHz for C). Spectra are reported (in δ) referenced to
internal Me4Si. Mass spectra were recorded on Thermo Scientific, Exactive Plus Orbitrap Mass
Spectrometer (Thermo Fisher Scientific, Waltham, MA, USA) with atmospheric pressure chemical
ionization (APCI) probe. IR spectra were recorded on JASCO FT/IR-610 spectrometer (JASCO,
Hachioji, Japan). UV-Vis spectra were recorded on Hitachi U2800 spectrometer (Hitachi High-
Technologies Corporation, Tokyo, Japan) using quartz cell. Melting points were determined with
Yanaco melting point apparatus (Yanaco, Tokyo, Japan). Elemental analyses were performed on
Perkin Elmer PE 2400-II CHNA/O analyzer (Perkin Elmer, Waltham, MA, USA). Optical resolution
was carried out by recycling preparative HPLC (JAI Model LC-9204) (Daicel Corporation, Osaka,
Japan) equipped with Daicel CHIRALPAK-IA3 column (20 × 250 mm). The optical rotations were
measured with JASCO P-1300 spectropolarimeter (JASCO, Hachioji, Japan) in 1dm quartz cell at 24 °C.
Electronic circular dichrimism (ECD) spectra were recorded on JASCO J-725 spectrodichrometer
(JASCO, Hachioji, Japan). The spectra were combined after the baseline correction of each
measurement. Cyclic voltammetry (CV) measurements were performed on Hokuto Denko HZ-5000
electrochemical analyzer (Hokuto Denko, Tokyo, Japan). X-ray crystallographic analysis was
performed on Bruker SMART AXIS APEX-II (Bruker Corporation, Billerica, MA, USA). Column
chromatography was carried out using Kanto chemical silica gel 60N, 60–210 m meshes. All solvents
were dried by conventional procedures and distilled before use.
3.2. Synthesis of 1,3-Diphenyl-2-propyne-1-pyrenyl-1-ol 5
To a solution of 1-phenylethyne (2.15 mL, 19.6 mmol) in THF (45 mL) was added dropwise
n-C4H9Li (12.4 mL, 19.6 mmol) at 0 °C under an Ar atmosphere. After the mixture was stirred for 10 min,

Molecules 2014, 19
2837
a solution of benzoylpyrene 4 (5.00 g, 16.3 mmol) in THF (150 mL) was added. The reaction mixture
was stirred for 20 min at rt, and then poured into cracked ice. The product was extracted with CH2Cl2
and the resultant organic phase was washed with saturated brine and dried over MgSO4. Purification
by column chromatography on silica gel with CH2Cl2 as eluent afforded 5 (6.65 g, quant.): light yellow
powder; m.p.: 69.4–69.6 °C; MS (EI) m/z = 408 (M+); 1H-NMR (600 MHz, CDCl3) δ 8.68 (d, J = 7.8 Hz,
1H), 8.47 (d, J = 9.0 Hz, 1H), 8.17 (d, J = 9.0 Hz, 1H), 8.07–8.08 (m, 1H), 7.97–8.08 (m, 3H), 7.85–7.90
(m, 2H), 7.63–7.65 (m, 2H), 7.42–7.45 (m, 2H), 7.20–7.30 (m, 6H), 3.27 (s, 1H); 13C-NMR (150 MHz,
CDCl3) δ 145.6, 137.1, 132.0, 131.9, 131.5, 130.6, 128.9, 128.8, 128.6, 128.4 (2C), 128.0, 127.7,
127.04, 127.03, 126.3, 126.08, 126.07, 125.58, 125.56, 125.0, 124.7, 124.5, 122.8, 92.4, 88.8, 75.7; IR
(KBr) 3435, 3039, 2222, 1597, 1585, 1489, 1446 cm−1. Anal. Calcd for C31H20O: C, 91.15%; H,
4.94% Found: C, 90.84%; H, 4.71%.
3.3. Synthesis of 1,3-Diphenyl-2-propyne-1-pyrenylacetate (6)
To a solution of 5 (8.4 g, 21 mmol) and DMAP (250 mg, 2.0 mmol) in THF 40 mL was added
dropwise Ac2O (9.6 mL) at 0 °C under an Ar atmosphere. The mixture was allowed to warm up to rt
and stirred for over night. Then, the mixture was poured into iced water and the resulted white solid
was collected by filtration. The white solid was used for next step without further purification due to
instability of a solution of 6 (9.0 g, 98%): colorless solid; M.p. 169 °C (decomp.); MS (EI) m/z = 450
(M+); 1H-NMR (600 MHz, CDCl3)  8.75 (d, J = 8.1 Hz, 1H), 8.36 (d, J = 9.5 Hz, 1H), 8.24 (d, J = 8.1 Hz,
1H), 8.18 (dd, J = 7.5 and 1.1 Hz), 8.08–8.12 (m, 3H), 7.98 (t, J = 7.6 Hz, 1H), 7.90 (d, J = 9.5 Hz,
13
1H), 7.55–7.58 (m, 2H), 7.49–7.52 (m, 2H), 7.28–7.35 (m, 6H), 2.16 (s, 3H); C-NMR (150 MHz,
CDCl3)  168.5, 143.5, 134.4, 132.3, 132.2, 131.6, 130.6, 129.0, 128.7, 128.6, 128.2, 127.8, 127.4,
127.3, 127.2, 126.4, 126.2, 125.8, 125.64, 125.58, 125.1, 145.5, 122.9, 91.5, 89.1, 22.1; IR (KBr)
3053, 2226, 1741, 1597, 1587, 1489, 1365, 1230 cm−1; Anal. Calcd for C33H22O2: C, 87.98%; H,
4.92% Found: C, 87.54%; H, 4.85%.
3.4. Synthesis of the Allene 3
To a solution of 4,5-bis(methylthio)tetrathiafulvalene (394 mg, 1.3 mmol) in THF (8 mL) was added
dropwise n-C4H9Li (0.81 mL, 1.33 mmol) at −78 °C under an Ar atmosphere. After stirring for 1.5 h, a
suspension of anhydrous ZnCl2 (182 mg, 1.3 mmol), which was dried at 200 °C in vacuo for 3 h, in
THF 4 mL) was added dropwise into the mixture at −65 °C. The mixture was stirred for 2 h at the
same temperature, followed by warming up to −10 °C. Then, a solution of 6 (200 mg, 0.44 mmol),
Pd2(dba)3•CHCl3 (79 mg, 0.27 mmol), and PPh3 (79 mg, 0.27 mmol) in THF (4 mL) was added
dropwise at −10 °C, and the resulting mixture was further stirred for 14 h at rt. The mixture was
poured into saturated aqueous NH4Cl solution, and the products were extracted by CH2Cl2. The
resultant crude product was purified by column chromatography on silica gel with CH2Cl2/hexane
(v/v = 1) as the eluent. Recrystallization from CH2Cl2/hexane gave 1 as yellow crystals (200 mg, 65%):
1
M.p. 160–161 °C. MS (EI) m/z = 686 (M+); H-NMR (600 MHz, CDCl3)  8.25 (d, J = 7.8 Hz, 1H),
8.21 (dd, J = 7.8 and 1.2 Hz), 8.15 (d, J = 7.8 Hz), 8.12–8.16 (m, 3H), 8.09 (d, J = 8.8 Hz, 1H), 8.0 (t,
J = 7.5 Hz, 1H), 7.97 (d, J = 9.0 Hz, 1H), 7.43–7.45 (m, 2H), 7.34–7.39 (m, 3H), 7.24–7.33 (m, 5H),
13
6.13 (s, 1H), 2.44 (s, 3H), 2.41 (s, 3H); C-NMR (150 MHz, CDCl3)  208.2, 136.1, 134.5, 133.5,

Molecules 2014, 19
2838
131.33, 131.31, 131.0, 130.3, 129.5, 128.8 (2C), 128.77, 128.75 (2C), 128.4, 127.90, 127.87, 127.81,
127.77, 127.7, 127.6, 127.4, 126.1, 125.7, 125.34, 125.26, 125.09, 125.06, 124.7, 116.6, 111.7, 107.4,
106.8, 19.27, 19.24; UV-Vis (5.0 × 10−3 M, CHCl3): max () 268 (43200), 278 (45200), 332 (30700),
348 (33600), 405sh nm; IR (KBr) 3041, 2918, 1919, 1491, 1444 cm−1; Anal. Calcd for C39H26S6: C,
68.18%; H, 3.81% Found: C, 68.12%; H, 4.17%.
3.5. X-ray Crystallographic Study of 3
X-ray crystallographic measurement of 3 was made by using graphite-monochromated MoK
(λ = 0.71069 Å) radiation. The unit cell parameters and the diffraction intensities were collected with
Bruker SMART AXIS APEX-II at −100 °C. The crystal structure was solved by using SHELXS-97
and refined by using the full matrix least-squares method included in SHELXL-97. All non-hydrogen
atoms were refined anisotropically, and hydrogen atoms were refined isotropically. The crystal lattice
contains (R)-3 and (S)-3 together with two CHCl3 molecules in P-1 space group. Crystal data for 3:
2(C39H18S6)•2(CHCl3), Mr = 1612.65, Triclinic, P-1 (#2),  = 9.7195(8)Å, b = 15.5891(12) Å,
c = 24.0137(19) Å, = 92.685(1)°, = 15.5891(12)°, = 24.0196(1)°, V = 3599.7(5) Å3, Z = 2,
dcalc = 1.488 g/cm3, T = 173 K, R1 = 0.0737 (I > 2σ(I)), wR2 = 0.1848 (I > 2σ(I)), gof = 1.012.
CCDC 982197 contains the supplementary crystallographic data for this compound. The data
can be obtained free of charge from The Cambridge Crystallographic Data Centre via
www.ccdc.cam.ac.uk/data_request/cif.
3.6. Computational Details
All quantum chemical calculations were performed with the Gaussian 09 (Revision C.01) program.
The molecular structures of 3 was estimated by theoretical calculations at the RB3LYP/6-31G(d,p)
level, and its minimum energies were confirmed by frequency calculations. The standard orientation of
the optimized structures of 3 was summarized in Table S2. Excitation energy was computed using
Coulomb-attenuating density functional theory (CAM-TD–B3LYP) with 6-31G(d,p) basis set in
RB3LYP/6-31G(d,p) optimized geometry (nstate = 64).
4. Conclusions
Herein, we have described the synthesis and characterization of 1-[4,5-bis(methylthio)-
tetrathiafulvalenyl]-3-pyrenyl-1,3-diphenylallene (3) as a dissymmetric framework. X-ray analysis
indicated the effective conjugation of TTF with the central allene, whereas the pyrenyl group was
almost perpendicular. CV measurements revealed that 3 underwent two one-electron reversible redox
processes responsible for the oxidation of TTF and the successive one-electron semi-reversible redox
reaction facilitated by the pyrene unit. Optical resolution of the enantiomers was achieved using chiral
HPLC. The chiroptical properties were also investigated by ECD spectra, and the obtained spectra
enabled validation of their absolute configurations by TD-DFT calculations. Both optically pure
allenes of (+)/(−)-3 showed intensive Cotton effects in their ECD spectra over their entire absorption
range. The absolute configurations of the enantiomers were assigned the by validation of the electronic
transition energies calculated with TD-DFT method at the CAM-B3LYP/6-311G(d,p) level. The

Molecules 2014, 19
2839
photoracemization behaviors of (R)-2 and (R)-3 were examined under daylight using an analysis of the
relative magnitude of ellipticity in the ECD spectra at given time intervals. An increase in the reaction
rate with decreasing solvent polarity was observed, presumably because of the non-polar excited state
or intermediates. Furthermore, the number of TTF groups also affects quick racemization. The detailed
mechanism, especially the photoracemization dynamics by monochromated light irradiation is
currently being elucidated. We hope to use this information to design new, valuable π-extended
optically pure allenes without racemization under ambient conditions.
Supplementary Materials
Supplementary materials can be accessed at: http://www.mdpi.com/1420-3049/19/3/2829/s1.
Acknowledgments
We thank Takahiro Tsuchiya at Kitasato University for his helpful discussion. This work is
financially supported in part by the Daicel Chemical Industry Award from The Society of Synthetic
Organic Chemistry, Japan and by the Kitasato University Research Grant for young researchers. The
calculations were performed at the Research Centre for Computational Science, Okazaki, Japan.
Author Contributions
M.H. conceived the concept and design of study and wrote the article. S.I. and Y.S. synthesized and
characterized compounds. J.E. measured CD spectra and analyzed its data together with H.M. Final
approval of the article was given by Y.M.
Conflicts of Interest
The authors declare no conflict of interest.
References and Notes
1. Krause, N.; Hashimi, A.S.K. Modern Allene Chemistry; Wiley-VCH: Weinheim, Germany, 2004.
2. Hopf, H. Allenea and cumulenes. In Classics in Hyderocarbon Chemistry; Wiley-VCH:
Weinheim, Germany, 2000; pp. 171–196.
3. Yu, S.; Ma, S. How easy are the synthesis of allenes? Chem. Commun. 2011, 5384–5418.
4. Canary, J.W. Redox-triggered chiroptical molecular switches. Chem. Soc. Rev. 2009, 38, 747–756.
5. Rivera-Fuentes, P.; Diederich, F. Allenes in molecular materials. Angew. Chem. Int. Ed. 2012, 51,
2818–2828.
6. Campolo, D.; Gastaldi, S.; Roussel, C.; Bertrand, M.P.; Nechab, M. Axial-to-central chirality
transfer in cyclization processes. Chem. Soc. Rev. 2013, 42, 8434–8466.
7. Wolf, C. Racemization, enantiomerization, and diastereomerization. In Dynamic Stereochemsitry
of Chiral Compounds, Principles and Applications; RSC Publishing: Cambridge, UK, 2008;
pp. 29–135.
8. Roth, W.R.; Ruf, G.; Ford, P.W. Rotationsbarriere in 1,2-Dienen; Resonanzenergie des
Allyl-Radikals. Chem. Ber. 1974, 107, 48–52.

Molecules 2014, 19
2840
9. Roth, W.R.; Bastigkeit, T. Die Allen-Racemisierung, eine zweistufige Reaktion. Liebigs Ann.
1996, 1996, 2171–2183.
10. Schurig, V.; Keller, F.; Reich, S.; Fluck, M. Dynamic phenomena involving chiral dimethyl-2,3-
pentadienedioate in enantioselective gas chromatography and NMR spectroscopy. Tetrahedron:
Asymm. 1997, 8, 3475–3480.
11. Trapp, V.; Scurig, V. Novel direct access to enantimerization barriers from peak profiles in
enantioselective dynamic chromatography: Enantiomerization of dialkyl-1,3-allenedicarboxylates.
Chirality 2002, 14, 465–470.
12. Rodriguez, O.; Morrisonm, H. Photosensitized racemization of an optically active allene. J. Chem.
Soc. D Chem. Commun. 1971, 679.
13. Stierman, T.; Johnson, R.P. Cumulene photochemistry: Singlet and triplet photorearrangements of
1,2-cyclononadiene. J. Am. Chem. Soc. 1985, 107, 3971–3980.
14. Horváth, K.; Bäckvall, J.-E. Mild and efficient palladium(II)-catalyzed racemization of allenes.
Chem. Commun. 2004, 964–965, doi:10.1039/B316482A.
15. Claesson, A.; Olsson, L.-I. Chiral allenes are racemised by organocuprates. J. Chem. Soc. Chem.
Commun. 1979, 524–525, doi:10.1039/C39790000524.
16. Sherry, B.D.; Toste, F.D. Gold(I)-Catalyzed Propargyl Claisen Rearrangement. J. Am. Chem. Soc.
2004, 126, 15978–15979.
17. Alonso-Gómez, J.L.; Schanen, P.; Rivera-Fuentes, P.; Seiler, P.; Diederich, F. 1,3-Diethynylallenes
(DEAs): Enantioselective synthesis, absolute configuration, and chiral induction in 1,1,4,4-
tetracyanobuta-1,3-dienes (TCBDs). Chem. Eur. J. 2008, 14, 10564–10568.
18. Odermatt, S.; Alonso-Gómez, L.; Seiler, P.; Cid, M.M.; Diederich, F. Shape-persistent
chiral alleno-acetylenic macrocycles and cyclophanes by acetylenic scaffolding with
1,3-diethynylallenes. Angew. Chem. Int. Ed. 2005, 44, 5074–5078.
19. Hasegawa, M.; Sone, Y.; Iwata, S.; Matsuzawa, H.; Mazaki, Y. Tetrathiafulvalenylallene: A new
class of donor molecules having strong chiroptical properties in neutral and doped states.
Org. Lett. 2011, 13, 4688–4691.
20. Deretey, E.; Shapiro M.; Brumer, P. Chiral molecules with achiral excited states: A computational
study of 1,3-dimethylallene. J. Phys. Chem. A 2001, 105, 9509–9517.
21. Jarowski, P.D.; Diederich, F.; Houk, K.N. Butatrienes as extended alkenes: Barriers to internal
rotation and substitution effects on the stabilities of the ground states and transition states. J. Phys.
Chem. A 2006, 110, 7237–7246.
22. Drucker, C.S.; Toscano, V.G.; Weiss, R.G. A general method for the determination of steric effects
during collisional energy transfer. Partial photoresolution of penta-2,3-diene. J. Am. Chem. Soc.
1973, 95, 6482–6484.
23. Löhr, S.; Averbeck, J.; Schurmann, M.; Krause, N. Synthesis and complexation properties of
allenic bipyridines, a new class of axially chiral ligands for transition metal catalysis. Eur. J.
Inorg. Chem. 2008, 2008, 552–556.
24. Zelder, C.; Krause, N. Enantioselective synthesis and circular dichroism of endocyclic allenes.
Eur. J. Org. Chem. 2004, 2004, 3968–3971.

Molecules 2014, 19
2841
25. Hasegawa, M.; Daigoku, K.; Hashimoto, K.; Nishikawa, H.; Iyoda, M. Face-to-face dimeric
tetrathiafulvalenes and their cation radical and dication species as models of mixed valence and π-
dimer states. Bull. Chem. Soc. Jpn. 2012, 85, 51–60.
26. Frisch, M.J.; Trucks, G.W.; Schlegel, H.B.; Scuseria, G.E.; Robb, M.A.; Cheeseman, J.R.;
Scalmani, G.; Barone, V.; Mennucci, B.; Petersson, G.A.; et al. Gaussian 09, Revision C. 01;
Gaussian, Inc.: Wallingford, CT, USA, 2010.
27. Iikura, H.; Tsuneda, T.; Yanai, T.; Hirao, K. A long-range correction scheme for generalized-
gradient-approximation exchange functionals. J. Chem. Phys. 2001, 115, 3540–3544.
28. See Supporting Information.
29. Waldeck, D.H. Photoisomerization dynamics of stilbenes. Chem. Rev. 1991, 91, 415–438.
Sample Availability: Samples of the compounds 3 are available from the authors.
© 2014 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/3.0/).
