buffer three times on ice. Cells were subsequently treated with 50 mM glycine
to quench unreacted aldehydes, followed by 10 mM potassium cyanide and
5 mM aminotriazole in the cacodylate buffer for 20 min on ice to suppress
background. Photooxidation was performed using a Leica SPI II inverted
confocal microscope equipped with a 150-W xenon light source. Labeled
cells were located by epifluorescence and treated with a fresh solution of
diaminobenzidine (prepared by dissolving 5.4 mg diaminobenzidine in 1 mL
0.1 N HCl and diluting to 10 mL total volume using cacodylate buffer;
Sigma). A stream of oxygen gas was blown over the surface of the so-
lution and the cells were illuminated using a 562/40 filter (Semrock) at full
intensity for 10–20 min until a brown reaction product appeared. These illu-
mination conditions are much more intense than for live-cell imaging, such
that most fluorescence was photobleached after the 10- to 20-min treatment.
The cells were then rinsed in cold cacodylate buffer and postfixed with 1%
osmium tetroxide on ice. After rinses in cold water, cells were either stained
with 2% (wt/vol) aqueous uranyl acetate at 4 °C overnight en bloc or directly
dehydrated in cold ethanol series [20, 50, 70, 90, and 100% (vol/vol)] for 3 min
each on ice, followed by a room temperature rinse in 100% ethanol. Cells were
embedded in Durcupan ACM resin (Electron Microscopy Sciences). Standard
80-nm-thick sections were imaged using a JEOL 1200 EX transmission electron
microscope operated at 80 kV. Cells in Fig. 4B were treated with 1 μg/mL
colcemid (Sigma) for 4 h before addition of resorufin-AM2.
ACKNOWLEDGMENTS. Birka Hein [Max Planck Institute (MPI) for Biophysical
Chemistry] performed preliminary STED imaging experiments. Stefan Hell (MPI
for Biophysical Chemistry) provided experimental advice and performed
critical reading of the manuscript. Chayasith Uttamapinant [Massachusetts
Institute of Technology (MIT)] provided the coumarin compounds and the
LAP–β-actin, vimentin-LAP, LAP-MAP2, and HaloTag–β-actin plasmids. Caro-
lyn Kwa (MIT) and Ken Loh (MIT) provided assistance with neuron cultures.
Justin Cohen (MIT) and Samuel Thompson (MIT) provided LplA protein.
Katharine White (MIT) provided the LAP-CaaX, LAP-NLS, and LAP-NES plas-
mids. Michael Davidson (Florida State University) provided the mApple–
β-actin plasmid. We thank Kyle Gee (Life Technologies) for helpful discus-
sions about the resorufin fluorophore. Diffraction data were obtained at the
Advanced Photon Source on the Northeastern Collaborative Access Team
beamlines, which are supported by Award RR-15301 from the National Center
for Research Resources at the National Institutes of Health (NIH). Use of the
Advanced Photon Source, an Office of Science User Facility operated for the US
Department of Energy (DOE) Office of Science by Argonne National Labora-
tory, was supported by the US DOE under Contract DE-AC02-06CH11357.
This work was funded by NIH Grants DP1 OD003961 and R01 GM072670
(to A.Y.T.), NIH Grant GM103412 (to M.H.E.), and the American Chemical Soci-
ety (A.Y.T.). C.L.D. is a Howard Hughes Medical Institute (HHMI) Investigator.
L.G.N. acknowledges support from a National Science Foundation Minority
Post-Doctoral Fellowship. A.Z.Y. acknowledges support from the Lord Founda-
tion and the HHMI-Massachusetts Institute of Technology Summer Research
Program in Chemical Biology.
1. Moritz OL, Tam BM, Papermaster DS, Nakayama T (2001) A functional rhodopsin-
green fluorescent protein fusion protein localizes correctly in transgenic Xenopus
laevis retinal rods and is expressed in a time-dependent pattern. J Biol Chem 276(30):
28242–28251.
24. Brown PH, Cronan JE, Grøtli M, Beckett D (2004) The biotin repressor: Modulation of
allostery by corepressor analogs. J Mol Biol 337(4):857–869.
25. Reche PA (2000) Lipoylating and biotinylating enzymes contain a homologous cata-
lytic module. Protein Sci 9(10):1922–1929.
2. Marsh DR, Holmes KD, Dekaban GA, Weaver LC (2001) Distribution of an NMDA re-
ceptor:GFP fusion protein in sensory neurons is altered by a C-terminal construct.
J Neurochem 77(1):23–33.
3. van de Linde S, et al. (2013) Investigating cellular structures at the nanoscale with
organic fluorophores. Chem Biol 20(1):8–18.
4. Müller T, Schumann C, Kraegeloh A (2012) STED microscopy and its applications: New
insights into cellular processes on the nanoscale. ChemPhysChem 13(8):1986–2000.
5. Los GV, et al. (2008) HaloTag: A novel protein labeling technology for cell imaging
and protein analysis. ACS Chem Biol 3(6):373–382.
6. Keppler A, et al. (2003) A general method for the covalent labeling of fusion proteins
with small molecules in vivo. Nat Biotechnol 21(1):86–89.
26. Green DE, Morris TW, Green J, Cronan JE, Jr, Guest JR (1995) Purification and prop-
erties of the lipoate protein ligase of Escherichia coli. Biochem J 309(Pt 3):853–862.
27. Lavis LD, Chao T-Y, Raines RT (2011) Synthesis and utility of fluorogenic acetoxymethyl
ethers. Chem Sci 2(3):521–530.
28. Riedl J, et al. (2008) Lifeact: a versatile marker to visualize F-actin. Nat Methods 5(7):
605–607.
29. Marmé N, Knemeyer J-P, Sauer M, Wolfrum J (2003) Inter- and intramolecular fluo-
rescence quenching of organic dyes by tryptophan. Bioconjug Chem 14(6):1133–1139.
30. Adams SR, et al. (2002) New biarsenical ligands and tetracysteine motifs for protein
labeling in vitro and in vivo: Synthesis and biological applications. J Am Chem Soc
124(21):6063–6076.
7. Jing C, Cornish VW (2013) A fluorogenic TMP-tag for high signal-to-background in-
tracellular live cell imaging. ACS Chem Biol 8(8):1704–1712.
8. Stroffekova K, Proenza C, Beam KG (2001) The protein-labeling reagent FLASH-EDT2
binds not only to CCXXCC motifs but also non-specifically to endogenous cysteine-rich
proteins. Pflugers Arch 442(6):859–866.
9. Lang K, et al. (2012) Genetic encoding of bicyclononynes and trans-cyclooctenes for
site-specific protein labeling in vitro and in live mammalian cells via rapid fluorogenic
Diels-Alder reactions. J Am Chem Soc 134(25):10317–10320.
10. Uttamapinant C, et al. (2010) A fluorophore ligase for site-specific protein labeling
inside living cells. Proc Natl Acad Sci USA 107(24):10914–10919.
31. Hell SW (2007) Far-field optical nanoscopy. Science 316(5828):1153–1158.
32. Deerinck TJ, et al. (1994) Fluorescence photooxidation with eosin: A method for high
resolution immunolocalization and in situ hybridization detection for light and electron
microscopy. J Cell Biol 126(4):901–910.
33. Jones JCR, Goldman AE, Steinert PM, Yuspa S, Goldman RD (1982) Dynamic aspects of
the supramolecular organization of intermediate filament networks in cultured
epidermal cells. Cell Motil 2(3):197–213.
34. Katsumoto T, Mitsushima A, Kurimura T (1990) The role of the vimentin intermediate
filaments in rat 3Y1 cells elucidated by immunoelectron microscopy and computer-
graphic reconstruction. Biol Cell 68(2):139–146.
11. Xu W, Kong JS, Yeh Y-TE, Chen P (2008) Single-molecule nanocatalysis reveals het-
erogeneous reaction pathways and catalytic dynamics. Nat Mater 7(12):992–996.
12. Tour O, Meijer RM, Zacharias DA, Adams SR, Tsien RY (2003) Genetically targeted
chromophore-assisted light inactivation. Nat Biotechnol 21(12):1505–1508.
13. Gaietta G, et al. (2002) Multicolor and electron microscopic imaging of connexin
trafficking. Science 296(5567):503–507.
14. Shu X, et al. (2011) A genetically encoded tag for correlated light and electron mi-
croscopy of intact cells, tissues, and organisms. PLoS Biol 9(4):e1001041.
15. Cohen JD, Thompson S, Ting AY (2011) Structure-guided engineering of a Pacific Blue
fluorophore ligase for specific protein imaging in living cells. Biochemistry 50(38):
8221–8225.
16. Fujiwara K, et al. (2010) Global conformational change associated with the two-step
reaction catalyzed by Escherichia coli lipoate-protein ligase A. J Biol Chem 285(13):
9971–9980.
17. Richter F, Leaver-Fay A, Khare SD, Bjelic S, Baker D (2011) De novo enzyme design
using Rosetta3. PLoS ONE 6(5):e19230.
18. Murphy PM, Bolduc JM, Gallaher JL, Stoddard BL, Baker D (2009) Alteration of en-
zyme specificity by computational loop remodeling and design. Proc Natl Acad Sci
USA 106(23):9215–9220.
19. Ashworth J, et al. (2006) Computational redesign of endonuclease DNA binding and
cleavage specificity. Nature 441(7093):656–659.
20. Chen C-Y, Georgiev I, Anderson AC, Donald BR (2009) Computational structure-based
redesign of enzyme activity. Proc Natl Acad Sci USA 106(10):3764–3769.
21. Puthenveetil S, Liu DS, White KA, Thompson S, Ting AY (2009) Yeast display evolution
of a kinetically efficient 13-amino acid substrate for lipoic acid ligase. J Am Chem Soc
131(45):16430–16438.
22. Fujiwara K, et al. (2005) Crystal structure of lipoate-protein ligase A from Escherichia
coli. Determination of the lipoic acid-binding site. J Biol Chem 280(39):33645–33651.
23. Van de Vijver P, et al. (2009) Synthetic microcin C analogs targeting different ami-
noacyl-tRNA synthetases. J Bacteriol 191(20):6273–6280.
35. Goldman R, et al. (1985) Intermediate filaments: Possible functions as cytoskeletal
connecting links between the nucleus and the cell surface. Ann N Y Acad Sci 455:1–17.
36. Shimi T, Butin-Israeli V, Goldman RD (2012) The functions of the nuclear envelope in
mediating the molecular crosstalk between the nucleus and the cytoplasm. Curr Opin
Cell Biol 24(1):71–78.
37. Nekrasova OE, et al. (2011) Vimentin intermediate filaments modulate the motility of
mitochondria. Mol Biol Cell 22(13):2282–2289.
38. Liu DS, Loh KH, Lam SS, White KA, Ting AY (2013) Imaging trans-cellular neurexin-
neuroligin interactions by enzymatic probe ligation. PLoS ONE 8(2):e52823.
39. Liu DS, Phipps WS, Loh KH, Howarth M, Ting AY (2012) Quantum dot targeting with
lipoic acid ligase and HaloTag for single-molecule imaging on living cells. ACS Nano
6(12):11080–11087.
40. Bueno C, et al. (2002) The excited-state interaction of resazurin and resorufin with
amines in aqueous solutions. Photophysics and photochemical reactions. Photochem
Photobiol 76(4):385–390.
41. Cao H, et al. (2007) A red cy3-based biarsenical fluorescent probe targeted to a
complementary binding peptide. J Am Chem Soc 129(28):8672–8673.
42. Fernández-Suárez M, et al. (2007) Redirecting lipoic acid ligase for cell surface protein
labeling with small-molecule probes. Nat Biotechnol 25(12):1483–1487.
43. Otwinowski Z, Minor W (1997) . Processing of X-ray diffraction data collected in
oscillation mode. Methods in Enzymology, ed Carter CW, Jr (Academic, New York),
Vol 276, pp 307–326.
44. Strong M, et al. (2006) Toward the structural genomics of complexes: Crystal structure
of a PE/PPE protein complex from Mycobacterium tuberculosis. Proc Natl Acad Sci USA
103(21):8060–8065.
45. McCoy AJ, et al. (2007) Phaser crystallographic software. J Appl Cryst 40(Pt 4):658–674.
46. Bückers J, Wildanger D, Vicidomini G, Kastrup L, Hell SW (2011) Simultaneous multi-
lifetime multi-color STED imaging for colocalization analyses. Opt Express 19(4):3130–3143.
47. Ho BK, Gruswitz F (2008) HOLLOW: generating accurate representations of channel
and interior surfaces in molecular structures. BMC Struct Biol 8:49.
