Polymer Photoreactions
l-Orthogonal Pericyclic Macromolecular Photoligation**
Kai Hiltebrandt, Thomas Pauloehrl, James P. Blinco, Katharina Linkert, Hans G. Bçrner, and
Christopher Barner-Kowollik*
Abstract: A photochemical strategy enabling l-orthogonal
reactions is introduced to construct macromolecular architec-
tures and to encode variable functional groups with site-
selective precision into a single molecule by the choice of
wavelength. l-Orthogonal pericyclic reactions proceed inde-
pendently of one another by the selection of functional groups
that absorb light of specific wavelengths. The power of the new
concept is shown by a one-pot reaction of equimolar quantities
of maleimide with two polymers carrying different maleimide-
reactive endgroups, that is, a photoactive diene (photoenol) and
a nitrile imine (tetrazole). Under selective irradiation at l =
310–350 nm, any maleimide (or activated ene) end-capped
compound reacts exclusively with the photoenol functional
polymer. After complete conversion of the photoenol, subse-
quent irradiation at l = 270–310 nm activates the reaction of
the tetrazole group with functional enes. The versatility of the
approach is shown by l-orthogonal click reactions of complex
maleimides, functional enes, and polymers to the central
polymer scaffold.
deactivation methods.[1] Such polymers find widespread
applications in areas such as drug delivery,[2] self-healing
materials,[3] organic solar cells (OSCs),[4] and microelectron-
ics.[5] Click chemistry is also an excellent method for the
synthesis of macromolecular materials.[6] The concept of click
chemistry was introduced by Sharpless in 2001.[7] Fast reaction
kinetics, quantitative yield, stereoselectivity, equimolarity,
orthogonal reactivity and no purification of the obtained
products are unique features of click chemistry.[8] Never-
theless, thermally induced click reactions lack spatial and
temporal control. Light-triggered click reactions offer a pos-
sibility to overcome these disadvantages.[9] In general, photo-
chemistry is environmentally friendly, can be orthogonal, and
offers the possibility of uphill photosensitization.[10] Herein
we define l-orthogonality of click reactions as the (kinetic)
preference of one reaction channel by using a specific wave-
length regime. Importantly, we wish to impart this orthogon-
ality using cheap, simple, and readily available radiation
sources.
There are examples of wavelength-dependent reactions;
for example, Del Campo et al. synthesized different photo-
active protecting groups consisting of aromatic chromo-
phores. These photoactive groups were then attached to
surfaces. After irradiating one of these chromophores with an
appropriate wavelength, small aromatic molecules and
carbon dioxide are released.[11] Franking et al. demonstrated
the wavelength-dependent (254 nm vs. 350 nm) photochem-
ical grafting of a set of alkenes onto single-crystal TiO2
samples.[12] Inui et al. addressed the wavelength-dependent
cleavage of azirine rings forming nitrile ylides at l > 300 nm
and acetonitrile oxides at l = 300 nm in the presence of
oxygen.[13] All the above studies either successfully establish
the photo-triggered attachment of molecules onto surfaces,
the release of small molecules from surfaces by irradiation, or
the decomposition of photoactive molecules into smaller
fragments. Until now, however, there is no description of
a chemical system that employs orthogonal wavelength-
dependent pericyclic click reactions in a one-pot fashion.
The key to achieve orthogonality in photo-induced click
reactions is to choose appropriate moieties that are kinetically
preferred by a specific wavelength as illustrated in Scheme 1.
Initial kinetic studies of two polymers each carrying
a different photoactive endgroup were performed in the
presence of maleimide in varying ratios. A poly(ethylene
glycol) methyl ether (PEG) chain is capped with 4-((2-formyl-
3-methylphenoxy)methyl)benzoic acid (“photoenol”, a diene
that can be photoactivated) to form compound 1 (Supporting
Information, Figure S3) and capped with 4-(2-phenyl-2H-
tetrazol-5-yl) benzoic acid (“tetrazole”, a nitrilamine that can
be photoactivated) to form compound 2 (Supporting Infor-
mation, Figure S4). Choosing the appropriate irradiation
T
he synthesis of polymers with tailored material properties
has been revolutionized with the advent of reversible
[*] K. Hiltebrandt, Dr. T. Pauloehrl, Prof. Dr. C. Barner-Kowollik
Preparative Macromolecular Chemistry
Institut fꢀr Technische Chemie und Polymerchemie
Karlsruhe Institute of Technology (KIT)
Engesserstrasse 18, 76128 Karlsruhe (Germany)
and
Institut fꢀr Biologische Grenzflꢁchen (IBG)
Karlsruhe Institute of Technology (KIT)
Hermann-von-Helmholtz-Platz 1
76344 Eggenstein-Leopoldshafen (Germany)
E-mail: christopher.barner-kowollik@kit.edu
Dr. T. Pauloehrl
Current address: Institute for Complex Systems
Eindhoven University of Technology
Post Office Box 513, 5600 MD Eindhoven (The Netherlands)
Dr. J. P. Blinco, Prof. Dr. C. Barner-Kowollik
School of Chemistry, Physics and Mechanical Engineering
Queensland University of Technology (QUT)
2 George St, Brisbane, Queensland 4001 (Australia)
K. Linkert, Prof. Dr. H. G. Bçrner
Laboratory for Organic Synthesis of Functional Systems
Humboldt-Universitꢁt zu Berlin
Brook-Taylor-Strasse 2, 12489 Berlin (Germany)
[**] C.B.K. acknowledges continued funding from the Karlsruhe Institute
of Technology (KIT) in the context of the Helmholtz STN program.
K.H.’s PhD studies are funded by the Fonds der Chemischen
Industrie (FCI). H.G.B. acknowledges funding from the ERC (ERC
305064).
