Three state redox-active molecular shuttle that switches in solution and on a surface

Article abstract of DOI:10.1021/ja077223a

Although the desirability of developing synthetic molecular machine systems that can function on surfaces is widely recognized, to date the only well-characterized examples of electrochemically switchable rotaxane-based molecular shuttles which can do so

Full text of DOI:10.1021/ja077223a

Published on Web 02/06/2008
Three State Redox-Active Molecular Shuttle That Switches in
Solution and on a Surface
Giulia Fioravanti,‡ Natalia Haraszkiewicz,| Euan R. Kay,† Sandra M. Mendoza,§
Carlo Bruno,‡ Massimo Marcaccio,‡ Piet G. Wiering,| Francesco Paolucci,*,‡
Petra Rudolf,*,§ Albert M. Brouwer,*,| and David A. Leigh*,†
Dipartimento di Chimica “G. Ciamician”, UniVersita` degli Studi di Bologna, V. F. Selmi 2,
40126, Bologna, Italy, School of Chemistry, UniVersity of Edinburgh, The King’s Buildings,
West Mains Road, Edinburgh EH9 3JJ, United Kingdom, Zernike Institute for AdVanced
Materials, UniVersity of Groningen, Nijenborgh 4, 9747AG Groningen, The Netherlands, and
Van’t Hoff Institute for Molecular Sciences, UniVersity of Amsterdam, Nieuwe Achtergracht 129,
NL-1018 WS Amsterdam, The Netherlands
Received September 18, 2007; E-mail: David.Leigh@ed.ac.uk; Francesco.Paolucci@unibo.it; P.Rudolf@rug.nl; A.M.Brouwer@uva.nl
Abstract: Although the desirability of developing synthetic molecular machine systems that can function
on surfaces is widely recognized, to date the only well-characterized examples of electrochemically
switchable rotaxane-based molecular shuttles which can do so are based on the tetracationic viologen
macrocycle pioneered by Stoddart. Here, we report on a [2]rotaxane which features succinamide and
naphthalene diimide hydrogen-bonding stations for a benzylic amide macrocycle that can shuttle and switch
its net position both in solution and in a monolayer. Three oxidation states of the naphthalene diimide unit
can be accessed electrochemically in solution, each one with a different binding affinity for the macrocycle
and, hence, corresponding to a different distribution of the rings between the two stations in the molecular
shuttle. Cyclic voltammetry experiments show the switching to be both reversible and cyclable and allow
quantification of the translational isomer ratios (thermodynamics) and shuttling dynamics (kinetics) for their
interconversion in each state. Overall, the binding affinity of the naphthalene diimide station can be changed
by 6 orders of magnitude over the three states. Unlike previous electrochemically active amide-based
molecular shuttles, the reduction potential of the naphthalene diimide unit is sufficiently positive (-0.68 V)
for the process to be compatible with operation in self-assembled monolayers on gold. Incorporating pyridine
units into the macrocycle allowed attachment of the shuttles to an acid-terminated self-assembled monolayer
of alkane thiols on gold. The molecular shuttle monolayers were characterized by X-ray photoelectron
spectroscopy and their electrochemical behavior probed by electrochemical impedance spectroscopy and
double-potential step chronoamperometry, which demonstrated that the redox-switched shuttling was
maintained in this environment, occurring on the millisecond time scale.
Introduction
is a rotaxane in which the thread contains two (or more)
macrocycle-binding sites (“stations”) connected by a traversable
pathway.3 Provided sufficient thermal energy is available to
break the intercomponent interactions at each site, the ring
moves randomly between the two stations. On average, however,
the macrocycle spends more time on the station with the higher
binding affinity (i.e., the molecule tends to adopt a particular
preferred co-conformation4). In a stimuli-responsive molecular
shuttle, chemically altering one of the stations is used to switch
the preferred location of the ring, while reversing that change
returns the system to the starting distribution. One particularly
attractive stimulus for the operation of such devices is electro-
chemistry, as it allows remote, reagent-free, and waste-free
Synthetic systems in which submolecular motions can be
controlled by the application of external stimuli have been
vigorously pursued in recent years.1 Such “mechanical” mo-
lecular devices are viewed both as putative components for
future functional nanotechnologies and as much simplified
models of complex biological machines. One of the most
versatile designs for a simple switch-like molecular machine is
the stimuli-responsive molecular shuttle.1,2 A molecular shuttle
† University of Edinburgh.
‡ Universita` degli Studi di Bologna.
§ University of Groningen.
| University of Amsterdam.
(1) (a) Balzani, V.; Credi, A.; Raymo, F. M.; Stoddart, J. F. Angew. Chem.,
Int. Ed. 2000, 39, 3349-3391. (b) Balzani, V.; Venturi, M.; Credi, A.
Molecular DeVices and Machines. A Journey into the Nanoworld; Wiley-
VCH: Weinheim, 2003. (c) Kinbara, K.; Aida, T. Chem. ReV. 2005, 105,
1377-1400. (d) Browne, W. R.; Feringa, B. L. Nat. Nanotech. 2006, 1,
25-35. (e) Kay, E. R.; Leigh, D. A.; Zerbetto, F. Angew. Chem., Int. Ed.
2007, 46, 72-191.
(3) (a) Anelli, P. L.; Spencer, N.; Stoddart, J. F. J. Am. Chem. Soc. 1991, 113,
5131-5133. For the first example of an amide-based molecular shuttle
see: (b) Lane, A. S.; Leigh, D. A.; Murphy, A. J. Am. Chem. Soc. 1997,
119, 11092-11093.
(4) “Co-conformation” refers to the relative positions of the mechanically
interlocked components with respect to each other, see: Fyfe, M. C. T.;
Glink, P. T.; Menzer, S.; Stoddart, J. F.; White, A. J. P.; Williams, D. J.
Angew. Chem., Int. Ed. Engl. 1997, 36, 2068-2070.
(2) Tian, H.; Wang, Q.-C. Chem. Soc. ReV. 2006, 35, 361-374.
9
10.1021/ja077223a CCC: $40.75 © 2008 American Chemical Society
J. AM. CHEM. SOC. 2008, 130, 2593-2601
2593

A R T I C L E S
Fioravanti et al.
control, while providing the opportunity to interface the mo-
lecular devices with existing electronic technologies.5
station shuttles in solid-state molecular electronic devices,5
successfully correlating several aspects of their solution-phase,
surface and solid-state behavior.13
Clearly, a key step in the development of electronic (and
many other) applications of synthetic molecular machines will
be transposing working systems from solution phase onto
surfaces and into the solid state.6 Already molecular shuttles
have been used to construct solid-state and surface-based devices
that exhibit switchable conductance,5,7 optical properties,8
wettability,9 porosity,10 and shape.11 Yet, although stimuli-
induced shuttling is strongly implicated in the operation of each
of these systems, reliable methods for anchoring shuttles to solid
supports and strategies for directly observing and fully char-
acterizing their stimuli-induced motions in such environments
have proven particularly challenging over nearly a decade of
study.5-11
We have previously reported14 on another structural type of
electrochemically switchable molecular shuttle; an amide-
based15-19 rotaxane in which net translocation of the macrocycle
can be induced by photochemical or electrochemical reduction
of a 1,8-naphthalimide station. The solution-phase shuttling was
characterized in detail and both states were shown to exhibit
unprecedented positional integrity. Furthermore, the shuttling
motion is reversible and occurs over a rather large distance of
∼1.5 nm on a microsecond time scale (the precise rate is
dependent on solvent and experimental conditions).14 The
relatively large, negative potentials required to cause switching,
however, prevented the operation of such devices on surfaces.20
In fact, despite the sophistication of modern synthetic routes
toward interlocked molecules,12 few classes of rotaxanes have
proved amenable to the construction of molecular shuttles. Still
fewer shuttles operate using electrochemical stimuli, and two
of these are among the only types of shuttle to be studied in
any detail on surfaces. Willner and co-workers have character-
ized the shuttling kinetics of a cationic ring on a single-station
rotaxane in which a cathode acts simultaneously as a redox
reagent, a stopper, and a station.7d,e However, the integral role
of the solid substrate in producing the bistability prevents
comparisons with solution-phase experiments. An extensive
program by Stoddart, Heath, and co-workers has studied the
shuttling behavior of a particular class of redox-switched two-
