Organic Letters
Letter
diastereoselectivities (dr) were determined from integration of
1H NMR from crude reaction mixtures. All yields are isolated
yields. Highly reactive electron-poor sulfonyl imines have been
identified as the best reaction partners (3−15, Table 1), with
aryl-substituted nitro, cyano, fluoro, and trifluoromethyl groups
being performing best. Ortho-substitution has been shown to
produce slightly higher yields in these cases. The main
competing reaction pathway is a hydride shift to form an
enamide, which becomes the major product when appropriate
aryl deactivation is not present as exemplified by 4-bromo
product 19. Interestingly, a cyclopropyl imine is compatible for
the reaction cascade affording aziridine product 16. Beyond
phenyl, we have learned that electronics of the nucleophile
substituents are critical as well with the parent phenyl
performing the best (3) followed by 4-OMe (20), then 4-Br
(21) with 4-NO2 (22) failing to react.
Excitingly, a phenyl ester nucleophile works as well as the
phenyl ketone nucleophile (24). We were able to secure a
crystal structure of 24, which confirmed that the SCF3- and
aryl substituents are syn to each other. This ester product
opens the door significantly for expanded synthetic applica-
tions. Finally, an intriguing cyclic sulfamate aldimine has been
shown to form aziridine product 25.
Presumably, following aziridine ring opening the resulting
dipole undergoes a cyclization followed by loss of the N-tosyl
protecting group driven by aromatization and formation of the
oxazole product. Padwa first demonstrated this type of
rearrangement for N-alkyl and N-aryl aziridines using forcing
conditions (220 °C).26 The three reported N-sulfonyl
examples proceed under higher temperature and lower
yield.27 This is the first example of an SCF3-substituted ring
expansion case affording a rare example of an SCF3-substituted
oxazole. We have further demonstrated this ring expansion for
the synthesis of SCF3-oxazoles 27, 28, and 29. It is worth
noting that oxazoles are a prominent motif in pharmaceutical
architectures and our two-step route represents a novel entry
for their assembly.28,29
Unexpectedly, when we attempted a Horner−Wadsworth−
Emmons olefination of ketone 3 with trimethyl phosphonoa-
cetate (TMPA) none of the expected enoate (31) was
observed, but instead all cis-SCF3 disubstituted aziridine 30
was formed as the only product in 65% yield. Presumably, the
phosphonate anion adds to the ketone, which then undergoes a
deacylation to form an SCF3-stabilized aziridine carbanion and
then the product upon protonation. This is the first example of
a 1,2-disubstituted SCF3-aziridine being synthesized and a rare
example of a mild anion-mediated aziridine deacylation
reaction. We were eager to learn if we could replace the
phosphonate anion with a more affordable and readily available
carbanion for this anionic deacylation process. Our inves-
tigations have identified both ethyl acetate and dimethyl
malonate (DMM) as excellent replacements for TMPA.
Disubstituted SCF3-aziridines 32, 33, and 34 were also
synthesized as single syn-diastereomers employing ethyl
acetate as deacylation nucleophile.
We have identified two attractive applications for these
SCF3-aziridine products (Scheme 2 and Scheme 3). Aziridine
Scheme 2. SCF3-Aziridine Ring Expansion to Oxazoles
We next turned our attention to using this class of
nucleophiles for the synthesis of SCF3-substituted cyclo-
propanes. We rationalized that highly reactive enones with
limited stability would provide the best opportunity for the
tandem Michael-SN2 displacement to occur. To that end, we
chose phenyl vinyl ketone as our electrophile (Table 2). For
Table 2. SCF3-Cyclopropane Synthesis Optimization
Scheme 3. Synthesis of Disubstituted SCF3-Aziridines via an
Unexpected Anionic Deacylation Process
entry
base
solvent
yield (%), major:minor
a
1
2
3
4
5
6
7
8
Cs2CO3
Cs2CO3
Cs2CO3
CH3CN
CHCl3
CH2Cl2
CHCl3
CHCl3
CHCl3
CH2Cl2
THF
CH3CN
THF
t-BuOH
THF
70, 1:25:1
65, 12.7:1
50, 5.3:1
60, 4.7:1
0
0
trace
0
0
a
a
a
K2CO3
a
Na2CO3
a
Li2CO3
a
Et3N
b c
,
LiHMDS
Proton sponge
a
9
a
10
11
12
DBU
10, 1.5:1
40, 6:1
20, 5.9:1
a
KOtBu
b c
,
NaH
a
Both substrates added together over 30 min to base and solvent.
b
c
3 undergoes a facile ring expansion under mild thermal
conditions to form SCF3-substituted oxazole 26 in 80% yield.
Base added last over 30 min. 0 °C to rt. Diastereomeric ratio was
1
based on integration of H NMR crude mixtures.
6123
Org. Lett. 2021, 23, 6121−6125
