Chemistry of Heterocyclic Compounds, Vol. 43, No. 4, 2007
SYNTHESIS OF THE FIRST EXAMPLE OF A TETRAHYDROINDENO[2,1-c]AZONINE
SYSTEM BY THE REACTION OF 2,3-DIHYDRO-1H-INDENO[2,1-c]PYRIDYINIUM
METHYLIDE WITH METHYL ACETYLENE DICARBOXYLATE
A. T. Soldatenkov, S. V. Volkov, and S. A. Soldatova
Keywords: methyl acetylenedicarboxylate, 2,3-dihydro-1H-indeno[21-c]pyridinium methylide, N-ylide,
tetrahydroindeno[2,1-c]azonin
N-Ethoxycarbonylmethylides of 1,2,3,6-tetrahydropyridines undergo a variety of reactions, the direction
of which depends on the nature of the substituents on the heterocycle. Six-membered heterocycles may decyclize
into pentadienamines [1], recyclize with constriction of the ring to derivatives of pyrrolidine [2], or recyclization
with expansion of a seven-membered azacycle [3]. When the anhydrobase is generated in the presence of methyl
acetylenedicarboxylate (MADC) the latter readily reacts with the carbanion center to give addition products [4]
or products of cyclization of the indolizine type [5-7].
However when a solution of an equimolar mixture of MADC, 2-methoxycarbonylmethyl-2-methyl-
9-phenyl-2,3-dihydro-1H-indeno[2,1-c]pyridinium bromide (1) and triethylamine in methylene chloride was
kept at ~20°C for 3 h the indenoazonine 2 was unexpectedly formed and was isolated in 47% yield by column
chromatography.
COOMe
6
–
7
Br
8
Me
COOMe
COOMe
Et3N
7b
7a
+
N
3
O
O
O
O
12a
CH2COOMe
Me
N
2
11a
11
12
Ph
1
Me
Me
Ph
1
2
In its 1H NMR spectrum two three proton singlets (at 3.19 ppm, NMe and 3.30 ppm, 3-COOMe) and one
six proton singlet at 3.71 (two COOMe groups) were observed. At strong field (3.04-4.60 ppm), four double signals
were observed from protons of two CH2 groups with large geminal coupling constants (2J = 14.6-16.3 Hz). A broad
singlet was observed at 6.31 ppm, which can be assigned to the methyne proton H-3, under the descreening
influence of the nitrogen atom and the COOMe group. Finally in the same region (7.62 ppm) there is a slightly
broadened singlet signal which is evidently assignable to the proton H-7 of the vinyl group. These results in
combination with the presence in the mass spectrum of a molecular ion peak at [M]+ with m/z 473 confirm the
structure of the indenoazonine derivative 2.
__________________________________________________________________________________________
Peoples' Friendship University of Russia, Moscow 117198; e-mail: asoldatenkov@mail.ru. Translate
from Khimiya Geterotsiklicheskikh Soedinenii, No. 4, 613-615, April, 2007. Original article submitted
November 29, 2006.
508
0009-3122/07/4304-0508©2007 Springer Science+Business Media, Inc.

Evidently the tetrahydroindenoazonine 2 can be formed by electrophilic addition of MADC to the
intermediate N-ylid, which arises from the corresponding 1,4-zwitterion and recyclization of the latter with
expansion of the six-membered piperidiene unit into the nine-membered azacycle. Thus a new direction of
recyclization of an N-ylid system is observed on interaction of a quaternary tetrahydroindenopyridium salt with a
base in the presence of MADC. The 2-methyl-9-phenyl-2,3-dihydro-1H-indeno[2,1-c]pyridine was prepared by
method [8].
1H NMR spectra of CDCl3 solutions with TMS as internal standard were recorded on a Bruker WM-400
(400 MHz) machine. Mass spectra were recorded on a MAT-112 spectrometer with direct input of the sample
into the ion source with an ionizing current of 70 eV. IR spectra of KBr disks were recorded on an IR-75
spectrometer. Silufol UV-254 strips (developed with iodine vapor) were used for TLC. Column chromatography
was carried out on silica gel (Silicagel L 32/63).
2-Methoxycarbonylmethyl-2-methyl-9-phenyl-2,3-dihydro-1H-indeno[2,1-c]pyridinium Bromide
(1). Methyl bromoacetate (6.11 g, 0.04 mol) was added with stirring to a solution of 2-methyl-9-phenyl-
2,3-dihydro-1H-indeno[2,1-c] pyridine (10 g, 0.4 mol) in THF. The mixture was boiled for 1 h in an atmosphere
of argon. The precipitate of the quaternary salt was filtered off, washed with ether, and dried in air to give yellow
crystals of salt 1 (16 g, 97%); mp 178-180°C. Found, %: N 3.45. C22H22NO2Br. Calculated, %: N 3.40.
2-Methyl-3,4,5-trimethoxycarbonyl-1,2,3,6-tetrahydroindeno[2,1-c]azonine [2]. Triethylamine (0.7
ml, 0.5 g, 5.8 mmol) and methyl acetylenedicarboxylate (0.61 ml, 0.71 g, 5.8 mmol) were added dropwise to a
suspension of salt 1 (2.06 g, 5.8 mmol) in dichloromethane. The mixture was stirred at 20°C for 3h. the solvent
was evaporated and compound 3 (1.27 g, 47%); mp 89-90°C, was isolated from the residue as brownish red
crystals by chromatography. IR spectrum, ν, cm-1: 1731 (C=O). 1H NMR spectrum, δ, ppm (J, Hz): 3.04 (1H, d,
J = 14.5, H-1); 3.19 (3H, s, NCH3); 3.30 (3H, s, OCH3); 3.71 (6H, s, OCH3); 3.73 (1H, d, J =14.5, H-1); 3.88
(1H, d, J =16.2, H-6); 4.60 (1H, d, J =16.2, H-6); 6.31 (1H, s, H-3); 7.09 (1H, d, J = 6.9 (H-11); 7.23-7.51 (5H,
m, Harom); 7.58 (1H, d, J = 6.9, H-9); 7.62 (1H, s, H-7). Mass spectrum, m/z: 473 [M]+ (57), 442 (7), 414 (100),
357 (33), 294 (28), 281 (29), 239 (78), 216 (76), 202 (78), 77 (16), 59 (100). Found, %: C 70.81; H 5.73; N 2.88.
C28H27NO6. Calculated, %: C 70.95; H 5.70; N 2.95.
REFERENCES
1.
2.
3.
S. J. Neeson and P. J. Stevenson, Tetrahedron Lett.,29, 3993 (1988).
J. B. Sweeney, A. Tavassoli, N. B. Carter, and J. F. Hayes, Tetrahedron, 58, 10113 (2002).
S. A. Soldatova, S. V. Akbulatov, G. S. Gimranova, Yu. O. Rudakov, K. V. Polyanskii, and
A. T. Soldatenkov, Khim. Geterotsikl. Soedin., 790 (2005). [Chem. Heterocycl. Comp., 41, 681 (2005)].
A. T. Soldatenko, N. S. Prostakov, and A. A. Obynochny, Khim. Geterotsikl. Soedin., 3 (1995). [Chem.
Heterocycl. Comp., 31, 1 (1995)].
N. S. Prostakov, L. A. Gaivoronskaya, R. I. Anastasi, S. M. Kamara Maiga, A. A. Savina
L. A. Murugova, and P. I. Zakharov, Khim. Geterotsikl. Soedin., 1514 (1979). [Chem. Heterocycl.
Comp., 15, 1214 (1979)].
4.
5.
6.
7.
8.
N. S. Prostakov, A. T. Soldatenkov, P. K. Radzhan, and M. V. Bagdadi, Khim. Geterotsikl. Soedin., 706
(1982). [Chem. Heterocycl. Comp., 18, 542 (1982)].
N. S. Prostakov, A. T. Soldatenkov, P. K. Radzhan, A. Samalyoa, V. F. Zakharov, and V. P. Zvolinskii,
Khim. Geterotsikl. Soedin., 252 (1983). [Chem. Heterocycl. Comp., 19, 206 (1983)].
J. T. Plati and W. Wenner, J. Org. Chem., 15, 209 (1950).
