Self-Assembling Behavior of Amphiphilic Dendron Coils in
the Bulk Crystalline and Liquid Crystalline States
Yeon-Wook Chung,† Jeong-Kyu Lee,‡ Wang-Cheol Zin,‡ and Byoung-Ki Cho*,†
Department of Chemistry and Institute of Nanosensor and Biotechnology, Dankook UniVersity,
Gyeonggi-Do, 448-701, Korea, and Department of Materials Science and Engineering,
Pohang UniVersity of Science and Technology, Pohang 790-784, Korea
Received February 23, 2008; E-mail: chobk@dankook.ac.kr
Abstract: We prepared a series of amphiphilic dendron coils (1-3) containing aliphatic polyether dendrons
with octadecyl peripheries and a poly(ethylene oxide) (PEO) coil (DP ) 44). The molecular design in this
study is focused on the variation of dendron generation (from first to third) with a fixed linear coil, upon
which the thermal and self-assembling behavior of the dendron coils was investigated in the bulk. All the
dendron coils exhibit two crystalline phases designated as k1 (both crystalline octadecyl chains and PEO)
and k2 states (crystalline octadecyl chains and molten PEO). Crystallinities for both octadecyl peripheries
and the PEO decrease as generation increases. In particular, the dendron coil (3) containing third generation
shows a drastic reduction of the PEO crystallinity, which is attributed to the considerable chain folding and
plasticization effects by the largest hydrophilic dendritic core segment. All the crystalline phases are bilayered
lamellar morphologies. On going from k1 to k2, the periodic lamellar thickness decreases in the dendron
coil (1) with first generation, but interestingly increases in 3. After melting of octadecyl peripheries, 1 shows
no mesophase (i.e., liquid crystalline phase). Additionally, dendron coil 2 (3) displays a network cubic
mesophase with Ia3d symmetry (micellar cubic with Pm3n) which is transformed into a lamellar (hexagonal
columnar) mesophase upon heating. Remarkably, the temperature-dependent mesomorphic behavior in 2
and 3 is a completely reverse pattern in comparison with conventional linear-linear block copolymers.
The unusual bulk morphological phenomena in the crystalline and liquid crystalline phases can be elucidated
by the dendron coil architecture and the associated coil conformational energy.
Introduction
drimers/dendrons have displayed self-assembled micelles and
cylinders in the bulk because of their typical cone or tapered
A great deal of attention has been paid to the generation of
supramolecular nanostructures by self-assembling molecules due
to the tremendous potentials for the development of functional
materials.1 It has been well established that the morphological
feature of each nanostructure is entirely dependent upon the
identity of organizing building blocks and can be fine-tuned by
the elaborate engineering of related molecular parameters such
as polarity, stiffness, and architecture.2 Therefore, a hybridization
approach of architecturally distinct building blocks with their
own self-assembling characteristics may become a powerful tool
to develope a new class of self-assemblers.
Dendrimers/dendrons are monodisperse macromolecules with
regular and highly branched architectures consisting of dendritic
cores and peripheral sites. Such a peculiar structural feature
provides a variety of possible applications in the field of
host-guest, medicinal, and catalytic chemistries.3 In addition,
the dendrimers/dendrons have been used as a fascinating self-
assembling building block.4 The compartmentalization of
chemically distinct peripheries and the dendritic core can afford
to microphase-separated structures.5 In most cases, the den-
molecular shape.
These aesthetic dendrimers/dendrons have been combined
with other molecular building blocks such as rods,6 discs,7 or
linear coils into hybrid macromolecules for the creation of new
functional materials. In particular, linear coils have been
compared as a counterpart with dendrimers/dendrons because
of their extremely different molecular shapes, by which they
reveal distinct physical properties in terms of viscosity, hydro-
dynamic volume, glass transition temperature, etc.3c,8 In the last
15 years or so, because of the rapid advances in synthetic
technology, an effort has been made to combine these two
molecular extremes, in order to explore the role of chain
topology on the physical and chemical properties. In the early
stages, the aim was mostly focused on the preparation of
dendritic-coil macromolecular structures by using a variety of
