A novel photo-responsive organogel based on azobenzene

Article abstract of DOI:10.1002/poc.1341

A novel triarmed cis-1,3,5-cyclohexanetricarboxamides gelator, functionalized by three azobenzene moieties grafted with three long alkyl chains, was designed and synthesized. The gelator can gel most of the organic solvents in low concentration. The morph

Full text of DOI:10.1002/poc.1341

Research Article
Received: 13 June 2007,
Revised: 7 January 2008,
Accepted: 9 January 2008,
Published online in Wiley InterScience: 12 March 2008
(www.interscience.wiley.com) DOI 10.1002/poc.1341
A novel photo-responsive organogel
based on azobenzene
a
a
a
a
a
*
Yifeng Zhou , Miao Xu , Junchen Wu , Tao Yi , Jiantao Han ,
Shuzhang Xiaoa, Fuyou Lia and Chunhui Huanga
*
A novel triarmed cis-1, 3, 5-cyclohexanetricarboxamides gelator, functionalized by three azobenzene moieties grafted
with three long alkyl chains, was designed and synthesized. The gelator can gel most of the organic solvents in low
concentration. The morphologies of the xerogels show one-dimensional aggregated bundles or helical fibres. The
azobenzene groups in the gel state form H-type aggregation and perform expected trans–cis photoisomerization with
a gel to sol phase transition upon irradiation of UV light. The main driving force for gelation is intermolecular
hydrogen bonding between amides and p–p interaction of azobenzene moieties. Copyright ß 2008 John Wiley &
Sons, Ltd.
Supplementary electronic material for this paper is available in Wiley InterScience at http://www.mrw.interscience.wiley.com/
suppmat/0894-3230/suppmat/
Keywords: azobenzene; helical structure; organogel; photochromism
system of two component photo-responsive gel.[24] However,
stimulus response operated in the self-assembled gel state is still
INTRODUCTION
The design of self-assembling supramolecules becomes the
charming target toward the development of new materials and
nanoscale devices.[1–6] As a novel class of self-assembled mate-
rials, low weight molecular (LWM) gels have received consider-
able attention in recent years because they can organize into
regular nanoarchitectures through specific non-covalent inter-
actions including hydrogen bonds, hydrophobic interactions,
p–p interactions and van der Waals forces.[7–13] The intermole-
cular hydrogen bonds or p–p interactions usually facilitate the
growth of linear, elongated aggregates in the gels. Chiral
diaminocyclohexane or cis-1, 3, 5-cyclohexanetricarboxamides
are important organogelator cores for the formation of chiral
organogel systems, which was reported by Hanabusa et al. for the
first time.[14,15] Shinkai et al. successfully transcribed the chiral,
helical structures of the organogels into silica gel and got chiral
silica with both right- and left-handed helical motif.[16,17]
Azobenzene moieties are known to all for their photo
responsive properties. The soft matter contained azobenzene
groups can potentially be applied in message storage and
transport, etc.[4] In the organogel systems, azobenzene groups
also acted as p system to enforce the interactions among the
molecules. Feringa reported the chiral recognition through
cooperative interactions between aggregates and gels of
bis(ureido)-cyclohexane skeleton containing azobenzene chro-
mophores.[18] Kato introduced azobenzene based chiral gelator
into liquid crystal systems to get photo responsive anisotropic
liquid-crystalline physical gels.[19,20] Zhao et al. achieved
electrically switchable diffraction gratings based on light-induced
reorganization process in two azobenzene contained gela-
tors.[21,22] In our previous work, we observed solvent tunable
morphologies in an azobenzene gelator with several competitive
or cooperative interactions[23] and we also developed a new
a challenge. In this work, we synthesized a novel triarmed cis-1, 3,
5-cyclohexanetricarboxamides gelator AZO-C16, functionalized
by three azobenzene moieties grafted with three long alkyl
chains (Scheme 1). The cooperative interactions of hydrogen
bonding, p–p interactions and van der Waals forces confirmed
the compound an effective gelator for various organic solvents.
The main attraction is that the self-assembly organization
resulted in a chiral helical structure in a supramolecular level
even using a non-chiral compound as a building block.
MATERIALS AND METHODS
General
All starting materials were obtained from commercial suppliers
and used as received. Moisture sensitive reactions were
performed under an atmosphere of dry argon. 1H NMR and
13C NMR spectra were recorded on a Mercuryplus, at 400 and
100 MHz, respectively. Proton chemical shifts are reported in
parts per million downfield from tetramethylsilane. Matrix-
assisted laser desorption ionization time-of-flight (MALDI-
TOF-MS) was recorded on an AXIMA-CFRPLVS mass spectrometer
(Shimadzu). Element analysis was carried out on a VARIOEL3
apparatus (ELEMENTAR).
*
Department of Chemistry & Laboratory of Advanced Materials, Fudan Uni-
versity, Shanghai 200433, China.
E-mail: yitao@fudan.edu.cn
a
Y. Zhou, M. Xu, J. Wu, T. Yi, J. Han, S. Xiao, F. Li, C. Huang
Department of Chemistry & Laboratory of Advanced Materials, Fudan Uni-
versity, Shanghai 200433, China
J. Phys. Org. Chem. 2008, 21 338–343
Copyright ß 2008 John Wiley & Sons, Ltd.

A NOVEL PHOTO-RESPONSIVE ORGANOGEL
yield 4 as a white solid. The product was used in the next reaction
without further purification.
(1s,3s,5s)-N1,N3,N5-tris(4-((E)-(4-hexadecyloxy phenyl) diazenyl)
phenyl) cyclohexane-1,3,5- tricarboxamide (AZO-C16)
4 (0.22 g, 1 mmol) in 5 ml THF was dropped into 30 ml THF
solution of 3 (1.44 g, 3.3 mmol) under an atmosphere of dry
argon, then 0.5 ml triethylamine (TEA) was added. The reaction
mixture was stirred and refluxed overnight. The resulted
precipitate was then filtered and washed with THF to obtained
1
0.96 g of AZO-C16 (65% yields). M.p. 73–75 8C, H-NMR (CDCl3,
608C) d 8.18 (br, NH, 3H), 7.83–7.85 (m, ArH, 12H), 7.69–7.71 (m,
ArH, 6H), 6.95–6.98 (m, ArH, 6H), 4.02 (t, —OCH2—, 6H), 3.58 (m,
3H), 2.05 (m, 3H), 1.79–1.82 (m, 9H), 1.44–1.49 (m, 6H), 1.30
(s, —CH2—, 72H), 0.89 (t, —CH3, 9H). Anal. Calcd (%) for
C93H135N9O6: C 75.72, H 9.22, N 8.55; found: C 75.46, H 9.11, N 8.67.
MALDI-TOF-MS: 1475.1 [MþH]þ.
Instruments
Fourier transform infrared (FT-IR) spectra were performed using a
Nexus 470 spectrometer (Nicolet Company). UV–visible spectra
were recorded on an UV–vis 2550 spectroscope (Shimadzu). The
UV and visible irradiation was carried out by a CHF-XM550W
power system (China). Visible light was generated by a 500 W Xe
lamp with a standard band-pass filter 440 AF10 (Omega).
Irradiations in the UV region were effected at 365 nm. Scanning
electron microscopy (SEM) images of the xerogels were obtained
using an SSX-550 (Shimadzu) with an accelerating voltage of
15 kV. Samples were prepared by spinning the gels on glass slices
and coating with Au.
Scheme 1. Structure and synthesis process of compound AZO-C16
Synthesis of the gelator
(E)-4-(4-nitrophenyl diazenyl) phenol (1)
Yellow solid 1 was synthesized according to a previous
report[23,24] (95% yields). 1H NMR (CDCl3) d 8.36 (d, J ¼ 9.2 Hz,
2H), 7.93–7.99 (q, J ¼ 8.8 Hz, 4H), 6.98 (d, J ¼ 8.8 Hz, 2H).
(E)-1-(4-(hexadecyloxy) phenyl)-2-(4-nitrophenyl)diazene (2)
1-Bromohexadecane (6.1 ml, 20 mmol) was dropped into 50 ml of
dry acetone solution containing 1 (2.43 g, 10 mmol) and
anhydrous potassium (2.78 g, 20 mmol). The reaction mixture
was refluxed, stirred for 8 h and then poured into excess
water. 2[25] was obtained by filtration and purified by column
chromatography on silica gel with chloroform/petrol ether
RESULTS AND DISCUSSIONS
Gelation properties
A typical procedure for gelation test is described below: a
weighed compound was mixed with a certain organic solvent in a
sealed test tube and the mixture was heated until the solid was
dissolved. The resulting solution was then cooled to room
temperature. If the test tube with gelled sample was turned
upside down without flow, the sample was labelled as ‘gel’.[14] The
gelation properties of AZO-C16 were tested in 20 kinds of
solvents (Table 1). It shows excellent gelling capability with 13
kinds of the test solvents and all the gels were semitransparent
and stable for months (Fig. 1). These gelling solvents ranged from
hydrocarbon solvents and aromatic solvents to dipolar aprotic
solvents. This indicates that AZO-C16 acts as a versatile gelator.
1
(1:2, v/v) as the eluent, yield 4.20 g (90%). M.p. 87–88; H NMR
(CDCl3) d 8.36 (d, J ¼ 8.8 Hz, 2H), 7.97 (q, J ¼ 7.2 Hz, 4H), 7.02 (d,
J ¼ 7.2 Hz, 4H), 4.06 (t, J ¼ 6.8 Hz, 2H), 1.80–1.86 (m, 2H), 1.26–1.50
(m, 28H), 0.88 (t, J ¼ 6.4 Hz, 3H).
(E)-4-((4-hexadecyloxy phenyl)diazenyl)benzenamine (3)
Na2S ꢀ 9H2O (4.80 g, 20 mmol) was added to a suspension of 2
(2.72 g, 6 mmol) in 50 ml of H2O/dioxane (1:1, v/v). The reaction
mixture was stirred at 80 8C for 24 h. Crude 3 (2.62 g) was
obtained and purified by column chromatography on silica gel
1
with chloroform as the eluent, yield 60%. M.p. 88–89; H NMR
UV–vis spectra and the photochromic
properties of the gels
(CDCl3) d 8.83 (d, J ¼ 8.8 Hz, 2H), 7.76 (d, J ¼ 8.8 Hz, 2H), 6.98 (d,
J ¼ 9.2 Hz, 2H), 6.73 (d, J ¼ 8.4 Hz, 2H), 4.02 (t, J ¼ 6.4 Hz, 2H),
3.98 (s, 2H), 1.77–1.84 (m, 2H), 1.26–1.47 (m, 28H), 0.88 (t,
J ¼ 6.4 Hz, 3H).
Electronic UV–vis absorption spectra of the gels were studied to
obtain information about the aggregated state of azobenzene on
the molecular scale. The concentration of both dioxane and DMF
gels is 1.0 ꢁ 10ꢂ2 M and the concentration of both dioxane and
DMF solution is 1.0 ꢁ 10ꢂ5 M. Dioxane and DMF solutions of
AZO-C16 have maximum absorbance at 367 and 372 nm,
respectively, corresponding to the trans-azobenzene chromo-
phore (Fig. 2a and 2b). In the gel state of the corresponding
(1s, 3s, 5s)-Cyclohexane-1,3,5-tricarbonyl trichloride (4)
SOCl2 (1 ml; excess) was dropped into 10 ml of dry THF solution of
(1s, 3s, 5s)-cyclohexane-1, 3, 5-tricarboxylic acid (0.43 g, 2 mmol).
The reaction mixture was refluxed and stirred for 3 h. The solvent
and excess SOCl2 were evaporated under reduced pressure to
*
solvents, the absorption band of p–p transitions of the
J. Phys. Org. Chem. 2008, 21 338–343
Copyright ß 2008 John Wiley & Sons, Ltd.
www.interscience.wiley.com/journal/poc

Y. ZHOU ET AL.
