Organic Letters
Letter
source. Such a synthetic pathway of generating carbon-center
radicals via a photocatalytic hydrogen atom transfer (HAT)
process is very attractive in organic synthesis, as there is no
need for prior functionalization. The most straightforward way
to implement the HAT process is to use a photocatalyst, which
could be excited by light to achieve the excited state followed
by hydrogen atom abstraction from simple alkanes.10 Among
these photocatalysts, tetrabutylammonium decatungstate
(TBADT; [W10O32] (nBu4N)4) is widely used by scientists
due to its high reactivity, unique site selectivity, and simple
preparation from inexpensive precursors.10d−f We envisaged
that under appropriate photochemical conditions, the use of
TBADT would facilitate the generation of alkyl radicals, which
will be further added to iminium ions formed in situ by
secondary amines and aldehydes to achieve the preparation of
α-branched tertiary amines (Scheme 1).
With the optimized conditions in hand, we next sought to
examine the scope of this multicomponent photocatalytic
reaction. At the outset, various secondary arylamines were
examined with 2a and 3a under the standard conditions,
affording the desired N-aryl tertiary amine products in good to
moderate yields (Scheme 2, 4a−4m). Diarylamine with methyl
(4b, 4d, 4f, and 4g), bromine (4c), and fluorine (4e) at
different positions on the aromatic ring (ortho, meta, and para
positions) was tolerated well. Moderate yields were obtained
for N-benzyl- and N-methylanilines as reaction substrates
(4h−4k), and our method was also applicable to indoline and
tetrahydroquinoline substrates (4l−4m), which are ubiquitous
in pharmaceutically relevant molecules.11
In addition, an excellent tolerance of functional groups was
observed during the subsequent investigation of the aldehydes
scope (Scheme 2, 4n−4x). Studies have showed that aliphatic
aldehydes bearing acyclic hydrocarbons were all converted into
the corresponding α-branched tertiary amines 4n−4t in good
to moderate yields. Branched aldehydes also worked well
under the optimal conditions (4u−4x). To highlight the
practicability of our method, a reaction of 3-methylbutanal
with 1a and 3a was successfully performed on a larger scale
(3.0 mmol), affording the desired product 4r in 75% yield.
Furthermore, the scope with respect to aliphatic C−H
compounds was investigated (Scheme 2, 4y−4kk). A wide
range of hydrocarbons proved to be competent coupling
partners for the three-component reaction. Cycloalkanes with
different ring sizes were effectively transformed into the
corresponding products 4y−4aa. Norbornane was predom-
inantly functionalized on the ethylene bridge (4bb), while the
sterically hindered tertiary C−H bonds showed almost no
reactivity despite their relatively low BDEs.12 The structures of
4bb as well as 4a was confirmed by X-ray crystallography. It is
worth noting that the functionalization of toluene derivatives
occurred exclusively on the primary benzylic C−H bonds, and
the corresponding tertiary amine products 4cc−4ii were
isolated in moderate to excellent yields. Tetrasubstituted
alkene 3jj was further examined to successfully furnish the
desired product 4jj in 29% yield. Additionally, α-heteroatom
C−H bonds were found to be effectively functionalized with
excellent regioselectivity. For example, tert-butyl methyl ether
(3kk) was functionalized at the α-oxy position to afford 4kk in
74% yield.
The scope with respect to the multicomponent synthesis of
α-branched secondary amines from aniline derivatives was
further explored (Scheme 3). These reactions were performed
in the presence of 2 mol % of TBADT using acetic acid as
additive. Various aniline derivatives, including substrates
bearing methyl (5a) and halogen (5b−5d) substituents,
underwent the photocatalytic multicomponent reaction with
benzaldehyde and cyclohexane (3a) to furnish the correspond-
ing secondary amines products 6a−6d in good yields.
Aromatic, heteroaromatic, and aliphatic aldehydes were
successfully employed as necessary components affording the
desired products 6e−6h in 62−78% yields. Furthermore, the
multicomponent reaction of aniline and benzaldehyde with a
variety of hydrocarbons, including cyclohexane (6i), 2,3-
dimethyl-2-butene (6j), 1,4-dioxane (6k), and p-xylene (6l),
proceeded smoothly under the standard conditions. Notably,
aldehyde substrate 2a can also serve as a suitable C−H
component to react with benzaldehyde, affording the two-
component reaction product 7 in 78% yield (Scheme 4).
Our study commenced with the three-component reaction
of diphenylamine (1a), cyclohexanecarbaldehyde (2a), and
cyclohexane (3a), as shown in Table 1. In the presence of 3
a
Table 1. Optimization of Reaction Conditions
TBADT
(mol %)
additive
(1.1 equiv)
solvent (0.1
M)
b
entry
yield (%)
1
2
3
4
5
6
7
8
9
10
11
12
3
3
3
3
3
3
2
1
3
3
BF3·Et2O
TMSOTf
TFA
dry MeCN
dry MeCN
dry MeCN
dry MeCN
dry DCM
benzonitrile
dry MeCN
dry MeCN
dry MeCN
dry MeCN
dry MeCN
dry MeCN
40
58
trace
82
62
trace
63
48
TBSOTf
TBSOTf
TBSOTf
TBSOTf
TBSOTf
TBSOTf
TBSOTf
TBSOTf
c
10
d
3
a
Standard conditions: 1a (0.20 mmol), 2a (1.5 equiv), 3a (40 equiv),
TBSOTf (1.1 equiv), TBADT (3 mol %), 4 Å MS (30 mg), MeCN
b
(0.1 M), 10 W 390 nm LEDs, 24 h. Yields of isolated products.
c
d
Without 4 Å MS molecular sieves. Without light.
mol % of TBADT as photocatalyst, BF3·Et2O as additive, and 4
Å molecular sieves in dry MeCN under irradiation of near-
ultraviolet light (390 nm, 10 W LEDs), the desired α-branched
tertiary amine product 4a was isolated in 40% yield (entry 1).
Different additives were first investigated (entries 2−4). To
our delight, tert-butyldimethylsilyl trifluoromethanesulfonate
(TBSOTf) was found to be the optimal candidate with 82%
yield of 4a (entry 4). The use of other solvents was explored
but provided no improvement over dry acetonitrile (entries 5
and 6). Moreover, reducing the photocatalyst loading led to a
drop of reaction efficiency (entries 7 and 8), and the reaction
in the absence of 4 Å molecular sieves resulted in much lower
yields (entry 9). As anticipated, control experiments revealed
that light, photocatalyst, as well as additive are essential for this
transformation (entries 10−12).
4474
Org. Lett. 2021, 23, 4473−4477
