PAPER
Asymmetric Synthesis of (–)-6-epi-Centrolobine
2941
IR (neat): 3443, 2926, 2855, 1609, 1510, 1249, 1081, 778 cm–1.
13C NMR (75 MHz, CDCl3): d = 159.4, 132.8, 129.6 (2 × C), 127.6,
125.4, 113.8 (2 × C), 73.8, 67.7, 65.5, 55.4, 26.5.
1H NMR (300 MHz, CDCl3): d = 7.22 (d, J = 9.0 Hz, 2 H), 6.76 (d,
J = 9.0 Hz, 2 H), 5.9 (s, 2 H), 5.06 (s, 1 H), 4.1 (d, J = 6.7 Hz, 1 H),
3.71 (s, 3 H), 3.71–3.67 (m, 1 H), 3.64–3.57 (m, 1 H), 3.33–3.25
(m, 1 H), 2.93 (br s, 1 H), 0.82 (s, 9 H), 0.01 (s, 6 H).
HRMS (ESI): m/z [M + Na]+ calcd for C13H16O3Na: 243.0997;
found: 243.1000.
(2S,6S)-6-[4-(Benzyloxy)styryl]-2-(4-methoxyphenyl)-5,6-dihy-
dro-2H-pyran (11)
13C NMR (75 MHz, CDCl3): d = 159.6, 131.6, 129.8 (2 × C), 129.5,
128.7, 113.8 (2 × C), 73.7, 70.9, 67.4, 66.0, 55.4, 26.0 (3 × C), 18.3,
–5.3, –5.4.
HRMS (ESI): m/z [M + Na]+ calcd for C19H30O4NaSi: 373.1811;
found: 373.1823.
To a solution of alcohol 4 (0.1 g, 0.45 mmol) under a nitrogen atmo-
sphere was added anhydrous CH2Cl2 (5 mL) and Dess–Martin peri-
odinane (0.19 g, 0.45 mmol) at 0 °C and the reaction was stirred at
the same temperature for 30 min. The reaction mixture was
quenched with aq sat. Na2S2O3 (10 mL), the organic layer was sep-
arated and the aqueous layer was extracted with CH2Cl2 (3 × 10
mL). The combined organic layers were washed with brine (15
mL), dried over Na2SO4 and evaporated in vacuo to obtain the crude
product, which was used for the next step without purification.
(2S,6S)-6-[(tert-Butyldimethylsilyloxy)methyl]-2-(4-methoxy-
phenyl)-5,6-dihydro-2H-pyran (10)
To a solution of compound 9 (0.25 g, 0.71 mmol) in CH2Cl2 (5 mL)
was added pyridine (0.18 mL, 2.2 mmol), PTSA (0.17 g, 0.9 mmol)
and a catalytic amount of DMAP at 0 °C, and the reaction was
stirred for 2 h at the same temperature. After the reaction was com-
plete (monitored by TLC), the reaction mixture was diluted with
CH2Cl2 (5 mL), washed with aq sat. CuSO4 (2 × 5 mL), brine (5
mL), dried over Na2SO4 and concentrated to dryness. The residue
was passed through a silica gel pad (EtOAc–hexanes, 1:9), to obtain
the corresponding tosylated compound (~0.36 g), which was imme-
diately used in the next step.
To a solution of phosphonium salt 3 (1.24 g, 2.29 mmol) in THF (5
mL) at 0 °C was added n-BuLi (1.07 mL, 1.72 mmol, 1.6 M in hex-
anes). The solution turned orange-red and was stirred for 20 min at
0 °C. To this, a solution of the above prepared aldehyde (0.25 g,
1.15 mmol) in THF (5 mL) was added and the reaction mixture was
stirred for 30 min at 0 °C. After the reaction was complete (moni-
tored by TLC), the mixture was quenched with aq sat. NH4Cl (10
mL) and extracted with EtOAc (3 × 10 mL). The combined organic
layers were washed with brine (15 mL), dried over Na2SO4 and con-
centrated to dryness. Purification of the residue by silica gel column
chromatography (EtOAc–hexanes, 3%) gave 11.
To a suspension of LAH (0.077 g, 2.01 mmol) in anhydrous THF (5
mL) at 0 °C was added the above obtained tosylated compound
(0.36 g, 0.67 mmol) in THF (5 mL) and the reaction was stirred at
r.t. for 3 h. After the reaction was complete (monitored by TLC), the
mixture was quenched with moistened Na2SO4 (50 mg) at 0 °C and
stirring was continued for 3 h. The white colored salts were filtered
on a sintered-glass funnel and the residue was rinsed with H2O (20
mL), EtOAc (3 × 10 mL). The organic layer was separated and
washed with brine (15 mL), dried over Na2SO4 and concentrated on
rotary evaporator. The residue obtained was purified by silica gel
column chromatography (EtOAc–hexanes, 1:4) to yield 10.
Yield: 0.198 g (88%); viscous oil; [a]D25 –132.5 (c 1.4, CHCl3).
IR (neat): 2928, 2856, 1604, 1512, 1252, 1106, 838 cm–1.
1H NMR (300 MHz, CDCl3): d = 7.25 (d, J = 8.3 Hz, 2 H), 6.78 (d,
J = 8.3 Hz, 2 H), 6.0–5.9 (m, 2 H), 5.14 (s, 1 H), 3.77 (s, 3 H), 3.76–
3.67 (m, 1 H), 3.64–3.47 (m, 2 H), 2.26–2.18 (m, 1 H), 2.04–1.99
(m, 1 H), 0.85 (s, 9 H), 0.01 (s, 6 H).
Yield: 0.39 g (87.3%); a 2:3 mixture of E/Z isomers.
IR (neat): 3448, 2922, 2852, 1605, 1509, 1244, 1174, 1032, 838,
739 cm–1.
1H NMR (300 MHz, CDCl3): d = 7.42–7.21 (m, 9 H), 6.92–6.76 (m,
4 H), 6.51 (d, J = 9.0 Hz, 1 H), 6.43 (d, J = 11.3 Hz, 1 H), 6.11–5.86
(m, 2 H), 5.24 (s, 1 H), 5.04 (s, 1 H), 4.95 (s, 1 H), 4.51–4.41 (m,
1 H), 3.81 (s, 3 H), 2.23–2.14 (m, 2 H).
13C NMR (75 MHz, CDCl3): d = 159.6, 159.3, 158.5, 157.9, 137.1,
133.4, 133.1, 132.9, 130.5, 130.4, 130.2, 130.0, 129.5, 128.7, 128.1,
127.9, 127.8, 127.6, 125.5, 125.3, 115.0, 114, 4, 113.9, 113.8, 74.0,
73.7, 70.2, 69.9, 68.4, 64.1, 55.5, 31.5, 30.9.
HRMS (ESI): m/z [M + Na]+ calcd for C27H26O3Na: 421.1779;
found: 421.1795.
13C NMR (75 MHz, CDCl3): d = 159.1, 133.3, 129.4 (2 × C), 127.9,
125.4, 113.6 (2 × C), 73.6, 68.2, 66.3, 55.3, 27.5, 26.0 (3 × C), 18.4,
–5.2 (2 × C).
(2S,6S)-6-[4-(Hydroxy)phenethyl]-2-(4-methoxyphenyl)-tetra-
hydro-2H-pyran (2)
To a solution of compound 11 (0.03 g, 0.07 mmol) in a mixture of
EtOAc–MeOH (3:1, 3 mL) was added a catalytic amount of PtO2
and the mixture was kept under a H2 atmosphere (balloon) for 8 h at
27 °C. After completion of the reaction (monitored by TLC), the re-
action mixture was filtered through a pad of celite and concentrated
to dryness. Purification of the residue by silica gel column chroma-
tography (EtOAc–hexanes, 1:5) afforded the desired product 2.
HRMS (ESI): m/z [M + Na]+ calcd for C19H30O4NaSi: 357.1861;
found: 357.1874.
(2S,6S)-6-(Hydroxymethyl)-2-(4-methoxyphenyl)-5,6-dihydro-
2H-pyran (4)
To a solution of tert-butyldimethylsilyl ether 10 (0.5 g, 1.49 mmol)
in THF (7 mL) was added TBAF (0.52 mL, 1.79 mmol, 1M in THF)
at r.t., and the mixture was stirred for 1 h. The reaction mixture was
quenched with aq sat. NH4Cl (10 mL), diluted with H2O (10 mL)
and the mixture was extracted with EtOAc (3 × 10 mL). The com-
bined organic layers were washed with brine (15 mL), dried over
Na2SO4 and evaporated in vacuo to give the crude product, which
was purified by silica gel column chromatography (EtOAc-hex-
anes, 1:3) to obtain 4.
Yield: 0.33 g (97.5%); white solid; mp 41–43 °C; [a]D25 –149.9 (c
1.1, CHCl3).
IR (neat): 3420, 2924, 1610, 1511, 1245,1032, 827 cm–1.
Yield: 0.22 g (98%); [a]D25 –1.4 (c 0.4, CHCl3).
IR (neat): 3441, 2923, 2853, 1613, 1512, 1244, 1033, 760 cm–1.
1H NMR (300 MHz, CDCl3): d = 7.29 (d, J = 8.7 Hz, 2 H), 7.02 (d,
J = 8.4 Hz, 2 H), 6.86 (d, J = 9.0 Hz, 2 H), 6.69 (d, J = 8.4 Hz, 2 H),
4.97 (br s, 1 H), 4.78 (t, J = 5.4 Hz, 1 H), 3.78 (s, 3 H), 3.76–3.72
(m, 1 H), 2.76–2.66 (m, 1 H), 2.57–2.47 (m, 1 H), 1.88–1.82 (m,
2 H), 1.75–1.57 (m, 6 H).
13C NMR (75 MHz, CDCl3): d = 158.8, 153.8, 134.7, 134.5, 129.6
(2 × C), 128.0 (2 × C), 115.3 (2 × C), 113.9 (2 × C), 72.0, 71.4, 55.5,
35.4, 31.5, 30.3, 30.1, 19.2.
1H NMR (300 MHz, CDCl3): d = 7.26 (d, J = 8.3 Hz, 2 H), 6.83 (d,
J = 9.0 Hz, 2 H), 6.08–5.91 (m, 2 H), 5.19 (s, 1 H), 3.79 (s, 3 H),
3.76–3.68 (m, 1 H), 3.64–3.45 (m, 2 H), 1.96–1.86 (m, 2 H).
HRMS (ESI): m/z [M + Na]+ calcd for C20H24O3Na: 335.1623;
found: 335.1634.
Synthesis 2008, No. 18, 2939–2942 © Thieme Stuttgart · New York
