(PPh3)AuCl/AgOTf-catalyzed intermolecular hydroamination of alkynes with sulfonamides to form N-sulfonyl imines

Article abstract of DOI:10.1055/s-0029-1219384

In the presence of a catalytic amount of (PPh₃)AuCl and AgOTf, intermolecular hydroamination of unactivated alkynes with sulfonamides has been shown to proceed and give N-sulfonyl ketimines in medium to excellent yields.

Full text of DOI:10.1055/s-0029-1219384

LETTER
809
(PPh3)AuCl/AgOTf-Catalyzed Intermolecular Hydroamination of Alkynes
with Sulfonamides To Form N-Sulfonyl Imines
Synthesis of
N
-
Sul
o
fonyl Iminesng-Mei Cui,*a Jin-Zhou Zheng,a Liu-Yang Yang,a Chen Zhangb
a
College of Pharmaceutical Science, Zhejiang University of Technology, Hangzhou 310014, P. R. of China
Fax +86(571)88320320; E-mail: cuidongmei@zjut.edu.cn
b
School of Pharmaceutical Sciences, Zhejiang University, Hangzhou 310058, P. R. of China
Received 9 October 2009
alkynes to full conversion (entry 3). Decreasing the
amount of AgOTf resulted in lower yields (entries 4 and
5). Using either gold or silver precatalyst alone gave lower
yields (entries 6 and 7). These results indicated that both
Au source and AgOTf played a crucial role in this hy-
droamination. The superior efficiency of trifluo-
romethanesulfonate anion through a comparison with
other weakly or noncoordinating counteranion was dem-
onstrated. While methanesulfonate and tetrafluoroborate
as counteranions were ineffective, change of counteranion
to hexafluroantimonate led to 73% yield of 3a (entries 8–
10). Only trace of 3a was formed by using Cu(OTf)2
which was a robust catalyst in intramolecular hydroami-
nation of alkynylsulfonamides (entry 11).11b Other metal
catalysts such as (PPh3)2NiCl2, (PPh3)2PdCl2, and
(cod)PtCl2 were ineffective (entries 12–14). Different sol-
vents were screened and toluene was found to be the most
suitable one. Other solvents, such as chloroform, THF,
and dioxane were compatible to the hydroamination. In all
case, 1-(4-methoxyphenyl)ethanone as the hydration
product could be detected due to water present in small
amounts in the reaction solution. In addition, the reaction
of 1-(4-methoxyphenyl)ethanone, instead of 1a, with 2a
did not proceed at all under the same conditions.
Abstract: In the presence of a catalytic amount of (PPh3)AuCl and
AgOTf, intermolecular hydroamination of unactivated alkynes with
sulfonamides has been shown to proceed and give N-sulfonyl
ketimines in medium to excellent yields.
Key words: hydroamination, N-sulfonyl ketimines, sulfonamide,
alkyne, gold catalysis
N-Sulfonyl imines are useful building blocks in organic
and medicinal chemistry.1 The most common method re-
ported in the literature for synthesis of these compounds
involves the condensation of carbonyl compounds with
sulfonamides.2 Syntheses of N-sulfonyl imines have also
been reported using other approaches, including the con-
densation of oximes with sulfinyl chlorides3 or sulfonyl
cyanides,4 isomerization of aziridines,5 reaction of the
carbonyl compounds with sulfinamides and following ox-
idation.6 Despite these advantages, several drawbacks re-
main associated with such reactions, including the use of
harsh acids and generating toxic byproducts in a multistep
process. Thus, development of new methods for their syn-
thesis is still needed.
Gold salts are powerful soft Lewis acids and readily pro-
mote reaction of unsaturated C–C bonds with a variety of
nucleophiles for the formation of carbon–carbon and car-
bon–heteroatom bonds.7,8 In the literature, a wide range of
metal-catalyzed inter- and intramolecular hydroamination
of alkynes are known, but the intermolecular hydroamina-
tion of alkynes with sulfonamides has not been reported
previously.9–16 On the basis of some recent studies,17 here-
in we describe an efficient gold-catalyzed intermolecular
hydroamination of unactivated alkynes with sulfonamides
to afford N-sulfonyl imines.
To further assess the scope of this process, we have exam-
ined the hydroamination of different alkynes with sul-
fonamides using the optimized reaction conditions as
described in entry 1 of Table1. The results are summa-
rized in Table2. Alkynes with an electron-donating group
on the benzene ring all gave higher the yields (entries 1–
4). In sharp contrast, with an electron-withdrawing sub-
stituent on the aromatic ring, the corresponding adduct 3g
was obtained in 40% yield (entry 6). Various aryl sulfona-
mides were then examined, not only electron-donating but
also electron-withdrawing groups on benzene ring of phe-
nylsulfonamide gave excellent yields (entries 1 and 7–10).
Under the same reaction conditions, hydroamination of al-
iphatic sulfonamides took place smoothly to afford the
corresponding N-sulfonyl ketimine 3l with 72% yield
(entry 11). In addition, p-TolSO2NHNH2 was also an
efficient substrate for hydroamination (entry 12). Further-
more, in striking contrast to aromatic alkynes, aliphatic
alkynes, such as 1-octyne and internal alkynes, such as
diphenylacetylene, failed to undergo Au-catalyzed hy-
droamination under the same conditions.
The reaction of 4-methoxyphenylacetylene (1a, 1.5
mmol) with 4-methylbenzenesufonamide (2a, 0.5 mmol)
in the presence of 2 mol% of (PPh3)AuCl and 8 mol% of
AgOTf in toluene at 100 °C proceeded efficiently to form
3a in 97% yield with perfect regioselectivity (Table1, en-
try 1). Efficient hydroamination was realized with signif-
icantly lower catalyst loading (entry 2). Investigation of
molar ratio of the starting materials revealed that an ex-
cess of alkynes (2–3 equiv) was necessary to drive the
SYNLETT 2010, No. 5, pp 0809–0811
1
6.
3
.2
0
1
0
Advanced online publication: 10.02.2010
DOI: 10.1055/s-0029-1219384; Art ID: W16509ST
© Georg Thieme Verlag Stuttgart · New York

810
J.-Z. Zheng et al.
LETTER
Table 1 Hydroamination of 1a with 2aa
Table 2 Reaction Scope for the Hydroamination of Alkynes with
Sulfonamidesa
NTs
catalyst
PG
N
additive
MeO
+
TsNH2
toluene
100 °C, 9 h
(PPh3)AuCl
R
AgOTf
+
PG NH2
MeO
R
toluene
1a
2a
3a
1
2
3
Entry Cat. (mol%)
Additive (mol%)
AgOTf (8)
AgOTf (8)
AgOTf (8)
AgOTf (6)
AgOTf (4)
–
Yield of 3a (%)b
Entry
1
PG
R
Product
3b
3c
Yield (%)b
1
2
3c
4
5
6
7
8
9
(PPh3)AuCl (2)
(PPh3)AuCl (1)
(PPh3)AuCl (2)
(PPh3)AuCl (2)
(PPh3)AuCl (2)
(PPh3)AuCl (2)
–
97
96
88
66
50
10
35
11
trace
73
trace
0
4-TolSO2
4-TolSO2
4-TolSO2
4-TolSO2
4-TolSO2
4-TolSO2
2-TolSO2
PhSO2
4-EtO
99
77
80
78
91
40
98
91
96
99
72
63
2c
4-n-C5H11
4-n-Bu
4-Et
3c
3d
3e
4c
5c
H
3f
6c
3-F
3g
AgOTf (8)
AgOMs (8)
AgBF4 (8)
AgSbF6 (8)
–
7
4-EtO
4-MeO
4-MeO
4-MeO
4-MeO
4-EtO
3h
3i
(PPh3)AuCl (2)
(PPh3)AuCl (2)
(PPh3)AuCl (2)
Cu(OTf)2 (2)
(PPh3)2NiCl2 (2)
(PPh3)2PdCl2 (2)
(cod)PtCl2 (2)
(PPh3)AuCl (2)
(PPh3)AuCl (2)
–
8
9
4-BrPhSO2
4-IPhSO2
MeSO2
3j
10
10
11c
12c
3k
3l
11
12
–
4-TolSO2NH
3m
13
–
0
a Reaction conditions: 1 (1.5 mmol), 2 (0.5 mmol), (PPh3)AuCl (0.01
mmol), AgOTf (0.04 mmol), toluene (2 mL), 100 °C, 9 h.
b Isolated yields.
14
–
0
15d
16d
17d
AgOTf (8)
TfOH (8)
TfOH (8)
78
0
c Using 2 mL of THF as solvent.
SO2R
Ar
N
[M]
0
Ar
a Conditions: 1a (1.5 mmol), 2a (0.5 mmol), cat. (0–2 mol%), silver
salt (0–8 mol%), toluene (2 mL), 100 °C, 9 h.
H+
b Isolated yields.
c Using 1.0 mmol of 2a.
d At r.t.
Ar
NHSO2R
Ar
[M]
[Au]
H
On the basis of the experiments and precedent reports,8g,18
a plausible mechanism is shown in Scheme1. We pro-
posed that (PPh3)Au+, generated in situ from (PPh3)AuCl
and Ag+, coordinated to the alkyne to form a cationic
M(I)–alkyne complex. Then the complex underwent an
intermolecular nucleophilic attack by sulfonamide to fin-
ish the reaction.
H+
RSO2NH2
Scheme 1 Proposed mechanism for hydroamination
Acknowledgment
This work was partially supported by the Natural Science Founda-
tion of China (Nos. 20672099, 20572094).
In conclusion, we have demonstrated an efficient
(PPh3)AuCl/AgOTf-catalyzed intermolecular hydroami-
nation of unactivated alkynes with sulfonamides to pro-
duce N-sulfonyl ketimines under mild conditions with
perfect regioselectivity.19 Further efforts to expand the
scope of the chemistry and studies of the detailed mecha-
nism are currently under way in our laboratories.
References and Notes
(1) (a) Weinreb, S. M. Top. Curr. Chem. 1997, 190, 131.
(b) Bloch, R. Chem. Rev. 1998, 98, 1407.
(2) (a) Ram, R. N.; Khan, A. A. Synth. Commun. 2001, 31, 841.
(b) Jin, T.; Feng, G.; Yang, M.; Li, T. Synth. Commun. 2004,
34, 1277. (c) Love, B. E.; Raje, P. S.; Willimas, T. C. I. I.
Synlett 1994, 493.
Supporting Information for this article is available online at
http://www.thieme-connect.com/ejournals/toc/synlett.
Synlett 2010, No. 5, 809–811 © Thieme Stuttgart · New York

LETTER
Synthesis of N-Sulfonyl Imines
811
(3) (a) Artman, G. D. III; Bartolozzi, A.; Franck, R. W.;
Weinreb, S. M. Synlett 2001, 232. (b) Brown, C.; Hudson,
R. F.; Record, K. A. F. J. Chem. Soc., Perkin Trans. 2 1978,
822.
(4) Boger, D. L.; Corbett, W. L. J. Org. Chem. 1992, 57, 4777.
(5) Wolfe, J. P.; Ney, J. E. Org. Lett. 2003, 5, 4607.
(6) Ruano, J. L. G.; Alemán, J.; Cid, M. B.; Parra, A. Org. Lett.
2005, 7, 179.
(7) Recent reviews, see: (a) Gorin, D. J.; Sherry, B. D.; Toste,
F. D. Chem. Rev. 2008, 108, 3351. (b) Jiménez-Núñez, E.;
Echavarren, A. M. Chem. Rev. 2008, 108, 3326. (c) Arcadi,
A. Chem. Rev. 2008, 108, 3266. (d) Li, Z.; Brouwer, C.; He,
C. Chem. Rev. 2008, 108, 3239. (e) Skouta, R.; Li, C.-J.
Tetrahedron 2008, 64, 4917. (f) Shen, H. C. Tetrahedron
2008, 64, 3885. (g) Muzart, J. Tetrahedron 2008, 64, 5815.
(h) Hashmi, A. S. K. Chem. Rev. 2007, 107, 3180.
(i) Hashmi, A. S. K. Gold Bull. 2004, 37, 51. (j) Arcadi, A.;
Di Giuseppe, S. Curr. Org. Chem. 2004, 8, 795.
(k) HashmiA, S. K.; Hutchings, G. J. Angew. Chem. Int. Ed.
2006, 45, 7896.
(13) Istrate, F. M.; G agosz, F. Org. Lett. 2007, 9, 3181.
(14) Kurisaki, T.; Naniwa, T.; Yamamoto, H.; Imagawa, H.;
Nishizawa, M. Tetrahedron Lett. 2007, 48, 1871.
(15) For intermolecular addition of sulfonamides to conjugated
alkynoates, see: Trost, B. M.; Dake, G. R. J. Am. Chem. Soc.
1997, 119, 7595.
(16) (a) Liu, X.-Y.; Ding, P.; Huang, J.-S.; Che, C. M. Org. Lett.
2007, 9, 2645. (b) Fukuda, Y.; Utimoto, K.; Nozaki, H.
Heterocycles 1987, 25, 297. (c) Müller, T. E. Tetrahedron
Lett. 1998, 39, 5961. (d) Hashmi, A. S. K.; Rudolph, M.;
Schymura, S.; Visus, J.; Frey, W. Eur. J. Org. Chem. 2006,
4905.
(17) (a) Zhang, C.; Cui, D.-M.; Yao, L.-Y.; Wang, B.-S.; Hu,
Y.-Z.; Hayashi, T. J. Org. Chem. 2008, 73, 7811. (b) Cui,
D.-M.; Zheng, Z.-L.; Zhang, C. J. Org. Chem. 2009, 74,
1426. (c) Cui, D.-M.; Meng, Q.; Zheng, J.-Z.; Zhang, C.
Chem. Commun. 2009, 1577. (d) Cui, D.-M.; Yu, K.-R.;
Zhang, C. Synlett 2009, 1103.
(18) Zhang, J.; Yang, C.-G.; He, C. J. Am. Chem. Soc. 2006, 128,
1798.
(8) Selected references: (a) Shapiro, N. D.; Toste, F. D. J. Am.
Chem. Soc. 2007, 129, 4160. (b) Dube, P.; Toste, F. D.
J. Am. Chem. Soc. 2006, 128, 12062. (c) Marion, N.; Díez-
González, S.; de Frémont, P.; Noble, A. R.; Nolan, S. P.
Angew. Chem. Int. Ed. 2006, 45, 3647. (d) Zhang, Y.;
Donahue, J. P.; Li, C.-J. Org. Lett. 2007, 9, 627.
(e) Mizushima, E.; Sato, K.; Hayashi, T.; Tanaka, M. Angew.
Chem. Int. Ed. 2002, 41, 4563. (f) Liu, B.; De Brabander,
J. K. Org. Lett. 2006, 8, 4907. (g) Mizushima, E.; Hayashi,
T.; Tanaka, M. Org. Lett. 2003, 5, 3349. (h) Arcadi, A.; Di
Giuseppe, S.; Marinelli, F.; Rossi, E. Adv. Synth. Catal.
2001, 343, 443. (i) Hashmi, A. S. K.; Weyrauch, J. P.; Frey,
W.; Bats, J. W. Org. Lett. 2004, 6, 4391. (j) Luo, Y. M.; Li,
Z. G.; Li, C. J. Org. Lett. 2005, 7, 2675. (k) Lavallo, V.;
Frey, G. D.; Donnadieu, B.; Soleihavoup, M.; Bertrand, G.
Angew. Chem. Int. Ed. 2008, 47, 5224.
(19) Typical Experimental Procedure
To a reactor containing sulfonamide (0.5 mmol),
(PPh3)AuCl (0.01 mmol), AgOTf (0.04 mmol), and anhyd
toluene (2 mL), was added alkyne (1.5 mmol). The mixture
was then sealed and stirred at 100 °C. After 9 h, it was
quenched with sat. soln of NaHCO3 and then with EtOAc
(3 × 10 mL), dried over Na2SO4, and concentrated in vacuo.
The residue was purified by flash chromatography to give
the pure product.
N-[1-(4-Ethoxyphenyl)ethylidene]-4-methylbenzene-
sulfonamide (3b)
Yellow solid; mp 103–105 °C. 1H NMR (500 MHz, CDCl3):
δ = 7.92–7.88 (m, 4 H), 7.32 (d, J = 8.0 Hz, 2 H), 6.86 (d,
J = 9.0 Hz, 2 H), 4.06 (q, J = 7.0 Hz, 2 H), 2.92 (s, 3 H), 2.43
(s, 3 H), 1.41 (t, J = 7.0 Hz, 3 H). 13C NMR (125 MHz,
CDCl3): δ = 178.7, 163.4, 143.3, 139.1, 130.7, 129.7, 129.4,
127.0, 114.3, 63.9, 21.6, 20.7, 14.6. IR (KBr): 2980, 2936,
2884, 1607, 1578, 1557, 1385, 1173, 1150 cm–1. HRMS
(CI): m/z calcd for C17H19NO3S [M + H]+: 318.1164; found:
318.1164.
(9) Yin, Y.; Ma, W.; Chai, Z.; Zhao, G. J. Org. Chem. 2007, 72,
5731.
(10) (a) Hiroya, K.; Matsumoto, S.; Sakamoto, T. Org. Lett.
2004, 6, 2953. (b) Hiroya, K.; Matsumoto, S.; Ashikawa,
M.; Kida, H.; Sakamoto, T. Tetrahedron 2005, 61, 12330.
(c) Wolf, L. B.; Tjen, K. C. M. F.; ten Brink, H. T.; Blaauw,
R. H.; Hiemstra, H.; Schoemaker, H. E.; Rutjes, F. P. J. T.
Adv. Synth. Catal. 2002, 344, 70.
(11) (a) Hiroya, K.; Itoh, S.; Sakamoto, T. Tetrahedron 2005, 61,
10958. (b) Hiroya, K.; Itoh, S.; Ozawa, M.; Kanamori, Y.;
Sakamoto, T. Tetrahedron Lett. 2002, 43, 1277.
(12) Barange, D. K.; Nishad, T. C.; Swamy, N. K.; Bandameedi,
V.; Kumar, D.; Sreekanth, B. R.; Vyas, K.; Pal, M. J. Org.
Chem. 2007, 72, 8547.
N-[1-(4-Methoxyphenyl)ethylidene]methane-
sulfonamide (3l)
Pale yellow solid; mp 107–108 °C. 1H NMR (500 MHz,
CDCl3): δ = 7.94 (d, J = 9.0 Hz, 2 H), 6.93 (d, J = 9.0 Hz, 2
H), 3.88 (s, 3 H), 3.22 (s, 3 H), 2.86 (s, 3 H). 13C NMR (125
MHz, CDCl3): δ = 178.9, 163.9, 130.5, 129.6, 114.0, 55.6,
43.2, 20.8. IR (KBr): 3032, 2937, 1635, 1609, 1595, 1384,
1182, 1143 cm–1. HRMS (EI): m/z calcd for C10H13NO3S
[M]+: 227.0616; found: 227.0612.
Synlett 2010, No. 5, 809–811 © Thieme Stuttgart · New York

Copyright of Synlett is the property of Georg Thieme Verlag Stuttgart and its content may not
be copied or emailed to multiple sites or posted to a listserv without the copyright holder's
express written permission. However, users may print, download, or email articles for
individual use.
