Palladium-catalysed direct alkenylation of sydnones

Article abstract of DOI:10.1016/j.tetlet.2009.04.075

Sydnones have been directly functionalised with alkenyl halides and an alkynyl bromide under palladium catalysis.

Full text of DOI:10.1016/j.tetlet.2009.04.075

Tetrahedron Letters 50 (2009) 3942–3944
Contents lists available at ScienceDirect
Tetrahedron Letters
journal homepage: www.elsevier.com/locate/tetlet
Palladium-catalysed direct alkenylation of sydnones
*
Arantxa Rodriguez, Rebecca V. Fennessy, Wesley J. Moran
Department of Chemical and Biological Sciences, University of Huddersfield, Queensgate, Huddersfield HD1 3DH, UK
a r t i c l e i n f o
a b s t r a c t
Article history:
Sydnones have been directly functionalised with alkenyl halides and an alkynyl bromide under palladium
Received 13 March 2009
Revised 3 April 2009
Accepted 21 April 2009
Available online 24 April 2009
catalysis.
Ó 2009 Elsevier Ltd. All rights reserved.
The palladium-catalysed direct cross-coupling reaction of elec-
tron-rich heteroaromatics with aryl halides and pseudohalides has
emerged as an incredibly useful and general synthetic technique to
access biaryl structures.1 These processes are superior to tradi-
tional cross-coupling techniques because a stoichiometric amount
of an organometallic reagent is not required. This results in lower
costs, less waste and, if the organometallic would need to be pre-
pared, shorter syntheses. This concept has been applied success-
fully to the direct coupling of a range of heterocycles including
furans,2 oxazoles,3 imidazoles,4 triazoles,5 purines,6 indoles7 and
pyrroles.8 Examples of intramolecular direct couplings have also
been reported.9
Our research group recently reported the direct cross-coupling
of aryl iodides and bromides with sydnones under palladium catal-
ysis (e.g., in Scheme 1).10 N-Phenyl and N-methyl sydnones were
found to react efficiently with aryl iodides and bromides in the
presence of palladium acetate (5 mol %), triphenylphosphine
(10 mol %) and potassium carbonate (2 equiv) in wet N,N-dimeth-
ylformamide at reflux open to air. Sydnones are five-membered
heterocycles which are part of an intriguing family of molecules
termed mesoionic.11 Sydnones have been investigated for their po-
tential uses as therapeutic agents,12 as liquid crystals13 and as elec-
trolytic solvents.14 In synthesis, the principal reactions of sydnones
are metallation,15 electrophilic aromatic substitutions and 1,3-
dipolar cycloadditions,16 however little new reactivity has been re-
vealed over the last few decades.17 Kalinin and Min have shown
that sydnones can be deprotonated at C-4 with butyllithium to
form unstable species in solution. Subsequent addition of copper(I)
bromide leads to the formation of relatively stable complexes that
can take part in palladium-catalysed coupling reactions with iodo-
arenes and b-bromostyrene in excellent overall yields.15a A recent
report by Harrity and co-workers has shown the application of the
Suzuki cross-coupling reaction to functionalising 4-bromosydnon-
es with a range of aryl boronic acids and with styrylboronic acid
under palladium catalysis.18
We set out to increase the scope of the direct cross-coupling
reaction with sydnones and investigated the reactivity of alkenyl
halides under our optimised conditions.19 We were pleased to find
that
a-bromostyrene coupled efficiently with N-phenyl sydnone
providing the product in 78% yield (Table 1, entry 1).20 Both (E)-
and (Z)-b-bromostyrene coupled successfully with the sydnone
(entries 2 and 3), however the latter product underwent slow (Z)
to (E) alkene isomerisation at room temperature. After eight
months at ambient conditions a 1:7 (E)/(Z) mixture had formed.
The para-methyl-substituted (E)-b-bromostyrene derivative
underwent clean conversion providing 62% of product (entry 4)
and (E)-2-(2-bromovinyl)naphthalene furnished 65% of the cou-
pled sydnone (entry 5). The trisubstituted vinyl bromide (entry
6) was coupled successfully albeit in somewhat lower yield of
42%. Surprisingly, 1-bromohex-1-ene and (3-bromoallyl)benzene
failed to react under the reaction conditions returning starting
materials (entries 7 and 8). However, the trisubstituted alkenyl io-
dide synthesised from cyclohexanone was coupled successfully in
moderate yield (entry 9). N-Methyl sydnone also coupled with a-
bromostyrene and (Z)-b-bromostyrene in moderate yields at the
lower temperature of 80 °C (entries 10 and 11). In the latter case,
very slow interconversion of the alkene from (Z) to (E) occurred
with an 11:1 (E)/(Z) mixture being present after eight months. As
with the arylation reaction, the N-methyl sydnone decomposes un-
der the reaction conditions at 120 °C, so the reactions have to be
run at 80 °C.
With these results in hand, the direct coupling of other electro-
philes was investigated. Accordingly, under our standard conditions,
* Corresponding author. Tel.: +44 0 1484 473741.
E-mail address: w.j.moran@hud.ac.uk (W.J. Moran).
Scheme 1. An example of the direct arylation of N-phenyl sydnone with
iodobenzene.
0040-4039/$ - see front matter Ó 2009 Elsevier Ltd. All rights reserved.
doi:10.1016/j.tetlet.2009.04.075

A. Rodriguez et al. / Tetrahedron Letters 50 (2009) 3942–3944
3943
Table 1
Direct alkenylation of sydnones
Entry
1
R
R0X
Yielda (%)
78
Ph
2
3
4
5
Ph
Ph
Ph
Ph
76
Figure 1. Postulated mechanism for the direct coupling reaction.
74
62
65
The mechanism of the coupling reaction is proposed to be oxi-
dative addition of Pd(0) to the alkenyl halide, then electrophilic
addition to the sydnone, followed by rearomatisation and reduc-
tive elimination to furnish the product and to regenerate the
Pd(0) catalyst (Fig. 1).10
In conclusion, the palladium-catalysed direct alkenylation of
sydnones with alkenyl halides has been achieved. The reaction
was found to be successful with di- and tri-substituted alkenyl ha-
lides. In addition, the first reported example of a palladium-cata-
lysed direct alkynylation of a heterocycle has been described.
6
7
Ph
Ph
Ph
Ph
Me
Me
42
0
Acknowledgements
We thank the Nuffield Foundation for the award of an Under-
graduate Summer Bursary (R.V.F.) and the University of Hudders-
field for funding.
8
0
Supplementary data
9
57
51b
46b
Supplementary data (full characterisation data of novel com-
pounds are provided) associated with this article can be found, in
the online version, at doi:10.1016/j.tetlet.2009.04.075.
10
References and notes
11
1. (a) Liégault, B.; Lapointe, D.; Caron, L.; Vlassova, A.; Fagnou, K. J. Org. Chem.
2009, 74, 1826; For reviews of direct arylations of heteroaromatics, see: (b)
Campeau, L.-C.; Fagnou, K. Chem. Commun. 2006, 1253; (c) Alberico, D.; Scott,
M. E.; Lautens, M. Chem. Rev. 2007, 107, 174; (d) Satoh, T.; Miura, M. Chem. Lett.
2007, 36, 200; (e) Seregin, I. V.; Gevorgyan, V. Chem. Soc. Rev. 2007, 36, 1173.
2. (a) McClure, M. S.; Glover, B.; McSorley, E.; Millar, A.; Osterhout, M. H.;
Roschangar, F. Org. Lett. 2001, 3, 1677; (b) Gottumukkala, A. L.; Doucet, H. Adv.
Synth. Catal. 2008, 350, 2183.
3. (a) Alagille, D.; Baldwin, R. M.; Tamagnan, G. D. Tetrahedron Lett. 2005, 46,
1349; (b) Hoarau, C.; Du Fou de Kerdaniel, A.; Bracq, N.; Grandclaudon, P.;
Couture, A.; Marsais, F. Tetrahedron Lett. 2005, 46, 8573; (c) Zhuravlev, F. A.
Tetrahedron Lett. 2006, 47, 2929; (d) Besselievre, F.; Mahuteau-Betzer, F.;
Grierson, D. S.; Piguel, S. J. Org. Chem. 2008, 73, 3278; (e) Derridj, F.; Djebbar, S.;
Benali-Baitich, O.; Doucet, H. J. Organomet. Chem. 2008, 693, 135; (f) Verrier, C.;
Martin, T.; Hoarau, C.; Marsais, F. J. Org. Chem. 2008, 73, 7383; (g) Ohnmacht, S.
A.; Mamone, P.; Culshawb, A. J.; Greaney, M. F. Chem. Commun. 2008, 1241; (h)
Flegeau, E. F.; Popkin, M. E.; Greaney, M. F. Org. Lett. 2008, 10, 2717; (i)
Ackermann, L.; Althammer, A.; Fenner, S. Angew. Chem., Int. Ed. 2009, 48, 201.
4. (a) Bellina, F.; Cauteruccio, S.; Mannina, L.; Rossi, R.; Viel, S. J. Org. Chem. 2005,
70, 3997; (b) Bellina, F.; Cauteruccio, S.; Mannina, L.; Rossi, R.; Viel, S. Eur. J. Org.
Chem. 2006, 693; (c) Bellina, F.; Cauteruccio, S.; Rossi, R. Eur. J. Org. Chem. 2006,
1379; (d) Bellina, F.; Cauteruccio, S.; Rossi, R. J. Org. Chem. 2007, 72, 8543; (e)
Bellina, F.; Calandri, C.; Cauteruccio, S.; Rossi, R. Tetrahedron 2007, 63, 1970; (f)
Bellina, F.; Cauteruccio, S.; Di Fiore, A.; Rossi, R. Eur. J. Org. Chem. 2008, 5436; (g)
Bellina, F.; Cauteruccio, S.; Di Fiore, A.; Marchetti, C.; Rossi, R. Tetrahedron 2008,
64, 6060.
a
Yield of isolated product.
Reaction run at 80 °C.
b
the coupling reactions of N-phenyl sydnone with benzyl bromide,
benzyl chloride, allyl bromide and (bromoethynyl)benzene were ex-
plored.21 In the event, only (bromoethynyl)benzene was coupled
successfully although in modest yield (Scheme 2). Notably, to the
best of the authors’ knowledge, this represents the first example of
a direct alkynylation of an aromatic molecule in the literature to
date.
5. (a) Chuprakov, S.; Chernyak, N.; Dudnik, A. S.; Gevorgyan, V. Org. Lett. 2007, 9,
2333; (b) Iwasaki, M.; Yorimitsu, H.; Oshima, K. Chem. Asian J. 2007, 2, 1430; (c)
Ackermann, L.; Vicente, R.; Born, R. Adv. Synth. Catal. 2008, 350, 741.
Scheme 2. Direct alkynylation of N-phenyl sydnone.

3944
A. Rodriguez et al. / Tetrahedron Letters 50 (2009) 3942–3944
ˇ
ˇ
ˇ
6. (a) Cerna, I.; Pohl, R.; Klepetárová, B.; Hocek, M. Org. Lett. 2006, 8, 5389; (b)
14. Sasaki, Y.; Hirobomi, O.; Handa, M. Nippon Kagaku Kaishi 1993, 11, 1217. ;Chem.
Abstr. 1994, 120, 34459t.
ˇ
ˇ
Cerna, I.; Pohl, R.; Hocek, M. Chem. Commun. 2007, 4729; (c) Storr, T. E.; Firth, A.
G.; Wilson, K.; Darley, K.; Baumann, C. G.; Fairlamb, I. J. S. Tetrahedron 2008, 64,
15. (a) Kalinin, V. N.; Min, S. F. J. Organomet. Chem. 1988, 352, C34; (b) Kalinin, V.
N.; Min, S. F.; Petrovskii, P. V. J. Organomet. Chem. 1989, 379, 195; (c)
Cherepanov, I. A.; Lebedev, S. N.; Kalinin, V. N. Synlett 1998, 667; (d)
Cherepanov, I. A.; Lebedev, S. N.; Kalinin, V. N. Russ. Chem. Bull. 1998, 47,
1725.
16. (a) Huisgen, R.; Grashey, R. Angew. Chem. 1962, 74, 29; (b) Vasil’eva, V. F.;
Yashunskii, V. G.; Shchukina, M. N. Zh. Obshch. Kim. 1960, 30, 698; (c) Browne,
D. L.; Helm, M. D.; Plant, A.; Harrity, J. P. A. Angew. Chem., Int. Ed. 2007, 46, 8656.
17. For the transformation of sydnones into oxadiazolinones with bromine in
acetic anhydride, see: Mallur, S. G.; Badami, B. V. Il Farmaco 2000, 55, 65.
18. Browne, D. L.; Taylor, J. B.; Plant, A.; Harrity, J. P. A. J. Org. Chem. 2009, 74, 396.
19. For the palladium-catalysed direct alkenylation, benzylation and alkylation of
ethyl oxazole-4-carboxylate, see: (a) Verrier, C.; Hoarau, C.; Marsais, F. Org.
Biomol. Chem. 2009, 7, 647; For the palladium-catalysed direct alkenylation of
pyridine N-oxides with acrylates, see: (b) Cho, S. H.; Hwang, S. J.; Chang, S. J.
Am. Chem. Soc. 2008, 130, 9254.
ˇ
ˇ
ˇ
6125; (d) Cerna, I.; Pohl, R.; Klepetárová, B.; Hocek, M. J. Org. Chem. 2008, 73,
9048; (e) Zhao, D.; Wang, W.; Lian, S.; Yang, F.; Lan, J.; You, J. Chem. Eur. J. 2009,
15, 1337.
7. (a) Lane, B. S.; Sames, D. Org. Lett. 2004, 6, 2897; (b) Lane, B. S.; Brown, M. A.;
Sames, D. J. Am. Chem. Soc. 2005, 127, 8050; (c) Toure, B. B.; Lane, B. S.; Sames,
D. Org. Lett. 2006, 8, 1979; (d) Djakovitch, L.; Dufaud, V.; Zaidi, R. Adv. Synth.
Catal. 2006, 348, 715; (e) Lebrasseur, N.; Larrosa, I. J. Am. Chem. Soc. 2008, 130,
2926; (f) Bellina, F.; Benelli, F.; Rossi, R. J. Org. Chem. 2008, 73, 5529.
8. Rieth, R. D.; Mankad, N. P.; Calimano, E.; Sadighi, J. P. Org. Lett. 2004, 6, 3981.
9. (a) Franck, P.; Hostyn, S.; Dajka-Halász, B.; Polonka-Bálint, Á.; Monsieurs, K.;
Mátyus, P.; Maes, B. U. W. Tetrahedron 2008, 64, 6030; (b) Meyers, C.;
Rombouts, G.; Loones, K. T. J.; Coelho, A.; Maes, B. U. W. Adv. Synth. Catal. 2008,
350, 465; (c) Blaszykowski, C.; Aktoudianakis, E.; Alberico, D.; Bressy, C.;
Hulcoop, D. G.; Jafarpour, F.; Joushaghani, A.; Laleu, B.; Lautens, M. J. Org. Chem.
2008, 73, 1888; (d) Bryan, C. S.; Lautens, M. J. Org. Lett. 2008, 10, 4633; (e)
Martins, A.; Lautens, M. J. Org. Chem. 2008, 73, 8705.
20. Representative procedure for the alkenylation of sydnones: a flask was charged
with 3-phenylsydnone (50 mg, 0.31 mmol, 1 equiv), Pd(OAc)2 (4 mg,
0.016 mmol, 0.05 equiv), K2CO3 (86 mg, 0.62 mmol, 2 equiv), PPh3 (8 mg,
10. Rodriguez, A.; Moran, W. J. Synthesis 2009, 650.
11. For reviews on sydnones, see: (a) Stewart, F. H. C. Chem. Rev. 1964, 64, 129; (b)
Newton, C. G.; Ramsden, C. A. Tetrahedron 1982, 38, 1965.
0.031 mmol, 0.1 equiv),
a-bromostyrene (61 lL, 0.47 mmol, 1.5 equiv) and
12. (a). J. Med. Chem. 1974, 17, 1337; (b) Hill, J. B.; Ray, R. E.; Wagner, H.; Aspinall,
R. L. J. Med. Chem. 1975, 18, 50; (c) Dunkley, C. S.; Thomas, C. J. Bioorg. Med.
Chem. Lett. 2003, 13, 2899; (d) Moustafa, M. A.; Gineinah, M. M.; Nasr, M. N.;
Bayoumi, W. A. H. Arch. Pharm. 2004, 337, 164.
13. (a) Geoffroy, I.; Carre, B.; Lemordant, D.; Herreyre, S.; Biensan, Ph. ITE Lett.
Batteries, New Technol. Med. 2000, 1, 20; (b) Chan, W.; Zhang, W.; Szeto, Y.
Mater. Lett. 2000, 42, 280; (c) Tien, H.; Hwang, Y.; Wen, T. J. Chin. Chem. Soc.
1998, 45, 209.
wet DMF (1 mL) and was heated at reflux for 12 h open to air. Upon cooling,
water (30 mL) was added to the reaction mixture that was extracted with
EtOAc (3 ꢀ 15 mL). The organic layers were combined, dried with MgSO4 and
filtered. The volatiles were removed in vacuo and the mixture was purified by
flash chromatography (5:1 PE/EtOAc on silica gel) to give 3-phenyl-4-(1-
phenylvinyl)sydnone (64 mg, 78%).
21. For the Sonogashira cross-coupling reactions of sydnones, see: Turnbull, K.;
Krein, D. M.; Tullis, S. A. Synth. Commun. 2003, 33, 2209.
