Synthesis of [n,5]-Spiroketals by Ring Enlargement of Donor-
Acceptor-Substituted Cyclopropane Derivatives
Christian Brand,† Gesche Rauch,† Michele Zanoni,† Birger Dittrich,‡ and
Daniel B. Werz*,†
†
€
Institut fu€r Organische und Biomolekulare Chemie der Georg-August-Universitat Gottingen, Tammannstr.
€
2, 37077 Go€ttingen, Germany, and ‡Institut fu€r Anorganische Chemie der Georg-August-Universita€t
€ €
Gottingen (X-ray Crystallography), Tammannstr. 4, 37077 Gottingen, Germany
dwerz@gwdg.de
Received September 2, 2009
Exocyclic enol ethers served as starting materials for the synthesis of [n,5]-spiroketals (n = 5, 6).
A metal-mediated cyclopropanation using ethyl diazoacetate afforded spiroannelated cyclopropane deriva-
tives bearing an ester group. A reduction of the corresponding ester by LiAlH4, followed by subsequent
oxidation using hypervalent iodine reagents, produced [n,5]-spiroketals in moderate to good yields. The key
step within this three-step sequence is the ring enlargement of the three-membered ring with an oxygen donor
and a carbonyl acceptor group into the five-membered enol ether system. Catalytic amounts of the Lewis acid
Yb(OTf)3 facilitate the ring enlargement and increase the yield of the corresponding spiroketal in many cases.
When Yb(OTf)3 was used, our experiments revealed an open transition state rather than a concerted
mechanism because the stereochemistry of the spirocenter was not conserved during the ring enlargement. As
a result, the thermodynamically more favored anomeric [n,5]-spiroketal was observed as the major product.
All the structures were established unambiguously by NOESY experiments.
Introduction
The classical route for the preparation of the spiroketal
motif is the Bronsted or Lewis acid mediated dehydrative
spirocyclization3 of the corresponding oxo diol 1 (Scheme 1).
This rather flexible method that can afford different ring
sizes is a thermodynamically driven process and commonly
results in a diaxial spiroketal arrangement 3. In such an
arrangement two anomeric effects are in operation leading to
a significant net energy stabilization.4 However, in the case of
acid-labile compounds (e.g., enol ethers) or in the case the
less thermodynamically stable isomer is required, this meth-
odology commonly fails.
The semirigid spiroketal moiety forms a characteristic
architectural feature in a plethora of simple as well as complex
natural products including insect pheromones and marine and
fungal toxins.1 A number of different ring arrangements are
observed in Nature; however the most abundant are [6,6]-,
[6,5]-, and [5,5]-spiroketals. The conformational and geo-
metric features of these frameworks have rendered spiroketals
as preferred targets in diversity-oriented synthesis.2
Accordingly, other spiroketal syntheses have attracted
considerable interest, and numerous elegant methods have
