3160
J. S. Yadav et al.
PAPER
(2R,4S)-4-(Benzyloxy)hept-6-en-2-ol (17)
mL). The organic phase was separated and the aqueous phase was
extracted with Et2O. The combined organic phases were washed
with brine, dried (Na2SO4), and concentrated in vacuo and purified
by flash chromatography to afford 20 (511 mg, 85%).
To a stirred soln of LiAlH4 (366 mg, 9.63 mmol) in anhyd THF (10
mL) at 0 °C, was added slowly a soln of 16 (700 mg, 3.21 mmol) in
anhyd THF (5 mL) and the mixture was stirred at r.t. for 2 h. After
completion, the mixture was quenched with sat. aq NH4Cl (20 mL)
at 0 °C and stirred for 1 h and then extracted with EtOAc (2 × 20
mL). The combined organic extracts were washed with brine (20
mL), dried (anhyd Na2SO4), and concentrated under reduced pres-
sure. The resulting residue was purified by column chromatography
(60–120 silica gel, EtOAc–hexane, 1:40) to afford 17 (632 mg,
90%) as a colorless liquid.
[a]D20 –33.5 (c 1.05, CHCl3).
IR (neat): 3675, 3468, 2928, 2852, 1731, 1597, 1459, 1431, 1350,
1205, 1066 cm–1.
1H NMR (300 MHz, CDCl3): d = 7.34–7.16 (m, 5 H), 6.41 (d,
J = 2.2 Hz, 2 H), 6.31 (t, J = 2.2 Hz, 1 H), 5.78–5.62 (m, 1 H), 4.27
(ABq, J = 11.3, 10.5 Hz, 2 H), 3.78–3.65 (s, 6 H), 3.47 (s, 2 H),
2.64–2.39 (m, 2 H), 1.83–1.74 (m, 1 H), 1.42–1.30 (m, 2 H), 1.27
(d, J = 6.0 Hz, 3 H).
13C NMR (75 MHz, CDCl3): d = 175.92, 170.89, 160.85, 137.66,
137.20, 136.24, 128.41, 128.06, 127.83, 107.26, 99.26, 72.41,
72.15, 68.37, 55.28, 42.18, 41.63, 39.48, 20.57.
[a]D20 –33.1 (c 0.61, CHCl3).
1H NMR (300 MHz, CDCl3): d = 7.36–7.22 (m, 5 H), 5.85–5.70 (m,
1 H), 5.13–5.03 (m, 2 H), 4.56 (ABq, J = 11.5 Hz, 2 H), 4.11–4.01
(m, 1 H), 3.72–3.68 (m, 1 H), 2.50–2.25 (m, 2 H), 1.65–1.57 (m, 2
H), 1.15 (d, J = 6.2 Hz, 3 H).
HRMS: m/z [M + Na]+ calcd for C23H28NaO7: 439.1732; found:
439.1723.
MS (EI): m/z = 221 [M + H]+.
(2R,4S)-4-(Benzyloxy)hept-6-en-2-yl 2-(3,5-Dimethoxyphe-
nyl)acetate (18)
(4R,6R)-6-(Benzyloxy)-9,11-dimethoxy-4-methyl-4,5,6,7-tetra-
hydro-2H-3-benzoxecine-2,8(1H)-dione (7)12
Reddish oil.
[a]D20 –5.90 (c 1.01, CHCl3).
To a stirred soln of 17 (500 mg, 2.28 mmol) in anhyd CH2Cl2 at 0
°C was added DMAP (557 mg, 4.56 mmol), DCC (940.7 mg, 4.56
mmol), and 3,5-dimethoxyphenylacetic acid (492 mg, 2.51 mmol)
and the resulting mixture was stirred at r.t. for 2 h. The mixture was
filtered, washed with brine, dried (Na2SO4), and concentrated in
vacuo. The residue was purified by column chromatography (hex-
anes–EtOAc, 10:1) to afford the 18 (815 mg, 90%) as a yellow oil.
[a]D20 –77.0 (c 1.15, CHCl3).
IR (KBr): 2934, 2839, 1730, 1597, 1459, 1431, 1350, 1205 cm–1.
1H NMR (300 MHz, CDCl3): d = 7.36–7.16 (m, 5 H), 6.38 (d,
J = 2.2 Hz, 2 H), 6.28 (t, J = 2.2 Hz, 1 H), 5.78–5.62 (m, 1 H), 5.08–
4.96 (m, 2 H), 4.22 (ABq, J = 11.3, 10.5 Hz, 2 H), 3.78–3.67 (m, 7
H), 3.42 (s, 2 H), 3.30–3.18 (m, 1 H), 2.32–2.11 (m, 2 H), 1.72–1.51
(m, 2 H), 1.22 (d, J = 6.7 Hz, 3 H).
IR (KBr): 2925, 1730, 1638, 1603, 1456, 1336, 1239, 1157, 1092
cm–1.
1H NMR (300 MHz, CDCl3): d = 7.36–7.17 (m, 5 H), 6.37 (d,
J = 1.5 Hz, 1 H), 6.21 (d, J = 1.5 Hz, 1 H), 4.91–4.81 (m, 1 H), 4.56
(ABq, J = 12.8, 11.3 Hz, 2 H), 4.27–4.17 (m, 1 H), 4.01–3.89 (m, 1
H), 3.84 (s, 3 H), 3.80 (s, 3 H), 3.38–3.28 (m, 1 H), 3.15–3.06 (m, 2
H), 2.10–2.01 (m, 1 H), 1.80–1.74 (m, 1 H), 1.20 (d, J = 6.0 Hz, 3
H).
13C NMR (75 MHz, CDCl3): d = 204.59, 168.75, 161.33, 159.02,
138.24, 134.40, 128.36, 127.65, 124.19, 107.75, 96.94, 71.70,
70.72, 55.65, 55.36, 52.35, 43.66, 40.31, 29.62, 20.84.
13C NMR (75 MHz, CDCl3): d = 170.71, 160.73, 138.39, 136.41,
134.20, 128.30, 127.89, 127.48, 117.39, 107.23, 99.09, 74.77,
71.39, 68.57, 55.19, 42.21, 41.17, 38.29, 20.57.
HRMS: m/z [M + Na]+ calcd for C23H26NaO6: 421.1627; found:
421.1620.
HRMS: m/z [M + Na]+ calcd for C24H30NaO5: 421.1990; found:
421.2004.
(4R,6R)-6-Hydroxy-9,11-dimethoxy-4-methyl-4,5,6,7-tetra-
hydro-2H-3-benzoxecine-2,8(1H)-dione (21)
To a stirred soln of 7 (0.150 mg, 0.37 mmol) in EtOAc (4 mL), was
added 10% Pd/C (catalytic) under a H2 atmosphere and stirred for 6
h. Then the mixture was filtered through a pad of Celite and concen-
trated in vacuo. The crude residue thus obtained was purified by col-
umn chromatography (silica gel, 60–120 mesh, EtOAc–hexane,
1:4) to afford 21 (104 mg, 90%) as colorless syrup.
(3R,5R)-3-(Benzyloxy)-5-[2-(3,5-dimethoxyphenyl)acet-
oxy]hexanoic Acid (20)
To a stirred soln of 18 (800 mg, 2.01 mmol) in acetone–H2O (8:2)
at r.t. was added OsO4 (cat.). After 15 min, NMO (258 mg, 2.21
mmol) was added and stirring was continued for 2 h. Acetone was
removed under reduced pressure and the mixture was quenched
with NaHSO3 soln at 0 °C and extracted with EtOAc (2 × 30 mL).
The combined organic extracts were washed with brine (20 mL),
dried (Na2SO4), and concentrated in vacuo. The resulting crude diol
(780 mg, 90%) was used in next reaction without further purifica-
tion.
[a]D20 +13.5 (c 0.3, CHCl3).
IR (KBr): 3350, 2925, 1730, 1638, 1603, 1456, 1239, 1157, 1092
cm–1.
1H NMR (300 MHz, CDCl3): d = 6.39 (s, 1 H), 6.27 (s, 1 H), 5.38–
5.09 (m, 1 H,), 4.29–4.11 (m, 1 H), 3.82 (s, 3 H), 3.81 (s, 3 H), 3.51–
3.40 (d, J = 13.5 Hz, 1 H), 3.09 (s, 2 H), 2.39–2.21 (m, 1 H), 2.19–
1.91 (m, 1 H), 1.82–1.4 (m, 1 H), 1.19 (d, J = 6.4 Hz, 3 H).
To a stirred soln of diol in a mixture of THF–H2O (2:1) at 0 °C was
added NaIO4 (774 mg, 3.61 mmol) and stirring was continued at r.t.
for 1 h. Then the mixture was extracted with EtOAc (2 × 30 mL) and
the combined organic extracts were washed with brine (20 mL) and
dried (Na2SO4). Removal of solvent followed by purification gave
the crude aldehyde 19 (577 mg, 80%) which was used in next reac-
tion without further purification.
HRMS: m/z [M + Na]+ calcd for C16H20NaO6: 331.1157; found:
331.1155.
(4R,6R)-6,9,11-Trihydroxy-4-methyl-4,5,6,7-tetrahydro-2H-3-
benzoxecine-2,8(1H)-dione (3)13
White solid; mp 166–168 °C.
[a]D20 +22.5 (c 0.8, MeOH).
IR (KBr): 3345, 2923, 1739, 1630, 1461, 1370 cm–1.
1H NMR (400 MHz, DMSO): d = 9.92 (s, 1 H), 9.71 (s, 1 H), 6.27
(d, J = 1.6 Hz, 1 H), 6.10 (s, 1 H), 4.75 (d, J = 4.0 Hz, 1 H), 4.72
To a stirred soln of crude 19 in t-BuOH (3 mL) was added 2-meth-
ylbut-2-ene (1.2 mL) in t-BuOH (2 mL). The mixture was cooled to
0 °C and then treated with a soln of NaClO2 (196 mg, 2.16 mmol)
and NaH2PO4 (338 mg, 2.17 mmol) in H2O (1 mL). After 12 h, the
mixture was diluted with brine (5 mL) and extracted with Et2O (5
Synthesis 2009, No. 18, 3157–3161 © Thieme Stuttgart · New York
