Synthetically useful transformations of δ-sultones and thiane-1,1-dioxides obtained by C-H insertion

Article abstract of DOI:10.3987/COM-09-11788

δ-Sultones and thiane-1,1-dioxides that carry a carbethoxy group at α-position, easily accessible by C-H insertion, are potentially useful synthetic intermediates. Their stereoselective alkylation, rearrangement and conversion to γ-lactones have been demo

Full text of DOI:10.3987/COM-09-11788

HETEROCYCLES, Vol. 78, No. 10, 2009
2531
HETEROCYCLES, Vol. 78, No. 10, 2009, pp. 2531 - 2539. © The Japan Institute of Heterocyclic Chemistry
Received, 2nd July, 2009, Accepted, 28th July, 2009, Published online, 29th July, 2009
DOI: 10.3987/COM-09-11788
SYNTHETICALLY USEFUL TRANSFORMATIONS OF -SULTONES
AND THIANE-1,1-DIOXIDES OBTAINED BY C-H INSERTION
Christian S. Jungong, Jinu P. John, Joseph P. Bequette, and Alexei V.
Novikov*
University of North Dakota, Chemistry Department, 151 Cornell St. Stop 9024,
Grand Forks, ND, 58201, U. S. A.
Abstract – -Sultones and thiane-1,1-dioxides that carry a carbethoxy group at
-position, easily accessible by C-H insertion, are potentially useful synthetic
intermediates. Their stereoselective alkylation, rearrangement and conversion to
-lactones have been demonstrated.
INTRODUCTION
We recently reported a novel modification of C-H insertion that leads to selective formation of
six-membered heterocycles (-sultones or thiane-1,1-dioxides, depending on the substrate used).1 Another
report on formation of -sultones by this method has been published by Du Bois.2 Most notably, the usual
overwhelming preference for formation of five-membered rings3,4 is overridden in this case (Scheme 1).
Scheme 1
Later we also discovered that with a modification of structure and catalyst, certain thiolane-1,1-dioxides
can be reached using this method.5 Only a few of -sultones and thiane-1,1-dioxides carrying a

2532
HETEROCYCLES, Vol. 78, No. 10, 2009
carbalkoxyl substituent at -position have been reported, and even fewer of their chemical transformation
have been performed. Meanwhile, these compounds show a lot of promise as synthetic intermediates. In
the following report we describe our studies of the transformations of these compounds for purposes of
use in synthesis.
RESULTS AND DISCUSSION
For -sultones, a particularly useful transformation would be a reductive scission of the C-S bond, as it
would permit a “remote alkylation” at a -position relative to the alcohol functionality (Scheme 2).
Scheme 2
While numerous examples of desulfonation have been performed with -arylsulfonyl esters, no examples
of this transformation are known for -alkoxysulfonyl substituted esters. Presence of the aryl group on
sulfur appears to be critical for the reaction, as common reagent for this reduction (Al/Hg,6 Na/Hg,7
Mg-MeOH,8 SmI2-MeOH9) did not induce any change in -sulfone 1. A report on -desulfonation of
fluoroalkylsulfonyl oxindoles quotes use of samarium(II) iodide at prolonged periods of time.10
Eventually, we have found that SmI2 in a combination with DMPU would effect this transformation
(Table 1).
Table 1 SmI2 reduction of sultones

HETEROCYCLES, Vol. 78, No. 10, 2009
2533
Use of HMPA produced similar results. The products isolated were valerolactones, which form,
apparently, by the cyclization of the initially forming 5-hydroxyesters. The yields of lactones 1a and 2a
are low apparently due to their volatility and a small scale of the reaction. The reaction appears to be
sensitive to SmI2 source. Mixed success was achieved with commercial SmI2; we found the reaction most
reliably working with SmI2 prepared by reaction of samarium metal with mercury iodide11 by
modification of the reported procedure for preparation of SmCl3.12
Then, we moved on to study the potential uses of carbethoxy thiane-1,1-dioxides. These compounds are
fairly strong C-H acids, permitting alkylation and similar reactions (although, notably, they are
configurationally stable in absence of a base). We were particularly interested in the effect of the
neighboring center (which is installed by C-H insertion).
Table 2 Alkylation of sultones and thiane-1,1-dioxides
The steric congestion in substrate 4, imposed by the quaternary center, did not impede the alkylation,

2534
HETEROCYCLES, Vol. 78, No. 10, 2009
which was possible with the use of active electrophiles under mild conditions (sodium hydride, alkylating
agent, THF, rt, 16 h). Under these conditions it was also possible to alkylate sultone 1, without affecting
the sulfonate, although Du Bois demonstrated that -sultones are susceptible to nucleophilic substitution.2
Also, gratifyingly, high diastereoselectivity (the other diastereomer was not detected) was observed in the
alkylation of substrates 5 and 6 (Table 2).
The stereochemistry of alkylation products 5a and 5b was deduced from NOE correlations (Figure 1).
The stereochemistry of 6a was deduced from NOEs of the alcohol 6b, obtained after DIBALH reduction.
Figure 1
Reduction of the ester group without affecting the sultone functionality in 1 can also be performed using
DIBALH, although care needs to taken, as prolonged reaction times and higher temperatures degrade the
yield. Borane-dimethyl sulfide also proved effective, although use of lithium aluminum hydride caused
complication with both sulfones and sulfonates – low yields were obtained with 1, and apparently a
complete hydrogenolysis of the ester functionality to the methyl group was happening with 5.
And finally, we have discovered that alkylated products can be rearranged by migration of carbethoxy
group in a fashion similar to that of -ketoesters,13 upon treatment with NaHMDS (Scheme 3).
Scheme 3

HETEROCYCLES, Vol. 78, No. 10, 2009
2535
This opens more possibilities for simple differential alkylation of thiane-1,1-dioxides, as well as
construction of bicyclic sulfur-containing heterocycles (which could be converted to medium-sized
carbocycles by desulfonation).
Thus, stereoselective alkylation of -sultones and thiane-1,1-dioxides, rearrangements of the alkylated
products, and conversion of -sultones to valerolactones have been demonstrated. Further studies directed
at the application of these compounds in synthesis are being performed and will be reported in due
course.
EXPERIMENTAL
All reactions were carried out under an inert atmosphere of dry nitrogen in oven or flame-dried glassware.
Proton magnetic resonance spectra were recorded at 500 MHz on an Avance 500 Bruker spectrometer.
Carbon magnetic resonance spectra were recorded at 125 MHz on an Avance 500 Bruker spectrometer.
All chemical shifts were reported in  units relative to tetramethylsilane. High resolution mass spectral
data were obtained on the Agilent 61969A TOF high resolution mass spectrometer using electrospray
ionization, direct infusion, 10 mL/min in 50% MeOH 5mM ammonium formate. Melting points were
determined on a MEL-TEMP melting point apparatus. Flash column chromatography was performed
using 40-63 m silica gel (Merck, Geduran, no. 11567-1) as the stationary phase. Tetrahydrofuran (THF)
was dried by distilling from sodium–benzophenone in a continuous still under an atmosphere of nitrogen.
General procedure for reduction of -sultones with SmI2/DMPU.
To the solution of sultone (0.1 mmol) in dry THF (0.5 mL) containing DMPU (50 mg, 0.4 mmol) was
added 0.1 M solution of SmI2 (commercially available, or prepared by dissolving solid SmI2, prepared by
reaction of samarium metal with HgI2,11 in dry THF) until the blue color persisted, and 2 mL after that
(typically around 5 mL). The reaction mixture was stirred at rt for the specified time, after which 1N HCl
was added (5 mL). Hexane (30 mL) was added, and the reaction mixture was stirred for 15 min at rt. The
layers were separated, the aqueous layer was washed with hexane (10 mL). The combined organic layers
were washed with water (10 mL), dried over Na2SO4, and carefully concentrated. Flash chromatography
(hexane-Et2O) provided the product.
The obtained lactones have been previously reported.14,15,16 The spectral data for the obtained compounds
match those reported in the literature, as that of the independently prepared authentic samples.
General procedure for alkylation of -sultones and thiane-1,1-dioxides.
Sodium hydride (20 mg, 60% dispersion in mineral oil, 0.5 mmol) was washed with THF (3x1 mL), and a
solution of thiane-1,1-dioxide (0.2 mmol) in THF (1 mL) was added to it. After stirring for 15 min (when
gas evolution subsided), the corresponding alkyl halide (allyl bromide, ethyl iodide or p-chlorobenzyl

2536
HETEROCYCLES, Vol. 78, No. 10, 2009
chloride, 0.4 mmol) was added, and the reaction mixture was allowed to stir at rt for 16 h. 1N HCl (5 mL)
was added, and the mixture was extracted with EtOAc (2x20 mL). The organic layer was dried with
Na2SO4, and concentrated under reduced pressure. The product was purified by flash chromatography
(hexane-EtOAc).
1
2-Allyl-2-carbethoxy-3,3-dimethylthiane-1,1-dioxide (4a): Pale yellow oil. H NMR (CDCl3, 500
MHz):  6.08-6.17 (m, 1H), 5.23 (dd, J = 17, 1.5 Hz, 1H), 5.14 (dd, J = 10, 1.5 Hz, 1H), 4.25-4.36 (m,
2H), 3.81 (td, J = 13.5, 4 Hz, 1H), 2.97-3.04 (m, 2H), 2.82 (dd, J = 15, 7 Hz, 1H), 2.12-2.29 (m, 2H),
1.92-1.99 (m, 1H), 1.33-1.39 (m, 4H), 1.36 (t, J = 7 Hz), 1.31 (s, 3H), 1.00 (s, 3H). 13C NMR (CDCl3, 125
MHz):  168.3 (C), 134.2 (CH), 118.6 (CH2), 78.0 (C), 62.2 (CH2), 51.2 (CH2), 40.1 (C), 36.4 (CH2),
31.8 (CH2), 28.8 (CH3), 23.0 (CH3), 19.4 (CH2), 14.2 (CH3). HRMS (ESI) calcd for C13H26NO4S
(M+NH4)+ 292.1577, found 292.1559.
1
2-Ethyl-2-carbethoxy-3,3-dimethylthiane-1,1-dioxide (4b): Pale yellow oil. H NMR (CDCl3, 500
MHz): 4.33-4.39 (m, 1H), 4.24-4.32 (m, 1H), 3.84 (td, J = 13.5, 4 Hz, 1H), 3.00 (dt, J = 13.5, 3.5 Hz, 1H),
2.24-3.31 (m, 1H), 2.20 (ddd, J = 14, 3.5, 3 Hz, 1H), 2.03-2.11 (m, 2H), 1.90-1.96 (m, 1H), 1.36 (t, J = 7.3
13
Hz, 3H), 1.29-1.35 (m, 1H), 1.27 (s, 3H), 1.26 (t, J = 7.3 Hz, 3H), 0.96 (s, 3H). C NMR (CDCl3, 125
MHz):  168.4 (C), 78.7 (C), 62.0 (CH2), 52.0 (CH2), 40.2 (C), 36.3 (CH2), 28.7 (CH3), 23.3 (CH3), 20.9
(CH2), 19.4 (CH2), 14.3 (CH3), 11.1 (CH3). HRMS (ESI) calcd for C12H26NO4S (M+NH4)+ 280.1577,
found 280.1577.
1
3-Allyl-3-carbethoxy-4,4-dimethyl-1,2-oxathiane-2,2-dioxide (1b): Pale yellow oil. H NMR (CDCl3,
500 MHz): 6.05 (ddt, J = 14, 10, 7 Hz, 1H), 5.27 (dd, J = 17, 1.5 Hz, 1H), 5.18 (dd, J = 10, 1.5 Hz, 1H),
4.72 (td, J = 12, 2 Hz, 1H), 4.44 (ddd, J = 11.5, 4.5, 2.5 Hz, 1H), 4.29-4.38 (m, 2H), 2.86-2.96 (m, 2H), 2.61
(td, J = 13.5, 4 Hz, 1H), 1.43 (s, 3H), 1.33-1.39 (m, 4H), 1.36 (t, J = 7 Hz), 0.99 (s, 3H). 13C NMR (CDCl3,
125 MHz):  166.5 (C), 133.4 (CH), 119.5 (CH2), 76.8 (C), 69.3 (CH2), 62.6 (CH2), 39.6 (CH2), 36.7 (CH2),
34.3 (CH2), 27.8 (CH3), 23.6 (CH3), 14.2 (CH3). HRMS (ESI) calcd for C12H24NO5S (M+NH4)+ 294.1369,
found 294.1388.
1
(2r,3s)-2-Allyl-2-carbethoxy-3-methylthiane-1,1-dioxide (5a): Pale yellow oil. H NMR (CDCl3, 500
MHz): 6.10-6.19 (m, 1H), 5.20 (dq, J = 17, 1 Hz, 1H), 5.14 (d, J = 10 Hz, 1H), 4.26-4.37 (m, 2H), 3.79 (td,
J = 13.5, 4.5 Hz, 1H), 3.11 (dd, J = 15, 5.5 Hz, 1H), 2.98 (dt, J = 13.5, 3.5 Hz, 1H), 2.82 (dd, J = 15.5, 8.5 Hz,
1H), 2.24-2.31 (m, 1H), 2.03-2.17 (m, 2H), 1.80 (qd, J=13, 3.5 Hz, 1H), 1.60 (dq, J = 14.5, 3.5 Hz, 1H,
13
overlapped with water peak), 1.36 (t, J = 7.5 Hz, 3H), 0.99 (d, J = 6.5 Hz, 3H). C NMR (CDCl3, 125
MHz):  167.5 (C), 133.3 (CH), 119.0 (CH2), 75.5 (C), 62.4 (CH2), 50.7 (CH2), 39.1 (CH), 34.8 (CH2), 29.1
(CH2), 23.0 (CH2), 17.4 (CH3), 14.3 (CH3). HRMS (ESI) calcd for C12H21O4S (M+H)+ 261.1155, found

HETEROCYCLES, Vol. 78, No. 10, 2009
2537
261.1171.
1
(2r,3s)-2-Carbethoxy-2-(4-chlorobenzyl)-3-methylthiane-1,1-dioxide (5b): Pale yellow oil. H NMR
(CDCl3, 500 MHz): 7.42 (d, J = 8 Hz, 2H), 7.22 (d, J = 8 Hz, 2H), 4.30-4.40 (m, 2H), 3.76 (td, J = 13.5, 4
Hz, 1H), 3.66 (d, J = 14.5 Hz, 1H), 3.34 (d, J = 14.5 Hz, 1H), 2.96 (dt, J = 14, 3.5 Hz, 1H), 2.33-2.41 (m, 1H),
2.08-2.19 (m, 1H), 2.00-2.07 (m, 1H), 1.63-1.72 (m, 2H), 1.37 (t, J = 7 Hz, 3H), 1.07 (d, J = 7 Hz, 3H). 13C
NMR (CDCl3, 125 MHz):  167.1 (C), 134.1 (C), 133.2 (CH), 133.1 (C), 128.0 (CH), 77.2 (C), 62.6 (CH2),
51.5 (CH2), 40.4 (CH), 35.6 (CH2), 29.6 (CH2), 22.9 (CH2), 18.1 (CH3), 14.4 (CH3). HRMS (ESI) calcd for
C16H25NO4SCl (M+NH4)+ 362.1187, found 362.1172.
(2r,3s)-2-Carbethoxy-2-(4-chlorobenzyl)-3-methylthiolane-1,1-dioxide (6a): Pale yellow oil. 1H NMR
(CDCl3, 500 MHz): 7.39 (d, J = 8.5 Hz, 2H), 7.25 (d, J = 8.5 Hz, 2H), 4.30 (qd, J = 7, 1.5 Hz, 2H),
3.44-3.52 (m, 2H), 3.27 (d, J = 14.5 Hz, 1H), 3.14-3.21 (m, 1H), 2.47-2.55 (m, 1H), 2.21-2.29 (m, 1H),
1.96-2.05 (m, 1H), 1.33 (t, J = 7.3 Hz, 3H), 0.90 (d, J = 7 Hz, 3H). 13C NMR (CDCl3, 125 MHz):  166.6 (C),
133.6 (C), 133.3 (C), 132.6 (CH), 128.5 (CH), 74.5 (C), 62.5 (CH2), 50.7 (CH2), 40.1 (CH), 35.2 (CH2),
27.0 (CH2), 17.0 (CH3), 14.3 (CH3). HRMS (ESI) calcd for C15H23NO4SCl (M+NH4)+ 348.1031, found
348.1035.
DIBALH reduction of 1 and 6a.
To the solution of 1 or 6a (0.1 mmol) in CH2Cl2 (0.5 mL), solution of DIBALH (0.5 mL, 1M in hexane,
o
o
0.5 mmol) was added at 0 C. The reaction mixture was kept at 0 C for 1h (1), or 10 h at rt (6a).
Concentrated aqueous solution of sodium potassium tartrate was added (10 mL), and the reaction mixture
was stirred for 1h. The layers were separated, the aqueous layer was washed with EtOAc (20 mL). The
combined organic layers were washed with brine, dried over Na2SO4, and concentrated. Flash
chromatography (hexane-EtOAc) provided the product.
3-Hydroxymethyl-4,4-dimethyl-1,2-oxathiane-2,2-dioxide (1c): Obtained in 90% yield. Clear oil,
solidified on standing. m.p. 62-63 oC. 1H NMR (CDCl3, 500 MHz): 4.66 (td, J = 11.5, 2.5 Hz, 1H), 4.46
(dt, J = 11.5, 4 Hz, 1H), 4.20 (ddd, J = 12.5, 8, 3 Hz, 1H), 4.02-4.09 (ddd, J = 12.5, 8, 3 Hz, 1H), 3.11 (dd, J
= 8, 3 Hz, 1H), 2.41 (dd, J = 8, 3 Hz, 1H), 1.92 (ddd, J = 14.5, 11.5 , 4 Hz, 1H), 1.61 (ddd, J = 14.5, 4, 2.5 Hz,
1H), 1.27 (s, 3H), 1.22 (s, 3H). 13C NMR (CDCl3, 125 MHz):  69.9 (CH), 69.7 (CH2), 58.3 (CH2), 38.9
(CH2), 35.8 (C), 29.9 (CH3), 22.1 (CH3). HRMS (ESI) calcd for C7H18NO4S (M+NH4)+ 212.0951, found
212.0950.
(2r,3s)-4-Chlorobenzyl-2-hydroxymethyl-3-methylthiolane-1,1-dioxide (6b): Obtained in 94% yield.
Pale yellow oil. 1H NMR (CDCl3, 500 MHz):  7.28-7.31 (m, 4H), 3.94 (dd, J = 13, 6 Hz, 1H), 3.75 (dd, J

2538
HETEROCYCLES, Vol. 78, No. 10, 2009
= 13, 8 Hz, 1H), 3.42 (d, J = 14 Hz, 1H), 3.29 (ddd, J = 13, 8.5, 3 Hz, 1H), 3.07 (ddd, J = 13, 10.5, 8.5 Hz,
1H), 2.82 (d, J = 14 Hz, 1H), 2.59 (dd, J = 8, 6 Hz, 1H), 2.31-2.39 (m, 1H), 2.13-2.21 (m, 1H), 1.90-2.00
(m, 1H), 0.85 (d, J = 7 Hz, 3H). 13C NMR (CDCl3, 125 MHz):  133.8 (C), 133.5 (C), 132.2 (CH), 128.9
(CH), 68.1 (C), 61.3 (CH2), 51.4 (CH2), 39.5 (CH), 36.5 (CH2), 27.7 (CH2), 15.8 (CH3). HRMS (ESI)
calcd for C13H21NO3SCl (M+NH4)+ 306.0925, found 306.0941.
Rearrangement of 4a.
4a (25 mg, 0.091 mmol) was dissolved in dry THF (0.2 mL), and solution of NaHMDS in THF (2M in
THF, 90 L, 0.18 mmol) was added. After stirring at rt for 1.5 h, the reaction was quenched with 1N HCl
(5 mL), and extracted with EtOAc (2x20 mL). The organic layer was washed with brine, dried and
concentrated. The products were isolated using flash chromatography (EtOAc-hexane). The products
isomerise during chromatography (verified by resubjecting pure 7a to chromatography). Typically, small
amounts of pure 7a and 7b were isolated, along with a mixture of the two. 7b (the more polar isomer) was
determined to be the cis-isomer by diaxial NOE correlation between H2 and H6. Combined yield 20 mg
(84%).
trans-2-Allyl-6-carbethoxy-3,3-dimethylthiane-1,1-dioxide (7a): Pale yellow oil. 1H NMR (CDCl3, 500
MHz): 5.94-6.03 (m, 1H), 5.16 (dd, J = 17, 1.5 Hz, 1H), 5.07 (dd, J = 10, 1.5 Hz, 1H), 4.21-4.32 (m, 2H),
3.88 (dd, J = 5, 3 Hz, 1H), 3.43 (dd, J = 7, 4 Hz, 1H), 2.78-2.87 (m, 1H), 2.50 (ddd, J = 14, 5, 3 Hz, 1H),
2.38-2.45 (m, 1H), 2.13 (dq, J = 15, 3 Hz, 1H), 2.04 (td, J = 14, 3 Hz, 1H), 1.39 (dt, J = 14.5, 3.5 Hz, 1H),
1.32 (t, J = 7 Hz, 3H), 1.15 (s, 3H), 1.11 (s, 3H). 13C NMR (CDCl3, 125 MHz):  167.2 (C), 136.8 (CH),
116.8 (CH2), 66.8 (CH), 63.9 (CH), 62.4 (CH2), 37.4 (C), 34.8 (CH2), 31.0 (CH3), 26.3 (CH2), 23.4 (CH2),
19.9 (CH3), 14.2 (CH3). HRMS (ESI) calcd for C13H23O4S (M+H)+ 275.1311, found 275.1320.
1
cis-2-Allyl-6-carbethoxy-3,3-dimethylthiane-1,1-dioxide (7b): Pale yellow oil. H NMR (CDCl3, 500
MHz): 5.94-6.03 (m, 1H), 5.14 (dd, J = 17, 1.5 Hz, 1H), 5.07 (dd, J = 10, 1.5 Hz, 1H), 4.25-4.37 (m, 2H),
3.81 (dd, J = 13, 3.5 Hz, 1H), 2.83-2.91 (m, 1H), 2.82 (dd, J = 7, 3 Hz, 1H), 2.37-2.51 (m, 2H), 2.14 (dq, J =
15, 3 Hz, 1H), 1.68 (ddd, J = 14.5, 4.5, 3 Hz, 1H), 1.52 (td, J = 14, 3 Hz, 1H), 1.33 (t, J = 7 Hz, 3H), 1.16 (s,
13
3H), 1.09 (s, 3H). C NMR (CDCl3, 125 MHz):  164.2 (C), 136.7 (CH), 117.1 (CH2), 71.6 (CH), 66.1
(CH), 62.8 (CH2), 39.6 (CH2), 37.7 (C), 30.9 (CH3), 26.7 (CH2), 23.5 (CH2), 19.5 (CH3), 14.3 (CH3).
HRMS (ESI) calcd for C13H23O4S (M+H)+ 275.1311, found 275.1319.
ACKNOWLEDGEMENTS
This work was supported by the American Chemical Society Petroleum Research Fund under grant No.
PRF#46278-G1. We thank Alena Kubatova for HRMS analyses. The work on TOF MS was supported by

HETEROCYCLES, Vol. 78, No. 10, 2009
2539
the National Foundation under grant No. CHE-0216038. Special thanks to Divine Dugah for samarium
iodide preparation and handling.
REFERENCES
1. J. P. John and A. V. Novikov, Org. Lett., 2007, 9, 61.
2. S. A. Wolckenhauer, A. S. Devlin, and J. Du Bois, Org. Lett., 2007, 9, 4363.
3. D. F. Taber and R. E. Ruckle, Jr., J. Am. Chem. Soc., 1986, 108, 7686.
4. M. P. Doyle, L. J. Westrum, W. N. E. Wolthuis, M. M. See, W. P. Boone, V. Bagheri, and M. M.
Pearson, J. Am. Chem. Soc., 1993, 115, 958.
5. C. S. Jungong, J. P. John, and A. V. Novikov, Tetrahedron Lett., 2009, 50, 1954.
6. H. O. House and J. K. Larson, J. Org. Chem., 1968, 33, 61.
7. B. M. Trost, H. C. Arndt, P. E. Strege, and T. R. Verhoeven, Tetrahedron Lett., 1976, 3477.
8. (a) G. H. Lee, E. B. Choi, E. Lee, and C. S. Pak, Tetrahedron Lett., 1993, 34, 4541; (b) A. C. Brown
and L. A. Caprino, J. Org. Chem., 1985, 50, 1749.
9. G. A. Molander and G. Hahn, J. Org. Chem., 1986, 51, 1135.
10. K. M. James, N. Willetts, and D. J. Procter, Org. Lett., 2008, 10, 1203.
11. E. E. Delbridge, D. T. Dugah, C. R. Nelson, B. W. Skelton, and A. H. White, Dalton Trans., 2007,
143.
12. G. B. Deacon, G. N. Pain, and T. D. Tuong, Inorg. Synth., 1990, 28, 291.
13. J. F. Wolfe, T. M. Harris, and C. R. Hauser, J. Org. Chem., 1964, 29, 3249.
14. R. D. Little, G. W. Muller, M. G. Venegas, G. L. Carroll, A. Bukhari, L. Patton, and K. Stone,
Tetrahedron, 1981, 37, 4371.
15. C. G. Chavdarian and C. H. Heathcock, J. Org. Chem., 1975, 40, 2970.
16. M. P. Doyle, A. V. Kalinin, and D. G. Ene, J. Am. Chem. Soc., 1996, 118, 8837.
