Molecules 2015, 20, 17016-17040; doi:10.3390/molecules200917016
OPEN ACCESS
molecules
ISSN 1420-3049
www.mdpi.com/journal/molecules
Article
Synthesis and Biological Activity of Isoflavone Derivatives from
Chickpea as Potent Anti-Diabetic Agents
Pengshou Li 1,2, Xiaojuan Shi 1,2, Ying Wei 1,2, Lingling Qin 2, Wen Sun 2, Guangyuan Xu 2,
Tunhai Xu 1,2,* and Tonghua Liu 2
1
School of Chinese Pharmacy, Beijing University of Chinese Medicine, Beijing 100029, China;
E-Mails: 15501051852@163.com (P.L.); 18810959032@163.com (X.S.);
weimozhuo@163.com (Y.W.)
2
Health Cultivation Laboratory of the Ministry of Education, Beijing University of Chinese
Medicine, Beijing 100029, China; E-Mails: qllqxtslx@126.com (L.Q.);
sunweng00897@163.com (W.S.); xuguangyuan102@126.com (G.X.); Thliu@163.com (T.L.)
* Author to whom correspondence should be addressed; E-Mail: thxu@163.com;
Tel./Fax: +86-10-6428-6935.
Academic Editor: Derek J. McPhee
Received: 20 July 2015 / Accepted: 3 September 2015 / Published: 17 September 2015
Abstract: A set of novel isoflavone derivatives from chickpea were synthesized. The
structures of derivatives were identified by proton nuclear magnetic resonance (1H-NMR),
carbon-13 (13C)-NMR and mass spectrometry (MS) spectral analyses. Their anti-diabetic
activities were evaluated using an insulin-resistant (IR) HepG2 cell model. Additionally,
the structure-activity relationships of these derivatives were briefly discussed. Compounds
1c, 2h, 3b, and 5 and genistein exhibited significant glucose consumption-enhancing effects
in IR-HepG2 cells. In addition, the combinations of genistein, 2h, and 3b (combination 6)
and of 3b, genistein, and 1c (combination 10) exhibited better anti-diabetic activity than
the individual compounds. At the same dosage, there was no difference in effect between
the combination 10 and the positive control (p > 0.05). Aditionally, we found the differences
between the combination 10 and combination 6 for the protective effect of HUVEC (human
umbilical vein endothelial cells) under high glucose concentration. The protective effects
of combination 10 was stronger than combination 6, which suggested that combination 10
may have a better hypoglycemic activity in future studies. This study provides useful clues
for the further design and discovery of anti-diabetic agents.

Molecules 2015, 20
Keywords: chickpea; isoflavones; derivative synthesis; anti-diabetic activity
17017
1. Introduction
With further research into the mechanisms of various diseases, it is understood that no “Magic
Bullets” exist for curing most diseases. Many diseases with high incidence rates such as diabetes, heart
disease, arthritis, asthma, depression and cancer are related to many changing pathological factors [1–3].
However, current research and drug development have generally been limited to one-target, one-model
drugs. In the other words, the goal is to identify highly selective drugs that act on a single target [4].
However, although research over the past 20 years had focused on identifying highly selective target
ligands, the proportion of successful drug candidates tested in clinical trials had not increased but rather
had decreased. This phenomenon prompted us to question the mode of drug development [5]. With the
development of molecular biology, genomics, and systems biology, the concept of multicomponent
drugs has been proposed. Multicomponent drug regimens differ from single target drugs from compounds
containing only one compound; these regimens contain a variety of compounds that exert synergistic
pharmacological effects, and such drugs can simultaneously interact with multiple targets. The total effect
is often greater than the effect of a single compound; thus, a better therapeutic effect can be achieved.
Chickpea (Cicer arietinum L.) is widely used in Uygur and exerts favorable hypoglycemic effects
both as a dietary or medicinal supplement. According to recent studies, isoflavones extracted from
chickpea exhibit favorable hypoglycemic activity [6]; however, these reports are limited to studies of
active components. In addition, previous research on the hypoglycemic activity of the compounds and
hypoglycemic activity optimization based on structural modifications is not sufficient. Regarding
isoflavonoids extracted and isolated from chickpea and based on the multiple target effect model of
traditional Chinese medicine, studies on the hypoglycemic activity of combinations of parent compounds
and their derivatives are lacking. Such studies are required to develop and utilize active compounds
in chickpea.
Genistein from chickpea significantly decreased serum insulin levels, total cholesterol, triglycerides,
low-density lipoprotein cholesterol, high-density lipoprotein cholesterol, and the ratio of high-density
lipoprotein cholesterol to low-density lipoprotein cholesterol, improved glucose tolerance, and reduced
serum liver glycogen and muscle glycogen in type 2 diabetic rats [7]. Genistein can be used not only to
treat type 2 diabetes but also to stimulate insulin release in type 1 diabetes [8]. Because of isoflavones
structure and the effect of surrounding phenolic hydroxyl, genistein has low bioavailability. The
combination of formononetin and hanfangichin B exerted favorable hypoglycemic effects in rats with
streptozotocin-induced diabetes, and formononetin reduced blood glucose by stimulating insulin
release [9]. In addition, biochanin A is also a major isoflavone component in chickpea. Although
there are few reports of hypoglycemic activity, hypoglycemic activity can be obtained via structural
modification, using the same isoflavone skeleton structure with genistein and biochanin A, thus
expanding the hypoglycemic applications of chickpea isoflavonoids. Therefore, based on structural
modifications of genistein, biochanin A, and formononetin derived from chickpea and combinations of
parent compounds and their derivatives, we studied the hypoglycemic activity of both individual

Molecules 2015, 20
17018
compounds and combinations of compounds. These results provide a reference for the development of
drugs that exert hypoglycemic activity. The structures of genistein, biochanin A, and formononetin are
shown in Figure 1.
Figure 1. The structures of genistein, biochanin A, and formononetin.
2. Results and Discussion
2.1. Synthesis
In the current study, a set of novel derivatives were synthesized, among which compounds 1d–1e,
2b–2j, 3c–3d, 4b and 5 have not been previously reported.
2.1.1. Sulfonate Derivative Formation
Because of their isoflavone skeletons and the influence of hydroxyl groups, the lipid and water solubility
of these isoflavones is poor. This characteristic lead to low bioavailability and limit their widespread
applications. Some researchers attempted to improve the water solubility of these isoflavones using
physical methods, but the effect was not obvious. Structural modification of the sulfonic acid sodium
of genistein, biochanin A, and formononetin were used to improve their water solubility. The synthetic
routes to derivatives 1a–1e are shown in Scheme 1.

Molecules 2015, 20
17019
R = OH, H; R′ = H, OH, OCH3
Reagents and conditions: (a) concentrated sulfuric acid; (b) NaCl, room temperature (r.t.).
Scheme 1. Synthesis of compounds 1a–1e.
2.1.2. Structural Modification: Isopropylation
Adding another lipid soluble group to the parent isoflavones can increase lipid solubility of the
compounds and increase the ability of the compound to pass through biomembranes and to reach the
target tissues and organs. The synthetic routes to derivatives 2a–2j are shown in Scheme 2.
Scheme 2. Cont.

Molecules 2015, 20
17020
Reagents and conditions: (a) (CH3)2CHOH, H2SO4; (b) 60 °C, 3 h.
Scheme 2. Synthesis of compounds 2a–2j.
2.1.3. Split with Other Small Molecules
The parent isoflavones were esterified with acetyl ferulic acid, which has strong effects regarding
many aspects of diabetes. This structural modification may improve their selectivity and efficacy. The
synthetic routes to derivatives 3a–3d are shown in Scheme 3.
R = OH, H; R′ = H, OH, OCH3
Reagents and conditions: (a) (CH3CO)2O, Py, reflux 4 h; (b) DCC, Py, reflux, 80 °C, 4 h.
Scheme 3. Synthesis of compounds 3a–3d.
2.1.4. The Introduction of Fluorine (F) Elements
Recently, organofluorine compounds have played an important role in the study and development of
drugs for the treatment of diabetes. For example, fluorine-containing drugs such as Januvia and the
aldose reductase inhibitor Sorbinil have been used to treat type II diabetes. Therefore, compounds

Molecules 2015, 20
17021
containing fluorine, which were expected to improve hypoglycemic activity, were synthesized in this
study. The synthetic routes to derivatives 4a–4c are shown in Scheme 4.
R = OH, H; R′ = H, OH, OCH3
Reagents and conditions: (a) 4-fluorobenzyl bromide, CH3ONa; (b) CH3OH, CH2Cl2, reflux 20 h.
Scheme 4. Synthesis of compounds 4a–4c.
2.1.5. Coordination with Trace Elements
Chromium (Cr3+) is an essential trace element in the human body and is required for glucose and
lipid metabolism. Cr3+ impacts the structure and function of insulin and the status of target tissues and
cells significantly. A lack of chromium in the body leads to the dysregulation of glucose and lipid
metabolism and promotes atherosclerosis, diabetes, hyperlipidemia and other symptoms. Previous studies
had shown that diabetic patients were often chromium deficient. Isoflavones may form complexes with
chromium, which could reduce toxicity of inorganic chromium and increase the degree of absorption [10]
in diabetic patients. This may lead to better hypoglycemic effects. The synthetic route to derivative 5 is
shown in Scheme 5.
Reagents and conditions: (a) CH3CH2OH, 60 °C, 1 h; (b) CH3COOCr, 80 °C,18 h; (c) maturing 48 h.
Scheme 5. Synthesis of compound 5.

Molecules 2015, 20
17022
2.2. Biological Activity
2.2.1. Study of the Hypoglycemic Activity of Individual Compounds
Many anti-diabetic isoflavonoids have been reported [11–13]. However, these isoflavonoids have
exhibited weak activity, as revealed by their high doses, compared with drugs currently on the market.
The isoflavonoids in chickpea are known for their anti-hyperglycemic effects, and their hypoglycemic
activity had been previously reported [1,14]. For the first time, we synthesized a series of isoflavonoid
(genistein, biochanin A, and formononetin) derivatives and studied the hypoglycemic activities of these
derivatives. We identified that these compounds induced significant anti-diabetic activities compared
with the commercially available drug metformin.
In this study, an insulin-resistant (IR) HepG2 cell model [15–17] was used to evaluate the
anti-hyperglycemic effects of the isoflavonoids derivatives. The individual compounds 1c, 2h, 3b, 5
and genistein all exerted significant glucose consumption-enhancing effects in the IR-HepG2 cells. The
hypoglycemic activity of each individual compound is shown in Figure 2.
Figure 2. Hypoglycemic activity of the compounds. The differences between these
compounds and genistein were statistically significant (denoted by “*” or “**” for p < 0.05
or p < 0.01, respectively). The differences between these compounds and metformin
hydrochloride were statistically significant (denoted by “▲” or “▲▲” for p < 0.05 or
p < 0.01, respectively).
Compounds with an ED50 < 20.0 μmol were considered to exert strong hypoglycemic activity; such
compounds are shown in bright blue. The ED50 value of genistein was approximately 20 μmol; thus,
genistein was included into this group. The effects of compounds 1c, 2h, 3b, and 5 were superior to those
of genistein. Compounds corresponding to 100 μmol > ED50 > 20.0 μmol were considered to have
weaker hypoglycemic activity; these compounds are shown in orange. Such compounds could be used
as substrates for further structural modification. The ED50 value of compound 2b was approximately
100 μmol; thus, compound 2b was included in this group. Compounds with an ED50 > 100.0 μmol were
considered to exert very weak hypoglycemic activity and were not considered for further evaluation;
these compounds are shown in purple.

Molecules 2015, 20
17023
Structure-Activity Relationship Analysis
The hypoglycemic activity of genistein was significantly better than that of biochanin A (p < 0.01),
indicating that 4′-OH substituted by methoxyl greatly decreased the hypoglycemic activity and that 4′-OH
was a strong active group. The activity of formononetin and biochanin A showed that activity was greatly
reduced if 5-OH existed, indicating that 5-OH was a group that prevent producing strong active.
Due to the derivatization of sodium sulfonate, compound 1c exhibited strong activity. Compared with
the activity of biochanin A, the difference was significant (p < 0.01). The difference was also significant
(p < 0.01) compared with other isoflavone derivatives of sodium sulfonate. This result indicates that
the sodium sulfonate group in genistein decrease the hypoglycemic activity of the compounds, possibly
due to the sodium sulfonate group leading to weak action of phenol hydroxyl on targets in the body.
The 3′-sodium sulfonate group in biochanin A may interact with ortho-methoxy and generate more
active groups.
The activities of the isopropylation-products showed that compound 2h exhibited optimal activity,
and compounds 2b, 2c, 2e and 2g exerted relatively weak activities. The other derivatives of isopropylation
exerted no significant activity. Through the introduction of 5′-isopropyl, the hypoglycemic activity of
biochanin A was increased. However, the activity was weakened due to the introduction of 3′-isopropyl
after introduction of 5′-isopropyl. The activity was also attenuated due to the introduction of 3′,6 and
8-isopropyl after introduction of 5′-isopropyl, indicating that the introduction of too many isopropyl
hinder the effect of the compounds on the target. However, compound 2f exhibited no activity, revealing
that the 6, 8-isopropyl or 6, 8-hydrogen of biochanin A is necessary when 3′,5′-isopropyl exist if we want
the derivatives exhibit activity. For genistein, the activity of compound 2c (2′,5′,6,8-isopropyl) was
better than compound 2b (3′,5′,6,8-isopropyl); moreover, compound 2d (2′,6′,6,8-isopropyl) and 2a
(3′,5′-isopropyl)did not result in activity. So the hypoglycemic activity is: 2′,5′ > 3′,5′ > 2′,6′-isopropyl
after 6,8-isopropyl were introduction. For formononetin, the hypoglycemic activity was lost due to
substitution of the isopropyl. For genistein and biochanin A, when the 3′,5′,6,8-isopropyl were introduced,
the activity was better when the 4′-hydrogen was replaced by a methoxyl group rather than a hydroxyl
group. When the 3′,5′-isopropyl were introduced, the activity was better when the 4′-hydrogen was
replaced by a methoxyl group rather than a hydroxyl group.
For genistein, substitution by acetyl ferulic acid showed that the activity was increased when the
4′,7-hydroxyl were replaced by acetyl ferulic acid compared with only 7-hydroxyl was substituted.
This indicated that more acetyl ferulic acid increased the target binding efficiency. The hypoglycemic
activity of compound 3b was better than genistein and the difference was significant (p < 0.01). For
biochanin A, the hypoglycemic activity of compound 3c was better than biochanin A and the difference
was also significant (p < 0.01). In addition, for compounds 3a and 3c, when the 7-hydroxyl was substituted,
the activity was better when the 4′-hydrogen was replaced by a methoxyl group rather than by a hydroxyl
group. Thus, under these structural conditions, the target binding effect is stronger when the 4′-hydrogen
is replaced by a methoxyl group rather than by a hydroxyl group. In addition, for formononetin,
substitution of the 7-OH with acetyl ferulic acid induced a loss in activity.
For the derivatives that were replaced by 4-fluorobenzyl bromide, 7-hydroxyl was substituted for
three starting material. However, all the derivatives losted hypoglycemic activity, indicating that the
4-fluorobenzyl bromide was not required to increase the activity of hypoglycemic activity.

Molecules 2015, 20
17024
The hypoglycemic activity of compound 5 was stronger, indicating that the introduction of chromium
greatly enhanced the hypoglycemic activity of the compound.
The structure-activity relationship analysis are shown in Table 1.
Table 1. Structure-activity relationship analysis.
Structure-Activity Relationship
The Hypoglycemic Activity
Active Group
Non Active Group
4′-OCH3 and 5-OH were groups that prevent
producing strong active
Genistein > Formononetin > Biochanin A
4′-OH is a strong active group
3′ or 3′,6-sodium sulfonate groups in
genistein; 3′-sodium sulfonate group in
formononetin
Genistein > 1c > Formononetin > 1a, 1b, 1d,
1e, Biochanin A
3′-sodium sulfonate group in biochanin A
BiochaninA: only 5′-isopropyl;
Biochanin A: 3′,5′,8- isopropyl
Genistein > 2h > 2c > 2e> 2g > Formononetin
> 2b > 2a, 2d, 2f, 2i, 2j, Biochanin A
6,8-isopropyl or 6,8-hydrogen of biochanin Genistein: all the isopropyl replacement.
A is necessary when 3′,5′-isopropyl exist.
Formononetin: same to Genistein.
7-acetyl ferulic acid in genistein;
3b > Genistein > Formononetin > 3c > 3a, 3d, 4′,7-acetyl ferulic acid in genistein;
Biochanin A
7-acetyl ferulic acid in biochanin A
7-acetyl ferulic acid in formononetin
7-hydroxyl was substituted by 4-fluorobenzyl
bromide in three starting material
Genistein > Formononetin > Biochanin A >
4a, 4b, 4c
5 > Genistein > Formononetin > Biochanin A
Cr3+
2.2.2. The Hypoglycemic Activity of Combined Compounds
We selected the derivatives with the best hypoglycemic effects and genistein (G) for use in
combinations. Each combination is shown in Figure 3. The y-axis indicates the sum of the ED50 values
of the compounds.
Figure 3. Combinations and activity superposition.
The hypoglycemic activities of the combinations evaluated according to glucose consumption
(GC)/CCK8 are shown in Figure 4.
Figure 4 shows that the hypoglycemic effects of the maximum concentration of combination 6 and
combination 10 (shown in bright blue) were similar to the effect of metformin hydrochloride in the positive
control group; the difference was not significant (p > 0.5). The effect of the maximum concentration
of combination 6 and combination 10 was better than that of the other combinations. At the same

Molecules 2015, 20
17025
dosage (500 µg/mL) as the positive control (3.02 µmol), no difference was found in the effects between
combination 10 (3b = 0.24 μmol, G = 0.43 μmol, 1c = 0.62 μmol, total 1.29 μmol) and the positive
control (p > 0.05).
Figure 4. Hypoglycemic activities of combinations. The differences between combination
6, combination 10 and other combinations were statistically significant (p < 0.05 or
p < 0.01, denoted by “*” or “**”, respectively).
The true activities differed from the activities calculated by simple addition. Combination 3 and
combination 8 exhibited the best hypoglycemic effects based on simple addition, whereas the actual
best effect was obtained using combination 6 and combination 10. This result indicates interference by
the compounds; thus, their effects on multiple target points should be considered. Genistein and the other
dosages of combination 6 and combination 10 (shown in red) can be used to obtain new combinations in
future studies.
2.2.3. The Effect of Combined Compounds on Cell Proliferation and Toxicity
Compared with the control group, changes in cell morphology or cell number were not found, indicating
that the toxicity of the combinations was low, as shown in Figure 5.
Combination 6 (100×)
Combination 10 (100×)
Combination 10 (200×)
Figure 5. Cont.

Molecules 2015, 20
17026
Metformin hydrochloride (100×)
Control (100×)
Control (200×)
Figure 5. Cellular morphology.
2.2.4. The Impacts of HUVEC Secrete LDH, MDA, SOD and NO under High Concentration
of Glucose
We found significant differences between combination 6 and combination 10 acting on HUVEC
under high concentration of glucose. Wherein the combination 10 had better protective effects on
HUVEC, and combination 6 had relatively weak protective effects. This prompted us that combination
10 would have better hypoglycemic effect through protecting HUVEC in further study. The protective
effects were shown in Figure 6.
LDH
MDA
SOD
NO
Figure 6. Combination 6 and combination 10 acting on human umbilical vein endothelial
cells (HUVEC) under high concentration of glucose. The differences of LDH and MDA
between model group and control group were statistically significant (p < 0.01, denoted by
“
▲▲”).The differences of NO content and SOD activity between model group and control
group were statistically significant (p < 0.01, denoted by “▲▲”). The differences of LDH,
MDA, NO and SOD between combination 6 and combination 10 were statistically significant
(p < 0.05 or p < 0.01, denoted by “*”or “**”, respectively).

Molecules 2015, 20
17027
Research indicated that model group of HUVEC cultured in medium of high concentration of glucose
had higher content of lipid peroxidation and produced more LDH and MDA than control group. And
NO content and SOD activity was decreased compared with control group. Combination 10 could
significantly reduce the amount of MDA and LDH leakage of HUVEC injured by high glucose, and it
also increased the NO content and SOD activity. Compared with combination 6, the difference was
obvious, which indicated that combination 10 could play a better role of protecting HUVEC.
3. Experimental Section
3.1. General Information
All reactions were monitored by thin-layer chromatography (TLC) on silica gel GF-254 plates purchased
from Qingdao Haiyang Corporation. Proton nuclear magnetic resonance (1H-NMR) and carbon-13
(13C)-NMR spectra were acquired using a Bruker AV500 MHz spectrometer, and dimethylsulfoxide
(DMSO-d6) was used as the solvent. Chemical shifts are reported in parts per million shift (δ value)
1
based on Me4Si (δ 0 ppm for H). High-resolution mass spectra (HR-MS) were acquired using a
Thermo Scientific LTQ Orbitrap XL (New York, NY, USA). Infrared (IR) analyses were conducted
using a Thermo Nicolet Nexus 670 spectrometer (New York, NY, USA). Ultraviolet (UV) analyses were
conducted using a UV-2450 Ultraviolet visible spectrophotometer. Melting points (m.p., uncorrected)
were measured using an X-5 micro melting point apparatus (Beijing, China). Silica-gel column
chromatography was performed using 300–400 mesh silica gel purchased from Qingdao Haiyang
Corporation. The yields were calculated based on the last step of the reaction. All chemicals and solvents
used were analytical or high-performance liquid chromatography grade.
3.2. Chemistry
3.2.1. Synthesis of Compounds 1a–1e (Considering One of the Parental Compounds as an Example)
A mixture of genistein (10.00 g, 0.037 mol) and 25 mL concentrated sulfuric acid was heated to
60 °C under stirring for 0.5 h. The mixture was then poured into 500 mL ice-cold saturated brine. A
precipitate formed slowly; the precipitate formed completely after 4 h incubation. The precipitate was
filtered and washed with saturated brine until the pH became neutral. The crude material was purified
in a 300–400 mesh silica column (water-saturated butanol).
3′-Sodium sulfonate genistein (1a). The product was obtained as a white solid (35.2% yield); m.p.
1
304~305 °C. H-NMR (DMSO-d6) δ (ppm): 12.91 (s, 1H, 5-OH), 10.82 (s, 1H, 7-OH), 10.56 (s, 1H,
4′-OH), 8.36 (s, 1H, H-2), 7.71 (s, 1H, H-2′), 7.37 (d, J = 8.4 Hz, 1H, H-6′), 6.86 (d, J = 8.4 Hz, 1H,
H-5′), 6.41 (s, 1H, H-8), 6.24 (s, 1H, H-6). 13C-NMR (DMSO-d6) δ (ppm): 180.50 (s, C-4), 164.82 (s, C-7),
162.42 (s, C-4′), 158.06 (s, C-5), 154.77 (s, C-8a), 153.81 (s, C-2), 132.01 (s, C-2′), 131.08 (s, C-3′),
128.20 (s, C-6′), 122.22 (s, C-1′), 121.55 (s, C-3), 116.84 (s, C-5′), 104.88 (s, C-4a), 99.50 (s, C-6), 94.21
(s, C-8). HRMS (ESI) m/z: 269.01752 [M − SO3Na − H]−, calcd. for C15H9O5 269.04500.
3′,6-Disodium sulfonate genistein (1b). The product was obtained as a white solid (31.2% yield); m.p.
1
312~313 °C. H-NMR (DMSO-d6) δ (ppm): 13.27 (s, 1H, 5-OH), 12.59 (s, 1H, 7-OH), 10.63 (s, 1H,

Molecules 2015, 20
17028
4′-OH), 8.51 (s, 1H, H-2), 7.74 (s, 1H, H-2′), 7.38 (d, J = 8.4 Hz, 1H, H-6′), 6.85 (d, J = 8.0 Hz, 1H,
H-5′), 6.21 (s, 1H, H-8). 13C-NMR (DMSO-d6) δ (ppm): 180.65 (s, C-4), 162.37 (s, C-7), 161.29 (s, C-4′),
155.12 (s, C-5), 154.97 (s, C-8a), 153.94 (s, C-2), 132.25 (s, C-2′), 131.04 (s, C-6′), 128.53 (s, C-3′),
122.66 (s, C-1′), 121.16(s, C-3), 116.87 (s, C-5′), 105.10 (s, C-4a), 101.86 (s, C-6), 99.52 (s, C-8).
HRMS (ESI) m/z: 370.98638 [M − SO3Na − H]−, calcd. for C15H8NaO8S 370.98376.
3′-Sodium sulfonate biochanin A (1c). The product was obtained as a buff solid (34.3% yield); m.p.
1
221~222 °C. H-NMR (DMSO-d6) δ (ppm): 12.93 (s, 1H, 5-OH), 10.94 (s, 1H, 7-OH), 8.35 (s, 1H,
H-2), 7.89 (s, 1H, H-2′), 7.48 (d, J = 8.4 Hz, 1H, H-6′), 7.02 (d, J = 7.9 Hz, 1H, H-5′), 6.42 (s, 1H,
H-8), 6.25 (s, 1H, H-6), 3.79 (s, 3H, -OCH3). 13C-NMR (DMSO-d6) δ (ppm): δ 180.56 (s, C-4), 164.83
(s, C-7), 162.44 (s, C-4′), 158.10 (s, C-5), 156.74 (s, C-8a), 154.76 (s, C-2), 135.92 (s), 131.34 (s),
129.66 (s), 122.58 (s), 121.93 (s), 112.21 (s), 104.90 (s, C-4a), 99.51 (s), 94.23 (s), 56.06 (s, -OCH3).
HRMS (ESI) m/z: 283.06832 [M − SO3Na − H]−, calcd. for C16H11O5 283.06065.
3′,6-Disodium sulfonate biochanin A (1d). The product was obtained as a buff solid (32.3% yield); m.p.
1
228~229 °C. H-NMR (DMSO-d6) δ (ppm): 13.28 (s, 1H, 5-OH), 12.59 (s, 1H, 7-OH), 8.50 (s, 1H,
H-2), 7.94 (s, 1H, H-2′), 7.47 (d, J = 8.3 Hz, 1H, H-6′), 7.06 (d, J = 8.5 Hz, 1H, H-5′), 6.21 (s, 1H, H-8),
3.82 (s, 3H, -OCH3). 13C-NMR (DMSO-d6) δ (ppm): 180.66 (s, C-4), 162.38 (s, C-7), 161.31 (s, C-4′),
156.73 (s, C-5), 155.15 (s, C-8a), 154.87 (s, C-2), 135.68 (s), 131.39 (s), 129.89 (s), 122.91 (s), 121.73
(s), 112.29 (s), 110.62 (s), 105.09 (s, C-4a), 99.52 (s), 56.19 (s, -OCH3). HRMS (ESI) m/z: 385.01812
[M − SO3Na − H]−, calcd. for C16H10NaO8S 384.99941.
3′-Sodium sulfonate formononetin (1e). The product was obtained as a white solid (31.7% yield); m.p.
263~264 °C. 1H-NMR (DMSO-d6) δ (ppm):10.88 (s, 1H, 7-OH), 8.31 (s, 1H, H-2), 7.98 (d, J = 8.7 Hz,
1H, H-5), 7.89 (d, J = 1.4 Hz, 1H, H-2′), 7.50 (dd, J = 8.4, 1.4 Hz, 1H, H-6′), 7.05 (d, J = 8.5 Hz, 1H,
H-5′), 6.96 (dd, J = 8.8, 1.0 Hz, 1H, H-6), 6.91 (s, 1H, H-8), 3.81 (s, 3H, -OCH3). 13C-NMR (DMSO-d6)
δ (ppm): 175.03 (s, C-4), 163.10 (s, C-7), 157.95 (s, C-4′), 156.40 (s, C-8a), 153.59 (s, C-2), 135.58 (s),
131.40 (s), 129.53 (s), 127.72 (s), 123.77 (s), 123.37 (s), 117.03 (s), 115.69 (s), 112.12 (s), 102.64 (s),
56.19 (s, -OCH3). HRMS (ESI) m/z: 267.06378 [M − SO3Na − H]−, calcd. for C16H11O4 267.06574.
3.2.2. Synthesis of Compounds 2a–2j (Considering One of the Parental Compounds as an Example)
Compounds 2a–2j were prepared according to the method described by Xie et al. [18]. Formononetin
(1.0 g, 3.73 mmol) was dissolved in 16 mL 80% sulfuric acid. After the formononetin was dissolved,
isopropyl alcohol (3 mL) was added to the mixture. The mixture was heated to 60 °C under stirring
for 3 h, and the mixture was then poured into water (200 mL). White floc formed immediately upon
the addition of water, and the precipitate formed completely after 4 h incubation. The precipitate was
filtered and washed with water until the pH became neutral. The crude material was separated in a
300–400 mesh silica column (petroleum ether:ethyl acetate, 3:1).
3′,5′-Diisopropyl genistein (2a). The product was obtained as a white solid (22.1% yield); m.p.
1
284~285 °C. H-NMR (DMSO-d6) δ (ppm): 13.01 (s, 1H, 5-OH), 10.89 (s, 1H, 7-OH), 9.31 (s, 1H,
4′-OH), 8.26 (s, 1H, H-2), 7.17 (s, 2H, H-2′,6′), 6.38 (s, 1H, H-8), 6.23 (s, 1H, H-6), 3.33 (dt, J = 13.2,

Molecules 2015, 20
17029
6.7 Hz, 2H, -CH(CH3)2), 1.18 (d, J = 6.7 Hz, 12H, -CH(CH3)2). 13C-NMR (DMSO-d6) δ (ppm): 180.82
(s, C-4), 164.70 (s, C-7), 162.49 (s, C-4′), 158.05 (s, C-5), 154.53 (s, C-8a), 151.30 (s, C-2), 135.41
(s, C-2′,6′), 124.44 (s, C-3′,5′), 123.45 (s, C-1′), 122.51 (s, C-3), 104.97 (s, C-4a), 99.39 (s, C-6), 94.08 (s,
C-8), 26.68 (s, 2C), 23.43 (s, 4C). HRMS (ESI) m/z: 353.09991 [M − H]−, calcd. for C21H21O5 353.13890.
3′,5′,6,8-Tetraisopropyl genistein (2b). The product was obtained as a white solid (21.1% yield); m.p.
278~279 °C. 1H-NMR (DMSO-d6) δ (ppm): 1H-NMR (500 MHz, DMSO) δ 13.61 (s, 1H, 5-OH), 10.99
(s, 1H, 7-OH), 9.46 (s, 1H, 4′-OH), 8.24 (s, 1H, H-2), 7.17 (s, 2H, H-2′,6′), 3.58 (m, J = 14.0, 6.9 Hz,
1H, -CH(CH3)2), 3.50 (dt, J = 13.9, 7.1 Hz, 1H, -CH(CH3)2), 3.34–3.26 (m, 2H, -CH(CH3)2), 1.34 (d,
J = 7.4 Hz, 6H, -CH(CH3)2), 1.31 (d, J = 6.8 Hz, 6H, -CH(CH3)2), 1.18 (d, J = 6.7 Hz, 12H, -CH(CH3)2).
13C-NMR (DMSO-d6) δ (ppm): 181.58 (s, C-4), 158.91 (s, C-7), 158.18 (s, C-4′), 154.34 (s, C-5),
153.90 (s, C-8a), 151.18 (s, C-2), 135.39 (s,C-2′,6′), 125.39 (s, C-1′), 124.41 (s, C-3′,5′), 122.83 (s, C-3),
117.74 (s, C-4a), 112.68 (s, C-6), 105.59 (s, C-8), 30.88 (s, 2C), 26.65 (s, 1C), 24.45 (s, 1C), 23.46 (s, 4C),
21.45 (s, 2C), 20.69 (s, 2C). HRMS (ESI) m/z: 437.23114 [M − H]−, calcd. for C27H33O5 437.23280.
2′,5′,6,8-Tetraisopropyl genistein (2c). The product was obtained as a white solid (20.3% yield); m.p.
1
273~274 °C. H-NMR (DMSO-d6) δ (ppm): 13.48 (s, 1H, 5-OH), 11.01 (s, 1H, 7-OH), 9.51 (s, 1H,
4′-OH), 8.26 (s, 1H, H-2), 7.07 (s, 1H, H-6′), 6.70 (s, 1H, H-3′), 3.72 (m, J = 5.2 Hz, 1H, -CH(CH3)2),
3.62–3.54 (m, 1H, -CH(CH3)2), 3.49 (d, J = 13.7 Hz, 2H, -CH(CH3)2), 1.23(d, J = 17.4 Hz, 24H,
-CH(CH3)2). 13C-NMR (DMSO-d6) δ (ppm): 172.78 (s, C-4), 159.13 (s, C-7), 158.07 (s, C-4′), 155.39
(s, C-5), 155.11 (s, C-8a), 154.06 (s, C-2), 130.11 (s, C-2′, 6′), 129.78 (s, C-1′), 128.91 (s, C-3), 128.24
(s, C-3′,5′), 105.30 (s, C-4a), 100.36 (s, C-6), 97.40 (s, C-8), 29.62 (s, 2C), 27.08 (s, 2C), 25.68 (s, 1C),
24.46 (s, 1C), 22.68 (s, 1C), 22.46 (s, 1C), 21.48 (s, 2C), 20.66 (s, 2C). HRMS (ESI) m/z: 437.23457
[M − H]−, calcd. for C27H33O5 437.23280.
2′,6′,6,8-Tetraisopropyl genistein (2d). The product was obtained as a white solid (19.5% yield); m.p.
1
289~290 °C. H-NMR (DMSO-d6) δ (ppm): 13.52 (s, 1H, 5-OH), 11.07 (s, 1H, 7-OH), 9.32 (s, 1H,
4′-OH), 8.25 (s, 1H, H-2), 6.86 (s, 2H, H-3′,5′), 3.63–3.52 (m, 1H, -CH(CH3)2), 3.53–3.43 (m, 1H,
-CH(CH3)2), 3.16 (dt, J = 13.3, 6.8 Hz, 1H, -CH(CH3)2), 2.66 (dt, J = 13.3, 6.6 Hz, 1H, -CH(CH3)2),
1.37–1.32 (m, 12H), 1.30 (d, J = 6.7 Hz, 6H), 1.15 (d, J = 6.2 Hz, 6H, -CH(CH3)2). 13C-NMR (DMSO-d6)
δ (ppm): 182.16 (s, C-4), 159.08 (s, C-7), 158.08 (s, C-4′), 155.45 (s, C-5), 155.08 (s, C-8a), 154.07
(s, C-2), 140.08 (s, C-2′,6′), 128.98 (s, C-1′), 125.32 (C-3′,5′), 121.60 (s, C-3), 105.33 (s, C-4a), 96.86
(s, C-6), 93.18 (s, C-8), 34.86 (s, 1C), 30.88 (s, 2C), 30.45 (s, 1C), 26.66 (s, 1C), 24.46 (s, 1C), 22.96 (s,
2C), 21.48 (s, 2C), 20.66 (s, 2C). HRMS (ESI) m/z: 437.23080 [M − H]−, calcd. for C27H33O5 437.23280.
3′,5′-Diisopropyl biochanin A (2e). The product was obtained as a buff solid (21.2% yield); m.p.
1
216~217 °C. H-NMR (DMSO-d6) δ (ppm): 12.94 (s, 1H, 5-OH), 10.90 (s, 1H, 7-OH), 8.37 (s, 1H,
H-2), 7.30 (s, 2H, H-2′,6′), 6.41 (d, J = 1.5 Hz, 1H, H-8), 6.25 (d, J = 1.5 Hz, 1H, H-6), 3.70 (s, 3H,
-OCH3), 3.29 (dt, J = 13.7, 6.9 Hz, 2H, -CH(CH3)2), 1.22 (d, J = 6.9 Hz, 12H, -CH(CH3)2). 13C-NMR
(DMSO-d6) δ (ppm): 180.49 (s, C-4) 165.19 (s, C-7), 162.46 (s, C-4′), 158.08 (s, C-5), 155.12 (s, C-8a),
154.57 (s, C-2), 141.38 (s, C-2′,6′), 127.38 (s, C-1′), 125.41 (s, C-3′,5′), 122.89 (s, C-3), 104.81 (s, C-4a),
99.60 (s, C-6), 94.24 (s, C-8), 62.44 (s, -OCH3), 26.52 (s, 2C), 24.34 (s, 4C). HRMS (ESI) m/z:
367.15324 [M − H]−, calcd. for C22H23O5 367.15455.

Molecules 2015, 20
17030
3′,5′,8-Triisopropyl biochanin A (2f). The product was obtained as a buff solid (19.2% yield); m.p.
1
211~212 °C. H-NMR (DMSO-d6) δ (ppm): 12.99 (s, 1H, 5-OH), 10.87 (s, 1H, 7-OH), 8.45 (s, 1H,
H-2), 7.32 (s, 2H, H-2′,6′), 6.33 (s, 1H, H-8), 3.69 (s, 3H, -OCH3), 3.28 (dt, J = 13.4, 6.6 Hz, 3H,
13
-CH(CH3)2), 1.21 (d, J = 6.7 Hz, 18H, -CH(CH3)2). C-NMR (DMSO-d6) δ (ppm): 180.94 (s, C-2),
162.54 (s, C-7), 159.94 (s, C-4′), 155.55 (s, C-5), 155.08 (s, C-8a), 154.51 (s, C-2), 141.35 (s, C-2′,6′),
127.48(s, C-1′), 125.40 (s, C-3′,5′), 122.34 (s, C-3), 105.61 (s, C-4a), 99.42 (s, C-6), 93.70 (s, C-8),
62.41 (s, -OCH3), 26.51 (s, 2C), 25.60 (s, 1C), 24.33 (s, 6C). HRMS (ESI) m/z: 409.20875 [M − H]−,
calcd. for C25H29O5 409.20150.
3′,5′,6,8-Tetraisopropyl biochanin A (2g). The product was obtained as a buff solid (23.4% yield); m.p.
1
208~209 °C. H-NMR (DMSO-d6) δ (ppm): 13.55 (s, 1H, 5-OH), 9.50 (s, 1H, 7-OH), 8.47 (s, 1H,
H-2), 7.31 (s, 2H, H-2′,6′), 3.70 (s, 3H,-OCH3), 3.62–3.54 (m, 1H, -CH(CH3)2), 3.53–3.46 (m, 1H,
-CH(CH3)2), 3.32–3.23 (m, 2H, -CH(CH3)2), 1.40–1.13 (m, 24H, -CH(CH3)2). 13C-NMR (DMSO-d6) δ
(ppm): 181.33 (s, C-4), 159.04 (s, C-7), 158.21 (s, C-4′), 154.89 (s, C-5), 154.40 (s, C-8a), 153.90 (s,
C-2), 141.35 (s, C-2′,6′), 127.60 (s, C-1′), 125.38 (s, C-3′,5′), 122.32 (s, C-3), 117.91 (s, C-4a), 112.81
(C-6), 105.59 (s, C-8), 62.44 (s, -OCH3), 30.89 (s, 1C), 26.52 (s, 2C), 24.47 (s, 1C), 24.34 (s, 4C),
21.44 (s, 2C), 20.68 (s, 2C). HRMS (ESI) m/z: 451.24680 [M − H]−, calcd. for C28H35O5 451.24845.
5′-Isopropyl biochanin A (2h). The product was obtained as a buff solid (21.2% yield); m.p. 202~203 °C.
1H-NMR (DMSO-d6) δ (ppm): 12.94 (s, 1H, 5-OH), 10.76 (s, 1H, 7-OH), 8.37 (s, 1H, H-2), 7.30 (s,
1H, H-6′), 7.21(d, J = 7.7 Hz, 1H, H-2′), 6.88 (d, J = 7.8 Hz, 1H, H-3′), 6.42 (s, 1H, H-8), 6.24 (s, 1H,
H-6), 3.70 (s, 3H, -OCH3), 3.28 (m, J = 13.8, 6.9 Hz, 1H, -CH(CH3)2), 1.36 (d, J = 6.9 Hz, 6H,
-CH(CH3)2). 13C-NMR (DMSO-d6) δ (ppm): 180.53 (s, C-4), 164.96 (s, C-7), 162.48 (s, C-4′), 158.07
(s, C-5), 155.16 (s, C-8a), 154.60 (s, C-2), 141.39 (s, C-2′,6′), 128.51 (s, C-1′), 125.41 (s, C-3′,5′),
122.93 (s, C-3), 104.91 (s, C-4a), 99.54 (s, C-6), 94.21 (s, C-8), 62.44 (s, -OCH3), 26.53 (s, 1C), 24.34
(s, 2C). HRMS (ESI) m/z: 325.10345 [M − H]−, calcd. for C19H17O5 325.10760.
3′,5′-Diisopropyl formononetin (2i). The product was obtained as a white solid (23.1% yield); m.p.
250~251 °C. 1H-NMR (DMSO-d6) δ (ppm): 10.83 (s, 1H, 7-OH), 8.35 (s, 1H, H-2), 7.97 (d, J = 11.2 Hz,
1H, H-5), 7.30 (s, 2H, H-2′,6′), 6.95 (d, J = 8.7 Hz, 1H, H-6), 6.88 (s, 1H, H-8), 3.69 (s, 3H, -OCH3),
3.28 (dt, J = 13.5, 6.7 Hz, 2H, -CH(CH3)2), 1.26–1.12 (m, 12H, two -CH(CH3)2).13C-NMR (DMSO-d6)
δ (ppm): 175.04 (s, C-4), 163.06 (s, C-7), 157.91 (s, C-4′), 154.36 (s, C-8a), 154.04 (s, C-2), 141.19 (s,
C-2′,6′), 128.60 (s, C-5), 127.80 (s, C-1′), 125.31 (s, C-3′,5′), 124.14 (s, C-3), 117.13 (s, C-6), 115.68
(s, C-8), 102.59 (s, C-4a), 62.42 (s, -OCH3), 26.50 (s, 2C), 24.36 (s, 4C). HRMS (ESI) m/z: 351.15826
[M − H]−, calcd. for C22H23O4 351.15964.
3′,5′,8-Triisopropyl formononetin (2j). The product was obtained as a white solid (24.3% yield); m.p.
242~243 °C. 1H-NMR (DMSO-d6) δ (ppm): 10.62 (s, 1H, 7-OH), 8.43 (s, 1H, H-2), 7.85 (d, J = 8.6 Hz,
1H, H-5), 7.33 (s, 2H, H-2′,6′), 6.99 (d, J = 8.7 Hz, 1H, H-6), 3.74–3.70 (m, 1H, -CH(CH3)2), 3.70 (s,
3H, -OCH3), 3.28 (dt, J = 13.4, 6.6 Hz, 2H, -CH(CH3)2), 1.37 (d, J = 6.8 Hz, 6H, -CH(CH3)2), 1.22 (d,
J = 6.6 Hz, 12H, -CH(CH3)2). 13C-NMR (DMSO-d6) δ (ppm): 175.40 (s, C-4), 160.33 (s, C-7), 155.96
(s, C-4′), 154.29 (s, C-8a), 153.92 (s, C-2), 141.16 (s, C-2′,6′), 128.71 (s, C-5), 125.28 (s, C-3′,5′), 124.62
(s, C-1′), 123.47 (s, C-3), 120.69 (s, C-6), 117.51 (s, C-8), 115.21 (s, C-4a), 62.41 (s, -OCH3), 26.49

Molecules 2015, 20
17031
(s, 2C), 24.44 (s, 4C), 24.28 (s, 1C), 20.92 (s, 2C). HRMS (ESI) m/z: 393.20514 [M − H]−, calcd. for
C25H29O4 393.20659.
3.2.3. Synthesis of Compounds 3a–3d (Considering One of the Parental Compounds as an Example)
Treatment of acetic anhydride [19]: P2O5 was added to acetic anhydride until the P2O5 became a
powder. The mixture was filtered to remove the P2O5. The filtrate was distilled at 90 °C and 0.096 MPa;
fractions were collected at a constant temperature and saved in a dryer.
Treatment of pyridine: KOH was added to pyridine and refluxed for 5 h until the KOH became
pasty. Then, the reflux was stopped to distill the solution at a lower pressure. Fractions were collected
at 68 °C until the pressure reached 0.085 MPa, and the pyridine was finally sealed with wax.
Synthesis of acetyl ferulic acid: Ferulic acid (19.4 g, 0.1 mol) was dissolved in acetic anhydride
(40 mL) and anhydrous pyridine (10 drops). The mixture was stirred at 120 °C for 4 h, and was then
cooled to room temperature. A large quantity of precipitate formed immediately. The precipitate was
filtered and washed with water and anhydrous ethanol. The resulting solid was finally re-crystallized
with anhydrous ethanol, producing the product as a white solid (67.2%); m.p. 190–191 °C.
Synthesis of target compounds 3a–3d: Acetyl ferulic acid (0.4 g, 1.69 mmol), genistein (0.5 g,
1.85 mmol), and DCC (0.6 g, 2.90 mmol) were dissolved in tetrahydrofuran (20 mL), and anhydrous
pyridine (1 mL) was then added to the mixture. The mixture was then stirred at 80 °C for 4 h. The resulting
mixture was filtered to remove the DCU, and the crude material was then purified in a 300–400 mesh
silica column (petroleum ether:ethyl acetate:methanol, 6:2:1).
Genistein 7-acetylferulic acid (3a). The product was obtained as a white solid (33.2%); m.p. 257~258 °C.
1H-NMR (DMSO-d6) δ (ppm): 13.02 (s, 1H, 5-OH), 9.63 (s, 1H, 4′-OH), 8.52 (s, 1H, H-2), 7.92 (d,
1H, J = 15.4 Hz, H-3′′), 7.63 (m, 1H, H-2′′′), 7.45 (d, 2H, J = 8.3 Hz, H-2′,6′), 7.17 (m, 1H, H-6′′′),
7.13 (m, 1H, H-5′′′), 6.97 (d, 1H, J = 15.4Hz, H-2′′), 6.83 (d, 2H, J = 8.3 Hz, H-3′,5′), 6.81 (s, 1H, H-6),
6.77 (s, 1H, H-8), 3.86 (s, 3H, -OCH3), 2.33 (s, 3H, -COCH3); 13C-NMR (DMSO-d6) δ (ppm): 180.7 (s,
C-4), 168.2 (s, C-1′′), 164.2 (s, -COO-), 161.1 (s, C-5), 157.8 (s, C-8a), 156.6 (s, C-7), 155.7 (s, C-4′),
155.6 (s, C-2), 151.8 (s, C-3′′′), 146.1 (s, C-3′′), 140.3 (s, C-4′′′), 132.9 (s, C-1′′′), 131.2 (s, C-2′,6′), 123.4
(s, C-1′), 123.1 (s, C-5′′′), 122.0 (s, C-3), 120.4 (s, C-6′′′), 116.3 (s, C-2′′′), 115.3 (s, C-3′, 5′), 112.2 (s,
C-2′′′), 108.4 (s, C-4a), 104.2 (s, C-6), 101.1 (s, C-8), 56.4 (s, -OCH3), 20.5 (s, -CH3). HRMS (ESI)
m/z: 489.10428 [M + H]+, calcd. for C27H21O9 489.11856.
Genistein 7,4′-diacetylferulic acid (3b). The product was obtained as a white solid (31.7%); m.p.
1
234–235 °C. H-NMR (DMSO-d6) δ (ppm): 12.95 (s, 1H, 5-OH), 8.73 (s, 1H, H-2), 7.97 (d, 2H,
J = 15.64 Hz, H-3′′), 7.75 (m, 2H, H-2′′′), 7.71 (d, 2H, J = 8.35 Hz, H-2′,6′), 7.43 (d, 2H, J = 8.35 Hz,
H-3′,5′), 7.42 (m, 2H, H-6′′′), 7.22 (m, 2H, H-5′′′), 7.05 (d, 2H, J = 15.65 Hz, H-2′′), 6.85 (s, 1H, H-6),
13
6.84 (s, 1H, H-8), 3.91 (s, 6H, -OCH3), 2.33 (s, 6H, -CH3); C-NMR (DMSO-d6) δ (ppm): 180.1 (s,
C-4), 167.5 (s), 167.7 (s, C-1′′), 164.2 (s), 164.2 (s, 2-COO-), 156.2 (s, C-5), 155.7 (s, C-4′), 152.4 (s,
C-7), 150.5 (s, C-8a), 150.5 (s), 150.6 (s, C-3′′′), 150.2 (s, C-2), 145.3 (s), 145.6 (s, C-3′′), 141.3 (s),
141.3 (s, C-4′′′), 131.6 (s), 132.1 (s, C-1′′′), 129.2 (s, C-2′,6′), 122.6 (s, C-1′), 122.3 (s), 122.3 (s, C-5′′′),
120.8 (s, C-3), 120.5 (s), 120.6 (s, C-6′′′), 116.4 (s), 116.6 (s, C-2′′), 112.4 (s, C-3′,5′), 110.6 (s), 110.7

Molecules 2015, 20
17032
(s, C-2′′′), 104.7 (s, C-4a), 100.1 (s, C-6), 95.3 (s, C-8), 55.1, 55.1 (s, -OCH3), 19.4 (s), 19.4 (-CH3).
HRMS (ESI) m/z: 707.15763 [M + H]+, calcd. for C39H31O13 707.17647.
Biochanin A 7-acetylferulic acid ester (3c). The product was obtained as a buff solid (38.3%); m.p.
192~193 °C. 1H-NMR (DMSO-d6) δ (ppm): 12.86 (s, 1H, 5-OH), 8.46 (s, 1H, H-2), 7.61 (d, J = 8.4 Hz,
2H, H-2′,6′), 7.38 (d, J = 8.4 Hz, 1H, H-6′′′), 7.21 (d, J = 8.4 Hz, 2H, H-3′,5′), 7.05–6.97 (d, J = 16.4 Hz,
1H, H-3′′), 6.88 (s, 1H, H-2′′′), 6.82 (d, J = 8.4 Hz, 1H, H-5′′′), 6.75–6.66 (d, J = 16.1 Hz, 1H, H-2′′),
6.41 (s, 1H, H-8), 6.25 (s, 1H, H-6), 3.80 (s, 3H, -OCH3), 3.93 (s, 3H, -OCH3), 2.30 (s, 3H, CH3COO-).
13C-NMR (DMSO-d6) δ (ppm): 180.28 (s, C-4), 169.69 (s, C-1′′), 165.14 (s, -COO-), 162.45 (s, C-5),
158.09 (s, C-8a), 156.69 (s, C-7), 155.50 (s, C-4′), 154.45 (s, C-2), 151.94 (s, C-3′′′), 150.78 (s, C-3′′),
139.66 (s, C-4′′′), 133.3 (s, C-1′′′), 130.59 (s, C-2′,6′), 128.85 (s, C-1′), 125.38 (s, C-5′′′), 122.74 (s, C-3),
122.17 (s, C-6′′′), 115.60 (s, C-2′′), 115.53 (s, C-3′,5′), 111.74 (s, C-2′′′), 106.01(s, C-4a), 99.67 (s, C-6),
94.34 (s, C-8), 57.44 (s, -OCH3), 49.94 (s, -OCH3), 21.93 (s, -CH3). HRMS (ESI) m/z: 503.11478
[M + H]+, calcd. for C28H23O9 503.13421.
Formononetin 7-acetylferulic acid ester (3d). The product was obtained as a white solid (30.8%); m.p.
236~237 °C. 1H-NMR (DMSO-d6) δ (ppm): 8.44 (s, 1H, H-2), 8.04 (d, J = 8.8 Hz, 1H, H-5), 7.66 (d,
J = 16.3 Hz, 1H, H-3′′), 7.62 (s, 1H, H-2′′′), 7.54 (d, J = 6.2 Hz, 2H, H-2′,6′),7.37 (d, J = 8.0 Hz, 1H,
H-6′′′), 7.32 (d, J = 8.4 Hz, 1H, H-5′′′), 7.08 (d, J = 8.9 Hz, 1H, H-6), 7.01 (d, J = 7.3 Hz, 2H, H-3′,5′),
6.88 (s, 1H, H-8), 6.73 (d, J = 16.3 Hz, 1H, H-2′′), 3.87 (s, 3H, -OCH3), 3.79 (s, 3H, -OCH3), 2.30 (d,
J = 8.5 Hz, 3H, -COCH3).13C-NMR (DMSO-d6) δ (ppm): 180.91 (s, C-4), 168.63 (s, C-1′′), 164.91 (s,
-COO-), 162.10 (s, C-7), 157.93 (s, C-4′), 156.27 (s, C-8a), 152.03 (s, C-2), 150.36 (s, C-3′′′), 146.21
(s, C-1′′), 142.04 (s, C-4′′′), 132.50 (s, C-1′′′), 130.66 (s, C-2′,6′), 128.62 (s, C-5), 125.39 (s, C-1′),
124.80 (s, C-3), 123.70 (s, C-5′′′), 119.96 (s, C-6′′′), 117.95 (s, C-2′′′), 116.60 (s, C-6), 114.92 (s, C-8),
114.09 (s, C-3′,5′), 112.34 (s, C-2′′′), 101.43 (C-4a), 64.71 (s, -OCH3), 56.61 (s, -OCH3), 21.89 (s, -CH3).
HRMS (ESI) m/z: 509.12245 [M + Na]+, calcd. for C28H22NaO8 509.12124.
3.2.4. Synthesis of Compounds 4a–4e (Take One of the Parental Compounds as an Example)
Formononetin (0.6 g, 2.1 mmol) was dissolved in anhydrous methanol (60 mL), and CH3ONa-CH3OH
(5 mL) was then added to the mixture. 4-fluorobenzyl bromide (0.47 g, 2.5 mmol) was dissolved in
dichloromethane (10 mL) and then added to the mixture. The solution was stirred under reflux for 20 h.
The resulting product was filtered and separated in a 300–400 mesh silica column (petroleum ether:ethyl
acetate:methanol, 6:2:1).
7-(4-Fluorine benzyl)-O-genistein (4a). The product was obtained as a white solid (30.1%); m.p.
1
243~244 °C. H-NMR (DMSO-d6) δ (ppm): 12.95 (s, 1H, 5-OH), 9.63 (s, 1H, 4′-OH), 8.45 (s, 1H,
H-2), 7.57–7.49 (m, 2H, H-2′′,6′′), 7.40 (d, J = 8.0 Hz, 2H, H-2′,6′), 7.25 (d, J = 8.5 Hz, 2H, H-3′′,5′′),
13
6.83 (d, J = 7.9 Hz, 2H, H-3′,5′), 6.76 (s, 1H, H-8), 6.50 (s, 1H, H-6), 5.19 (s, 2H, -CH2-). C-NMR
(DMSO-d6) δ (ppm): 180.89 (s, C-4), 164.56 (s, C-7), 163.39 (s, C-4′′), 162.24 (s, C-4′), 157.93 (s, C-5),
157.90 (s, C-8a) 154.96 (s, C-2), 132.80 (s, C-1′′), 130.83 (s, C-2′′), 130.76 (s, C-6′′), 130.66 (s, C-2′,6′),
122.99 (s, C-1′), 121.49 (s, C-3), 115.96 (s, C-3′′), 115.78 (s, C-5′′), 115.55 (s, C-3′,5′), 106.02 (s, C-4a),

Molecules 2015, 20
17033
99.14 (s, C-6), 93.77 (s, C-8), 69.77 (s, -CH2O-). HRMS (ESI) m/z: 377.09124 [M − H]−, calcd. for
C22H14FO5 377.08253.
7-(4-Fluorine benzyl)-O-biochanin (4b). A The product was obtained as a buff solid (26.8%); m.p.
175~176 °C. 1H-NMR (DMSO-d6) δ (ppm): 12.94 (s, 1H, 5-OH), 8.48 (s, 1H, H-2), 7.54 (dd, J = 13.6,
7.4 Hz, 4H, H-2′,6′; H-2′′,6′′), 7.26 (t, J = 8.3 Hz, 2H, H-3′′,5′′), 7.02 (d, J = 7.6 Hz, 2H, H-3′,5′), 6.78
(s, 1H, H-8), 6.52 (s, 1H, H-6), 5.23 (s, 2H, -CH2-), 3.80 (s, 3H, -OCH3). 13C-NMR (DMSO-d6) δ
(ppm): 180.81 (s, C-4), 167.45 (s, C-4′′), 164.62 (s, C-7), 162.24 (s, C-4′), 159.69 (s, C-5), 157.92 (s,
C-8a), 155.30 (s, C-2), 132.02 (s, C-1′′), 130.84 (s, C-2′′), 130.78 (s, C-6′′), 130.66 (s, C-2′,6′), 123.21
(s, C-1′), 122.67 (s, C-3), 115.96 (s, C-3′′), 115.79 (s, C-5′′), 114.21 (s, C-3′,5′), 106.02 (s, C-10), 99.21
(s, C-6), 93.84 (s, C-8), 69.79 (s, -CH2O-), 55.65 (s, CH3O-). HRMS (ESI) m/z: 391.11194 [M − H]–,
calcd. for C23H16FO5 391.09818.
7-(4-Fluorine benzyl)-O-formononetin (4c). The product was obtained as a white solid (32.3%); m.p.
193~194 °C. 1H-NMR (DMSO-d6) δ (ppm): 8.44 (s, 1H, H-2), 8.05 (d, J = 8.8 Hz, 1H, H-5), 7.62–7.48
(m, 4H, H-2′,6′; H-2′′,6′′), 7.23–7.33 (m, 3H, H-3′′,5′′;H-8), 7.16 (d, J = 8.8 Hz, 1H, H-6), 7.01 (d,
13
J = 7.6 Hz, 2H, H-3′,5′), 5.26 (s, 2H, -CH2-), 3.80 (s, 3H, -OCH3). C-NMR (DMSO-d6) δ (ppm):
175.09 (s, C-4), 167.44 (s, C-4′′), 163.06 (s, C-7), 159.48(s, C-4′), 157.81 (s, C-8a), 154.03 (s, C-2),
132.02 (s, C-1′′), 130.89 (s, C-2′′), 130.82 (s, C-6′′), 130.56 (s, C-2′, 6′), 127.50 (s, C-5), 124.50 (s, C-1′),
123.85 (s,C-3), 118.23 (s, C-6), 115.97 (s, C-8),115.80 (s, C-3′′), 115.73(s, C-5′′), 114.10 (s, C-3′,5′),
102.06 (s, C-4a), 69.82 (s, -CH2O-), 55.62 (s, CH3O-). HRMS (ESI) m/z: 399.11270 [M + Na]+, calcd.
for C23H17FNaO4 399.10085.
3.2.5. Synthesis of Compound 5
Biochanin A (0.81 g, 2.8 mmol) was dissolved in anhydrous ethanol (30 mL). The mixture was heated
to 60 °C. After the biochanin A dissolved, (CH3COO)3Cr (0.34 g, 1.5 mmol) was added to the solution,
and the mixture was stirred under reflux for 18 h. The mixture was then cooled to room temperature. A
green precipitate formed and was filtered. The precipitate was washed with DI H2O and anhydrous
ethanol until the biochanin A and (CH3COO)3Cr were removed. The resulting product was purified in
a 300–400 mesh silica column (petroleum ether:ethyl acetate:methanol, 6:2:1).
(1) The physicochemical properties and element analysis
The biochanin A chromium complex was in the form of a grass-green powder that could be
dissolved in DMSO, dimethyl formamide (DMF), and tetrahydrofuran (THF), that was slightly soluble in
methanol or acetone and that was insoluble in water and CCl4. The C and H contents of the biochanin A
chromium complex were measured using a Vario EL element analyzer. The chromium content was
measured via EDTA titration. The molecular weight was analyzed using a Thermo LQT Orbitrap XL
LC-MS. The results are shown in Table 2.
(2) Thermogravimetry (TG) and differential thermal analysis (DTA)
The thermal spectrum of the complex was measured under airflow at a heating rate of 10 °C/min.
Two stages of weight loss can be observed in the TG-DTA spectrum. The first stage of weight loss was

Molecules 2015, 20
17034
at approximately 75 °C, corresponding to a weight loss rate of 3.94% and a considerable loss of 2 water
molecules (the theoretical weight loss rate was 4.05%). The corresponding absorption peak in the DTA
curve was very small and showed that the complex contained 2 crystal water molecules. The second
stage included the range from 320 °C to 420 °C, and the weight loss rate was 90.60%, corresponding to the
considerable loss of 3 ligand molecules (the theoretical weight loss rate was 90.62%). The corresponding
absorption peak, which was an oxidation-decomposition peak of the complex in the DTA curve, was
very large. Chromium was oxidized in air, and the remnant of the decomposition was Cr2O3.
Table 2. Elemental analysis of the complex.
C %
H %
Cr %
Molecular
theory [M − 2H2O − H]−
test
test
61.43
theory
61.47
test
3.93
theory
test
5.53
theory
5.55
3.95
900.12354
900.11463
(3) Infrared spectrum analysis
From 400–4000 cm−1, the IR spectra of the ligand and complex were measured using a Thermo-
Nicolet nexus of a Fourier transform IR spectrometer (KBr pellets), as shown in Figure 7. The primary
spectral data are listed in Table 3.
A comparison of the IR spectral data of the ligand and chromium complex is shown in Table 3.
Biochanin A exhibited an absorption band (OH) at 3388 cm−1, which shifted to 3432 cm−1 in the IR
spectrum of the complex. Biochanin A exhibited a very strong absorption band at 1653 cm−1 due to the
stretching vibration of the 4-carbonyl, which shifted to 1627 cm−1 in the IR spectrum of its complex.
Therefore, coordination of the 4-carbonyl is involved in the coordination of the ligands.
Table 3. The primary IR spectral data of genistein and the chromium complexes (cm−1).
V(O-H) V(C=O)
V(C=C)
1623
1612
V(C-O-C)
1249
Compound
Biochanin A (L)
CrL3·2H2O
3388
3432
1653
1627
1249
Biochanin A
Figure 7. Cont.

Molecules 2015, 20
17035
CrL3·2H2O
Figure 7. IR spectra analysis.
(4) Ultraviolet spectrum
There were two characteristic UV absorption peaks at 260 nm (band II) and 330 nm (band I, weak)
in DMSO:CH3OH = 1:9 solvent. After complex formation, the two peaks red shifted to 270 nm and
394 nm (weak). Because the B ring could not conjugate with the unsaturated carbonyl of the C ring in
biochanin A, the absorption intensity of the band I was therefore weakened. However, the band I was
red-shifted in the chromium complex, and the intensity of this band increased due to the enhanced plane
type of molecule. The conjugated system of complex was larger, which was attributed to the 4-carbonyl
and 5-hydroxyl of the three biochanin A molecules coordinated with chromium, as shown in Figure 8.
Biochanin A
CrL3·2H2O
Figure 8. UV spectra analysis.

Molecules 2015, 20
17036
3.3. Biological Activity
3.3.1. Hypoglycemic Activity Screening
Cell culture and IR-HepG2 model [20,21]: HepG2 cells were cultured in high-glucose Dulbecco’s
modified Eagle’s medium (DMEM) supplemented with 10% fetal bovine serum (FBS). After reaching
confluence, the cells were cultured in 96-well cluster plates with density of 104 cells/mL in high-glucose
DMEM supplemented with 10% FBS for 24 h and then treated with 10−7 mol/L insulin for 36 h in
serum-free medium. After 36 h of stimulation with a high concentration of insulin, the cells were washed
twice with phosphate-buffered saline (PBS). Then serum-free high-glucose DMEM was added with
compounds in different concentrations and incubated for 24 h. After 24 h, the glucose content in the
culture medium was measured using a glucose assay kit to study the effect of IR-HepG2 cells on glucose
consumption. The enhancement ratio of glucose consumption (GC) was calculated as follows: GC% =
(GC of the drug group-GC of the model group)/GC of the model group × 100. The ED50 values were
calculated using GraphPad Prism 5.
We then combined the derivatives (1c, 2h, 3b, and 5) and genistein (instead of G) to attempt to
obtain improved hypoglycemic activities using these combinations. The derivatives were dissolved in a
certain volume of DMEM. The concentration of each compound in these combinations was 1/3 the
quantity of the original concentration. This concentration was determined which primarily based on
our previous study of the three compounds in chickpea. Wherein the content of genistein and biochanin A
was basically 1: 1 relationship, as shown in Figure 9 and Table 4. Test sample (A) and reference substances
(B), 1 genistein; 2 biochanin A; 3 formononetin.
(A)
(B)
Figure 9. Chromatograms of test sample (A) and reference substances (B).

Molecules 2015, 20
17037
Table 4. Result of content determinition of five samples (mg·g−1, n = 5, ⎯x ± s).
Lot No.
141205
141208
141212
141218
141220
Genistein Biochanin A Formononetin
1.42 ± 0.13
1.41 ± 0.11
1.45 ± 0.12
1.48 ± 0.15
1.42 ± 0.09
1.35 ± 0.08
1.38 ± 0.07
1.31 ± 0.09
1.39 ± 1.11
1.34 ± 1.15
1.15 ± 0.08
1.12 ± 0.09
1.21 ± 0.08
1.13 ± 0.07
1.18 ± 0.09
Cell morphology was observed using an optical microscope. All the images were captured at the
maximum concentration of the compounds and before determination. The cellular morphology was
assessed by green light microscopy (Nikon, Kobe, Japan).
3.3.2. Combination 6 and Combination 10 Acting on HUVEC under High Concentration of Glucose
HUVEC were cultured in endothelial cell medium (ECM). ECM contains 5% fetal bovine serum,
penicillin/streptomycin solution, endothelial cell growth supplements (ECGS), and D-glucose concentration
is 5.55 mmol/L. The HUVEC were inoculated in the ECM after recovery and cultured at 37 °C, 5%
CO2 in the incubator. When the cells growed to 80% confluence, the cells were digested with 0.025%
trypsin-EDTA 1min after washing with PBS 2 times. And then added trypsin neutralize solution when
80% of the cells became round. Pipetting cells into single, and inoculated into 25 cm2 cell culture flasks
after centrifugation. The cells were uesed into experimental study after 4–8 generations passed. The cells
were cultured in 96-well cluster plates with density of 105 cells/mL and cultured in 37 °C, 5% CO2
incubator for 24 h. Then serum-free culture medium DMEM 199 with low concentration of sugar was
used to culture for 24 h so that cells were in a stationary state. Then ECM (The concentration of glucose
was 25 mmol/L) was added with compounds in different concentrations and incubated for 48 h (This
time point was determined through the pre-test results for the maximum difference between control group
and test group). The LDH, MDA, SOD and NO were measured after cell supernatant liquid was collected.
Detection method
(1) Determination of MDA content
The MDA content was tested according to kit instructions to MDA by TBA method. 20 μL cell
supernatant liquid from each well was used to determine.
(2) Detection of LDH release quantity
LDH release quantity was tested according to kit instructions of LDH. 20 μL cell supernatant liquid
from each well was used to determine.
(3) Detection of NO content
The NO content was tested according to kit instructions of NO by nitrate reductase method. 20 μL
cell supernatant liquid from each well was used to determine.

Molecules 2015, 20
17038
(4) Determination of SOD activity
The SOD activity was tested according to kit instructions by Xanthine oxidase method. 10 μL cell
supernatant liquid from each well was used to determine.
4. Conclusions
In this study, fifteen novel isoflavonoid derivatives from chickpea were synthesized and characterized
1
by H-NMR, 13C-NMR and MS analyses. The preliminary bioassay data indicated that the target
compounds 1c, 2h, 3b, and 5 exerted increased anti-hyperglycemic activities compared with parent
compounds. In addition, the combination of genistein, 2h, 3b and of 3b, genistein, 1c exhibited better
anti-diabetic activity than other combinations. At the same dosage as the positive control, combination
10 exerted the same anti-diabetic activity as the positive control (p > 0.05). These results showed that
the combinations could act on many targets in the body simultaneously and that stronger effects could
be induced by combining compounds.
The endothelial cell is a multifunctional cell. It regulates vascular tone, and maintains the balance
between coagulation and fibrinolysis system, and regulates the accumulation of inflammatory cells,
and suppresses the aggregation and activation of platelet [22]. The dysfunction of endothelial cells is
an important factor leading to vascular and nerve disease of diabetes [23]. Research reported high
sugar concentration could cause damage to endothelial cells, causing MDA, LDH, NO, SOD and other
abnormalities [24]. Combination 10 had protective effect on high glucose injured HUVEC. It may be
related to the regulation of cell activity, improve oxidative stress, maintain cell membrane stability.
This result provided a reference for better prevention and treatment of diabetes.
Further biological evaluations and the mechanism of the active compounds are currently underway.
Acknowledgments
The study was supported by the International Science & Technology Cooperation Program of China
(2010DFB33260) and Beijing Municipal Education Commission to build the project in 2011: Technology
platform constructing and prescriptions screening of Chinese medicine treatment of insulin resistance.
Author Contributions
Pengshou Li performed chemistry experiments and wrote the paper; Pengshou Li, Xiaojuan Shi and
Ying Wei performed the biological evaluation experiments; Wen Sun analyzed pharmacological data and
elaborated cell morphology; Lingling Qin and Guangyuan Xu did the data analyses; Tunhai Xu designed
the study; Tonghua Liu was principle investigator of the project and provided the research funding.
Conflicts of Interest
The authors declare no conflict of interest.

Molecules 2015, 20
17039
References
1. Lokitionov, A. Common gene polymorphisms and nutrition: Emerging links with pathogenesis of
multifactorial chronic diseases. J. Nutr. Biochem. 2003, 14, 426–451.
2. Kaplan, J.C.; Junien, C. Genomics and medicine: An anticipation. From Booolean Mendelian
genetics to multifactorial molecular medicine. CR Acad. Sci. III 2000, 323, 1167–1174.
3. Reich, D.E.; Lander, E.S. On the allelic spectrum of human disease. Trends Genet. 2001, 17, 502–510.
4. Keith, C.T.; Borisy, A.A.; Stockwell, B.R. Multicomponent therapeutics for networked systems.
Nat. Rev. Drug Discov. 2005, 4, 1–8.
5. Zimmermann, G.R.; Lehar, J.; Keith, C.T. Multi-target therapeutics: When the whole is greater
than the sum of the parts. Drug Discov. Today 2007, 12, 34–42.
6. Li, Y.; Wu, G.Z.; Zhang, J.S.; Ma, H. Effects of the isoflavone extract of Cicer arietium L. on blood
level and oxidation-antioxidation status in diabetic mice. CRTER 2007, 11, 7625–7629.
7. Yang, W.X.; Liang, Z.S.; Wang, S.W.; Zhang, L.; Xie, Y.H.; He, Z.M. Effect of genistein to FPG
and blood lipids on typeⅡ diabetes rats. J. Northwest A ＆F Univ. (Nat. Sci. Ed.) 2009, 37, 1–6.
8. Ayumi, H.; Katsuhiro, T.; Kosuke, A.; Soichiro N.; Norio, K.; Kazuya, Y. Genistein stimulates
the insulin-dependent signaling pathway. Front. Biosci. 2011,3, 1534–1540.
9. Ma, W.J.; Masaaki, N.; Tatsuo, T.N.; Shinjiro, K. Combined Effects of Fangchinoline from Stephania
Tetrandra Radix and Formononetin and Calycosin from Astragalus membranaceus Radix on
Hyperglycemia and Hypoinsulinemia in Streptozotocin-Diabetic Mice. Biol. Pharm. Bull. 2007,
30, 2079–2083.
10. Li, F. Synthesis, Characterization and Preliminary Application of Several Organic Chromium
Complexes. Master’s Thesis, Jiangsu University, Zhenjiang, China, 2009.
11. Li, R.F.; Cao Chun, Y.; Liu, Z.H. Protective effect of soybean isoflavone on the kidney of diabetic
rats and its mechanism. Cent. South Pharm. 2014, 12, 532–534.
12. Li, R.F.; Cao, C.Y.; Tan, Y.H.; Liu Z.H. Effect of soybean isoflavone on expression of nephrin in
kidney tissue of diabetic model rats. Chin. J. Pharmacol. Toxicol. 2014, 28, 531–535.
13. Zhang, G.Z. Studies on Metabolism of Irisolidone in vivo and in vitro of Rats. Ph.D. Thesis,
Shenyang Pharmaceutical University, Shenyang, China, 2014.
14. Li, Y. The Research about Extracting, Separating, Purifying Isoflavone and Saponin from Cicer
arietium L. and Their Decreasing Blood Glucose, Regulating Blood Lipid Effect. Master’s Thesis,
Xin Jiang Agricultural University, Wulumuqi, China, 2007.
15. Kenji, A.; Tomomi, I.; Masamichi, A.; Masanori, I.; Akira, S.; Katsuo, I. Action of novel antidiabetic
thiazolidinedione, T-174, in animal models of non-insulin-dependent diabetes mellitus (NIDDM)
and in cultured muscle cells. Br. J. Pharm. 1998, 125, 429–436.
16. Li, C.G.; Ning, G.; Chen, J.L. Establishing and identifying insulin-resistance HepG2 cell line.
Chin. J. Diabetes 1999, 7, 198–200.
17. Xie, W.D.; Wang, W.; Su, H.; Xing, D.M.; Pan, Y.; Du, L.J. Effects of ethanolic extracts of Ananas
comosus L. leaves on insulin sensitivity in rats and HepG2. Comp. Biochem. Physiol. Part C 2006,
143, 429–435.
18. Xie, F.Y.; Ma, Y.; Ding, E.X.; Zhong, Y.X.; Dang, W.H.; Wang, Q.Y. Syntheses and Structural
Characterization of Formononetin Derivatives. Chin. J. Spectrosc. Lab. 2013, 30, 892–897.

Molecules 2015, 20
17040
19. Huang, S.; Xie, R.G.; Tian, B.Z.; Qin, S.Y. Preparation Manual of Organic Synthesis Reagent;
Science Press: Beijing, China, 2005.
20. Zhu, Y.J.; Zhang, Y.J.; Liu, Y.; Chu, H.W.; Duan, H.Q. Synthesis and Biological Activity of
trans-Tiliroside Derivatives as Potent Anti-Diabetic Agents. Molecules 2010, 15, 9174–9183.
21. Wu, C.M.; Luan, H.; Wang, S. Zhang, X.; Wang R.; Jin, L.F.; Guo, P.; Chen, X. Modulation of
Lipogenesis and Glucose Consumption in HepG2 Cells and C2C12 Myotubes by Sophoricoside.
Molecules 2013, 18, 15624–15635.
22. Michiels, C. Endothelial cell unctions. J. Cell. Physiol. 2003, 196, 430–443.
23. Ding, H.; Hashem, M.; Wiehler, W.B.; Lau, W.; Martin, J.; Reid, J.; Triggle, C. Endothelial
dysfunction in the streptozotocin-induced diabetic apoE-deficient mouse. Br. J. Pharmacol. 2005,
146, 1110–1118.
24. Jiang, L.; Jin, K.K.; Guo, J.; Wang, W. Effects of glucose in different concentrations on SOD,
NOS and NO produced by human umbilical vein endothelial cell. J. Wenzhou Med. Coll. 2007, 37,
24–25.
Sample Availability: Samples of the compounds 1a–1e, 2a–2j, 3a–3d, 4a–4c, 5 are available from
the authors.
© 2015 by the authors; licensee MDPI, Basel, Switzerland. This article is an open access article
distributed under the terms and conditions of the Creative Commons Attribution license
(http://creativecommons.org/licenses/by/4.0/).
