ture to a solution of compound 6 (79.4 g, 0.395 mol) in CH2Cl2
(450 mL), after which methanesulfonyl chloride (33.9 mL,
0.435 mol) was added dropwise with cooling to –78 °С, and the
mixture was stirred for 1 h. Then cooling was removed, and
the reaction mixture was stirred at room temperature for 4 h.
Then 3.5% HCl (100 mL) was added. The aqueous phase was
extracted with CH2Cl2 (2×100 mL), and the joined organic
phases were washed with a solution of Na2CO3, dried over
MgSO4, and concentrated by evaporation to obtain a blue oil,
which further crystallized completely. The yield was 105.2 g
(96%, dark blue crystals, the color is caused by admixtures),
m.p. 118 °С (after recrystallization from benzene). 1H NMR, δ:
1.90 (s, 6 Н, 2 —СН3); 2.80 (s, 3 Н, —OSO2СН3); 4.78 (s, 2 Н,
—СН2—О—); 5.90 (s, 2 Н, H(3), H(4), pyrrolyl); 7.22—7.25
(m, 1 Н); 7.46—7.50 (m, 2 Н); 7.59—7.63 (m, 1 Н). Found (%):
C, 60.27; H, 6.18. C14H17NO3S. Calculated (%): C, 60.19;
H, 6.13.
Thus, a possibility to synthesize 4ꢀhetarylindenyl
zirconium complexes, viz., structural analogs of bisindenyl
complex 1, was demonstrated using indenylpyrrole 12 and
zirconocene 14 as an example. In addition, it was shown
that the presence of the pyrrole fragment unsubstituted in
the αꢀposition in the molecule of an organic ligand does
not principally prevent the synthesis of organoelement
derivatives and metallocenes using standard procedures.
Experimental
All experiments were carried out in inert atmosphere (argon).
Wholeꢀsealed glass systems of the Schlenk type were used for
crystallization of complex 14. Ethyl anthranylate (2ꢀaminoꢀ
benzoate) was prepared according to a known procedure4 in
60% yield. Ethereal solvents and toluene were distilled over
sodium in the presence of benzophenone (dibenzoꢀ18ꢀcrownꢀ6
was added in the case of toluene). Methylene chloride was
purified by distillation with CaH2. 1H and 13C NMR spectra
were recorded on a Varian VXRꢀ400 instrument in CDCl3 at
20 °C. Elemental analyses for hydrogen and carbon were carried
out on a Carlo Erba automated analyzer (model 1106). Samples
for elemental analysis of oily compounds were preheated at
70—80 °С on a vacuum setup to a constant residual pressure
(about 10–2 Torr).
Ethyl 2ꢀ(2,5ꢀdimethylꢀ1Hꢀpyrrolꢀ1ꢀyl)benzoate (5). A mixture
of ester 4 (18.1 g, 110 mmol) and 2,5ꢀhexanedione (20 mL,
165 mmol) in glacial acetic acid (100 mL) was refluxed for 1 h,
cooled, and poured into water with ice (250 mL). After CH2Cl2
(100 mL) was added, the organic phase was separated, and the
aqueous phase was extracted with CH2Cl2 (5×50 mL). Joined
organic phases were washed with a solution of Na2CO3, dried
over MgSO4, and concentrated by evaporation to obtain the
product as a light brown oil in a yield of 26.3 g (98%). 1H NMR,
δ: 1.23 (t, 3 Н, —О—СН2—СН3, J = 7.2 Hz); 1.94 (s, 6 Н,
—СН3); 4.1 (q, 2 Н, —О—СН2—СН3, J = 7.2 Hz); 5.88 (s,
2 Н, H(3), H(4), pyrrolyl); 7.28 (dd, 1 Н, J = 8 Hz, J = 2 Hz);
7.50 (ddd, 1 Н, J = 8 Hz, J = 8 Hz, J = 2 Hz); 7.60 (ddd, 1 Н,
J = 8 Hz, J = 8 Hz, J = 2 Hz); 7.95 (dd, 1 H, J = 8 Hz, J = 2 Hz).
Found (%): C, 73.99; H, 7.11. C15H17NO2. Calculated (%):
C, 74.05; H, 7.04.
3ꢀ[2ꢀ(2,5ꢀDimethylꢀ1Hꢀpyrrolꢀ1ꢀyl)phenyl]ꢀ2ꢀmethylpropionic
acid (8). A solution of diethyl 2ꢀmethylmalonate (6.8 mL,
0.039 mol) in Et2O (20 mL) was added dropwise to a suspension
of NaH (1.45 g of 60% suspension in oil, 36 mmol) in Et2O
(80 mL) under argon with cooling to 0 °С. Cooling was removed,
and the reaction mixture was stirred for 1.5 h. Then a solution of
compound 7 (8.46 g, 0.03 mol) in Et2O (50 mL) was rapidly
added by small portions to the reaction mixture with cooling to
–40 °С. Cooling was removed, and the mixture was refluxed
for 3 h and stirred at room temperature for 16 h. Then 3% HCl
(100 mL) was added to the reaction mixture, the aqueous phase
was extracted with CH2Cl2 (4×50 mL), and the joined organic
phase was washed with a solution of Na2CO3, dried over MgSO4,
and evaporated. The obtained brown oil was dissolved in alcohol
(45 mL), then mixed with an aqueous solution of KOH (12 g of
KOH in 22.5 mL of H2O), and the mixture was refluxed for 4 h.
The reaction mixture was poured into water (100 mL), the
solution formed was extracted with Et2O (3×50 mL), and the
aqueous phase was acidified with HCl to pH ≈ 1 and extracted
with CH2Cl2 (4×80 mL). The joined organic phases were washed
with a solution of Na2CO3, dried over MgSO4, and evaporated
to dryness. The resulting redꢀbrown solid residue was heated in
an oil bath (160 °С) until gas stopped evolving (about 25 min),
and the product was obtained as a viscous brown oil, which
further crystallized, in a yield of 5.46 g (70%). 1H NMR, δ: 1.06
(d, 3 Н, CH2CHCH3 , J = 7.6 Hz); 1.90 (s, 3 Н); 1.94 (s, 3 Н);
2.56 (sext, 1 Н, —СН2СНCH3—, J = 7.6 Hz); 2.75 (dd, 1 Н,
J = 14 Hz, J = 7.6 Hz), 2.32 (dd, 1 Н, J = 14 Hz, J = 7.6 Hz)
{—СН2—СНМе—}; 5.9 (s, 2 Н, H(3), H(4), pyrrolyl);
7.14—7.17 (m, 1 Н); 7.29—7.36 (m, 3 Н). Found (%): C, 74.61;
H, 7.39. C16H19NO2. Calculated (%): C, 74.68; H, 7.44.
4ꢀ(2,5ꢀDimethylꢀ1Hꢀpyrrolꢀ1ꢀyl)ꢀ2ꢀmethylindanꢀ1ꢀone (9).
Compound 8 (2.57 g, 10 mmol) was added with stirring to
polyphosphoric acid (prepared by dissolution of P2O5 (100 g) in
80 mL of H3PO4) and heated to 120 °C. After 1 h at this
temperature the mixture was poured to water with ice (500 mL).
The resulting mixture was extracted with methylene chloride
(4×25 mL), and the joined organic phases were washed with a
solution of Na2CO3 (2×50 mL), dried over MgSO4, and conꢀ
centrated by evaporation. A broad fraction (Rf in an interval of
0.8—0.4) was separated by column chromatography (silica gel,
benzene—ethyl acetate (5 : 1) as eluent). After the solvent was
removed, the weight of the fraction was 0.1 g. The isolated
[2ꢀ(2,5ꢀDimethylꢀ1Hꢀpyrrolꢀ1ꢀyl)phenyl]methanol (6).
A solution of 5 (26.3 g, 0.108 mol) in Et2O (30 mL) was added
dropwise to a suspension of LiAlH4 (4.1 g, 0.108 mol) in Et2O
(120 mL) under argon with cooling to 0 °С. Then cooling was
removed, and the reaction mixture was stirred at room tempeꢀ
rature for 1 h. Then water was added by small portions to the
reaction mixture until the end of gas evolution. The resulting
mixture was washed with Et2O (6×50 mL), and the joined organic
phases were washed with water (2×100 mL), dried over MgSO4,
and evaporated to obtain a dark brown solid residue, which was
recrystallized from boiling hexane. The yield was 18.12 g (83.5%)
1
of 6 as light beige needleꢀlike crystals (m.p. 107 °С). H NMR,
δ: 1.60 (s, 1 Н, —СН2—ОН); 1.90 (s, 6 Н, —СН3); 4.30 (s, 2 Н,
—СН2—ОН); 5.90 (s, 2 Н, H(3), H(4), pyrrolyl); 7.17 (dd, 1 Н,
J = 7.8 Hz, J = 1.9 Hz); 7.37—7.48 (m, 2 Н); 7.59 (dd, 1 Н,
J = 8.1 Hz, J = 1.6 Hz). Found (%): C, 77.60; H, 7.56.
C13H15NO. Calculated (%): C, 77.59; H, 7.51.
2ꢀ(2,5ꢀDimethylꢀ1Hꢀpyrrolꢀ1ꢀyl)benzyl methanesulfonate (7).
Triethylamine (68.4 mL, 0.494 mol) was added at room temperaꢀ
product was compound
9 insignificantly contaminated
