Identification of HSP60 as a Primary Target of
o-Carboranylphenoxyacetanilide, an HIF-1r Inhibitor
Hyun Seung Ban, Kazuki Shimizu, Hidemitsu Minegishi, and Hiroyuki Nakamura*
Department of Chemistry, Faculty of Science, Gakushuin UniVersity, Mejiro, Tokyo 171-8588, Japan
Received May 31, 2010; E-mail: hiroyuki.nakamura@gakushuin.ac.jp
Abstract: We succeeded in the design and synthesis of multi-
functional chemical probes of the HIF-1R inhibitor carboranylphe-
noxyacetanilide (1) that combine photoaffinity labeling and click
reaction to identify the target protein. HSP60 was identified as a
primary target protein of 1 using the chemical probes 2 and 3.
Furthermore, HSP60 inhibitor 4 suppressed hypoxia-induced HIF
activation, indicating that HSP60 affects HIF-1R accumulation
directly or indirectly.
The hypoxia-inducible factor (HIF) is a basic helix-loop-helix
heterodimeric transcription factor composed of one of three subunits
(HIF-1R, -2R, or -3R) and a HIF-1ꢀ subunit.1-3 Under aerobic
conditions, HIF-1R is rapidly degraded via a 26S proteasome-
dependent pathway, whereas under hypoxic conditions, HIF-1R is
stabilized and translocated into the nucleus, where it dimerizes with
the constitutively expressed HIF-1ꢀ.4-7 The HIF-1R/ꢀ dimer binds
to specific nucleotide sequences [hypoxia-responsive elements
(HREs)] in the promoter of hypoxia-responsive genes such as
vascular endothelial growth factor (VEGF), insulin-like growth
factor, heme oxygenase-1, and inducible nitric oxide synthase.8,9
Among the HIF-regulated genes, VEGF plays a pivotal role in
pathological angiogenesis and tumor growth;10,11 therefore, the
inhibition of the VEGF inducer HIF is recognized as an attractive
strategy for cancer therapy.8,12 Our efforts have been focused on
the development of HIF inhibitors13-17 as antiangiogenesis agents.
Recently, we reported that o-carboranylphenoxyacetanilide (1)
induced a potent inhibitory effect on HIF-1R activation under
hypoxic conditions.18 In the present study, we clarified the action
mechanism of 1 against HIF inhibition.
Figure 1. Chemical probes of o-carboranylphenoxyacetanilide 1 and their
HIF inhibitory activities under hypoxic conditions. (A) Chemical structures
of 1 and the chemical probes 2 and 3. (B) Inhibitory effects of 1 and the
probes 2 and 3 on transcriptional activity of HIF were determined by HeLa
cell-based HRE reporter gene assay. (C) Effects of 1 (10 µM) and probes
2 and 3 (30 µM) on the hypoxia-induced increase in HIF-1R protein were
determined by immunoblot analysis in HeLa cells.
Standard chemical biology techniques, including photoaffinity
labeling, click conjugation, and biotinylation, are very useful tools
for detecting target proteins of biologically active molecules having
undefined action mechanisms.19-21 On the basis of this approach,
we designed and synthesized multifunctional chemical probes of 1
substituted with benzophenone to covalently bond with a target
protein by UV (photoaffinity labeling) and an acetylene moiety to
conjugate with azide-linked fluorescence by click reaction (Figure
1A). The chemical probes of 1 (2 and 3) were synthesized from
4-ethynylphenoxyacetic acid (5) and aminobenzophenones 6a-c
(Scheme S1 in the Supporting Information). To confirm whether
the synthesized probes exhibit HIF inhibitory activity, we examined
the effects of the probes on the hypoxia-induced activation of HIF
in HeLa human cervical cancer cells by HRE reporter gene assay
and immunoblot analysis. As shown in Figure 1B,C, although the
inhibitory effects of probes 2 and 3 against HIF transcriptional
activity were decreased almost 10-fold relative to 1 (Figure 1B),
the reducing property of the probes on the HIF-1R protein level
were parallel to that of 1 (Figure 1C). These results indicate that
Figure 2. Fluorescence imaging of target protein bound to the probe. (A)
HeLa cell lysate was irradiated for 30 min at 360 nm with various
concentrations (30, 100, and 300 µM) of each probe. The conjugation of
probe and Alexa Fluor 488 azide was performed by click reaction. (B) Total
cell lysates from HeLa cells were photoaffinity-labeled with 3 (100 µM) in
the presence or absence of 1 (500 µM).
the boronic acid in 1 is an efficient functional group for HIF
inhibition, a finding similar to the results of our previous study.18
Using these chemical probes, we performed photoaffinity labeling
in HeLa cell lysate and click conjugation with Alexa Fluor 488
azide to visualize the target protein (see the Supporting Information).
After sodium dodecyl sulfate polyacrylamide gel electrophoresis
(SDS-PAGE), proteins bound to the probe Alexa Fluor 488 were
visualized by direct in-gel fluorescence detection. As shown in
Figure 2A, a major fluorescent band above the 55 kDa molecular
weight marker was detected by both probes in a concentration-
dependent manner, and binding of 3 with the protein was slightly
9
11870 J. AM. CHEM. SOC. 2010, 132, 11870–11871
10.1021/ja104739t  2010 American Chemical Society

C O M M U N I C A T I O N S
that stimulates HIF-1R degradation by affecting folding and
maturation.23-25 Unlike HSP90, the interaction of HSP60 and HIF-
1R has not been established. To our knowledge, this is the first
report demonstrating the implication of HSP60 in HIF activation.
However, details of the functional association between HSP60 and
HIF-1R remain to be elucidated.
In conclusion, we have succeeded in the design and synthesis
of multifunctional molecular probes of the HIF-1 inhibitor o-
carboranylphenoxyacetanilide 1 that combine photoaffinity labeling
and click reaction to identify the target protein. Using the chemical
probes 2 and 3, we identified that HSP60 is the target protein of 1.
Furthermore, HSP60 inhibitor 4 suppressed hypoxia-induced HIF
activation, indicating that HSP60 affects HIF-1R accumulation
directly or indirectly.
Acknowledgment. This work was supported in part by a Grant-
in-Aid for Scientific Research on Priority Areas “Cancer Therapy”
from the Ministry of Education, Culture, Sports, Science and
Technology, Japan.
Figure 3. Fluorescence imaging of probe-labeled recombinant HSP60 and
HIF inhibition by 4. (A) Recombinant human HSP60 (2 µg) was irradiated
with 3 (10 µM) in the presence or absence of 1 (100 µM) and click-
conjugated with Alexa Fluor 488 azide. (B) Structure of HSP60 inhibitor
4. (C) Inhibition of HIF transcriptional activity by 4 in HeLa cells.
Supporting Information Available: Detailed experimental proce-
dures for syntheses and biological assays, analytical data for compounds,
and results of biological experiments. This material is available free
of charge via the Internet at http://pubs.acs.org.
more sensitive than that of 2. To confirm the specificity of probe
binding, we performed competition assays with 1. As shown in
Figure 2B, competition with 1 resulted in almost complete
abrogation of the level of the fluorescent band at ∼55 kDa. Similar
results were also observed in a competition assay with 8c, an
acetylene-free analogue of the chemical probes 2 and 3 (Figure S1
in the Supporting Information). These results raise the possibility
that the band at ∼55 kDa may be the main target protein of 1 and
its probes.
References
(1) Iwai, K.; Yamanaka, K.; Kamura, T.; Minato, N.; Conaway, R. C.;
Conaway, J. W.; Klausner, R. D.; Pause, A. Proc. Natl. Acad. Sci. U.S.A.
1999, 96, 12436.
(2) Harris, A. L. Nat. ReV. Cancer 2002, 2, 38.
(3) Maxwell, P. H.; Wiesener, M. S.; Chang, G. W.; Clifford, S. C.; Vaux,
E. C.; Cockman, M. E.; Wykoff, C. C.; Pugh, C. W.; Maher, E. R.; Ratcliffe,
P. J. Nature 1999, 399, 271.
To identify the protein manifested at above 55 kDa, we next
performed two-dimensional electrophoresis (Figure S2) followed
by in-gel digestion and peptide mass fingerprinting analysis (PMF)
by liquid chromatography/electrospray ionization time-of-flight mass
spectrometry (LC/ESI-TOF MS). As shown in Figure S3, PMF
analysis searched in Mascot revealed that the protein bound to the
probe was heat shock protein 60 (HSP60) with a significant score
value of 245, sequence coverage of 73%, and 28 matching peptides
(Table S1). To confirm the direct binding of chemical probe 3 and
HSP60, in-gel fluorescence imaging was performed with recom-
binant human HSP60 protein, and a fluorescent band was observed
in the presence of 3 (Figure 3A, lane 2). Under these conditions,
an excess of 1 suppressed the binding of HSP60 and the chemical
probe 3 (Figure 3A, lane 3). In addition, 3 selectively bound to
HSP60 in a mixture of recombinant HSP60, -70, and -90 (Figure
S5). Moreover, an immunoprecipitation assay demonstrated that
HSP60 interacts with HIF-1R in HeLa cells (Figure S6A). These
results suggest that the binding of 1 to HSP60 appears to be
implicated in the inhibition of HIF-1R. To further clarify the
relationship between HSP60 and HIF-1R, the effects of the known
HSP60 inhibitor epolactaene tert-butyl ester (4)22 (Figure 3B) on
the hypoxia-induced activation of HIF were examined. As shown
in Figure 3C, 4 inhibited the hypoxia-induced transcriptional
activation of HIF with an IC50 value of 1.91 µM (Figure 3C) and
accumulation of HIF-1R similar to 1 (Figure S6C). Furthermore, 4
showed the competitive property against binding of 3 to recombi-
nant HSP60 (Figure S6E, lane 3). These results show that HSP60
inhibitor 4 inhibits activation of HIF as well as 1, indicating that
HSP60 is involved in the activation of HIF-1R. Moreover, 1
inhibited HSP60 chaperone activity similar to 4 (Figure S7A).
Interestingly, 1 suppressed HSP60 ATPase activity (Figure S7B),
but 4 did not affect the activity.
(4) Cockman, M. E.; Masson, N.; Mole, D. R.; Jaakkola, P.; Chang, G. W.;
Clifford, S. C.; Maher, E. R.; Pugh, C. W.; Ratcliffe, P. J.; Maxwell, P. H.
J. Biol. Chem. 2000, 275, 25733.
(5) Berra, E.; Richard, D. E.; Gothie, E.; Pouyssegur, J. FEBS Lett. 2001, 491,
85.
(6) Jaakkola, P.; Mole, D. R.; Tian, Y. M.; Wilson, M. I.; Gielbert, J.; Gaskell,
S. J.; Kriegsheim, A.; Hebestreit, H. F.; Mukherji, M.; Schofield, C. J.;
Maxwell, P. H.; Pugh, C. W.; Ratcliffe, P. J. Science 2001, 292, 468.
(7) Ivan, M.; Kondo, K.; Yang, H.; Kim, W.; Valiando, J.; Ohh, M.; Salic, A.;
Asara, J. M.; Lane, W. S.; Kaelin, W. G., Jr. Science 2001, 292, 464.
(8) Semenza, G. L. Nat. ReV. Cancer 2003, 3, 721.
(9) Dawn, B.; Bolli, R. Am. J. Physiol. Heart Circ. Physiol. 2005, 289, H522.
(10) Cao, Y.; Linden, P.; Farnebo, J.; Cao, R.; Eriksson, A.; Kumar, V.; Qi,
J. H.; Claesson-Welsh, L.; Alitalo, K. Proc. Natl. Acad. Sci. U.S.A. 1998,
95, 14389.
(11) Ferrara, N.; Gerber, H. P.; LeCouter, J. Nat. Med. 2003, 9, 669.
(12) Semenza, G. L. Oncogene 2010, 29, 625.
(13) Rapisarda, A.; Uranchimeg, B.; Scudiero, D. A.; Selby, M.; Sausville, E. A.;
Shoemaker, R. H.; Melillo, G. Cancer Res. 2002, 62, 4316.
(14) Koh, M. Y.; Spivak-Kroizman, T.; Venturini, S.; Welsh, S.; Williams, R. R.;
Kirkpatrick, D. L.; Powis, G. Mol. Cancer Ther. 2008, 7, 90.
(15) Yeo, E.-J.; Chun, Y.-S.; Cho, Y.-S.; Kim, J.; Lee, J.-C.; Kim, M.-S.; Park,
J.-W. J. Natl. Cancer Inst. 2003, 95, 516.
(16) Uno, M.; Ban, H. S.; Nakamura, H. Bioorg. Med. Chem. Lett. 2009, 19,
3166.
(17) Won, M.-S.; Im, N.; Park, S.; Boovanahalli, S. K.; Jin, Y.; Jin, X.; Chung,
K.-S.; Kang, M.; Lee, K.; Park, S.-K.; Kim, H. M.; Kwon, B. M.; Lee,
J. J.; Lee, K. Biochem. Biophys. Res. Commun. 2009, 385, 16.
(18) Shimizu, K.; Maruyama, M.; Yasui, Y.; Minegishi, H.; Ban, H. S.;
Nakamura, H. Bioorg. Med. Chem. Lett. 2010, 20, 1453.
(19) Kotzyba-Hibert, F.; Kapfer, I.; Goeldner, M. Angew. Chem., Int. Ed. Engl.
1995, 34, 1296.
(20) Kolb, H. C.; Finn, M. G.; Sharpless, K. B. Angew. Chem., Int. Ed. 2001,
40, 2004.
(21) Rostovtsev, V. V.; Green, L. G.; Fokin, V. V.; Sharpless, K. B. Angew.
Chem., Int. Ed. 2002, 41, 2596.
(22) Nagumo, Y.; Kakeya, H.; Shoji, M.; Hayashi, Y.; Dohmae, N.; Osada, H.
Biochem. J. 2005, 387, 835.
(23) Gradin, K.; McGuire, J.; Wenger, R. H.; Kvietikova, I.; Whitelaw, M. L.;
Toftgård, R.; Tora, L.; Gassmann, M.; Poellinger, L. Mol. Cell. Biol. 1996,
16, 5221.
(24) Mabjeesh, N. J.; Post, D. E.; Willard, M. T.; Kaur, B.; Van Meir, E. G.;
Simons, J. W.; Zhong, H. Cancer Res. 2002, 62, 2478.
(25) Isaacs, J. S.; Jung, Y. J.; Mimnaugh, E. G.; Martinez, A.; Cuttitta, F.;
Neckers, L. M. J. Biol. Chem. 2002, 277, 29936.
It has been reported that HIF-1R is one of the client proteins of
molecular chaperon HSP90 and geldanamycin, an HSP90 inhibitor
JA104739T
9
J. AM. CHEM. SOC. VOL. 132, NO. 34, 2010 11871
