Chemistry of Heterocyclic Compounds, Vol. 46, No. 3, 2010
SYNTHESIS OF A NOVEL HETEROCYCLIC SYSTEM
6H-PYRROLO[2',3',4':4,5]NAPHTHO[1,8-de][1,2,3]TRIAZINES
A. S. Lyakhovnenko1, A. V. Aksenov1*, and A. V. Andrienko1
Keywords: 6H-pyrrolo[2',3',4':4,5]naphtho[1,8-de][1,2,3]triazines, PPA, sodium azide, 1H-1,5,6,7-
tetraazacyclopenta[c,d]phenalenes, peri annelation, Schmidt reaction.
We have previously developed a series of methods of peri annelation of six-membered rings to a
1H-naptho[1,8-de][1,2,3]triazine [1, 2]. With the high biological activity of a significant number of indole
derivatives we have now developed a method for the peri annelation of a pyrrole ring to this compound. It was
found that the reaction of 1 mmole of ketone 1 and NaN3 (0.07 g, 1.08 mmol) in PPA* (2-3 g; the PPA used had
an 86% P2O5 content and was prepared by method [3]) at 60-70ºC for 1 h followed by addition of acetic or
benzoic acid (2 mmol) with heating at 100-110ºC for 4 h (monitoring by TLC) gave the previously unknown
1H-1,5,6,7-tetraazacyclopenta[c,d]phenalenes 3a,b in 41 and 34% yield respectively
N
N
N
N
N
NH
N
NH
N
RCO2H
PPA
NaN3
PPA
N
H
HN
O
O
R
Me
3a,b
Me
1
2
3 a R = Me, b R = Ph
The reaction included an intermediate formation of the amide 2 which could be separated.
1H NMR spectra were recorded on a Bruker WP-200 (200 MHz) instrument using DMSO-d6 with TMS
as internal standard. Monitoring of the reaction course and the purity of the synthesized compounds was carried
out on Silufol UV-254 plates with ethyl acetate as solvent. The reaction mixture was treated with water (50 ml)
and basified with ammonia solution to pH 8-9. The precipitate formed was filtered off. The mother liquor was
extracted with hot benzene (3×50 ml). The solvent was evaporated and the residue was combined with the
precipitate. The compounds obtained were purified by recrystallization.
_______
* To whom correspondence should be addressed, e-mail: k-biochem-org@stavsu.ru.
1Stavropol State University, Stavropol 355009, Russia.
__________________________________________________________________________________________
Translated from Khimiya Geterotsiklicheskikh Soedinenii, No. 3, pp. 462-464. March, 2010. Original
article submitted February 2, 2010.
370
0009-3122/10/4603-0370©2010 Springer Science+Business Media, Inc.

N-(1H-Naphtho[1,8-de][1,2,3]triazin-6(7)-yl)acetamide (2). Yield 0.147 g (65%); mp 225-226ºC
(decomp., ethyl acetate). 1H NMR spectrum, , ppm (J, Hz): 2.13 (3H, s, COCH3); 6.93 (1H, d, J = 7.7, H-9(4));
7.31 (1H, dd, J = 8.4 and J = 7.7, H-8(5)); 7.38 (1H, d, J = 8.1, H-4(9)); 7.46 (1H, d, J = 8.4, H-7(6)); 8.31 (1H,
d, J = 8.1, H-5(8)); 9.60 (1H, br. s, NHCO); 11.0 (1H, br. s, NH). Found, %: C 63.87; H 4.42; N 24.68.
C12H10N4O. Calculated, %: C 63.71; H 4.46; N 24.76.
7-Methyl-6H-pyrrolo[2',3',4':4,5]naphtho[1,8-de][1,2,3]triazine (3a). Yield 0.085 g (41%); mp
1
271-273ºC (decomp., benzene). H NMR spectrum, , ppm (J, Hz): 2.96 (3H, s, CH3); 7.63 (1H, d, J = 9.0,
H-9); 7.82 (1H, d, J = 9.0, H-3); 8.34 (1H, d, J = 9.0, H-4); 8.54 (1H, d, J = 9.0, H-8); 13.1 (1H, br. s, NH).
Found, %: C 69.38; H 3.79; N 26.83. C12H8N4. Calculated, %: C 69.22; H 3.87; N 26.91.
7-Phenyl-6H-pyrrolo[2',3',4':4,5]naphtho[1,8-de][1,2,3]triazine (3b). Yield 0.092
g
(34%);
1
mp 284-286ºC (decomp., benzene). H NMR spectrum, , ppm (J, Hz): 7.55 (3H, m, H-3,4,5 Ph); 7.69 (1H, d,
J = 9.0, H-3); 7.82 (1H, d, J = 8.8, H-9); 8.21 (2H, d, J = 7.7, H-2,6 Ph); 8.38 (1H, d, J = 8.8, H-8); 8.74 (1H, d,
J = 9.0, H-4); 12.8 (1H, br. s, NH). Found, %: C 75.71; H 3.65; N 20.64. C17H10N4. Calculated, %: C 75.54;
H 3.73; N 20.73.
This work was carried out with the financial support of the Russian Fund for Basic Research (grant
No. 10-03-00193a).
REFERENCES
1.
2.
3.
A. V. Aksenov, I. V. Borovlev, I. V. Aksenova, S. V. Pisarenko, and D. A. Kovalev, Tetrahedron Lett.,
49, 707 (2008).
А. V. Aksenov, I. V. Borovlev, I. V. Aksenova, and D. A. Kovalev, Khim. Geterotsikl. Soedin., 1590
(2007). [Chem. Heterocycl. Comp., 43, 1353 (2007)].
F. Uhlig, Angew. Chem., 66, 435 (1954).
