AD-H, OD-H, or AS-H. Mass spectra were recorded by EI
and ESI, and HRMS were measured on a HP-5989 instrument.
For thin layer chromatography (TLC) analysis throughout this
work, TLC plates were used. TLC spots were visualized under
ultraviolet light or developed by heating after treatment with
potassium permanganate. The products were purified by flash
column chromatography on silica gel (100–200 mesh).
(2S,2¢S,3R,3¢R)-1-benzyl-3,3¢-bis(benzyloxy)-2,2¢-bipyrrolidine
(2c)
In accordance with the general procedure, the reaction was carried
out in the presence of benzaldehyde (73.0 mL, 0.71 mmol) in diethyl
ether (10 mL) as solvent to afford title compound 2c as a yellowish
oil (126 mg, 40% yield). [a]2D5 = -38.6 (c = 0.60, EtOH); 1H
NMR (400 MHz, CDCl3) d 7.37–7.20 (m, 15H), 4.50 (dd, J =
2.4, 12.0 Hz, 2H), 4.38 (dd, J = 12.0, 14.0 Hz, 2H), 4.07 (d,
J = 13.6 Hz, 1H), 3.90–3.87 (m, 1H), 3.80–3.75 (m, 1H), 3.54 (d,
J = 12.8 Hz, 2H), 3.09 (dd, J = 4.4, 5.2 Hz, 1H), 3.03–2.87 (m,
4H), 2.62–2.54 (m, 1H), 2.02–1.58 (m, 4H); 13C NMR (100 MHz,
CDCl3) d 139.9, 138.6, 138.4, 128.9, 128.8, 128.7, 128.6, 128.5,
128.0, 127.9, 127.9, 127.3, 83.0, 81.6, 71.4, 71.2, 70.7, 67.3, 61.7,
53.1, 44.9, 32.5, 30.8; HRMS (ESI-TOF) Calcd. For C29H34N2O2
[M+H] 443.2699, Found: 443.2690;
General procedure for the synthesis of catalyst 2
To a solution of bipyrrolidine 1 (250 mg, 0.71 mmol) in solvent
˚
(10 mL) was added activated 4 A molecular sieves, and ketone or
aldehyde (0.71 mmol). The reaction mixture was stirred overnight
at ambient temperature, and then K2CO3 was added and stirred for
1 h. The precipitate was filtered and the filtrate was concentrated to
give the crude aminal which was used without further purification.
To a solution of the aminal in MeOH (10 mL) was added NaBH4
(40 mg, 1.07 mmol) at 0 ◦C. After stirring for 10 min, acetic acid
(0.12 mL, 2.13 mmol) was added and the mixture was stirred for
4 h. The reaction was quenched by 5 mL of 30% NaOH aqueous
solution and extracted with ethyl acetate (20 mL ¥ 3). The organic
layer was washed with brine, dried over K2CO3, filtered, and the
solvent was removed in vacuo. The obtained residue was purified
by column chromatography on silica gel (ethyl acetate : petroleum
ether = 1 : 4, 5% Et3N) to afford N-alkylated bipyrrolidine 2.
(2S,2¢S,3R,3¢R)-3,3¢-bis(benzyloxy)-1-(3-phenylpropyl)-2,2¢-
bipyrrolidine (2d)
In accordance with the general procedure, the reaction was carried
out in the presence of 3-phenylpropanal (94.3 mL, 0.71 mmol)
in diethyl ether (10 mL) as solvent to afford title compound 2d
as a yellowish oil (184 mg, 55% yield), [a]2D5 = -14.8 (c = 0.24,
EtOH); 1H NMR (400 MHz, CDCl3) d 7.37–7.23 (m, 12H), 7.20–
7.14 (m, 3H), 4.51–4.36 (m, 3H), 4.28 (d, J = 11.6 Hz, 1H),
3.85 (d, J = 5.2 Hz, 1H), 3.70–3.64 (m, 1H), 3.16–3.08 (m, 1H),
2.97–2.89 (m, 3H), 2.84–2.74 (m, 2H), 2.70–2.60 (m, 1H), 2.59–
2.45 (m, 3H), 1.97–1.66 (m, 6H); 13C NMR (100 MHz, CDCl3)
d 142.5, 138.8, 138.7, 128.6, 128.6, 128.5, 128.0, 127.8, 127.8, 127.7,
82.8, 81.7, 72.2, 71.4, 70.4, 68.4, 57.3, 52.6, 45.2, 33.7, 32.9, 30.9,
30.7; HRMS (ESI-TOF) Calcd. for C31H38N2O2 [M+H] 470.2933,
Found: 470.2938.
(2S,2¢S,3R,3¢R)-3,3¢-bis(benzyloxy)-1-isopropyl-2,2¢-bipyrrolidine
(2a)
In accordance with the general procedure, the reaction was carried
out in acetone (10 mL) as solvent to afford title compound 2a as a
yellowish oil (207 mg, 74% yield). [a]2D5 = +19.0 (c = 0.20, EtOH);
1H NMR (400 MHz, CDCl3) d 7.35–7.21 (m, 10H), 4.50 (d, J =
12.0 Hz, 1H), 4.43 (s, 2H), 4.35 (d, J = 12.0 Hz, 1H), 3.83–3.80
(m, 1H), 3.74–3.69 (m, 1H), 3.03–2.76 (m, 7H), 1.92–1.72 (m, 4H),
1.65 (s, 1H), 1.08 (d, J = 6.0 Hz, 3H), 0.97 (d, J = 6.0 Hz, 3H);
13C NMR (100 MHz, CDCl3) d 128.6, 128.1, 127.8, 127.7, 127.6,
82.4, 81.7, 71.3, 70.2, 68.8, 68.0, 51.2, 45.2, 44.0, 33.0, 30.8, 23.0,
15.1; HRMS (EI-TOF) calcd for C25H34N2O2 394.2620, Found:
394.2629.
General procedure for the asymmetric Friedel–Crafts alkylation
reaction
To a stirred solution of catalysts 2a (0.01 mmol, 3.9 mg) and TfOH
(0.02 mmol, 1.8 mL) in MeOH (2 mL) was added a,b-unsaturated
aldehyde (1.5 mmol) at -45 ◦C. The solution was stirred for 10 min
before indole (0.5 mmol) was added. The reaction mixture was
stirred at -45 ◦C for 36–64 h and warmed to ambient temperature.
The reaction was quenched by saturated NaHCO3, extracted with
CH2Cl2 (5 mL ¥ 3) and washed with brine. The organic layer
was dried by anhydrous Na2SO4, filtered, and the solvent was
removed in vacuo. The residue was purified by silica gel column
chromatography (ethyl acetate : petroleum ether = 1 : 6) to afford
the corresponding 3-alkylated indole. To determine enantiomeric
excess, the product was converted to the corresponding alcohol
with NaBH4 in MeOH and enantiomeric excess was determined
by HPLC using a Chiracel AD-H, OD-H, or AS-H. See the ESI†
for further details.
(2S,2¢S,3R,3¢R)-3,3¢-bis(benzyloxy)-1-cyclohexyl-2,2¢-
bipyrrolidine (2b)
In accordance with the general procedure, the reaction was carried
out in the presence of cyclohexenone (73.5 mL, 0.71 mmol) in THF
(10 mL) as solvent to afford title compound 2b as a yellowish oil
1
(139 mg, 45% yield). [a]2D5 = +4.4 (c = 1.2, EtOH); H NMR
(400 MHz, CDCl3) d 7.34–7.23 (m, 10H), 4.49 (d, J = 11.6 Hz,
1H), 4.42 (d, J = 2.8 Hz, 2H), 4.35 (d, J = 11.6 Hz, 1H), 3.85–3.81
(m, 1H), 3.73–3.68 (m, 1H), 3.09 (d, J = 6.0 Hz, 1H), 3.01–2.84
(m, 5H), 2.63–2.52 (m, 1H), 1.82–1.69 (m, 6H), 1.61 (m, J =
11.6 Hz, 1H), 1.36–0.97 (m, 7H); 13C NMR (100 MHz, CDCl3)
d 138.8, 138.6, 128.6, 128.6, 128.0, 127.8, 127.7, 82.0, 81.8, 71.3,
70.3, 68.2, 68.1, 61.0, 45.7, 45.2, 33.6, 33.0, 30.9, 26.6, 26.5, 26.0,
25.9; HRMS (ESI-TOF) Calcd. For C28H38N2O2 [M+H] 435.3012,
Found: 435.3021.
Acknowledgements
This research was supported by the National Natural Science
Foundation of China, and Shanghai Jiao Tong University (Chenx-
ing Program).
