A ditetrylyne as a π-electron donor: Synthesis and characterization of [AgAr′GeGeAr′]+SbF6- and [Ag 2Ar′GeGe(F)Ar′]+SbF6- (Ar′ = C6H3-2,6(C6H3-2,6- Pri2)2)

Article abstract of DOI:10.1021/ja1051236

The reaction of a digermyne Ar′GeGeAr′ (Ar′ = C ₆H₃-2,6-(C₆H₃-2,6-Pr ⁱ₂)₂) with AgSbF₆ at-40 °C forms the complex (AgAr′GeGeAr′)⁺SbF₆^-, which provides the first example of a heavier group 14 element alkyne analogue behaving as a π donor to a transition metal. The cation (AgAr′ GeGeAr′)⁺ is best described as a hybrid of a π-complex and a σ-metallacyclopropene structure.

Full text of DOI:10.1021/ja1051236

Published on Web 09/01/2010
A Ditetrylyne as a π-Electron Donor: Synthesis and Characterization of
-
-
[AgAr′GeGeAr′]+SbF6 and [Ag2Ar′GeGe(F)Ar′]+SbF6
(Ar′ ) C6H3-2,6(C6H3-2,6-Pri2)2)
Xinping Wang, Yang Peng, Marilyn M. Olmstead, Ha˚kon Hope, and Philip P. Power*
Department of Chemistry, UniVersity of California, DaVis, One Shields AVenue, DaVis, California 95616
Received June 11, 2010; E-mail: pppower@ucdavis.edu
Scheme 1. Reactions of 1 with AgSbF6 at -40 and 25 °C
Abstract: The reaction of a digermyne Ar′GeGeAr′ (Ar′ ) C6H3-
2,6-(C6H3-2,6-Pri2)2) with AgSbF6 at -40 °C forms the complex
(AgAr′GeGeAr′)+SbF6-, which provides the first example of a
heavier group 14 element alkyne analogue behaving as a π donor
to a transition metal. The cation (AgAr′GeGeAr′)+ is best de-
scribed as a hybrid of a π-complex and a σ-metallacyclopropene
structure.
Several alkyne analogues (REER, E ) Si, Ge, Sn, Pb; R ) aryl
or silyl ligand) of heavier group 14 elements have been isolated
and characterized.1 Calculations on the Ge and Sn species show
that their bonding can be represented by a or b.2 In valence bond
terms, there is an approximate E-E double bond and a nonbonded,
The structure of 2·SbF6 consists of well-separated cations and
anions. The cation (Figure 1) is characterized by a C2 axis through
the silver atom and midpoint of the Ge-Ge bond. The C-Ge-Ge-C
core of 2 has a trans configuration (Ge-Ge-C ) 130.4(3)°) featuring
a near-planar Ge2{C(ipso)}2 array. The silver bridges the two Ge atoms
in a symmetric fashion. The Ag-Ge bonds (2.6501(14) Å) are ca.
0.2 Å longer than the Ag-Ge(II) bonds in complexes Ag[Ge(OC6HPh4-
2,3,5,6)3(AgOSO2CF3)]·4C6H6, HB{3,5(CF3)2Pz}3]AgGeCl[(Me)2-
ATI] and [HB{3,5-(CF3)2Pz}3]AgGe-(OSO2CF3)[(Me)2ATI] ((Me)2-
ATI ) N-methyl-2-methylamino-troponiminate), consistent with their
bridging character.6 In addition, silver is coordinated by four C atoms
from two flanking rings with Ag-C distances of 2.636(10) and
2.680(10) Å that are considerably longer than Ag-arene bonds (∼2.4
Å) in Ag(η2-PhMe)2(Al(OCH(CF3)2)4.7 The Ge-Ge distance (2.303(2)
Å) is within the range (2.2060(7)-2.307(1) Å) for digermynes1b,8,9
and is slightly longer than the 2.2850(6) Å of the Ge-Ge bond in
uncomplexed 1.1b The closest previously known structure to 2 is that
of NaAr′GeGeAr′10 (cf. very similar effective radii of four coordinate
resonating lone pair at an E. It is also possible to represent the
Ag+ (1.00 Å) and Na+ (0.99 Å)).11 In that compound, however, the
structure as the singlet diradicaloid form c.2 Their Lewis acidic
Na· · ·Ge distances (3.1391(15) and 3.1596(15) Å) are ca. 0.5 Å longer
although the closest Na-C distances are 0.15-0.2 Å longer than
Ag-C in 2. These distances suggest a significantly stronger Ge-M
character has been supported by reactions of REER (E ) Si, Ge,
Sn) with R′NC: (R′ ) But, Mes, SiMe3) that led to the formation
of adducts shown by d or e.3 In contrast, complexes such as f or g
demonstrating Lewis basic properties and species such as h, in
which REER acts as a π electron donor resembling the alkyne
congener i, have not been described.4 We now report that the
reaction of Ar′GeGeAr′ (1, Ar′ ) C6H3-2,6-(C6H3-2,6-Pri2)21b with
AgSbF6 at -40 °C (Scheme 1) leads to a metal cation REER adduct
(AgAr′GeGeAr′)+SbF6- (2·SbF6) with an SbF6- counteranion, the
first example of a heavier group 14 element alkyne analogue-
transition-metal π-complex.5
Reaction of AgSbF6 and 1 equiv of 1 in chlorobenzene at -40
°C yielded, after workup, green crystals of compound 2·SbF6 in
Figure 1. Thermal ellipsoid (50%) drawing of 2. H atoms and Pri groups
23% yield (Scheme 1). The UV-vis spectrum of 2·SbF6 in C6H5Cl
are not shown. Selected bond distances (Å) and angles (deg): Ag1-C9
displays an absorption maximum at λmax ) 412 nm (ε ) 640), which
2.636(10), Ag1-Ge1 2.6501(14), Ag1-C8 2.680(10), Ge1-C1 1.972(9),
Ge1-Ge1′ 2.303(2), Ge1-Ag1-Ge1′ 51.51(5), C1-Ge1-Ge1′ 130.4(3),
C1-Ge1-Ag1 108.6(3), Ge1-Ge1′-Ag1 64.24(2).
differs considerably from that of uncomplexed 1 (λmax ) 501 nm
(ε ) 7500), 371 nm (34 000)).1b
9
13150 J. AM. CHEM. SOC. 2010, 132, 13150–13151
10.1021/ja1051236  2010 American Chemical Society

C O M M U N I C A T I O N S
interaction for the silver species especially in view of the fact that, in
NaAr′GeGeAr′, the “Ar′GeGeAr′” unit formally carries the negative
charge.10
F1 are disordered with respect to a crystallographic inversion center,
and each atom was refined at half-occupancy at the two disordered
sites (see Supporting Information). The Ge-Ag distances (avg.
2.5310(11), 2.7415(12) Å) are unequal with the shorter bond distance
to the fluorinated Ge. The Ge-F distance (1.795(5) Å) is close to that
in compounds (e.g., 1.805(17) Å in [{HC-(CMeNAr)2}GeF] (Ar )
2,6-iPr2C6H3)).14 The Ge-Ge distance (2.4861(12) Å) may be
compared with the 2.44 Å of a single Ge-Ge bond.15 4 can be viewed
as an anionic digermyne fluoride adduct that is π-bonded to two Ag+
ions.16 Its formation and possible resonance structures of the
Ar′GeGe(F)Ar′ monoanion are shown in Scheme 2.
To further understand 2, we performed DFT calculations12 for
the model complex cation Ag(MeGeGeMe)+ (3). This was found
to have an energy minimum whose geometrical parameters compare
well with those found in the X-ray structure of 2. The calculated
HOMO-LUMO gap (71.0 kcal/mol) for 3 is close to the energy
difference of 69.4 kcal/mol suggested by the experimental UV/vis
absorption at 412 nm. Natural bond orbital (NBO) calculations
Scheme 2
In summary, it has been shown that digermyne Ar′GeGeAr′ (1)
reacts with Ag+ at low temperature to form the side-on complex 2.
Its geometry, the Ge-Ge bond lengthening, and calculated electron
densities indicate that the digermyne 1 is acting as a π electron
donor. The exploration of its chemistry is in hand.
reveal that 0.43 electrons are donated from the digermyne
MeGeGeMe to Ag+. According to the calculated second-order
perturbation interaction energies, the strongest orbital interaction
(54.0 kcal/mol) in 3 (and thus in 2) is between the π orbital
(HOMO) of the Ge-Ge bond and the empty 5s or 5p orbitals of
the Ag+ cation, shown above as j and k. The back-donation (l)
from the 4dxz orbital of Ag+ into the empty π* orbital (LUMO+1)
of Ge-Ge (l) is relatively weak (5.5 kcal/mol). Complex 2 is best
described as a hybrid of a π-complex m and a σ-metallacyclopro-
pene structure n shown below.
Acknowledgment. We thank the National Science Foundation
(CHE-0948417) for support of this research.
Supporting Information Available: CIF for 2 and 4, experimental
data, and DFT calculations. This material is available free of charge
via the Internet at http://pubs.acs.org.
References
(1) (a) Sekiguchi, A.; Kingo, R.; Ichinohe, M. Science 2004, 305, 1755. (b)
Stender, M.; Philips, A. D.; Wright, R. J.; Power, P. P. Angew. Chem., Int.
Ed. 2002, 41, 1785. (c) Phillips, A. D.; Wright, R. J.; Olmstead, M. M.;
Power, P. P. J. Am. Chem. Soc. 2002, 124, 5930. (d) Pu, L.; Twamley, B.;
Power, P. P. J. Am. Chem. Soc. 2000, 122, 3524.
(2) Jung, Y.; Brynda, M.; Power, P. P.; Head-Gordon, M. J. Am. Chem. Soc.
2006, 128, 7185.
The green color of solutions of 2·SbF6 becomes brown when
warmed above ca. 0 °C. Brown crystals of compound [Ag2Ar′GeGe-
(F)Ar′]SbF6 (4·SbF6) in 30% yield were obtained upon cooling
(Scheme 1). The reaction of 1 with AgSbF6 at room temperature also
gave 4·SbF6 in a similar yield. The mechanism of formation of 4 is
unclear, but an abstraction of F from SbF6- to form what may be a
stronger Ge-F bond (bond energy: Ge-F 473, Sb-F 405 kJ/mol) is
a possibility.13 In addition, the fluorophilicity of the three-coordinate
Ge atoms in 2 is probably quite high. The unique structure of 4 (Figure
2) features a near-planar AgGeAgGe core. The atoms Ge1, Ge2, and
(3) (a) Takeuchi, K.; Ichinohe, M.; Sekiguchi, A. J. Am. Chem. Soc. 2008,
130, 16848. (b) Cui, C.; Olmstead, M. M.; Fettinger, J. C.; Spikes, G. H.;
Power, P. P. J. Am. Chem. Soc. 2005, 127, 17530. (c) Spikes, G. H.; Power,
P. P. Chem. Commun. 2007, 85. (d) Peng, Y.; Wang, X.; Fettinger, J. C.;
Power, P. P. Chem. Commun. 2010, 46, 943.
(4) Reisinger, A.; Trapp, N.; Krossing, I.; Altmannshofer, S.; Herz, V.; Presnitz,
M.; Scherer, W. Angew. Chem., Int. Ed. 2007, 46, 8295.
(5) For complexes of alkene analogues of Si or Ge with transition metals, see:
(a) Berry, D. H.; Chey, J. H.; Zipin, H. S.; Carroll, P. J. J. Am. Chem. Soc.
1990, 112, 452. (b) Kira, M.; Sekiguchi, Y.; Iwamoto, T.; Kabuto, C. J. Am.
Chem. Soc. 2004, 126, 12778. (c) Bravo-Zhivotovskii, D.; Peleg-Vasserman,
H.; Kosa, M.; Molev, G.; Botoshanskii, M.; Apeloig, Y. Angew. Chem.,
Int. Ed. 2004, 43, 745. (d) Fischer, R.; Zirngast, M.; Flock, M.; Baum-
garther, J.; Marschner, C. J. Am. Chem. Soc. 2005, 127, 70. (e) Zirngast,
M.; Flock, M.; Baumgarther, J.; Marschner, C. J. Am. Chem. Soc. 2009,
131, 15952.
(6) (a) Weinert, C. S.; Fanwick, P. E. Acta Crystallogr. 2002, E58, 718. (b)
Rasika Dias, H. V.; Wang, Z. Inorg. Chem. 2000, 39, 3890.
(7) Krossing, I. Chem.sEur. J. 2001, 7, 490.
(8) Sugiyama, Y.; Sasamori, T.; Hosoi, Y.; Furukawa, Y.; Takagi, N.; Nagase,
S.; Tokitoh, N. J. Am. Chem. Soc. 2006, 128, 1023.
(9) Peng, Y.; Fischer, R. C.; Merrill, W. A.; Fischer, J.; Pu, L.; Ellis, B. D.;
Fettinger, J. C.; Hevler, R. H.; Power, P. P. Chem. Sci. 2010, in press.
(10) Pu, L.; Phillips, A. D.; Richards, A. F.; Stender, M.; Simons, R. S.;
Olmstead, M. M.; Power, P. P. J. Am. Chem. Soc. 2003, 125, 11626.
(11) Shannon, R. D.; Prewitt, C. T. Acta Crystallogr., Sect. B: Struct. Sci. 1969,
B25, 925.
(12) DFT calculations were performed at the level of B3LYP/3-21G* with the
Gaussian 03 package (for citation and calculation details see Supporting
Information).
(13) Huheey, J. E. Inorganic Chemistry, 3rd ed.; Harper and Row: New York,
1983; Appendix E.
Figure 2. Thermal ellipsoid (50%) drawing of 4 (only one of the disordered
core arrangements is illustrated). H atoms and Pri groups are not shown. Selected
bond distances (Å) and angles (deg): Ag1-Ge2 2.5710(11)Å, Ag1-Ge1
2.7650(12), Ag1′-Ge2 2.4908(11), Ag1′-Ge1 2.7182(11), Ge1-Ge2 2.4861(16),
Ge2-F1 1.795(5), Ag1-C11 2.814(4), Ag1-C12 2.562(3), Ag1-C13 2.820(3),
Ag1-C18 2.642(3), Ag1-Ge2-Ge1 66.274(1), Ag1-Ge1-Ge2 58.3(3),
Ge1-Ag1-Ge2 55.4(4), C1-Ge2-Ge1 124.8(1), F1-Ge2-Ge1 130.8(1),
F1-Ge2-Ag1 102.6(1), C1′-Ge1-Ge2 108.5(1).
(14) Ding, Y.; Hao, H.; Roesky, H. W.; Noltemeyer, M.; Schmidt, H.
Organometallics. 2001, 20, 4806.
(15) (a) Mackay, K. M. The Chemistry of Organic Germanium, Tin, and Lead
Compounds; Patai, S., Ed.; Wiley: Chichester, 1995; Chapter 2. (b) Baines,
K. M.; Stibbs, W. G. AdV. Organomet. Chem. 1996, 39, 275.
(16) For the formation of disilene fluoride adducts, see: Zirngast, M.; Flock,
M.; Baumgartner, J.; Marschner, C. J. Am. Chem. Soc. 2008, 130, 17460.
