Hajare et al.
JOCNote
judged by 1H NMR) can be explained based on the transition
state A. The stereochemistry of substituents on the tetrahy-
dropyran ring was established by using nOe’s (see highlighted
protons and nOe’s in B). Ester hydrolysis of 2 followed by
dimerization with Yamaguchi’s lactonization protocol16 fur-
nished 16-membered macrolide, which was subsequently con-
verted to macrocyclic diol 8 by the deprotection of benzyl
groups. Macrolide 8 was previously reported as a penultimate
precursor in the synthesis of 1. It was well-characterized by
Hong’s group, which includes X-ray crystal structure, and the
were evaporated under reduced pressure. The resulting residue
was taken in water and washed with n-pentane. Then the
aqueous layer was acidified by 1.0 N HCl and extracted
with ethyl acetate. The ethylacetate layer was washed with
brine, dried over anhydrous sodium sulfate, and concentrated
to give 64 mg (93%) of [(2S,4S,6R)-4-benzyloxy-6-((R)-2-
hydroxybutyl)-3,3-dimethyltetrahydropyran-2-yl]-acetic acid
as a white solid. Mp 162-163 °C; [R]22.1D þ11.5 (c 1.0, CHCl3);
1H NMR (400 MHz, CDCl3) δ 0.89 (t, J=7.6 Hz, 3H), 0.90 (s,
3H), 0.95 (s, 3H), 1.42-1.58 (m, 4H), 1.65 (dd, J=20.4, 10.0
Hz, 1H), 1.85 (d, J=12.0 Hz, 1H), 2.43 (s, 2H), 3.17 (dd, J =
11.2, 3.2 Hz, 1H), 3.54 (dd, J=8.4, 3.6 Hz, 1H), 3.67 (t, J=10.4
Hz, 1H), 3.87-3.90 (m, 1H), 4.43 (d, J=11.6 Hz, 1H), 4.64 (d,
J=11.6 Hz, 1H), 4.95 (br s, 1H), 7.27-7.35 (m, 5H); 13C NMR
(100 MHz, CDCl3) δ 9.6, 13.6, 22.7, 29.7, 33.7, 34.9, 38.6, 40.9,
71.3, 74.1, 77.8, 81.3, 81.9, 127.6, 127.7, 128.5, 138.8, 174.4; IR
(neat) 1728, 3459 cm-1; LCMS=351.2 [M þ H]þ.
same was glycosilated to yield 1.9 The spectral data(1Hand13
C
NMR) of the macrolide 8 from our lab were compared with
those of Hong’s group and both were found to be identical.
Specific rotation of our sample 8 showed [R]23D -38.8 (c 0.33,
CHCl3) compared to that of the literature [R]25D -36.3 (c 0.56,
CHCl3).9
To a stirred solution of the above [(2S,4S,6R)-4-benzyloxy-
6-((R)-2-hydroxybutyl)-3,3-dimethyltetrahydropyran-2-yl]-
acetic acid (70 mg, 0.2 mmol) in THF (1.0 mL) was added
triethylamine (40 μL, 0.3 mmol) followed by 2,4,6-trichloro-
benzoyl chloride (40 μL, 0.3 mmol), then the mixture was
stirred at room temperature for 3 h. The solid was filtered
and the filtrate was diluted with toluene (6 mL) and then added
dropwise to a solution of 4-dimethylaminopyridine (122 mg,
1.0 mmol) in toluene (40 mL) at reflux (125 °C) over a period of
3 h. After refluxing for an additional 4 h, the reaction mixture
was cooled to room temperature and concentrated. The crude
product was partitioned between water (15 mL) and ethyl
acetate (30 mL), and the aqueous layer was extracted with
ethyl acetate. The combined organic layer was washed with
brine, dried over anhydrous sodium sulfate, concentrated, and
purified by column chromatography (10% ethyl acetate in
hexanes) to give 32 mg (48%) of (1S,5R,7R,9S,11S,15R,
17R,19S)-9,19-bis-benzyloxy-5,15-diethyl-10,10,20,20-tetra-
methyl-4,14,21,22-tetraoxatricyclo[15.3.1.17,11]docosane-3,13-
dione. [R]22.3D þ9.2 (c0.5, CHCl3);1HNMR(400MHz, CDCl3) δ
0.85-0.89 (m,12H), 0.94 (s, 6H), 1.30 (ddd, J=12.0, 12.0Hz, 2H),
1.58-1.67 (m, 6H), 1.86-1.93 (m, 2H), 2.04-2.10 (m, 2H), 2.29
(dd, J=15.2, 9.2 Hz, 2H), 2.39 (d, J = 14.0 Hz, 2H), 3.16 (dd, J =
11.6, 4.4 Hz, 2H), 3.36-3.41 (m, 4H), 4.44 (d, J=12.0 Hz, 2H),
4.67 (d, J=12.0 Hz, 2H), 4.90 (ddd, J=8.0, 6.8, 6.8 Hz, 2H),
7.26-7.34 (m, 10 H); 13C NMR (100 MHz, CDCl3) δ 9.4, 13.2,
22.3, 27.9, 33.1, 35.1, 38.3, 41.1, 70.8, 73.2, 74.6, 80.9, 82.0, 127.2,
128.0, 138.6, 172.1; IR (neat) 1738 cm-1; LCMS=665.5 [M þ
H]þ; HRMS (ESI) m/z calcd for C40H57O8 [M þ H]þ 665.4053,
found 665.4047.
In short, we have achieved the formal synthesis of cyanolide
A (1), a potent molluscicidal agent, through Hong’s inter-
mediate, macrolide 8, starting from D-(-)-pantolactone in
a highly stereoselective manner. Choosing readily available
pantolactone and highly stereoselective Mukaiyama aldol
reaction, oxa-Michael addition to form tetrahydropyran ring,
and dimerization with Yamaguchi’s lactonization are the
salient features of this synthesis. As L-(þ)-pantolactone is also
commercially available, our route can be used for the synthesis
of the unnatural enantiomer of cyanolide A and other ana-
logues which may show improved molluscicidal activity.
Experimental Section
[(2S,4S,6R)-4-Benzyloxy-6-((R)-2-hydroxybutyl)-3,3-di-
methyltetrahydropyran-2-yl]acetic Acid Ethyl Ester (2). To a
stirred solution of (E)-(S)-5-benzyloxy-6-((4R,6R)-6-ethyl-2,
2-dimethyl[1,3]dioxan-4-yl)-4,4-dimethyl-hex-2-enoic acid eth-
yl ester 7 (110 mg, 0.3 mmol) in chloroform (5 mL) was added
p-toluenesulfonic acid monohydrate (8 mg, 0.15 mmol) then the
mixture was refluxed for 20 h. The reaction mixture was cooled
to room temperature, diluted with chloroform, washed with
saturated sodium bicarbonate solution, water, and brine, dried
over anhydrous sodium sulfate, concentrated, and purified by
column chromatography (9% ethyl acetate in hexanes) to give
82 mg (83%) of [(2S,4S,6R)-4-benzyloxy-6-((R)-2-hydroxy-
butyl)-3,3-dimethyltetrahydropyran-2-yl]acetic acid ethyl ester
2 as a colorless oil. [R]22.5D þ9.5 (c 1.0, CHCl3); 1H NMR (400
MHz, CDCl3) δ 0.91 (t, J=7.2 Hz, 3H), 0.91 (s, 3H), 0.95 (s, 3H),
1.26 (t, J=6.8 Hz, 3H), 1.40-1.54 (m, 4H), 1.57-1.67 (m, 1H),
1.85-1.89 (m, 1H), 2.38-2.48 (m, 2H), 3.17 (dd, J=11.6, 4.8 Hz,
1H), 3.49 (br s, 1H), 3.53 (dd, J=9.2, 3.2 Hz, 1H), 3.62 (t, J=10.0
Hz, 1H), 3.79 (dd, J=13.2, 6.8 Hz, 1H), 4.11-4.21 (m, 2H), 4.43
(d, J=12.0 Hz, 1H), 4.64 (d, J=12.0 Hz, 1H), 7.28-7.35 (m,
5H); 13C NMR (100 MHz, CDCl3) δ 9.9, 13.6, 14.3, 22.7, 30.2,
33.8, 35.1, 38.5, 42.0, 61.1, 71.2, 73.4, 77.9, 81.0, 82.0, 127.6,
127.7, 128.5, 138.8, 172.5; IR (neat) 1733, 3533 cm-1; LCMS=
379.3 [M þ H]þ; HRMS (ESI) m/z calcd for C22H35O5 [M þ H]þ
379.2484, found 379.2482.
Palldium hydroxide (10 mg) was added to a solution of
(1S,5R,7R,9S,11S,15R,17R,19S)-9,19-bis-benzyloxy-5,15-di-
ethyl-10,10,20,20-tetramethyl-4,14,21,22-tetraoxatricyclo-
[15.3.1.17,11]docosane-3,13-dione (30 mg) in methanol (4 mL)
then the mixture was stirred under hydrogen atmospheric
pressure (using balloon) for 20 h. The reaction mixture was
then filtered through a Celite bed. Filtrate was concentrated
and purified by column chromatography (60% ethyl acetate in
hexanes) to give 13 mg (60%) of (1S,5R,7S,9S,11S,15R,17S,
19S)-5,15-diethyl-9,19-dihydroxy-10,10,20,20-tetramethyl-
4,14,21,22-tetraoxatricyclo[15.3.1.17,11]docosane-3,13-dione
(1S,5R,7S,9S,11S,15R,17S,19S)-5,15-Diethyl-9,19-dihy-
droxy-10,10,20,20-tetramethyl-4,14,21,22-tetraoxatricyclo[15.3.1.
17,11]docosane-3,13-dione (8). To a stirred solution of [(2S,4S,
6R)-4-benzyloxy-6-((R)-2-hydroxybutyl)-3,3-dimethyltetra-
hydropyran-2-yl]acetic acid ethyl ester 2 (75 mg, 0.2 mmol) in a
mixture of THF:methanol:water (2:1:1, 2.0 mL) was added
lithium hydroxide monohydrate (33 mg, 0.8 mmol) at room
temperature. After the mixture was stirred for 20 h, volatiles
8 as a white solid. Mp 132-134 °C; [R]22.7 -38.8 (c 0.33,
D
CHCl3); 1H NMR (400 MHz, CDCl3) δ 0.83 (s, 6H), 0.87 (dd,
J=7.2, 7.2 Hz, 6H), 0.93 (s, 6H), 1.33 (ddd, J=12.0, 11.6, 11.6
Hz, 2H), 1.52-1.60 (m, 6H), 1.83-1.91 (m, 4H), 2.29 (dd, J=
15.6, 8.8 Hz, 2H), 2.40 (dd, J=15.6 Hz, 2H), 3.40 (d, J=8.0 Hz,
2H), 3.43-3.49 (m, 4H), 4.91 (ddd, J = 7.6, 6.8, 6.8 Hz, 2H);
13C NMR (100 MHz, CDCl3) δ 9.7, 12.6, 22.4, 28.3, 35.4, 37.3,
38.8, 41.0, 73.8, 75.1, 75.4, 80.8, 172.2; IR (neat) 1726, 3409
cm-1; LCMS=485.4 [M þ H]þ; HRMS (ESI) m/z calcd for
(16) Inanaga, J.; Hirata, K.; Saeki, H.; Katsuki, T.; Yamaguchi, M. Bull.
Chem. Soc. Jpn. 1979, 52, 1989–1993.
C
26H45O8 [M þ H]þ 485.3114, found 485.3097. The spectral
J. Org. Chem. Vol. 76, No. 3, 2011 965
