Enantio- and diastereoselective cyclopropanation with tert-butyl α-diazopropionate catalyzed by dirhodium(II) tetrakis[N- tetrabromophthaloyl-(S)-tert-leucinate]

Article abstract of DOI:10.1016/j.tetlet.2011.06.008

The first successful example of a catalytic asymmetric cyclopropanation with α-diazopropionates is described. The cyclopropanation reaction of 1-aryl-substituted and related conjugated alkenes with tert-butyl α-diazopropionate has been achieved by catalysis with dirhodium(II) tetrakis[N-tetrabromophthaloyl-(S)-tert-leucinate], Rh₂(S-TBPTTL) ₄, providing the corresponding cyclopropane products containing a quarternary stereogenic center in good to high yields and with high diastereo- and enantioselectivities (trans:cis = 90:10 to >99:1, 81-93% ee).

Full text of DOI:10.1016/j.tetlet.2011.06.008

Tetrahedron Letters 52 (2011) 4200–4203
Contents lists available at ScienceDirect
Tetrahedron Letters
journal homepage: www.elsevier.com/locate/tetlet
Enantio- and diastereoselective cyclopropanation
with tert-butyl
a-diazopropionate catalyzed by dirhodium(II)
tetrakis[N-tetrabromophthaloyl-(S)-tert-leucinate]
Takayuki Goto a,b, Koji Takeda a, Masahiro Anada a, Kaori Ando c, Shunichi Hashimoto a,
⇑
a Faculty of Pharmaceutical Sciences, Hokkaido University, Sapporo 060 0812, Japan
b Development Research Laboratories, Kyorin Pharmaceutical Co., Ltd, 1848, Nogi, Nogi-machi, Shimotsuga-gun, Tochigi 329 0114, Japan
c Department of Chemistry, Faculty of Engineering, Gifu University, Yanagido 1-1, Gifu 501 1193, Japan
a r t i c l e i n f o
a b s t r a c t
Article history:
The first successful example of a catalytic asymmetric cyclopropanation with
described. The cyclopropanation reaction of 1-aryl-substituted and related conjugated alkenes with tert-
butyl -diazopropionate has been achieved by catalysis with dirhodium(II) tetrakis[N-tetrabromophtha-
loyl-(S)-tert-leucinate], Rh2(S-TBPTTL)4, providing the corresponding cyclopropane products containing a
quarternary stereogenic center in good to high yields and with high diastereo- and enantioselectivities
(trans:cis = 90:10 to >99:1, 81–93% ee).
a-diazopropionates is
Received 16 May 2011
Revised 1 June 2011
Accepted 3 June 2011
Available online 12 June 2011
a
Keywords:
Ó 2011 Elsevier Ltd. All rights reserved.
Asymmetric catalysis
Cyclopropanation
Dirhodium(II) complex
a-Alkyl-
a-diazoester
Carbene
Substituted cyclopropanes are commonly encountered struc-
tural subunits in a wide variety of biologically important natural
products and medicinal agents.1 Since the pioneering work of
Nozaki and Noyori in 1966,2 the transition metal-catalyzed asym-
metric cyclopropanation of alkenes with diazo compounds has
emerged as one of the most direct and efficient routes to optically ac-
tive cyclopropane building blocks.3 Over the past two decades, a
number of powerful catalytic systems based on Cu(I),4 Co(II),5
Rh(II),6 Ru(II),7 and Ir(III)8 complexes of well-designed chiral ligands
have been developed to achieve high enantio- and diastereoselectiv-
ity for cyclopropanation reactions with various types of diazo
compounds.9–20 While the majority of successful asymmetric cyclo-
propanations reported involved the use of acceptor-substituted dia-
zo compounds,4–8,10 most commonly diazoacetates,4–8 substantial
progress in this field has recently been achieved by expanding the
reaction scope to include donor/acceptor-substituted diazo com-
pounds11–14 such as vinyldiazoacetates11 and aryldiazoacetates,12
as well as acceptor/acceptor-substituted carbene precursors15–22
such as nitrodiazoacetates,15 nitrodiazoketones,16 amidodiazoace-
tates,17 cyanodiazoacetamides,18 diazomalonates19,20 and related
phenyliodinium ylide variants.21 However, asymmetric cyclopropa-
shift26 in metal-carbene intermediates until a recent breakthrough
by Fox et al.27 Fox et al. developed highly enantio-, diastereo-, and
chemoselective cyclopropanations of terminal aromatic alkenes
and benzofuran with a-alkyl-a-diazoesters using dirhodium(II) tet-
rakis[N-phthaloyl-(S)-tert-leucinate], Rh2(S-PTTL)4 (3a),28 as a chiral
catalyst in hexanes at ꢀ78 °C. While this work was a notable land-
mark, the enantioselectivity was highly sensitive to the structure
of the diazoester. Exceptionally high levels of enantioselectivity
Rh2(S-PTTL)4 (3a)
R
CO2Et
(0.5 mol %)
R
CO2Et
Ph
+
hexanes, –78 °C
N2
5 (3 equiv)
5a R = Me
5b R = Et
5c R = nPr
Ph
4a
6
5d R = nBu
5e R = CH2CH2CHMe2
Me CO2Et
Et CO2Et nPr CO2Et nBu CO2Et
CO2Et
Ph
Ph
Ph Ph
Ph
6a
6b
6c
6d
6e
95% (68%)
91:9 dr
95% (76%) 100% (85%) 96% (84%)
92% (89%)
>95:5 dr
99% ee
92:8 dr
79% ee
>95:5 dr
94% ee
>95:5 dr
96% ee
nation with a-alkyl-a
-diazoesters23–25 has remained elusive due to
3% ee
the propensity to form
a,b-unsaturated esters via a 1,2-hydride
Scheme 1. Catalytic asymmetric cyclopropanation of styrene with
a-alkyl-a-
diazoesters catalyzed by Rh2(S-PTTL)4 reported by Fox.27 The isolated yields in
parentheses were obtained when 1.1 equiv of styrene and 1.0 equiv of diazoesters
were used.
⇑
Corresponding author. Tel.: +81 11 706 3236; fax: +81 11 706 4981.
E-mail address: hsmt@pharm.hokudai.ac.jp (S. Hashimoto).
0040-4039/$ - see front matter Ó 2011 Elsevier Ltd. All rights reserved.
doi:10.1016/j.tetlet.2011.06.008

T. Goto et al. / Tetrahedron Letters 52 (2011) 4200–4203
4201
Me
(up to 99% ee) in cyclopropanations of styrene were achieved with
diazoesters bearing larger -alkyl groups than the -ethyl substitu-
ent as the reaction with ethyl -diazopropionate (5a) and ethyl
Me CO2R
Ph
OH
LiAlH4
R
a
a
THF, 0 °C
98%
S
Ph
a
a-
8
6f R = CHiPr2
diazobutanoate (5b) gave the corresponding cyclopropane products
in 3% and 79% ee, respectively (Scheme 1).27 Very recently, we re-
ported the first example of catalytic asymmetric cyclopropenation
6g R = tBu
Scheme 2. Determination of the absolute stereochemistry of 6f and 6g.
of 1-alkynes with
a-alkyl-a
-diazoesters.29 In this process, Rh2(S-
TBPTTL)4 (3d), a brominated analog of Rh2(S-PTTL)4 (3a), emerged
as the catalyst of choice for achieving exceptionally high levels of
asymmetric induction (up to 99% ee) as well as good to high selectiv-
ities over alkene formation via a 1,2-hydride shift. As part of our
interest in further extension of the scope and utility of 3d, we now
Daicel Chiralpak IC column. The preferred absolute stereochemis-
try of 6f [½a 2D1
ꢀ104.2 (c 1.01, CHCl3) for 84% ee] was established
ꢁ
as 1R,2S by its transformation [LiAlH4, THF, 0 °C, 3 h] to the known
trans-1-phenyl-2-methylcyclopropane-1-methanol [½a D22
ꢀ15.4 (c
ꢁ
0.64, CHCl3); lit.,29
½
a 2D1
ꢁ
ꢀ17.2 (c 0.17, CHCl3) for 95% ee of
address the issue of enantiocontrol in cyclopropanations with a-dia-
zopropionates,25 a virtually unmet challenge in Fox’s cyclopropana-
tion methodology.27
(1R,2S)-enantiomer] (Scheme 2). We next evaluated the perfor-
mance of other dirhodium(II) carboxylates, Rh2(S-PTTL)4 (3a),28
Rh2(S-TFPTTL)4 (3b)30 and Rh2(S-TCPTTL)4 (3c).31,32 While all of
these catalysts provided the trans-cyclopropane 6f in high yields
and with the same sense of asymmetric induction and similar high
diastereoselectivity as those observed with Rh2(S-TBPTTL)4 (3d),
the highest level of enantioselectivity was only 69% ee, which
was obtained using Rh2(S-TCPTTL)4 (3c) (entries 1 vs 2–4). Clearly,
3d proved to be by far the best choice for this transformation as
well as for the asymmetric cyclopropenation reaction. An examina-
tion of the temperature profile demonstrated that lowering the
reaction temperature from ꢀ60 to ꢀ78 °C resulted in perfect
trans-diastereoselectivity, though catalysis at ꢀ78 °C required a
significantly longer reaction time to reach completion and resulted
in 86% ee (entry 5). Not unexpectedly, increasing the reaction tem-
perature to ꢀ40 or ꢀ20 °C was accompanied by a significant
decrease in enantioselectivity while maintaining high diastereose-
lectivity (75% and 66% ee, entries 6 and 7). Using Rh2(S-TBPTTL)4 as
a catalyst, the effect of the ester moiety was also evaluated at
ꢀ60 °C. While the use of ethyl ester 5a resulted in lower enantiose-
lectivity (35% ee, entry 8), the reaction with tert-butyl ester 5g
afforded the trans-cyclopropane product 6g as a single diastereo-
mer in high yield and with somewhat higher enantioselectivity
O
S
O
X
O
N
X
X
N
C12H25
O
H
X
H
O
H
O
O
O
O
N
CO2Me
O
Rh Rh
Rh Rh
Rh Rh
Rh2(4S-MEOX)4 (1)
Rh2(S-DOSP)4 (2)
X = H: Rh2(S-PTTL)4 (3a)
X = F: Rh2(S-TFPTTL)4 (3b)
X = Cl: Rh2(S-TCPTTL)4 (3c)
X = Br: Rh2(S-TBPTTL)4 (3d)
Based on our previous work,29 we initially explored the cyclo-
propanation of styrene (4a) (4 equiv) with 2,4-dimethyl-3-pentyl
a-diazopropionate (5f) using 1 mol % of Rh2(S-TBPTTL)4 (3d) in
dichloromethane at ꢀ60 °C. The reaction proceeded to completion
within 7 h, giving the trans-cyclopropane product 6f in 92% yield
and 97:3 dr with no signs of the formation of alkene 7f (Table 1,
entry 1). As with the Rh2(S-TBPTTL)4-catalyzed cyclopropenation
system,29 no slow addition of 5f was required. The trans-stereo-
chemistry of 6f was established by 1H NOE between the C1 methyl
group and ortho protons on the benzene ring. The enantioselectiv-
ity of this reaction was determined to be 84% ee by HPLC using a
Table 1
Enantio- and diastereoselective cyclopropanation of styrene with
a
-diazopropionates catalyzed by dirhodium(II) carboxylatesa
2.5% NOE
Me CO2CHiPr2
Rh(II) complex
CO2R (1 mol %)
Me CO2R
Ph
H
Me
Ph
+
N2
5
CH2Cl2
4a (4 equiv)
6
6f
i
CO2R
7f
R = CH Pr2
t
7g
R = Bu
not detected
7a R = Et
Entry
a-Diazoesters
Rh(II) catalyst
Temp (°C)
Time (h)
Cyclopropanes
R
Yieldb (%)
trans:cisc
Eed (%)
1
2
3
4
5
6
7
8
5f
5f
5f
5f
5f
5f
5f
5a
5g
5g
5g
CHiPr2
Rh2(S-TBPTTL)4 (3d)
Rh2(S-PTTL)4 (3a)
ꢀ60
ꢀ60
ꢀ60
ꢀ60
ꢀ78
ꢀ40
ꢀ20
ꢀ60
ꢀ60
ꢀ78
ꢀ78
7
4
3
3
48
2
0.5
2
2
6
8
6f
6f
6f
6f
6f
6f
6f
6a
6g
6g
6g
92
89
86
89
86
92
90
80
94
92
87
97:3
94:6
92:8
95:5
>99:1
96:4
94:6
91:9
>99:1
>99:1
>99:1
84
47
33
69
86
75
66
35
88
90
92
CHiPr2
CHiPr2
CHiPr2
CHiPr2
CHiPr2
CHiPr2
Et
Rh2(S-TFPTTL)4 (3b)
Rh2(S-TCPTTL)4 (3c)
Rh2(S-TBPTTL)4 (3d)
Rh2(S-TBPTTL)4 (3d)
Rh2(S-TBPTTL)4 (3d)
Rh2(S-TBPTTL)4 (3d)
Rh2(S-TBPTTL)4 (3d)
Rh2(S-TBPTTL)4 (3d)
Rh2(S-TBPTTL)4 (3d)
9
tBu
10
tBu
11e
tBu
a
b
c
All reactions were carried out as follows: Rh(II) catalyst (1 mol %) was added to a solution of 4a (0.8 mmol, 4 equiv) and 5 (0.2 mmol) in CH2Cl2 (0.1 M).
Isolated yield.
Determined by 1H NMR spectroscopy of the crude reaction mixture.
Determined by HPLC analysis. See Supplementary data for details.
2 equiv of 4a was used.
d
e

4202
T. Goto et al. / Tetrahedron Letters 52 (2011) 4200–4203
Table 2
a
Enantio- and diastereoselective cyclopropanation of alkenes with tert-butyl
a-diazopropionate (5g) catalyzed by Rh2(S-TBPTTL)4
Rh2(S-TBPTTL)4
(3d) (1 mol %)
t
t
Me CO2 Bu
R1
R1
Me
CO2 Bu
+
N2
5g
CH2
Cl2, –78 °C
R2
R2
4 (2 equiv)
6
Entry
Alkenes
Time (h)
Cyclopropanes
trans:cisc
R1
R2
Yieldb (%)
eed (%)
1
2
3
4
5
6
7
8
4a
4b
4c
4d
4e
4f
4g
4h
4i
C6H5
4-CH3OC6H4
4-FC6H4
4-ClC6H4
4-CF3C6H4
1-Naphthyl
2-Naphthyl
(E)-C6H5CH@CH
nC4H9
H
H
H
H
H
H
H
H
8
9
10
10
9
12
12
12
24
12
9
6g
6h
6i
6j
6k
6l
6m
6n
6o
6p
6q
87
90
86
89
81
61
95
87
59
73
84
>99:1
>99:1
>99:1
>99:1
>99:1
98:2
>99:1
90:10
95:5
92
90
90
91
93
88
81
92
77
70
57
9e
10
11
H
CH3
C6H5
4j
4k
C6H5
C6H5
91:9
–
a
b
c
All reactions were carried out with 2 equiv of 4 on a 0.2 mmol scale unless otherwise stated.
Isolated yield.
Determined by 1H NMR spectroscopy of the crude reaction mixture.
Determined by HPLC analysis. See Supplementary data for details.
5 equiv of 4i was used.
d
e
than that observed with 2,4-dimethyl-3-pentyl ester 5f (88% ee,
entry 9). In a similar way to 6f, the absolute stereochemistry of
6g was determined to be 1R,2S (Scheme 2). When the reaction with
5g was conducted at ꢀ78 °C, the enantioselectivity was further en-
hanced to 90% ee without compromising the product yield or
greatly affecting the reaction rate (entry 10). In addition, virtually
the same result was obtained using only 2 equiv of styrene, in
which a slight increase in enantioselectivity was noted (92% ee, en-
try 11).
a 1,2-hydride shift or dimer products such as carbene dimer and
azine were observed. This protocol represents the first successful
example of a catalytic asymmetric cyclopropanation of alkenes
with
propanation methodology.27 Further extension of this method to
-diazobutanoates as well as stereochemical studies are currently
a-diazopropionates and partially complements the Fox cyclo-
a
underway.
Acknowledgments
Having determined the effectiveness of the combinational use
of Rh2(S-TBPTTL)4 as a catalyst and 5g as a carbene precursor, we
then explored the scope of the reaction with respect to the alkene
component (Table 2). Aside from essentially complete trans-diaste-
reoselectivity, high enantioselectivity was consistently observed
with styrenes bearing electron-donating or electron-withdrawing
substituents at the para position on the benzene ring (90–93% ee,
entries 2–5). The reaction with 1-vinylnaphthalene (4f) provided
exclusively the trans-cyclopropane product 6l with 88% ee, albeit
in moderate yield (61% yield, entry 6), while the use of 2-vinyl-
naphthalene (4g) gave 6m in excellent yield with a modest de-
crease in enantioselectivity (95% yield, 81% ee, entry 7). The
regioselective cyclopropanation of (E)-1-phenyl-1,3-butadiene
(4h) also proceeded cleanly and afforded predominantly the sty-
ryl-substituted trans-cyclopropane 6n in high yield with 92% ee
(entry 8). As might be expected from Davies’ studies on cycloprop-
anation chemoselectivity,33 the terminal aliphatic alkene 1-hexene
(4i) was found to be much less reactive, as the reaction with
5 equiv of 4i required a significantly longer reaction time (24 h)
to reach completion, with 6o being obtained in only 59% yield with
77% ee (entry 9). 1,1-Disubstituted alkenes 4j and 4k could be
cyclopropanated in good to high yields but with only modest
enantioselectivity (70% and 57% ee, entries 10 and 11).
This research was supported, in part, by a Grant-in Aid for Sci-
entific Research on Innovative Areas (Project No. 2105: Organic
Synthesis Based on Reaction Integration) from the Ministry of Edu-
cation, Culture, Sports, Science and Technology, Japan. We thank
Ms. S. Oka, and M. Kiuchi of the Center for Instrumental Analysis
at Hokkaido University for technical assistance in the MS and ele-
mental analyses.
Supplementary data
Supplementary data (detailed experimental procedures and full
spectroscopic characterization data for all new compounds) associ-
ated with this article can be found, in the online version, at
doi:10.1016/j.tetlet.2011.06.008.
References and notes
1. (a) Salaün, J. Chem. Rev. 1989, 89, 1247–1270; (b) Donaldson, W. A. Tetrahedron
2001, 57, 8589–8627; (c) Faust, R. Angew. Chem., Int. Ed. 2001, 40, 2251–2253;
(d) Pietruszka, J. Chem. Rev. 2003, 103, 1051–1070; (e) Wessjohann, L. A.;
Brandt, W.; Thiemann, T. Chem. Rev. 2003, 103, 1625–1647; (f) Brackmann, F.;
de Meijere, A. Chem. Rev. 2007, 107, 4493–4537.
2. Nozaki, H.; Moriuti, S.; Takaya, H.; Noyori, R. Tetrahedron Lett. 1966, 5239–
5244.
In summary, we have demonstrated that Rh2(S-TBPTTL)4 is an
exceptionally effective catalyst for asymmetric cyclopropanation
reactions of 1-aryl-substituted and related conjugated alkenes
3. For recent reviews on asymmetric cyclopropanation of alkenes, see: (a) Doyle,
M. P.; Forbes, D. C. Chem. Rev. 1998, 98, 911–936; (b) Davies, H. M. L.;
Antoulinakis, E. G. Org. React. 2001, 57, 1–326; (c) Lebel, H.; Marcoux, J.-F.;
Molinaro, C.; Charette, A. B. Chem. Rev. 2003, 103, 977–1050; (d) Nishiyama, H.
In Rhutenium in Organic Synthesis; Murahashi, S.-I., Ed.; Wiley-VCH: Weinheim,
2004; pp 179–187. Chapter 7; (e) Davies, H. M. L.; Walji, A. M. In Modern
Rhodium-Catalyzed Organic Reactions; Evans, P. A., Ed.; Wiley-VCH: Weinheim,
2005; pp 301–340. Chapter 14; (f) Doyle, M. P. In Modern Rhodium-Catalyzed
Organic Reactions; Evans, P. A., Ed.; Wiley-VCH: Weinheim, 2005; pp 341–355.
Chapter 15; (g) Zhang, Z.; Wang, J. Tetrahedron 2008, 64, 6577–6605; (h)
with tert-butyl a-diazopropionate, in which high levels of enanti-
oselectivity (up to 93% ee) as well as virtually complete trans-dia-
stereoselectivity have been achieved. The reaction could be carried
out in a one-pot fashion and would not require the slow addition of
the diazo reagent, in which no signs of alkene product derived from

T. Goto et al. / Tetrahedron Letters 52 (2011) 4200–4203
4203
Pellissier, H. Tetrahedron 2008, 64, 7041–7095; (i) Honma, M.; Takeda, H.;
Takano, M.; Nakada, M. Synlett 2009, 1695–1712; (j) Doyle, M. P. Angew. Chem.,
Int. Ed 2009, 48, 850–852.
17. (a) Marcoux, D.; Charette, A. B. Angew. Chem., Int. Ed. 2008, 47, 10155–10158;
(b) Marcoux, D.; Goudreau, S. R.; Charette, A. B. J. Org. Chem. 2009, 74, 8939–
8955; (c) Marcoux, D.; Lindsay, V. N. G.; Charette, A. B. Chem. Commun. 2010,
46, 910–912.
18. (a) Marcoux, D.; Azzi, S.; Charette, A. B. J. Am. Chem. Soc. 2009, 131, 6970–6972;
(b) Zhu, S.; Xu, X.; Perman, J. A.; Zhang, X. P. J. Am. Chem. Soc. 2010, 132, 12796–
12799.
4. (a) Fritschi, H.; Leutenegger, U.; Pfaltz, A. Helv. Chim. Acta 1988, 71, 1553–1565;
(b) Lowenthal, R. E.; Abiko, A.; Masamune, S. Tetrahedron Lett. 1990, 31, 6005–
6008; (c) Evans, D. A.; Woerpel, K. A.; Hinman, M. M.; Faul, M. M. J. Am. Chem.
Soc. 1991, 113, 726–728; (d) Leutenegger, U.; Umbricht, G.; Fahrni, C.; von Matt,
P.; Pfaltz, A. Tetrahedron 1992, 48, 2143–2156; (e) Ito, K.; Katsuki, T. Synlett
1993, 638–640; (f) Lo, M. M.-C.; Fu, G. C. J. Am. Chem. Soc. 1998, 120, 10270–
10271.
5. (a) Nakamura, A.; Konishi, A.; Tatsuno, Y.; Otsuka, S. J. Am. Chem. Soc. 1978, 100,
3443–3448; (b) Nakamura, A.; Konishi, A.; Tsujitani, R.; Kudo, M.; Otsuka, S. J.
Am. Chem. Soc. 1978, 100, 3449–3461; (c) Niimi, T.; Uchida, T.; Irie, R.; Katsuki,
T. Adv. Synth. Catal. 2001, 343, 79–88; (d) Ikeno, T.; Sato, M.; Sekino, H.;
Nishizuka, A.; Yamada, T. Bull. Chem. Soc. Jpn. 2001, 74, 2139–2150; (e) Ikeno,
T.; Iwakura, I.; Yamada, T. J. Am. Chem. Soc. 2002, 124, 15152–15153; (f) Chen,
Y.; Ruppel, J. V.; Zhang, X. P. J. Am. Chem. Soc. 2007, 129, 12074–12075; (g)
Chen, Y.; Zhang, X. P. J. Org. Chem. 2007, 72, 5931–5934; (h) Shitama, H.;
Katsuki, T. Chem. Eur. J. 2007, 13, 4849–4858.
6. (a) Doyle, M. P.; Brandes, B. D.; Kazala, A. P.; Pieters, R. J.; Jarstfer, M. B.;
Watkins, L. M.; Eagle, C. T. Tetrahedron Lett. 1990, 31, 6613–6616; (b) Doyle, M.
P.; Winchester, W. R.; Hoorn, J. A. A.; Lynch, V.; Simonsen, S. H.; Ghosh, R. J. Am.
Chem. Soc. 1993, 115, 9968–9978; (c) Doyle, M. P.; Austin, R. E.; Bailey, A. S.;
Dwyer, M. P.; Dyatkin, A. B.; Kalinin, A. V.; Kwan, M. M. Y.; Liras, S.; Oalmann, C.
J.; Pieters, R. J.; Protopopova, M. N.; Raab, C. E.; Roos, G. H. P.; Zhou, Q.-L.;
Martin, S. F. J. Am. Chem. Soc. 1995, 117, 5763–5775; (d) Kitagaki, S.; Matsuda,
H.; Watanabe, N.; Hashimoto, S. Synlett 1997, 1171–1174; (e) Lou, Y.;
Horikawa, M.; Kloster, R. A.; Hawryluk, N. A.; Corey, E. J. J. Am. Chem. Soc.
2004, 126, 8916–8918.
19. (a) Doyle, M. P.; Davies, S. B.; Hu, W. Org. Lett. 2000, 2, 1145–1147; (b) Doyle,
M. P.; Hu, W. ARKIVOC 2003, vii, 15–22.
20. Very recently, Nishimura and Hayashi achieved asymmetric cyclopropanation
of alkenes with dimethyl diazomalonate, which had remained a formidable
challenge, by develping a new chiral diene-Rh(I) complex, where the observed
enantioselectivity (up to 90% ee) was the highest reported to date: Nishimura,
T.; Maeda, Y.; Hayashi, T. Angew. Chem., Int. Ed 2010, 49, 7324–7327.
21. (a) Müller, P.; Allenbach, Y.; Robert, E. Tetrahedron: Asymmetry 2003, 14, 779–
785; (b) Wurz, R. P.; Charette, A. B. Org. Lett. 2003, 5, 2327–2329; (c) Müller, P.
Acc. Chem. Res. 2004, 37, 243–251.
22. For examples of asymmetric intramolecular cyclopropanations of acceptor/
acceptor-substituted carbene precursors, see: (a) Koskinen, A. M. P.; Hassila, H.
J. Org. Chem. 1993, 58, 4479–4480; (b) Honma, M.; Sawada, T.; Fujisawa, Y.;
Utsugi, M.; Watanabe, H.; Umino, A.; Matsumura, T.; Hagihara, T.; Takano, M.;
Nakada, M. J. Am. Chem. Soc. 2003, 125, 2860–2861; (c) Lin, W.; Charette, A. B.
Adv. Synth. Catal. 2005, 347, 1547–1552; (d) Takeda, H.; Honma, M.; Ida, R.;
Sawada, T.; Nakada, M. Synlett 2007, 579–582.
23. For examples of intramolecular cyclopropanation of a-alkyl-a-diazoesters, see:
(a) Dauben, W. G.; Hendricks, R. T.; Luzzio, M. J.; Ng, H. P. Tetrahedron Lett.
1990, 31, 6969–6972; (b) Nicolaou, K. C.; Postema, M. H. D.; Miller, N. D.; Yang,
G. Angew. Chem. Int. Ed. 1997, 36, 2821–2823; (c) Dudones, J. D.; Sampson, P.
Tetrahedron 2000, 56, 9555–9567; For an example of intermolecular
7. (a) Nishiyama, H.; Itoh, Y.; Matsumoto, H.; Park, S.-B.; Itoh, K. J. Am. Chem. Soc.
1994, 116, 2223–2224; (b) Nishiyama, H.; Itoh, Y.; Sugawara, Y.; Matsumoto,
H.; Aoki, K.; Itoh, K. Bull. Chem. Soc. Jpn. 1995, 68, 1247–1262; (c) Miller, J. A.;
Jin, W.; Nguyen, S. T. Angew. Chem., Int. Ed. 2002, 41, 2953–2956; (d) Ito, J.;
Ujiie, S.; Nishiyama, H. Chem. Eur. J. 2010, 16, 4986–4990; (e) Abu-Elfotoh, A.-
M.; Phomkeona, K.; Shibatomi, K.; Iwasa, S. Angew. Chem., Int. Ed. 2010, 49,
8439–8443.
cyclopropanations of alkenes with a-alkyl-a-diazoesters catalyzed by
dirhodium(II) tetrakis(triphenylacetate), see: (d) Panne, P.; DeAngelis, A.;
Fox, J. M. Org. Lett 2008, 10, 2987–2989.
24. Doyle and Zhou reported the first example of asymmetric intramolecular
cyclopropanation of allylic
a-diazopropionates (up to 85% ee) using Rh2(4S-
MEOX)4 (1) as a chiral catalyst Doyle, M. P.; Zhou, Q.-L. Tetrahedron: Asymmetry
1995, 6, 2157–2160.
8. (a) Kanchiku, S.; Suematsu, H.; Matsumoto, K.; Uchida, T.; Katsuki, T. Angew.
Chem., Int. Ed. 2007, 46, 3889–3891; (b) Suematsu, H.; Kanchiku, S.; Uchida, T.;
Katsuki, T. J. Am. Chem. Soc. 2008, 130, 10327–10337.
25. Davies and co-workers reported the first example of asymmetric
cyclopropanation reaction of styrene with methyl
Rh2(S-DOSP)4 (2), where methyl trans-
a
-diazopropionate using
and cis-1-methyl-2-
9. For a classification of diazo reagents, see: Davies, H. M. L.; Beckwith, R. E. J.
Chem. Rev 2003, 103, 2861–2903.
phenylcyclopropanecarboxylates were obtained in a ratio of 80:20 and with
12% and 58% ee, respectively.12b
10. (a) Ye, T.; Zhou, C. New J. Chem. 2005, 29, 1159–1163; (b) Zhu, S.; Ruppel, J. V.;
Lu, H.; Wojtas, L.; Zhang, X. P. J. Am. Chem. Soc. 2008, 130, 5042–5043.
11. (a) Davies, H. M. L.; Hutcheson, D. K. Tetrahedron Lett. 1993, 34, 7243–7246; (b)
Davies, H. M. L.; Bruzinski, P. R.; Lake, D. H.; Kong, N.; Fall, M. J. J. Am. Chem. Soc.
1996, 118, 6897–6907; (c) Müller, P.; Bernardinelli, G.; Allenbach, Y. F.; Ferri,
M.; Grass, S. Synlett 2005, 1397–1400; (d) Bykowski, D.; Wu, K.-H.; Doyle, M. P.
J. Am. Chem. Soc. 2006, 128, 16038–16039; (e) Ichinose, M.; Suematsu, H.;
Katsuki, T. Angew. Chem., Int. Ed. 2009, 48, 3121–3123.
12. (a) Doyle, M. P.; Zhou, Q.-L.; Charnsangavej, C.; Longoria, M. A.; McKervey, M.
A.; García, C. F. Tetrahedron Lett. 1996, 37, 4129–4132; (b) Davies, H. M. L.;
Bruzinski, P. R.; Fall, M. J. Tetrahedron Lett. 1996, 37, 4133–4136; (c) Davies, H.
M. L.; Nagashima, T.; Klino, J. L., III Org. Lett. 2000, 2, 823–826; (d) Davies, H. M.
L.; Townsend, R. J. J. Org. Chem. 2001, 66, 6595–6603; (e) Davies, H. M. L.;
Venkataramani, C. Org. Lett. 2003, 5, 1403–1406; (f) Nowlan, D. T., III; Gregg, T.
M.; Davies, H. M. L.; Singleton, D. A. J. Am. Chem. Soc. 2003, 125, 15902–15911;
(g) Hedley, S. J.; Ventura, D. L.; Dominiak, P. M.; Nygren, C. L.; Davies, H. M. L. J.
Org. Chem. 2006, 71, 5349–5356; (h) Ventura, D. L.; Li, Z.; Coleman, M. G.;
Davies, H. M. L. Tetrahedron 2009, 65, 3052–3061; (i) Bonge, H. T.; Kaboli, M.;
Hansen, T. Tetrahedron Lett. 2010, 51, 5375–5377.
26. (a) Ikota, N.; Takamura, N.; Young, S. D.; Ganem, B. Tetrahedron Lett. 1981, 22,
4163–4166; (b) Taber, D. F.; Hennessy, M. J.; Louey, J. P. J. Org. Chem. 1992, 57,
436–441; (c) Taber, D. F.; Herr, R. J.; Pack, S. K.; Geremia, J. M. J. Org. Chem.
1996, 61, 2908–2910; (d) Müller, P.; Tohill, S. Tetrahedron 2000, 56, 1725–
1731; (e) Taber, D. F.; Joshi, P. V. J. Org. Chem. 2004, 69, 4276–4278.
27. DeAngelis, A.; Dmitrenko, O.; Yap, G. P. A.; Fox, J. M. J. Am. Chem. Soc 2009, 131,
7230–7231. In this work, they also demonstrated that the cyclopropanation
reaction proceeds through the all-up chiral crown conformation of Rh2(S-
PTTL)4 established by single-crystal X-ray analysis, which is consistent with
DFT calculations.
28. (a) Watanabe, N.; Ogawa, T.; Ohtake, Y.; Ikegami, S.; Hashimoto, S. Synlett 1996,
85–86; (b) Saito, H.; Oishi, H.; Kitagaki, S.; Nakamura, S.; Anada, M.;
Hashimoto, S. Org. Lett. 2002, 4, 3887–3890; (c) Minami, K.; Saito, H.;
Tsutsui, H.; Nambu, H.; Anada, M.; Hashimoto, S. Adv. Syn. Catal 2005, 347,
1483–1487; For a practical synthesis of Rh2(S-PTTL)4, see: (d) Tsutsui, H.; Abe,
T.; Nakamura, S.; Anada, M.; Hashimoto, S. Chem. Pharm. Bull. 2005, 53, 1366–
1368; For an immoblization of Rh2(S-PTTL)4, see: (e) Takeda, K.; Oohara, T.;
Anada, M.; Nambu, H.; Hashimoto, S. Angew. Chem. Int. Ed 2010, 49, 6979–
6983.
13. Recently, Davies and co-workers reported highly enantio- and
diastereoselective cyclopropanations (up to 99% ee) of styrenes with
29. Goto, T.; Takeda, K.; Shimada, N.; Nambu, H.; Anada, M.; Ando, K.; Hashimoto,
S. Angew. Chem., Int. Ed., in press. doi:10.1002/anie.201101905.
dimethyl
phenyldiazoacetonitrile and
tetrakis[N-phthaloyl-(S)-1-adamantylglycinate], Rh2(S-PTAD)4, as
a
-diazophosphonate,
1-aryl-2,2,2-trifluorodiazoetanes,
-diazoketones using dirhodium(II)
chiral
a
-
30. (a) Tsutsui, H.; Yamaguchi, Y.; Kitagaki, S.; Nakamura, S.; Anada, M.;
Hashimoto, S. Tetrahedron: Asymmetry 2003, 14, 817–821; (b) Anada, M.;
Tanaka, M.; Washio, T.; Yamawaki, M.; Abe, T.; Hashimoto, S. Org. Lett. 2007, 9,
4559–4562; (c) Shimada, N.; Nakamura, S.; Anada, M.; Shiro, M.; Hashimoto, S.
Chem. Lett. 2009, 38, 488–489.
a-aryl-
a
a
catalyst. See: (a) Reddy, R. P.; Lee, G. H.; Davies, H. M. L. Org. Lett. 2006, 8,
3437–3440; (b) Denton, J. R.; Sukumaran, D.; Davies, H. M. L. Org. Lett. 2007, 9,
2625–2628; (c) Denton, J. R.; Cheng, K.; Davies, H. M. L. Chem. Commun 2008,
1238–1240; (d) Denton, J. R.; Davies, H. M. L. Org. Lett 2009, 11, 787–790.
14. For examples of asymmetric cyclopropanation of alkenes with 1-sufonyl-4-
aryl-1,2,3-triazoles, see: (a) Chuprakov, S.; Kwok, S. W.; Zhang, L.; Lercher, L.;
Fokin, V. V. J. Am. Chem. Soc. 2009, 131, 18034–18035; (b) Grimster, N.; Zhang,
L.; Fokin, V. V. J. Am. Chem. Soc. 2010, 132, 2510–2511.
31. (a) Yamawaki, M.; Tsutsui, H.; Kitagaki, S.; Anada, M.; Hashimoto, S.
Tetrahedron Lett. 2002, 43, 9561–9564; (b) Shimada, N.; Anada, M.;
Nakamura, S.; Nambu, H.; Tsutsui, H.; Hashimoto, S. Org. Lett. 2008, 10,
3603–3606; (c) Tanaka, M.; Kurosaki, Y.; Washio, T.; Anada, M.; Hashimoto, S.
Tetrahedron Lett. 2007, 48, 8799–8802; (d) Anada, M.; Tanaka, M.; Shimada, N.;
Nambu, H.; Yamawaki, M.; Hashimoto, S. Tetrahedron 2009, 65, 3069–3077; (e)
Nambu, H.; Hikime, M.; Krishnamurthi, J.; Kamiya, M.; Shimada, N.;
Hashimoto, S. Tetrahedron Lett. 2009, 50, 3675–3678; (f) Shimada, N.; Hanari,
T.; Kurosaki, Y.; Takeda, K.; Anada, M.; Nambu, H.; Shiro, M.; Hashimoto, S. J.
Org. Chem. 2010, 75, 6039–6042; (g) Shimada, N.; Hanari, T.; Kurosaki, Y.;
Anada, M.; Nambu, H.; Hashimoto, S. Tetrahedron Lett. 2010, 51, 6572–6575.
32. (a) Sato, S.; Shibuya, M.; Kanoh, N.; Iwabuchi, Y. Chem. Commun. 2009, 6264–
6266; (b) Sato, S.; Shibuya, M.; Kanoh, N.; Iwabuchi, Y. J. Org. Chem. 2009, 74,
7522–7524.
15. Zhu, S.; Perman, J. A.; Zhang, X. P. Angew. Chem., Int. Ed. 2008, 47, 8460–8463.
16. Charette and co-workers recently reported highly enantioselective
cyclopropanations (up to 98% ee) of styrenes with
a-nitro
diazoacetophenones using Rh2(S-TCPTTL)4 (3c). Based on single-crystal X-ray
analysis and 1H–13C heteronuclear NOESY experiments, they also proposed
that while 3c adopts a chiral crown conformation like Rh2(S-PTTL)4 (3a),27 3c,
which could benefit from halogen-bonding interactions, might be even more
rigid in solution than 3a Lindsay, V. N. G.; Lin, W.; Charette, A. B. J. Am. Chem.
Soc 2009, 131, 16383–16385.
33. Davies, H. M. L.; Panaro, S. A. Tetrahedron 2000, 56, 4871–4880.
