Trimethylyttrium and Trimethyllutetium**
H. Martin Dietrich, Gabriele Raudaschl-Sieber, and
Reiner Anwander*
Permethylated transition-metal complexes, as represented by
neutral M(CH3)x and anionic [M(CH3)y]nꢀ, have attracted
considerable interest not only for displayingthe simplest truly
organometallic derivatives but also for their intrinsic bonding
phenomena.[1,2] While structural and theoretical investiga-
tions have led to enormous progress for thermally labile
homoleptic Group 4, 5, 6, and 7 derivatives, monometallic
Group 3 and lanthanide congeners have remained elusive.[2,3]
For example, the synthesis of rare-earth-metal–alkyl com-
plexes such as LnEt3 (Ln = Sc, Y) was claimed as early as
1938, however, strikingevidence of their existence, be it
spectroscopic data or clarifyingfollow-up chemistry, has
never been reported.[4] Moreover, the ease of b-hydride
elimination in such early transition-metal–alkyl complexes
led to controversial discussions.[5,6] Nevertheless, a consider-
able number of silylalkyl complexes includinghomoleptic,
donor-coordinated, donor-functionalized, and ate-type deriv-
atives have been unambiguously identified.[7–11] In the early
1980s, Schumann et al. reported the synthesis of thermally
stable ate complexes of the type [Li3(donor)3][Ln(CH3)6]
(donor= TMEDA (N,N,N’,N’-tetramethylethylenediamine),
DME (1,2-dimethoxyethane)), which featured an octahedral
coordination geometry, for the entire series of rare-earth
metals.[12] Approximately ten years later, Evans et al. de-
scribed permethylated derivatives [Nd(GaMe4)3] and [Ln-
(AlMe4)3] (Ln = Y, Nd, Sm) which can be viewed as
trimethylgallium and trimethylaluminum adduct complexes,
respectively, of the elusive LnMe3.[13,14] Meanwhile, hetero-
bimetallic derivatives [Ln{(m-Me)2AlMe2}3] are available for
the entire Group 3 and 4f series except for scandium and
promethium.[15,16] Herein, another ten years later, we describe
the synthesis and derivatization of homoleptic trimethyl-
yttrium and trimethyllutetium.
[*] H. M. Dietrich, Dr. R. Anwander
Department of Chemistry
University of Bergen
AllØgaten 41, 5007 Bergen (Norway)
Fax: (+47)5558-9490
E-mail: reiner.anwander@kj.uib.no
G. Raudaschl-Sieber
Anorganisch-chemisches Institut
Technische Universität München
Lichtenbergstraße 4, 85747 Garching (Germany)
[**] Financial support by the Deutsche Forschungsgemeinschaft (SPP
1166) and the Fonds der Chemischen Industrie is gratefully
acknowledged. We thank M. Barth and co-workers for performing
the elemental analyses.
Supporting information for this article is available on the WWW
under http://www.angewandte.org or from the author.
Angew. Chem. Int. Ed. 2005, 44, 5303 –5306
ꢀ 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
5303

Communications
[22]
Donor (Do)-induced cleavage of tetraalkylaluminates
amongthe most volatile of rare-earth metal compounds.
(Do = THF, diethyl ether, pyridine) has been previously
applied to convert heteroleptic lanthanidocene and half-
lanthanidocene complexes, [Cp02Ln(AlR4)] and [Cp’Ln-
(AlR4)2] (Cp’ = substituted cyclopentadienyl), into the corre-
sponding s-bonded alkyl derivatives [Eqs. (1) and (2)].[17–20]
Such optimized reaction conditions were crucial for the
synthesis of pure [LuMe3]n (2b). The precursor [Lu(AlMe4)3]
(1b) was most efficiently separated from the coproduct of the
synthesis, [Me2Al(m-NMe2)], by fractional sublimation (ca.
908C at 10ꢀ3 mbar; > 20% yield).[23] (Caution! Compound 2b
which is also obtained quantitatively as a white powder like
the yttrium derivative 2a detonates spontaneously when
exposed to air; it also decomposes spontaneously at elevated
temperature under high vacuum (ca. 808C at 10ꢀ4 mbar) to
yield a black powder.) In addition to the C,H microanalytical
data, unambiguous evidence for the formation of compounds
2a,b stemmed from the complete reversibility of this donor-
induced cleavage reaction (Scheme 1).[18] That is, treatment of
the precipitated compounds 2 (non-isolated, as formed from
the initial reaction mixture) and likewise the isolated
compounds 2, which were resuspended in hexane, with
3 equivalents of AlMe3 both led to quantitative re-formation
of the homoleptic complexes 1. Visually, thus was
indicated by the immediate formation of a clear
solution.
2 ½Cp02YfAlðCH3Þ4gŠ þ 2 Do ! ½Cp20 Yðm-CH3ފ2 þ 2 AlðCH3Þ3ðDoÞ ð1Þ
3 ½Cp0YfAlðCH3Þ4g2Š þ 6 Do ! ½Cp0Yðm-CH3Þ2Š3 þ 6 AlðCH3Þ3ðDoÞ ð2Þ
We found that homoleptic [Y(AlMe4)3] (1a) and [Lu-
(AlMe4)3] (1b) are also amenable to this donor-induced
tetraalkylaluminate cleavage. Accordingly, addition of a
stoichiometric amount of THF (3 equiv) to a solution of 1a
in hexane at ambient temperature produced a white precip-
itate, which was insoluble in aliphatic and aromatic solvents
(Scheme 1). After several washings with hexane and drying
A uniform coordination environment at the
rare-earth-metal center in compounds 2 was con-
firmed by solid-state FTIR and MAS NMR spec-
troscopy. Nujol mulls of [LnMe3]n gave IR spectra
that displayed a characteristic vibration at n˜ = 1191
and 1202 cmꢀ1 for the yttrium and lutetium deriv-
atives, respectively, and a broad, intense low-
energy band featuring three maxima at n˜ = 522,
1
431, and 361 cmꢀ1 (2a). The H MAS NMR spec-
trum of 2a showed a broad resonance centered at
d = ꢀ0.3 ppm that exhibited two well-resolved
shoulders at around d = 0.1 and 1.0 ppm. The
13C CPMAS NMR spectra of compounds 2 are
shown in Figures 1a and b. For each, one signal was
detected for the methyl carbon atoms at d = 28.3
(2a) and 31.4 ppm (2b). For comparison, the
yttrium precursor complex 1a revealed two signals
at d ꢁ ꢀ10 and 18.0 ppm which can be assigned to
Y-CH3-Al bridging and Al-CH3 terminal methyl
ligands (Figure 1c), whereas the half-yttrocene
[Cp*Y(m-Me)2]3 (Cp* = C5Me5), which is discussed
later, exhibits 13C resonances at d = 11.9, 30.3, and
118.7 ppm that are attributed to carbon atoms of
CH3(Cp*) substituents, Y-CH3-Y bridging methyl
ligands, and the Cp* ring, respectively (Fig-
ure 1d).[19] Similar solid-state NMR chemical
shifts have been previously reported for the com-
Scheme 1. Synthesis and derivatization of [LnMe3]n (2). Detailed reaction conditions are
given in the Supporting Information (Cn=1,4,7-trimethyl-1,4,7-triazacyclononane).
*
plex [Cp2 Th(CH3)2] (Cp*: d = 123.1 and 12.0 ppm;
under high vacuum, the white powder was identified as
polymeric [YMe3]n (2a). Optimized conditions for this
cleavage reaction comprised the use of freshly sublimed 1a
as well as the less Lewis basic donor diethyl ether as a
cleavage reagent, and a low reaction temperature (ꢀ358C).[21]
1H NMR experiments in C6D6 confirmed Al(CH3)3(OEt2) as
the only soluble byproduct of the cleavage reaction (d =
ꢀ0.42 (s, 9H, AlCH3), 0.73 (t, 6H, CH3), 3.25 ppm (q, 4H,
OCH2)). Note that owingto its relatively low sublimation
point (808C at 10ꢀ3 mbar; > 90% yield), compound 1a is
Th-CH3(terminal): d = 68.4 ppm).[24] These findings clearly
indicate the formation of homoleptic complexes 2 (ether
donor ligands can be ruled out by the 13C CPMAS NMR
spectra) and to the absence of any methyl groups bonded to
aluminum centers.[25,26] Carbon resonances of “Al-CH3”
moieties were previously shown to appear upfield,[27] and
this is also corroborated by the spectrum of precursor
compound 1a (Figure 1c).
Preliminary investigations into the reaction behavior of
[LnMe3]n were performed usingthe yttrium derivative 2a
5304
www.angewandte.org
ꢀ 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Angew. Chem. Int. Ed. 2005, 44, 5303 –5306

Angewandte
Chemie
ment of compound 2 with AlMe2Cl and documents the
comparatively higher halophilicity of the rare-earth elements.
Use of AlEt2Cl as a halogenating reagent afforded the mixed
alkylaluminum AlMeEt2 (7) as a coproduct.
In conclusion, we have shown that homoleptic rare-earth-
metal–methyl complexes can be obtained through donor-
induced
tetraalkylaluminate
cleavage
of
[Ln{(m-
Me)2AlMe2}3] (Ln = Y, Lu). Compounds [LnMe3]n are
highly condensed materials. Notably, those derived from the
smaller rare-earth-metal cations are stable at ambient tem-
perature and accessible to a variety of ligand-exchange and
addition reactions. Current investigations of [LnMe3]n com-
pounds are focused on 1) the accessibility of derivatives of the
large rare-earth-metal cations, 2) the feasibility of controlled
alkyl-elimination reactions, and 3) their potentials as cata-
lysts.
Experimental Section
2a: In a glovebox, a solution of diethyl ether (3 equiv; 222 mg,
3.00 mmol) in hexane (5 mL) at ꢀ358C was added under vigorous
Figure 1. 13C cross-polarization magic-angle-spinning (CPMAS) NMR
spectra of a) neat [YMe3]n (2a), b) neat [LuMe3]n (2b), c) neat
[Y(AlMe4)3] (1a), and d) neat [Cp*YMe2]3. Resonances due to C5Me5
stirringto a solution of Y(AlMe )3 (1a; 350 mg, 1.00 mmol) in cold
4
(ꢀ358C) hexane (10 mL). Instant formation of a white precipitate
occurred. After stirringthe reaction mixture for 10 min, the product
was separated by centrifugation and washed three times with hexane
to completely remove any soluble byproducts. After dryingfor 6 h
under high vacuum, [YMe3]n (2a) was obtained as a white powder in
quantitative yield (133 mg). IR (Nujol): n˜ = 1191 (vs), 522 (s), 431 (s),
361 (s), 320 cmꢀ1 (w); far-IR (polyethylene): n˜ = 186 cmꢀ1 (w);
1H MAS NMR (300.13 MHz, 258C): d = 1.0, 0.1, ꢀ0.3 ppm.
13C MAS NMR (75.46 MHz, 258C): d = 28.3 ppm; elemental analysis
(%): calcd for C3H9Y (134.010 gmolꢀ1): C 26.89, H 6.77; found: C
26.88, H 6.51.
Typical procedure for addition reactions, as shown for the
synthesis of 6: In a glovebox, a solution of GaMe3 (3 equiv; 128 mg,
1.12 mmol) in hexane (5 mL) cooled to ꢀ358C was added under
vigorous stirring to a suspension of [YMe3]n (2a, 50 mg, 0.37 mmol) in
hexane (5 mL) also cooled to ꢀ358C. The reaction mixture became
clear after 15 min stirring. After a further 15 min, the reaction mixture
was filtered, and the filtrate was retained. Evaporation of the solvent
in vacuo yielded compound 6 as a white crystalline product (169 mg,
95%). IR (Nujol): n˜ = 1302 (w), 1202 (s), 967 (w), 571 (s), 530 (s),
416 cmꢀ1 (m); 1H NMR (400 MHz, C6D6, 258C): d = ꢀ0.10 ppm;
13C{1H} NMR (100 MHz, C6D6, 258C): d = 4.0 ppm (v br); elemental
analysis (%): calcd for C12H36Ga3Y (478.492 gmolꢀ1): C 30.12, H 7.58;
found: C 31.30, H 7.34, N < 0.2.
(Cp*) are indicated by asterisks ( ).
*
(Scheme 1). Although the isolation of simple ether adduct
complexes, such as [YMe3(thf)x], was not successful, addition
of a stoichiometric amount of 1,4,7-trimethyl-1,4,7-triazacy-
clononane (Cn) to a suspension of [YMe3]n in hexane gave
[CnYMe3] (3) in almost quantitative yield.[28] The solid-state
13C NMR spectrum of complex 3 (not shown) was similar to
its spectrum in solution (C6D6) and gave signals at d = 55.2
(NCH2), 48.7 (NCH3), and 20.9 ppm (YCH3). In the presence
of TMEDA as an N-donor solvent, treatment of [YMe3]n with
3 equivalents of MeLi gave Schumannꢀs ate complex [Li3-
(tmeda)][Y(CH3)6] (4) in moderate yield.[12] Given the
“reversibility” of the formation of [LnMe3]n, we anticipated
that other strongLewis acids might redissolve [LnMe 3]n as
well. Accordingly, AlEt3 and GaMe3 form heterobimetallic/
heteroleptic [YAl3Me3Et9] (5) and heterobimetallic/homolep-
tic [YGa3Me12] (6) in almost quantitative yields
(Scheme 1).[29] Whereas compound 5 was obtained as an oily
residue, tetramethylgallate complex 6 yielded colorless crys-
tals from solutions in hexane. Complex 6 shows a very broad
1H NMR signal in C6D6 which is indicative of a decreased
fluxional behavior of the bridging and terminal methyl ligands
relative to tetramethylaluminate 2a.
Full experimental and physicochemical details for complexes 1–7
are available in the SupportingInformation.
Received: December 31, 2004
Revised: March 1, 2005
Published online: July 22, 2005
Instantaneous evolution of methane was observed when
compound [YMe3]n was treated with Brønsted acidic sub-
strates such as HN(SiMe3)2, HOCHtBu2, and HC5Me5
(HCp*) in hexane. The reactions of 3 equivalents of either
the silylamine or the alcohol with 2a gave the homoleptic
complexes [Y{N(SiMe3)2}3] and [Y(OCHtBu2)3], respectively,
in high yields (see Supporting Information).[30,31] Owingto
ligand scrambling, half-yttrocene complex [Cp*Y(m-Me)2]3
did not form selectively upon addition of 1 equivalent of
HCp* to compound 2a, however, its presence could be
Keywords: aluminum · lanthanides · NMR spectroscopy ·
.
yttrium
[1] P. J. Davidson, M. F. Lappert, R. Pearce, Chem. Rev. 1976, 76,
219.
[2] K. Seppelt, Acc. Chem. Res. 2003, 36, 147, and references
therein.
[3] For a recent review on non-cyclopentadienyl organolanthanide
complexes, see: F. T. Edelmann, D. M. M. Freckmann, H.
Schumann, Chem. Rev. 2002, 102, 1851.
1
identified by means of H NMR spectroscopy.[19] A Me!Cl
transformation with formation of YCl3 occurred upon treat-
Angew. Chem. Int. Ed. 2005, 44, 5303 –5306
ꢀ 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
www.angewandte.org
5305

Communications
[4] For a survey of the historical development of homoleptic s-
[21] Nonstoichiometric reactions inevitably give Al-contaminated
products as confirmed by atomic absorption spectroscopy. For
example, an Al contamination of 0.6 wt%, which was observed
for one of the donor-induced cleavage reactions of 1a
(23.11 wt% Al) would correspond to a Y/Al ratio of 33:1.
[22] R. Anwander, F. C. Munck, W. Scherer, T. Priermeier, O. Runte,
W. A. Herrmann, Inorg. Chem. 1997, 36, 3545.
bonded organolanthanide compounds, see: a) H. Schumann, J.
Organomet. Chem. 1985, 281, 95; b) H. Schumann, J. Less-
Common Met. 1985, 112, 327.
[5] For donor-solvated neopentyl complexes, see: a) M. F. Lappert,
R. Pearce, J. Chem. Soc. Chem. Commun. 1973, 126; b) M.
Niemeyer, Z. Anorg. Allg. Chem. 2000, 626, 1027.
[6] For homoleptic anionic tert-butyl ate complexes, see: a) A. L.
Wayda, W. J. Evans, J. Am. Chem. Soc. 1978, 100, 7119; b) H.
Schumann, W. Genthe, E. Hahn, J. Pickardt, H. Schwarz, K.
Eckart, J. Organomet. Chem. 1986, 306, 215.
[7] For a homoleptic donor-functionalized dimethylaminopropyl ate
complex, see: T. Herbrich, K.-H. Thiele, U. Thewalt, Z. Anorg.
Allg. Chem. 1996, 622, 1609.
[8] a) P. B. Hitchcock, M. F. Lappert, R. G. Smith, R. A. Bartlett,
P. P. Power, J. Chem. Soc. Chem. Commun. 1988, 126; b) C.
Eaborn, P. B. Hitchcock, K. Izod, J. D. Smith, J. Am. Chem. Soc.
1994, 116, 12071; c) J. R. van den Hende, P. B. Hitchcock, S. A.
Holmes, M. F. Lappert, S. Tian, J. Chem. Soc. Dalton Trans. 1995,
3933; d) C. Eaborn, P. B. Hitchcock, K. Izod, Z.-R. Lu, J. D.
Smith, Organometallics 1996, 15, 4783; e) M. Westerhausen, M.
Hartmann, W. Schwartz, Inorg. Chim. Acta 1998, 269, 91.
[9] a) J. L. Atwood, W. E. Hunter, R. D. Rogers, J. Holton, J.
McMeeking, R. Pearce, M. F. Lappert, J. Chem. Soc. Chem.
Commun. 1978, 140; b) H. Schumann, J. Müller, J. Organomet.
Chem. 1978, 146, C5 – C7; c) W. J. Evans, J. C. Brady, J. W. Ziller,
J. Am. Chem. Soc. 2001, 123, 7711; d) H. Schumann, D. M. M.
Freckmann, S. Dechert, Z. Anorg. Allg. Chem. 2002, 628, 2422.
[10] W. Clegg, C. Eaborn, K. Izod, P. OꢀShaughnessy, J. D. Smith,
Angew. Chem. 1997, 109, 2925; Angew. Chem. Int. Ed. Engl.
1997, 36, 2815.
[23] [Lu(AlMe4)3] (1b) is isostructrual to [Nd(AlMe4)3][14a]: H. M.
Dietrich, E. Herdtweck, R. Anwander, unpublished results.
[24] P. J. Toscano, T. J. Marks, J. Am. Chem. Soc. 1985, 107, 653.
[25] Preliminary X-ray diffraction studies revealed [LnMe3]n to be
amorphous powders.
[26] I. Nagl, M. Widenmeyer, E. Herdtweck, G. Raudaschl-Sieber, R.
Anwander, Microporous Mesoporous Mater. 2001, 44–45, 311.
[27] R. Anwander, C. Palm, O. Groeger, G. Engelhardt, Organo-
metallics 1998, 17, 2027.
[28] S. Hajela, W. P. Schaefer, J. E. Bercaw, J. Organomet. Chem.
1997, 532, 45.
[29] Mg(nBu)2 also redissolves [YMe3]n to form a heterobimetallic/
heteroleptic YMgcomplex which was obtained as a colorless oil.
For comparison, ZnEt2 afforded no addition product.
[30] D. C. Bradley, J. S. Ghotra, F. A. Hart, J. Chem. Soc. Dalton
Trans. 1973, 1021.
[31] W. A. Herrmann, R. Anwander, W. Scherer, Chem. Ber. 1993,
126, 1533.
[11] W. J. Evans, J. L. Shreeve, R. N. R. Broomhall-Dillard, J. W.
Ziller, J. Organomet. Chem. 1995, 501, 7.
[12] a) H. Schumann, J. Müller, Angew. Chem. 1978, 90, 307; Angew.
Chem. Int. Ed. Engl. 1978, 17, 276; b) H. Schumann, J. Pickardt,
N. Bruncks, Angew. Chem. 1981, 93, 127; Angew. Chem. Int. Ed.
Engl. 1981, 20, 120; c) H. Schumann, J. Müller, N. Bruncks, H.
Lauke, J. Pickardt, H. Schwarz, K. Eckart, Organometallics 1984,
3, 69; d) H. Schumann, H. Lauke, E. Hahn, J. Pickardt, J.
Organomet. Chem. 1984, 263, 29.
[13] W. J. Evans, R. Anwander, R. J. Doedens, J. W. Ziller, Angew.
Chem. 1994, 106, 1725; Angew. Chem. Int. Ed. Engl. 1994, 33,
1641.
[14] a) W. J. Evans, R. Anwander, J. W. Ziller, Organometallics 1995,
14, 1107; b) W. T. Klooster, R. S. Lu, R. Anwander, W. J. Evans,
T. F. Koetzle, R. Bau, Angew. Chem. 1998, 110, 1326; Angew.
Chem. Int. Ed. 1998, 37, 1268.
[15] a) R. Anwander, O. Runte, J. Eppinger, G. Gerstberger, M.
Spiegler, E. Herdtweck, J. Chem. Soc. Dalton Trans. 1998, 847;
b) A. Fischbach, PhD Thesis, Technische Universität München,
2003; c) A. Fischbach, M. G. Klimpel, M. Widenmeyer, E.
Herdtweck, W. Scherer, R. Anwander, Angew. Chem. 2004, 116,
2284; Angew. Chem. Int. Ed. 2004, 43, 2234; d) H. M. Dietrich,
E. Herdtweck, R. Anwander, unpublished results.
[16] For the synthesis and structural characterization of tetraalkyla-
luminate complexes of the divalent rare-earth metals, [Ln-
(AlR4)2] (R = Me, Et, iBu), see: M. G. Klimpel, R. Anwander,
M. Tafipolsky, W. Scherer, Organometallics 2001, 20, 3983.
[17] J. Holton, M. F. Lappert, D. G. H. Ballard, R. Pearce, J. L.
Atwood, W. E. Hunter, J. Chem. Soc. Dalton Trans. 1979, 54.
[18] M. G. Klimpel, J. Eppinger, P. Sirsch, W. Scherer, R. Anwander,
Organometallics 2002, 21, 4021.
[19] [Cp*YMe2]3 can be obtained in high yield through donor-
induced cleavage of [Cp*Y(AlMe4)2] (see SupportingInforma-
tion): H. M. Dietrich, E. Herdtweck, R. Anwander, unpublished
results.
[20] C. J. Schaverien, Organometallics 1994, 13, 69.
5306
www.angewandte.org
ꢀ 2005 Wiley-VCH Verlag GmbH & Co. KGaA, Weinheim
Angew. Chem. Int. Ed. 2005, 44, 5303 –5306
