7.46−7.39 (m, 1H, 0.3H), 7.12−7.03 (m, 2H), 7.02−6.96 (m, 1H),
6.03−5.78 (m, 1H), 5.31−4.83 (m, 3H), 2.72−2.40 (m, 2H), 2.28−
2.01 (m, 1H), 1.99−1.62 (m, 4H), 1.57 (m, 3H), 1.49−1.44 (m, 3H),
1.20 (m, 3H), 0.96 (s, 1H), 0.89 (s, 2H). 13C NMR (75 MHz,
CDCl3): δ 144.2, 143.8, 140.6, 140.1, 139.8, 139.7, 139.6, 139.5, 131.0,
129.0, 128.4, 128.2, 126.7, 126.6, 125.2, 125.2, 125.1, 124.99, 115.51,
115.0, 76.3, 75.6, 49.5 (2C), 36.9, 36.2, 35.1, 34.6, 30.9, 30.9, 25.7,
25.7, 23.6, 23.4, 21.0, 20.8, 17.66, 17.6, 17.0, 16.9. IR (υ/cm−1, neat):
3467, 2928, 1634, 1448, 1375, 1011, 909, 749, 670, 454. HRMS (EI)
M+ for C20H28O calcd, 284.2140; found, 284.2146.
AcOEt) followed by preparative TLC (95:5 cyclohexane/AcOEt) to
separate the two isomers.
2-Ethyl-2,6-dimethyl-1-phenylhept-5-en-1-ol (12).25 Rf: 0.57
(9:1 cyclohexane/AcOEt). 1H NMR (300 MHz, CDCl3) 2
diastereoisomers (1:1): δ 7.34−7.25 (m, 5H), 5.83 (m, 1H), 5.15
(m, 3H), 4.44 (m, 1H), 2.07−1.94 (m, 1H), 1.86 (m, 2H), 1.65 (s,
3H), 1.55 (s, 3H), 1.46−1.19 (m, 2H), 1.08 (s, 1.5H), 0.93 (s, 1.5H).
13C NMR (75 MHz, CDCl3): δ 144.0, 142.8, 141.4, 140.6, 131.4,
131.3, 128.2, 127.9, 127.6, 127.6, 127.5, 127.4, 124.9, 124.8, 115.9,
115.2, 80.9, 80.2, 46.0, 45.4, 37.7, 36.5, 25.8, 22.9, 19.0, 17.7, 16.3. IR
(υ/cm−1, neat): 3469, 2927, 2857, 2838, 1703, 1636, 1449, 1367,
1139, 1001, 909, 845, 586 cm−1. MS (CI, isobutane, m/z 227) [M −
OH]+ for C17H23 calcd, 227; found, 227.
1-(3,7-Dimethylocta-1,6-dien-3-yl)cyclohex-2-en-1-ol (7d).
The reaction of 4 (222 mg, 0.52 mmol, 1 equiv), n-BuLi (0.325 mL,
0.52 mmol), and 2-cyclohexenone (49 μL, 0.52 mmol) in THF (5
mL) gave alcohol 7d after 4 h of reaction (66 mg, 55%) as a colorless
oil after purification (95:5 cyclohexane/AcOEt). Rf: 0.52 (9:1
(3E)-4,8-Dimethyl-1-phenylnona-3,7-dien-1-ol (12′).25 Rf: 0.5
1
(9:1 cyclohexane/AcOEt). H NMR (300 MHz, CDCl3) δ 7.44−7.25
1
cyclohexane/AcOEt) 2 diastereoisomers (1:1): H NMR (300 MHz,
(m, 5H), 5.17 (t, J = 7.4 Hz, 1H), 5.07 (m, 1H), 4.75−4.62 (m, 1H),
2.47 (m, 2H), 2.06 (m, 4H), 1.69 (s, 3H), 1.61 (s, 6H). 13C NMR (75
MHz, CDCl3): δ 143.9, 139.3, 131.5, 128.0 (2C), 127.1, 125.5 (2C),
123.8, 119.3, 73.6, 39.6, 37.9, 26.2, 25.4, 17.4, 15.9. IR (υ/cm−1, neat):
3370, 2965, 2914, 2857, 1874, 1806, 1494, 1450, 1380, 755, 694. MS
(CI, isobutane, m/z 227) [M−OH]+ for C17H23 calcd, 227; found,
227.
CDCl3): δ 5.98−5.84 (m, 2H), 5.80−5.70 (m, 1H), 5.26−5.18 (m,
1H), 5.13−4.98 (m, 2H), 2.06−1.95 (m, 1H), 1.90 (m, 3H), 1.71−
1.62 (m, 7H), 1.59−1.56 (m, 4H), 1.48−1.36 (m, 2H), 1.02 (s, 3H).
13C NMR (75 MHz, CDCl3): δ 143.5, 143.0, 132.0, 131.5, 131.2,
131.1, 129.8, 129.7, 125.3, 125.2, 115.7, 115.1, 73.2, 72.9, 47.0, 47.0,
34.7, 34.4, 31.12, 30.80, 25.8 (2C), 25.3, 25.3, 23.4, 23.3, 19.1, 18.9,
17.7 (2C), 16.4 (2C). IR (υ/cm−1, neat): 3467, 2931, 2873, 1707,
1633, 1438, 1375, 1168, 1078, 1013, 944, 910, 816, 734, 532. HRMS
(EI) M+ for C16H26O calcd, 234.2017; found, 234.2015.
Preparation of Geranyllithium from Geranyloxybenzene.
The glassware employed consisted of a one-neck flask connected to a
second one-neck flask through a glass bridge equipped with a fritted
glass filter. To the first flask were added THF (5 mL) and freshly cut
pieces of Li° (40 mg, 6 mmol, 3 equiv) at rt. A solution of
geranyloxybenzene (462 mg, 2 mmol, 1 equiv) in anhydrous Et2O (2
mL) was added dropwise. When a color change was observed, the
solution was stirred for an additional 10 min at rt. Then, the solution
was transferred into the second flask through the filter using gravity
and a positive pressure of argon, and the mother solution was cooled
at −78 °C. From the mother solution, 3.5 mL was removed with a
syringe and quickly transferred into a flask cooled at −78 °C. PhCHO
(100 μL, 1 mmol) was added, and the resulting mixture was stirred for
1 h at this temperature. The mixture was quenched with MeOH and
water. After extraction with CH2Cl2, the combined organic layers were
brined, dried over MgSO4, filtered, and concentrated under reduced
pressure. Purification gave 12 and 12′ in equal quantities.
2-Methoxy-3,5-dimethyl-6-[(2E,4E)-5-phenylpenta-2,4-dien-
1-yl]-4H-pyran-4-one (11). A 250 mL, single-necked, round-bottom
flask equipped with a magnetic stirring bar was charged with 5 (471
mg, 1.1 mmol, 2 equiv) and 1 (100 mg, 0.55 mmol, 1 equiv) in
anhydrous THF (10 mL). n-BuLi (0.69 mL, 1.1 mmoL, 2 equiv, C =
1.6 M in hexane) was added at −90 °C. The solution became red and
was stirred for 30 min at this temperature before addition of MeOH
(0.11 mL, 2.72 mmol, 5 equiv) at −90 °C. The bath was removed, and
the solution was allowed to reach a temperature of 20 °C. The mixture
was quenched with sat. NH4Cl and extracted with Et2O (3 × 10 mL).
The combined organic layers were brined, dried (MgSO4), filtered,
and concentrated under reduced pressure. The reaction mixture was
purified by flash chromatography (7:3 cyclohexane/AcOEt) to give the
products 11/11′ (49 mg, 31% combined yield with a ratio 2:1).
Complete selectivity toward 11′ (34%) can be obtained by transferring
with cannula the cold reaction mixture (−90 °C) to a solution of
CF3CO2H (3 equiv) in Et2O at −78 °C.
1-(1-Methylcyclopent-2-en-1yl)cyclohexanol (14a). To a
sealed tube containing 7a (30 mg, 0.13 mmol, 1 equiv) in anhydrous
toluene (1 mL) was added Grubbs catalyst second generation
[246047-72-3] (5 mg, 0.06 mmol, 0.05 equiv) at rt. The solution
was stirred at 110 °C until complete conversion of the starting material
(24 h). The mixture was then concentrated under reduced pressure
and purified by flash chromatography (9:1 cyclohexane/AcOEt) to
give alcohol 14a (12 mg, 50% yield) as a colorless oil. Rf: 0.40 (8:2
1
Data for 11: Rf = 0.40 (6:4 cyclohexane/AcOEt). H NMR (300
MHz, CDCl3): δ 7.32−7.19 (m, 5H), 6.86 (dd, J = 15.3, 10.3 Hz, 1H),
6.42 (dAB, J = 15.3 Hz, 1H), 6.32−6.08 (m, 2H), 4.01 (s, 3), 3.52 (d, J
= 6.6 Hz, 2H), 2.02 (s, 3H), 1.86 (s, 3H). 13C NMR (75 MHz,
CDCl3): δ 180.9, 161.7, 152.1, 139.2, 138.7, 133.4, 130.4, 128.7 (2C),
128.6 (2C), 126.4, 119.8, 118.7, 99.6, 55.3, 39.3, 9.5, 6.9. IR (υ/cm−1,
neat): 2955, 2925, 1660, 1574, 1377, 1332, 1257, 1164, 983, 733, 690,
475. HRMS (ESI) m/z for C19H21O3 (M + H)+, 297.1491; calcd,
297.1491. Data for 11′: Rf = 0.3 (6:4 cyclohexane/AcOEt).
1
cyclohexane/AcOEt). H NMR (300 MHz, CDCl3): δ 5.75 (dt, J =
5.7, 2.3 Hz, 1H), 5.62 (dt, J = 5.7, 2.2 Hz, 1H), 2.37−2.28 (m, 2H),
2.18−2.04 (m, 2H), 1.70−1.52 (m, 7H), 1.48−1.39 (m, 3H), 1.25 (s,
1H), 1.05 (s, 3H,). 13C NMR (75 MHz, CDCl3): δ 136.4, 131.3, 75.20,
57.6, 32.6, 32.4, 32.3, 31.7, 26.1, 22.5, 21.9, 21.9. IR (υ/cm−1, neat):
3368, 2926, 2854, 1718, 1449, 1078, 836. HRMS (EI) M+ for C12H20O
calcd, 180.1512; found, 180.1517.
1H NMR (300 MHz, CDCl3): δ 7.34−7.24 (m, 5H), 6.68 (dd, J =
15.6, 10.3 Hz, 1H), 6.45 (d, J = 15.7 Hz, 1H), 6.23 (appdd, J = 15.1,
10.3 Hz, 1H), 5.76 (dt, J = 14.4, 6.6 Hz, 1H), 3.87 (s, 3H), 3.35 (appd,
J = 6.6 Hz, 2H), 1.90 (s, 3H), 1.79 (s, 3H). 13C NMR (75 MHz,
CDCl3): δ 181.2, 162.4, 155.7, 137.1, 133.7, 132.6, 128.8 (2C), 128.1,
127.8, 126.7, 126.5 (2C), 119.1, 99.7, 55.5, 34.4, 10.0, 7.0. IR (υ/cm−1,
neat): 2956, 2925, 1663; 1575, 1464, 1412, 1251, 1165, 983, 732, 694,
476. HRMS (ESI) m/z for C19H21O3 (M + H)+, 297.1492; calcd,
297.1491.
1-Benzyl-4-(1-methylcyclopent-2-en-1-yl)piperidin-4-ol
(14b). To a sealed tube containing 7b (20 mg, 0.06 mmol, 1 equiv) in
anhydrous toluene (0.5 mL) was added Grubbs catalyst second
generation (2.5 mg, 0.003 mmol, 0.05 equiv) at rt. The solution was
stirred at 110 °C until complete conversion of the starting material (48
h). The mixture was then concentrated under reduced pressure and
purified by flash chromatography (9:1:0.1 CH2Cl2/MeOH/NH3 aq) to
give alcohol 14b (9 mg, 44%). Rf: 0.3 (9:1:0.1 CH2Cl2/MeOH/
Study of the Hydroalkylation of PhCHO. To a solution of 4
(402 mg, 0.94 mmol, 2 equiv) in anhydrous THF (5 mL) was added n-
BuLi (0. 59 mL, 0. 94 mmol, 1 equiv, C = 1.6 M in hexane) at −78 °C.
The solution was stirred for 5 min at this temperature before the
introduction of PhCHO (48 μL, 0.47 mmol, 1 equiv). The solution
was then stirred at this temperature for 30 min. The mixture was
quenched with sat. NH4Cl solution and extracted with Et2O (3 × 10
mL). The combined organic layers were washed with brine (10 mL),
dried (MgSO4), filtered, and concentrated under reduced pressure.
The crude was purified by flash chromatography (95:5 cyclohexane/
1
NH3 aq). H NMR (300 MHz, CDCl3): δ 7.37−7.27 (m, 5H), 5.7−
5.74 (m, 1H), 5.63−5.54 (m, 1H), 3.56 (br s, 2H), 2.87−2.67 (m,
2H), 2.46−2.24 (m, 4H), 2.18−2.01 (m, 1H), 1.98−1.72 (m, 2H),
1.61−1.37 (m, 4H), 1.06 (s, 3H). 13C NMR (75 MHz, CDCl3): δ
135.9, 132.0, 129.5, 128.4, 127.2, 125.05, 7.4, 57.2, 49.5, 49.3, 32.6,
32.3, 29.8, 22.3. IR (υ/cm−1, neat): 3330, 2927, 2852, 1638, 1448,
1144, 1007, 746, 534. HRMS (ESI) [M + H]+ for C18H26NO calcd,
272.2014; found, 272.2017.
