Full Paper
2-(4-Ethynylbenzyl)isoindoline-1,3-dione (16). To a cooled (08C)
solution of 15 (546 mg, 2.6 mmol) in dry DMF (10 mL) was added
phthalimide potassium salt (722 mg, 3.9 mmol). The reaction mix-
ture was stirred on ice for 2 h and at rt for 18 h. After addition of
water, the product precipitated. The suspension was filtered and
the solid was dissolved in DCM, washed with HCl (0.1m), brine,
dried (MgSO4), filtered and concentrated to yield 16 (625 mg,
2.4 mmol, 92%). 1H NMR (400 MHz, CDCl3): d=7.85 (m, 2H), 7.72
(m, 2H), 7.44 (d, J=8.4 Hz, 2H), 7.38 (d, J=8.4 Hz, 2H), 4.84 (s, 2H),
3.06 ppm (s, 1H). 13C NMR (100 MHz, CDCl3): d=137.10, 134.25,
132.58, 132.15, 128.69, 123.58, 77.63, 41.43 ppm.
combined organic layers were washed with brine, dried (MgSO4),
filtered and concentrated. The residue was dissolved in dry THF
(3 mL) and DMAP (39 mg, 0.32 mmol), DIPEA (167 mL, 0.96 mmol)
and 17 (97 mg, 0.32 mmol) were added and stirred at 608C for 3 h.
The reaction was quenched by the addition of NH4Cl (sat. aq.), ex-
tracted with EtOAc (3ꢂ15 mL), washed with water, brine, dried
(MgSO4), filtered and concentrated. Purification of the residue by
silica gel column chromatography (7:3 pentane:EtOAc) yielded 20
1
(55 mg, 86 mmol, 27%). H NMR (400 MHz, CDCl3): d=8.39 (s, 1H),
7.86 (m, 2H), 7.80 (m, 2H), 7.71 (m, 2H), 7.51 (m, 2H), 7.31–7.07 (m,
5H), 4.88 (s, 2H), 4.63 (s, 1H), 3.96 (m, 1H), 3.73 (m, 1H), 3.63–3.45
(m, 2H), 3.23–2.90 (m, 3H), 1.84–1.66 (m, 2H), 1.66–1.53 (m, 1H),
1.43 ppm (s, 9H). 13C NMR (100 MHz, CDCl3): d=156.15, 146.11,
136.85, 134.17, 132.15, 129.32, 128.99, 128.81, 126.80, 126.70,
126.51, 126.26, 123.52, 121.17, 120.95, 51.35, 49.21, 41.42, 40.38,
35.14, 33.58, 29.86, 28.51, 26.99, 24.06, 23.71 ppm. LC-MS m/z:
637.2 [M+H]+. HRMS m/z calculated for C36H40N6O5 [M+H]+:
637.3133, found: 637.3134.
2-(4-(1H-1,2,3-Triazol-4-yl)benzyl)isoindoline-1,3-dione (17). To a
degassed solution of 16 (102 mg, 0.4 mmol) and TMS-azide (79 mL,
0.6 mmol) in DMF:MeOH (4:0.8 mL) was added CuI (5 mg,
25 mmol). The reaction mixture was refluxed for 18 h, concentrated
and purification of the residue by silica gel column chromatogra-
phy (6:4 pentane:EtOAc) yielded 17 (78 mg, 0.26 mmol, 64%).
1H NMR (400 MHz, CDCl3): d=8.05–7.66 (m, 6H), 7.52 (m, 2H), 7.00
(s, 1H), 4.89 ppm (s, 2H). LC-MS m/z: 305.2 [M+H]+.
tertButyl (5-(4-(4-(aminomethyl)phenyl)-N-phenethyl-1H-1,2,3-tri-
azole-1-carboxamido)pentyl)carbamate (22). To a solution of 20
(27 mg, 0.04 mmol) in EtOH (1 mL) was added ethylene diamine
(4.3 mL, 0.06 mmol). The reaction mixture was stirred for 18 h, con-
centrated and purification of the residue by silica gel column chro-
matography (1:9 MeOH:DCM >1:9 MeOH:DCM+1% Et3N) yielded
22 (10 mg, 20 mmol, 50%). A side reaction was nucleophilic addi-
tion on the urea by the ethylenediamine, requiring the deprotec-
tion to be stopped before full conversion was reached. 1H NMR
(400 MHz, CDCl3): d=8.38 (s, 1H), 7.71 (m, 2H), 7.30 (m, 2H), 7.29–
7.12 (m, 5H), 4.60 (br s, 1H), 3.99 (s, 2H), 3.72–3.39 (m, 4H), 3.16–
3.00 (m, 4H), 1.75 (br s, 2H), 1.55–1.43 (m, 11H), 1.34–1.23 ppm (m,
2H). LC-MS m/z: 507.0 [M+H]+.
tertButyl (5-((2-nitro-N-phenethylphenyl)sulfonamido)pentyl)car-
bamate. To a solution of N-Boc-cadaverine (372 mg, 1.84 mmol) in
THF (8 mL) were added 2-nitrobenzenesulfonyl chloride (408 mg,
1.84 mmol) and Et3N (0.38 mL, 2.76 mmol). The cloudy reaction
mixture was stirred for 75 minutes, quenched with water (40 mL)
and extracted with EtOAc (3ꢂ20 mL). The combined organic layers
were washed with water (60 mL), brine (60 mL), dried (MgSO4), fil-
tered and concentrated. The residue was dissolved in CH3CN
(16 mL) and Cs2CO3 (1798 mg, 5.52 mmol) and phenethylbromide
(0.38 mL, 2.76 mmol) were added. The solution was stirred at 808C
for 6 h. Another equivalent of phenethylbromide (0.38 mL,
2.76 mmol) was added and stirred at 808C for 18 h. The mixture
was poured into water (50 mL) and extracted with EtOAc (3ꢂ
25 mL). The combined organic layers were washed with water
(50 mL), brine (50 mL), dried (MgSO4), filtered, and concentrated.
Purification of the residue by silica gel column chromatography
(2:8 >3:7 EtOAc:pentane) yielded the title compound (781 mg,
1.6 mmol, 87%) as a yellow oil. TLC: Rf =0.75 (1:1 pentane:EtOAc).
1H NMR (400 MHz, CDCl3): d=7.95 (d, J=7.6 Hz, 1H), 7.67–7.58 (m,
3H), 7.26–7.15 (m, 5H), 4.52 (br s, 1H), 3.50 (t, J=8.0 Hz, 2H), 3.33
(t, J=7.6 Hz, 2H), 3.07–3.06 (m, 2H), 2.84 (t, J=8.0 Hz, 2H), 1.57
(m, 2H), 1.49–1.43 (m, 11H), 1.27 ppm (m, 2H). 13C NMR (100 MHz,
CDCl3) 156.06, 148.10, 138.11, 133.67, 133.48, 131.69, 130.73,
128.84, 128.69, 126.75, 124.24, 79.07, 48.87, 47.68, 40.35, 35.19,
29.69, 28.51, 27.82, 23.75 ppm. LC-MS m/z: 492.1 [M+H]+.
1-Amino-4-((4-(2-((4-(1-((5-((tert-butoxycarbonyl)amino)pentyl)(phe-
nethyl)carbamoyl)-1H-1,2,3-triazol-4-yl)benzyl)amino)-2-oxoethyl)-
phenyl)amino)-9,10-dioxo-9,10-dihydroanthracene-2-sulfonate (23).
To a solution of cAB40 (8.5 mg, 0.02 mmol) and HCTU (7.7 mg,
0.02 mmol) in dry DMF (1 mL) was added DIPEA (3.6 mL,
0.02 mmol). The reaction mixture was stirred for 15 minutes before
addition of 22 (10 mg in 1 mL DMF, 0.02 mmol). The reaction mix-
ture was stirred for 3 h, concentrated and purification of the resi-
due by silica gel column chromatography (5:5:1 DCM:pentane:-
MeOH+1% AcOH) yielded 23 (10 mg, 11 mmol, 53%) as a blue
solid. 1H NMR (500 MHz, CDCl3/MeOD): d=8.31 (t, J=9.0 Hz, 2H)
8.27 (s, 1H), 7.84–7.74 (m, 4H), 7.35–7.13 (m, 12H), 4.46 (br s, 2H),
3.67–3.57 (m, 4H), 3.37 (s, 2H), 3.16–2.99 (m, 6H), 1.77 (br s, 2H),
1.43–1.33 (m, 11H), 1.31–1.26 ppm (m, 2H). 13C NMR (125 MHz,
CDCl3/MeOD) 183.97, 172.03, 140.92, 138.67, 134.53, 134.07, 133.09,
132.80, 131.04, 130.46, 128.90, 128.76, 128.13, 126.44, 126.31,
126.15, 124.29, 123.43, 54.73, 51.37, 46.77, 43.18, 42.86, 42.64,
29.58, 28.34 ppm. LC-MS m/z: 940.93 [M+H]+.
tertButyl (5-(phenethylamino)pentyl)carbamate (19). To a solu-
tion of tert-butyl (5-((2-nitro-N-phenethylphenyl)sulfonamido)pen-
tyl)carbamate (781 mg, 1.59 mmol) in CH3CN (15 mL) were added
Cs2CO3 (1.57 g, 4.77 mmol) and PhSH (244 mL, 2.38 mmol). The re-
action mixture was stirred for 18 h, poured into water (100 mL)
and extracted with DCM (3ꢂ50 mL). The combined organic layers
were dried (MgSO4), filtered and concentrated. Purification of the
residue by silica gel column chromatography (1:9 MeOH:DCM
>1:9 MeOH:DCM + 1% Et3N) yielded 19 (400 mg, 1.3 mmol, 82%)
1-Amino-4-((4-(2-((4-(1-((5-(6-(3,3-dimethyl-2-((1E,3E)-5-((Z)-1,3,3-tri-
methylindolin-2-ylidene)penta-1,3-dien-1-yl)-3H-indol-1-ium-1-yl)-
hexanamido)pentyl)(phenethyl)carbamoyl)-1H-1,2,3-triazol-4-yl)ben-
zyl)amino)-2-oxoethyl)phenyl)amino)-9,10-dioxo-9,10-dihydroan-
thracene-2-sulfonate (2). A solution of 23 (9 mg, 9.6 mmol) in DCM
(9 mL) and TFA (1 mL) was stirred for 45 minutes. The solvent was
evaporated and co-evaporated with toluene. The crude was dis-
solved in dry DMF (5 mL), Cy5-OSu ester (5.5 mg, 9.6 mmol) and
DIPEA (5.2 mL, 0.03 mmol) were added and the reaction mixture
was stirred for 4 h, concentrated and purified by semi-preparative
HPLC to yield 2 (1.3 mg, 1.0 mmol, 10%) as a blue solid. HRMS m/z
calculated for C77H80N10O8S [M+H]+: 1305.5954, found: 1305.5941.
1
as a clear oil. H NMR (400 MHz, CDCl3): d=7.33–7.27 (m, 2H), 7.21
(dt, J=5.9, 1.4 Hz, 3H), 4.66 (br s, 1H), 3.74 (br s, 1H), 3.09 (m, 2H),
3.00–2.84 (m, 4H), 2.68 (m, 2H), 1.56 (m, 2H), 1.44 (s, 11H), 1.40–
1.23 ppm (m, 2H). LC-MS m/z: 307.2 [M+H]+.
tertButyl
(5-(4-(4-((1,3-dioxoisoindolin-2-yl)methyl)phenyl)-N-phe-
nethyl-1H-1,2,3-triazole-1-carboxamido)pentyl)carbamate (20). To a
cooled (08C) solution of 19 (98 mg, 0.32 mmol) in dry THF (3 mL)
were added DIPEA (167 mL, 0.96 mmol) and triphosgene (47 mg,
0.16 mmol). The reaction mixture was stirred on ice for 1 h,
quenched with water and extracted with EtOAc (3ꢂ15 mL). The
1-(6-((5-(4-(4-((1,3-Dioxoisoindolin-2-yl)methyl)phenyl)-N-phenethyl-
1H-1,2,3-triazole-1-carboxamido)pentyl)amino)-6-oxohexyl)-3,3-di-
&
&
Chem. Asian J. 2018, 00, 0 – 0
