PAPER
Synthesis, structure and luminescence of Co-crystals
with hexagonal channels: arranging disposition and p–p
interactions3
Cite this: DOI: 10.1039/c2ce25759a
Gui-Ge Hou,* Hui-Juan Zhao, Ju-Feng Sun, Dong Lin, Xian-Ping Dai, Jing-Tian Han
and Hui Zhao
Co-crystallization of asymmetric building blocks 5-(4-pyridyl)pyrimidine (A) and 5-(4-(1-imidazolyl)phe-
nyl)pyrimidine (B) with resorcinol and hydroquinone, respectively, was investigated. Four new organic co-
crystals (1–4) were generated. The X-ray single crystal analysis indicates that the crystal packing in 1, 2 and
4 generates open hexagonal channels with resorcinol or hydroquinone molecules encapsulated through
hydrogen bonding interactions. In 3, {B2(resorcinol)2} macrocycle is generated from clip-like resorcinol and
asymmetric B molecules. In addition, the luminescent properties of A, B and 1–4 were investigated
primarily in the solid state. The luminescent property is dependent on the molecular vertical arranging
disposition and the intermolecular p–p contacting characteristic. The results display more interesting
tunability of the emission intensity of the building modules by the incorporation of coformers into the co-
crystals.
Received 15th May 2012,
Accepted 23rd August 2012
DOI: 10.1039/c2ce25759a
www.rsc.org/crystengcomm
obtaining potential organic co-crystals with outstanding
luminescent properties is a challenge for scientists. Recent
Introduction
Hydrogen bonding has been widely used in the construction of
supramolecular aggregation because of their strength and
directionality.1,2 During past decades, Etter’s set of rules for
hydrogen bonding interaction in organic crystals,1a Desiraju’s
concept of ‘supramolecular synthons1b and the definition of
‘‘co-crystal’’2c have been brought forward. A co-crystal is one of
the crystalline materials composed of different molecular
species held together by non-covalent forces in which all
components are solid under ambient conditions when in their
pure form.2c Co-crystals offer aggregation to modify the
physical properties of the subset involved without changing
the compound structure. Some of them exhibit encouraging
potential for application in pharmaceutical science and solid-
state organic synthesis.3 Investigation of co-crystals as
luminescent materials, however, is extremely rare.4 In terms
of fundamental studies and practical applications, the ability
to tune and control the luminescent color or intensity of an
organic material is important to achieve multi-color materials
or intensity-tunable fluorescent materials, and further to meet
the need of next generation light-emitting materials.5 So,
advances in organic co-crystals have indicated that the
intermolecular interactions or molecular stacking patterns in
the solid state play a key role in the observed bulk luminescent
characteristics. Co-crystals are molecular solids composed of
at least two types of neutral chemical species. Incorporation of
different coformers with the different functional groups and
orientations may profoundly influence the structural assem-
blies and luminescent properties because of their different
hydrogen bonding capabilities and steric/electronic effects. So,
the exploration of the synthesis of new and patentable co-
crystals, and furthermore their luminescent properties are very
significant.
Previously, some symmetric pyrimidine derivatives as
‘‘linear’’ building blocks, such as 5,59-dipyrimidine and 1,2-
bis(59-pyrimidyl)ethyne, have occasionally been used in supra-
Binzhou Medical University, Yantai, 264003, P. R. China.
E-mail: guigehou@163.com
Electronic supplementary information (ESI) available. CCDC reference
3
numbers 855279, 855280, 874492 and 874493. Copies of the data can be
obtained free of charge on application to CCDC, 12 Union Road, Cambridge CB2
1EZ, UK (fax: (+44)1223-336-033; e-mail: deposit@ccdc.cam.ac.uk). For ESI and
crystallographic data in CIF or other electronic format see DOI: 10.1039/
c2ce25759a
Scheme 1 Building modules A, B and co-crystals 1–4.
This journal is ß The Royal Society of Chemistry 2012
CrystEngComm

View Article Online
Paper
CrystEngComm
molecular chemistry and the construction of co-crystals.6 In
contrast, hydrogen bonding-driven organic co-crystals based
on asymmetric pyrimidine derivatives have not received much
attention.7 Thus, the inclusion of different functional groups,
such as pyrimidine, pyridine and imidazole, can lead to
different and patentable co-crystals with versatile structures
and potential properties.
Additionally, some organic hydroxybenzene and aromatic
carboxylic acids have been selected as hydrogen-bond donors
to investigate hydrogen-bond topology and dimensionali-
ty.4c,7,8 In this contribution, an effective strategy for getting
novel organic co-crystals by designing and controlling the
orientation of coformers and dimension of building blocks is
carried out and we report four new co-crystals 1–4 (Scheme 1),
7.69 (d, 2H, –C6H4), 7.57–7.54 (d, 2H, –C6H4), 7.34 (s, 1H, –
C3H3N2), 7.24 (s, 1H, –C3H3N2). Elemental analysis (%) cald for
C13H10N4: C 70.26, H 4.53, N 25.21; found: C 69.89, H 4.62, N
25.35.
Preparation of co-crystals 1–4
A CH2Cl2 and CH3CN solution (10 mL, 1 : 1, v/v) of A (15.7 mg,
0.1 mmol) or B (22.2 mg, 0.1 mmol) with resorcinol (11.0 mg,
0.1 mmol) and hydroquinone (11.0 mg, 0.1 mmol), respec-
tively, was kept at room temperature. Upon slow evaporation
of the solvent about 5 days, colorless crystals 1–4 were
obtained.
Co-crystal 1
Yield: 80%. IR (KBr pellet cm21): 3049(s), 2972(s), 1603(s),
1568(s), 1485(s), 1410(s), 1327(s), 1292(s), 1240(m), 1180(s),
1142(m), 964(m), 870(m), 822(m), 771(m), 723(m). 1H NMR
(400 MHz, DMSO, 25 uC, TMS, ppm): 9.29 (d, 3H, –C4H3N2),
9.16 (s, 1H, C6H6O2), 8.74 (d, 2H, –C5H4N), 7.85 (d, 2H,
–C5H4N), 6.91 (t, 0.5H, C6H6O2), 6.17 (m, 1.5H, C6H6O2).
Elemental analysis (%) calcd for C12H10N3O: C 67.91, H 4.74, N
19.80; found: C 67.54, H 4.87, N 19.89.
namely [(A)?(resorcinol)0.5
] (1), [(A)?(hydroquinone)0.5] (2),
[(B)?(resorcinol)] (3) and [(B)2?(hydroquinone)] (4), based on
A, B with hydroquinone and resorcinol, respectively.
Experimental
Materials and methods
Co-crystal 2
A was prepared according to the literature.9 Infrared (IR)
samples were prepared as KBr pellets and spectra were
obtained in the 400–4000 cm21 range using a Bruker Tensor-
27 FTIR spectrometer. Elemental analyses were performed on
a Perkin-Elmer Model 240c analyzer. 1H NMR data were
collected using Bruker Avance-300 and 400 spectrometers.
Chemical shifts are reported in d relative to TMS. All
fluorescence measurements were carried out on a Cary
Eclipse Spectrofluorimeter (Varian, Australia) equipped with
a xenon lamp and quartz carrier at room temperature.
Yield: 82%. IR (KBr pellet cm21): 3041(s), 2833(s), 2702(s),
1603(s), 1568(s), 1473(s), 1417(s), 1331(m), 1221(s), 1070(m),
825(s), 753(m). H NMR (400 MHz, DMSO, 25 uC, TMS, ppm):
9.28 (d, 3H, –C4H3N2), 8.73 (d, 2H, –C5H4N), 8.60 (s, 1H,
C6H6O2), 7.87 (d, 2H, –C5H4N), 6.54 (s, 2H, C6H6O2). Elemental
analysis (%) calcd for C12H10N3O: C 67.91, H 4.74, N 19.80;
found: C 67.68, H 4.85, N 19.92.
1
Co-crystal 3
Yield: 87%. IR (KBr pellet cm21): 3125(br), 1614(s), 1559(s),
1525(s), 1485(s), 1400(s), 1311(m), 1175(s), 1149(s), 1059(m),
1006(m), 826(s), 773(m), 749(m). 1H NMR (400 MHz, DMSO, 25
uC, TMS, ppm): 9.22 (d, 3H, –C4H3N2), 9.14 (s, 2H, C6H6O2),
8.39 (s, 1H, –C3H3N2), 7.98 (d, 2H, –C6H4), 7.87 (s, 1H,
–C3H3N2), 7.85 (d, 2H, –C6H4), 7.15 (s, 1H, –C3H3N2), 6.91 (t,
1H, C6H6O2), 6.18 (m, 3H, C6H6O2). Elemental analysis (%)
calcd for C19H16N4O2: C 68.66, H 4.85, N 16.85; found: C 68.32,
H 4.67, N 16.98.
Preparation of B
5-Bromopyrimidine (1.59 g, 10.0 mmol), 4-bromophenylboro-
nic acid (2.00 g, 10.0 mmol), [Pd(PPh3)4] (0.23 g, 0.2 mmol) and
K2CO3 (4.14 g, 30.0 mmol) in EtOH/H2O (v/v, 3 : 1, 50 mL) were
placed into a flame-dried Schlenk flask, then heated to reflux
for 48 h. After removal of the solvent under vacuum, the
residue was purified on silica gel using column chromato-
graphy with CH2Cl2/THF (v/v, 10 : 1) as the eluent to give 5-(4-
bromophenyl)pyrimidine as a colorless crystalline solid (yield
Co-crystal 4
1
85%). H NMR (300 MHz, CDCl3, 25 uC, TMS, ppm): 9.23 (s,
Yield: 83%. IR (KBr pellet cm21): 3128(s), 1610(m), 1556(m),
1526(s), 1468(s), 1407(s), 1358(m), 1333(m), 1314 (m), 1251(s),
1H, –C4H3N2), 8.95 (s, 2H, –C4H3N2), 7.68–7.65 (d, 2H, –C6H4),
7.51–7.47 (d, 2H, –C6H4). Elemental analysis (%) cald for
C10H7BrN2: C 51.09, H 3.00, N 11.92; found: C 51.43, H 3.08, N
11.78.
A mixture of 5-(4-bromophenyl)pyrimidine (1.88 g, 8.0
mmol), imidazole (5.40 g, 80.0 mmol), CuSO4 (0.06 g, 0.24
mmol) and K2CO3 (5.52 g, 40.0 mmol) was heated neat with
stirring at 190 uC. After 6 h, the reaction was stopped and the
crude product was dissolved in CH2Cl2/MeOH (v/v, 10 : 1) and
filtrated. The filtrate was removed from the solvent under
vacuum and the residue was purified on silica gel by using
column chromatography with CH2Cl2/THF (v/v, 5 : 1) as the
1
1217(s), 1060(s), 962(m), 835(s), 759(m), 728(m). H NMR (400
MHz, DMSO, 25 uC, TMS, ppm): 9.22 (d, 3H, –C4H3N2), 8.66 (s,
1H, C6H6O2), 8.41 (s, 1H, –C3H3N2), 7.96 (d, 2H, –C6H4), 7.88
(s, 1H, –C3H3N2), 7.85 (d, 2H, –C6H4), 7.16 (s, 1H, –C3H3N2),
6.57 (s, 2H, C6H6O2). Elemental analysis (%) calcd for
C32H26N8O2: C 69.30, H 4.72, N 20.20; found: C 69.03, H
4.61, N 20.36.
Single-crystal structure determination
Suitable single crystals of 1–4 were selected and mounted in
air onto thin glass fibers. X-ray intensity data of 1–4 were
measured at 293 K on a Bruker SMART APEX CCD-based
diffractometer (Mo-Ka radiation, l = 0.71073 Å). The raw frame
1
eluent to give B as a colorless crystalline solid (yield 65%). H
NMR (300 MHz, CDCl3, 25 uC, TMS, ppm): 9.23 (s, 1H,
nC4H3N2), 8.97 (s, 2H, –C4H3N2), 7.92 (s, 1H, –C3H3N2), 7.72–
CrystEngComm
This journal is ß The Royal Society of Chemistry 2012
