Organic Letters
Letter
rarely changes the attractive noncovalent interactions in TSL3-
o. In sharp contrast, the coordination geometry of L3
significantly changed in TSL3-m. The pyridine moiety of
TSL3-m is located relatively far from the C(sp2)−H group of
1a compared with TSL1-m. The lack of an electron-donating
tert-butyl group weakens the CH/π interactions between the
pyridine ring and the C(sp2)−H group of 1a and destabilizes
TSL3-m. Therefore, the CH−O hydrogen bond between the
SCH3 and Beg moieties plays a crucial role in stabilizing TSL3-
o (e in Figure 1b). Indeed, because 3r bears a SCF3 group, it
was not suitable for ortho-selective C−H borylation due to the
lack of a stabilizing CH−O hydrogen bond in the TS at the
ortho position (Scheme 2A).
Yoichiro Kuninobu − Institute for Materials Chemistry and
Engineering and Department of Molecular and Material
Sciences, Interdisciplinary Graduate School of Engineering
Sciences, Kyushu University, Fukuoka 816-8580, Japan;
Authors
Jialin Zeng − Department of Molecular and Material Sciences,
Interdisciplinary Graduate School of Engineering Sciences,
Kyushu University, Fukuoka 816-8580, Japan
On the contrary, 5 preferentially afforded the ortho-
borylated product, 6, even using L1. The TS models for the
L1-Ir(Beg)3-mediated C−H oxidative addition of 5 at the ortho
and meta positions (TSL1-o-5 and TSL1-m-5) indicate that
TSL1-o-5 is more stable than TSL1-m-5, in good agreement
with the experimentally observed ortho selectivity of 5 (Figure
1c). This is because the two-point hydrogen bond between the
CH2SCH3 and Beg moieties enhances the stability of TSL1-o-5
(e and f in Figure 1c). The distortion/interaction analysis15
indicates that the interaction energy between the catalyst [L1-
Ir(Beg)3 or L3-Ir(Beg)3] and substrate moieties (1a or 5) has
a significant impact on the relative stabilities of TS-o and TS-m
(Figure S2). Most importantly, the difference in interaction
energies between TS-o and TS-m increases in both TSL3 and
TSL1-5 relative to TSL1. This is mainly caused by a CH−O
hydrogen bond between the sulfide and Beg moieties at the
ortho position in the TS model, as previously described. These
computational results clarify both the importance of the CH−
O hydrogen bond between the sulfide and Beg moieties for
ortho-selective borylation and the origin of changes in
regioselectivity with bipyridine-type ligands (L1 and L3).
In summary, we have developed a simple catalytic system for
the ortho-selective C−H borylation of thioanisoles using
phenylbipyridine as a ligand. The regioselectivity was in
sharp contrast with the Ir-dtbpy-promoted C−H borylation, in
which the reaction occurred at the meta and para positions. In
comparison, the ortho-selective C−H borylation proceeded in
moderate to good yields with high regioselectivity and good
functional group tolerance. Both the boryl and the methylthio
groups of ortho-borylated thioanisole derivatives were success-
fully converted via palladium-catalyzed transformations. DFT
calculations helped to elucidate the origin of the ligand effect
for regioselectivity and revealed the importance of hydrogen
bonding between the C−H bond of the substrate SCH3 group
and an oxygen atom from the boryl ligand as well as the CH/π
interaction between the C−H bond of the aromatic ring of the
substrate and the pyridyl ring.
Morio Naito − Department of Chemistry and Research Center
for Smart Molecules, Faculty of Science, Rikkyo University,
Tokyo 171-8501, Japan
Takeru Torigoe − Institute for Materials Chemistry and
Engineering and Department of Molecular and Material
Sciences, Interdisciplinary Graduate School of Engineering
Sciences, Kyushu University, Fukuoka 816-8580, Japan;
Complete contact information is available at:
Notes
The authors declare no competing financial interest.
ACKNOWLEDGMENTS
■
This work was partially supported by JSPS KAKENHI grant
numbers JP 17H03016, 18H04656, and 18H04660 and the
Yamada Science Foundation.
REFERENCES
■
(1) Mkhalid, I. A. I.; Barnard, J. H.; Marder, T. B.; Murphy, J. M.;
Hartwig, J. F. Chem. Rev. 2010, 110, 890.
́
(2) Ros, A.; Fernandez, R.; Lassaletta, J. M. Chem. Soc. Rev. 2014, 43,
3229.
(3) (a) Ishiyama, T.; Takagi, J.; Ishida, K.; Miyaura, N.; Anastasi, N.
R.; Hartwig, J. F. J. Am. Chem. Soc. 2002, 124, 390. (b) Boller, T. M.;
Murphy, J. M.; Hapke, M.; Ishiyama, T.; Miyaura, N.; Hartwig, J. F. J.
Am. Chem. Soc. 2005, 127, 14263.
(4) (a) Boebel, T. A.; Hartwig, J. F. J. Am. Chem. Soc. 2008, 130,
7534. (b) Robbins, D. W.; Boebel, T. A.; Hartwig, J. F. J. Am. Chem.
Soc. 2010, 132, 4068.
(5) (a) Crawford, K. M.; Ramseyer, T. R.; Daley, C. J. A.; Clark, T.
B. Angew. Chem., Int. Ed. 2014, 53, 7589. (b) Yamamoto, T.;
Ishibashi, A.; Suginome, M. Org. Lett. 2017, 19, 886. (c) Liu, L.;
Wang, G.; Jiao, J.; Li, P. Org. Lett. 2017, 19, 6132. (d) Wright, S. E.;
Richardson-Solorzano, S.; Stewart, T. N.; Miller, C. D.; Morris, K. C.;
Daley, C. J. A.; Clark, T. B. Angew. Chem., Int. Ed. 2019, 58, 2834.
(6) (a) Kawamorita, S.; Ohmiya, H.; Hara, K.; Fukuoka, A.;
Sawamura, M. J. Am. Chem. Soc. 2009, 131, 5058. (b) Yamazaki, K.;
Kawamorita, S.; Ohmiya, H.; Sawamura, M. Org. Lett. 2010, 12, 3978.
(c) Ishiyama, T.; Isou, H.; Kikuchi, T.; Miyaura, N. Chem. Commun.
2010, 46, 159. (d) Sasaki, I.; Amou, T.; Ito, H.; Ishiyama, T. Org.
ASSOCIATED CONTENT
* Supporting Information
■
sı
The Supporting Information is available free of charge at
1
Experimental procedures, characterization data, and H
́
Biomol. Chem. 2014, 12, 2041. (e) Ros, A.; Estepa, B.; Lopez-
and 13C NMR spectra for new compounds (PDF)
́
́
Rodríguez, R.; Alvarez, E.; Fernandez, R.; Lassaletta, J. M. Angew.
Chem., Int. Ed. 2011, 50, 11724. (f) Roering, A. J.; Hale, L. V. A.;
Squier, P. A.; Ringgold, M. A.; Wiederspan, E. R.; Clark, T. B. Org.
Lett. 2012, 14, 3558. (g) Ghaffari, B.; Preshlock, S. M.; Plattner, D. L.;
Staples, R. J.; Maligres, P. E.; Krska, S. W.; Maleczka, R. E.; Smith, M.
R. J. Am. Chem. Soc. 2014, 136, 14345. (h) Wang, G.; Liu, L.; Wang,
H.; Ding, Y.; Zhou, J.; Mao, S.; Li. J. Am. Chem. Soc. 2017, 139, 91.
AUTHOR INFORMATION
Corresponding Authors
■
Masahiro Yamanaka − Department of Chemistry and Research
Center for Smart Molecules, Faculty of Science, Rikkyo
D
Org. Lett. XXXX, XXX, XXX−XXX
