Alkylation of gold surface by treatment with C18H 37HgOTs and anodic Hg stripping

Article abstract of DOI:10.1021/ja3117125

Treatment of a gold surface with a solution of C₁₈H ₃₇HgOTs under ambient conditions results in the formation of a covalently adsorbed monolayer containing alkyl chains attached directly to gold, Hg(0) atoms, and no tosyl groups. It is stable against a variety of chemical agents. When the initial deposition is performed at a positive applied potential and is followed by oxidative electrochemical stripping, the mercury can be completely removed, leaving a gold surface covered only with alkyl chains. The details of the attachment structure are not known. The conclusions are based on infrared spectroscopy, X-ray and UV photoelectron spectroscopy, ellipsometry, contact angle goniometry, differential pulse polarography, and measurements of electrode blocking and electrochemical admittance.

Full text of DOI:10.1021/ja3117125

Subscriber access provided by LAURENTIAN UNIV
Article
Alkylation of Gold Surface by Treatment
with C18H37HgOTs and Anodic Hg Stripping
Malgorzata Mucha, Eva Kaletova, Anna Kohutova, Frank Scholz, Elizabeth S
Stensrud, Ivan Stibor, Lubomir Pospisil, Florian von Wrochem, and Josef Michl
J. Am. Chem. Soc., Just Accepted Manuscript • DOI: 10.1021/ja3117125 • Publication Date (Web): 11 Feb 2013
Downloaded from http://pubs.acs.org on February 28, 2013
Just Accepted
“Just Accepted” manuscripts have been peer-reviewed and accepted for publication. They are posted
online prior to technical editing, formatting for publication and author proofing. The American Chemical
Society provides “Just Accepted” as a free service to the research community to expedite the
dissemination of scientific material as soon as possible after acceptance. “Just Accepted” manuscripts
appear in full in PDF format accompanied by an HTML abstract. “Just Accepted” manuscripts have been
fully peer reviewed, but should not be considered the official version of record. They are accessible to all
readers and citable by the Digital Object Identifier (DOI®). “Just Accepted” is an optional service offered
to authors. Therefore, the “Just Accepted” Web site may not include all articles that will be published
in the journal. After a manuscript is technically edited and formatted, it will be removed from the “Just
Accepted” Web site and published as an ASAP article. Note that technical editing may introduce minor
changes to the manuscript text and/or graphics which could affect content, and all legal disclaimers
and ethical guidelines that apply to the journal pertain. ACS cannot be held responsible for errors
or consequences arising from the use of information contained in these “Just Accepted” manuscripts.
Journal of the American Chemical Society is published by the American Chemical
Society. 1155 Sixteenth Street N.W., Washington, DC 20036
Published by American Chemical Society. Copyright © American Chemical Society.
However, no copyright claim is made to original U.S. Government works, or works
produced by employees of any Commonwealth realm Crown government in the course
of their duties.

Page 1 of 45
Journal of the American Chemical Society
1
2
3
Alkylation of Gold Surface by Treatment with C H HgOTs and Anodic Hg Stripping
18 37
4
5
6
7
8
a a a b a
Malgorzata Mucha, Eva Kaletová, Anna Kohutová, Frank Scholz, Elizabeth S. Stensrud, Ivan
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
a a,c b
Stibor, Lubomír Pospíšil, Florian von Wrochem, and Josef Michl*
a,d
a
Institute of Organic Chemistry and Biochemistry, Academy of Sciences of the Czech Republic,
Flemingovo nám. 2, 16610 Prague 6, Czech Republic
b
Sony Deutschland GmbH, Materials Science Laboratory, Hedelfinger Strasse 61, 70327 Stuttgart,
Germany
c
J. Heyrovský Institute of Physical Chemistry, Academy of Sciences of the Czech Republic,
Dolejškova 3, 18223 Prague, Czech Republic
d
Department of Chemistry and Biochemistry, University of Colorado, 215 UCB, Boulder, Colorado
80309-0215, United States. E-mail: michl@eefus.colorado.edu
Abstract. Treatment of a gold surface with a solution of C H HgOTs under ambient conditions
18 37
results in the formation of a covalentlyadsorbed monolayer containingalkyl chains attached directly
to gold, Hg(0) atoms, and no tosyl groups. It is stable against a variety of chemical agents. When
the initial deposition is performed at a positive applied potential and is followed by oxidative
electrochemical stripping, the mercury can be completely removed, leaving a gold surface covered
only with alkyl chains. The details of the attachment structure are not known. The conclusions are
based on infrared spectroscopy, X-ray and UV photoelectron spectroscopy, ellipsometry, contact
angle goniometry, differential pulse polarography, and measurements of electrode blocking and
electrochemical admittance.
1
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 2 of 45
1
2
3
Introduction
4
5
6
1,2
It has been recently reported that disordered monolayers form on gold surface upon
7
8
treatment with solutions of trialkylstannyl tosylates, trifluoroacetates, or triflates under ambient
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
conditions. This discovery was preceded and motivated by accidental observations of attachment
3,4,5
of organomercury salts to the surface of gold
and even earlier investigations of adsorption of
6
organoplatinum complexes to platinum. The results indicated that such behavior may have some
generality and that other organometallics should be examined, but trialkylsilyl derivatives were
found to be unreactive. At the time, it was established that the leaving group did not remain in the
monolayer, but no direct information on the mode of attachment of the adsorbate to the gold surface
was available. We have since found that the process can be extended to additional structural types
7
of organometallics, carrying various main group metals. The organic groups are detached from the
metal atom during their transfer to the gold surface, and under ambient conditions the metal usually
ends up as an oxide.
Complementary evidence for transfer of alkyl groups from
alkyltrimethylstannanes to the atoms of a gold surface resulted from recent independent
8,9
measurements of single-molecule conductivity, and dovetails with our findings.
Presently, we take a closer look at the behavior of an organomercurial, C H HgOTs, and
18 37
report spectroscopic and electrochemical evidence that a treatment of a gold surface with a solution
of n-octadecylmercuric tosylate under ambient conditions covers the surface with a monolayer that
consists of n-octadecyl groups and mercury in its elemental form, and contains no tosylate. The
adsorbed atomic mercury can be removed by oxidative anodic stripping, leaving a coating of alkyl
10
groups on an otherwise clean gold surface. Elsewhere, we report analogous monolayer formation
with C H HgOTs and find that the removal of elemental mercury from the initially formed surface
4 9
2
ACS Paragon Plus Environment

Page 3 of 45
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
monolayers can be accomplished by thermal annealing of the monolayer. At this time, we do not
have direct spectroscopic evidence for the detailed structure of the direct attachment of the alkyl
groups to the surface. The simplest possibility is a single alkyl-Au bond, but we cannot exclude a
loss of one or more hydrogen atoms from the terminal or penultimate carbons of the alkyl chain and
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
more complex bonding patterns such as alkylidene-Au , etc.
2
The use of main group organometallics for the direct transfer of organic residues to gold
11,12,13,14,15,16,17
surface promises to complement the established application of thiols
and analogous
18,19,20
compounds
that produces monolayers in which carbon is believed to be attached to the gold
surface through a mediating atom such as sulfur. Each choice appears to have certain disadvantages
21,22,23
(for thiols, sensitivity to aerial oxidation has been noted
), and a wider selection of options is
likely to be useful.
Results
Monolayer Formation and Ellipsometric Characterization. Figure 1 compares the
!5
gradual increase of the ellipsometric thickness of the surface layers formed from 10 M solutions
of C H HgOTs in THF and C H SH in ethanol. In both instances, the adsorption process is self-
18 37 18 37
limiting, and the growth of the adsorbed layer stops after about two hours at an ellipsometric
thickness of ~13 Å for C H HgOTs and ~21 Å for C H SH, regardless of whetherthe gold surface
18 37 18 37
was first cleaned with a hydrogen flame or a piranha solution. Although the growth limit is reached
after about 2 h in both cases, the ellipsometricallydetermined initial rate of growth of the monolayer
!3
is faster with C H SH than with C H HgOTs. At 10 M C H HgOTs concentration the same
18 37
18 37
18 37
limiting thickness is reached in ~1.5 h.
3
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 4 of 45
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 1. Kinetics of monolayer formation followed by ellipsometric
thickness d for C H HgOTs (•,–) and C H SH (#,!) on gold
18 37
18 37
substrates cleaned by piranha (P) and hydrogen flame annealing (A).
Contact Angle Goniometry. Contact angles of water on monolayers from C H HgOTs
18 37
are 96° ± 4° and 101° ± 2° when the gold substrates are cleaned by hydrogen flame or piranha
solution, respectively. They are distinctly higher than the 17 ± 3° and 71 ± 4° angles measured on
the initial gold substrate cleaned by hydrogen flame or piranha, respectively, and are similar to the
1
values 92 – 97° found for layers generated from trialkylstannyl precursors. The angle is
significantly lower than the 113° we observe for a monolayer from C H SH adsorbed on gold
18 37
cleaned by piranha and close to the 100° we observe for a C H SH monolayer on flame-annealed
18 37
gold.
4
ACS Paragon Plus Environment

Page 5 of 45
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 2. ATR-FTIR spectra. A: C H SH (black and red) and
18 37
C H HgOTos (cyan and green) based monolayers adsorbed on
18 37
gold substrates cleaned by piranha (P) and hydrogen flame
annealing (A). B: Au plate treated with C H HgOTs before
18 37
(black) and after (red) electrochemical stripping.
Infrared Spectroscopy (IR). Single-reflectionattenuatedtotalreflectance(ATR)IR spectra
contain the typical peaks of alkyl chains (Figure 2A) and those of the tosylate residue are absent.
The spectra show only vibrations attributable to the CH and CH groups: stretching at 2853,
3 2
í (CH ), 2871, í (CH ), 2925, í (CH ), and 2958, í (CH ), and bending at 1378, 1418 and 1468 (all
s 2 s 3 3
as
2
as
5
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 6 of 45
1
2
3
-1 1 -1
in cm ). As in the monolayers from trialkylstannyl compounds, í (CH ) occurs 5 cm and í (CH )
2
s
2
as
4
5
6
-1
6 cm above their respective locations in the highly ordered monolayer of 1-octadecanethiol,
7
8
suggesting that the alkyl chain are not all-trans, but disordered. Upon heating, the monolayer
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
formed from octadecanethiol becomes disordered and the symmetric and antisymmetric CH
2
stretches move to higher frequencies. In the octadecylmercury derived monolayer these bands are
alreadyshifted at room temperature and no further shift occurs upon heating. As expected, the peaks
due to CH vibrations dominate considerably over those due to CH vibrations, more so than they
2
3
do for monolayers obtained from C H HgOTs (Supporting Information).
4 9
Photoelectron Spectroscopy: X-Ray (XPS) and UV (UPS). X-ray photoelectron spectra
show the presence of Hg and C and the absence of S at the gold surface in a fully grown
C H HgOTs derived monolayer, hence the tosylate residue is lost from C H HgOTs during the
18 37
18 37
1
self-assembly process, similarly as it is from organostannyl tosylates. In the XP spectra of the
pristine monolayers, the Hg atoms yield only a single set of peaks both in the 4f and in the 4d
24,25
regions. The core level energies (99.67 for Hg 4f ) fit the expectations for elemental Hg.
7/2
The stability of the Hg signals in time as a function of temperature was investigated
10
separately on very similar samples produced by treatment of a gold surface with C H HgOTs. In
4
9
high vacuum, the signals are stable indefinitely at ambient temperature and up to ~60 EC, but begin
to disappear rapidly at ~90 EC, and are inobservable above 120 EC. The disappearance of Hg from
the surface is presumablydue to diffusion into the bulk, but evaporation maycontribute as well. The
stability of the Hg signals at room temperature is important for the present purposes because it
permits us to use their intensities for a quantitation of the relative amounts of Hg and C present.
The results are collected in Table 1 and sample spectra are shown in Figure 3.
6
ACS Paragon Plus Environment

Page 7 of 45
Journal of the American Chemical Society
1
2
3
Table 1. XPS results for monolayers from C H HgOTs.
18 37
4
5
6
______________________________________________________________________________
7
8
a a
Sample R(Hg/Au) R(C/Au) A(Hg)/D
2 b
2 b
c
c
c
A(C )/D
18
E
/eV
E
/eV
E /eV
C 1s
Hg 4f7/2
Hg 4d5/2
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
______________________________________________________________________________
initial
0.073
0.64
13
36
99.67
358.16
284.63
stripped
-
0.68
-
34
-
-
284.50
______________________________________________________________________________
a
Elemental ratios from XPS peak areas after correction for instrumental sensitivity factors and for attenuation from the
b
Hg and S layers (attenuation factor is 0.69 for a dense Hg layer as in the initial SAM). Area/atom and area/molecule
26
obtained by comparison of Hg/Au and C/Au ratios with S/Au ratios of densely packed alkanethiol monolayers (S/Au
2
~ 0.045, area/molecule = 21.6 Å ) and by consideration of the photoemission attenuation due to the organic layer,
c
respectively. Chemical shifts derived from peak centers of Gaussian/Lorentzian fits to the XPS data.
The Hg 4d signals appear at binding energies of 358.16 eV (shoulder) and 378.06 eV for the
5/2 and the 3/2 components, respectively . The Hg 4d peaks are partially overlapped by strong Au
4d signals from the gold substrate at 334.98 and 353.09 eV (Au 4d and Au 4d , respectively). A
5/2
3/2
fit to the data, subject to peak area constraints imposed by angular momentum rules, permits an
evaluation of Hg abundance at the surface, assuming equal attenuation of Au and Hg photoelectrons
by the alkyl chain overlayer. With these assumptions, consistent results are obtained for Hg 4d and
Hg 4f lines. A comparison of the XPS intensity ratios of Hg and Au signals in C H Hg SAMs with
18 37
the intensity ratios of S and Au signals in densely packed dodecanethiol monolayers, which we use
2
as a reference, yields an area of ~13 Å per Hg atom for C H Hg SAMs. This corresponds to an
18 37
Hg surface density that is roughly twice as high as that of sulfur atoms in alkanethiol monolayers.
7
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 8 of 45
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 3. XPS in the Hg 4f (panel A) and Hg 4d (panel B) regions for monolayers formed by the
treatment of gold surface with C H HgOTs. Symbols represent data points, lines (red an blue)
18 37
are fitted curves. The black line is the background.
8
ACS Paragon Plus Environment

Page 9 of 45
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
The C 1s and Hg 4f signal intensities indicate however that the surface concentration of carbon is
about 3 times lower than what is expected based on Hg density and on molecular composition
(C H Hg). Overall, the surface density of C units on Au is about 40% lower than in the densely
18 37
18
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
packed alkanethiols.
The location of the C 1s peak at a binding energy of 284.5 eV is in good agreement with its
position in alkanes. The relative abundance of surface-bound carbon (or carbons) is too low for
them to be discerned as a peak with a chemical shift different from the others.
The UV photoelectron spectrum (Supporting Information, Figure S9) of the monolayer
produced with C H HgOTs is verysimilar to that of a monolayer produced with dodecanethiol and
18 37
shows the characteristic alkyl valence band structure.
Chemical Stability. Chemical stability of the C H HgOTs derived monolayers was
18 37
-1
examined by monitoring the loss of their IR absorbance between 2800 and 3000 cm as a function
of time after exposure either to the laboratory atmosphere for a week or to various solvents and
reagents overnight. It is similar to the stability of monolayers produced from trialkylstannyl
1
precursors and generally slightly lower than that of monolayers obtained with C H SH (Figure 4).
18 37
Only the resistance to oxidants is significantly higher. Even after the monolayers are partially or
fully desorbed, no new absorption bands appear. There is not much difference between the two gold
cleaning procedures. In a sense, a stability comparison to monolayers obtained with C H SH is
18 37
unfair since the latter are denser and less permeable (cf. electrode blocking below). It is conceivable
that at similar density monolayers composed of directly bound alkyls would be considerably more
resistant than thiolate monolayers. This is not an issue that we can address presently and present
9
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 10 of 45
1
2
3
Figure 4 primarily as evidence that the alkyl groups in our monolayers are attached strongly and not
4
5
6
by mere physisorption.
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 4. Stability of adsorbed monolayers from C H SH
18 37
(black and red bars) and from C H HgOTos (cyan and green
18 37
bars) on gold surface after 20 - 23 h immersion at room
temperature, followed by rinsing and drying. R is the percent
monolayer remaining on the gold surface, calculated as the ratio
of the final to the initial integrated intensity of the 2800-3000
-1
cm bands. (A) Dry CH Cl , (B) wet CH Cl , (C) n-hexane, (D)
2
2
2
2
ethanol, (E) water, (F) 0.1 M H SO , (G) 0.1 M NaOH, (H) 1
2 4
mM KMnO , (I) 30% H O , (J) 10 mM NaBH , and (K) 7 days
4 2 2 4
in laboratory air. Gold substrates cleaned by piranha (P) and
hydrogen flame annealing (A).
Electrochemistry. The electrochemical stability range is similar for monolayers derived
from C H HgOTs (!1,38 to +1,40 V) and C H SH (!1,33 to +1,40 V). Cyclic voltammetry with
18 37 18 37
3- 4!
aqueous[Fe(CN) ] /[Fe(CN) ] asaredox probeshowsthatthelayerdepositedfromC H HgOTs,
6
6
18 37
1
like those obtained from trialkylstannnyl compounds, reduces the cyclic voltammetric peak height
to about two-thirds with respect to a clean Au sample (the electrode surface is ~35 % blocked,
3- 4!
Figure 5A). Since the electron transfer rate constant of [Fe(CN) ] /[Fe(CN) ] is high, cyclic
6
6
voltammetry may not be sensitive enough to the change of the electron transfer rate due to the
10
ACS Paragon Plus Environment

Page 11 of 45
Journal of the American Chemical Society
1
2
3
4
5
6
7
8
9
blocking. A more sensitive method is impedance spectroscopy, which yields the charge transfer
resistance of fast electron transfer reactions, derived from the radius of a semicircle of the electrode
impedance plot. The impedance method can detect rate changes that are still within the diffusion
controlled limit on the time scale of voltammetry. Indeed, already a qualitative inspection indicates
a substantial increase of the semicircle relative to the one obtained on a clean Au surface (Figure
5B).
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
The blockingis incomplete even after an overnight immersion in a solution of C H HgOTs,
18 37
whereas a 2-h immersion in a solution of C H SH is sufficient to produce a monolayer that
18 37
completely suppresses the electrochemical response.
A more detailed electrochemical examination of the adsorbed monolayer took advantage of
the known properties of the Hg(0)/Hg(II) redox couple on gold electrode (Figure S1 in Supporting
Information). In aqueous media, its potential lies at about 0.1 V against the Ag|AgCl|3M LiCl
27
electrode. It was considered important to perform the electrochemical measurements on the very
same flat plates covered with a thin layer of Au that were used for other measurements, such as IR
2
and XPS. A special electrochemical cell that permits a measurement on a selected 4.02 mm area
of the plate was designed for the purpose (Supporting Information, Figures S2 and S3). We verified
that results obtained in this fashion were similar to those obtained on Au disc electrodes embedded
in a glass capillary. The measured complex electrochemical impedance is shown in the Supporting
Information (Figure S4).
28
Successive scans by differential pulse polarography (DPP) yielded mercury oxidation
signals of gradually decreasing size (Figure S5), suggesting that elemental mercury was being
11
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 12 of 45
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Figure 5. Aqueous solution of 2 mM K [Fe(CN) ] and 0.1 M KNO . A: Cyclic voltammetry and B: local complex
3 6 3
2
impedance plot of a 4.02 mm spot on a Au plate (virgin, black; with an adsorbed layer of C H HgOTs, red; and with
18 37
an adsorbed layer of C H SH, magenta). C: Cyclic voltammetry and D: local complex impedance plot of an Au plate
18 37
(virgin, black; with an adsorbed layer of C H HgOTs, red; and after electrochemical Hg stripping, green).
18 37
removed. A determination averaged over four different spots on a plate yielded a peak potential
2
value of +135 ±5 mV and peak current of 11.9 ± 4.4 nA at an area of 4.02 mm .
When potential steps from -0.1 to +0.3 V were applied to an Au surface covered with a
monolayerproduced with C HgOTs andimmersedinto anaqueous0.1M KNO solution (immersed
18 3
2
area 0.32 cm ), transient currents i decayed in time (t) as 1/t (Figure S6), demonstrating that the
12
ACS Paragon Plus Environment

Page 13 of 45
Journal of the American Chemical Society
1
2
3
current transient is not controlled by diffusion from the bulk of the solution and that the decay
4
5
6
corresponds to the oxidation of surface confined Hg atoms. A similar hyperbolic i-t dependence for
7
8
29
an adsorbed species has been described before. Numerical integration yielded a charge of 48 mC,
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
which contains faradaic (Q ) and double layer (Q ) contributions. Repetition of the experiment with
F C
a clean Au surface of the same area yielded Q = 12.9 mC. The charging current decayed
C
exponentially in time (Figure S6). From Q = 35.1 mC, the surface concentration of Hg atoms is
F
-9 2 2
1.14×10 mol/cm , or 1 Hg atom per 15 Å .
Electrochemical Stripping of Mercury. A suitable stripping potential of 0.3 V against the
Ag|AgCl|3M LiCl electrode was estimated from the DPP results. When it was applied to the whole
electrode for 1 h, the DPP peak of mercury disappeared, but XPS indicated that 65 % of the
elemental Hg remained on the surface. Repeated scans of E from -1.0 V to +1.4 V lead to a gradual
decrease of the double layer capacitance C between -1 V and +1 V to a very low value, suggestive
of 100% coverage by a fairly compact layer (Figure 6). The decrease is especially apparent at
positive potentials, whereas at negative potentials the initial capacitance is already smaller. The
capacitance values show that outside this range C H HgOTs is still adsorbed to some extent, in a
18 37
form of a less compact adsorbate.
The C - E plots contain a sharp AC peak at 0.5 V against the Ag|AgCl|3M LiCl electrode,
absent at early and late times. Complex impedance at the potential of the peak maximum as a
function of the applied frequency (Figure S4) is a semicircle connected to a mass transfer line,
implying that the removal of mercury is a kinetically controlled process (for numerical fitting, see
Supporting Information).
13
ACS Paragon Plus Environment

Journal of the American Chemical Society
Page 14 of 45
1
2
3
4
5
6
7
8
9
The results obtained on gold electrodes are quite unlike those obtained on a glassy carbon
electrode, which we expect to be inert (Figure S7). On carbon the admittance data show no
maximum and no substantial time evolution of the adsorption zones upon repeated voltage scans.
Admittance at positive potentials never reaches very low and potential-independent values.
The results shown in Figure 6 suggested an improved protocol for possible electrochemical
removal of Hg from the surface. In a series of experiments Au plates were immersed for 2 h in a
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
C H HgOTs solution. The plate was then transferred to an electrochemical cell filled with 0.1 M
18 37
TBAPF and a potential of 1.0 V was applied for 1 h. XPS analysis indicated that the content of Hg
6
on the surface dropped to about 20% of the original value.
Figure 6. Imaginary component of Au electrode admittance in 0.2 mM
C H HgOTs in acetonitrile and 0.1 M n-Bu PF . AC frequency: 64 Hz;
18 37
4
6
amplitude: 5 mV. Voltage scan start: -1.0 V.
An even higher degree of Hg removal was achieved by initially immersing the Au plate in
-5
the electrochemical cell containing 10 M C H HgOTs and in 0.1 M TBAPF in THF and allowing
18 37
6
14
ACS Paragon Plus Environment

Page 15 of 45
Journal of the American Chemical Society
1
2
3
the monolayer formation to take place at 1.0 V for a period of 4 h. The plate was then rinsed with
4
5
6
THF and kept at a potential of 1.0 V in a 0.1 M solution of TBAPF6 in acetonitrile or in a 0.1 M
7
8
9
solution of KF in water for approximately 1 h. This procedure yielded an adsorbed layer containing
no detectable Hg (at most 5% of the original content) but still containing the C(1s) peak,
demonstrating the presence of the monolayer (Figure 7).
