Gareth J. Rowlands,[a] Rebecca J. Severinsen,[a] Jenna K. Buchanan,[a] Karl J. Shaffer,[a]
Heather T. Jameson,[a] Nishani Thennakoon,[a] Ivo Leito,[b] Märt Lõkov,[b] Agnes Kütt,[b]
Robert Vianello,[c] Ines Despotović,[c] Nena Radić[c] and Paul G. Plieger*[a]
[a] School of Fundamental Sciences, Massey University, Private Bag 11 222, Palmerston
North, New Zealand
Email: p.g.plieger@massey.ac.nz
[b] Institute of Chemistry, University of Tartu, Ravila 14a, Tartu 50411, Estonia
[c] Ruđer Bošković Institute, Bijenička cesta 54, 10000 Zagreb, Croatia
Abstract
Quinolino[7,8-h]quinoline is a superbasic compound, with a pKaH in acetonitrile greater
than that of 1,8-bis(dimethylaminonaphthalene) (DMAN), although its synthesis and the
synthesis of its derivatives can be problematic. The use of halogen derivatives 4,9-
dichloroquinolino[7,8-h]quinoline (16) and 4,9-dibromoquinolino[7,8-h]quinoline (17) as
precursors has granted the formation of a range of substituted quinolinoquinolines. The
basicity and other properties of quinolinoquinolines can be modified by the inclusion of
suitable functionalities. The experimentally obtained pKaH values of quinolino[7,8-
h]quinoline derivatives show that N4,N4,N9,N9-tetraethylquinolino[7,8-h]quinoline-4,9-
diamine (26) is more superbasic than quinolino[7,8-h]quinoline. Computationally derived
pKaH values of quinolinoquinolines functionalised with dimethylamino (NMe2), 1,1,3,3-
tetramethylguanidino (N=C(NMe2)2) or N,N,N′,N′,N′′,N′′-hexamethylphosphorimidic
triamido (N=P(NMe2)3) groups are significantly greater than that of quinolino[7,8-
h]quinoline. Overall, electron-donating functionalities are observed to increase the basicity of
the quinolinoquinoline moiety, while the substitution of electron-withdrawing groups lowers
