Liquid crystalline bis(N-salicylideneaniline)s: synthesis and thermal behavior
of constitutional isomers
⇑
Uma S. Hiremath
Centre for Soft Matter Research, Prof. U.R. Rao Road, Jalahalli, Bangalore 560013, Karnataka, India
a r t i c l e i n f o
a b s t r a c t
Article history:
The first examples of mesogenic bis(N-salicylideneaniline)s (BSANs), wherein two lipophilic (half-disk
shaped) entities are interlinked through the dihydroxydiformylbenzene core, were synthesized and char-
acterized. In particular, three constitutional (positional) isomeric BSANs were prepared by the facile two-
fold condensation of 3,4,5-tris(alkoxy)anilines with 2,3-dihydroxyterephthalaldehyde, 4,6-
dihydroxyisophthalaldehyde, and 2,5-dihydroxyterephthalaldehyde and their structures were estab-
lished by elemental analyses, FT-IR, 1H NMR, and 13C NMR. Proton NMR experiments demonstrated their
existence in enol–imine (OH) form solely. Polarizing optical microscopic, differential scanning calorimet-
ric, and powder X-ray diffraction studies evidenced the occurrence of columnar mesomorphism in two
sets of isomers.
Received 18 January 2013
Revised 16 April 2013
Accepted 18 April 2013
Available online 25 April 2013
Keywords:
Bis(N-salicylideneaniline)s
Shape-anisotropy
Hexacatenars
Intramolecular H-bonding
Columnar phase
Ó 2013 Elsevier Ltd. All rights reserved.
It is well-known that the facile reaction of salicylaldehydes (I-2)
with primary amines readily affords a unique class of organic com-
pounds called N-salicylideneanilines (SANs), the o-hydroxy Schiff
bases (II-2), where a highly stable, hydrogen (H)-bridged, quasi
six-membered ring exists due to intramolecular H-bonding be-
tween the H-atom of the hydroxy group and the N-atom of the
imine linkage.1,2 The significance of these systems, in the context
of both basic and applied research, primarily originates from the
fact that they show reversible proton-transfer processes both in
solution and solid state to form two tautomers viz., enol–imine
(OH) and keto-enamine (NH) forms. This unique behavior enables
SANs to exhibit technologically important phenomena such as
thermochromism and photochromism.2,3 These tautomers are ex-
pected to be in equilibrium with each other, but it is the (OH) form
that is commonly found and thus, well studied.
fact, five constitutional (positional) isomers of BSANs, II-2,3, II-
4,6, II-2,5, II-2,4, and II-3,6, respectively, derived from
H
O
O
H
H
O
O
H
H
O
O
H
2 R-NH2
R
N
N
R
R
N
N
R
O
O
-2 H2
O
2,3-Dihydroxyterephthalaldehyde : I-2,3
BSAN - (OH) form: II-2,3
BSAN - (NH) form: II-2,3
O
O
O
O
O
O
H
N
H
2 R-NH2
-2 H2O
H
N
H
N
H
O
H
O
X
R
N
R
R
R
R
4,6-Dihydroxyisophthalaldehyde : I-4,6
BSAN - (OH) form: II-4,6
BSAN - (NH) form: II-4,6
O
O
R
O
R
2 R-NH2
-2 H2O
H
O
H
N
N
O
H
H
N
H
X
H
O
N
R
O
O
2,5-Dihydroxyterephthalaldehyde : I-2,5
BSAN - (OH) form: II-2,5
BSAN - (NH) form: II-2,5
R
R
O
H
O
H
O
H
N
O
O
H
O
H
N
O
O
H
O
O
2 R-NH2
-2 H2
N
R
H
N
R
N
R
O
O
H
R-NH2
-H2O
H
N
R
O
R
R
R
2,4-Dihydroxyisophthalaldehyde : I-2,4
BSAN - (OH) form: II-2,4
BSAN - (NH) form: II-2,4
SAN : II-2
SAN : II-2
R
R
N
R
R
Salicylaldehyde : I-2
Enol-imine (OH) form
Keto-enamine (NH) form
O
O
O
O
N
N
N
O
2 R-NH2
-2 H2O
H
H
H
H
O
H
H
Notably, analogous compounds namely, bis(N-salicylidene-ani-
line)s (BSANs)4–7 and tris(N-salicylideneaniline)s (TSANs)8–10 have
also been made to reveal their novel material and electronic prop-
erties. Recently, MacLachlan and co-workers have carried out pio-
neering work on BSANs which are made by the twofold
condensation of 1° amines with dihydroxydiformylbenzenes.5 In
O
O
3,6-Dihydroxyphthalaldehyde : I-3,6
BSAN - (OH) form: II-3,6
BSAN - (NH) form: II-3,6
R
H
R
H
O
N
O
H
O
O
O
H
O
N
O
3 R-NH2
-3 H2O
O
R
N
H
R
N
H
X
O
O
O
O
H
N
H
H
N
⇑
Tel.: +91 80 2838 1119x232; fax: +91 80 2838 2044.
E-mail addresses: hiremath@csmr.res.in, umahiremath66@gmail.com
R
R
1,3,5-triformylphloroglucinol : I-1,3,5
TSAN - (NH) form: II-1,3,5
TSAN - (OH) form: II-1,3,5
0040-4039/$ - see front matter Ó 2013 Elsevier Ltd. All rights reserved.
http://dx.doi.org/10.1016/j.tetlet.2013.04.071

3420
U. S. Hiremath / Tetrahedron Letters 54 (2013) 3419–3423
dihydroxydiformylbenzenes, I-2,3, I-4,6, I-2,5, I-2,4, and I-3,6, are
known. The enol–imine (OH) form of BSANs II-2,3, II-2,4
and II-3,6 can tautomerize to give corresponding keto-enamine
(NH) form; however, such a process in BSANs II-4,6 and II-2,5 gives
rise to radical intermediates and thus, ruled out. Although the
exploration on BSAN materials is still in its infancy and thus, re-
mains elusive,5–7 they may be regarded as one of the significant
classes of supramolecular functional materials given the recent
observation that a specially designed BSAN, existing in (NH) form,
gives rise to H-bonded cleft in solution and an elongated, H-bond
assisted ladder-assembly in the solid state.5 Likewise, TSANs (II-
1,3,5), which are produced from the reaction of 1,3,5-triformylphl-
oroglucinol (I-1,3,5) with excess of aniline derivatives, have been
demonstrated by MacLachlan’s7 and Lee’s8 research groups as
functional motifs capable of yielding supramolecular networks.8,9
Interestingly enough, they generally exist in (NH) tautomeric
form,8–10 unlike BSANs. These systems with inter- and intra-molec-
ular H-bonding abilities, display tunable electronic and photo-
physical properties8–10 and thus, they are strongly gaining impor-
tance in material science.
Most importantly, since long ago, some of these motifs have
been incorporated in developing thermally and hydrolytically sta-
ble thermotropic mesogens exhibiting a rich variety of liquid crys-
tal (LC) phases.11–15 Specially, the molecular architecture of SAN
has been used extensively in synthesizing rod-like,11 banana-
shaped12 and dimeric13,14 bidentate ligands and their correspond-
ing metallo-mesogens.11,15 Due to the presence of the SAN core
some of these LCs have shown remarkable phase transitional
behavior.10–14 By utilizing the TSAN core we have developed an en-
tirely new class of disk-like (discotic) LCs existing exclusively in
ketoenamine tautomeric forms.10 These discotics show columnar
LC phases where protons and electrons can interact with each
other through the H-bonding environment. Markedly, the fluid/fro-
zen Col phases formed by these discotics show photolumines-
cence.9 On the other hand, to the best of our knowledge, liquid
crystallinity (mesomorphism) has not been induced in BSAN mate-
rials. That is, mesomorphic BSANs have not been reported hitherto
despite their attractive features in terms of both basic and applied
research points of view.
In this Letter, the synthesis and thermal behavior of the first
examples of BSANs exhibiting LC behavior are reported. As shown
in Figure 1 (left portion), three constitutional (positional) isomeric
BSANs, II-2,3-a–b, II-4,6-a–b, and II-2,5-a–b were prepared from
the corresponding dihydroxydiformylbenzenes, I-2,3, I-4,6, and I-
2,5 and investigated for their mesomorphism.
The target BSANs were prepared via the synthetic route out-
lined in Scheme 1. The requisite 1,2-dimethoxybenzene (1), 1,3-
dimethoxybenzene (2), and 1,4-dimethoxybenzene (3) were pre-
pared in high yield by the reaction of respective benzenediols
viz., catechol, resorcinol, and hydroquinone with dimethyl-sulfate
using potassium carbonate (K2CO3) as a mild base and acetone as
solvent. The dilithiation of veratrole 1 with n-butyllithium (n-BuLi)
in the presence of tetramethylethylene-diamine (TMEDA)16a fol-
lowed by dimethylformamide (DMF) treatment yielded 2,3-dim-
ethoxyterephthalaldehyde (4).16b,c Subsequent boron tribromide
(BBr3) mediated O-demethylation of 4 afforded 2,3-dihydroxyte-
rephthalaldehyde (I-2,3) in 84% yield.16b,c Compound 2 was bromi-
nated using two equivalents of lithium bromide (LiBr) in the
presence of copper(II) bromide (CuBr2) and oxygen atmosphere
to obtain 1,5-dibromo-2,4-dimethoxybe-nzene (5) in 92% yield.17
The lithium–bromine exchange of 5 with n-BuLi followed by reac-
tion with N-methylformanilide gave 4,6-dimethoxyisophthalalde-
hyde (6); demethylation of
6 using aluminum chloride in
nitrobenzene furnished the requisite 4,6-dihydroxyisophthalalde-
hyde (I-4,6).18 Treating 1,4-dimethoxybenzene (3) first with n-BuLi
in the presence of TMEDA16a then with DMF gave 2,5-dimethoxy-
tere-phthalaldehyde (7). Compound 7 was demethylated with
48% HBr (aq) to get 2,5-dihydroxyterephthalaldehyde (I-2,5)19 in
42% yield. The reaction of pyrogallol with a large excess of 1-bro-
mooctane/1-bromodecane in the presence of K2CO3 using DMF as
solvent yielded 1,2,3-trialkoxybenzenes (8a–b)10c Two-phase
nitration10c,20a of 8a–b using aqueous solution of nitric acid (70%)
and sodium nitrite in dichloromethane gave 3,4,5-trialkoxynitro-
benzenes (9a–b). These nitro compounds were subjected to cata-
lytic (Pd–C/H2) hydrogenation to obtain 3,4,5-trialkoxyanlines
(10a–b).10c,20b
Finally, dihydroxydiformylbenzenes, I-2,3, I-4,6, and I-2,5 were
condensed with two equivalents of alkoxyanilines 10a–b in reflux-
RO
OR
OR
H
O
O
H
N
N
RO
OR
(a)
(b)
RO
II-2,3-a : R = C8H17 ; II-2,3-b : R= C10H21
O
O
H
N
H
N
RO
OR
OR
RO
OR
OR
II-4,6-a : R = C8H17 ; II-4,6-b : R= C10H21
OR
O
H
RO
N
OR
RO
N
OR
(c)
H
O
RO
II-2,5-a : R = C8H17 ; II-2,5-b : R = C10H21
Figure 1. Left portion: Molecular structures of three types of BSANs synthesized where the dotted lines represent H-bonds existing between N and O atoms. Right portion:
Space-filling energy minimized (all-trans) molecular models of II-2,3-a (a), II-4,6-a (b), and II-2,5-a (c) derived from MM2 method.

U. S. Hiremath / Tetrahedron Letters 54 (2013) 3419–3423
