824
D. M. Neumann et al. / Bioorg. Med. Chem. 22 (2014) 813–826
mixture was a suspension the entire time. The reaction mixture
was concentrated to about 1/3 of the original volume and left at
room temperature overnight. Solid material was separated by filtra-
tion from the dark solution, washed with a small portion of ice–
water chilled acetone, ether (3 ꢁ 10 mL) and dried on air to give pure
product (2.9 g; 85%). 1H NMR (DMSO-d6) d 11.77 (1H, s, NH), 11.04
(1H, s, NH), and 2.56 (3H, s, CH3) ppm. 13C NMR (DMSO-d6) d
195.67, 149.8, 96.1, and 24.5 ppm. Elemental Analysis Calculated:
C 42.36, H 3.55, N 16.47. Found: C 42.25, H. 3.68, N 16.35.
4.5.9. Typical procedure for preparation of Schiff bases with
amino acids (Table 5)
Preparation of 6-{(E)-[1-(2,4,6-trioxohexahydropyrimidin-5-
yl)ethylidene]amino}hexanoic acid (BA29). A methanol (500 mL)
suspension of 5-acetyl-2,4,6-pyrimidinetrione (1.7 g; 0.01 mol)
and 5-aminohexanoic acid (1.3 g; 0.01 mol) with kaolin clay (1 g)
was refluxed with stirring overnight. Insoluble material was sepa-
rated by hot filtration. The filtrate volume was reduced to ꢀ30 mL
and cooled at ice water for 30 min. The formed white powder was
separated by filtration, washed with ether (3 ꢁ 10 mL) and dried
on air to give pure product (2.1 g; 74%). 1H NMR (DMSO-d6) d
10.0 (2H, broad s, NH), 2.74 (2H, t, J = 7.6 Hz, NCH2), 2.25 (3H, s,
CH3), 2.16 (2H, t, J = 7.6 Hz), 1.51 (2H, m), 1.45 (2H, m), and 1.26
(2H, m) ppm. 13C NMR (DMSO-d6) d 194.7, 175.2, 166.4, 151.7,
95.6, 39.3, 34.1, 32.7, 27.3, 26.0, and 24.6 ppm.
4.5.5. Typical procedure for preparation of 5-rylidene-2,4,6-pyri
midinetrione (Table 2)
Preparation of 5-(2-hydroxybenzylidene)pyrimidine-2,4,6-tri-
one (BA47). Salicylic aldehyde (1.22 g; 0.01 mol) was added into
a
stirring water (75 mL) solution of 2,4,6-pyrimidinetrione
(1.28 g; 0.01 mol). Immediately after mixing, an orange precipitate
started to form. The resulting orange suspension was stirred at
room temperature for additional 10 min. The solid product was
separated by filtration, washed with water (3 ꢁ 10 mL) and dried
on air to give 2.2 g (91%) of pure product. 1H NMR (DMSO-d6) d
11.29 (1H, s), 11.12 (1H, s), 10.58 (1H, s), 8.60 (1H, s), 8.14 (1H,
d, J = 8.0 Hz), 7.35 (1H, t, J = 8.0 Hz), 6.91 (1H, d, J = 8.4 Hz), 6.81
(1H, t, J = 8.0 Hz) ppm. 13C NMR (DMSO-d6) d 164.4, 162.5, 159.7,
151.0, 135.4, 133.5, 120.6, 118.9, 117.8, and 116.1 ppm.
4.5.10. Typical procedure for preparation of Schiff bases with
aromatic and aromatic heterocyclic amines (Table 5)
5-{(E)-[(4-Hydroxyphenyl)imino]methyl}-1,3-dimethylpyrimidine-
2,4,6-trione (BA79). Methanol (150 mL) solution of 5-formyl-1,
3-dimethyl-2,4,6-pyridinetrione (1.84 g; 0.01 mol), and 4-amino-
phenol (1.2 g; 0.011 mol) was refluxed for two hours. The reaction
mixture became a suspension after refluxing for a few minutes. The
pale yellow solid was separated by filtration, washed with cold
methanol (3 ꢁ 20 mL) and dried on air to give 2.6 g (95%) of pure
product. 1H NMR (DMSO-d6) d 11.78 (1H, d, J = 1.32 Hz, 5-H),
9.66 (1H, s, OH), 8.32 (d, J = 1.28, CH), 7.23 (2H, d, J = 8.8 Hz,
m-H), 6.75 (2H, d, J 8.8 Hz), and 3.09 (6H, s, NCH3) ppm. 13C NMR
(DMSO-d6) d 164.5, 152.5, 156.7, 152.1, 151.9, 130.9, 120.7,
116.7, 92.0, 28.1, and 27.4 ppm. Elemental Analysis Calculated: C
56.72; H 4.76; N 15.27. Found: C 56.65, H 4.87, N 15.16.
4.5.6. Typical procedure for preparation of 5-alkyl-2,4,6-pyrimid
one (Table 3)
Preparation
of
5-(3-phenylpropyl)pyrimidine-2,4,6-trione
(BA66). A methanol (30 mL) suspension of 5[3-phenylprop-2-en-
1-ylidene]pyrimidine-2,4,6-trione (BA42) (500 mg; 2 mmol) and
5% Pt/C (50 mg) was shaken under hydrogen pressure (32 psi) at
room temperature for 5 h. The catalyst was separated by filtration
and filtrate was evaporated to white powdery material (480 mg;
96%). 1H NMR (DMSO-d6) d 11.19 (2H, s NH), 7.24 (2H, t,
J = 7.2 Hz), 7.15 (3H, m), 3.53 (1H, m, 5-H), 2.53 (2H, t, J = 7.
6 Hz), 1.89 (2H, m), and 1.55 (2H, m) ppm. 13C NMR (DMSO-d6) d
171.2, 151.6, 142.2, 128.95, 128.92, 126.4, 48.5, 35.6, 28.6, and
28.4 ppm.
4.5.11. Preparation of Schiff bases with amino pyridines
(Table 5)
Preparation of (E)-1,3-dimethyl-5-((pyridin-4-ylimino)methyl)
pyrimidine-2,4,6-trione (BA82). A methanol (150 mL) solution of
5-formyl-1,3-dimethylpyrimidine-2,4,6-trione (1.84 g; 0.01 mol)
and 4-aminopyridine (0.94 g; 0.01 mol) was refluxed for three
hours. The volume of the reaction mixture was reduced to 1/3
(ꢀ50 mL) by distilling off methanol at atmospheric pressure. A
deep red colored reaction mixture was left at room temperature
overnight. The formed yellow crystals were separated by filtration,
and washed with cold methanol to give 2.1 g (81%) pure product.
1H NMR (CDCl3) d 11.95 (1H, d, J = 13.6 Hz, 5-H), 8.75 (1H, d, J
=13.6 Hz, CH), 8.63 (2H, d, J = 6.2 Hz, 2-H pyridine), 7.16 (2H, d,
J = 6.0 Hz, 3-H pyridine), and 3.38 (6H, s, NCH3) ppm. 13C NMR
(CDCl3) d 165, 152, 151, 145, 115, 112, 96, 28, and 27 ppm.
4.5.7. Typical procedure for preparation of 5,5-dialkylated pyri
midinetrione (Table 4)
Preparation of 5,5-di[4-(dimethylamino)benzyl]pyrimidine-
2,4,6-trione (BA71). A methanol (50 mL) suspension of 2,4,6-pyri-
dinetrione (256 mg; 2 mmol), 4-dimethylaminobenzaldehyde
(600 mg; 4 mmol) and 5% Pt–C (50 mg) was first shaken under
nitrogen for two hours and then under hydrogen pressure (32
psi) for 10 h. Catalyst was separated by filtration and the filtrate
evaporated to a yellow powdery product (750 mg; 94%). 1H NMR
(DMSO-d6) d 11.10 (2H, s, NH), 6.84 (4H, d, J = 8.4 Hz), 6.56 (4H,
d, J = 8. 4 Hz), 3.11 (4H, s, CH2), and 2.80 (12H, s, NCH3) ppm. 13C
NMR (DMSO-d6) d 173.3, 150.1, 149.9, 130.5, 123.0, 112.8, 71.1,
60.3, and 43.9 ppm.
4.5.12. Typical procedure for preparation of unsubstituted 2,4,6-
pyrimidinetrione hydrazones (Table 6)
Preparation of 5-[(E)-hydrazinylidenemethyl]pyrimidine-2,4,6-
trione (BA116). A methanol (200 mL) suspension of 5-formylpyrim-
idine-2,4,6-trione (1.56 g; 0.01 mol) and hydrazine (2 g; 0.04 mol)
was refluxed for one hour, sonicated for 30 min and refluxed for an
additional hour. The still hot, yellow insoluble material was sepa-
rated by filtration, washed with hot methanol (3 ꢁ 20 mL) and dried
at 110 °C for 10 min to give pure product (1.6 g; 94%). 1H NMR
(DMSO-d6) d 11.01 (1H, br s, 5-H), 10.55 (1H, s, NH), 10.49 (1H, s,
NH), 7.97 (1H, s, CH), and 5.64 (2H, s, NH2) ppm. 13C NMR (DMSO-
d6) d 161.9, 155.5, 151.6, and 87.5 ppm. Elemental Analysis
Calculated: C 35.30, H 3.55, N 32.93; Found: C 35.21, H 3.61, N 32.85.
4.5.8. Preparation of (E)-1,3-dimethyl-5-((2-phenylhydrazono)
methyl)pyrimidine-2,4,6-trione (BA73)
A
methanol solution (100 ml) of carbaldehyde (1.82 g;
0.01 mol) and phenylhydrazine (1,3 g; 0.012 mol) was refluxed
for two hours. The reaction mixture was left at room temperature
overnight and cooled in ice water for 10 min before being filtered.
The solid product was washed with ice–water cooled methanol
(3 ꢁ 10 ml) and dried on air to give pure product in 95% (2.6 g) iso-
lated yield. 1H NMR (DMSO-d6) d 11.15 (1H, d, J = 11 Hz, NH), 8.79
(1H, s), 8.14 (1H, d, J = 11 Hz), 7.19 (2H, t, J = 8 Hz), 6.83 (1H, t,
J = 7 Hz), 6.73 (2H, d, J = 8 Hz) 3.10 (3H, s), and 3.09 ppm (3H, s);
13C NMR (DMSO-d6) d 163.9, 162,6, 160.8, 158.3, 152.1, 148.4,
129.7, 121.3, 113,7, 90.3, 28.1, and 27.5 ppm.
4.5.13. Typical procedure for preparation of hydrazones of 2,4,6-
pyrimidinetriones (Table 7)
Preparation
of
5-{(E)-[2-(4-nitrophenyl)hydrazinylidene]
methyl}pyrimidine-2,4,6-trione (BA22). A hot methanol (200 mL)
