3716
E. P. Keaney et al. / Bioorg. Med. Chem. Lett. 24 (2014) 3714–3718
Scheme 1. Reagents and conditions: (a) nBuLi, MeI, THF, ꢀ78 °C to rt (91%); (b) Br2,
CH2Cl2, rt, 45 min (Quant. carried on crude); (c) cyclopropane carboxamide, N,N0-
dimethylenediamine, CuI, K2CO3, toluene, 110 °C, 5 d (8%; undesired regioisomer
30%); (d) ClSO3H, rt, 2.5 h (87% carried on crude); (e) NH2-R, pyridine, THF, rt, 1.5 h
(42–71%).
was then utilized to form the oxazole ring (9).26,27 They report lim-
ited work on the formation of 2,4,5-trisubstituted oxazoles, though
they did highlight one example albeit with reduced yield compared
to that for the synthesis of disubstituted oxazoles. We also
observed low conversion to the desired tri-substituted oxazole 9
and isolated a mixture of both oxazole regioisomers. From the oxa-
zole intermediate, synthesis of the desired compounds was
straightforward, where regioselective chlorosulfonylation followed
by reaction with various amines (R) provided sulfonamides 10.
An alternate synthetic route provided a streamlined synthesis
and allowed for rapid elaboration of both the oxazole alkyl substi-
tuent R0 and the sulfonamide R (Scheme 2). Chlorosulfonylation
and subsequent reaction with a variety of amines led to sulfona-
mides 13. Bromination was accomplished by reaction with carb-
Scheme 2. Reagents and conditions: (a) ClSO3H, 0 °C to rt, 2 h (quant.); (b) NH2-R,
Et3N, CH2Cl2, 0 °C to rt, 5 h (16%-Quant.); (c) carboxyethyltriphenylphosphonium
tribromide, THF, 0 °C to rt, 18 h (27–95%); (d) R0COOH, K2CO3, acetone, rt, 5 min
(43%-Quant. carried on crude); (e) AcOH, NH4OAc, 120 °C, 15 min (8–70%).
set of compounds (up to 5-fold in compound 26) and a correlation
between enzyme and cellular activity was observed. Kinase selec-
tivity was also maintained, exemplified by the lack of compounds
20 and 22 to inhibit PI4K
trations of 9 M. Importantly, the compounds showed no evidence
of cytotoxicity in replicon containing cells at concentrations up to
30 M, suggesting that a therapeutic window may be achievable
a and PI3 kinases a, b, and d up to concen-
l
oxyethyltriphenylphosphonium
tribromide
to
give
the
corresponding -bromoketones 14, which then underwent dis-
a
l
placement with various carboxylic acids to provide esters 15. As
the penultimate step, the displacement reaction proved to be a
useful point with which to introduce diversity, given the high
yields, lack of purification required, and wide availability of car-
boxylic acids. A subsequent simple cyclization with ammonium
acetate in acetic acid led to oxazoles 16.28
with this mode of inhibition of a host cell factor. Additionally,
the inhibitory effects of these compounds on HCV replication
extends to the GT1a replicon and the GT2a live virus settings as
well (Compound 19 HCV replicon 1a EC50 = 86 nM and GT2a JFH1
EC50 = 147 nM; Compound 26 HCV replicon 1a EC50 = 53 nM and
GT2a JFH1 EC50 = 383 nM).
Compounds were evaluated for inhibition of the PI4KIIIb
enzyme in a biochemical assay as well as for inhibitory activity
against HCV replication using a subgenomic GT1b replicon assay
(Table 2).29–31 With a structure close to that of the HTS hit com-
pound 1, we sought to increase potency of 5 against both the
PI4KIIIb enzyme as well as HCV in the GT1b replicon assay. Initial
modification of the 2-oxazole position (R0) highlighted a tolerabil-
ity for variation, providing further support to our docking model.
We envisioned this moiety to be somewhat solvent exposed how-
ever, and were consequently hopeful that introduction of a hetero-
atom would provide the basis for an additional interaction below
the hinge region. Interestingly, in this putative solvent exposed
region, some hydrophobic contact flanking the hinge binding
region is required for enzymatic potency (compounds 5 and 18)
as compared to unsubstituted oxazole 17. Despite this, neither
increasing bulk (compounds 19, 20, 21) nor introducing heteroat-
oms (22, 23) within this moiety provided any incremental
enhancement in enzymatic potency, therefore supporting the
hypothesis that this region of the molecule is solvent exposed.
The PI4KIIIb inhibitory potency was modestly enhanced within this
Further exploration of the scaffold revealed a requirement for
the sulfonyl moiety for potent PI4KIIIb inhibition (Table 3). Based
on our docking model, we envisioned both the O and NH of the sul-
fonamide to be engaging in significant interactions with the pro-
tein with the catalytic lysine and DFG loop respectively (Fig. 1).
To probe this hypothesis, the des-sulfonamide (27), sulfones (28)
and (29), and amide (30) analogs were synthesized. From this set
of compounds, PI4KIIIb IC50 values suggested a key role for the sul-
fonyl oxygens, where removal of the sulfonamide nitrogen did not
have a detrimental effect on activity, therefore suggesting that the
proposed interaction with Asp689 is either non-existent or not
critical for compound binding. Complete removal of the sulfon-
amide or replacement with an amide (30) led to significant loss
in PI4KIIIb inhibition. Substitution in this position is not limited
to hydroxylated alkyls, as aryl analog 31 also potently inhibits
PI4KIIIb. In general a correlation is observed between PI4IIIKb
and replicon activity and the window over cytotoxicity in replicon
containing cells is maintained.
In an effort to expand the breadth of this class of compounds to
investigate other heterocyclic cores, both the corresponding
