An unusual imine (NNC) alkylalumination reaction
Pingrong Wei and David Atwood*
Center for Main Group Chemistry, Department of Chemistry, North Dakota State University, Fargo, North Dakota 58105, USA
Addition of 3 equiv. of AlMe3 to a heptadentate Schiff-base
ligand made from salicylaldehyde and bis(2-aminoethyl)-
ethylenediamine (H3L1) results in an unusual alkylalumina-
tion of one of the imine bonds; addition of 2 equiv. of
B(OMe)3 or AlMe3 to one of these ligands leads to the
formation of bimetallic derivatives containing four- and five-
coordinate metals, respectively.
clear (Fig. 1). The formation of 1 follows similar reactions for
bimetallic salen derivatives.7 This is not the case for 2 for which
the 27Al NMR data indicates that only five-coordinate alumin-
ium is present (d 65.40). In the 1H NMR there are two Al–Me
shifts in a 1:2 ratio. This data can tentatively be attributed to the
structure shown in Scheme 1. Surprisingly, in reactions with 3
equiv. of the aluminium reagent, one of the NNC bonds
undergoes an unsual alkyalumination reaction in the formation
of trimetallic derivative 3 (Scheme 1, Fig. 2).
In the course of our explorations of group 13 Schiff-base chelate
complexes we have discovered an unusual imine (NNC)
alkylalumination reaction. Schiff-base ligands (and the salen
class, in particular) form a wide range of complexes with
transition1 and main-group metals.2 One of the reasons why
these ligands are so useful is because they do not undergo
further reactions after coordinating a metal. In fact, transition-
metal complexes of the reduced form of the salen ligand (the
salan class)3 are difficult to isolate because they dehydrogenate
back to the Schiff-base derivative when exposed to air.4
In turning our attention to ligands possessing multiple (more
than four) binding sites we examined those derived from the
condensation of 3 equiv. of salicylaldehyde (with H or But at the
2,4-positions, or Cl at the 4-position, of the aryl ring) with bis(2-
aminoethyl)ethylenediamine. The resulting ligands are denoted
H3L1, H3L2 and H3L3, respectively. We had intended to prepare
neutral bi- and tri-metallic derivatives of these ligands for
potential catalytic applications. Previously reported group 13
complexes with this5 and related systems6 have focused on
charged compounds useful in medicinal applications.
In the structure‡ one portion of the molecule coordinates an
AlMe2 unit by an oxygen and imine nitrogen, forming a six-
O(2)
O(3)
B(2)
O(1)
O(6)
N(4)
N(1)
O(5)
B(1)
O(7)
N(3)
N(2)
In the present work, two neutral bimetallic derivatives,
(HL2)[B(OMe)2]2 1 and L1AlMe(AlMe2) 2, could be prepared
in good yields using the appropriate stoichiometry (Scheme 1).†
The X-ray data for 1 was such that a full solution could not be
obtained. However, the overall morphology of the molecule is
O(4)
Fig. 1 Preliminary structure of 1 demonstrating the overall morphology of
