S. Rubinsztajn et al. / Journal of Catalysis 379 (2019) 90–99
91
has recently been found that the reaction of phenyldimethylsilane
with tetrabutoxygermane in the presence of TPFPB leads exclu-
sively to the reactive group exchange i.e. to the substitution of
alkoxy group at germanium with hydrogen [31].
sample to remove traces of water. The presence of dry borane
was confirmed by recording 19F NMR spectra. The desired amount
of silicon or germanium reagent was then introduced, typically
about a 50-fold molar excess, compared to the borane. The NMR
tube was sealed and 19F NMR spectra were taken at desired time
intervals. The chemical shifts were reported relative to the CFCl3
standard.
The rapid increase in the use of hydrosilanes and hydroger-
manes in combination with catalytic amounts of B(C6F5)3 in syn-
thetic chemistry poses the question about the chemical stability
of these systems. In our experimental works, we observed that
the catalytic ability of TPFPB is decreasing over time in the pres-
ence of reagents containing SiH and GeH moieties. Synthetic che-
mists should be conscious of the reactions of the borane with
hydrosilanes and hydrogermanes and should know to what extent
they affect catalytic activity of TPFPB. The knowledge on the reac-
tions between TPFPB and SiH functional compounds is scarce. It is
known that the reaction leads to the exchange of one of the aro-
matic groups attached to boron to hydrogen. This reaction was
used for the generation of HB(C6F5)2, which was applied further
as hydroboration agent [32]. Theoretical calculation gave the free
energy barrier to this reaction of 27.8 kcal/mol [33]. To the best
of our knowledge, kinetic studies of reactions of B(C6F5)3 with Si-
H reagents and any studies of the interaction of TPFPB with GeH
reagents have not yet been reported. The aim of our research
was to gain more knowledge about reactions of B(C6F5)3 with
hydrosilanes and hydrogermanes, which result in a strong reduc-
tion of its catalytic activity.
2.4. Kinetic studies by UV spectroscopy
A mother solution of tris(pentafluorophenyl)borane in dry
toluene 0.033 mol/L was prepared and stored in dry box. A suitable
amount of this solution was diluted with dry toluene to obtain the
final B(C6F5)3 solution at a concentration of about 5.5 ꢁ 10ꢂ4 mol/L.
0.3 mL of the final solution was transferred to 1 mm thick UV
quartz cuvette. In the case of the germanium reagent, an excess
of dimethylphenylsilane was introduced to remove borane-bound
water. The presence of water-free B(C6F5)3 was confirmed by the
appearance of a strong UV band with a maximum at 305 nm. The
desired amounts of PhMe2SiH, Et3SiH or Et3GeH were then added
using a Hamilton syringe. The cuvette was closed with stopcock,
removed from dry box and placed in the Peltier temperature-
controlled changer set at a constant temperature. UV spectra were
recorded in a desired time interval using a UV–VIS spectrometer,
Specord S600 Zeiss Jena, Analytik Jena AG, Jena Germany, equipped
with Peltier temperature-controlled 8-cell changer.
2. Experimental section
2.5. Theoretical calculations
2.1. Materials
All quantum mechanical calculations were performed using
the Gaussian 16 suite of programs [34]. Geometries of the
reagents and complexes were optimized using the hybrid B3LYP
density functional [35] corrected for dispersion interactions using
Grimme GD3 empirical term [36], with Def2-SVP basis set [37] in
the gas phase. All stationary points were identified as stable min-
ima by frequency calculations. The vibrational analysis provided
thermal enthalpy and entropy corrections at 298 K within the
rigid rotor/harmonic oscillator/ideal gas approximation [34].
Thermochemical corrections were scaled by a factor of 0.985
[38]. More accurate single point electronic energies were
obtained using the B3LYP functional, including Grimme GD3 dis-
persion correction [36], with the larger Def2-TZVP basis set for
the Def2-SVP optimized geometries [39]. This level of theory is
denoted as B3LYP-GD3/Def2TZVP//Def2SVP. Integration grid was
set to ultrafine. The basis set superposition error (BSSE) has been
neglected since it is small (<0.5 kcal/mol) and the method of its
estimation [40] is not accurate enough to precisely calculate weak
interactions.
Triethylsilane and dimethylphenylsilane were products of
Aldrich, declared purities were 99% and ꢀ98% respectively. Tri-
ethylgermane, declared purity 97%, 1,1,3,3-tetramethyldisiloxane,
declared purity 99%, were purchased from ABCR. Their purity
was checked by gas chromatography and were used as received.
Poly(methylhydrosiloxane), Catalog #: AB112087, viscosity 15-
25cSt, molecular weight about 2000 g/mol, was purchased from
ABCR. Tris(pentafluorophenyl)borane was
a product of TCI,
declared purity > 97%. Its purity was confirmed by 19F NMR spec-
troscopy. Toluene HPLC Plus, a product of JT Baker, purity 99.9%,
was additionally dried on column system NBSPS of dry-box
MBRAVN model UNILAB. Toluene d8, a product of Deutero GmbH
of declared purity 99.5%, was stored over 3 Å molecular sieves.
2.2. Analytical methods
19F NMR spectra were registered on a Bruker AV III 500 MHz
spectrometer working at 470.54 MHz. Gas chromatography-mass
spectrometry GC/MS analysis was carried out using a Shimadzu
QP2010 ultra apparatus equipped with Zebron ZB-5MSi Capillary
3. Results and discussions
GC column (30 m ꢁ 0.25 mm ꢁ 0.25
lm). Carrier gas was helium.
3.1. Studies by 19F NMR spectroscopy
Temperature program was: hold at 50 °C for 3 min, heating to
250 °C at a rate 10 °C /min, hold at 250 °C for 20 min. Quadrupole
mass spectrometer, Shimadzu QP2010 Ultra, with electron ioniza-
tion was connected to the GC system. UV spectra were recorded
using a UV–VIS spectrometer, Specord S600 Zeiss Jena, Analytik
Jena AG, Jena Germany, equipped with Peltier temperature-
controlled 8-cell changer. A 1 mm quartz cuvette with a Rotaflo
stopcock was used.
Studies of B(C6F5)3 reaction with silyl and germyl hydrides were
carried out using dimethylphenylsilane, triethylsilane and triethyl-
germane as model reagents and toluene as solvent. 19F NMR spec-
troscopy is an effective method for the investigation of the
chemical transformation of fluoroarylboranes [41–43]. The reac-
tions between borane and PhMe2SiH, Et3SiH and Et3GeH were fol-
lowed directly in an NMR tube at a constant temperature. It is
known that the presence of water strongly reduces the catalytic
activity of TPFPB in various reactions, such as dehydrocarbonate
condensation, ring-opening polymerization of cyclic siloxanes by
a hydride transfer mechanism, and oligomerization of SiH func-
tional siloxanes due to the formation of strong hydrates [44,45].
2.3. Studies by 19F NMR
The solutions of the borane in toluene d8 were prepared in dry-
box and were placed in an NMR tube purged with dry nitrogen.
Small excess of 1,1,3,3-tetramethyldisiloxane was added to the
