SCIENCE CHINA
Chemistry
August 2014 Vol.57 No.8: 1144–1149
doi: 10.1007/s11426-014-5137-4
• ARTICLES •
Synthesis and characterization of titanium complexes bearing
sulfoxide groups and their catalytic behaviors in ethylene
homo- and copolymerization
WANG Zheng, PENG Ai-Qing, SUN Xiu-Li & TANG Yong*
State Key Laboratory of Organometallic Chemistry, Shanghai Institute of Organic Chemistry, Chinese Academy of Sciences,
Shanghai 200032, China
Received February 28, 2014; accepted March 21, 2014; published online July 1, 2014
Titanium complexes derived from 2,4-di-tert-butyl-6-((2-(arylsulfinyl)phenylimino)methyl)phenol are designed and synthe-
sized. X-ray diffraction studies reveal that the complexes adopt distorted octahedral geometry with O(phenol), N(imine), and
O(sulfoxide) coordinated with titanium. Combined with modified methylaluminoxane(MMAO), the complexes exhibit moder-
ate to high activity to afford polyethylene even at 120 °C under 1 atm ethylene pressure. The complexes also show excellent
capability in copolymerization of ethylene with either 1-hexene or norbornene. Results indicate that the introduction of sulfox-
ide groups could open the space around central metal and favors the insertion of bulky comonomers.
sulfoxide, catalyst, synthesis, ethylene polymerization, copolymerization
eton [2534]. In this system, strong side-arm effects on cat-
alytic efficiency were observed. When the sidearm was SR,
SeR, or PPh2, high activity could be obtained whereas low
activity was always observed when OR was used as a
sidearm (Scheme 1). However, a less-hindered R group en-
hanced activity levels as well as -olefin incorporation [25,
26]. To understand the different effects of O-pendant and
S-pendant groups on activity, we developed single- crystal
titanium complexes 1a and 1b. As shown in Figure 1, the O
atom in the pendant group of complex 1a adopted sp2 hy-
bridization, whereas an sp3-hybridized S atom was observed
in compound 1b. The phenyl group in complex 1b deviated
from the [ONS] plane, but the phenyl group of complex 1a
was at the [ONO] plane (177.6(5)° for N–Ti–O–C(22)
compared to 107.51(13)° for N–Ti–S–C(22) in 1b). Due to
the hybridization pattern of the donor atom as well as the
bond lengths of TiS and TiO1, the space around the tita-
nium was much more open and favored the coordination
and insertion of ethylene by replacement of the side- arm
O-atom in compound 1a with S-atom in compound 1b.
1 Introduction
Many efforts have been made to develop well-defined or-
ganometallic species as homogeneous olefin polymerization
catalysts for the production of a variety of polymers that
have novel uses and properties [121]. Of the catalysts de-
veloped, ligand scaffolds have shown significant influence
in stabilizing polymerization-active metal centers and in
controlling their behaviors of olefin polymerization [2224].
For example, the introduction of bulky imine groups in -
diimine, salicylaldemine, and pyridine diimine backbones
allows the development of active late-transition metal cata-
lysts [1013]. In our previous study on olefin polymeriza-
tion catalysts, we developed a family of [ONX]titanium
complexes based on regulation of the electronic and steric
properties of the active species by introducing a ped-
ant-coordination group (side-arm) into a simple ligand skel-
Dedicated to Professor Qian Changtao on the occasion of his 80th birthday.
*Corresponding author (email: tangy@sioc.ac.cn)
© Science China Press and Springer-Verlag Berlin Heidelberg 2014
chem.scichina.com link.springer.com

Wang Z, et al. Sci China Chem August (2014) Vol.57 No.8
1145
structures were solved by direct methods and refined on F2
by full-matrix least squares techniques with anisotropic
thermal parameters for non-hydrogen atoms. Hydrogen at-
oms were placed at the calculated positions and were in-
cluded in the structure calculation without further refine-
ment of the parameters. All calculations were carried out
using the SHELXS-97 program.
Scheme 1 Activity comparison between complexes bearing –OPh (1a)
and –SPh (1b) side-arm [26].
2.2 Synthesis of the ligands and complexes
(E)-2,4-di-tert-butyl-6-((2-(phenylsulfinyl)phenylimino)meth-
yl)phenol (7a)
A mixture of the aniline 6a (6.2 g, 28.5 mmol) and
3,5-di-tert-butylsalicylaldehyde (6.7 g, 28.5 mmol) in etha-
nol (50 mL) in the presence of a catalytic amount of acetic
acid (3 mL) was refluxed until the reaction was complete.
The mixture was cooled to room temperature and the col-
lected yellow solid was washed with cool ethanol to give
Figure 1 Molecular structures of complexes 1a and 1b.
1
pure product. Yield: 8.72 g (71%). H NMR (300 MHz,
CDCl3, ppm): δ 12.81 (s, 1 H), 8.45 (s, 1 H), 8.16–8.17 (m,
1H), 7.68–7.12 (m, 10 H), 1.50 (s, 9 H), 1.31 (s, 9 H). 13C
NMR (300 MHz, CDCl3): δ 165.1, 158.0, 145.7, 145.0,
140.9, 138.9, 137.2, 131.9, 131.1, 129.1, 129.1, 127.4,
127.4, 126.0, 124.5, 118.0, 117.8, 35.1, 34.1, 31.4, 29.3.
Anal. calcd. for C27H31NO2S: C 74.79, H 7.21, N 3.23.
Found: C 74.40, H 7.22, N 3.01.
In this work, we designed and synthesized ligand 7a- and
7b-bearing sulfoxide groups to further elaborate the influ-
ence of the electronic and steric properties of the pendant
group on the catalyst behaviors during ethylene polymeriza-
tion. The corresponding titanium complexes of 7b showed
good activity even at 120 °C upon activation with modified
methyl aluminominato (MMAO). 1-Hexene and norbornene
(NBE) could incorporate into polyethylene in more than 30
mol%.
(E)-2,4-di-tert-butyl-6-((2-(2,6-diisopropylphenylsulfinyl)ph-
enylimino)methyl)phenol (7b)
Using a similar procedure to 7a, pure 7b was obtained.
Yield: 2.82 g (67%). 1H NMR (300 MHz, CDCl3, δ ppm): δ
11.91 (s, 1 H), 7.96–7.98 (m, 2 H), 7.27–7.45 (m, 3 H),
7.00–7.09 (m, 2H), 6.85–6.91 (m, 2 H), 3.75–3.70 (m, 2 H),
1.42 (s, 9 H), 1.30 (s, 9 H), 0.96 (d, J = 6.6 Hz, 12 H). 13C
NMR (75 MHz, CDCl3): δ 166.7, 157.7, 150.7, 147.8, 140.6,
136.9, 137.0, 132.0, 131.1, 128.6, 127.3, 126.4, 125.7,
124.7, 120.6, 117.9, 35.0, 34.0, 31.3, 29.4, 28.6, 24.4, 23.2.
Anal. calcd. for C33H43NO2S: C 76.55, H 8.37, N 2.71.
Found: C 76.58, H 8.29, N 2.71.
2 Experimental
2.1 General information
All manipulations were carried out using standard Schlenk
technique or glove-box under nitrogen or argon. Toluene,
THF, hexane, and dichloromethane were purified by an MB
SPS-800 (MBRAUN Company, Germany) prior to use.
Modified methylaluminoxane (MMAO) was purchased
from Akzo Chemical (Holland) as heptane solution (1.88
M). Molecular weights (Mw and Mn) and molecular-weight
distributions (Mw/Mn) of polymers were determined using a
Waters Alliance GPC 2000 series (WATERS, USA) at
135 °C (using polystyrene calibration, 1,2,4-trichloroben-
zene as solvent at a flow rate of 0.92 mL/min). 1H NMR and
13C NMR spectra were recorded on a Varian XL-300 MHz
and Varian XL-400 MHz spectrometer (VARIAN, USA).
Elemental analysis was performed by the Analytical Labor-
atory of Shanghai Institute of Organic Chemistry (CAS).
13C NMR data for polymers were obtained using CDCl3 as
the solvent at 25 °C. X-ray crystallographic data were col-
lected at 20 °C on a Bruker SMART diffractometer with
graphite-monochromated Mo-Kα radiation ( = 0.71073 Å).
The SADABS absorption correction was applied. The
[(E)-2,4-di-tert-butyl-6-((2-(phenylsulfinyl)phenylimino)-
methyl) phenol] Ti(IV)Cl3 (8a)
To a solution of TiCl4 (0.56 mL, 5.0 mmol) in toluene (30 mL)
was added dropwise a solution of 7a (2.0 g, 4.6 mmol) in tolu-
ene (30 mL) over 10 min at 78 ºC. The resulting mixture was
allowed to warm to room temperature and stirred for 3 h. The
generated dark-red solids were collected and washed with tol-
uene (3 × 20 mL). Pure product was recrystallized in toluene at
1
30 ºC. Yield: 2.0 g (74%). H NMR (400 MHz, CDCl3, δ
ppm): 8.46 (s, 1 H), 7.99–7.24 (m, 10 H), 6.48–6.46 (m, 1H),
1.61 (s, 9 H), 1.36 (s, 9 H) ppm. 13C NMR (100 MHz, CDCl3,
δ ppm): δ 168.1, 161.1, 150.1, 146.4, 137.0, 135.4, 134.5,
133.2, 133.1, 131.9, 130.6, 129.6, 128.2, 127.3, 126.1, 125.0,
35.4, 34.7, 31.2, 31.1, 29.8. Anal. calcd. for C27H30Cl3NO2STi:

1146
Wang Z, et al. Sci China Chem August (2014) Vol.57 No.8
C 55.26, H 5.15, N 2.39. Found: C 55.87, H 5.39, N 2.11.
benzenethiol 3a and 3b, which were prepared according to
the procedures in literature [26]. Oxidation of 5 readily
generated 2-(phenylsulfinyl)aniline 6. Refluxing the mixture
of 6 and the aldehyde for several hours in ethanol resulted
in the formation of 7, which was recrystallized from cool
EtOH to give the pure product as yellow solid. Complexes
8a and 8b were obtained by treating ligand 7 with TiCl4 in
toluene as dark-red solid, which was purified from recrys-
tallization in toluene or CH2Cl2 at 30 ºC (Scheme 3).
[(E)-2,4-di-tert-butyl-6-((2-(2,6-diisopropylphenylsulfinyl)-
phenylimino)methyl)phenol] Ti(IV)Cl3 (8b)
By employing a similar procedure to that of 8a, 8b was ob-
tained as dark-red solid. Pure product was obtained from
recrystallization in CH2Cl2. Yield: 2.0 g (77%). 1H NMR
(300 MHz, CDCl3, δ ppm): δ 8.45 (s, 1 H), 7.26–7.77 (m, 8
H), 6.80–6.84 (m, 1H), 3.61–3.66 (m, 1 H), 3.48–3.52 (m, 1
H), 1.61 (s, 9 H), 1.42 (d, J = 3.9 Hz, 3 H), 1.40 ( d, J = 4.8
Hz, 3H), 1.35 (s, 9 H), 1.17 (d, J = 5.4 Hz, 3 H), 0.98 (d, J =
5.1 Hz, 3 H). 13C NMR (100 MHz, CDCl3, δ ppm): δ
167.9, 161.7, 155.2, 152.9, 150.4, 145.9, 136.8, 135.7,
134.3, 133.0, 130.5, 130.0, 128.7, 128.0, 127.0, 126.99,
125.5, 125.1, 124.1, 35.4, 34.6, 31.2, 31.0, 30.6, 29.8, 25.9,
25.2, 23.6, 22.6 ppm. Anal. calcd. for C33H42Cl3NO2STi: C
59.07, H 6.31, N 2.09. Found: C 59.30, H 6.28, N 1.82.
1
Complexes 8a and 8b were characterized by H and 13C
NMR and elemental analysis. Crystals of 8a and 8b were
developed from toluene/CH2Cl2 for X-ray structure deter-
mination. As shown in Figures 2 and 3, complexes 8a and
8b adopted a distorted octahedral coordination around the
titanium, similar to the parental complexes in 1 [26]. Three
chlorines appeared in a mer-position, which could facilitate
olefin insertion. Phenolate, imine, and sulfoxide fragment in
the ligands coordinated with titanium in both cases. The
TiO1 bond in complex 8a (2.013(4) Å) was significantly
shortened compared with the corresponding complex 1a
bearing ether appending group (2.249(5) Å) [26]. Bond
lengths of TiO2 and TiN1 in 8a were 1.793(4) and
2.236(5) Å, respectively. The bond angle of O1TiO2 in
8a was larger than in the corresponding complex 1a that
bore ether appending group (163.66(18) vs. 158.32(17)
[26]. In the molecular structure of 8b, similar bond lengths
and bond angles to those of 8a were observed.
2.3 General procedure of ethylene (co)polymerization
A flame-dried Schlenk flask was charged with ethylene and
placed in an oil bath at the polymerization temperature. The
desired amount of freshly distilled dry toluene was trans-
ferred into the flask and saturated with ethylene, followed
by a comonomer in the case of copolymerization. MMAO
was injected into the flask via a syringe and the mixture was
stirred for 5 min. Then the catalyst precursor in toluene was
added. After the polymerization was quenched with acidi-
fied ethanol, the mixture was poured into acidified ethanol
(300 mL, 10 vol% HCl in ethanol). The precipitated poly-
mer was collected, washed with ethanol, and dried at 50 ºC
under vacuum until it maintained a constant weight.
3.2 Ethylene homo-polymerization
Complex 8a was first used as a model to investigate the
ethylene polymerization in the presence of modified methyl
aluminoxane (MMAO) for optimizing the conditions. It is
worthwhile to note that 8a showed good thermostability. As
shown in Table 1, the highest activity of 5.3 × 105
g/mol[Ti] h atm was achieved at 60 ºC when 8a/MMAO
polymerized ethylene in toluene (entry 3). This activity was
influenced by the polymerization temperature. At 30 ºC, the
activity was 1.9 × 105 g/mol[Ti] h atm, which increased to 4.9
× 105 g/mol[Ti] h atm at 80 ºC (entry 6). Decalin was also a
3 Results and discussion
3.1 Synthesis and characterization of ligands and com-
plexes
The synthesis of ligands and complexes is summarized in
Scheme 2. Thioether 5a and 5b were readily available from
Scheme 2 Synthesis of ligand 7.

Wang Z, et al. Sci China Chem August (2014) Vol.57 No.8
1147
Table 1 Effect of reaction temperature on ethylene polymerization results
using catalyst 8a in toluene a)
T b)
(oC)
30
Time
(min)
10
d,e)
e)
Entry
Solvent
Activity c) Mw
Mw/Mn
1
2
toluene
toluene
toluene
toluene
toluene
toluene
toluene
toluene
toluene
decalin
decalin
decalin
1.9
4.6
5.3
2.7
4.8
4.9
3.2
3.2
2.4
8.0
5.0
2.2
20.2
9.5
2.0
1.6
1.7
2.9
1.5
1.7
1.7
1.8
2.0
2.7
1.9
1.7
50
60
10
10
10
10
10
20
30
60
10
10
10
3
4 f)
7.8
19.8
5.6
3.2
3.8
4.7
6.5
1.8
0.7
0.5
60
5
70
Scheme 3 Synthesis of titanium(IV) complexes 8.
6
80
7
60
8
60
9
60
10
11
12
80
100
120
a) Conditions: 8a (3 µmol) in 30 mL solvent; ethylene pressure, 0.1
MPa; reaction time, 10 min; cocatalyst, MMAO 3.2 mL (1.88 mmol/mL in
heptane). b) Temperature of the bath. c) 105 g/mol[Ti] h atm. d) 104 g/mol.
e) Determined by GPC. f) 8b (3 µmol) was used instead of 8a.
Figure 2 Molecular structure of 8a. Hydrogen atoms were omitted for
clarity. Selected bond lengths (Å) and angles (o): Ti1O1, 2.013(4);
Ti1O2, 1.793(4); O1S1, 1.542(4); Ti1N1, 2.236(5); O2TiO11,
63.66(18); C13S1C14, 102.9(3).
Figure 4 The ethylene polymerization character of 8a/MMAO. Condi-
tions: 3 μmol of catalyst 8a in 30 mL solvent; ethylene pressure, 0.1 MPa;
cocatalyst, MMAO 3.2 mL (1.9 mmol/mL in heptane).
Figure 3 Molecular structure of 8b. Hydrogen atoms were omitted for
clarity. Selected bond lengths (Å) and angles (o): Ti1O1, 2.004(3);
Ti1O2, 1.813(3); O1S1, 1.542(3); Ti1N1, 2.244(3); O2TiO1,
163.36(12); C6S1C12, 102.56(19).
10000, probably due to rapid chain transfer during
polymerization process at high temperature [35]. As shown
in Table 1, the molecular weight distribution was narrow,
similar to that of a single-site catalyst. Under the same
polymerization conditions, the activity of 8b was halved
relative to 8a and the molecular weight of the resulting
polymer from 8b/MMAO was almost doubled. These re-
sults could be ascribed to steric effects.
The cocatalyst/catalyst molar ratio (Al/Ti ratio) had little
effect on the polymerization activity (Table 2). For example,
reducing the Al/Ti ratio to 1000, the activity was nearly
maintained (5.3 × 105 vs. 4.5 × 105 g/mol[Ti] h atm, entries
2 and 4). The activity was 4.1×105 g/mol[Ti] h atm when
the ratio was further reduced to 500 (entry 1).
suitable solvent for the polymerization. For example, an
activity of 8.0 × 105 g/mol[Ti] h atm was achieved at 80 ºC
(entry 10) and was still very active even when the tempera-
ture was increased to 120 ºC (2.2 × 105 g/mol[Ti] h atm,
entry 12) under 1 atm of ethylene pressure (in spite of the
reduced solubility of ethylene at 120 ºC). The polymer yield
was increased when the polymerization time was prolonged
to 1 h, which indicated good catalyst thermostability (Figure
4).
The molecular weight of the polymer reduced sharply
when temperature was increased. For example, Mw in tolu-
ene decreased from 20.2 × 104 g/mol at 30 ºC to 3.2 × 104
g/mol at 80 ºC. When the polymerization proceeded in de-
calin at above 100 ºC, the molecular weights were below
We also examined 8a in the ethylene/1-hexene copoly-
merization (Table 3) and good activities were observed in
all cases. The 1-hexene incorporation proved to be influ-
enced by its initial concentration. For example, the copoly-
merization produced copolymer in an activity of 3.2 × 105

1148
Wang Z, et al. Sci China Chem August (2014) Vol.57 No.8
g/mol[Ti] h atm with 16.6 mol% incorporation in the case of
1.5 mL of 1-hexene. However, when 10 mL of 1-hexene
was added, the activity of 1.6 × 105 g/mol[Ti] h atm and
38.8 mol% incorporation was achieved (entries 3 vs. 4).
8b/MMAO was also active in the ethylene/1-hexene co-
polymerization but with low incorporation compared to 8a
(entry 5).
Complex 8a also proved to be suitable for ethylene/
norbornene (NBE) copolymerization although NBE was a
steric comonomer (Table 4). As summarized in Table 4,
moderate activity and high NBE incorporation (25–32
mol%) could be obtained under the optimized conditions
(entries 1–4). The copolymerization behaviors of the cata-
lysts and the chain structures of the copolymers were af-
fected by both the initial concentration of NBE and reaction
time. Higher initial NBE concentration favored the incor-
poration (entries 3 and 4). The incorporation of NBE had
little influence when the reaction time was prolonged from
10 to 60 min.
4 Conclusions
In summary, titanium complexes bearing sulfoxide as side-
arm were synthesized and fully characterized. In the pres-
ence of MMAO, the complexes exhibited good activity in
the polymerization of ethylene and copolymerization of
ethylene/1-hexene, ethylene/NBE, which was different than
the corresponding titanium complexes 1a bearing an ether
side-arm. Future study will focus on exploring the here-
oatom effects.
This work was supported by the National Natural Sciences Foundation of
China (21174159, 21121062), the Science and Technology Commission of
Shanghai Municipality, and the Chinese Academy of Sciences.
1
Alt HG, Köppl, A. Effect of the nature of metallocene complexes of
group IV metals on their performance in catalytic ethylene and pro-
pylene polymerization. Chem Rev, 2000, 100: 1205–1221
Coates GW. Precise control of polyolefin stereochemistry using sin-
gle-site metal catalysts. Chem Rev, 2000, 100: 1223–1252
Resconi L, Cavallo L, Fait A, Piemontesi F. Selectivity in propene
polymerization with metallocene catalysts. Chem Rev, 2000, 100:
1253–1345
2
3
Table 2 Effect of Al/Ti ratio on ethylene polymerization results using
catalyst 8a a)
d,e)
e)
Entry
Al/Ti b)
PE (mg)
208
Activity c)
Mw
11.3
Mw/Mn
1.8
4
5
6
Kaminsky W. Trends in polyolefin chemistry. Macromol Chem Phys,
2008, 209: 459–466
1
2
3
4
500
4.1
1000
1500
2000
225
4.5
7.6
6.7
7.8
1.7
Chen EYX. Coordination polymerization of polar vinyl monomers by
single-site metal catalysts. Chem Rev, 2009, 109: 5157–5214
Makio H, Fujita T. Development and application of FI catalysts for
olefin polymerization: unique catalysis and distinctive polymer for-
mation. Acc Chem Res, 2009, 42: 1532–1544
215
4.3
1.6
267
5.3
1.7
a) Conditions: 8a (3 µmol) in 30 mL toluene; ethylene pressure, 0.1
MPa; reaction time, 10 min; temperature of the bath, 60 ºC. b)Cocatalyst,
MMAO (1.88 mmol/mL in heptane). c) 105 g/mol[Ti] h atm. d) 104 g/mol.
e) Determined by GPC.
7
8
9
Nomura K. Syndiospecific styrene polymerization and ethylene/sty-
rene copolymerization using half-titanocenes: ligand effects and some
new mechanistic aspects. Catal Surv Asia, 2010, 14: 33–49
Makio H, Terao H, Iwashita A, Fujita T. FI catalysts for olefin
polymerization—A comprehensive treatment. Chem Rev, 2011, 111:
2363–2449
Redshaw C, Tang Y. Tridentate ligands and beyond in group IV met-
al α-olefin homo-/co-polymerization catalysis. Chem Soc Rev, 2012,
41: 4484–4510
Table 3 Results of ethylene/1-hexene copolymerization using catalyst 8a a)
1-Hexene
(mL)
t b)
Incorp.
e,f)
f)
Entry
Activity d) Mw
Mw/Mn
(min) (mol%) c)
1
2
1.5
1.5
1.5
10
60
30
10
10
10
11.0
13.1
16.6
38.8
0.6
1.0
1.3
3.2
1.6
2.2
7.9
10.1
2.0
1.8
3.7
3.3
3.8
10 Ittel SD, Johnson LK, Brookhart M. Late-metal catalysts for ethylene
homo- and copolymerization. Chem Rev, 2000, 100: 1169–1203
11 Guan Z. Control of polymer topology by chain-walking catalysts.
Chem Eur J, 2002, 8: 3086–3092
12 Gibson VC, Spitzmesser SK. Advances in non-metallocene olefin
polymerization catalysis. Chem Rev, 2003, 103: 283–315
13 Gibson VC, Redshaw C, Solan GA. Bis(imino)pyridines: surprisingly
reactive ligands and a gateway to new families of catalysts. Chem
Rev, 2007, 107: 1745–1776
3
16.3
9.0
4
5 g)
1.5
14.3
a) Conditions: 8a (3 µmol) in 30 mL toluene; ethylene pressure, 0.1
MPa; temperature of the bath, 50 ºC; cocatalyst, MMAO 3.2 mL (1.88
mmol/mL in heptane); b) Reaction time. c) Determined by 13C NMR spec-
troscopy, mol%. d) 105 g/mol[Ti] h atm. e) 104 g/mol. f) Determined by
GPC. g) 8b (3 µmol) in 30 mL of toluene.
14 Boardman BM, Bazan GC. α-Iminocarboxamidato nickel complexes.
Acc Chem Res, 2009, 42: 1597–1606
15 Nakamura A, Ito S, Nozaki K. Coordination-insertion copolymeriza-
tion of fundamental polar monomers. Chem Rev, 2009, 109: 5215–
5244
16 Yao ZJ, Jin GX. Transition metal complexes based on carboranyl
ligands containing N, P, and S donors: synthesis, reactivity and ap-
plications. Coord Chem Rev, 2013, 257: 2522–2535
17 Hou Z, Wakatsuki Y. Recent developments in organolanthanide
polymerization catalysts. Coord Chem Rev, 2002, 231: 1–22
18 Tang XY, Wang YX, Liu SR, Liu JY, Li YS. Monochloro non-
bridged half-metallocene-type zirconium complexes containing
phosphine oxide-(thio)phenolate chelating ligands as efficient eth-
ylene polymerization catalysts. Dalton Trans, 2013, 42: 499–506
19 Hu T, Tang LM, Li XF, Li YS, Hu NH. Synthesis and ethylene
Table 4 Results of ethylene/NBE copolymerization using catalyst 8a a)
NBE
(mmol)
10
Incorp.
(mol%) c)
22.2
e, f)
f)
Entry
t (min) b)
Activity d) Mw
Mw/Mn
1
2
3
4
60
30
10
10
3.6
3.6
6.0
8.0
3.3
5.4
3.0
3.8
3.0
4.2
10
10
20
23.4
20.7
30.4
7.7
5.4
a) Conditions: 8a (12 µmol) in 30 mL toluene; ethylene pressure, 0.1
MPa; temperature of the bath, 50 ºC; cocatalyst, MMAO 6.4 mL (1.88
mmol/mL in heptane); b) Reaction time. c) Determined by 13C NMR spec-
troscopy, mol%. d) 104 g/mol[Ti] h atm. e) 104 g/mol. f) Determined by
GPC.

Wang Z, et al. Sci China Chem August (2014) Vol.57 No.8
1149
polymerization activity of a novel, highly active single-component
binuclear neutral nickel(II) catalyst. Organometallics, 2005, 24:
2628–2632
Tang Y, Xie Z, Bu SZ, Qian C. Copolymerization of ethylene with
cycloolefins by titanium complexes containing tridentate [ONSR]
ligands. J Polym Sci Part A: Polym Chem, 2008, 46: 2807–2819
28 Yang XH, Liu CR, Wang C, Sun XL, Guo YH, Wang XK, Wang Z,
Xie Z, Tang Y. [ONSR]TiCl3-catalyzed copolymerization of eth-
ylene with functionalized olefins. Angew Chem Int Ed, 2009, 48:
8099–8102
29 Yang XH, Wang Z, Sun XL, Tang Y. Synthesis, characterization, and
catalytic behaviours of β-carbonylenamine-derived [ONS]TiCl3
complexes in ethylene homo- and copolymerization. Dalton Trans,
2009, 41: 8945–8954
20 Xu T, Mu Y, Gao W, Ni J, Ye L, Tao Y. Highly active half-metallo-
cene chromium(III) catalysts for ethylene polymerization activated by
trialkylaluminum. J Am Chem Soc, 2007, 129: 2236–2237
21 Liu FS, Hu HB, Xu Y, Guo LH, Zai SB, Song KM, Gao HY, Zhang
L, Zhu FM, Wu Q. Thermostable α-diimine nickel(II) catalyst for
ethylene polymerization: effects of the substituted backbone structure
on catalytic properties and branching structure of polyethylene.
Macromolecules, 2009, 42: 7789–7796
22 Qiao YL, Hu P, Jin GX. Syntheses, characterization and ethylene
polymerization of half-sandwich group IV metal complexes with tri-
dentate [O,N,S] ligands. Chin J Polym Sci, 2013, 31: 760–768
23 Shi XC, Jin GX. Synthesis and characterization of nickel(II) and pal-
ladium(II) complexes based on tridentate [N–NP] and [N–NS] lig-
ands and their applications in norbornene polymerization. Organo-
metallics, 2012, 31: 4748−4754
30 Yang XH, Sun XL, Han FB, Liu B, Tang Y, Wang Z, Gao ML, Xie Z,
Bu SZ. One-pot screening of titanium catalysts for ethylene polymer-
ization. Organometallics, 2008, 27: 4618–4624
31 Wang X, Sit MM, Sun J, Tang Y, Xie Z. Synthesis, structure and
ethylene polymerization behavior of group 4 metal complexes bear-
ing salicylaldaminato ligands with appended donor functionality.
Acta Chim Sinica, 2012, 70: 1909–1916
24 Hu P, Qiao YL, Wang JQ, Jin GX. Syntheses, characterization, and
ethylene polymerization of titanium complexes with double-duty tri-
dentate [ONN] ligands. Organometallics, 2012, 31: 3241−3247
25 Hu WQ, Sun XL, Wang C,Gao Y, Tang Y, Shi LP, Xia W, Sun J,
Dai HL, Li XQ, Yao XL, Wang XR. Synthesis and characterization
of novel tridentate [NOP] titanium complexes and their application to
copolymerization and polymerization of ethylene. Organometallics,
2004, 23: 1684–1688
26 Wang C, Ma Z, Sun XL, Gao Y, Guo YH, Tang Y, Shi LP. Synthesis
and characterization of titanium(IV) complexes bearing monoanionic
[ONX] (X = O, S, Se) tridentate ligands and their behaviors in eth-
ylene homo- and copolymerizaton with 1-hexene. Organometallics,
2006, 25: 3259–3266
32 Wan DW, Chen Z, Gao YS, Shen Q, Sun XL, Tang Y. Synthesis and
characterization of tridentate [ON(H)X] titanium complexes and
their applications in olefin polymerization. J Polym Sci Part A:
Polym Chem, 2013, 51: 2495–2503
33 Chen Z, Li JF, Tao WJ, Sun XL, Yang XH, Tang Y. Copolymeriza-
tion of ethylene with functionalized olefins by [ONX] titanium com-
plexes. Macromolecules, 2013, 46: 2870–2875
34 Xu C, Chen Z, Ji G, Sun XL, Li JF, Tang Y. Synthesis, characteriza-
tion, and catalytic behaviors of β-carbonylenamine-derived metal
complexes (M = Ti, Zr) in styrene polymerization. J Organomet
Chem, 2014, 761: 142–146
35 No C=C double bond in the (co)polymers are observed by 13C NMR
1
and H NMR studies. The polymer chain may transfer to aluminum
27 Gao ML, Sun XL, Gu YF, Yao XL, Li CF, Bai JY, Wang C, Ma Z,
species as the Mw decreased when increasing the amount of MMAO.
TANG Yong received his Ph.D. degree in 1996 at Shanghai Institute of Organic Chemistry, Chinese
Academy of Sciences, under the supervision of Prof. Yaozeng Huang and Prof. Lixin Dai. After
three years’ postdoctoral research in the USA, he joined Shanghai Institute of Organic Chemistry,
CAS, in 1999. He was promoted to a full Professor in 2000. His current research interests are the
development of new synthetic methodologies and the design and synthesis of olefin polymerization
catalysts.
